Advanced Diagnostics: Other Honda Element I

Enable Conditions

ENABLE CONDITIONS

Malfunction Threshold

The timing difference between the timing control command and the actual timing of the camshaft is 5.0° or more for at least 15 seconds.

Confirmation Procedure with the HDS

Do the VTC TEST in the INSPECTION MENU of the HDS.

Driving Pattern

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a steady speed between 25 - 75 mph (40 - 120 km/h) for at least 15 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

Conditions for illuminating the MIL

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

Conditions for clearing the MIL

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Manifold Absolute Pressure Sensor Circuit Diagram. Scheme 272

Manifold Absolute Pressure Sensor Output Voltage Graph. Scheme 273

ENABLE CONDITIONS

The MAP sensor output voltage is 0.23 V or less for at least 2 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The MAP sensor output voltage is 4.49 V or more for at least 2 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Intake Air Temperature Sensor Range/Performance Graph. Scheme 274

ENABLE CONDITIONS

A malfunction is detected if the temperature difference (IAT minus ECT) is 46°F (26°C) or more after the engine and the ignition switch have been off for at least 6 hours.

1. Turn the ignition off, and wait at least 6 hours.
2. Start the engine, and let it idle for at least 10 seconds.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Intake Air Temperature Sensor Circuit Diagram. Scheme 275

Intake Air Temperature Sensor Output Voltage Graph. Scheme 276

ENABLE CONDITIONS

The IAT sensor output voltage is 0.08 V or less for at least 2 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The IAT sensor output voltage is 4.92 V or more for at least 2 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Engine Coolant Temperature Range/Performance Graph. Scheme 277

ENABLE CONDITIONS

Malfunction determination 1

With a completely cooled engine (one that has been off for at least 6 hours)

When the change in coolant temperature after 10 minutes or more of running time is 50°F (10°C) or less, a malfunction is detected.

Malfunction determination 2

With a partially cooled engine (one that has been off for less than 6 hours)

When the difference between the coolant temperature after 10 minutes or more of running time minus the coolant temperature after the engine has been off for 150 minutes and then run for 10 seconds is 50°F (10°C) or less, a malfunction is detected.

1. With a completely cooled engine (one that has been off for at least 6 hours).

1. Start the engine, and let it idle for at least 10 minutes.
2. Turn off the ignition for 10 seconds, then restart the engine and let it idle for at least 10 seconds.

1. With a partially cooled engine (one that has been off for less than 6 hours).

1. Start the engine, and let it idle for at least 10 minutes.
2. Turn off the ignition for 150 minutes, then restart the engine and let it idle for at least 10 seconds.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Engine Coolant Temperature Sensor Graph. Scheme 278

ENABLE CONDITIONS

The engine running time before the engine coolant temperature reaches 98°F (36°C), based on the initial engine coolant temperatures, is as follows.

ENABLE CONDITIONS

1. Start the engine at an engine coolant temperature as specified under Enable Conditions.
2. Let the engine idle for at least 20 minutes.

When a malfunction is detected during the first drive cycle with the ECT and IAT at engine start-up within the specified temperature range, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle with the ECT and IAT at engine start-up within the specified temperature range, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Cooling System Malfunction Operation Graph. Scheme 279

ENABLE CONDITIONS

1. The ECT sensor output is 158°F (70°C) or less when the estimated engine coolant temperature is 167°F (75°C) or more.
2. The difference between the estimated engine coolant temperature and the ECT sensor output is 18°F (10°C) or more.

Do the RADIATOR FAN TEST in the INSPECTION MENU with the HDS for 20 minutes.

1. Start the engine at an engine coolant temperature and intake air temperature as specified under Enable Conditions.
2. Drive the vehicle at a speed between 15 - 75 mph (24 - 120 km/h) for at least 10 minutes.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

A/F Sensor Output Voltage And Deteriorated Response Graph. Scheme 280

ENABLE CONDITIONS

The A/F sensor inversion cycle is 1.6*1, 1.8*2 seconds or more.

*1: A/T model

*2: M/T model

Vehicle Speed Driving Pattern. Scheme 281

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a steady speed between 25 - 55 mph (40 - 88 km/h) for at least 5 minutes.
3. Then, drive immediately at a steady speed between 30 - 75 mph (48 - 120 km/h) for at least 15 seconds.

1. If the EVAP monitor runs instead of the HO2S monitor, turn the engine off, then restart it, and the HO2S monitor will restart.
2. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Air/Fuel Ratio Sensor Malfunction Determination And Malfunction Determination. Scheme 282

ENABLE CONDITIONS

Malfunction determination 1

The A/F sensor internal resistance value is 50 ohms or more for at least 90 seconds right after the engine starts.

Malfunction determination 2

1. The A/F sensor internal resistance value is 50 ohms or more for at least 15 seconds.
2. The A/F sensor internal resistance value is 80 ohms or more for at least 1 second.

Start the engine, then let it idle for at least 2 minutes.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Secondary Heated Oxygen Sensor Circuit Diagram. Scheme 283

Secondary Heated Oxygen Sensor Output Voltage Graph. Scheme 284

ENABLE CONDITIONS

The secondary HO2S output voltage is 0.293 V or less for at least 30 seconds.

1. Start the engine. Let it idle until the radiator fan comes on.
2. Then, drive immediately at a steady engine speed between 1,500 - 3,000 rpm for at least 1 minute.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Secondary Heated Oxygen Sensor Output Voltage Graph. Scheme 285

ENABLE CONDITIONS

The secondary HO2S output voltage is 1.270 V or more for at least 5 seconds.

1. Start the engine. Let it idle until the radiator fan comes on.
2. Then, drive immediately at a steady engine speed between 1,500 - 3,000 rpm for at least 1 minute.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Secondary Heated Oxygen Sensor Output Voltage Graph. Scheme 286

ENABLE CONDITIONS

1. When the secondary HO2S output drops to the response deterioration judgment threshold value and the response characteristics measurement is finished. MALFUNCTION THRESHOLD MIN 0.75 second MAX 2.20 seconds
2. The voltage does not drop to the response deterioration judgment threshold value after a predetermined time (1 second) has elapsed.

