Single Speed Gearbox
This vehicle has a single speed gear reduction transmission that transfers power from the electric motor to the halfshafts. The gear reduction system is mounted on the back of the electric motor and is enclosed by a gear box housing. The gear reduction system consists of 3 component: the input gear assembly, intermediate shaft assembly and a differential assembly.
Park Pawl
This transmission has a park pawl mechanism with a park gear, park pawl, and a park pawl actuator rod. The park gear is splined to the intermediate shaft assembly. The park pawl is pinned to the gear box housing and the electric motor housing. The park pawl actuator rod is connected to the manual lever detent plate and pushes the park pawl into the park gear when park is selected.
TR Sensor
The TR sensor is bolted to the gear box housing and is keyed to the manual shaft by a flat keyway. The TR sensor provides the PCM with a signal for the manual lever position and is not adjustable.
TCM
The TCM is mounted on the electric motor and is not serviceable. The TCM converts high-voltage DC current into 3-phase AC current for the electric motor. The TCM also supplies fused high-voltage DC current to the DC/DC converter, air conditioning compressor module (ACCM) and the electric supplemental PTC heater.
Park
When the selector lever is in the park position, the TR sensor sends a signal of 4.20-4.50 volts to the PCM on pins 1-2 and 0.60-0.90 volts on pins 4-5. The park pawl locks the final drive to the gearbox. Voltage is not supplied to the electric motor.
Reverse
When the selector lever is in the reverse position, the TR sensor sends a signal of 3.40-3.70 volts to the PCM on pins 1-2 and 1.40-1.70 volts on pins 4-5. The vehicle can only be operated in a rearward direction and the reversing lamps are illuminated. The PCM sends a signal to the TCM to supply voltage to the electric motor with reverse polarity based off of the TR sensor signal.
Neutral
When the selector lever is in the neutral position, the TR sensor sends a signal of 2.60-2.90 volts to the PCM on pins 1-2 and 2.20-2.50 volts on pins 4-5. The electric motor does not input any torque to the gearbox. Voltage is removed from the electric motor.
Drive
When the selector lever is in the drive position, the TR sensor sends a signal of 1.80-2.10 volts to the PCM on pins 1-2 and 3-3.30 volts on pins 4-5. The PCM sends a signal to the TCM to supply voltage to the electric motor based off of the TR sensor signal.
Low
When the selector lever is in the low position, the TR sensor sends a signal of 1-1.30 volts to the PCM on pins 1-2 and 3.80-4.10 volts on pins 4-5. The PCM sends a signal to the TCM to supply voltage to the electric motor based off of the TR sensor signal. In low, conventional low position is simulated with limited RPM and engine braking is simulated through the regenerative braking.
Scheme 144
The single speed gear reduction transmission has an input gear assembly, intermediate shaft assembly and a differential assembly.
The input gear is pressed into a bearing retained in the motor housing by a snap ring and has 2 inner roller bearings that allows it to spin on the RH outer surface of the differential. The input gear transfers torque from the electric motor to the intermediate shaft assembly.
The intermediate shaft assembly spins on a bearing that is pressed into the motor housing and a bearing that is pressed into the gearbox housing. The intermediate shaft assembly has the park gear splined to it. The intermediate shaft transfers torque from the input gear to the differential ring gear.
The differential spins on 2 roller bearings housed in the input gear and a bearing that is retained by a snap ring in the gearbox housing. The differential is a conventional type with 2 pinion gears supported by a pinion shaft and 2 side gears supported by the differential case, the LH halfshaft and the transfer shaft (which splines to the RH halfshaft).
The gear reduction transmission has a final drive ratio of 7.82:1.
Scheme 145
The park gear is located on the intermediate shaft assembly. There are lugs around the outer diameter of the park gear to allow the park pawl to hold the park gear stationary to the motor housing, which holds the differential in place and keeps the vehicle from moving. The park pawl is pinned to the electric motor housing and the gear housing. The park pawl actuator rod is connected to the manual shaft detent plate and pushes the park pawl into the park gear when park is selected.
Scheme 146
The TR sensor has a 6-pin connector. The TR sensor is bolted to the gear box housing and is keyed to the manual shaft by a flat keyway. The manual shaft is turned by the selector lever linkage and the manual lever. The TR sensor sends a signal to the PCM to start the vehicle in PARK and NEUTRAL. The TR sensor opens/closes a set of 4 switches that are monitored by the PCM to determine the position of the manual lever (P, R, N, D, L). The TR sensor is not adjustable.
Scheme 147
The primary purpose of the TCM is to convert high-voltage DC current into 3-phase AC current to supply the field coils of the electric motor when requested by the PCM . This is accomplished through the use of inverters and internal speed sensors. Additionally, the TCM carries out regenerative braking when requested by the brake system control module (BSCM) by reconfiguring the electric motor to act as a generator. This decelerates the vehicle and returns energy to the high voltage traction battery (HVTB), extending vehicle range.
The TCM also serves as a high-voltage DC junction box, distributing fused high-voltage DC to the following underhood components
- DC/DC converter
- Air conditioning compressor module (ACCM)
- Electric supplemental PTC heater
The TCM and electric motor are serviceable as an assembly only. Do not attempt to open or carry out internal repairs on the TCM and electric motor.
P1A0A:01 P1A0A:17 P1A0A:18 P1A0A:29
Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.
Possible Sources
- Voltage to TCM concern
- TCM ground concern
Halfshaft Seal LH
SPECIAL TOOL(S)/GENERAL EQUIPMENT 205-115 Installer, Drive Pinion Seal TKIT-2000-F/FM/FLM Flat Headed Screw Driver Rubber Mallet
Scheme 148
Scheme 149
- Refer to: «FRONT HALFSHAFT LH»(ref-566968-S33633420222013071700000) .
- General Equipment : Flat Headed Screw Driver
Halfshaft Seal RH
SPECIAL TOOL(S)/GENERAL EQUIPMENT 205-115 Installer, Drive Pinion Seal TKIT-2000-F/FM/FLM Flat Headed Screw Driver Plastic Mallet
Scheme 150
- Refer to: «FRONT HALFSHAFT RH»(ref-566968-S30607938452013071700000) .
- General Equipment : Flat Headed Screw Driver
Transmission Support Insulator
| Trolley Jack |
|---|
| Wooden Block |
SPECIAL TOOL(S)/GENERAL EQUIPMENT
Scheme 151
Scheme 152
Scheme 153
- Refer to: «BATTERY TRAY»(ref-566962-S04123997952013071700000) .
- Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-566931-S32888765652013071700000) .
- If equipped.
- General Equipment : Trolley Jack General Equipment : Wooden Block
Scheme 154
- Torque : 148 Nm
- Torque : 48 Nm
- If equipped.
- Refer to: «BATTERY TRAY»(ref-566962-S04123997952013071700000) .
Transmission
SPECIAL TOOL(S)/GENERAL EQUIPMENT 100-D112 Slider Hammer Master Set 205-115 Installer, Drive Pinion Seal TKIT-2000-F/FM/FLM 205-153 (T80T-4000-W) Handle 303-D012 (D80L-100-H) Actuator Pin 303-D022 (D80L-100-T) Collet, 1 1/4 to 1 1/2 307-626 Installer, Differential Seal TKIT-2008ET-FLM TKIT-2008ET-ROW
Scheme 155
Scheme 156
Scheme 157
| Name | Specification |
|---|---|
| Ultra Silicone Sealant TA-29 |
MATERIALS SPECIFICATIONS
