Communication - Non-Dtc Based Diagnostics: Other Dodge Avenger II facelift

WHEN MONITORED

When the scan tool queries the Totally Integrated Power Module (TIPM).

SET CONDITION

The scan tool has detected an open condition on both Diagnostic CAN C circuits.

POSSIBLE CAUSES

Scheme 20

Scheme 21

1. CHECK THE STATUS OF THE ERROR MESSAGE NOTE: Ensure the vehicle being tested is a CAN BUS VEHICLE. If not, false error messages may be displayed. NOTE: Ensure the scan tool is updated to the latest software. NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. With the scan tool, record the error message. Disconnect the scan tool from the DLC. Cycle the ignition from on to off 3 times. Turn the ignition on. Does the scan tool display this same error message? Yes Go To 2 . No The conditions that caused this error message to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. (D72) CAN C DIAGNOSTIC (+) CIRCUIT OPEN Turn the ignition off. Disconnect the TIPM C3 harness connector. Disconnect the scan tool from the DLC. NOTE: Check the connectors at both the DLC and the TIPM. Measure the resistance of the (D72) Diagnostic CAN C (+) circuit between the TIPM connector and the DLC. Is the resistance below 5.0 ohms? Yes Go To 3 . No Repair the (D72) Diagnostic CAN C (+) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. (D71) DIAGNOSTIC CAN C (-) CIRCUIT OPEN Measure the resistance of the (D71) Diagnostic CAN C (-) circuit between the TIPM C3 harness connector and the DLC. Is the resistance below 5.0 ohms? Yes Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Repair the (D71) Diagnostic CAN C (-) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

When the scan tool queries the Totally Integrated Power Module (TIPM).

The scan tool has detected a shorted high condition on either or both Diagnostic CAN C circuits.

Scheme 22

1. CHECK THE STATUS OF THE ERROR MESSAGE NOTE: Ensure the vehicle being tested is a CAN BUS VEHICLE. If not, false error messages may be displayed. NOTE: Ensure the scan tool is updated to the latest software. NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. With the scan tool, record the error message. Disconnect the scan tool from the Data Link Connector (DLC). Cycle the ignition from on to off 3 times. Turn the ignition on. Does the scan tool display this same error message? Yes Go To 2 . No The conditions that caused this error message to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. DIAGNOSTIC CAN C CIRCUITS SHORTED TO VOLTAGE Turn the ignition off. Disconnect the Totally Integrated Power Module (TIPM) C3 harness connector. Disconnect the scan tool from the DLC. Turn the ignition on. Measure the voltage of the Diagnostic CAN C circuits at the TIPM C3 harness connector. Is the voltage above 6.0 volts on either circuit? Yes Repair the Diagnostic CAN C circuits for a short to voltage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

When the scan tool queries the Totally Integrated Power Module (TIPM).

The scan tool has detected a shorted together condition on the Diagnostic CAN C circuits.

Scheme 23

1. CHECK THE STATUS OF THE ERROR MESSAGE NOTE: Ensure the vehicle being tested is a CAN BUS VEHICLE. If not, false error messages may be displayed. NOTE: Ensure the scan tool is updated to the latest software. NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. With the scan tool, record the error message. Disconnect the scan tool from the DLC. Cycle the ignition from on to off 3 times. Turn the ignition on. Does the scan tool display this same error message? Yes Go To 2 . No The conditions that caused this error message to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. (D72) DIAGNOSTIC CAN C (+) CIRCUIT SHORTED TO (D71) DIAGNOSTIC CAN C (-) CIRCUIT Turn the ignition off. Disconnect the Totally Integrated Power Module (TIPM) C3 harness connector. Disconnect the scan tool from the DLC. Measure the resistance between the (D72) Diagnostic CAN C (+) circuit and the (D71) Diagnostic CAN C (-) circuit at the TIPM C3 harness connector. Is the resistance below 100.0 ohms? Yes Repair the (D72) Diagnostic CAN C (+) circuit for a short to the (D71) Diagnostic CAN C (-) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

When the scan tool queries the Totally Integrated Power Module (TIPM).

The scan tool has detected a shorted low condition on the (D72) Diagnostic CAN C (+) circuit.