1. Start the engine. Let it idle until the radiator fan comes on.
2. Then, drive immediately at a steady speed of 35 mph (57 km/h) or more for at least 11.5 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The current is 0.38 A or less, or 3.33 A or more, for at least 5 seconds when the heater is on.

Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Fuel System Normal Operation And System Failure Signal Graph. Scheme 287

ENABLE CONDITIONS

Long term fuel trim is higher than 1.18 (+18 %).

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Then, drive at a steady speed between 15 - 75 mph (24 - 120 km/h) for at least 15 minutes, and watch the long term fuel trim. If the long term fuel trim stays at about 1.0, the vehicle is OK or it is a very minor problem. If a significant fault is still present, the long term fuel trim will move up or down while driving.

1. When freeze frame data is stored, drive the vehicle under those conditions instead of Driving Pattern 2.
2. If the EVAP monitor runs instead of the HO2S monitor, turn the engine off, then restart it, and the HO2S monitor will restart.
3. After clearing the DTC by disconnecting the battery or using the scan tool, extend Driving Pattern 2 to 40 minutes or longer to allow time for long term fuel trim to recover.
4. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive drive cycles in which the engine conditions are similar to the first time the malfunction was detected.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Fuel System Normal Operation And System Failure Signal Graph. Scheme 288

ENABLE CONDITIONS

Long term fuel trim is lower than 0.81 (-19 %).

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Then, drive at a steady speed between 15 - 75 mph (24 - 120 km/h) for at least 15 minutes, and watch the long term fuel trim. If the long term fuel trim stays at about 1.0, the vehicle is OK or it is a very minor problem. If a significant fault is still present, the long term fuel trim will move up or down while driving.

1. When freeze frame data is stored, drive the vehicle under those conditions instead of Driving Pattern 2.
2. If the EVAP monitor runs instead of the HO2S monitor, turn the engine off, then restart it, and the HO2S monitor will restart.
3. After clearing the DTC by disconnecting the battery or using the scan tool, extend Driving Pattern 2 to 40 minutes or longer to allow time for long term fuel trim to recover.
4. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive drive cycles in which the engine conditions are similar to the first time the malfunction was detected.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Crankshaft Position Sensor Pulse Data Graph. Scheme 289

ENABLE CONDITIONS

The number of misfires versus engine revolutions is equal to or greater than the values in the table.

MALFUNCTION THRESHOLD

Vehicle Speed Driving Pattern. Scheme 290

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a speed between 15 - 75 mph (24 - 120 km/h) for at least 3 minutes.
3. Stop the vehicle, and let the engine idle for at least 3 minutes.

1. When freeze frame data is stored, drive the vehicle under those conditions instead of Driving Patterns 2 or 3.
2. When you have difficulty duplicating the DTC because of road conditions and traffic situations, repeat the driving pattern several times.
3. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

Misfire Type 1: Under high rpm or high load conditions: The MIL blinks once per second if a type 1 misfire (catalyst damaging) occurs, and a Temporary DTC is stored. If the type 1 misfire ceases, the MIL goes off. If a type 1 misfire occurs during the next (second) drive cycle, the MIL blinks at the first misfire occurrence, and the DTC and the freeze frame data are stored. The MIL remains on steady if the type 1 misfire ceases.

Under normal driving conditions: The MIL blinks once per second if a type 1 misfire occurs a third time, and a Temporary DTC is stored. If a type 1 misfire occurs during the next (second) drive cycle, the MIL blinks during the third type 1 misfire occurrence, and the DTC and the freeze frame data are stored. If the type 1 misfire ceases, the MIL remains on steady.

Misfire Type 2: When a type 2 misfire (emission-related but not severe enough to immediately damage the TWC) occurs within the first 1,000 engine revolutions after engine start-up, a Temporary DTC is stored.

If a type 2 misfire occurs after the first 1,000 engine revolutions after engine start-up, a Temporary DTC is stored during the fourth type 2 misfire occurrence.

If a type 2 misfire occurs during the next (second) drive cycle, the MIL comes on, and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive drive cycles in which the engine conditions are similar to the first time the malfunction was detected.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The number of misfires versus engine revolutions is equal to or greater than the values in the table.

MALFUNCTION THRESHOLD

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a speed between 15 - 75 mph (24 - 120 km/h) for at least 3 minutes.
3. Stop the vehicle, and let the engine idle for at least 3 minutes.

1. When freeze frame data is stored, drive the vehicle under those conditions instead of Driving Patterns 2 or 3.
2. When you have difficulty duplicating the DTC because of road conditions and traffic situations, repeat the driving pattern several times.
3. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

Misfire Type 1: Under high rpm or high load conditions: The MIL blinks once per second if a type 1 misfire (catalyst damaging) occurs, and a Temporary DTC is stored. If the type 1 misfire ceases, the MIL goes off. If a type 1 misfire occurs during the next (second) drive cycle, the MIL blinks at the first misfire occurrence, and the DTC and the freeze frame data are stored. The MIL remains on steady if the type 1 misfire ceases.

Under normal driving conditions: The MIL blinks once per second if a type 1 misfire occurs a third time, and a Temporary DTC is stored. If a type 1 misfire occurs during the next (second) drive cycle, the MIL blinks during the third type 1 misfire occurrence, and the DTC and the freeze frame data are stored. If the type 1 misfire ceases, the MIL remains on steady.

Misfire Type 2: When a type 2 misfire (emission-related but not severe enough to immediately damage the TWC) occurs within the first 1,000 engine revolutions after engine start-up, a Temporary DTC is stored. If a type 2 misfire occurs after the first 1,000 engine revolutions after engine start-up, a Temporary DTC is stored during the fourth type 2 misfire occurrence.

