Wiring Systems and Power Management - Component Connector End Views - a3l Through b34 Cadillac SRX II

Body Electrical 26 illustrations ~547 words

Scheme 452

Scheme 452: A3L Sunshade - Left
Scheme 452: A3L Sunshade - Left
Connector Part Information Harness Type: Headliner OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.35 OG6815Inadvertent Power Supply Voltage
B0.35 BK1350Ground

A3L Sunshade - Left

A3R Sunshade - Right

Connector Part Information Harness Type: Headliner OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.35 OG6815Inadvertent Power Supply Voltage
B0.35 BK1350Ground

A3R Sunshade - Right

Scheme 453

Scheme 453: A9A Outside Rearview Mirror - Driver X1
Scheme 453: A9A Outside Rearview Mirror - Driver X1
Connector Part Information Harness Type: Driver Door OEM Connector: 13548147 Service Connector: 19149476 Description: 10-Way M AIT Series (BK)
Terminal Part Information Terminal/Tray: SAITW-A03T-064/20 Core/Insulation Crimp: J/J Release Tool/Test Probe: J-38125-215A/J-35616-65B (L-BU)
PinWireCircuitFunction
10.35 TN3391Driver Side Mirror Motor Common
20.35 D-BU/WH3390Driver Side Mirror Up/Down Motor Control
30.35 L-GN/WH3389Driver Side Mirror Right/Left Motor Control
40.35 GY1690Automatic Day/Night Mirror Signal
50.35 PK1691Automatic Day/Night Mirror Low Reference
60.5 BK750Ground
70.5 OG2267Mirror Heating Element Supply Voltage
8-10Not Used

A9A Outside Rearview Mirror - Driver X1

Scheme 454

Scheme 454: A9A Outside Rearview Mirror - Driver X2
Scheme 454: A9A Outside Rearview Mirror - Driver X2
Connector Part Information Harness Type: Driver Door OEM Connector: 13640058 Service Connector: See Catalog Description: 8-Way M Kaizen 64 Series (BK)
Terminal Part Information Terminal/Tray: 7114-4618-02/27 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-65B (L-BU)
PinWireCircuitFunction
10.35 D-BU3392Reference Voltage
20.35 GY3395Driver Side Mirror Horizontal Position Signal
30.35 BN3393Low Reference
40.35 D-GN3394Driver Side Mirror Vertical Position Signal
50.5 YE3411Driver Side Outside Rearview Mirror Extend Control
60.5 L-BU3412Driver Side Outside Rearview Mirror Retract Control
7-8Not Used

A9A Outside Rearview Mirror - Driver X2

A9B Outside Rearview Mirror - Passenger X1

Connector Part Information Harness Type: Passenger Door OEM Connector: 13548147 Service Connector: 19149476 Description: 10-Way M AIT Series (BK)
Terminal Part Information Terminal/Tray: SAITW-A03T-064/20 Core/Insulation Crimp: J/J Release Tool/Test Probe: J-38125-215A/J-35616-65B (L-BU)
PinWireCircuitFunction
10.35 WH3398Passenger Side Mirror Motor Common
20.35 OG/BK3397Passenger Side Mirror Up/Down Motor Control
30.35 GY/BK3396Passenger Side Mirror Right/Left Motor Control
4-5Not Used
60.5 BK650Ground
70.5 OG2267Mirror Heating Element Supply Voltage
8-10Not Used

A9B Outside Rearview Mirror - Passenger X1

A9B Outside Rearview Mirror - Passenger X2

Connector Part Information Harness Type: Passenger Door OEM Connector: 13640058 Service Connector: See Catalog Description: 8-Way M Kaizen 64 Series (BK)
Terminal Part Information Terminal/Tray: 7114-4618-02/27 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-65B (L-BU)
PinWireCircuitFunction
10.35 YE3399Reference Voltage
20.35 BN3403Passenger Side Mirror Horizontal Position Signal
30.35 L-GN3400Low Reference
40.35 L-BU/BK3401Passenger Side Mirror Vertical Position Signal
50.5 YE/BK3413Passenger Side Outside Rearview Mirror Extend Control
60.5 L-BU/BK3414Passenger Side Outside Rearview Mirror Retract Control
7-8Not Used

