Totally Integrated Power Module (Tipm) - Electrical Diagnostics: Other Dodge Avenger II facelift

WHEN MONITORED

With the ignition on. Battery voltage greater than 10.4 volts.

SET CONDITION

A shorted low condition on the (C515) Rear Defogger Control Output or (C16) Fused Rear Defogger Control Output circuit.

POSSIBLE CAUSES

Scheme 191

Scheme 192

1. VERIFY DTC B106B-REAR DEFROST CONTROL CIRCUIT LOW IS ACTIVE Ensure the Rear Defogger is switched off. With the scan tool, erase TIPM DTCs. Operate the Rear Defogger Switch several times. With the scan tool, read TIPM DTCs. Does the scan tool display active DTC B106B-REAR DEFROST CONTROL CIRCUIT LOW? Yes Go To 2 . No Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also, inspect the related connectors for broken, bent, corroded, or contaminated terminals. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. INSPECT (C515) REAR WINDOW DEFOGGER CONTROL OUTPUT CIRCUIT AT REAR WINDOW GRID Inspect (C515) Rear Window Defogger Control Output wiring at rear window grid. If necessary remove trim around rear window. Check for a chafed, pierced or pinched wire. Also look for a metal object that may cause a short to ground condition at the grid. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. VEHICLE EQUIPPED WITH HEATED MIRRORS Is this vehicle equipped with heated mirrors? Yes Go To 4 . No Go To 6 .
4. DISCONNECT MIRROR AND RE-CHECK DTC NOTE: For this step disconnect each outside rearview mirror one at a time and re-check DTC's. With the scan tool, erase TIPM DTCs. Operate the Rear Defogger Switch several times. With the scan tool, read TIPM DTCs. Does the scan tool display active DTC B106B-REAR DEFROST CONTROL CIRCUIT LOW? Yes Go To 5 . No Inspect mirror pigtail wiring, if the wiring is OK replace mirror as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
5. (C16) FUSED REAR WINDOW DEFOGGER CONTROL OUTPUT CIRCUIT SHORTED TO GROUND Turn the ignition off. Both outside review mirrors should be disconnected at this time. Disconnect the TIPM C8 harness connector. Measure the resistance between ground and the (C16) Fused Rear Window Defogger Control Output circuit at the TIPM C8 harness connector. Is the resistance below 100 ohms? Yes Repair the short to ground in the (C16) Fused Rear Window Defogger Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 6 .
6. (C515) REAR WINDOW DEFOGGER CONTROL OUTPUT CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Electric Heated Backlite (Power) 1-way connector. Disconnect the TIPM C8 harness connector. Measure the resistance between ground and the (C515) Rear Window Defogger Control Output circuit at the TIPM C8 harness connector. Is the resistance below 100 ohms? Yes Repair the short to ground in the (C515) Rear Window Defogger Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 7 .
7. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the Totally Integrated Power Module in accordance with the service information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

B106C-REAR DEFROST CONTROL CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on. Battery voltage greater than 10.4 volts.

A shorted high condition in the (C515) Rear Defogger Control Output circuit or (C16) Fused Rear Defogger Control Output circuit.

Scheme 193

Scheme 194

Scheme 195

Scheme 196

1. CHECK FOR ACTIVE DTC B106C-REAR DEFROST CONTROL CIRCUIT HIGH IN THE TIPM Turn the ignition on. With the scan tool, record and erase DTC's Operate the Rear Defogger Switch several times. With the scan tool, read DTC's. Does the scan tool display active DTC B106C-REAR DEFROST CONTROL CIRCUIT HIGH? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. CHECKING THE WINDOW GRID AND (Z917) GROUND CIRCUIT Turn the ignition off. Disconnect the Electric Heated Backlite (Power) 1-way connector. Using a 12-volt test light connected to 12-volts, probe the power terminal at the grid. Does the test light illuminate? Compare with a known good vehicle, if necessary. Yes Go To 4 . No Go To 3 .
3. (Z917) GROUND CIRCUIT OPEN Turn the ignition off. Disconnect the Electric Heated Backlite (Ground) 1-way connector. Using a 12-volt test light connected to 12-volts, probe the (Z917) ground circuit at the 1-way connector. Does the test light illuminate brightly? Yes Repair the open or excessive resistance in the Rear Window Defogger Grid. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the open or excessive resistance in the (Z917) Ground circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
4. VEHICLE EQUIPPED WITH HEATED MIRRORS Is vehicle equipped with heated mirrors? Yes Go To 5 . No Go To 7 .
5. DISCONNECT MIRROR AND RE-CHECK DTC NOTE: For this step disconnect each outside rearview mirror one at a time and re-check DTC's. With the scan tool, erase TIPM DTCs. Operate the Rear Defogger Switch several times. With the scan tool, read TIPM DTCs. Does the scan tool display active DTC B106C-REAR DEFROST CONTROL CIRCUIT HIGH? Yes Go To 7 . No Go To 6 .
6. MIRROR GROUND CIRCUIT Using a 12-volt test light connected to 12-volts, probe the (Z907) or (Z908) ground circuit at the mirror connector. Does the test light illuminate brightly? Yes Inspect mirror pigtail wiring and repair or replace mirror as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the excessive resistance in the (Z907) or (Z908) Ground circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
7. (C515) REAR WINDOW DEFOGGER CONTROL OUTPUT CIRCUIT SHORTED TO BATTERY VOLTAGE Turn the ignition off. Disconnect the TIPM C8 harness connector. Ignition on, engine not running. Measure the voltage between (C515) Rear Window Defogger Control Output circuit and ground at the TIPM C8 harness connector. Is there any voltage present? Yes Repair the short to battery voltage in the (C515) Rear Window Defogger Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 8 .
8. (C16) FUSED REAR WINDOW DEFOGGER CONTROL OUTPUT CIRCUIT SHORTED TO BATTERY VOLTAGE Ignition on, engine not running. Measure the voltage between (C16) Fused Rear Window Defogger Control Output circuit and ground at the TIPM C8 harness connector. Is there any voltage present? Yes Repair the short to battery voltage in the (C16) Fused Rear Window Defogger Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 9 .
9. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the Totally Integrated Power Module in accordance with the service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

B106D-REAR DEFROST CONTROL CIRCUIT OPEN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article

With the ignition on. Battery voltage greater than 10.4 volts.

An open condition on the (C515) Rear Defogger Control Output circuit.

Scheme 197

1. CHECK FOR ACTIVE DTC B106D-REAR DEFROST CONTROL CIRCUIT OPEN Turn the ignition on. With the scan tool, record and erase DTC's. Operate the Rear Defogger Switch several times. With the scan tool, read DTC's. Does the scan tool display active DTC B106D-REAR DEFROST CONTROL CIRCUIT OPEN? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. VISUAL AND PHYSICAL CONNECTOR AND TERMINAL INSPECTION Turn the ignition off. Inspect the following connector terminal condition. Check for signs of corrosion build up or damage that would compromise the terminal to controller pin connector. NOTE: Make sure that all in-line connectors are inspected for corrosion and/or damage. Disconnect the rear window defogger grid connectors. Disconnect the C8 TIPM harness connector. Visually inspect the wiring harness. Look for any chafed, pierced, pinched or partially broken wires hidden in the wire insulation. Were any of the above conditions found? Yes Repair or replace as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. (C515) REAR DEFOGGER CONTROL OUTPUT CIRCUIT OPEN Turn the ignition off. Measure the resistance of the (C515) Rear Defogger Control Output circuit at the between the C8 TIPM harness connector and the 1-way connector. Is the resistance below 5.0 ohms? Yes Go To 4 . No Repair the (C515) Rear Defogger Control Output circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
4. CHECKING THE WINDOW GRID AND (Z917) GROUND CIRCUIT Turn the ignition off. Disconnect the Electric Heated Backlite (Power) 1-way connector. Using a 12-volt test light connected to 12-volts, probe the power terminal at the grid. Does the test light illuminate? Yes Go To 6 . No Go To 5 .
5. (Z917) GROUND CIRCUIT OPEN Turn the ignition off. Disconnect the Electric Heated Backlite (Ground) 1-way connector. Using a 12-volt test light connected to 12-volts, probe the (Z917) ground circuit at the 1-way connector. Does the test light illuminate brightly? Yes Repair the open Rear Window Defogger Grid. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the (Z917) Ground circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
6. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

B10ED-REAR DEFROST CONTROL CIRCUIT OVERCURRENT

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article

With the ignition on. Battery voltage greater than 10.4 volts.

An overcurrent condition on the (C515) Rear Defogger Control Output circuit or the (C16) Fused Rear Defogger Control Output circuit.

Scheme 198

Scheme 199

1. CHECK FOR ACTIVE DTC B10ED-REAR DEFROST CONTROL CIRCUIT OVERCURRENT Turn the ignition on. With the scan tool, record and erase DTC's. Operate the Rear Defogger Switch several times. With the scan tool, read DTC's. Does the scan tool display active DTC B10ED-REAR DEFROST CONTROL CIRCUIT OVERCURRENT? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. VISUAL AND PHYSICAL CONNECTOR AND TERMINAL INSPECTION Turn the ignition off. Inspect the following connector terminal condition. Check for signs of corrosion build up or damage that would compromise the terminal to controller pin connector. NOTE: Make sure that all in-line connectors are inspected for corrosion and/or damage. Disconnect the TIPM C8 harness connector. Visually inspect the wiring harness. Look for any chafed, pierced, pinched or partially broken wires hidden in the wire insulation. Were any of the above conditions found? Yes Repair or replace as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. VEHICLE EQUIPPED WITH HEATED MIRRORS Is vehicle equipped with heated mirrors? Yes Go To 4 . No Go To 7 .
4. (C16) FUSED REAR DEFOGGER CONTROL OUTPUT CIRCUIT HIGH RESISTANCE Disconnect both mirror connectors. With a jumper wire, connect one end to the (C16) Fused Rear Defogger Control Output circuit at one mirror connector and the other to a clean chassis ground. Using a 12-volt test light to battery voltage, probe the (C16) Rear Defogger Control Output circuit in the TIPM C8 harness connector. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. NOTE: Repeat this test for each outside mirror. Does the test light illuminate brightly for each mirror circuit? Yes Go To 5 . No Repair the excessive resistance in the (C16) Fused Rear Defogger Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
5. DISCONNECT ONE MIRROR AND RE-CHECK DTC NOTE: For this step have only one outside rearview mirror disconnected at a time and re-check DTC's. Reconnect the TIPM and one outside rearview mirror. With the scan tool, erase TIPM DTCs. Operate the Rear Defogger Switch several times. With the scan tool, read TIPM DTCs. Does the scan tool continue to display active DTC B10ED-REAR DEFROST CONTROL CIRCUIT OVERCURRENT for each mirror? Yes Go To 7 . No Go To 6 .
6. (Z907)/(Z908) GROUND CIRCUIT NOTE: Perform this test on the mirror that caused the code to set. Using a 12-volt test light connected to 12-volts, probe the (Z907) or (Z908) ground circuit at the mirror connector. Does the test light illuminate brightly? Yes Inspect mirror pigtail wiring and repair or replace mirror as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the excessive resistance in the (Z907) or (Z908) Ground circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
7. (C515) REAR DEFOGGER CONTROL OUTPUT CIRCUIT HIGH RESISTANCE Disconnect the TIPM C8 if not disconnected. Disconnect the Electric Heated Backlite (Power) 1-way connector. With a jumper wire, connect one end to the (C515) Rear Defogger Control Output circuit at the 1-way connector and the other to a clean chassis ground. Using a 12-volt test light to battery voltage, probe the (C515) Rear Defogger Control Output circuit in the TIPM C8 harness connector. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 8 . No Repair the excessive resistance in the (C515) Rear Defogger Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
8. CHECKING THE WINDOW GRID AND (Z917) GROUND CIRCUIT Turn the ignition off. Disconnect the Electric Heated Backlite (Power) 1-way connector. Using a 12-volt test light connected to 12-volts, probe the power terminal at the grid. Does the test light illuminate? Compare with a known good vehicle, if necessary. Yes Go To 10 . No Go To 9 .
9. (Z917) GROUND CIRCUIT OPEN Turn the ignition off. Disconnect the Electric Heated Backlite (Ground) 1-way connector. Using a 12-volt test light connected to 12-volts, probe the (Z917) ground circuit at the 1-way connector. Does the test light illuminate brightly? Yes Repair the open or excessive resistance in the Rear Window Defogger Grid. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the open or excessive resistance in the (Z917) Ground circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
10. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

B162B-LEFT LOW BEAM CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Headlamps activated.

