Automatic Dual Clutch Transaxle (Dct) Powershift (DPS6/6DCT250): Maintenance Ford Focus III

LUBRICANTS, FLUIDS, SEALERS AND ADHESIVES

LUBRICANTS, FLUIDS, SEALERS AND ADHESIVES

Transmission Fluid Drain and Refill

MATERIALS SPECIFICATIONS

Scheme 64

Scheme 65

Scheme 66

Scheme 67

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
2. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-515942-S20089493392012120400000) .
3. 2. If equipped.
4. NOTE: Make sure that the component is at the specified temperature.
5. WARNING: Be prepared to collect escaping fluid. WARNING: Avoid skin contact with the fluid.
6. WARNING: Be prepared to collect escaping fluid. WARNING: Avoid skin contact with the fluid.

Scheme 68

1. Torque : 43 Nm
2. Fill the transmission until the fluid level is just below the filler hole. Material : Motorcraft® Dual Clutch Transmission Fluid / XT-11-QDC (WSS-M2C200-D2)
3. Torque : 43 Nm
4. 2. If equipped.
5. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-515942-S20089493392012120400000) .

Transmission Fluid Level Check

MATERIALS SPECIFICATIONS

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
2. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-515942-S20089493392012120400000) .
3. If equipped.
4. NOTE: Make sure that the component is at the specified temperature.
5. WARNING: Be prepared to collect escaping fluid. WARNING: Avoid skin contact with the fluid.
6. Fill the transmission until the fluid level is just below the filler hole. Material : Motorcraft® Dual Clutch Transmission Fluid / XT-11-QDC (WSS-M2C200-D2)
7. Torque : 43 Nm
8. If equipped.
9. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-515942-S20089493392012120400000) .
