Wiring Systems and Power Management - Splice Pack Connector End Views Cadillac SRX II

Body Electrical 1 illustration

Scheme 440

Scheme 440: Splice Pack Connector End Views

Scheme 440: Splice Pack Connector End Views

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12176461 Service Connector: 15305914 Description: 12-Way F GT 150 Series (BK)
Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Pin	Wire	Circuit	Function
A	0.35 D-GN	5060	Low Speed GMLAN Serial Data
B	0.35 D-GN	5060	Low Speed GMLAN Serial Data (ULS)
C			Not Used
D	0.35 D-GN	5060	Low Speed GMLAN Serial Data
E			Not Used
F	0.35 D-GN	5060	Low Speed GMLAN Serial Data (ULD)
G	0.35 D-GN	5060	Low Speed GMLAN Serial Data (UTE or UYK or UYI)
H	0.35 D-GN	5060	Low Speed GMLAN Serial Data (UE1)
J	0.35 D-GN	5060	Low Speed GMLAN Serial Data
K	0.35 D-GN	5060	Low Speed GMLAN Serial Data
L	0.35 D-GN	5060	Low Speed GMLAN Serial Data
M	0.35 D-GN	5060	Low Speed GMLAN Serial Data

JX200

Connector Part Information Harness Type: Body OEM Connector: 12176461 Service Connector: 15305914 Description: 12-Way F GT 150 Series (BK)
Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Pin	Wire	Circuit	Function
A	0.35 D-GN	5060	Low Speed GMLAN Serial Data
B-C			Not Used
D	0.35 D-GN	5060	Low Speed GMLAN Serial Data (UD5)
E	0.35 D-GN	5060	Low Speed GMLAN Serial Data
F	0.35 D-GN	5060	Low Speed GMLAN Serial Data (AL0 without ASP)
G	0.35 D-GN	5060	Low Speed GMLAN Serial Data (U4G)
H	0.35 D-GN	5060	Low Speed GMLAN Serial Data (KA1 without AAB)
J	0.35 D-GN	5060	Low Speed GMLAN Serial Data (KA6)
K	0.35 D-GN	5060	Low Speed GMLAN Serial Data (TB5)
L	0.35 D-GN	5060	Low Speed GMLAN Serial Data (AAB)
M			Not Used

JX300