A9B Outside Rearview Mirror - Passenger X2

Scheme 455

Scheme 455: A10 Inside Rearview Mirror
Scheme 455: A10 Inside Rearview Mirror
Connector Part Information Harness Type: Headliner OEM Connector: 13641322 Service Connector: 19177676 Description: 10-Way F Kaizen 0.64 Series (BK)
Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 L-GN24Backup Lamp Supply Voltage
20.35 PK1039Ignition 1 Voltage
30.35 D-GN/WH2514Keypad Signal
40.35 L-GN/BK2515Keypad Supply Voltage
50.35 BK/WH1351Ground
60.35 YE/BK2516Keypad Green LED Signal
70.35 BN/WH2517Keypad Red LED Signal
80.35 PK1691Automatic Day/Night Mirror Low Reference
90.35 GY1690Automatic Day/Night Mirror Signal
10Not Used

A10 Inside Rearview Mirror

Scheme 456

Scheme 456: A11 Radio X1
Scheme 456: A11 Radio X1
Connector Part Information Harness Type: Instrument Panel OEM Connector: 13589609 Service Connector: 88988902 Description: 44-Way F GT 150/280 64 Series (BK)
Terminal Part Information Pins: 1-6, 9-13, 16-20, 22-28 Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) Pins: 29-37, 39-43 Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY) Pins: 38, 44 Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)
PinWireCircuitFunction
10.35 BARE1574Drain Wire
20.35 YE7459CGI (-)
30.35 BARE7460Drain Wire
40.35 OG6761Left Rear Low Level Audio Signal (-)
50.35 PK6762Subwoofer Speaker Low
60.35 L-BU/BK659Cellular Telephone Voice Signal
7-8Not Used
90.35 BARE5842Drain Wire (except EXP)
100.35 D-GN/WH5841Right Auxiliary Audio Signal (2) (without UYE or UYK or UYI)
0.35 TN/WH3378Auxiliary Audio Jack Right (+) (UYE or UYK or UYI)
110.35 PK2060Auxiliary Detection Signal (Except EXP)
120.35 TN3352RSA Audio Common Signal
130.35 L-GN3291Center Stack Wake - Up Signal
14-15Not Used
160.35 TN7458CGI (+)
170.35 BARE6759Drain Wire
180.35 D-BU6760Left Rear Low Level Audio Signal (+)
190.35 WH6763Subwoofer Speaker High
200.35 D-BU658Cellular Telephone Voice Signal
21-22Not Used
230.35 D-BU5843Auxiliary Audio Common Signal (without UYE or UYK or UYI)
0.35 D-GN/WH3376Auxiliary Audio Common Signal (UYE or UYK or UYI)
240.35 L-GN5839Left Auxiliary Audio Signal (2) (except EXP)
250.35 L-BU5312RSA Left Audio Signal
260.35 L-GN5313RSA Right Audio Signal
270.35 PK3290Center Stack Reset Signal
280.35 D-GN5060Low Speed GMLAN Serial Data
290.35 BARE2011Drain Wire
300.35 BARE2099Drain Wire
310.35 OG/BK1546Front Low Level Audio Signal (-)
320.35 D-GN1947Left Front Low Level Audio Signal (-)
330.35 TN1946Right Rear Low Level Audio Signal (-)
340.35 BN1999Left Rear Low Level Audio Signal (-)
350.35 BN/WH5169Mid Speed GMLAN Serial Data Bus+ (UPH or UPJ or UYG or UYI or UYK)
360.35 BN5170Mid Speed GMLAN Serial Data Bus - (UPH or UPJ or UYG or UYI or UYK)
370.35 OG6978Amplifier Control
380.5 BK/WH1551Ground
390.35 L-GN/WH512Right Front Low Level Audio Signal (+)
400.35 TN511Left Front Low Level Audio Signal (+)
410.35 D-BU546Right Rear Low Level Audio Signal (+)
420.35 BN/WH599Left Rear Low Level Audio Signal (+)
430.35 WH7066Remote Enable
440.5 RD/WH340Battery Positive Voltage

