Driver Door Module (Ddm) - Electrical Diagnostics: Diagnosis Dodge Avenger II facelift

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

Scheme 292

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Note. This test shows graphics, circuit numbers and text for a Left Hand Drive (LHD) vehicle. For a Right Hand Drive (RHD) vehicle, refer to the schematic for the different circuit numbers, cavities and names.

Note. Even though the JS27 (Convertible) is not equipped with the Express (AUTO) Up feature, the front window circuits are still referred to as "EXPRESS".

DIAGNOSTIC TEST

1. Replace the Driver Door Module in accordance with the Service Information. NOTE: Anytime this code is logged, the module must be replaced. Repair Replace the Driver Door Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000).

1. CHECK POWERTRAIN CONTROL MODULE DTCs With the scan tool, read Powertrain Control Module (PCM) DTCs. Are there any Charging or Starting DTCs Active? No Go To 2 . Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(/dodge/avenger/ii-facelift-2011-2014/remont/testing-diagnostics/#24l-diagnostic-code-index) or «3.6L - DIAGNOSTIC CODE INDEX»(/dodge/avenger/ii-facelift-2011-2014/remont/testing-diagnostics/#36l-diagnostic-code-index) and perform the appropriate diagnostic procedure .
2. TEST FOR INTERMITTENT CONDITION With the scan tool, record and erase the DTCs. Start the engine and run for two minutes. With the scan tool, read the active DTCs. Does the scan tool display B210E-BATTERY VOLTAGE HIGH? Yes Replace the Driver Door Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000). No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000).

1. Replace the Door Module NOTE: Anytime this code is logged, the module must be replaced. Repair Replace the Driver Door Module. Perform BODY VERIFICATION TEST Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000).

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0141-LOST COMMUNICATION WITH IPM (FCM/TIPM)»(ref-485529-S32074441492012071300000) and perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0151-LOST COMMUNICATION WITH OCCUPANT RESTRAINT CONTROLLER (ORC)»(ref-485529-S35550684532012071300000) and perform the U0151-Lost Communication with Occupant Restraint Controller (ORC) diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0155-LOST COMMUNICATION WITH CLUSTER/CCN»(ref-485529-S17191963192012071300000) and perform the U0155-Lost Communication with Cluster/CCN diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0156-LOST COMMUNICATION WITH EOM»(ref-485535-S41033677252012071300000) and perform the U0156-Lost Communication with EOM diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0164-LOST COMMUNICATION WITH HVAC CONTROL MODULE»(ref-485529-S33046253092012071300000) and perform the U0164-Lost Communication with HVAC Control Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0167-LOST COMMUNICATION WITH INTRUSION TRANSCEIVER CONTROL MODULE»(ref-485535-S25831153782012071300000) and perform the U0167-Lost Communication with Intrusion Transceiver Control Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0168-LOST COMMUNICATION WITH VEHICLE SECURITY CONTROL MODULE (WCM)»(ref-485529-S24301198802012071300000) and perform the U0168-Lost Communication with Vehicle Security Control Module (WIN) diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0169-LOST COMMUNICATION WITH SUNROOF CONTROL MODULE»(ref-485535-S25923771322012071300000) and perform the U0169-Lost Communication with Sunroof Control Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0184-LOST COMMUNICATION WITH RADIO»(ref-485529-S40159287352012071300000) and perform the U0184-Lost Communication with Radio diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0186-LOST COMMUNICATION WITH AUDIO AMPLIFIER (AMP)»(ref-485529-S31443719702012071300000) and perform the U0186-Lost Communication with Audio Amplifier diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0196-LOST COMMUNICATION WITH VEHICLE ENTERTAINMENT CONTROL MODULE»(ref-485535-S01302017352012071300000) and perform the U0196-Lost Communication with Vehicle Entertainment Control Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0197-LOST COMMUNICATION WITH HANDS FREE PHONE MODULE (HFM)»(ref-485529-S41525900412012071300000) and perform the U0197-Lost Communication with Hands Free Phone Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0200-LOST COMMUNICATION WITH PASSENGER DOOR MODULE»(ref-485529-S19544055862012071300000) and perform the U0200-Lost Communication with Passenger Door Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0206-LOST COMMUNICATION WITH FOLDING TOP CONTROL MODULE (PTCM)»(ref-485529-S39377164052012071300000) and perform the U0206-Lost Communication with Folding Top Control Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0208-LOST COMMUNICATION WITH HEATED SEAT CONTROL MODULE»(ref-485535-S24218532892012071300000) and perform the U0208-Lost Communication with Heated Seat Control Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

Scheme 293

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
