DTC Chart: Body Control Module (BCM)
Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.
| DTC | Description | Action |
|---|---|---|
| B1319:11 | Shift Interlock (BSI) Output Circuit: Circuit Short to Ground | GO to PINPOINT TEST A |
| B1319:15 | Shift Interlock (BSI) Output Circuit: Circuit Short to Battery or Open | GO to PINPOINT TEST A |
BODY CONTROL MODULE (BCM) DTC CHART
Symptom Chart: External Controls
Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
| Condition | Possible Sources | Actions |
|---|---|---|
| Brake shift interlock system does not release/lock correctly | Circuitry shorted to ground Body Control Module (BCM) Brake Shift Interlock Actuator (BSIA) | GO to PINPOINT TEST A |
| Circuitry open or shorted to power Body Control Module (BCM) Brake Shift Interlock Actuator (BSIA) | GO to PINPOINT TEST A | |
| Selector lever will not shift from PARK | Selector lever cable | VERIFY selector lever cable adjustment. REFER to: SELECTOR LEVER CABLE ADJUSTMENT . |
| Selector lever cable retaining clip or bracket | INSTALL a new selector lever retaining clip or bracket. REFER to: Selector Lever Cable . | |
| Broken selector lever cable | INSTALL a new selector lever cable. REFER to: Selector Lever Cable . | |
| Selector lever linkage is out of correct gear relationship | Selector lever linkage out of adjustment Manual control lever not aligned correctly on the sensor (flat surfaces do not line up) Loose selector lever cable bracket | REFER to: SELECTOR LEVER CABLE ADJUSTMENT . |
| Vibration - a high frequency (20-80 Hz) that is felt through the seat or selector lever. Changes with engine speed | Selector lever cable grounded out or loose | REFER to: Selector Lever Cable . |
SYMPTOM CHART
PINPOINT TEST A: BRAKE SHIFT INTERLOCK ACTUATOR
- A1 READ AND RECORD ALL DTCS Read and record all DTCs . Is DTC B1319:11 and/or B1379:15 set? Yes : For DTC B1319:11 GO to A2 For DTC B1379:15 GO to A3 No : The issue may not be the Brake Shift Interlock Actuator (BSIA) electrical system, go to «SYMPTOM CHARTS»(ref-566955-S17135646482013071700000) .
- A2 CHECK THE BRAKE SHIFT INTERLOCK ACTUATOR POWER CIRCUIT FOR A SHORT TO GROUND Disconnect Floor Shifter C3245 . Disconnect BCM C2280C . Measure the resistance between: Positive Lead Measurement/Action Negative Lead C3245-3 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new selector lever assembly. REFER to: «SELECTOR LEVER ASSEMBLY»(ref-566955-S16729771482013071700000) . No : REPAIR the circuit. CLEAR the DTC.
- A3 CHECK THE BRAKE SHIFT INTERLOCK ACTUATOR POWER CIRCUIT FOR AN OPEN Disconnect Floor Shifter C3245 . Disconnect BCM C2280C . Measure the resistance between: Positive Lead Measurement/Action Negative Lead C3245-3 C2280C-41 Is the resistance less than 5 ohms? Yes : GO to A4 No : REPAIR the circuit. CLEAR the DTC.
- A4 CHECK THE BRAKE SHIFT INTERLOCK ACTUATOR GROUND CIRCUIT FOR AN OPEN Measure the resistance between: Positive Lead Measurement/Action Negative Lead C3245-4 Ground Is the resistance less than 5 ohms? Yes : GO to A5 No : REPAIR the circuit. CLEAR the DTC .
- A5 CHECK BRAKE SHIFT INTERLOCK ACTUATOR POWER CIRCUIT FOR VOLTAGE Ignition ON. Measure for voltage between: Positive Lead Measurement/Action Negative Lead C3245-3 Ground Is any voltage present? Yes : REPAIR the circuit. CLEAR the DTC . No : INSTALL a new selector lever assembly. REFER to: «SELECTOR LEVER ASSEMBLY»(ref-566955-S16729771482013071700000) .
Scheme 159
Scheme 160
Scheme 161
Scheme 162
Scheme 163
Scheme 164
- Rotate the manual control lever clockwise until it stops. Rotate the manual control lever counterclockwise one detent.
- Set the selector lever to the (D) position.
- Verify that the vehicle only starts in PARK and NEUTRAL and the reversal lamps illuminate in REVERSE.
Scheme 165
Scheme 166
Scheme 167
Scheme 168
- NOTE: If it is necessary to use the override procedure to move the selector lever out of the PARK position, it is possible that an electrical failure has occurred. Using the scan tool check for Diagnostic Trouble Codes (DTCs). This vehicle is equipped with a brake shift interlock feature that prevents the selector lever from being moved out of PARK when the ignition is in the ON position until the brake pedal is applied. If the selector lever cannot be moved out of the PARK position when the ignition is in the ON position and the brake pedal is applied: Fully apply the parking brake lever. Set ignition switch to the 0 position (Ignition off).
- NOTE: Move the brake shift interlock lever forward and hold the brake shift interlock lever while pulling the gearshift lever out of the PARK position and into the NEUTRAL position. Screwdriver.
- Apply the brake pedal and start the vehicle.
- Fully release the parking brake.
Scheme 169
Scheme 170
Scheme 171
Scheme 172
Scheme 173
- With the vehicle in NEUTRAL, position it on a hoist. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-566931-S32888765652013071700000) .
- Discard the specified component. Follow local disposal regulations.
Scheme 174
Scheme 175
Scheme 176
Scheme 177
Scheme 178
Scheme 179
Scheme 180
- Torque : 9 Nm
- Torque : 25 Nm
- Torque : 25 Nm
- Set the selector lever to the (D) position
- Rotate the manual control lever clockwise until it stops. Rotate the manual control lever counterclockwise one detent.
- Verify that the vehicle only starts in PARK and NEUTRAL and the reversal lamps illuminate in REVERSE.