A11 Radio X1

Scheme 457

Scheme 457: A11 Radio X3 (Except UYZ)
Scheme 457: A11 Radio X3 (Except UYZ)
Connector Part Information Harness Type: Infotainment OEM Connector: 15489824 Service Connector: 15126711 Description: 20-Way F 64 Series (BK)
Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 L-BU5826Left DVD Audio Signal (+)
20.35 PU6979DVD Audio Common
30.35 YE2059Auxiliary Audio Left Signal
40.35 PK/BK5844Video Bright Signal
50.35 L-GN/BK5845Video Module Signal
60.35 OG/BK5831Remote Infrared Signal (+)
70.35 PU2056Auxiliary Video High Signal
80.35 L-GN7396DVD Video Signal 2 (+) (DNU)
90.35 BARE6976DVD Video Drain Wire
100.35 D-GN6975DVD Video Signal (+)
110.35 WH5828Right DVD Audio Signal (+)
120.35 BARE6980DVD Drain Wire
130.35 WH2058Auxiliary Audio Right Signal
140.35 BARE5345Drain Wire
150.35 D-GN/WH7395Video Mode 2 Signal
160.35 TN/WH5830Right Infrared Audio Signal
170.35 BARE5346Video Drain Wire
180.35 WH7394DVD Video Signal 2 (-)
190.35 BARE5818Drain Wire
200.35 WH/BK5335DVD Video Signal (-)

A11 Radio X3 (Except UYZ)

A11 Radio X3 (UYZ)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 15489824 Service Connector: 15126711 Description: 20-Way F 64 Series (BK)
Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 L-BU5826Left DVD Audio Signal (+)
20.35 PU6979DVD Audio Common
30.35 YE2059Auxiliary Audio Left Signal
40.35 PK/BK5844Video Bright Signal
50.35 L-GN/BK5845Video Module Signal
60.35 OG/BK5831Remote Infrared Signal (+)
70.35 PU2056Auxiliary Video High Signal
80.35 L-GN7396DVD Video Signal 2 (+) (DNU)
90.35 NONE6976DVD Video Drain Wire
100.35 D-GN6975DVD Video Signal (+)
110.35 WH5828Right DVD Audio Signal (+)
120.35 NONE6980DVD Drain Wire
130.35 WH2058Auxiliary Audio Right Signal
140.35 NONE5345Drain Wire
150.35 D-GN/WH7395Video Mode 2 Signal
160.35 TN/WH5830Right Infrared Audio Signal
170.35 NONE5346Video Drain Wire
180.35 WH7394DVD Video Signal 2 (-)
190.35 NONE5818Drain Wire
200.35 WH/BK5335DVD Video Signal (-)

A11 Radio X3 (UYZ)

Scheme 458

Scheme 458: A11 Radio X4
Scheme 458: A11 Radio X4
Connector Part Information Harness Type: Infotainment OEM Connector: 15491304 Service Connector: 15126710 Description: 20-Way F USCAR 64 Series (GY)
Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 BN5384Traffic Information Signal (-) (without UYS)
20.35 GY5383Traffic Information Signal (+) (without UYS)
30.35 YE5385Traffic Information Request Signal (without UYS)
40.35 PU/WH3361Display Pop-Up Control Signal
50.35 PK6972Camera Signal +
60.35 PK5149Microphone Signal (+)
7Not Used
80.35 BARE3368Drain Wire
90.35 PK3369Navigation Display Touch +
100.35 L-GN3364Reset
110.35 BARE1782Drain Wire (without UYS)
12Not Used
130.35 WH3362Display Position Signal
14Not Used
150.35 L-BU6973Camera Signal #2
160.35 PK/BK5152Microphone Signal (-)
17-18Not Used
190.35 PU3370Navigation Display Touch
200.35 L-GN1903Left Front Wheel Speed Sensor Signal

A11 Radio X4

Scheme 459

Scheme 459: A20 Radio/HVAC Controls
Scheme 459: A20 Radio/HVAC Controls
Connector Part Information Harness Type: Instrument Panel OEM Connector: 13607274 Service Connector: 13576645 Description: 18-Way F Kaizen 64 Series (WH)
Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 TN7458CGI (+) (with Navigation)
20.35 YE7459CGI (-) (with Navigation)
30.35 BARE7460Drain Wire (with Navigation)
40.35 L-GN3291Center Stack Wake - Up Signal (with Navigation)
50.35 L-BU3265Child Security Lock Switch Signal
60.35 GY5697Child Security Indicator Control
70.35 L-BU7532Local Interconnect Network 10 (without Navigation)
80.35 YE7531Local Interconnect Network 9
9Not Used
100.35 RD/WH3240Battery Positive Voltage
11Not Used
120.35 PK/BK780Driver Door Lock Switch Lock Signal
130.35 OG/BK781Driver Door Lock Switch Unlock Signal
14Not Used
150.35 PK3290Center Stack Reset Signal (with Navigation)
160.35 WH111Hazard Switch Signal
170.35 BK/WH1751Ground
18Not Used