Scheme 24

1. CHECK THE STATUS OF THE ERROR MESSAGE NOTE: Ensure the vehicle being tested is a CAN BUS VEHICLE. If not, false error messages may be displayed. NOTE: Ensure the scan tool is updated to the latest software. NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. With the scan tool, record the error message. Disconnect the scan tool from the DLC. Cycle the ignition from on to off 3 times. Turn the ignition on. Does the scan tool display this same error message? Yes Go To 2 . No The conditions that caused this error message to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. (D72) DIAGNOSTIC CAN C (+) CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Totally Integrated Power Module (TIPM) C3 harness connector. Disconnect the scan tool from the DLC. Measure the resistance between ground and the (D72) Diagnostic CAN C (+) circuit at the TIPM C3 harness connector. Is the resistance below 100.0 ohms? Yes Repair the (D72) Diagnostic CAN C (+) circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

When the scan tool queries the Totally Integrated Power Module (TIPM).

The scan tool has detected a shorted low condition on the (D71) Diagnostic CAN C (-) circuit.

Scheme 25

1. CHECK THE STATUS OF THE ERROR MESSAGE NOTE: Ensure the vehicle being tested is a CAN BUS VEHICLE. If not, false error messages may be displayed. NOTE: Ensure the scan tool is updated to the latest software. NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. With the scan tool, record the error message. Disconnect the scan tool from the DLC. Cycle the ignition from on to off 3 times. Turn the ignition on. Does the scan tool display this same error message? Yes Go To 2 . No The conditions that caused this error message to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. (D71) DIAGNOSTIC CAN C (-) CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Totally Integrated Power Module (TIPM) C3 harness connector. Disconnect the scan tool from the DLC. Measure the resistance between ground and the (D71) Diagnostic CAN C (-) circuit at the TIPM C3 harness connector. Is the resistance below 100.0 ohms? Yes Repair the (D71) Diagnostic CAN C (-) circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

When the scan tool queries the Totally Integrated Power Module (TIPM).

The scan tool has detected an open condition on the (D72) Diagnostic CAN C (+) circuit.

When the scan tool queries the Totally Integrated Power Module (TIPM).

The scan tool has detected an open condition on the (D71) Diagnostic CAN C (-) circuit.

Scheme 26

Scheme 27

Scheme 28

Scheme 29

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. NOTE: Check the TIPM for any active CAN C hardware DTCs, perform DTC before proceeding. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. (Z905) GROUND CIRCUITS OPEN Turn the ignition off. Disconnect the ABS harness connector. Using a 12-volt test light connected to 12-volts, check both (Z905) ground circuits. Does the test light illuminate brightly for each circuit? Yes Go To 3 . No Repair the (Z905) ground circuits for an open. Perform the ABS VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485487-S19412834172012071300000) .
3. (F202) IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT OPEN OR SHORTED Turn the ignition on. Using a 12-volt test light connected to ground, check the (F202) Ignition Switch Output (Run-Start) circuit. Does the test light illuminate brightly? Yes Go To 4 . No Repair the (F202) Ignition Switch Output (Run-Start) circuit for an open or short. Perform the ABS VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485487-S19412834172012071300000) .
4. (D65) CAN C BUS (+) CIRCUIT OPEN Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance of the (D65) CAN C Bus (+) circuit between the TIPM connector and the Antilock Brake Module connector. Is resistance below 5.0 ohms? Yes Go To 5 . No Repair the (D65) CAN C Bus (+) circuit for an open. Perform the ABS VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485487-S19412834172012071300000) .
5. (D64) CAN C BUS (-) CIRCUIT OPEN Measure the resistance of the (D64) CAN C Bus (-) circuit between the TIPM connector and the Antilock Brake Module connector. Is resistance below 5.0 ohms? Yes Replace the Antilock Brake Module in accordance with the Service Information. Perform the ABS VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485487-S19412834172012071300000) . No Repair the (D64) CAN C Bus (-) circuit for an open. Perform the ABS VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485487-S19412834172012071300000) .