If a type 2 misfire occurs during the next (second) drive cycle, the MIL comes on, and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive drive cycles in which the engine conditions are similar to the first time the malfunction was detected.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Knock Sensor Circuit Diagram. Scheme 291

ENABLE CONDITIONS

No signals from the knock sensor are detected for at least 5 seconds.

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Hold the engine speed at 3,000 - 4,000 rpm for at least 60 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Crankshaft Position Sensor Circuit Diagram. Scheme 292

ENABLE CONDITIONS

No signals from the CKP sensor are input at least 30 times.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Identifying Oil Control Solenoid Valve And CKP Sensor. Scheme 293

ENABLE CONDITIONS

VTC OFF

1. The gap between the position of the CMP sensor A pulse and the median of the CMP sensor A assembly is 10° or more for at least 5 seconds.

Engine running, VTC active

1. The timing of the camshaft is out of the specified range (other than when BTDC is between 10 - 100°) for at least 5 seconds.

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a steady speed between 19 - 38 mph (30 - 60 km/h) for at least 10 minutes.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Camshaft Position Sensor. Scheme 294

ENABLE CONDITIONS

More or less than CMP sensor A pulses is detected during intervals between the CKP standard pulses at least 30 times.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Camshaft Position Sensor Circuit Diagram. Scheme 295

ENABLE CONDITIONS

Abnormal CMP sensor B pulsing signal is detected at least 30 times.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Catalyst System Efficiency Voltage And Time Graph. Scheme 296

ENABLE CONDITIONS

The number of detections is 960 (CTAGLT67)*1, 256 (CTAGLT67)*2 or more.

*1: A/T model

*2: M/T model

Vehicle Speed Driving Pattern. Scheme 297

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a speed between 45 - 75 mph (73 - 120 km/h) for at least 5 minutes, to warm up the TWC.
3. Set a vehicle speed of 55 mph (88 km/h) on the cruise control, and drive for at least 1 minute.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Evaporative Emission System Diagram. Scheme 298

Malfunction Detection Elapsed Time Graph. Scheme 299

0.04 inch Leak (Step 1) Detection

MONITOR DESCRIPTION CHART

0.04 inch Leak (Step 2) Detection

MONITOR DESCRIPTION CHART

0.04 inch Leak (Step 1) Detection

The change of fuel tank pressure is -0.4 kPa (-0.1 in.Hg, -3 mmHg) or more.

0.04 inch Leak (Step 2) Detection

The change of fuel tank pressure is 4 kPa (1.2 in.Hg, 30 mmHg)/min or more.

Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS.

1. Start the engine at an engine coolant temperature and intake air temperature as specified under Enable Conditions, and let it idle until the radiator fan comes on.
2. Drive the vehicle immediately at a speed between 45 - 75 mph (72 - 120 km/h) for at least 10 minutes.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle with the ECT and IAT at engine start-up within the specified temperature range, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle with the ECT and IAT at engine start-up within the specified temperature range, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Evaporative Emission Control System Canister Purge Valve Circuit Diagram. Scheme 300

ENABLE CONDITIONS

The return signal does not change according to the EVAP canister purge valve output for at least 5 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Fuel Tank Pressure Sensor Circuit Diagram. Scheme 301

Fuel Tank Pressure Sensor Voltage Graph. Scheme 302

Fuel Tank Pressure Graph. Scheme 303

ENABLE CONDITIONS

The FTP sensor output fluctuates by 0.3 kPa (0.1 in.Hg, 2 mmHg) or more at least five times within 3 seconds.

Start the engine in a cold condition, and let it idle for at least 20 seconds.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Fuel Tank Pressure Operation Graph. Scheme 304

ENABLE CONDITIONS

The output from the fuel tank pressure sensor is less than -7 kPa (-2.1 in.Hg, -55 mmHg) for at least 3 seconds.

Start the engine in a cold condition, and let it idle until the radiator fan comes on.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Fuel Tank Pressure Operation Graph. Scheme 305

ENABLE CONDITIONS

The output from the fuel tank pressure sensor is more than 8 kPa (2.2 in.Hg, 55 mmHg) for at least 3 seconds.

Start the engine in a cold condition, and let it idle until the radiator fan comes on.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

0.02 inch Leak (Step 3) Detection

MONITOR DESCRIPTION CHART

0.02 inch Leak (Step 3) Detection

The change of fuel tank pressure is 0.6 kPa (0.2 in.Hg, 5 mmHg)/min or more.

Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS.

1. Start the engine at an engine coolant temperature and intake air temperature as specified under Enable Conditions, and let it idle until the radiator fan comes on.
2. Drive the vehicle immediately at a speed between 45 - 75 mph (72 - 120 km/h) for at least 10 minutes.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle with the ECT and IAT at engine start-up within the specified temperature range, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle with the ECT and IAT at engine start-up within the specified temperature range, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Evaporative Emission Fuel Vapor Density And Vacuum Graph. Scheme 306

ENABLE CONDITIONS

The output from the fuel tank pressure sensor is at least -0.6 kPa (-0.1 in.Hg, -5 mmHg) for up to 65.2 *1 , 67.2 *2 , 214.96 *3 , 216.96 *4 seconds.

Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS.

1. After the vehicle has been left for an appropriate amount of time as specified, with the engine coolant temperature and intake air temperature within the specified range, start the engine.
2. Warm up the engine at idle until the radiator fan comes on.
3. Drive the vehicle immediately at a speed between 45 - 75 mph (72 - 120 km/h) for at least 10 minutes.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

Conditions for illuminating the fuel fill cap caution

When a malfunction is detected during the first drive cycle with the ECT at engine start-up within the specified temperature range, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle with the ECT at engine start-up within the sepcified temperature, the caution is indicated. If the malfunction recurs during the next (third) drive cycle with the ECT at engine start-up within the specified temperature range, the MIL comes on and the DTC and the freeze frame data are stored. The caution is cleared when the MIL comes on.