A20 Radio/HVAC Controls

Scheme 460

Scheme 460: A23C Liftgate Latch Assembly (TB5)
Scheme 460: A23C Liftgate Latch Assembly (TB5)
Connector Part Information Harness Type: Liftgate OEM Connector: 15476196 Service Connector: 88988498 Description: 6-Way F GT 280 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: Service by Connector Assembly - 15476196 Core/Insulation Crimp: Not Available Release Tool/Test Probe: Pending
PinWireCircuitFunction
12 BK5790Liftgate Latch Motor Open Control
22 BK5801Low Reference
32 BK5791Liftgate Latch Motor Close Control
42 BK5512Liftgate Latch Sector Switch Signal
52 BK7000Liftgate Latch Pawl Switch Signal
62 BK6000Liftgate Latch Ratchet Switch Signal

A23C Liftgate Latch Assembly (TB5)

Scheme 461

Scheme 461: A23C Liftgate Latch Assembly (without TB5)
Scheme 461: A23C Liftgate Latch Assembly (without TB5)
Connector Part Information Harness Type: Liftgate OEM Connector: 15476199 Service Connector: 88988358 Description: 6-Way F GT 280 Series, Sealed (GN)
Terminal Part Information Terminal/Tray: 15304719/19 Core/Insulation Crimp: 2/5 Release Tool/Test Probe: 15315247/J-35616-4A (PU)
PinWireCircuitFunction
11 L-BU6128Rear Closure Unlatch Motor Unlatch Control
21 BK1350Ground
31 OG6129Liftgate Lock Actuator Ground
41 BK1350Ground
51 BK1350Ground
61 PK/BK1303Liftgate Ajar Switch Signal

A23C Liftgate Latch Assembly (without TB5)

Scheme 462

Scheme 462: A23D Door Latch Assembly - Driver
Scheme 462: A23D Door Latch Assembly - Driver
Connector Part Information Harness Type: Driver Door OEM Connector: 10768367 Service Connector: 88952463 Description: 10-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: 964274-2/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-560/J-35616-14 (GN)
PinWireCircuitFunction
10.8 BN5910Global Door Lock
20.8 TN294Door Lock Actuator Unlock Control
30.8 GY5911Driver Door Lock Motor Lock Control
40.35 D-GN3270Driver Door Lock Status Signal
51 GY3578Driver Door Unlatch Signal
60.35 GY/BK745Left Front Door Ajar Switch Signal
70.35 TN/WH3574Driver Door Open Switch Signal
80.35 BK750Ground
90.35 PU1124Door Lock Key Switch Unlock Signal
101 L-BU/BK6666Driver Door Latch Signal

A23D Door Latch Assembly - Driver

A23LR Door Latch Assembly - Left Rear

Connector Part Information Harness Type: Left Rear Door OEM Connector: 10768367 Service Connector: 88952463 Description: 10-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: 964274-2/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-560/J-35616-14 (GN)
PinWireCircuitFunction
10.8 BN5910Global Door Lock
20.8 TN294Door Lock Actuator Unlock Control
30.8 GY295Door Lock Actuator Lock Control
40.8 TN294Door Lock Actuator Unlock Control
51 D-BU/WH3580Left Rear Door Unlatch Signal
60.35 L-BU/BK747Left Rear Door Ajar Switch Signal
70.8 D-BU/WH3266Child Security Lock Motor Control
80.35 BK2150Ground
90.35 BN/WH3269Left Rear Door Lock Status
101 L-BU/WH6667Left Rear Door Latch Signal

A23LR Door Latch Assembly - Left Rear

A23P Door Latch Assembly - Passenger

Connector Part Information Harness Type: Passenger Door OEM Connector: 10768367 Service Connector: 88952463 Description: 10-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: 964274-2/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-560/J-35616-14 (GN)
PinWireCircuitFunction
10.35 TN/WH746Right Front Door Ajar Switch Signal
20.35 L-GN3575Passenger Door Open Switch Signal
30.35 BK650Ground
4Not Used
51 L-GN3583Passenger Door Latch Signal
60.8 BN5910Global Door Lock
70.8 TN294Door Lock Actuator Unlock Control
80.8 GY295Door Lock Actuator Lock Control
9Not Used
101 PK/BK3579Passenger Door Unlatch Signal