When the Totally Integrated Power Module (TIPM) detects a low condition.

B162C-LEFT LOW BEAM CONTROL CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the headlamps activated.

When the Totally Integrated Power Module (TIPM) detects a high condition.

B162F-RIGHT LOW BEAM CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Headlamps activated.

When the Totally Integrated Power Module (TIPM) detects a low condition.

With the Headlamps activated.

When the Totally Integrated Power Module (TIPM) detects a high condition.

With the Headlamps activated.

When the Totally Integrated Power Module (TIPM) detects a low condition.

With the high beam headlamps activated.

When the Totally Integrated Power Module (TIPM) detects a high condition.

With the High Beam Headlamps activated.

When the Totally Integrated Power Module (TIPM) detects a low condition.

With the Headlamps activated.

When the Totally Integrated Power Module (TIPM) detects a high condition.

B163B-FRONT LEFT TURN CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Turn Signal activated.

When the Totally Integrated Power Module (TIPM) detects a low condition.

B163C-FRONT LEFT TURN CONTROL CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously

When the Totally Integrated Power Module (TIPM) detects an open or short to battery on the control circuit.

B163F-FRONT RIGHT TURN CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Turn Signal activated.

When the Totally Integrated Power Module (TIPM) detects a low condition.

Continuously

When the Totally Integrated Power Module (TIPM) detects an open or short to battery on the control circuit.

With the Turn Signal activated.

When the Totally Integrated Power Module (TIPM) detects a low condition.

Continuously

When the Totally Integrated Power Module (TIPM) detects an open or short to battery on the Left Rear Turn Signal Control circuit.

With the Turn Signal activated.

When the Totally Integrated Power Module (TIPM) detects a low condition.

Continuously

When the Totally Integrated Power Module (TIPM) detects an open or short to battery on the Right Rear Turn Signal Control circuit.

With the fog lamps active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L139) Front Fog Lamps Relay Driver circuit.

Scheme 200

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTCs. Turn the ignition on. Turn the fog lamps on. With the scan tool, read DTCs. Does the scan tool display DTC: B1659-FRONT FOG LAMP CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. CHECK THE FRONT FOG LAMPS RELAY Turn the fog lamps off. Turn the ignition off. Remove the Front Fog Lamps Relay and substitute it with a known good relay. Turn the ignition on. With the scan tool, clear all DTCs. Turn the fog lamps on. With the scan tool, read DTCs. Does the scan tool display DTC: B1659-FRONT FOG LAMP CONTROL CIRCUIT LOW? Yes Go To 3 . No Replace the Front Fog Lamps Relay. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
3. CHECK THE (L139) FRONT FOG LAMPS RELAY DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Remove the Front Fog Lamps Relay. Disconnect the TIPM C11 harness connector. Measure the resistance between ground and the (L139) Front Fog Lamps Relay Driver circuit at the TIPM C11 harness connector. Is the resistance above 10k Ohms? Yes Replace the TIPM in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the short to ground in the (L139) Front Fog Lamps Relay Driver circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

B165C-PARK LAMP CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Parklamps activated.

When the Totally Integrated Power Module (TIPM) detects a low condition.

B165D-PARK LAMP CONTROL CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Park Lamps are activated.

When the Totally Integrated Power Module (TIPM) detects a high condition.

B165E-PARK LAMP CONTROL CIRCUIT OPEN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Park Lamps Activated.

When the Totally Integrated Power Module (TIPM) detects an open condition.

With the fog lamps active.

When the Totally Integrated Power Module (TIPM) detects a high condition on the (L139) Front Fog Lamps Relay Driver circuit.

With the fog lamps active.

When the Totally Integrated Power Module (TIPM) detects an open condition on the (L139) Front Fog Lamps Relay Driver circuit.

With the ignition on.

The TIPM detects a short to ground condition.

With the ignition on.

The TIPM detects an open condition.

With the Reverse Lamps Activated.

When the TIPM detects a high condition.

With the Stop Lamps activated.

When the TIPM detects a low condition.

B16E0-RIGHT TAIL LAMP 1 CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Stop Lamps activated.

When the TIPM detects a low condition.

Continuously

When the Totally Integrated Power Module senses 12 volts on the Hood Ajar Switch Sense circuit for over 10 seconds, this code will set.

Scheme 201

Scheme 202

Scheme 203

1. TEST FOR INTERMITTENT CONDITION NOTE: Open the hood and ensure the Hood Ajar Switch is connected before proceeding With the scan tool, record and erase DTCs Close the hood. Cycle the ignition from on to off. Turn the ignition on. Open then close the hood. With the scan tool, read DTCs. Does the scan tool display B1820-HOOD AJAR INPUT CIRCUIT HIGH? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. INCORRECT HOOD AJAR SWITCH INSTALLED Inspect the retainer ring on the hood ajar switch. A dark brown retainer ring identifies the hood ajar switch used for certain export applications, while a white retainer ring identifies the remote starter system application. Is the correct switch installed? Yes Go To 3 . No Replace the Hood Ajar Switch. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
3. HOOD AJAR SWITCH OPEN Disconnect the Hood Ajar Switch harness connector. Depress the plunger of the hood ajar switch and measure the resistance between the two terminals of the switch. Is the resistance approximately 1k ohms? Yes Go To 4 . No Replace the Hood Ajar Switch. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
4. (Z920) GROUND CIRCUIT OPEN Using a 12-volt Test Light connected to 12-volts, check the (Z920) Ground circuit. Does the test light illuminate? Yes Go To 5 . No Repair the (Z920) Ground circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
5. (G70) HOOD AJAR SWITCH SENSE CIRCUIT SHORT TO VOLTAGE Disconnect the TIPM C2 connector. Turn the ignition on. Measure the voltage between the (G70) Hood Ajar Switch Sense circuit and ground. Is there any voltage present? Yes Repair the (G70) Hood Ajar Switch Sense circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 6 .
6. (G70) HOOD AJAR SWITCH SENSE CIRCUIT OPEN Turn the ignition off. Measure the resistance of the (G70) Hood Ajar Switch Sense circuit between the TIPM C2 connector and the Hood Ajar Switch connector. Is the resistance below 2.0 ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the (G70) Hood Ajar Switch Sense circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

Scheme 204

Note. For a Right Hand Drive Vehicle, refer to the master schematic, in the Wiring Section, for correct connector pinouts.

Note. The schematic shows just the Left Rear Window Motor circuit for JS 41 Base only. The other Passenger Window Motor circuits are similar. For the JS Express Up or the JS 27 schematics, see the Wiring Section.

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Whenever the module is awake.

When the Totally Integrated Power Module (TIPM) senses a draw of between 65 and 100 amps for 80 ms., this code will set.

Note. The most probable cause for this DTC to set is that the driver held all four window switches down or up for an extended period of time thereby causing the high side driver, in the TIPM, to overheat and cut out. Once the high side driver is opened, it will remain open for approximately 10 seconds or until the next key cycle. However, the code will remain as stored.