Conditions for clearing the fuel fill cap caution

The caution will be cleared if the malfunction does not recur during the EVAP system leakage diagnostic. The caution can be cleared by using the scan tool Clear command or by disconnecting the battery.

Evaporative Emission System Purge Flow Graph. Scheme 307

ENABLE CONDITIONS

The output from the fuel tank pressure sensor is -2 kPa (-0.6 in.Hg, -15 mmHg) or less for at least 10 seconds.

Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS.

Start the engine at an engine coolant temperature and intake air temperature as specified under Enable Conditions, and let it idle until the radiator fan comes on.

When a malfunction is detected during the first drive cycle with the ECT and IAT at engine start-up within the specified temperature range, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle with the ECT and IAT at engine start-up within the specified temperature range, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Evaporative Emission System Purge Flow Graph. Scheme 308

ENABLE CONDITIONS

1. The output from the fuel tank pressure sensor is at least -0.6 kPa (-0.1 in.Hg, -5 mmHg) for up to 65.2*1, 214.96*2 seconds.
2. Fuel vapor density during compression is at least 0.08 g (0.003 oz) for up to 65.2*1, 214.96*2 seconds.

Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS.

1. After the vehicle has been left for an appropriate amount of time as specified, with the engine coolant temperature and intake air temperature within the specified range, start the engine.
2. Warm up the engine at idle until the radiator fan comes on.
3. Drive the vehicle immediately at a speed between 45 - 75 mph (72 - 120 km/h) for at least 10 minutes.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle with the ECT and IAT at engine start-up within the specified temperature range, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle with the ECT and IAT at engine start-up within the specified temperature range, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Evaporative Emission System Vent Shut Valve Circuit Diagram. Scheme 309

ENABLE CONDITIONS

The return signal is "Low" for at least 5 seconds when the ECM/PCM outputs the "ON" signal to the EVAP canister vent shut valve.

Do the EVAP CVS ON in the INSPECTION MENU with the HDS.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The return signal is "ON" for at least 5 seconds when the ECM/PCM outputs the "Low" signal to the EVAP canister vent shut valve.

Do the EVAP CVS ON in the INSPECTION MENU with the HDS.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Idle Control System Flow Diagram. Scheme 310

Normal Operation And System Failure Graph. Scheme 311

ENABLE CONDITIONS

The actual idle speed is at least 100 rpm less than the target idle speed for at least 20 seconds.

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Let the engine idle for at least 20 seconds.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Normal Operation And System Failure Graph. Scheme 312

ENABLE CONDITIONS

The actual idle speed is at least 200 rpm greater than the target idle speed for at least 20 seconds.

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Let the engine idle for at least 20 seconds.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Idle Air Control Valve Circuit Diagram. Scheme 313

ENABLE CONDITIONS

The return circuit did not receive the duty signals from the ECM/PCM for at least 5 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Charging System Circuit Diagram. Scheme 314

ENABLE CONDITIONS

The IGP terminal voltage is 11.0 V or less for at least 60 seconds.

Conditions for illuminating the indicator

When a malfunction is detected, the DTC and the freeze frame data are stored in the ECM/PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The ECM/PCM operates for 5 seconds or more after the ignition switch is turned OFF.

When a malfunction is detected, the DTC and the freeze frame data are stored in the ECM/PCM memory. The MIL does not come on.

ENABLE CONDITIONS

One of these communication abnormality judgment limits is exceeded

1. Abnormality judgment number when 1 byte is received: 2500 times or more
2. Abnormality judgment number when 1 frame is received: 500 times or more

When a malfunction is detected, the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The ECM/PCM program update is stopped before it is finished, and this condition continues for at least 1 second.

When the ECM/PCM program is not written in the ECM/PCM, the DTC is stored in the ECM/PCM memory.

The DTC will be cleared when the ECM/PCM program update is complete.

ECM/PCM Internal Circuit Diagram. Scheme 315

ENABLE CONDITIONS

A malfunction is detected whenever the keep alive data retrieval and writing process is not completed normally.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ECM/PCM Processor Circuit Diagram. Scheme 316

ENABLE CONDITIONS

Either condition mentioned below must be met for at least 5 seconds.

1. No signal from the DKS CPU is detected.
2. Signal from the DKS CPU is detected to be abnormal.

Start the engine, let it idle for at least 30 seconds or raise the engine speed to at least 1,000 rpm.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

VIN Circuit Diagram. Scheme 317

ENABLE CONDITIONS

The VIN is not registered in the keep-alive memory in the ECM/PCM.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

When the VIN registration is completed, MIL is cleared.

Engine Control Module/Powertrain Control Module Power Control Circuit Diagram. Scheme 318

ENABLE CONDITIONS

The ECM/PCM is shut down without the normal shut-down procedure.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive drive cycles in which the engine conditions are similar to the first time the malfunction was detected.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Transmission Range Switch Circuit Diagram. Scheme 319

Transmission range switch contact point input matrix

TRANSMISSION RANGE SWITCH CONTACT POINT INPUT MATRIX

ENABLE CONDITIONS

Case 1

The PCM detects the selected range switch input and another range switch (except FWD switch) input simultaneously for at least 1 second.

Case 2

The PCM detects the P, R, or N range switch input and the FWD switch input simultaneously for at least 1 second.

Start the engine, then place the shift lever in each position for at least 1 second.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

No FWD position signal is detected when the vehicle speed changes from 6 mph (10 km/h) 30 mph (48 km/h) 6 mph (10 km/h) in the D or 2 position.