A23P Door Latch Assembly - Passenger

A23RR Door Latch Assembly - Right Rear

Connector Part Information Harness Type: Right Rear Door OEM Connector: 10768367 Service Connector: 88952463 Description: 10-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: 964274-2/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-560/J-35616-14 (GN)
PinWireCircuitFunction
10.35 L-GN/BK748Right Rear Door Ajar Switch Signal
20.8 D-BU/WH3266Child Security Lock Motor Control
30.35 BK2050Ground
40.35 GY/BK3268Right Rear Door Lock Status
51 L-GN/BK6669Right Rear Door Unlatch Signal
60.8 BN5910Global Door Lock
70.8 TN294Door Lock Actuator Unlock Control
80.8 GY295Door Lock Actuator Lock Control
90.8 TN294Door Lock Actuator Unlock Control
101 L-GN/WH3581Right Rear Door Unlatch Signal

A23RR Door Latch Assembly - Right Rear

Scheme 463

Scheme 463: B1 A/C Refrigerant Pressure Sensor
Scheme 463: B1 A/C Refrigerant Pressure Sensor
Connector Part Information Harness Type: Forward Lamp OEM Connector: 15477863 Service Connector: 88988301 Description: 3-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/4 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
10.5 TN5514Low Reference
20.5 GY27005-Volt Reference
30.5 OG/BK380A/C Refrigerant Pressure Sensor Signal

B1 A/C Refrigerant Pressure Sensor

Scheme 464

Scheme 464: B5LF Wheel Speed Sensor - Left Front
Scheme 464: B5LF Wheel Speed Sensor - Left Front
Connector Part Information Harness Type: Left Front Wheel Speed Sensor Jumper OEM Connector: 15419715 Service Connector: 88988313 Description: 2-Way F GT 150 Series, Sealed (GY)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.8 YE873Left Front Wheel Speed Sensor Low Reference
B0.8 L-BU830Left Front Wheel Speed Sensor Signal

B5LF Wheel Speed Sensor - Left Front

B5LR Wheel Speed Sensor - Left Rear

Connector Part Information Harness Type: Chassis OEM Connector: 15419715 Service Connector: 88988313 Description: 2-Way F GT 150 Series, Sealed (GY)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.5 OG885Left Rear Wheel Speed Sensor Low Reference
B0.5 TN884Left Rear Wheel Speed Sensor Signal

B5LR Wheel Speed Sensor - Left Rear

B5RF Wheel Speed Sensor - Right Front

Connector Part Information Harness Type: Right Front Wheel Speed Sensor Jumper OEM Connector: 15419715 Service Connector: 88988313 Description: 2-Way F GT 150 Series, Sealed (GY)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.8 TN833Right Front Wheel Speed Sensor Low Reference
B0.8 D-GN872Right Front Wheel Speed Sensor Signal

B5RF Wheel Speed Sensor - Right Front

B5RR Wheel Speed Sensor - Right Rear

Connector Part Information Harness Type: Chassis OEM Connector: 15419715 Service Connector: 88988313 Description: 2-Way F GT 150 Series, Sealed (GY)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.5 WH883Right Rear Wheel Speed Sensor Low Reference
B0.5 BN882Right Rear Wheel Speed Sensor Signal

B5RR Wheel Speed Sensor - Right Rear

Scheme 465

Scheme 465: B7C Air Temperature Sensor - Duct Lower Auxiliary (CJ4)
Scheme 465: B7C Air Temperature Sensor - Duct Lower Auxiliary (CJ4)
Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047662 Service Connector: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN)
PinWireCircuitFunction
A0.35 L-GN405Lower Air Temperature Sensor Signal
B0.35 BN6102Low Reference

B7C Air Temperature Sensor - Duct Lower Auxiliary (CJ4)

B7D Air Temperature Sensor - Duct Left Lower

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047662 Service Connector: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN)
PinWireCircuitFunction
A0.35 TN518Lower Left Air Temperature Sensor Signal
B0.35 TN407Low Reference