Scheme 30

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 31

Scheme 32

Scheme 33

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. (A419) (A420) FUSED B(+) CIRCUIT OPEN OR SHORTED Turn the ignition off. Disconnect the Radio Amplifier C1 harness connector. Using a 12-volt test light connected to ground, check each (A419) and (A420) Fused B(+) circuit. Does the test light illuminate brightly for each circuit? Yes Go To 3 . No Repair the (A419) or (A420) Fused B(+) circuit for an open or short. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. (Z912) GROUND CIRCUIT OPEN Using a 12-volt test light connected to 12-volts, check each (Z912) ground circuit. Does the test light illuminate brightly for each circuit? Yes Go To 4 . No Repair the (Z912) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. (D55) AND (D54) CAN B BUS CIRCUITS OPEN Turn the ignition on. NOTE: One open circuit will not cause this condition. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Radio Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 34

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 35

Scheme 36

Scheme 37

Scheme 38

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. (A412) FUSED B(+) CIRCUIT OPEN OR SHORTED Turn the ignition off. Disconnect all Cluster harness connectors. Using a 12-volt test light connected to ground, check the (A412) Fused B(+) circuit. Does the test light illuminate brightly? Yes Go To 3 . No Repair the (A412) Fused B(+) circuit for an open or short. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. (Z910) GROUND CIRCUIT OPEN Using a 12-volt test light connected to 12-volts, check each (Z910) ground circuit. Does the test light illuminate brightly for each circuit? Yes Go To 4 . No Repair the (Z910) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. (F202) IGNITION SWITCH OUTPUT CIRCUIT OPEN OR SHORTED Turn the ignition on. Using a 12-volt test light connected to ground, check the (F202) Ignition Switch Output circuit. Does the test light illuminate brightly? Yes Go To 5 . No Repair the (F202) Ignition Switch Output circuit for an open or short. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
5. (D55) AND (D54) CAN B BUS CIRCUITS OPEN NOTE: One open circuit will not cause this condition. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 39

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 40

Scheme 41

Scheme 42

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Ensure fuse 36 is installed and not open and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. REMOVE AND REINSTALL FUSE 36 Remove Fuse 36, wait 20 seconds and reinstall fuse. Does the scan tool display a red "X" next to the module? Yes Go To 3 . No Test complete. NOTE: Anytime the DDM C1 and C2 harness connectors are disconnected from the module the C2 harness connector MUST be connected before the C1 connector or a No Response condition may result. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. (A937) FUSED B(+) CIRCUIT OPEN OR SHORTED Turn the ignition off. Disconnect the Driver Door Module C1 harness connector. Using a 12-volt test light connected to ground, check each (A937) Fused B(+) circuit. Does the test light illuminate brightly for each circuit? Yes Go To 4 . No Repair the (A937) Fused B(+) circuit for an open or short. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. (Z908) GROUND CIRCUIT OPEN Disconnect the Driver Door Module C2 harness connector. Using a 12-volt test light connected to 12-volts, check each (Z908) ground circuit. Does the test light illuminate brightly for each circuit? Yes Go To 5 . No Repair the (Z908) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
5. (D55) AND (D54) CAN B BUS CIRCUITS OPEN Turn the ignition on. NOTE: One open circuit will not cause this condition. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Driver Door Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 43

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 44

Scheme 45

Scheme 46

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. (A417) FUSED B(+) CIRCUIT OPEN OR SHORTED Turn the ignition off. Disconnect the Hands Free Module harness connector. Using a 12-volt test light connected to ground, check the (A417) Fused B(+) circuit. Does the test light illuminate brightly? Yes Go To 3 . No Repair the (A417) Fused B(+) circuit for an open or short. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. (Z912) GROUND CIRCUIT OPEN Using a 12-volt test light connected to 12-volts, check the (Z912) ground circuit. Does the test light illuminate brightly? Yes Go To 4 . No Repair the (Z912) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. (D55) AND (D54) CAN B BUS CIRCUITS OPEN NOTE: One open circuit will not cause this condition. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Hands Free Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 47