1. Start the engine, and accelerate to 30 mph (48 km/h) or more in D position, then slow down to 6 mph (10 km/h).
2. Stop the vehicle, turn the ignition switch OFF, and repeat step 1.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ATF Temperature Sensor Circuit Diagram. Scheme 320

ATF Temperature Graph. Scheme 321

1. Stuck at Low temperature MONITOR DESCRIPTION CHART Condition Minimum Maximum Battery voltage 11.0 V - ATF temperature - -4°F (-20°C) Initial engine coolant temperature - 95°F (35°C) Engine coolant temperature 158°F (70°C) - Throttle position 4.0° - Vehicle speed 19 mph (30 km/h) - No active DTCs P0116, P0117, P0118, P0712, P0713, P0721, P0722 Other After the engine coolant temperature reaches the fixed value, both the vehicle speed and the throttle position meet the conditions for at least 5 minutes
2. Stuck at High temperature

MONITOR DESCRIPTION CHART

1. Stuck at Low temperature The ATF temperature rise is 9°F (5°C) or less after the ignition switch is turned ON, and the current ATF temperature is -4°F (-20°C) or less for at least 5 minutes.
2. Stuck at High temperature

The ATF temperature drop is -9°F (-5°C) or less after the ignition switch is turned OFF, and the current ATF temperature is 230°F (110°C) or more for at least 20 seconds.

1. Stuck at Low temperature Start the engine with engine coolant temperature at 95°F (35°C) or less, and warm up the engine until the engine coolant temperature reaches 158°F (70°C) or more. Then drive the vehicle at a speed of 19 mph (30 km/h) or more with the throttle position at 4.0° or more for at least 5 minutes.
2. Stuck at High temperature

Turn off the engine with the engine coolant temperature at 158°F (70°C) or more. Restart the engine after the engine coolant temperature drops to 95°F (35°C) or less, and warm up the engine until the engine coolant temperature reaches 158°F (70°C), and wait for at least 20 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the D indicator blinks, and the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The ATF temperature sensor output voltage is less than 0.07 V for at least 10 seconds.

Start the engine, shift to the P position, and wait for at least 10 seconds.

When a malfunction is detected, the D indicator blinks, and the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The ATF temperature sensor output voltage is 4.93 V or more for at least 10 seconds.

Start the engine, shift to the P position, and wait for at least 10 seconds.

When a malfunction is detected, the D indicator blinks, and the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The vehicle speed measured by the input shaft (mainshaft) speed sensor/(divided by) the vehicle speed measured by the output shaft (countershaft) speed sensor < 0.188 for at least 10 seconds.

Start the engine, and drive the vehicle at a speed of 13 mph (20 km/h) or more for at least 10 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Speed Sensor Graph. Scheme 322

ENABLE CONDITIONS

When the vehicle speed measured by the output shaft (countershaft) speed sensor is 13 mph (20 km/h) or more, the vehicle speed measured by the input shaft (mainshaft) speed sensor is 1 mph (2 km/h) or less for at least 10 seconds.

Start the engine, and drive the vehicle at a speed of 13 mph (20 km/h) or more for at least 10 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Input Shaft Speed Sensor Graph. Scheme 323

ENABLE CONDITIONS

The fluctuation of the vehicle speed measured by the input shaft (mainshaft) speed sensor in 10 milliseconds is 4 mph (6km/h) or more, and it fluctuates at least six times within 500 milliseconds.

Start the engine, and drive the vehicle at a speed of 13 mph (20 km/h) or more so it shifts from 1st to 4th in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Output Shaft Speed Sensor Circuit Diagram. Scheme 324

Output Shaft Speed Sensor Graph. Scheme 325

ENABLE CONDITIONS

The vehicle speed measured by the input shaft (mainshaft) speed sensor/(divided by) the vehicle speed measured by the output shaft (countershaft) speed sensor > 5.0 for at least 10 seconds.

Start the engine, and drive the vehicle at a speed of 13 mph (20 km/h) or more for at least 10 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Output Shaft Countershaft Speed Sensor Graph. Scheme 326

ENABLE CONDITIONS

When the vehicle speed measured by the input shaft (mainshaft) speed sensor is 13 mph (20 km/h) or more, the vehicle speed measured by the output shaft (countershaft) speed sensor is 1 mph (2 km/h) or less for at least 10 seconds.

Start the engine, and drive the vehicle at a speed of 13 mph (20 km/h) or more for at least 10 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Output Shaft Speed Sensor Graph. Scheme 327

ENABLE CONDITIONS

The fluctuation of the vehicle speed measured by the output shaft (countershaft) speed sensor in 10 milliseconds is 4 mph (6km/h) or more, and it fluctuates at least six times within 500 milliseconds.

Start the engine, and drive the vehicle at a speed of 13 mph (20 km/h) or more so it shifts from 1st to 4th in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

1st Clutch And 1st Clutch Hydraulic Circuit Flow Chart. Scheme 328

Gear Ratio And Shift Status Reference Graph. Scheme 329

ENABLE CONDITIONS

The actual gear ratio must match one of these conditions for at least 12 seconds with the 1st gear command

1. Actual gear ratio > 1st gear ratio by a factor of 1.2
2. Actual gear ratio < 1st gear ratio by a factor of 0.75

Start the engine, shift to D position, and drive the vehicle at a speed of 8 mph (12 km/h) or more for at least 12 seconds in 1st gear.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the D indicator blinks, and the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The actual gear ratio must match one of these conditions for at least 12 seconds with the 2nd gear command

1. Actual gear ratio > 2nd gear ratio by a factor of 1.2
2. Actual gear ratio < 2nd gear ratio by a factor of 0.75

Start the engine, shift to D position, and drive the vehicle at a speed of 8 mph (12 km/h) or more for at least 12 seconds in 2nd gear.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the D indicator blinks, and the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The actual gear ratio must match one of these conditions for at least 12 seconds with the 3rd gear command

1. Actual gear ratio > 3rd gear ratio by a factor of 1.2
2. Actual gear ratio < 3rd gear ratio by a factor of 0.75

Start the engine, shift to D position, and drive the vehicle at a speed of 8 mph (12 km/h) or more for at least 12 seconds in 3rd gear.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the D indicator blinks, and the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The actual gear ratio must match one of these conditions for at least 12 seconds with the 4th gear command

1. Actual gear ratio > 4th gear ratio by a factor of 1.2
2. Actual gear ratio < 4th gear ratio by a factor of 0.75

Start the engine, shift to D position, and drive the vehicle at a speed of 8 mph (12 km/h) or more for at least 12 seconds in 4th gear.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the D indicator blinks, and the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The ratio of the engine revolution to the transmission input pulse does not reach about 100% for at least 20 seconds.

