DTC P0118: ECT Sensor Circuit High Voltage Honda Element I

Testing & Diagnostics 5 illustrations ~529 words

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 68

Scheme 68: DTC P0118: ECT Sensor Circuit High Voltage
Scheme 68: DTC P0118: ECT Sensor Circuit High Voltage

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72
  1. Turn the ignition switch ON (II).
  2. Check the ECT SENSOR in the DATA LIST with the HDS. Is about -40°F (-40°C) or less, or 4.90 V or more indicated? YES- Go to step 3 . NO- Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the ECT sensor and the ECM/PCM.
  3. Turn the ignition switch OFF.
  4. Disconnect the ECT sensor 2P connector.
  5. Connect ECT sensor 2P connector terminals No. 1 and No. 2 with a jumper wire.
  6. Turn the ignition switch ON (II).
  7. Check the ECT SENSOR in the DATA LIST with the HDS. Is about -40°F (-40°C) or less, or 4.90 V or more indicated? YES- Go to step 8 . NO- Go to step 18 .
  8. Turn the ignition switch OFF.
  9. Remove the jumper wire.
  10. Turn the ignition switch ON (II).
  11. Measure voltage between ECT sensor 2P connector terminal No. 1 and body ground. Is there about 5 V? YES- Go to step 12 . NO- Go to step 17 .
  12. Turn the ignition switch OFF.
  13. Jump the SCS line with the HDS.
  14. Disconnect ECM/PCM connector A (31P).
  15. Connect ECT sensor 2P connector terminal No. 2 to body ground with a jumper wire.
  16. Check for continuity between ECM/PCM connector terminal A23 and body ground. Is there continuity? YES- Go to step 25 . NO- Repair open in the wire between the ECM/PCM (A23) and the ECT sensor, then go to step 20 .
  17. Measure voltage between ECM/PCM connector terminal B8 and body ground. Is there about 5 V? YES- Repair open in the wire between the ECM/PCM (B8) and the ECT sensor, then go to step 20 . NO- Go to step 25 .
  18. Turn the ignition switch OFF.
  19. Replace the ECT sensor (see «ECT SENSOR REPLACEMENT»(ref-220570-S34870321162006022000000) ).
  20. Reconnect all connectors.
  21. Turn the ignition switch ON (II).
  22. Reset the ECM/PCM with the HDS.
  23. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-220572-S08440202922006022000000) ).
  24. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES- If DTC P0118 is indicated, check for poor connections or loose terminals at the ECT sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO- Troubleshooting is complete.
  25. Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «ECM/PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-220569-S23624043112006022000000) ).
  26. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES- If DTC P0118 is indicated, check for poor connections or loose terminals at the ECT sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO- If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «MAP SENSOR REPLACEMENT»(ref-220570-S17955277902006022000000) ).