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 48

Scheme 49

Scheme 50

Scheme 51

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. (Z912) GROUND CIRCUIT OPEN Turn the ignition off. Disconnect the A/C Heater Control harness connector. Using a 12 volt test light connected to 12 volts check the (Z912) ground circuit. Does the test light illuminate brightly? Yes Go To 3 . No Repair the (Z912) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. (A417) FUSED B+ (I.O.D.) CIRCUIT OPEN OR SHORTED Using a 12-volt test light connected to ground, check the (A417) Fused B+ (I.O.D.) circuit. Does the test light illuminate brightly? Yes Go To 4 . No Repair the (A417) Fused B+ (I.O.D.) circuit for an open or short. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. (F929) FUSED IGNITION SWITCH OUTPUT (RUN) CIRCUIT OPEN OR SHORTED Turn the ignition on. Using a 12-volt test light connected to ground, check the (F929) Fused Ignition Switch Output (RUN) circuit. Does the test light illuminate brightly? Yes Go To 5 . No Repair the (F929) Fused Ignition Switch Output (RUN) circuit for an open or short. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
5. (D55) AND (D54) CAN B BUS CIRCUITS OPEN NOTE: One open circuit will not cause this condition. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Heating, Ventilation and Air Conditioning Control Head in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 52

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 53

Scheme 54

Scheme 55

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. (Z912) GROUND CIRCUIT OPEN Turn the ignition off. Disconnect the A/C Heater Control C1 harness connector. Using a 12 volt test light connected to 12 volts check the (Z912) ground circuit. Does the test light illuminate brightly? Yes Go To 3 . No Repair the (Z912) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. (F929) FUSED IGNITION SWITCH OUTPUT (RUN) CIRCUIT OPEN OR SHORTED Turn the ignition on. Using a 12-volt test light connected to ground, check the (F929) Fused Ignition Switch Output (RUN) circuit. Does the test light illuminate brightly? Yes Go To 4 . No Repair the (F929) Fused Ignition Switch Output (RUN) circuit for an open or short. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. (D55) AND (D54) CAN B BUS CIRCUITS OPEN NOTE: One open circuit will not cause this condition. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Heating, Ventilation and Air Conditioning Control Head in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 56

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. (Z945) GROUND CIRCUIT OPEN WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the Occupant Restraint Controller Module C1 and C2 harness connectors. Connect the appropriate Load Tool ACM Adaptor to the ORC connectors. Measure the resistance between ground and the (Z945) ground circuit. Is the resistance below 10k ohms? Yes Go To 3 . No Repair the (Z945) ground circuit for an open. Perform the AIRBAG SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485515-S14989137882012071300000) .
3. (F100) FUSED IGNITION SWITCH OUTPUT (RUN) CIRCUIT OPEN OR SHORTED NOTE: Check the TIPM for and diagnose any ignition related DTCs before proceeding. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Using a 12-volt test light connected to ground, check the (F100) Fused Ignition Switch Output (RUN) circuit. Does the test light illuminate brightly? Yes Go To 4 . No Repair the (F100) Fused Ignition Switch Output (RUN) circuit for an open or short. Perform the AIRBAG SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485515-S14989137882012071300000) .
4. (F200) FUSED IGNITION SWITCH OUTPUT (RUN/START) CIRCUIT OPEN OR SHORTED Using a 12-volt test light connected to ground, check the (F200) Fused Ignition Switch Output (RUN/START) circuit. Does the test light illuminate brightly? Yes Go To 5 . No Repair the (F200) Fused Ignition Switch Output (RUN/START) circuit for an open or short. Perform the AIRBAG SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485515-S14989137882012071300000) .
5. (D55) AND (D54) CAN B BUS CIRCUITS OPEN WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental airbag deployment. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: One open circuit will not cause this condition. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Occupant Restraint Controller Module in accordance with the Service Information. Perform the AIRBAG SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485515-S14989137882012071300000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform the AIRBAG SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485515-S14989137882012071300000) .