1. Start the engine. Hold the engine at 3,000 rpm with no load (in park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a constant speed of 60 mph (97 km/h) for at least 20 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the D indicator blinks, and the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

One of these symptoms occurs.

Symptom 1 (Symptom 1-B occurs after Symptom 1-A occurs.)

MALFUNCTION THRESHOLD

Symptom 2-A

MALFUNCTION THRESHOLD

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Shift Solenoid Valve Circuit Diagram. Scheme 330

Shift solenoid valve driving signal combination table

Shift Solenoid Valve Driving Signal Combination Table. Scheme 331

ENABLE CONDITIONS

One of these symptoms occurs.

Symptom 1 (Both Symptom 1-A and Symptom 1-B occur.)

MALFUNCTION THRESHOLD (SYMPTOM 1)

Symptom 2 (Symptom 2-B occurs after Symptom 2-A occurs)

MALFUNCTION THRESHOLD (SYMPTOM 2)

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Shift Solenoid Valve Circuit Diagram. Scheme 332

Shift solenoid valve driving signal combination table

Shift Solenoid Valve Driving Signal Combination Table. Scheme 333

ENABLE CONDITIONS

Both Symptom 1-A and Symptom 1-B occur.

MALFUNCTION THRESHOLD

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Shift Solenoid Valve Circuit Diagram. Scheme 334

Shift solenoid valve driving signal combination table

Shift Solenoid Valve Driving Signal Combination Table. Scheme 335

ENABLE CONDITIONS

This symptom occurs.

Symptom 1

MALFUNCTION THRESHOLD

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

Symptom 1-B occurs after Symptom 1-A occurs.

MALFUNCTION THRESHOLD

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

Symptom 1 (Symptom 1-B occurs after Symptom 1-A occurs.)

MALFUNCTION THRESHOLD

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Refer to (P1731, P1732, P1735, P1736)

One of these DTCs is stored.

P1731, P01732, P1735, P1736

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

Symptom 1 (Symptom 1-B occurs after Symptom 1-A occurs.)

MALFUNCTION THRESHOLD

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

This symptom occurs.

Symptom 1

MALFUNCTION THRESHOLD

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

No RVS signal is detected with the shift lever in R position while shifting between the P, R, and N positions.

Start the engine, and shift to P, R, and N positions.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the D indicator blinks, and the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The input signal from the 2nd clutch transmission fluid pressure switch to the PCM is low when driving in 4th gear.

Start the engine, and drive the vehicle in D position and 4th gear for at least 2 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Gear Ratio And Shift Status Reference Graph. Scheme 336

ENABLE CONDITIONS

The input signal from the 2nd clutch transmission fluid pressure switch to the PCM is high when driving in 2nd gear.

Start the engine, and drive the vehicle in D position and 2nd gear for at least 2 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

3rd Clutch Transmission Fluid Pressure Switch Circuit Diagram. Scheme 337

Gear Ratio And Shift Status Reference Graph. Scheme 338

ENABLE CONDITIONS

The input signal from the 3rd clutch transmission fluid pressure switch to the PCM is low when driving in 4th gear.

Start the engine, and drive the vehicle in D position and 4th gear for at least 2 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the D indicator blinks, and the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The input signal from the 3rd clutch transmission fluid pressure switch to the PCM is high when driving in 3rd gear.

Start the engine, and drive the vehicle in D position and 3rd gear for at least 2 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the D indicator blinks, and the DTC and the freeze frame data are stored in the PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The measured current for the PCM's command value is as specified here for at least 1 second.

TRANSMISSION RANGE SWITCH CONTACT POINT INPUT MATRIX

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

A/T Clutch Pressure Control Solenoid Valve Failure Area Graph. Scheme 339

ENABLE CONDITIONS

The measured current for the PCM's command value is as specified here for at least 1 second.

MALFUNCTION THRESHOLD

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

A/T Clutch Pressure Control Solenoid Valve Circuit Diagram. Scheme 340

ENABLE CONDITIONS

The measured current for the PCM's command value is as specified here for at least 1 second.

MALFUNCTION THRESHOLD

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The measured current for the PCM's command value is as specified here for at least 1 second.

MALFUNCTION THRESHOLD

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

A/T Clutch Pressure Control Solenoid Valve Circuit Diagram. Scheme 341

ENABLE CONDITIONS

The measured current for the PCM's command value is as specified here for at least 1 second.

MALFUNCTION THRESHOLD

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The measured current for the PCM's command value is as specified here for at least 1 second.

MALFUNCTION THRESHOLD

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Shift Solenoid Valve Circuit Diagram. Scheme 342

Shift solenoid valve driving signal combination table

Shift Solenoid Valve Driving Signal Combination Table. Scheme 343

ENABLE CONDITIONS

The return signal does not match the command to turn ON shift solenoid valve A for at least 1 second.

Start the engine, and drive the vehicle with the 1st gear in D position for at least 1 second.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The return signal does not match the command to turn OFF shift solenoid valve A for at least 1 second.

Start the engine, shift to P position, and wait for at least 1 second.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Shift Solenoid Valve Circuit Diagram. Scheme 344

Shift solenoid valve driving signal combination table

Shift Solenoid Valve Driving Signal Combination Table. Scheme 345

ENABLE CONDITIONS

The return signal does not match the command to turn ON shift solenoid valve B for at least 1 second.

Start the engine, shift to P position, and wait for at least 1 second.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The return signal does not match the command to turn OFF shift solenoid valve B for at least 1 second.