Scheme 205

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Cycle the ignition switch off for 30 seconds then on. Ensure the Window Lock Out Switch is ON. Operate the Driver Window Switch in all positions several times. Operate each Passenger Window Switch in both directions several times. Wait 30 seconds. With the scan tool, read the DTCs. Does the scan tool display B18BB-WINDOW CONTROL CIRCUIT LOW? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Check for a sticking switch or any window motor that is not operating properly. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. CHOOSE THE VEHICLE NOTE: If you know which window caused the circuit to open, in the previous step, you can use the wiring schematic in the Wiring section to isolate the problem or you can continue this test. Which vehicle are you working on? JS27 Go To 18 . JS41 WITH EXPRESS UP WINDOWS Go To 10 . JS41 WITHOUT EXPRESS UP WINDOWS Go To 3 .
3. (F981) IGNITION SWITCH OUTPUT CIRCUIT SHORT TO GROUND Turn the ignition off. Disconnect the Driver Power Window Switch C1 and C2 connectors. Test the Master Switch to insure it is not shorted. Replace if needed. Disconnect the Passenger Window Switch connector. Turn the ignition on. Measure the voltage between ground and the (F981) Ignition Switch Output circuit in the Driver Power Window Switch C2 connector. Is the voltage above 11.5 volts? Yes Go To 4 . No Go To 8 .
4. WINDOW DRIVER CIRCUIT SHORT TO GROUND Turn the ignition off. Reconnect the Passenger Window Switch. Measure the resistance between ground and each Window Driver (Up and Down) or Master Window Switch Driver (Up or Down) circuit in the Driver Window Switch C1 connector. Is the resistance below 10, 000 ohms in any Window Driver or Master Window Switch Driver circuit in the C1 connector? No Go To 5 . Yes Locate and repair the Window Driver circuit for a short to ground. The short circuit could be in either the Window Driver wire, the Passenger Window Switch or the affected motor. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
5. FRONT WINDOW DRIVER CIRCUIT SHORT TO GROUND Measure the resistance between ground and the Driver Window Driver (Up and Down) (LHD) or the Master Window Switch Passenger (Up or Down) (RHD) circuits in the Driver Window Switch C2 connector. Is the resistance below 10, 000 ohms in either or both circuits? Yes Repair the Window Driver circuit for a short to ground. The short circuit could be in either Window Driver wire, Passenger Window Switch (RHD) or the motor. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 6 .
6. (Q15) WINDOW LOCK OUT SWITCH OUTPUT CIRCUIT SHORT TO GROUND Measure the resistance between ground and the (Q15) Window Lock Out Switch Output circuit in the Driver Window witch C2 connector Is the resistance below 10, 000 ohms? No Go To 7 . Yes Repair the (Q15) Window Lock Out Switch Output circuit for a short to ground. The short could be in any wire going to a Passenger Window Switch or in one of the Passenger Window Switches. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
7. CHECK EACH WINDOW DRIVER UP CIRCUIT FOR A SHORT TO THE WINDOW DRIVER DOWN CIRCUIT Measure the resistance of each window motor circuit between the Window Driver Up circuit and the Window Driver Down circuit in the Master Window Switch C1 and C2 connectors. Do this test for all four motors. Is the resistance below 0.5 ohms in any of the Window Motor circuits? Yes Disconnect the Window Motor and retest the circuits. If the resistance between the circuits is above 20, 000.0 ohms, replace the motor in accordance with service information. If the resistance is still low, check the Passenger Window Switch. If the switch is not shorted, repair the Window Driver or Master Window Switch circuits for a short to each other. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Test complete. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
8. (F981) IGNITION SWITCH OUTPUT CIRCUIT SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C7 connector. Measure the resistance between ground and the (F981) Ignition Switch Output circuit in the TIPM C7 connector. Is the resistance below 10, 000 ohms? Yes Repair the (F981) Ignition Switch Output circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 9 .
9. (F981) IGNITION SWITCH OUTPUT CIRCUIT OPEN Measure the resistance of the (F981) Ignition Switch Output circuit between the TIPM C7 connector and the Driver Power Window Switch C2 connector. Is the resistance below 5.0 ohms? Yes Repair the (F981) Ignition Switch Output circuit for an open Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the Totally Integrated Power Module in accordance with the Service Information. Retest the system to be sure a short to ground didn't damage the TIPM. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
10. (F981) IGNITION SWITCH OUTPUT CIRCUIT SHORT TO GROUND Turn the ignition off. Disconnect the Driver Power Window Switch C1 and C2 connectors. Disconnect the Passenger Window Switch connector. Turn the ignition on. Measure the voltage between ground and the (F981) Ignition Switch Output circuit in the Driver Power Window Switch C1 connector. Is the voltage above 11.5 volts? Yes Go To 11 . No Go To 16 .
11. WINDOW DRIVER CIRCUITS SHORT TO GROUND Turn the ignition off. Reconnect the Passenger Window Switch. Measure the resistance between ground and each Master Window Switch Rear (Up and Down) circuits in the Driver Window Switch C1 connector. Is the resistance below 10, 000 ohms in any Window Driver circuit in the C1 connector? No Go To 12 . Yes Locate and repair the Master Window Switch circuit for a short to ground. The short circuit could be in the Master Window Switch wire to the rear switch, the Up or Down Window Driver circuit, a Rear Switch or the affected motor. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
12. FRONT WINDOW CIRCUIT SHORT TO GROUND Measure the resistance between ground and each Master Switch Window Mux circuit in the Driver Window Switch C2 connector. Is the resistance below 10, 000 ohms in either or both circuits? Yes Repair the Window Mux circuit for a short to ground. The short circuit could be in either Window Module, a wire or the motor. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 13 .
13. (Q15) WINDOW LOCK OUT SWITCH OUTPUT CIRCUIT SHORT TO GROUND Measure the resistance between ground and the (Q15) Window Lock Out Switch Output circuit in the Driver Window Switch C2 connector. Is the resistance below 10, 000 ohms? No Go To 14 . Yes Repair the (Q15) Window Lock Out Switch Output circuit for a short to ground. The short could be in any wire going to a Passenger Window Switch or in one of the Passenger Window Switches. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
14. CHECK EACH REAR WINDOW DRIVER UP CIRCUIT FOR A SHORT TO THE WINDOW DRIVER DOWN CIRCUIT Measure the resistance for each window motor between the Master Window Switch Rear Up circuit and the Master Window Switch Rear Down circuit in the Driver Window Switch C1 connector. Do this test for both rear motors. Is the resistance below 0.5 ohms in any of the Window Motor circuits? Yes Disconnect the Window Motor and retest the circuit. If the resistance between the circuits is above 20, 000.0 ohms, replace the motor in accordance with service information. If the resistance is still low, check for a shorted rear window switch. If the switch is not shorted, repair the Window Driver or Master Window Switch circuits for a short to each other. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 15 .
15. CHECK EACH FRONT WINDOW DRIVER UP CIRCUIT FOR A SHORT TO THE WINDOW DRIVER DOWN CIRCUIT Disconnect the Driver Door Module C1 connector. Measure the resistance for the Driver window motor between the Window Express Up Driver circuit and the Window Express Down Driver circuit in the Door Module C1 connector. Repeat the above test for the Passenger Window Motor. NOTE: The graphic shows the Driver Door Module connector. The Passenger Door Module uses the same cavities for the Window Express Driver circuits. Is the resistance below 0.5 ohms in any of the Window Motor circuits? Yes Disconnect the Window Motor and retest the circuit. If the resistance between the circuits is above 20, 000.0 ohms, replace the motor in accordance with service information. If the resistance is still low, repair the Window Driver circuits for a short to each other. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Check the Passenger Window Switch and the wiring between the switch and the Door Module for a short to ground. Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
16. (F981) IGNITION SWITCH OUTPUT CIRCUIT SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C7 connector. Measure the resistance between ground and the (F981) Ignition Switch Output circuit in the Driver Power Window Switch C2 connector. Is the resistance below 10, 000 ohms? Yes Repair the (F981) Ignition Switch Output circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 17 .
17. (F981) IGNITION SWITCH OUTPUT CIRCUIT OPEN Measure the resistance of the (F981) Ignition Switch Output circuit between the TIPM C7 connector and the Driver Power Window Switch C2 connector. Is the resistance below 5.0 ohms? Yes Repair the (F981) Ignition Switch Output circuit for an open Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the Totally Integrated Power Module in accordance with service information. Retest the system to be sure a short to ground didn't damage the TIPM. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
18. (F981) IGNITION SWITCH OUTPUT CIRCUIT SHORT TO GROUND Turn the ignition off. Disconnect the Driver Power Window Switch connector. Disconnect the Passenger Window Switch connector. Turn the ignition on. Measure the voltage between ground and the (F981) Ignition Switch Output circuit in the Driver Power Window Switch connector. Is the voltage above 11.5 volts? Yes Go To 19 . No Go To 23 .
19. WINDOW SWITCH MUX CIRCUITS SHORT TO GROUND Turn the ignition off. Measure the resistance between ground and each Master Switch Front and Rear Window Mux circuit in the Driver Window Switch connector. Is the resistance below 10, 000 ohms in any Window Mux circuit? No Go To 20 . Yes Locate and repair the appropriate Window Mux circuit for a short to ground between the switch and the Driver Door Module. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
20. (Q15) WINDOW LOCK OUT SWITCH OUTPUT CIRCUIT SHORT TO GROUND Reconnect the Passenger Window Switch. Measure the resistance between ground and the (Q15) Window Lock Out Switch Output circuit in the Driver Window Switch connector. Is the resistance below 10, 000 ohms? No Go To 21 . Yes Repair the (Q15) Window Lock Out Switch Output circuit for a short to ground. The short could be in the wire going to the Driver Door Module, to the Passenger Window Switch or in the Switch. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
21. CHECK EACH WINDOW DRIVER CIRCUIT FOR A SHORT TO GROUND It will now be necessary to disconnect each front Door Module and the Power Top Control Module (C2) connector and check each Window Driver (Up and Down) circuit for a short to ground. Measure the resistance between ground and each Window Driver (Up and Down) circuit in each module connector. Do this test for all four window motors. Is the resistance below 10, 000 ohms in any of the Window Driver circuits? Yes Repair the Window Driver circuit for a short to ground. The short circuit could be in the wire or the motor. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 22 .
22. CHECK EACH WINDOW DRIVER UP CIRCUIT FOR A SHORT TO THE WINDOW DRIVER DOWN CIRCUIT Measure the resistance for each window motor between the Window Driver Up circuit and the Window Driver Down circuit in the module connectors. Do this test for all four motors. Is the resistance below 0.5 ohms in any of the Window Motor circuits? Yes Disconnect the Window Motor and retest the circuit. If the resistance between the circuits is above 20, 000.0 ohms, replace the motor in accordance with service information. If the resistance is still low, repair the Window Driver circuits for a short to each other. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Test complete. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
23. (F981) IGNITION SWITCH OUTPUT CIRCUIT SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C7 connector. Measure the resistance between ground and the (F981) Ignition Switch Output circuit in the Driver Window Switch connector. Is the resistance below 10, 000 ohms? Yes Repair the (F981) Ignition Switch Output circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 24 .
24. (F981) IGNITION SWITCH OUTPUT CIRCUIT OPEN Measure the resistance of the (F981) Ignition Switch Output circuit between the TIPM C7 connector and the Driver Power Window Switch connector. Is the resistance below 5.0 ohms? Yes Repair the (F981) Ignition Switch Output circuit for an open Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the Totally Integrated Power Module in accordance with the Service Information. Retest the system to be sure a short to ground didn't damage the TIPM. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

B191D-WINDOW CONTROL CIRCUIT OVERCURRENT

Note. The schematic shows just the Left Rear Window Motor circuit. The other Passenger Window Motor circuits are similar.

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Whenever the module is awake.

When the Totally Integrated Power Module (TIPM) senses a draw of over 35 amps for over 120 ms. on the F981 Ignition Switch Output circuit, this code will set

Note. A possible cause for this DTC to set would be if the driver held more than one window switch down for an extended period of time thereby causing the high side driver, in the TIPM, to overheat and cut out. Once the high side driver is opened, it will remain open until the next key cycle. However, the code will remain as stored.

Scheme 224

Scheme 225

Scheme 226

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Cycle the ignition switch off then on. Make sure the Window Lock Out Switch is ON. Operate the Driver Window Switch in all positions several times. Operate each Passenger Window Switch in both directions several times. Wait 30 seconds. With the scan tool, read DTCs. Does the scan tool display B191D-WINDOW CONTROL CIRCUIT OVERCURRENT? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Check for a sticking switch and using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. TEST WINDOW MOTORS Do all window motors operate properly at this time? Yes Check for any sticking switches, restrictions in any window channels or binding regulators and repair or replace as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. WINDOW MOTOR Turn the ignition off. Disconnect the inoperative window motor connector. Turn the ignition on. Connect a 12-volt test light between the Window Driver (UP) circuit and the Window Driver (DOWN) circuit. NOTE: The graphic shows the Left Front Window Motor (LHD), all others are similar, Turn the ignition on. Operate the Window Switch in both directions while observing the test light. Does the test light illuminate brightly when the switch in held in both directions? Yes Replace the window motor or regulator as necessary in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
4. WINDOW DRIVER (UP) CIRCUIT SHORT TO GROUND Turn the ignition off. Disconnect the Driver Power Window Switch C1 and C2 connectors. Measure the resistance between ground and the Window Driver (Up) circuit in the motor connector. Is the resistance below 10, 000.0 Ohms? Yes Repair the Window Driver (Up) circuit for a short to ground. If this is not the driver window, the short could be from the master switch to the motor. Using the Power Window Schematic, check for the proper circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 5 .
5. WINDOW DRIVER (DOWN) CIRCUIT SHORT TO GROUND Measure the resistance between ground and the Window Driver (Down) circuit in the motor connector. Is the resistance below 10, 000 Ohms? Yes Repair the Window Driver (Down) circuit for a short to ground. If this is not the driver window, the short could be from the master switch to the motor. Check the Power Window Schematic for the proper circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Check the Window Driver (Up) circuit for a short to the Window Driver Down circuit. Repair if the resistance is under 10, 000.0 Ohms. If okay, check all the windows for alignment or any reason for the heavy current draw. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

(F200) Fused Ignition Switch Output (Run-Start) circuit low.

With the ignition on.

The Totally Integrated Power Module (TIPM) detects a short to ground on the A/C Pressure Sensor Supply circuit.

With the ignition on.

The Totally Integrated Power Module (TIPM) detects high voltage or an open on the A/C Pressure Sensor Supply circuit.

With the ignition on.

The Totally Integrated Power Module (TIPM) detects a short to ground condition on the Fused Ignition Switch Output (RUN).

Scheme 227

Scheme 228

Scheme 229

Scheme 230

1. CHECK FOR ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Check all fuses. If any fuses are open, diagnose the appropriate circuit. With the scan tool, read the DTCs. Cycle the ignition switch from off to on, leaving the ignition on for a minimum of 10 seconds. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Using the wiring diagram/schematic as a guide, visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
2. CHECK FOR SHORT TO GROUND ON (F100) FUSED IGNITION SWITCH OUTPUT (RUN) CIRCUIT Turn the ignition off. Remove fuse number 27. Turn the ignition on. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go To 5 . No Go To 3 .
3. CHECK ORC FOR A SHORT TO GROUND WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Turn the ignition off. Disconnect the ORC harness connector. Reinstall fuse number 27. Turn the ignition on. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go To 4 . No Replace the ORC in accordance with the Service Information. Refer to «MODULE, OCCUPANT RESTRAINT CONTROLLER, REMOVAL»(ref-485488-S18365749822012071300000) . Refer to «STANDARD PROCEDURE»(ref-485515-S14989137882012071300000) and perform the AIRBAG SYSTEM VERIFICATION TEST.
4. CHECK FOR SHORT TO GROUND ON (F100) FUSED IGNITION SWITCH OUTPUT (RUN) CIRCUIT Turn the ignition off. Disconnect the TIPM C7 harness connector. Measure the resistance between the (F100) Fused Ignition Switch Output (Run) circuit and ground. Is the resistance below 10k Ohms? Yes Repair the (F100) Fused Ignition Switch Output (Run) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Test complete.
5. CHECK FOR SHORT TO GROUND ON (F929) FUSED IGNITION SWITCH OUTPUT (RUN) CIRCUIT Turn the ignition off. Remove fuse number 22. Turn the ignition on. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-485482-S02522181472012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 6 .
6. CHECK THE A/C HEATER CONTROL FOR A SHORT TO GROUND Turn the ignition off. Disconnect the A/C Heater Control harness connector. Reinstall fuse number 22. Turn the ignition on. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go To 7 . No Replace the A/C Heater Control in accordance with the Service Information. Refer to «CONTROL, A/C AND HEATER, REMOVAL»(ref-485480-S08818067002012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
7. CHECK COMPASS MODULE FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Compass Module harness connector. Turn the ignition on. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go To 8 . No Replace the Compass Module in accordance with the Service Information. Refer to «MODULE, COMPASS, REMOVAL»(ref-485512-S34281634072012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
8. CHECK FOR SHORT TO GROUND ON (F929) FUSED IGNITION SWITCH OUTPUT (RUN) CIRCUIT Turn the ignition off. Disconnect the TIPM C8 harness connector. Measure the resistance between the (F929) Fused Ignition Switch Output (Run) circuit and ground. Is the resistance below 10k Ohms? Yes Repair the (F929) Fused Ignition Switch Output (Run) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-485482-S02522181472012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

Scheme 231

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Totally Integrated Power Module (TIPM) detects a short to ground condition on the Fused Ignition Switch Output (RUN/ACC) circuit.