B7D Air Temperature Sensor - Duct Left Lower

B7E Air Temperature Sensor - Duct Right Lower

Connector Part Information Harness Type: HVAC OEM Connector: 12047662 Service Connector: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: J-38125-12A/J-35616-14 (GN)
PinWireCircuitFunction
A0.35 TN520Lower Right Air Temperature Sensor Signal
B0.35 TN407Low Reference

B7E Air Temperature Sensor - Duct Right Lower

B7G Air Temperature Sensor - Duct Upper Auxiliary (CJ4)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047662 Service Connector: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: J-38125-12A/J-35616-14 (GN)
PinWireCircuitFunction
A0.35 BN404Upper Air Temperature Sensor Signal
B0.35 BN6102Low Reference

B7G Air Temperature Sensor - Duct Upper Auxiliary (CJ4)

B7H Air Temperature Sensor - Duct Left Upper

Connector Part Information Harness Type: HVAC OEM Connector: 12047662 Service Connector: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: J-38125-12A/J-35616-14 (GN)
PinWireCircuitFunction
A0.35 TN516Upper Left Air Temperature Sensor Signal
B0.35 TN407Low Reference

B7H Air Temperature Sensor - Duct Left Upper

B7J Air Temperature Sensor - Duct Right Upper

Connector Part Information Harness Type: HVAC OEM Connector: 12047662 Service Connector: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: J-38125-12A/J-35616-14 (GN)
PinWireCircuitFunction
A0.35 TN517Upper Right Air Temperature Sensor Signal
B0.35 TN407Low Reference

B.C. Air Temperature Sensor - Duct Right Upper

Scheme 466

Scheme 466: B9 Ambient Air Temperature Sensor
Scheme 466: B9 Ambient Air Temperature Sensor
Connector Part Information Harness Type: Forward Lamp OEM Connector: 12047662 Service Connector: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-14 (GN)
PinWireCircuitFunction
A0.5 D-GN/WH636Ambient Air Temperature Sensor Signal
B0.5 YE61Low Reference

B9 Ambient Air Temperature Sensor

Scheme 467

Scheme 467: B10B Ambient Light/Sunload Sensor (EXP)
Scheme 467: B10B Ambient Light/Sunload Sensor (EXP)
Connector Part Information Harness Type: Instrument Panel OEM Connector: 15344190 Service Connector: 13316153 Description: 6-Way F 0.64 Micro Quadlok Series (BK)
Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 GY728Security Indicator Control
20.35 L-BU/BK590Driver Sunload Sensor Signal
30.35 D-GN734Inside Air Temperature Sensor Signal
40.35 PU1783Twilight Sentinel Delay Signal
50.35 WH278Ambient Light Sensor Signal
60.35 BN6102Low Reference

B10B Ambient Light/Sunload Sensor (EXP)

B10B Ambient Light/Sunload Sensor (without EXP)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 13726957 Service Connector: 13316153 Description: 6-Way F 0.64 Micro Quadlok Series (BK)
Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 GY728Security Indicator Control
20.35 L-BU/BK590Driver Sunload Sensor Signal
30.35 D-GN734Inside Air Temperature Sensor Signal
40.35 PU1783Twilight Sentinel Delay Signal
50.35 WH278Ambient Light Sensor Signal
60.35 BN6102Low Reference

B10B Ambient Light/Sunload Sensor (without EXP)

Scheme 468

Scheme 468: B192 Throttle Inlet Absolute Pressure Sensor (LF1)
Scheme 468: B192 Throttle Inlet Absolute Pressure Sensor (LF1)
Connector Part Information Harness Type: Engine OEM Connector: 15365614 Service Connector: 88988583 Description: 3-Way F Kompakt 2.8 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-561/J-35616-35 (VT)
PinWireCircuitFunction
10.5 GY/WH3201Low Reference
20.5 TN/WH3202Reference Voltage
30.5 YE/WH3200Pressure Signal

B192 Throttle Inlet Absolute Pressure Sensor (LF1)

Scheme 469

Scheme 469: B18 Battery Current Sensor
Scheme 469: B18 Battery Current Sensor
Connector Part Information Harness Type: Engine OEM Connector: 15326808 Service Connector: 15326808 Description: 3-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.5 PK5076Current Sensor Voltage
B0.5 BN5077Low Reference
C0.5 WH5075Current Sensor Signal