Scheme 61

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Make sure the Ignition Off Draw (IOD) fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, read the module status. NOTE: Check the TIPM for any active CAN hardware DTCs, perform DTC before proceeding. Does the scan tool indicate that the module is active on the bus? Yes The no response condition is not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. No Go To 2 .
2. CHECK THE (A209) FUSED B(+) CIRCUIT FOR AN OPEN OR SHORT Turn the ignition off. Disconnect the PCM C1 harness connector. Using a 12-volt test light connected to ground, check the (A209) Fused B(+) circuit. Does the test light illuminate brightly? Yes Go To 3 . No Repair the open or short in the (A209) Fused B(+) circuit. Perform the POWERTRAIN VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) or «62TE TRANSMISSION VERIFICATION TEST»(ref-485571-S26684901912012071300000) .
3. CHECK THE (Z902) GROUND CIRCUIT FOR AN OPEN Using a 12-volt test light connected to 12-volts, check the (Z902) Ground circuit. Does the test light illuminate brightly? Yes Go To 4 . No Repair the open in the (Z902) Ground circuit. Perform the POWERTRAIN VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) or «62TE TRANSMISSION VERIFICATION TEST»(ref-485571-S26684901912012071300000) .
4. CHECK THE (F202) IGNITION SWITCH OUTPUT CIRCUIT FOR AN OPEN OR SHORT Turn the ignition on. Using a 12-volt test light connected to ground, check the (F202) Ignition Switch Output circuit. Does the test light illuminate brightly? Yes Go To 5 . No Repair the open or short in the (F202) Ignition Switch Output circuit. Perform the POWERTRAIN VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) or «62TE TRANSMISSION VERIFICATION TEST»(ref-485571-S26684901912012071300000) .
5. CHECK THE (F342) FUSED ASD RELAY OUTPUT CIRCUIT FOR AN OPEN OR SHORT Remove the ASD/Main Relay. Connect a fused jumper wire between terminals 30 and 87. Using a 12-volt test light connected to ground, check the (F342) Fused ASD Relay Output circuit. Does the test light illuminate brightly? Yes Go To 6 . No Repair the open or short in the (F342) Fused ASD Relay Output circuit. Perform the POWERTRAIN VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) or «62TE TRANSMISSION VERIFICATION TEST»(ref-485571-S26684901912012071300000) .
6. CHECK THE (D65) CAN C BUS (+) CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the TIPM C2 harness connector. Measure the resistance of the (D65) CAN C Bus (+) circuit between the TIPM C2 harness connector and the PCM C1 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 7 . No Repair the open in the (D65) CAN C Bus (+) circuit. Perform the POWERTRAIN VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) or «62TE TRANSMISSION VERIFICATION TEST»(ref-485571-S26684901912012071300000) .
7. CHECK THE (D64) CAN C BUS (-) CIRCUIT FOR AN OPEN Measure the resistance of the (D64) CAN C Bus (-) circuit between the TIPM C2 harness connector and the PCM C1 harness connector. Is the resistance below 5.0 Ohms? Yes Replace and program the Powertrain Control Module in accordance with the Service Information. Perform the POWERTRAIN VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) or «62TE TRANSMISSION VERIFICATION TEST»(ref-485571-S26684901912012071300000) . No Repair the open in the (D64) CAN C Bus (-) circuit. Perform the POWERTRAIN VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) or «62TE TRANSMISSION VERIFICATION TEST»(ref-485571-S26684901912012071300000) .

Scheme 68

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 69

Scheme 70

Scheme 71

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. (A937) FUSED B(+) CIRCUIT OPEN OR SHORTED Turn the ignition off. Disconnect the Passenger Door Module C1 harness connector. Using a 12-volt test light connected to ground, check each (A937) Fused B(+) circuit. Does the test light illuminate brightly for each circuit? Yes Go To 3 . No Repair the (A937) Fused B(+) circuit for an open or short. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. (Z907) GROUND CIRCUIT OPEN Using a 12-volt test light connected to 12-volts, check each (Z907) ground circuit. Does the test light illuminate brightly for each circuit? Yes Go To 4 . No Repair the (Z907) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. (D55) AND (D54) CAN B BUS CIRCUITS OPEN Disconnect the Passenger Door Module C2 harness connector. Turn the ignition on. NOTE: One open circuit will not cause this condition. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Passenger Door Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 72