Scheme 232

Scheme 233

Scheme 234

Scheme 235

1. CHECK FOR ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Check all fuses. Using the scan tool, read the DTCs. Cycle the ignition switch from off to on, leaving the ignition on for a minimum of 10 seconds. Using the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Using the wiring diagram/schematic as a guide, visually inspect the related wiring harness connectors. Look for broken, bent, pushed out or corroded terminals. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. CHECK TIPM FOR AN INTERNAL SHORT TO GROUND Turn the ignition off. Remove fuse 16. Turn the ignition on. Using the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Replace the TIPM in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. CHECK SUNROOF MOTOR FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Sunroof Motor harness connector. Turn the ignition on. Using the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go To 4 . No Replace the Sunroof Motor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
4. CHECK THE INSTRUMENT PANEL POWER OUTLET FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Instrument Panel Power Outlet harness connector. Turn the ignition on. Using the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go To 5 . No Replace the Instrument Panel Power Outlet in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
5. CHECK FOR SHORT TO GROUND ON THE (F996) IGNITION SWITCH OUTPUT (RUN/ACC) CIRCUIT Turn the ignition off. Disconnect the TIPM C7 harness connector. Measure the resistance between ground and the (F996) Ignition Switch Output (RUN/ACC) circuit. Is the resistance below 10K Ohms? Yes Repair the (F996) Ignition Switch Output (RUN/ACC) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 6 .
6. CHECK FOR SHORT TO GROUND ON THE (F986) IGNITION SWITCH OUTPUT (RUN/ACC) CIRCUIT Disconnect the TIPM C8 harness connector. Measure the resistance between ground and the (F986) Ignition Switch Output (RUN/ACC) circuit. Is the resistance below 10K Ohms? Yes Repair the (F986) Ignition Switch Output (RUN/ACC) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

Scheme 236

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Ignition Run Control 2 Circuit Low.

With the ignition on.

(F901) Fused Ignition Switch Output (Unlock-Run-Start) circuit low.

B218B-IGNITION RUN/START 1 CONTROL CIRCUIT OVERCURRENT

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Over current condition detected on the Fused Ignition Switch Output (Run-Start) circuit.

With the ignition on.

The Totally Integrated Power Module (TIPM) will set this code if the Vehicle Identification Number (VIN) stored in the TIPM does not match the VIN message on the CAN C Bus.

Continuously.

The Totally Integrated Power Module (TIPM) detects an internal fault.

B222C-VEHICLE CONFIGURATION NOT PROGRAMMED

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Totally Integrated Power Module (TIPM) is not configured correctly to the vehicle.

With the ignition on.

The Totally Integrated Power Module (TIPM) detects a short to ground condition.

Scheme 237

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all TIPM DTCs. Turn the Wipers on. With the scan tool, read the Wiper DTCs. Does the scan tool read: B2304-WIPER PARK SWITCH INPUT CIRCUIT LOW? Yes Go To 2 . No The condition that caused the symptom is currently not present. Inspect the related wiring for a possible intermittent condition. Look for any chafed, pierced, pinched, or partially broken wires. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. WIPER MOTOR With the scan tool, erase DTCs. Turn the ignition off. Disconnect the Front Wiper Motor harness connector. Turn the ignition on. Wait 30 seconds With the scan tool, read DTCs. Does the Scan Tool read: B2305-WIPER PARK SWITCH INPUT CIRCUIT HIGH? Yes Replace the Front Wiper Motor in accordance with the Service Information. Refer to «MOTOR, WIPER, FRONT, REMOVAL»(ref-485521-S26657431602012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. (W7) FRONT WIPER MOTOR PARK SWITCH SENSE CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the TIPM C2 harness connector. Measure the resistance between ground and the (W7) Front Wiper Park Switch Sense circuit. Is the resistance below 5.0 Ohms? Yes Repair the (W7) Front Wiper Park Switch Sense circuit for a short to ground condition. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-485482-S02522181472012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

The Totally Integrated Power Module (TIPM) detects an open condition in the front wiper park switch sense circuit.

With the ignition on.

When the Totally Integrated Power Module (TIPM) detects a short/low condition on the Washer Pump Motor Control circuit.

Scheme 238

Scheme 239

Scheme 240

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all TIPM DTCs. Turn the Washers on. With the scan tool, read the Wiper/Washers DTCs. Does the scan tool read: B231F-FRONT/REAR WASHER MOTOR CONTROL CIRCUIT LOW? Yes Go To 2 . No The condition that caused the symptom is currently not present. Inspect the related wiring for a possible intermittent condition. Look for any chafed, pierced, pinched, or partially broken wires. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. WASHER PUMP MOTOR Turn the ignition off. Disconnect the Washer Pump Motor harness connector. Turn the ignition on. With the scan tool, read the DTCs. Does the scan tool read: B231F-FRONT/REAR WASHER MOTOR CONTROL CIRCUIT LOW? Yes Go To 3 . No Replace the Washer Pump Motor in accordance with the Service Information. Refer to «PUMP, WINDSHIELD WASHER, REMOVAL»(ref-485521-S34169004342012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
3. (W10)/(W20) WASHER PUMP MOTOR CONTROL CIRCUITS SHORT TOGETHER Turn the ignition off. Disconnect the Washer Pump Motor harness connector. Disconnect the TIPM C1 harness connector. Measure the resistance between the (W10) and (W20) Washer Pump Motor Control circuits. Is the resistance below 5.0 Ohms? Yes Repair the (W10) and (W20) Washer Pump Motor Control circuits for a short together. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
4. (W20) WASHER PUMP MOTOR CONTROL CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (W20) Washer Pump Motor Control circuit. Is the resistance below 5.0 Ohms? Yes Repair the (W20) Washer Pump Motor Control circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 5 .
5. (W10) WASHER PUMP MOTOR CONTROL CIRCUIT SHORT TO GROUND Measure the resistance between ground and the (W10) Washer Pump Motor Control circuit. Is the resistance below 5.0 Ohms? Yes Repair the (W10) Washer Pump Motor Control circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the TIPM in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

The Totally Integrated Power Module (TIPM) detects a high condition on the front and rear washer motor control circuits.

Scheme 241

Scheme 242

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all TIPM DTCs. Turn the Washers on. With the scan tool, read the Wiper/Washers DTCs. Does the scan tool read: B2320-FRONT/REAR WASHER MOTOR CONTROL CIRCUIT HIGH? Yes Go To 2 . No The condition that caused the symptom is currently not present. Inspect the related wiring for a possible intermittent condition. Look for any chafed, pierced, pinched, or partially broken wires. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. (W20) REAR WASHER PUMP MOTOR CONTROL CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the TIPM C1 harness connector. Disconnect the Windshield Washer Pump harness connector. Turn the ignition on. Using a 12-volt test light connect to ground, probe the (W20) Rear Washer Pump Motor Control circuit in the Windshield Washer Pump harness connector. Does the test light illuminate? Yes Repair the (W20) Rear Washer Pump Motor Control circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. (W10) WASHER PUMP MOTOR CONTROL CIRCUIT SHORTED TO VOLTAGE Using a 12-volt test light connect to ground, probe the (W10) Front Washer Pump Motor Control circuit in the Windshield Washer Pump harness connector. Does the test light illuminate? Yes Repair the (W10) Front Washer Pump Motor Control circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the Totally Integrated Power Module in accordance with the service information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

Battery voltage greater than 10.4 volts.

When the Totally Integrated Power Module (TIPM) detects the Horn Control Output circuit is shorted to ground.

Scheme 243

Scheme 244

1. VERIFY DTC B2336-HORN CONTROL CIRCUIT LOW IS ACTIVE Turn the ignition on. With the scan tool, erase TIPM DTCs. Operate the Horn Switch several times. With the scan tool, read TIPM DTCs. Does the scan tool display active DTC B2336-HORN CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. (X21) OR (X22) HORN CONTROL OUTPUT CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Horn 1 C1 harness connector. Disconnect the Horn 2 C1 harness connector. Disconnect the TIPM C11 harness connector. Measure the resistance between ground and the (X21) and (X22) Horn Control Output circuits at the Horn 1 and 2 C1 harness connectors. Is the resistance below 100 Ohms? Yes Repair the short to ground in the (X21) or (X22) Horn Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. HORN Connect the TIPM C11 harness connector. Turn the ignition on, engine not running. With the scan tool, actuate the Horn. Using a 12-volt test light connected to ground, check the (X21) and (X22) Horn Control Output circuits at the Horn 1 and 2 C1 harness connectors. Does the test light illuminate brightly and flash on and off? Yes Replace the Horn(s) as necessary in accordance with the service information. Refer to «HORN, REMOVAL»(ref-485508-S33586094812012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
4. TOTALLY INTEGRATED POWER MODULE (TIPM) NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-485482-S02522181472012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

Battery voltage greater than 10.4 volts.

When the Totally Integrated Power Module (TIPM) detects the Horn Control Output circuit is shorted to voltage.

Scheme 245

Scheme 246

1. CHECK FOR ACTIVE DTC B2337-HORN CONTROL CIRCUIT HIGH IN THE TIPM Turn the ignition on. With the scan tool, record and erase DTCs. Operate the Horn Switch several times. With the scan tool, read DTCs. Does the scan tool display active DTC B2337-HORN CONTROL CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. CHECK THE HORNS FOR PROPER OPERATION Turn the ignition off. Disconnect the Horn 1 C1 harness connector. Disconnect the Horn 2 C1 harness connector. Using a fused jumper wire, momentarily connect the (X21) Horn Control Output circuit and B(+) in the Horn 1 C1 component connector. Using a fused jumper wire, momentarily connect the (X22) Horn Control Output circuit and B(+) in the Horn 2 C1 component connector. Do both horns operate properly? Yes Go To 4 . No Go To 3 .
3. (Z920) GROUND CIRCUIT OPEN Disconnect the jumper wire. Disconnect the Horn 1 C2 harness connector. Disconnect the Horn 2 C2 harness connector. Using a 12-volt test light connected to 12-volts, check the (Z920) Ground circuit in the Horn 1 and 2 C2 harness connectors. Does the test light illuminate brightly? Yes Replace the Horn(s) as necessary in accordance with the Service Information. Refer to «HORN, REMOVAL»(ref-485508-S33586094812012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the open or excessive resistance in the (Z920) Ground circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
4. (X21) OR (X22) HORN CONTROL OUTPUT CIRCUIT SHORTED TO VOLTAGE Disconnect the jumper wire. Disconnect the TIPM C11 harness connector. Ignition on, engine not running. Measure the voltage between the (X21) and (X22) Horn Control Output circuits and ground at the Horn 1 and 2 C1 harness connectors. Is there any voltage present? Yes Repair the short to voltage in the (X21) or (X22) Horn Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 5 .
5. TOTALLY INTEGRATED POWER MODULE (TIPM) NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-485482-S02522181472012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

Battery voltage greater than 10.4 volts.

When the Totally Integrated Power Module (TIPM) detects the Horn Control Output circuit is open.

Scheme 247

1. CHECK FOR ACTIVE DTC B2338-HORN CONTROL CIRCUIT OPEN Turn the ignition on. With the scan tool, record and erase DTCs. Operate the Horn switch several times. With the scan tool, read DTCs. Does the scan tool display active DTC B2338-HORN CONTROL CIRCUIT OPEN? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. (X21) AND (X22) HORN CONTROL OUTPUT CIRCUITS OPEN Turn the ignition off. Disconnect the Horn 1 C1 harness connector. Disconnect the Horn 2 C1 harness connector. Disconnect the TIPM C11 harness connector. Measure the resistance of the (X21) and (X22) Horn Control Output circuits between the TIPM C11 harness connector and the Horn 1 and 2 C1 harness connectors. Are the resistances below 5.0 Ohms? Yes Go To 3 . No Repair the open in the (X21) and (X22) Horn Control Output circuits. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
3. CHECK THE HORNS FOR PROPER OPERATION Using a fused jumper wire, momentarily connect the (X21) Horn Control Output circuit and B(+) in the Horn 1 C1 component connector. Using a fused jumper wire, momentarily connect the (X22) Horn Control Output circuit and B(+) in the Horn 2 C1 component connector. Do both horns operate properly? Yes Go To 5 . No Go To 4 .
4. (Z920) GROUND CIRCUIT OPEN Disconnect the jumper wire. Disconnect the Horn 1 C2 harness connector. Disconnect the Horn 2 C2 harness connector. Using a 12-volt test light connected to 12-volts, check the (Z920) Ground circuit in the Horn 1 and 2 C2 harness connectors. Does the test light illuminate brightly? Yes Replace the Horn(s) as necessary in accordance with the Service Information. Refer to «HORN, REMOVAL»(ref-485508-S33586094812012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the open or excessive resistance in the (Z920) Ground circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
5. TOTALLY INTEGRATED POWER MODULE (TIPM) NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-485482-S02522181472012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the Windshield Wipers activated.