Start the engine, drive the vehicle so that it shifts from 1st to 3rd gear in D position, then drive the vehicle in 3rd gear for at least 1 second.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Shift Solenoid Valve Circuit Diagram. Scheme 346

Shift solenoid valve driving signal combination table

Shift Solenoid Valve Driving Signal Combination Table. Scheme 347

ENABLE CONDITIONS

The return signal does not match the command to turn ON shift solenoid valve C for at least 1 second.

Start the engine, and drive the vehicle with the 1st gear in D position for at least 1 second.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The return signal does not match the command to turn OFF shift solenoid valve C for at least 1 second.

Start the engine, shift to P position, and wait for at least 1 second.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Shift Solenoid Valve Circuit Diagram. Scheme 348

Shift solenoid valve driving signal combination table

Shift Solenoid Valve Driving Signal Combination Table. Scheme 349

ENABLE CONDITIONS

The return signal does not match the command to turn ON shift solenoid valve E for at least 1 second.

Start the engine, shift to P position, and wait for at least 1 second.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The return signal does not match the command to turn OFF shift solenoid valve E for at least 1 second.

Start the engine, and drive the vehicle with the 2nd gear in D position for at least 1 second.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

When the camshaft phase value is not 24.0° or less within the monitored area (camshaft phase control directed value plus failure judgment value) after 3 seconds have passed, or when the camshaft phase value is 20.0° or less and continues for 3 seconds or more, even when the VTC does not actuate.

Start the engine. Let it idle.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Barometric Pressure Sensor Circuit Diagram. Scheme 350

Barometric Pressure Sensor Voltage Graph. Scheme 351

ENABLE CONDITIONS

The BARO sensor output voltage is between 3.59 V to 4.49 V for at least 2 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

A malfunction is detected if the temperature difference (IAT minus ECT) is 46°F (26°C) or more after the engine and the ignition switch have been off for at least 6 hours before restarting the engine.

1. Turn the ignition off, and wait at least 6 hours.
2. Start the engine, and let it idle for at least 10 seconds.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Throttle Position Sensor Output Voltage Graph. Scheme 352

Throttle Position Sensor Output Graph. Scheme 353

ENABLE CONDITIONS

The throttle position is 4.3° or less at 1,000 rpm, or 16.0° or less at 4,000 rpm, for at least 2 seconds.

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a steady speed between 15 - 75 mph (25 - 120 km/h) (the set MAP value or more) for at least 2 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Throttle Position Sensor Output Graph. Scheme 354

ENABLE CONDITIONS

The throttle position is 13.0° or less at 1,000 rpm, or 21.5° or less at 4,000 rpm, for at least 2 seconds.

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a steady speed between 15 - 75 mph (25 - 120 km/h) (the set MAP value or less) for at least 2 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Manifold Absolute Pressure Sensor Signal Graph. Scheme 355

ENABLE CONDITIONS

1. The MAP sensor output is 36 kPa (10.9 in.Hg, 277 mmHg) or less for at least 2 seconds when atmospheric pressure is 61 kPa (18.1 in.Hg, 460 mmHg).
2. The MAP sensor output is 53 kPa (15.9 in.Hg, 405 mmHg) or less for at least 2 seconds when atmospheric pressure is 103 kPa (30.6 in.Hg, 776 mmHg).

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a speed of 15 mph (24 km/h) or more with a throttle position as specified under Enable Conditions for at least 2 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Manifold Absolute Pressure Sensor Signal Higher Graph. Scheme 356

ENABLE CONDITIONS

The MAP sensor output is 37 kPa (10.9 in.Hg, 277 mmHg) or more for at least 2 seconds.

Vehicle Speed Driving Pattern. Scheme 357

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a steady speed between 55 - 75 mph (88 - 120 km/h) for at least 10 seconds.
3. Then, decelerate with the throttle valve fully closed for at least 2 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Air/Fuel Ratio Sensor Circuit Diagram. Scheme 358

ENABLE CONDITIONS

The A/F sensor (sensor 1) heater element resistance is 250 ohms or more for at least 5 seconds.

Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Air/Fuel Ratio Sensor Voltage Graph. Scheme 359

ENABLE CONDITIONS

A malfunction is detected when the A/F sensor output voltage is 4.9 V or more.

Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Electrical Load Detector Circuit Diagram. Scheme 360

ENABLE CONDITIONS

The ELD output voltage is 0.27 V or less for at least 5 seconds.

When a malfunction is detected, the DTC and the freeze frame data are stored in the ECM/PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The ELD output voltage is 4.95 V or more for at least 5 seconds.

When a malfunction is detected, the DTC and the freeze frame data are stored in the ECM/PCM memory. The MIL does not come on.

ENABLE CONDITIONS

1. The FTP sensor output fluctuates by 0.4 kPa (0.2 in.Hg, 3 mmHg) or more, or -0.4 kPa (-0.2 in.Hg, -3 mmHg) or less, for at least 3 seconds.
2. The FTP sensor output value is -1.3 kPa (-0.3 in.Hg, -10 mmHg) or less for at least 3 seconds.

Do the EVAP CVS ON in the INSPECTION MENU with the HDS.

Start the engine, and let it idle until the radiator fan comes on.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The IGP terminal voltage is 16.0 V or more for at least 60 seconds.

When a malfunction is detected, the DTC and the freeze frame data are stored in the ECM/PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The IGP terminal voltage is 12.0 V or less, and the alternator power generation amount is within 1.0 % to 50.0 %, for at least 60 seconds.

1. Start the engine.
2. Maintain an engine speed of 500 rpm to 3,000 rpm.
3. Turn on the headlights (high beam) and rear window defogger.

When a malfunction is detected, the DTC and the freeze frame data are stored in the ECM/PCM memory. The MIL does not come on.