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 73

Scheme 74

Scheme 75

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. (A925) (A926) (A927) FUSED B(+) CIRCUITS OPEN OR SHORTED Turn the ignition off. Disconnect the Power Top Control Module C2 and C3 harness connectors. Using a 12-volt test light connected to ground, check each (A925), (A926) and (A927) Fused B(+) circuit. Does the test light illuminate brightly for each circuit? Yes Go To 3 . No Repair the (A925), (A926) or (A927) Fused B(+) circuit for an open or short. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. (Z916) GROUND CIRCUIT OPEN Disconnect the Power Top Control Module C1 harness connector. Using a 12-volt test light connected to 12-volts, check each (Z916) ground circuit. Does the test light illuminate brightly for each circuit? Yes Go To 4 . No Repair the (Z916) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. (D55) AND (D54) CAN B BUS CIRCUITS OPEN Turn the ignition on. NOTE: One open circuit will not cause this condition. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Power Top Control Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 76

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 77

Scheme 78

Scheme 79

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. (A413) FUSED B(+) CIRCUIT OPEN OR SHORTED Turn the ignition off. Disconnect the Radio C1 harness connector. Using a 12-volt test light connected to ground, check each (A413) Fused B(+) circuit. Does the test light illuminate brightly for each circuit? Yes Go To 3 . No Repair the (A413) Fused B(+) circuit for an open or short. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. (Z912) GROUND CIRCUIT OPEN Using a 12-volt test light connected to 12-volts, check each (Z912) ground circuit. Does the test light illuminate brightly for each circuit? Yes Go To 4 . No Repair the (Z912) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. (D55) AND (D54) CAN B BUS CIRCUITS OPEN Turn the ignition on. NOTE: One open circuit will not cause this condition. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Radio in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 80

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 81

Scheme 82

Scheme 83

Scheme 84

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Make sure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, read the module status. NOTE: Check the TIPM for any active CAN hardware DTCs, perform DTC before proceeding. Does the scan tool indicate that the module is active on the bus? Yes The no response condition is not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. No Go To 2 .
2. CHECK THE (F202) IGNITION SWITCH OUTPUT CIRCUIT FOR AN OPEN OR SHORT Turn the ignition off. Disconnect the Clockspring C3 (SAS) harness connector. Turn the ignition on. Using a 12-volt test light connected to ground, check the (F202) Ignition Switch Output circuit. Does the test light illuminate brightly? Yes Go To 3 . No Repair the open or short in the (F202) Ignition Switch Output circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. CHECK THE (Z910) GROUND CIRCUIT FOR AN OPEN Turn the ignition off. Using a 12-volt test light connected to 12-volts, check the (Z910) Ground circuit. Does the test light illuminate brightly? Yes Go To 4 . No Repair the open in the (Z910) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. CHECK THE (D65) CAN C BUS (+) CIRCUIT FOR AN OPEN Disconnect the TIPM C2 harness connector. Measure the resistance of the (D65) CAN C Bus (+) circuit between the TIPM C2 harness connector and the Clockspring C3 (SAS) harness connector. Is resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (D65) CAN C Bus (+) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
5. CHECK THE (D64) CAN C BUS (-) CIRCUIT FOR AN OPEN Measure the resistance of the (D64) CAN C Bus (-) circuit between the TIPM C2 harness connector and the Clockspring C3 (SAS) harness connector. Is resistance below 5.0 Ohms? Yes Replace the Clockspring in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Repair the open in the (D64) CAN C Bus (-) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 85