When the TIPM detects a low condition.

With the Windshield Wipers are turned on.

When the TIPM detects a high condition.

Whenever the module is awake.

When the Totally Integrated Power Module (TIPM) senses an open in the (W3) Front wiper low speed control circuit.

B234A-WIPER MOTOR HIGH SPEED CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Windshield Wipers on.

When the Totally Integrated Power Module (TIPM) detects a low condition.

B234B-WIPER MOTOR HIGH SPEED CONTROL CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Windshield Wipers on.

When the TIPM detects a high condition.

B234C-WIPER MOTOR HI SPEED CONTROL CIRCUIT OPEN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously with the ignition on and wipers on high speed.

The code will set if the Totally Integrated Power Module detects an open in the front wiper high speed control circuit.

With the ignition on.

The Totally Integrated Power Module (TIPM) detects a problem in the front washer pump motor control circuit.

Scheme 248

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all TIPM DTCs. Turn the Front Wipers on. With the scan tool, read the Front Wiper DTCs. Does the scan tool read: B2367-WINDOW WASHER MOTOR 1 CONTROL CIRCUIT? Yes Go To 2 . No The condition that caused the symptom is currently not present. Inspect the related wiring for a possible intermittent condition. Look for any chafed, pierced, pinched, or partially broken wires. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. (W10) FRONT WASHER PUMP MOTOR CONTROL Turn the ignition off to the lock position. Disconnect the Windshield Washer Pump harness connector. Ignition on, engine not running. Using a 12-volt test light connected to ground, check the (W10) Front Washer Pump Motor Control circuit in the Windshield Washer Pump harness connector while pressing the Front Washer Switch. Does the test light illuminate brightly? Yes Replace the Front Washer Pump Motor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. EXCESSIVE RESISTANCE IN THE (W10) FRONT WASHER PUMP MOTOR CONTROL CIRCUIT Turn the ignition off. Disconnect the TIPM C1 harness connector. Measure the resistance of the (W10) Front Washer Pump Motor Control Circuit from the TIPM C1 connector to the Windshield Washer Pump harness connector. Is the resistance above 3.0 Ohms? Yes Repair the excessive resistance in the (W10) Front Washer Pump Motor Control circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the Totally Integrated Power Module (TIPM) in accordance with the service information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the Window Washers activated.

When the Totally Integrated Power Module (TIPM) detects a low condition in the front washer pump motor control circuit.

With the Washer Pump Motor turned on.

When the Totally Integrated Power Module (TIPM) detects a high condition in the front washer pump motor control circuit.

B236A WINDOW WASHER MOTOR 1 CONTROL CIRCUIT OPEN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

B236F-WIPER MOTOR LOW SPEED CONTROL CIRCUIT OVERCURRENT

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 12.0 volts.

An over current condition in the Front Wiper Low Speed Control Output circuit.

With the ignition on.

Battery voltage greater than 12.0 volts.

An over current condition in the Front Wiper High Speed Control Output Circuit.

With the ignition on.

Battery voltage greater than 10.4 volts.

When the Totally Integrated Power Module (TIPM) detects excessive current draw in the Horn Control Output circuit.

Scheme 249

1. CHECK FOR ACTIVE DTC B2371-HORN CONTROL CIRCUIT OVERCURRENT Turn the ignition on. With the scan tool, record and erase DTCs. Operate the Horn switch several times. With the scan tool, read DTCs. Does the scan tool display active DTC B2371-HORN CONTROL CIRCUIT OVERCURRENT? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. VISUAL AND PHYSICAL CONNECTOR AND TERMINAL INSPECTION Turn the ignition off. Inspect the following connector terminal condition. Check for signs of corrosion build up or damage that would compromise the terminal to controller pin connector. NOTE: Make sure that all in-line connectors are inspected for corrosion and/or damage. Disconnect the Horn harness connectors. Disconnect the TIPM C11 harness connector. Visually inspect the wiring harness. Look for any chafed, pierced, pinched or partially broken wires hidden in the wire insulation. Were any of the above conditions found? Yes Repair or replace as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. (X21) OR (X22) HORN CONTROL OUTPUT CIRCUIT HIGH RESISTANCE Connect a jumper wire between the (X21) Horn Control Output circuit and ground in the Horn 1 C1 harness connector. Using a 12-volt test light connected to 12-volts, check the (X21) Control Output circuit in the TIPM C11 harness connector. Connect a jumper wire between the (X22) Horn Control Output circuit and ground in the Horn 2 C1 harness connector. Using a 12-volt test light connected to 12-volts, check the (X22) Control Output circuit in the TIPM C11 harness connector. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 4 . No Repair the excessive resistance in the (X21) or (X22) Horn Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
4. CHECK THE HORNS FOR PROPER OPERATION Momentarily connect a jumper wire between the (X21) Horn Control Output circuit and B(+) in the Horn 1 C1 component connector. Momentarily connect a jumper wire between the (X22) Horn Control Output circuit and B(+) in the Horn 2 C1 component connector. Do both horns operate properly? Yes Go To 6 . No Go To 5 .
5. (Z920) GROUND CIRCUIT OPEN Disconnect the jumper wire. Using a 12-volt test light connected to 12-volts, check the (Z920) Ground circuit in the Horn 1 and 2 C2 harness connectors. Does the test light illuminate brightly? Yes Replace the Horn(s) as necessary. Refer to «HORN, REMOVAL»(ref-485508-S33586094812012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the open or excessive resistance in the (Z920) Ground circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
6. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Disconnect the jumper wire. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-485482-S02522181472012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

Scheme 250

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition off and all doors closed.

CAN Bus ready to go to sleep and brake input active for more than three minutes.

Scheme 251

Scheme 252

1. ACTIVE DTC NOTE: If any Powertrain Brake DTCs are present they must be repaired before continuing. NOTE: Make sure the Stop Lamp Switch is properly adjusted before continuing. Ignition on, engine not running. With a scan tool, select View DTCs. Is the DTC Active at this time? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. STOP LAMP SWITCH Turn the ignition off. Disconnect the Stop Lamp Switch. Measure the resistance between the (A924) Fused B+ terminal and the (L53) Stop Lamp Switch Output terminal in the Stop Lamp Switch. Apply and release the brake pedal while monitoring the ohmmeter. Does the resistance change from below 5.0 Ohms to an open circuit? Yes Go To 3 . No Replace the Stop Lamp Switch. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
3. (L53) STOP LAMP SWITCH OUTPUT CIRCUIT Reconnect the Stop Lamp Switch. Disconnect the Totally Integrated Power Module (TIPM) C3 harness connector. Turn the ignition on. Using a 12-volt test light connected to ground, check the (L53) Stop Lamp Switch Output circuit in the Totally Integrated Power Module (TIPM) C3 harness connector while pressing and releasing the brake pedal several times. Does the test light change from illuminated when the pedal is pressed to not illuminated when the pedal is released? Yes Replace and program the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the (L53) Stop Lamp Switch Output circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

Scheme 253

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

When the Totally Integrated Power Module indicates that the Brake Fluid Level Circuit is greater than 4.9 volts for more than five seconds.

With the ignition on.

Battery voltage greater than 10 volts.

A/C Switch on.

A shorted condition is detected in the A/C clutch control circuit. One Trip Fault. Three good trips to turn off the MIL.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE for 2.4L or STANDARD PROCEDURE for 3.6L.

Scheme 254

Scheme 255

1. ACTIVE DTC Start the engine. Allow the engine to reach normal operating temperature. Turn the A/C on. With a scan tool, select View DTCs. Is the DTC Active at this time? Yes Go To 2 . No Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the INTERMITTENT CONDITION diagnostic procedure.
2. A/C CLUTCH CONTROL OPERATION FROM THE PCM Turn the ignition off. Disconnect the TIPM C1 harness connector. Ignition on, engine not running. Using a 12-volt test light connected to 12-volts, check the (C13) A/C Clutch Control circuit in the TIPM C1 harness connector. With the scan tool under the PCM Actuators, actuate the A/C Clutch. Does the test light illuminate brightly and flash on an off? Yes Go To 3 . No Refer to «P0645-A/C CONTROL CIRCUIT/OPEN»(ref-485543-S34393469662012071300000) and perform the Diagnostic Procedure.
3. (C3) A/C CLUTCH CONTROL OUTPUT CIRCUIT SHORTED TO GROUND Turn the ignition off Disconnect the TIPM C10 harness connector. Disconnect the A/C Compressor Clutch harness connector. Measure the resistance between ground and the (C3) A/C Clutch Control Output circuit at the A/C Compressor Clutch harness connector. Is the resistance below 100 Ohms? Yes Repair the short to ground in the (C3) A/C Clutch Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST. No Go To 4 .
4. A/C COMPRESSOR CLUTCH Connect the TIPM C1 and TIPM C10 harness connectors. Ignition on, engine not running. Using a 12-volt test light connected to ground, check the (C3) A/C Clutch Control Output circuit at the A/C Compressor Clutch harness connector. With the scan tool under the TIPM Actuators, actuate the A/C Clutch. Does the test light illuminate brightly and flash on and off? Yes Replace the A/C Compressor Clutch in accordance with the Service Information. Refer to «COMPRESSOR, A/C, REMOVAL»(ref-485480-S16902540862012071300000) . Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST. No Go To 5 .
5. TOTALLY INTEGRATED POWER MODULE (TIPM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the A/C Clutch, TIPM, and the Powertrain Control Module (PCM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the A/C Clutch, TIPM, and Powertrain Control Module connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST. No Replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

Battery voltage greater than 10 volts.

A/C Switch on.

A shorted high condition has been detected in the A/C Clutch Control output circuit by the Totally Integrated Power Module (TIPM). One Trip Fault. Three good trips to turn off the MIL.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE for 2.4L or STANDARD PROCEDURE for 3.6L.

Scheme 256

Scheme 257

Scheme 258

1. A/C CLUTCH OPERATION Ignition on, engine not running. With a scan tool under the PCM Actuators, actuate the A/C Clutch. Is the A/C Clutch actuating? Yes Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the INTERMITTENT CONDITION diagnostic procedure. No Go To 2 .
2. A/C CLUTCH CONTROL OPERATION FROM THE PCM Turn the ignition off. Disconnect the TIPM C1 harness connector. Ignition on, engine not running. With the scan tool under the TPIM Actuators, actuate the A/C Clutch. Using a 12-volt test light connected to ground, check the (C13) A/C Clutch Control circuit in the TIPM C1 harness connector. Does the test light illuminate brightly and flash on an off? Yes Go To 3 . No Refer to «P0645-A/C CONTROL CIRCUIT/OPEN»(ref-485543-S34393469662012071300000) and perform the diagnostic procedure.
3. (C3) A/C CLUTCH CONTROL OUTPUT CIRCUIT SHORTED TO BATTERY VOLTAGE Turn the ignition off Disconnect the TIPM C10 harness connector. Disconnect the A/C Compressor Clutch harness connector. Ignition on, engine not running. Measure the voltage on the (C3) A/C Clutch Control Output circuit at the A/C Compressor Clutch harness connector. Is any voltage present? Yes Repair the short to battery voltage in the (C3) A/C Clutch Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST. No Go To 4 .
4. A/C CLUTCH GROUND CIRCUIT OPEN Turn the ignition off. Connect the TIPM C1 and TIPM C10 harness connectors. Using a 12-volt test light connected to ground, check the (Z931) A/C Clutch ground circuit at the A/C Compressor Clutch harness connector. Does the test light illuminate brightly? Yes Go To 5 . No Repair the excessive resistance in the (Z931) A/C Clutch ground circuit. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST.
5. A/C COMPRESSOR CLUTCH Ignition on, engine not running. With the scan tool under the TIPM Actuators, actuate the A/C Clutch. Using a 12-volt test light connected to ground, check the (C3) A/C Clutch Control Output circuit at the A/C Compressor Clutch harness connector. Does the test light illuminate brightly and flash on and off? Yes Replace the A/C Compressor Clutch in accordance with the service information. Refer to «COMPRESSOR, A/C, REMOVAL»(ref-485480-S16902540862012071300000) . Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST. No Go To 6 .
6. TOTALLY INTEGRATED POWER MODULE (TIPM) NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST. No Replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

Battery voltage greater than 10.4 volts.