B18 Battery Current Sensor

Scheme 470

Scheme 470: B19B Brake Booster Vacuum Sensor
Scheme 470: B19B Brake Booster Vacuum Sensor
Connector Part Information Harness Type: Body OEM Connector: 13511996 Service Connector: 19149288 Description: 3-Way F GT 150 Series, Sealed (GY)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
10.5 OG6030Brake Booster Vacuum Sensor Signal
20.5 YE/BK6032Low Reference
30.5 GY60315-Volt Reference

B19B Brake Booster Vacuum Sensor

Scheme 471

Scheme 471: B20 Brake Fluid Level Switch
Scheme 471: B20 Brake Fluid Level Switch
Connector Part Information Harness Type: Body OEM Connector: 15449028 Service Connector: 88987993 Description: 2-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/4 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.5 PU333Brake Fluid Level Sensor Signal
B0.5 BK1050Ground

B20 Brake Fluid Level Switch

Scheme 472

Scheme 472: B22 Brake Pedal Position Sensor
Scheme 472: B22 Brake Pedal Position Sensor
Connector Part Information Harness Type: Instrument Panel OEM Connector: 15332132 Service Connector: 88953364 Description: 3-Way F GT 150 Series (BK)
Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.35 WH53595-Volt Reference
B0.35 YE5361Brake Pedal Position Sensor Signal
C0.35 BN5360Low Reference

B22 Brake Pedal Position Sensor

B23A Camshaft Position Sensor - Bank 1 Exhaust

Connector Part Information Harness Type: Engine OEM Connector: 15339753 Service Connector: 88988595 Description: 3-Way F Kompakt 2.8 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-561/J-35616-35 (VT)
PinWireCircuitFunction
10.5 GY5296Low Reference (LF1)
0.5 PK/BK632Low Reference (LAU)
20.5 D-GN5273Camshaft Position (CMP) Sensor - Exhaust Bank 1 Signal
30.5 YE/BK5297CMP Sensor 5-Volt Reference Bank 1 Exhaust (LF1)
0.5 OG/BK7376Reference Voltage (LAU)

B23A Camshaft Position Sensor - Bank 1 Exhaust

B23B Camshaft Position Sensor - Bank 1 Intake

Connector Part Information Harness Type: Engine OEM Connector: 15339753 Service Connector: 88988595 Description: 3-Way F Kompakt 2.8 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-561/J-35616-35 (VT)
PinWireCircuitFunction
10.5 TN5301Low Reference (LF1)
0.5 PK/BK632Low Reference (LAU)
20.5 OG5275Camshaft Position (CMP) Sensor - Intake Bank 1 Signal
30.5 D-BU5300CMP Sensor 5-Volt Reference Bank 1 Intake (LF1)
0.5 OG/BK7376Reference Voltage (LAU)

B23B Camshaft Position Sensor - Bank 1 Intake

B23C Camshaft Position Sensor - Bank 2 Exhaust

Connector Part Information Harness Type: Engine OEM Connector: 15339753 Service Connector: 88988595 Description: 3-Way F Kompakt 2.8 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-561/J-35616-35 (VT)
PinWireCircuitFunction
10.5 BN5299Low Reference (LF1)
0.5 PK/BK632Low Reference (LAU)
20.5 PU5274Camshaft Position (CMP) Sensor - Exhaust Bank 2 Signal
30.5 L-GN5298CMP Sensor 5-Volt Reference Bank 2 Exhaust (LF1)
0.5 OG/BK7376Reference Voltage (LAU)

B23C Camshaft Position Sensor - Bank 2 Exhaust

B23D Camshaft Position Sensor - Bank 2 Intake

Connector Part Information Harness Type: Engine OEM Connector: 15339753 Service Connector: 88988595 Description: 3-Way F Kompakt 2.8 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-561/J-35616-35 (VT)
PinWireCircuitFunction
10.5 BN/WH5303Low Reference (LF1)
0.5 PK/BK632Low Reference (LAU)
20.5 YE5276Camshaft Position (CMP) Sensor - Intake Bank 2 Signal
30.5 L-BU5302CMP Sensor 5-Volt Reference Bank 2 Intake (LF1)
0.5 OG/BK7376Reference Voltage (LAU)