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 86

Scheme 87

Scheme 88

Scheme 89

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any TSB(s) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. NOTE: Make sure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. NOTE: Make sure the scan tool is updated to the latest software. NOTE: If the scan tool displays any error messages involving the Diagnostic CAN C circuits, diagnose and repair the errors before proceeding. Refer to the «DTC INDEX»(ref-485605) article. NOTE: A loss of communication with the TIPM can cause the ECU View button on the scan tool to be inoperative (not highlighted). Turn the ignition on. With the scan tool, attempt to select ECU View. Can the scan tool communicate with the TIPM? Yes The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals. No Go To 2 .
2. DIRECT BATTERY FEED CIRCUIT OPEN AT TIPM Disconnect the scan tool from the DLC. Using a 12-volt test light connected to ground, check the (A0) B(+) circuit at the TIPM C9 connector. Does the test light illuminate brightly? Yes Go To 3 . No Repair the open in the (A0) B(+) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
3. GROUND CIRCUITS OPEN AT TIPM Turn the ignition off. Disconnect the TIPM C1, C2, C6, and C11 harness connectors. Using a 12-volt test light connected to 12-volts, check the (Z901) Ground circuits in the TIPM harness connectors. Does the test light illuminate brightly on each circuit? Yes Go To 4 . No Repair the open in the (Z901) Ground circuit that did not illuminate the test light. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
4. CHECK FOR (D72) DIAGNOSTIC CAN C (+) CIRCUIT OPEN AT DLC Disconnect the TIPM C3 harness connector. Measure the resistance on the (D72) Diagnostic CAN C (+) circuit between the TIPM C3 harness connector and the DLC. Is the resistance above 10.0 Ohms? Yes Repair the (D72) Diagnostic CAN C (+) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Go To 5 .
5. CHECK FOR (D71) DIAGNOSTIC CAN C (-) CIRCUIT OPEN AT DLC Measure the resistance on the (D71) Diagnostic CAN C (-) circuit between the TIPM C3 harness connector and the DLC. Is the resistance above 10.0 Ohms? Yes Repair the (D71) Diagnostic CAN C (-) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Go To 6 .
6. CHECK FOR (D72) DIAGNOSTIC CAN C (+) CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (D72) Diagnostic CAN C (+) circuit at the TIPM C3 harness connector. Is the resistance below 100.0 Ohms? Yes Repair the (D72) Diagnostic CAN C (+) circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Go To 7 .
7. CHECK FOR (D71) DIAGNOSTIC CAN C (-) CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (D71) Diagnostic CAN C (-) circuit at the TIPM C3 harness connector. Is the resistance below 100.0 Ohms? Yes Repair the (D71) Diagnostic CAN C (-) circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Go To 8 .
8. CHECK FOR DIAGNOSTIC CAN C CIRCUITS SHORTED TOGETHER Measure the resistance between the (D72) Diagnostic CAN C (+) circuit and the (D71) Diagnostic CAN C (-) circuit at the TIPM C3 harness connector. Is the resistance below 100.0 Ohms? Yes Repair the (D72) Diagnostic CAN C (+) circuit for a short to the (D71) Diagnostic CAN C (-) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No Replace the Totally Integrated Power Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 90

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 91

Scheme 92

Scheme 93

Scheme 94

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for any Technical Service Bulletins (TSBs) related to the condition. If a TSB applies, perform the procedure outlined in the TSB before continuing. Turn the ignition on. NOTE: Make sure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. Using the scan tool, select ECU View. NOTE: A red "X" will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red "X" next to the module? Yes Go To 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched and partially broken wires and the wiring harness connectors for broken, bent, pushed out and corroded terminals.
2. (A411) FUSED B(+) CIRCUIT OPEN OR SHORTED Turn the ignition off. Disconnect the WCM harness connector. Using a 12-volt test light connected to ground, check the (A411) Fused B(+) circuit. Does the test light illuminate brightly? Yes Go To 3 . No Repair the (A411) Fused B(+) circuit for an open or short. Perform the WCM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) .
3. (Z910) GROUND CIRCUIT OPEN Using a 12-volt test light connected to 12-volts, check the (Z910) ground circuit. Does the test light illuminate brightly? Yes Go To 4 . No Repair the (Z910) ground circuit for an open. Perform the WCM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) .
4. (F20) IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT OPEN OR SHORTED Turn the ignition on. Using a 12-volt test light connected to ground, check the (F20) Ignition Switch Output (Run-Start) circuit. Does the test light illuminate brightly? Yes Go To 5 . No Repair the (F20) Ignition Switch Output (Run-Start) circuit for an open or short. Perform the WCM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) .
5. (D55) AND (D54) CAN B BUS CIRCUITS OPEN NOTE: One open circuit will not cause this condition. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Wireless Control Module in accordance with the Service Information. Perform the WCM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform the WCM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) .

STORED LOST COMMUNICATION DTCS

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received for approximately one second.