Totally Integrated Power Module (TIPM) requesting A/C Clutch operation.

An open condition has been detected in the A/C Clutch Control Output circuit by the TIPM. One Trip Fault. Three good trips to turn off the MIL.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE for 2.4L or STANDARD PROCEDURE for 3.6L.

Scheme 259

1. A/C CLUTCH OPERATION Ignition on, engine not running. With a scan tool under the PCM Actuators, actuate the A/C Clutch. Is the A/C Clutch actuating? Yes Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the INTERMITTENT CONDITION diagnostic procedure. No Go To 2 .
2. A/C CLUTCH CONTROL OPERATION FROM THE PCM Turn the ignition off. Disconnect the TIPM C1 harness connector. Ignition on, engine not running. With the scan tool under the TPIM Actuators, actuate the A/C Clutch. With a 12-volt test light connected to ground, probe the (C13) A/C Clutch Control circuit in the TIPM C1 harness connector. Does the test light illuminate brightly and flash on an off? Yes Go To 3 . No Refer to «P0645-A/C CONTROL CIRCUIT/OPEN»(ref-485543-S34393469662012071300000) and perform the diagnostic procedure.
3. (C3) A/C CLUTCH CONTROL OUTPUT CIRCUIT OPEN Turn the ignition off Disconnect the TIPM C10 harness connector. Disconnect the A/C Clutch harness connector. Measure the resistance of the (C3) A/C Clutch Control Output circuit between the TIPM C10 harness connector and the A/C Clutch harness connector. Is the resistance below 5.0 Ohms? Yes Go To 4 . No Repair the open in the (C3) A/C Clutch Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST .
4. A/C CLUTCH Connect the TIPM C1 and C10 harness connectors. Ignition on, engine not running. With the scan tool under the TIPM Actuators, actuate the A/C Clutch. Using a 12-volt test light connected to ground, check the (C3) A/C Clutch Control Output circuit at the A/C Compressor Clutch harness connector. Does the test light illuminate brightly and flash on and off? Yes Replace the A/C Clutch in accordance with the Service Information. Refer to «COMPRESSOR, A/C, REMOVAL»(ref-485480-S16902540862012071300000) . Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST . No Go To 5 .
5. TOTALLY INTEGRATED POWER MODULE (TIPM) NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST . No Replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

Scheme 260

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 10.4 volts and Main Relay is on.

Totally Integrated Power Module (TIPM) requesting Starter operation.

Actual Starter state is not equal to desired state. One Trip Fault. Three good trips to turn off the Malfunction Indicator Lamp (MIL).

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE for 2.4L or STANDARD PROCEDURE for 3.6L.

Scheme 261

Scheme 262

1. DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: If P0615, P0616 or P0617 has set along with this DTC, diagnose those DTCs first before continuing. Turn the Ignition on, engine not running. Using the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go To 2 . No Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the INTERMITTENT CONDITION diagnostic procedure.
2. STARTER CONTROL OUTPUT OPERATION Turn the ignition off. Disconnect the Starter (1-way) harness connector. Using a 12-volt test light connected to ground, check the (T750) Starter Control Output circuit in the Starter (1-way) harness connector. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts or fan. Do not wear loose clothing. Failure to follow these instructions may result in possible serious or fatal injury. Crank the engine and monitor the test light. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Replace the Starter in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST . No Go To 3 .
3. (T750) STARTER CONTROL OUTPUT CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the TIPM C10 harness connector. Measure the resistance between ground and the (T750) Starter Control Output circuit at the TIPM C10 harness connector. Is the resistance below 100 Ohms? Yes Repair the short to ground in the (T750) Starter Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST . No Go To 4 .
4. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST . No Replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

Battery voltage greater than 10.4 volts and Main Relay is on.

Totally Integrated Power Module (TIPM) requesting Starter operation.

Actual Starter state is not equal to desired state. One Trip Fault. Three good trips to turn off the MIL.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE for 2.4L or STANDARD PROCEDURE for 3.6L.

Scheme 263

1. DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: If P0615, P0616 or P0617 has set along with this DTC, diagnose those DTCs first before continuing. Turn the Ignition on, engine not running. Using the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go To 2 . No Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the INTERMITTENT CONDITION diagnostic procedure .
2. STARTER CONTROL OUTPUT VERIFICATION Turn the ignition off. Disconnect TIPM C10 harness connector. Turn the ignition on. Measure the voltage of the (T750) Starter Control Output circuit in the TIPM C10 harness connector. Is there any voltage present? Yes Go To 3 . No Go To 4 .
3. (T750) STARTER CONTROL OUTPUT CIRCUIT SHORTED TO BATTERY VOLTAGE Turn the ignition off Disconnect the Starter (1-way) harness connector. Turn the ignition on. Measure the voltage between ground and the (T750) Starter Control Output circuit in the TIPM C10 harness connector. Is there any voltage present? Yes Repair the short to voltage in the (T750) Starter Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST . No Replace the Starter in accordance with the Service information. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST .
4. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST . No Replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

Battery voltage greater than 10.4 volts and Main Relay is on.

Totally Integrated Power Module (TIPM) requesting Starter operation.

Actual Starter state is not equal to desired state. One Trip Fault. Three good trips to turn off the MIL.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE for 2.4L or STANDARD PROCEDURE for 3.6L.

Scheme 264

Scheme 265

1. DTC IS ACTIVE NOTE: If P0615, P0616 or P0617 has set along with this DTC, diagnose those DTCs first before continuing. Ignition on, engine not running. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go To 2 . No Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the INTERMITTENT CONDITION diagnostic procedure .
2. STARTER CONTROL OUTPUT OPERATION Turn the ignition off. Disconnect the Starter (1-way) harness connector. Using a 12-volt test light connected to ground, check the (T750) Starter Control Output circuit in the Starter (1-way) harness connector. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts or fan. Do not wear loose clothing. Failure to follow these instructions may result in possible serious or fatal injury. Crank the engine and monitor the test light. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Replace the Starter in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST . No Go To 3 .
3. (T750) STARTER CONTROL OUTPUT CIRCUIT OPEN Turn the ignition off Disconnect the TIPM 10 harness connector. Measure the resistance of the (T750) Starter Control Output circuit between the TIPM C10 harness connector and the Starter harness connector. Is the resistance below 5.0 Ohms? Yes Go To 4 . No Repair the open in the (T750) Starter Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST .
4. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST . No Replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

P127A-STARTER CONTROL CIRCUIT 2 OVERCURRENT

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 10.4 volts and Main Relay is on.

Totally Integrated Power Module (TIPM) requesting Starter operation.

An overcurrent condition is detected in the Starter control output circuit. One Trip Fault. Three good trips to turn off the MIL.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE for 2.4L or STANDARD PROCEDURE for 3.6L.

Scheme 266

1. DTC IS ACTIVE NOTE: If P0615, P0616 or P0617 has set along with this DTC, diagnose those DTCs first before continuing. Ignition on, engine not running. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go To 2 . No Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the INTERMITTENT CONDITION diagnostic procedure .
2. VISUAL AND PHYSICAL CONNECTOR AND TERMINAL INSPECTION NOTE: Make sure the Starter is bolted securely and is properly mounted. Turn the ignition off. Disconnect the TIPM C10 harness connector. Disconnect the Starter (1-way) harness connector. Inspect the terminal and connector condition. Check for signs of corrosion build up or damage that would compromise the terminal to controller pin connector. NOTE: Make sure that all in-line connectors are inspected for corrosion and/or damage. Visually inspect the wiring harness. Look for any chafed, pierced, pinched or partially broken wires hidden in the wire insulation. Were any of the above conditions found? Yes Repair or replace as necessary. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST . No Go To 3 .
3. STARTER CONTROL OUTPUT OPERATION Turn the ignition off. Reconnect the TIPM C10 harness connector. Using a 12-volt test light connected to ground, check the (T750) Starter Control Output circuit in the Starter (1-way) harness connector. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts or fan. Do not wear loose clothing. Failure to follow these instructions may result in possible serious or fatal injury. Crank the engine and monitor the test light. NOTE: The test light should be illuminated only when cranking the engine. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly when cranking the engine and then turn off when it is not being cranked? Yes Replace the Starter in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST . No Go To 4 .
4. (T750) STARTER CONTROL OUTPUT CIRCUIT HIGH RESISTANCE Turn the ignition off. Disconnect the TIPM C10 harness connector. Connect a jumper wire between the (T750) Starter Control Output circuit in the Starter harness connector and a clean chassis ground. Using a 12-volt test light connected to 12-volts, check the (T750) Starter Control Output circuit in the TIPM C10 harness connector. NOTE: The test light should be illuminated and bright. Compared the brightness to that of a direct connection to the battery. Does the test light illuminate brightly. Yes Go To 5 . No Repair the high resistance in the (T750) Starter Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST .
5. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

P127C-FUEL PUMP CONTROL CIRCUIT 2 LOW

For a complete wiring diagram refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on. Battery voltage greater than 10.4 volts and the Main Relay on. TIPM requesting Fuel Pump operation.

Actual Fuel Pump state is not equal to desired state. One Trip Fault. Three good trips to turn off the MIL.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE for 2.4L or STANDARD PROCEDURE for 3.6L.

P127D-FUEL PUMP CONTROL CIRCUIT 2 HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on. Battery voltage greater than 10.4 volts and the Main Relay on. TIPM requesting Fuel Pump operation.

Actual Fuel Pump state is not equal to desired state. One Trip Fault. Three good trips to turn off the MIL.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE for 2.4L or STANDARD PROCEDURE for 3.6L .

P127E-FUEL PUMP CONTROL CIRCUIT 2 OPEN

For a complete wiring diagram refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on. Battery voltage greater than 10.4 volts and the Main relay is on. TIPM requesting Fuel Pump operation.

Actual Fuel Pump state is not equal to desired state. One Trip Fault. Three good trips to turn off the MIL.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE for 2.4L or STANDARD PROCEDURE for 3.6L .

P127F-FUEL PUMP CONTROL CIRCUIT 2 OVERCURRENT

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 10.4 volts.

Totally Integrated Power Module (TIPM) requesting fuel pump operation.

An overcurrent condition is detected in the Fuel Pump control output circuit. One Trip Fault. Three good trips to turn off the MIL.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE for 2.4L or STANDARD PROCEDURE for 3.6L .

With the ignition on.

Battery voltage greater than 10.0 volts.

The Totally Integrated Power Module (TIPM) has detected a short to ground condition in the Transmission Control Output circuit.

Scheme 267

1. CHECK IF THE DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read TIPM DTCs. Does the scan tool display this DTC as Active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. CHECK THE (T16) TRANSMISSION CONTROL OUTPUT CIRCUIT FOR A SHORT TO GROUND Turn the ignition off to the lock position. Disconnect the TIPM C10 harness connector. Disconnect the PCM C1 harness connector. Disconnect the Transmission Solenoid/Pressure Switch Assembly harness connector. Disconnect the Line Pressure Sensor/Variable Force Solenoid Assembly harness connector (4-Speed Automatic Transmission). Measure the resistance between ground and the (T16) Transmission Control Output circuit. Is the resistance above 10k Ohms? Yes Go To 3 . No Repair the short to ground in the (T16) Transmission Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
3. CHECK THE TIPM FOR CORRECT OPERATION Turn the ignition off. Reconnect the TIPM C10 harness connector. Ignition on, engine not running. With the scan tool, actuate the Transmission Relay system test. Using a 12-volt test light connected to ground, check the (T16) Transmission Control Output circuits. Does the test light illuminate brightly at the (T16) Transmission Control Output circuits? Yes Go To 4 . No Replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
4. CHECK THE TRANSMISSION SOLENOID/PRESSURE SWITCH ASSEMBLY FOR A SHORT Turn the ignition off. Reconnect the Transmission Solenoid/Pressure Switch Assembly harness connector. Ignition on, engine not running. With the scan tool, read TIPM DTCs. Does the scan tool display this DTC as Active? Yes Replace the Transmission Solenoid/Pressure Switch Assembly in accordance with the Service Information. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) or «62TE TRANSMISSION VERIFICATION TEST»(ref-485571-S26684901912012071300000) and perform the appropriate TRANSMISSION VERIFICATION TEST. No For vehicles with a 40TE Transmission, replace the Line Pressure Sensor/Variable Force Solenoid in accordance with the Service Information. Perform the 40/41TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . For vehicles with a 62TE Transmission, test complete.

