Automatic Transaxle -- Electric: Removal & Installation Ford Focus III

Automatic Trans 20 illustrations ~339 words

Installation

Pinpoint Test B

B1 205-115 Installer, Drive Pinion Seal
  1. click to open the image
B2 205-115 Installer, Drive Pinion Seal
  1. General Equipment : Rubber Mallet
  2. click to open the image

Pinpoint Test B

B1 205-115 Installer, Drive Pinion Seal
  1. click to open the image
B2 205-115 Installer, Drive Pinion Seal
  1. General Equipment : Plastic Mallet
  2. click to open the image

Scheme 122

Scheme 122: Removal

Scheme 123

Scheme 123
  1. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-566931-S32888765652013071700000) .
  2. If equipped.

Scheme 124

Scheme 124: Installation
  1. Torque : 145 Nm Torque : 125 Nm
  2. Torque : 80 Nm
  3. If equipped.

Removal

  1. Refer to: «ELECTRIC MOTOR»(ref-566981-S05026797902013071700000) .
  1. Refer to: «ELECTRIC MOTOR»(ref-566981-S05026797902013071700000) .
  2. Refer to: «TRANSMISSION FLUID DRAIN AND REFILL»(ref-566947-S31748185852013071700000) .

Scheme 125

Scheme 125: Removal

Scheme 126

Scheme 126

Scheme 127

Scheme 127

Scheme 128

Scheme 128

Scheme 129

Scheme 129: Installation

Scheme 130

Scheme 130
  1. NOTE: The O-ring seal is to be reused unless damaged.
  2. Torque : 8 Nm
  3. Torque : 8 Nm

Scheme 131

Scheme 131: Removal

Scheme 132

Scheme 132

Scheme 133

Scheme 133

Scheme 134

Scheme 134

Scheme 135

Scheme 135

Scheme 136

Scheme 136
  1. Refer to: «BATTERY DISCONNECT AND CONNECT»(ref-566962-S25797072622013071700000) .
  2. Refer to: «HIGH VOLTAGE BATTERY DISCONNECT AND CONNECT»(ref-566940-S00773601342013071700000) .
  3. NOTE: Use an antistatic wrist strap grounded to the vehicle when performing this procedure.
  4. NOTE: The gasket is to be reused unless damaged.
  5. NOTE: Note the position of the component before removal. Cabin coolant heater Air conditioning compressor Direct current/direct current converter control module

Scheme 137

Scheme 137: Installation

Scheme 138

Scheme 138

Scheme 139

Scheme 139

Scheme 140

Scheme 140

Scheme 141

Scheme 141
  1. NOTE: Make sure that the components are installed to the position noted before removal. Cabin coolant heater Air conditioning compressor Direct current/direct current converter control module
  2. Torque : 4 Nm
  3. NOTE: Make sure that new components are installed.
  4. NOTE: Make sure that new components are installed. Torque : 4 Nm
  5. Refer to: «HIGH VOLTAGE BATTERY DISCONNECT AND CONNECT»(ref-566940-S00773601342013071700000) .
  6. Refer to: «BATTERY DISCONNECT AND CONNECT»(ref-566962-S25797072622013071700000) .