ENABLE CONDITIONS

The IGP terminal voltage is 12.0 V or less, and the alternator power generation amount is 0.5 % or less, for at least 60 seconds. Driving Pattern

1. Start the engine.
2. Maintain an engine speed of 500 rpm to 3,000 rpm.
3. Turn on the headlights (high beam) and rear window defogger.

When a malfunction is detected, the DTC and the freeze frame data are stored in the ECM/PCM memory. The MIL does not come on.

ENABLE CONDITIONS

Symptom 1-B occurs after Symptom 1-A occurs.

MALFUNCTION THRESHOLD

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

Symptom 1-B occurs after Symptom 1-A occurs.

MALFUNCTION THRESHOLD

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

Symptom 1-A and Symptom 1-B occurs.

MALFUNCTION THRESHOLD

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

Symptom 1-A and Symptom 1-B occurs.

MALFUNCTION THRESHOLD

Start the engine, and accelerate the vehicle until the transmission shifts into 4th gear in D position.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Air/Fuel Ratio Sensor Signal Graph. Scheme 361

ENABLE CONDITIONS

The A/F sensor output voltage is 3.67 V or more for at least 7 seconds.

Start the engine. Let the engine idle for at least 2 minutes.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Barometric Pressure Sensor Throttle Position Graph. Scheme 362

ENABLE CONDITIONS

The difference between the BARO sensor output and the MAP sensor output is 28 kPa (8.1 in.Hg, 204 mmHg) or more for at least 3 seconds.

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle with the throttle position as specified under Enable Conditions for at least 3 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The BARO sensor output voltage value is 1.58 V or less for at least 2 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The BARO sensor output voltage value is 4.49 V or more for at least 2 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The AFS+ terminal voltage is 0.4 V or less for at least 5 seconds.

Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle for 2 minutes.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The AFS-terminal voltage is 0.4 V or less for at least 5 seconds.

Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle for 2 minutes.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Air Fuel Ratio Graph. Scheme 363

ENABLE CONDITIONS

The secondary HO2S output voltage is 0.650 V or less.

1. Start the engine. Let it idle until the radiator fan comes on.
2. Drive the vehicle at a steady speed of 35 mph (57 km/h) or more for at least 22.5 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The secondary HO2S output voltage is 0.293 V or more.

1. Start the engine. Let it idle until the radiator fan comes on.
2. Drive the vehicle at a steady speed of 35 mph (57 km/h) or more for at least 22.5 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Intake Air System Flow Diagram. Scheme 364

Air Estimated Volume Graph. Scheme 365

ENABLE CONDITIONS

One of these conditions is met.

1. The estimated volume of intake air is 200 l/min (211.4 US qt/min, 176.0 lmp qt/min) or more when the MAP value is 34 kPa (10.2 in.Hg, 260 mmHg).
2. The estimated volume of intake air is 200 l/min (211.4 US qt/min, 176.0 lmp qt/min) or more when the MAP value is 61 kPa (18.1 in.Hg, 460 mmHg).

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Let the engine idle for at least 22 seconds.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

FTP Sensor Output And Purge Flow Graph. Scheme 366

ENABLE CONDITIONS

The output from the fuel tank pressure sensor is -4 kPa (-1.0 in.Hg, -25 mmHg) or less for at least 3.04 seconds.

Do the EVAP CVS ON in the INSPECTION MENU with the HDS.

Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Engine Control Module Communication Diagram. Scheme 367

ENABLE CONDITIONS

The access process to the ignition off timer fails, or a malfunction is found in the read data for at least 10 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

VTEC Oil Pressure Switch Low And High VTEC Range Circuit Diagram. Scheme 368

MALFUNCTION THRESHOLD

ENABLE CONDITIONS

When the rocker arm oil control solenoid (VTEC solenoid valve) is ON, the rocker arm oil pressure switch (VTEC oil pressure switch) remains ON.

Do the VTEC TEST in the INSPECTION MENU with the HDS.

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle in a lower gear at 4,000 rpm or more with a MAP value of 27 kPa (7.9 in.Hg, 200 mmHg) or more for at least 10 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

Low lift cam operation

When the rocker arm oil control solenoid (VTEC solenoid valve) is OFF, the rocker arm oil pressure switch (VTEC oil pressure switch) remains OFF.

Do the VTEC TEST in the INSPECTION MENU with the HDS.

Start the engine, and let it idle for at least 10 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

Rocker Arm Oil Control Solenoid Circuit Diagram. Scheme 369

ENABLE CONDITIONS

The return signal is OFF (Low) for at least 1.1 seconds when the ECM/PCM outputs the ON (High) signal to the rocker arm oil control solenoid (VTEC solenoid valve).

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle in a lower gear at 4,000 rpm or more with a manifold absolute pressure (MAP) value of 27 kPa (7.9 in.Hg, 200 mmHg) or more for at least 10 seconds.

1. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

ENABLE CONDITIONS

The return signal is ON (High) for at least 1.1 seconds when the ECM/PCM outputs the OFF (Low) signal to the rocker arm oil control solenoid (VTEC solenoid valve).

Start the engine, and let it idle for at least 10 seconds.

When a malfunction is detected, the MIL comes on and the DTC and the freeze frame data are stored in the ECM/PCM memory.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.

A/F Sensor Voltage Graph. Scheme 370

ENABLE CONDITIONS

The A/F sensor output voltage is 2.8 V or less, or 4.8 V or more.

Vehicle Speed Driving Pattern. Scheme 371

1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on.
2. Drive the vehicle at a speed between 25 - 55 mph (40 - 88 km/h) for at least 5 minutes.
3. Then, drive immediately at a steady speed between 55 - 75 mph (88 - 120 km/h) for at least 10 seconds.
4. Decelerate with the throttle valve fully closed for at least 4 seconds.

1. If the EVAP monitor runs instead of the HO2S monitor, turn the engine off, then restart it, and the HO2S monitor will restart.
2. Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.

When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the freeze frame data are stored.

The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic runs.

The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear command or by disconnecting the battery.