P128C-TCM POWER CONTROL CIRCUIT 2 HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on with the battery voltage greater than 10.0 volts.

The Totally Integrated Power Module (TIPM) has detected voltage on the Transmission Control Output circuit when none should be present.

Scheme 268

1. CHECK IF THE DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read TIPM DTCs. Is the status Active for this DTC? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
2. CHECK THE (T16) TRANSMISSION CONTROL OUTPUT CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the TIPM C10 harness connector. Disconnect the PCM C1 harness connector. Turn the ignition on. Measure the voltage between ground and the (T16) Transmission Control Output circuit. Is the voltage above 10.0 volts? Yes Repair the short to voltage in the (T16) Transmission Control Output circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Using the schematics as a guide, check the Totally Integrated Power Module (TIPM) terminals for corrosion, damage, water intrusion, or terminal push out. Check for any Service Bulletins that may apply. If no problems are found, replace and program the TIPM in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

P128D-TCM POWER CONTROL CIRCUIT 2 OPEN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 10.0 volts.

The Totally Integrated Power Module (TIPM) has detected an open condition on the Transmission Control Output circuit.

P128E-TCM POWER CONTROL CIRCUIT 2 OVERCURRENT

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 10.0 volts.

The Totally Integrated Power Module (TIPM) has detected an overcurrent condition in the Transmission Control Output circuit.

With the ignition on.

A CAN C Bus module (except the TIPM) detects a short in either CAN C Bus circuit.

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any Technical Service Bulletins (TSBs) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. ANTILOCK BRAKE MODULE - INTERNAL SHORT Turn the ignition off. Disconnect the Antilock Brake Module harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 3 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Antilock Brake Module in accordance with the Service Information. Refer to «MODULE, ANTI-LOCK BRAKE SYSTEM, REMOVAL»(ref-485482-S28697645202012071300000) . Refer to «STANDARD PROCEDURE»(ref-485487-S19412834172012071300000) and perform the ABS VERIFICATION TEST.
3. POWERTRAIN CONTROL MODULE - INTERNAL SHORT Turn the ignition off. Disconnect the Powertrain Control Module C1 harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 4 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Powertrain Control Module in accordance with the Service Information. Refer to «MODULE, POWERTRAIN CONTROL, REMOVAL»(ref-485482-S06048014282012071300000) . Refer to «STANDARD PROCEDURE»(ref-485547-S35074881862012071300000) for 2.4L or «STANDARD PROCEDURE»(ref-485569-S08442602642012071300000) for 3.6L and perform the POWERTRAIN VERIFICATION TEST .
4. STEERING ANGLE SENSOR - INTERNAL SHORT Turn the ignition off. NOTE: If vehicle is not equipped with this sensor, answer yes to the question. Disconnect the Clockspring C3 harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 5 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Steering Angle Sensor in accordance with the Service Information. Refer to «CLOCKSPRING, REMOVAL»(ref-485488-S39236840502012071300000) . Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
5. (D65) CAN C BUS (+) CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the Totally Integrated Power Module C2 and C3 harness connectors. Turn the ignition on. Measure the voltage between the (D65) CAN C Bus (+) circuit and ground on both connectors. Is there any voltage present? Yes Repair the (D65) CAN C Bus (+) circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 6 .
6. (D64) CAN C BUS (-) CIRCUIT SHORTED TO VOLTAGE Measure the voltage between the (D64) CAN C Bus (-) circuit and ground. Is there any voltage present? Yes Repair the (D64) CAN C Bus (-) circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 7 .
7. (D65) CAN C BUS (+) CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (D65) CAN C Bus (+) circuit. Is any resistance present? Yes Repair the (D65) CAN C Bus (+) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 8 .
8. (D64) CAN C BUS (-) CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (D64) CAN C Bus (-) circuit. Is any resistance present? Yes Repair the (D64) CAN C Bus (-) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 9 .
9. (D65) CAN C BUS (+) CIRCUIT SHORTED TO THE (D64) CAN C BUS (-) CIRCUIT Measure the resistance between the (D65) CAN C Bus (+) circuit and the (D64) CAN C Bus (-) circuit. Is any resistance present? Yes Repair the (D65) CAN C Bus (+) circuit for a short to the (D64) CAN C Bus (-) circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

A CAN B Bus module detects an open, a short high, a short low or a short together in either of the CAN B Bus circuits.

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any Technical Service Bulletins (TSBs) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. MEASURE VOLTAGE AT TIPM Gain access to the Totally Integrated Power Module C3 harness connector, but do not disconnect. Backprobe and measure the voltage on both the (D55) CAN B Bus (+) and the (D54) CAN B (-) circuits. Does the voltage read approximately 4.65 - 4.98 volts on the (D54) CAN B Bus (-) and 0.39 - 0.46 volts on the (D55) CAN B (+) circuits? Yes Go To 3 . No - Voltage Between 0.3 - 0.7 of a Volt on Both Circuits Go To 9 . No - Voltage Reads 0 Volts on Either Circuit Go To 7 . No - Voltage Above 10 Volts on Either Circuit Go To 5 .
3. (D55) CAN B BUS (+) CIRCUIT OPEN Turn the ignition on. With the scan tool select ECU View. Using a fused jumper wire, connect one end to ground and with the other end backprobe the (D55) CAN B Bus (+) circuit at the TIPM C3 harness connector. NOTE: This may cause some modules to no longer communicate on the Bus. Are some modules no longer communicating? Yes Using the Wiring Diagrams to further isolate the open in the circuit, repair the (D55) CAN B Bus (+) circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
4. (D54) CAN B BUS (-) CIRCUIT OPEN Remove the fused jumper wire. Using a fused jumper wire, connect one end to ground and with the other end backprobe the (D54) CAN B Bus (-) circuit at the TIPM C3 harness connector. NOTE: This may cause some modules to no longer communicate on the Bus. Are some modules no longer communicating? Yes Using the Wiring Diagrams to further isolate the open in the circuit, repair the (D54) CAN B Bus (-) circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Inspect the wiring and connectors for damage. If OK, replace and program the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
5. (D55) CAN B BUS (+) CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the TIPM C3 harness connector. Turn the ignition on. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is the voltage above 10.0 volts? Yes Disconnect each CAN B Bus module one at a time while observing the voltage to determine if the short is caused by an internal short within a module. Replace the module, in accordance with the Service Information, that when disconnected eliminates the short to voltage. If the short condition is still present with all CAN B Bus modules disconnected use the Wiring Diagrams to help isolate and repair the (D55) CAN B Bus (+) circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 6 .
6. (D54) CAN B BUS (-) CIRCUIT SHORTED TO VOLTAGE Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Is the voltage above 10.0 volts? Yes Disconnect each CAN B Bus module one at a time while observing the voltage to determine if the short is caused by an internal short within a module. Replace the module, in accordance with the Service Information, that when disconnected eliminates the short to voltage. If the short condition is still present with all CAN B Bus modules disconnected use the Wiring Diagrams to help isolate and repair the (D54) CAN B Bus (-) circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Inspect the wiring and connectors for damage. If OK, replace and program the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
7. (D55) CAN B BUS (+) CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance between ground and the (D55) CAN B Bus (+) circuit. Is the resistance above 1000.0 Ohms? Yes Go To 8 . No Disconnect each CAN B Bus module one at a time while observing the resistance to determine if the short is caused by an internal short within a module. Replace the module, in accordance with the Service Information, that when disconnected eliminates the short to ground. If the short condition is still present with all CAN B Bus modules disconnected use the Wiring Diagrams to help isolate and repair the (D55) CAN B Bus (+) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
8. (D54) CAN B BUS (-) CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (D54) CAN B Bus (-) circuit. Is the resistance above 1000.0 Ohms? Yes Inspect the wiring and connectors for damage. If OK, replace and program the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Disconnect each CAN B Bus module one at a time while observing the resistance to determine if the short is caused by an internal short within a module. Replace the module, in accordance with the Service Information, that when disconnected eliminates the short to ground. If the short condition is still present with all CAN B Bus modules disconnected use the Wiring Diagrams to help isolate and repair the (D54) CAN B Bus (-) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
9. (D55) CAN B BUS (+) CIRCUIT SHORTED TO THE (D54) CAN B BUS (-) CIRCUIT Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance between the (D55) CAN B Bus (+) circuit and (D54) CAN B Bus (-) circuit. Is any resistance present? Yes Disconnect each CAN B Bus module one at a time while observing the resistance to determine if the short is caused by an internal short within a module. Replace the module, in accordance with the Service Information, that when disconnected eliminates the short between the two circuits. If the short condition is still present with all CAN B Bus modules disconnected use the Wiring Diagrams to help isolate and repair the (D55) CAN B Bus (+) circuit for a short to the (D54) CAN B Bus (-) circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Inspect the wiring and connectors for damage. If OK, replace and program the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

Ignition on

Battery voltage between 10 and 16 volts

The Totally Integrated Power Module (TIPM) detects the (D55) CAN B Bus (+) circuit is open.

Scheme 281

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any Technical Service Bulletins (TSBs) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. ATTEMPT TO ISOLATE THE OPEN CONDITION Turn the ignition on. With the scan tool, select ECU View. Verify that all CAN B Bus modules are communicating with the scan tool. NOTE: If any module is not communicating, perform the appropriate no response test procedure before proceeding. Turn the ignition off. Gain access to the Totally Integrated Power Module C3 harness connector, but do not disconnect. Using a fused jumper wire, connect one end to ground and with the other end backprobe the CAN B Bus (-) circuit at the TIPM C3 harness connector. Turn the ignition on. With the scan tool monitor the ECU View screen and document all the modules that are not communicating. Are there any CAN B Bus modules not communicating? Yes Go To 3 . No Check backprobe connection to ground, make sure it is proper. The CAN B Bus open DTC may no longer be active, it may be stored. Check all module connections. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
3. ATTEMPT TO ISOLATE THE OPEN CONDITION - MULTIPLE MODULES With the scan tool continue monitoring the ECU View screen. Are there multiple CAN B Bus modules not communicating? Yes The most likely cause of this condition is an open CAN B Bus (+) circuit between a common CAN B Bus splice and the modules. Use the wiring diagrams to help you determine where the open condition exists. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
4. (D55) CAN B BUS (+) CIRCUIT OPEN Turn the ignition off. Disconnect the module that is not communicating. Turn the ignition on. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present? Yes Inspect the connector and terminal for damage, inspect for spread terminals, or pushed out terminals. If OK, replace the module in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the (D55) CAN B Bus (+) circuit for an open between the next common splice and the module. Use the wiring diagrams to help you determine where the open condition exists. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

Continuously.

The Totally Integrated Power Module (TIPM) detects the (D55) CAN B Bus (+) circuit is shorted to ground.

Scheme 282

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any Technical Service Bulletins (TSBs) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. CHECK THE (D55) CAN B BUS (+) CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Totally Integrated Power Module C3 harness connector. Measure the resistance between ground and the (D55) CAN B Bus (+) circuit. Is resistance below 1000.0 Ohms? Yes Go To 3 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
3. (D55) CAN B BUS (+) CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (D55) CAN B Bus (+) circuit. While monitoring the ohmmeter, disconnect each CAN B Bus module one at a time. NOTE: This is to determine if the circuit is shorted to ground internally within a module or if the circuit is shorted in the harness. NOTE: Disconnecting an in-line connector can eliminate a module or group of modules from the list of possible causes for this fault. Refer to the wiring diagrams to assist in diagnosis. Is resistance below 1000.0 Ohms with all the CAN B Bus modules disconnected? Yes Repair the (D55) CAN B Bus (+) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the module that when disconnected eliminated the short to ground in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

Continuously.

