Parking Aid System - Visual: Overview Ford Escape III

Collision/avoidance 2 illustrations ~364 words

Scheme 16

Scheme 16: Component Location
ItemDescriptionComments
1FDIM
2Video camera
3IPM-B

Overview

The video camera system visually aids the driver while reversing or reverse parking the vehicle. The video camera system is controlled though the FDIM. Refer to the Owner's Literature for information on how to operate the video camera system features.

Scheme 17

Scheme 17: System Diagram

Diagnostic Overview

Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information about these practices.

Refer to SYSTEM WIRING DIAGRAMS - Parking Aid for additional information.

Normal Operation and Fault Conditions

Refer to IMAGE DISPLAY .

Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information about these practices.

Refer to SYSTEM WIRING DIAGRAMS - Parking Aid for additional information.

Refer to IMAGE DISPLAY .

Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information about these practices.

Refer to SYSTEM WIRING DIAGRAMS - Parking Aid for additional information.

Refer to VISUAL PARKING AID .

Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information about these practices.

Refer to SYSTEM WIRING DIAGRAMS - Parking Aid for additional information.

Refer to VISUAL PARKING AID . If the liftgate is not fully closed or a trailer is connected to the vehicle, the guidelines will not be shown.

Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information about these practices.

DTCDescriptionFault Trigger Conditions
U0155:87Lost Communication With Instrument Panel Cluster (IPC) Control Module: Missing MessageA continuous and on-demand DTC that sets when the IPM-B does not retrieve the required messages from the IPC.

DTC FAULT TRIGGER CONDITIONS

Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information about these practices.

Refer to SYSTEM WIRING DIAGRAMS - Parking Aid for additional information.

DTCDescriptionFault Trigger Conditions
U3006:16Control Module Input Power "A": Circuit Voltage Below ThresholdSet by the IPM-B when the supply voltage falls below 8 volts.

DTC FAULT TRIGGER CONDITIONS

Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information about these practices.

DTCDescriptionFault Trigger Conditions
U3006:17Control Module Input Power "A": Circuit Voltage Above ThresholdSet by the IPM-B when the supply voltage is more than 16 volts.

DTC FAULT TRIGGER CONDITIONS

Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information about these practices.

DTCDescriptionFault Trigger Conditions
U0140:87Lost Communication With Body Control Module: Missing MessageA continuous and on-demand DTC that sets when the IPM-B does not receive the required messages from the BCM.

DTC FAULT TRIGGER CONDITIONS