B23D Camshaft Position Sensor - Bank 2 Intake

Scheme 473

Scheme 473: B24 Cellular Phone Microphone (NAV, UPH, or UPJ)
Scheme 473: B24 Cellular Phone Microphone (NAV, UPH, or UPJ)
Connector Part Information Harness Type: Overhead Console OEM Connector: 13646861 Service Connector: Service by Harness - See Part Catalog Description: 3-Way M 0.64 Series (BK)
Terminal Part Information Terminal/Tray: SAITW-A03T-064/20 Core/Insulation Crimp: J/J Release Tool/Test Probe: J-38125-215A/J-35616-65B (L-BU)
PinWireCircuitFunction
1Not Used
20.35 D-GN654Cellular Microphone Signal
30.35 GY655Cellular Microphone Signal

B24 Cellular Phone Microphone (NAV, UPH, or UPJ)

B24 Cellular Phone Microphone (UE1)

Connector Part Information Harness Type: Overhead Console OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.35 D-GN654Cellular Microphone Signal
B0.35 GY655Cellular Microphone Signal

B24 Cellular Phone Microphone (UE1)

Scheme 474

Scheme 474: B26 Crankshaft Position Sensor
Scheme 474: B26 Crankshaft Position Sensor
Connector Part Information Harness Type: Engine OEM Connector: 13599025 Service Connector: 88988337 Description: 3-Way F 64 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: SAIT-A03GF-M064/27 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.5 TN452Low Reference (LF1)
0.5 PU574Low Reference (LAU)
20.5 YE573CKP Sensor Signal
30.5 GY6055-Volt Reference (LF1)
0.5 L-GN286712-Volt Reference (LAU)

B26 Crankshaft Position Sensor

Scheme 475

Scheme 475: B27A Door Handle Switch - Driver Exterior
Scheme 475: B27A Door Handle Switch - Driver Exterior
Connector Part Information Harness Type: Driver Door OEM Connector: 13528494 Service Connector: 19178174 Description: 2-Way F Kaizen 64 Series (BK)
Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 BK750Ground
20.35 L-GN/WH3570Door Handle Switch - Driver Signal

B27A Door Handle Switch - Driver Exterior

B27B Door Handle Switch - Passenger Exterior

Connector Part Information Harness Type: Passenger Door OEM Connector: 13528494 Service Connector: 19178174 Description: 2-Way F Kaizen 64 Series (BK)
Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 BK650Ground
20.35 PU/WH3571Door Handle Switch - Passenger Signal

B27B Door Handle Switch - Passenger Exterior

B27LR Door Handle Switch - Left Rear Exterior

Connector Part Information Harness Type: Left Rear Door OEM Connector: 13528494 Service Connector: 19178174 Description: 2-Way F Kaizen 64 Series (BK)
Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 BK2150Ground
20.35 BN6157Door Handle Switch - Left Rear Signal

B27LR Door Handle Switch - Left Rear Exterior

B27RR Door Handle Switch - Right Rear Exterior

Connector Part Information Harness Type: Right Rear Door OEM Connector: 13528494 Service Connector: 19178174 Description: 2-Way F Kaizen 64 Series (BK)
Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 BK2050Ground
20.35 GY6158Door Handle Switch - Right Rear Signal

B27RR Door Handle Switch - Right Rear Exterior

Scheme 476

Scheme 476: B33 Engine Coolant Level Switch (T89)
Scheme 476: B33 Engine Coolant Level Switch (T89)
Connector Part Information Harness Type: Body OEM Connector: 13548106 Service Connector: 13314083 Description: 2-Way F 1.2 Timer Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 964274-2/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-560/J-35616-14 (GN)
PinWireCircuitFunction
10.5 BK1050Ground
20.5 YE/BK68Low Coolant Level Indicator Control

B33 Engine Coolant Level Switch (T89)

Scheme 477

Scheme 477: B34 Engine Coolant Temperature Sensor (LAU)
Scheme 477: B34 Engine Coolant Temperature Sensor (LAU)
Connector Part Information Harness Type: Engine OEM Connector: 15339756 Service Connector: 88988963 Description: 2-Way F Kompakt 2.8 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-561/J-35616-35 (VT)
PinWireCircuitFunction
10.5 YE410ECT Sensor Signal
20.5 TN2761Low Reference

B34 Engine Coolant Temperature Sensor (LAU)

More articles — Electrical