The Totally Integrated Power Module (TIPM) detects the (D55) CAN B Bus (+) circuit is shorted to voltage.

Scheme 283

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any Technical Service Bulletins (TSBs) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. CHECK THE (D55) CAN B BUS (+) CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the Totally Integrated Power Module C3 harness connector. Turn the ignition on. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is voltage above 10.0 volts? Yes Go To 3 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
3. (D55) CAN B BUS (+) CIRCUIT SHORTED TO VOLTAGE Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. While monitoring the voltmeter, disconnect each CAN B Bus module one at a time. NOTE: When performing the above step, turn the ignition off (wait one minute) before disconnecting any module. When the module is disconnected turn the ignition on to check for a short to voltage. NOTE: This is to determine if the circuit is shorted to voltage internally within a module or if the circuit is shorted to voltage in the harness. NOTE: Disconnecting an in-line connector can eliminate a module or group of modules from the list of possible causes for this fault. Refer to the wiring diagrams to assist in diagnosis. Is the voltage above 10.0 volts with all the CAN B Bus modules disconnected? Yes Repair the (D55) CAN B Bus (+) circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the module that when disconnected eliminated the short to voltage in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Ignition on

Battery voltage between 10 and 16 volts

The Totally Integrated Power Module (TIPM) detects the (D54) CAN B Bus (-) circuit is open.

Scheme 284

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any Technical Service Bulletins (TSBs) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. ATTEMPT TO ISOLATE THE OPEN CONDITION Turn the ignition on. With the scan tool select ECU View. Verify that all CAN B Bus modules are communicating with the scan tool. NOTE: If any module is not communicating, perform the appropriate no response test procedure before proceeding. Turn the ignition off. Gain access to the Totally Integrated Power Module C3 harness connector, but do not disconnect. Using a fused jumper wire, connect one end to ground and with the other end backprobe the CAN B Bus (+) circuit at the TIPM C3 harness connector. Turn the ignition on. With the scan tool monitor the ECU View screen and document all the modules that are not communicating. Are there any CAN B Bus modules not communicating? Yes Go To 3 . No Check backprobe connection to ground, make sure it is proper. The CAN B Bus open DTC may no longer be active, it may be stored. Check all module connections. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
3. ATTEMPT TO ISOLATE THE OPEN CONDITION With the scan tool, continue monitoring the ECU View screen. Are there multiple CAN B Bus modules not communicating? Yes The most likely cause of this condition is an open CAN B Bus (-) circuit between a common CAN B Bus splice and the modules. Use the wiring diagrams to help you determine where the open condition exists. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
4. (D54) CAN B BUS (-) CIRCUIT OPEN Turn the ignition off. Disconnect the module that is not communicating. Turn the ignition on. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Is there any voltage present? Yes Inspect the connector and terminal for damage, inspect for spread terminals, or pushed out terminals. If OK, replace the module in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the (D54) CAN B Bus (-) circuit for an open between the next common splice and the module. Use the wiring diagrams to help you determine where the open condition exists. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

Continuously.

The Totally Integrated Power Module (TIPM) detects the (D54) CAN B Bus (-) circuit is shorted to ground.

Scheme 285

Scheme 286

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any Technical Service Bulletins (TSBs) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. CHECK THE (D54) CAN B BUS (-) CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Totally Integrated Power Module C3 harness connector. Measure the resistance between ground and the (D54) CAN B Bus (-) circuit. Is resistance below 1000.0 Ohms? Yes Go To 3 . No Go To 4 .
3. (D54) CAN B BUS (-) CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (D54) CAN B Bus (-) circuit. While monitoring the ohmmeter, disconnect each CAN B Bus module one at a time. NOTE: This is to determine if the circuit is shorted to ground internally within a module or if the circuit is shorted to ground in the harness. NOTE: Disconnecting an in-line connector can eliminate a module or group of modules from the list of possible causes for this fault. Refer to the wiring diagrams to assist in diagnosis. Is resistance below 1000.0 Ohms with all the CAN B Bus modules disconnected? Yes Repair the (D54) CAN B Bus (-) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the module that when disconnected eliminated the short to ground in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. CHECK THE (D55) CAN B BUS (+) CIRCUIT FOR A SHORT TO THE (D54) CAN B BUS (-) CIRCUIT Measure the resistance between the (D55) CAN B Bus (+) circuit and (D54) CAN B Bus (-) circuit. Is resistance below 1000.0 Ohms? Yes Go To 5 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
5. (D55) CAN B BUS (+) CIRCUIT SHORTED TO THE (D54) CAN B BUS (-) CIRCUIT Measure the resistance between the (D55) CAN B Bus (+) circuit and (D54) CAN B Bus (-) circuit. While monitoring the Ohmmeter, disconnect each CAN B Bus module one at a time. NOTE: This is to determine if the short together is internal within a module or if the circuits are shorted together. NOTE: Disconnecting an in-line connector can eliminate a module or group of modules from the list of possible causes for this fault. Refer to the wring diagrams to assist in diagnosis. Is resistance below 1000.0 Ohms with all the CAN B Bus modules disconnected? Yes Repair the (D55) CAN B Bus (+) circuit for a short to the (D54) CAN B Bus (-) circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the module that when disconnected the short together was eliminated, in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Continuously.

The Totally Integrated Power Module (TIPM) detects the (D54) CAN B Bus (-) circuit is shorted to voltage.

Scheme 287

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any Technical Service Bulletins (TSBs) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. CHECK THE (D54) CAN B BUS (-) CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the Totally Integrated Power Module C3 harness connector. Turn the ignition on. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Is voltage above 10.0 volts? Yes Go To 3 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
3. (D54) CAN B BUS (-) CIRCUIT SHORTED TO VOLTAGE Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. While monitoring the voltmeter, disconnect each CAN B Bus module one at a time. NOTE: When performing the above step, turn the ignition off (wait one minute) before disconnecting any module. When the module is disconnected turn the ignition on to check for a short to voltage. NOTE: This is to determine if the circuit is shorted to voltage internally within a module or if the circuit is shorted to voltage in the harness. NOTE: Disconnecting an in-line connector can eliminate a module or group of modules from the list of possible causes for this fault. Refer to the wiring diagrams to assist in diagnosis. Is the voltage above 10.0 volts with all the CAN B Bus modules disconnected? Yes Repair the (D54) CAN B Bus (-) circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace the module, in accordance with the Service Information, that when disconnected eliminated the short to voltage. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Continuously.

The Totally Integrated Power Module (TIPM) detects the (D55) CAN B Bus (+) circuit is shorted to the (D54) CAN B Bus (-) circuit.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Powertrain Control Module (PCM) for approximately one second.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Antilock Brake Module (ABS) for approximately 500ms.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) configured correctly.

Bus messages not received from the Steering Angle Sensor (SAS) for approximately 500ms.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the TIPM for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Airbag fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Occupant Restraint Controller for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Cluster/Cabin Compartment Node (CCN) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the A/C Heater Control (HVAC) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Wireless Control Module (WCM) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Radio for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Amplifier (AMP) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Hands Free Module (HFM) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Driver Door Module (DDM) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Passenger Door Module (PDM) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Power Top Control Module (PTCM) for approximately two to five seconds.

Continuously

When the CAN B Bus messages are not received within two seconds.

Scheme 288

Scheme 289

1. CHECK FOR ACTIVE DIAGNOSTIC TROUBLE CODE (DTC)S NOTE: Check for any Technical Service Bulletins (TSBs) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. With the scan tool, read the active DTCs. Cycle the ignition switch from off to on at least five times, leaving the ignition on for a minimum of 90 seconds per cycle. With the scan tool, read the active DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out or corroded terminals.
2. CHECK THE MODULE FOR DTC U0019 With the scan tool, read the active DTCs on the module that set the U1105 DTC. Does the scan tool display U0019-CAN B BUS as ACTIVE? Yes Refer to «DIAGNOSIS AND TESTING»(ref-485529-S21413626642012071300000) and perform the U0019-CAN B BUS diagnostic procedure. No Go To 3 .
3. (D55) CAN B BUS (+) CIRCUIT OPEN Turn the ignition off. Disconnect the TIPM C3 harness connector. Turn the ignition on. Measure the voltage of the (D55) CAN B Bus (+) circuit. Is there any voltage present? Yes Go To 4 . No Repair the (D55) CAN B Bus (+) circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
4. (D54) CAN B BUS (-) CIRCUIT OPEN Measure the voltage of the (D54) CAN B Bus (-) circuit. Is there any voltage present? Yes Replace the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the (D54) CAN B Bus (-) circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

With the ignition on.

A CAN C Bus module detects a short in either CAN C Bus circuit.

With the ignition on.

The Totally Integrated Power Module (TIPM) detects an open, a short high, a short low or a short together in either of the CAN B Bus circuits.

Scheme 290

Scheme 291

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any Technical Service Bulletins (TSBs) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. With the scan tool, record and erase TIPM DTCs. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. ANY CAN B BUS MODULE - INTERNAL FAULT Turn the ignition off. With the scan tool, monitor the active TIPM DTCs. While monitoring the scan tool, disconnect each CAN B Bus module one at a time. NOTE: When performing the above step, turn the ignition off (wait one minute) before disconnecting any module. When the module is disconnected turn the ignition on. NOTE: This is to determine if the fault is internal within a module. Check for this DTC to become active after disconnecting each CAN B Bus module the vehicle is equipped with. NOTE: If the DTC becomes stored when a particular CAN B Bus module is disconnected, that module is causing the DTC to set. With all the CAN B Bus modules disconnected did the TIPM still set this DTC as active? Yes Go To 3 . No Replace the module in accordance with the Service Information that when disconnected caused the DTC to become stored. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. (D55) CAN B BUS (+) CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the TIPM C3 harness connector. NOTE: Make sure each CAN B Bus module is disconnected at this time. Turn the ignition on. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is the voltage above 10.0 volts? Yes Repair the (D55) CAN B Bus (+) circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
4. (D54) CAN B BUS (-) CIRCUIT FOR A SHORT TO VOLTAGE NOTE: Make sure each CAN B Bus module is disconnected at this time. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Is the voltage above 10.0 volts? Yes Repair the (D54) CAN B Bus (-) circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 5 .
5. (D55) CAN B BUS (+) CIRCUIT FOR A SHORTED TO GROUND Turn the ignition off. NOTE: Make sure each CAN B Bus module is disconnected at this time. Measure the resistance between ground and the (D55) CAN B Bus (+) circuit. Is the resistance above 1000.0 Ohms? Yes Go To 6 . No Repair the (D55) CAN B Bus (+) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
6. (D54) CAN B BUS (-) CIRCUIT FOR A SHORTED TO GROUND NOTE: Make sure each CAN B Bus module is disconnected at this time. Measure the resistance between ground and the (D54) CAN B Bus (-) circuit. Is the resistance above 1000.0 Ohms? Yes Go To 7 . No Repair the (D54) CAN B Bus (-) circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
7. (D55) CAN B BUS (+) CIRCUIT SHORTED TO THE (D54) CAN B BUS (-) CIRCUIT Measure the resistance between the (D55) CAN B Bus (+) circuit and (D54) CAN B Bus (-) circuit. NOTE: Make sure each CAN B Bus module is disconnected at this time. Is any resistance present? Yes Repair the (D55) CAN B Bus (+) circuit for a short to the (D54) CAN B Bus (-) circuit. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 8 .
8. (D55) CAN B BUS (+) CIRCUIT OPEN Measure the resistance of the (D55) CAN B Bus (+) circuit between the TIPM C3 harness connector and the Cluster C4 harness connector. Is the resistance above 10.0 Ohms? Yes Repair the (D55) CAN B Bus (+) circuit for an open or high resistance. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 9 .
9. (D54) CAN B BUS (-) CIRCUIT OPEN Measure the resistance of the (D54) CAN B Bus (-) circuit between the TIPM C3 harness connector and the Cluster C4 harness connector. Is the resistance above 10.0 Ohms? Yes Repair the (D54) CAN B Bus (-) circuit for an open or high resistance. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Replace and program the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

Continuously.

The Totally Integrated Power Module (TIPM) detects an additional CAN B module and requires a reconfiguration.
