Wiring Systems and Power Management - Component Connector End Views - B153D Through E29LF Cadillac SRX II

Body Electrical 19 illustrations ~621 words

Scheme 273

Scheme 273: B153D Seat Belt Buckle - Driver
Scheme 273: B153D Seat Belt Buckle - Driver
Connector Part Information Harness Type: Driver Seat OEM Connector: 12052832 Service Connector: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: Pending Release Tool/Test Probe: 12094429/J-35616-14 (GN)
PinWireCircuitFunction
A0.35 TN/WH238Seat Belt Switch - Left
B0.35 D-BU1363Seat Belt Switch - Left - Low Reference

B153D Seat Belt Buckle - Driver

B153P Seat Belt Buckle - Passenger

Connector Part Information Harness Type: Passenger Seat OEM Connector: 12052832 Service Connector: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: Pending Release Tool/Test Probe: 12094429/J-35616-14 (GN)
PinWireCircuitFunction
A0.35 OG1362Seat Belt Switch - Right - Signal
B0.35 L-BU1361Seat Belt Switch - Right - Low Reference

B153P Seat Belt Buckle - Passenger

Scheme 274

Scheme 274: B157 Secondary Air Injection Pressure Sensor (LAU)
Scheme 274: B157 Secondary Air Injection Pressure Sensor (LAU)
Connector Part Information Harness Type: Engine OEM Connector: 15398808 Service Connector: 19115590 Description: 3-Way F SSC Series (BK)
Terminal Part Information Terminal/Tray: 184095-1/7 Core/Insulation Crimp: E/D Release Tool/Test Probe: 12094429/J-35616-33 (YE)
PinWireCircuitFunction
10.5 GY4745-Volt Reference
20.5 BK/WH51Ground
30.5 BN/WH6331Baro Sensor Signal

B157 Secondary Air Injection Pressure Sensor (LAU)

Scheme 275

Scheme 275: B160 Windshield Temperature and Inside Moisture Sensor (ASV)
Scheme 275: B160 Windshield Temperature and Inside Moisture Sensor (ASV)
Connector Part Information Harness Type: Headliner OEM Connector: 15344190 Service Connector: 13316153 Description: 6-Way F 0.64 Micro Quadlok Series (BK)
Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 GY5975-Volt Reference
20.35 L-BU7564Humidity Sensor Signal
30.35 D-GN7566Low Reference
40.35 GY7565Temperature Signal
50.35 TN3197Temperature Signal
6Not Used

B160 Windshield Temperature and Inside Moisture Sensor (ASV)

Scheme 276

Scheme 276: B161LF Vertical Suspension Acceleration Sensor - Left Front (F55)
Scheme 276: B161LF Vertical Suspension Acceleration Sensor - Left Front (F55)
Connector Part Information Harness Type: Left Front Wheel Speed Sensor Jumper OEM Connector: 13519047 Service Connector: Service by Harness - See Part Catalog Description: 3-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.8 YE1817Left Front Wheel Accelerometer Reference Voltage
B0.8 WH1100Left Front Wheel Damping Accelerometer Signal
C0.8 PK/BK1099Left Front Wheel Damping Accelerometer Low Reference

B161LF Vertical Suspension Acceleration Sensor - Left Front (F55)

B161RF Vertical Suspension Acceleration Sensor - Right Front (F55)

Connector Part Information Harness Type: Right Front Wheel Speed Sensor Jumper OEM Connector: 13519047 Service Connector: Service by Harness - See Part Catalog Description: 3-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.8 L-GN/BK1819Right Front Wheel Accelerometer Reference Voltage
B0.8 WH1106Right Front Wheel Damping Accelerometer Signal
C0.8 PK/BK1105Right Front Wheel Damping Accelerometer Low Reference

B161RF Vertical Suspension Acceleration Sensor - Right Front (F55)

Scheme 277

Scheme 277: B162LF Vertical Body Acceleration Sensor - Left Front (F45)
Scheme 277: B162LF Vertical Body Acceleration Sensor - Left Front (F45)
Connector Part Information Harness Type: Body OEM Connector: 15397338 Service Connector: 19179748 Description: 3-Way F 2.8 Timer Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-36/J-35616-35 (VT)
PinWireCircuitFunction
10.5 PU/WH3258Reference Voltage
20.5 L-BU3259Vertical Body Acceleration Sensor - Left Front Signal
30.5 GY3260Low Reference

B162LF Vertical Body Acceleration Sensor - Left Front (F45)

B162R Vertical Body Acceleration Sensor - Rear (F45)

Connector Part Information Harness Type: Body OEM Connector: 15397338 Service Connector: 19179748 Description: 3-Way F 2.8 Timer Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-36/J-35616-35 (VT)
PinWireCircuitFunction
10.5 D-BU/WH3255Reference Voltage
20.5 D-GN3256Vertical Body Acceleration Sensor - Rear Signal
30.5 BN3257Low Reference

B162R Vertical Body Acceleration Sensor - Rear (F45)

B162RF Vertical Body Acceleration Sensor - Right Front (F45)

Connector Part Information Harness Type: Body OEM Connector: 15397338 Service Connector: 19179748 Description: 3-Way F 2.8 Timer Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-36/J-35616-35 (VT)
PinWireCircuitFunction
10.5 PK/WH3252Reference Voltage
20.5 D-BU3253Vertical Body Acceleration Sensor - Right Front Signal
30.5 TN3254Low Reference

B162RF Vertical Body Acceleration Sensor - Right Front (F45)

Scheme 278

Scheme 278: B164 Liftgate Angle Sensor
Scheme 278: B164 Liftgate Angle Sensor
Connector Part Information Harness Type: Liftgate OEM Connector: 15332145 Service Connector: 15306407 Description: 8-Way F GT 150 Series (BK)
Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.5 TN/BK5803Battery Positive Voltage
BNot Used
C0.5 L-BU/WH5805Liftgate Position Sensor 1 Signal
D0.5 PU5806Liftgate Position Sensor 2 Signal
E0.5 D-GN5804Low Reference
F-GNot Used
H0.5 YE/BK2999Drain Wire

B164 Liftgate Angle Sensor

Scheme 279

Scheme 279: E1D Accent Lamp - Driver Door (TSQ)
Scheme 279: E1D Accent Lamp - Driver Door (TSQ)
Connector Part Information Harness Type: Driver Door OEM Connector: 13670097 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F 1.6 Timer Series (BK)
Terminal Part Information Terminal/Tray: 964274-2/16 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: J-38125-560/J-35616-14 (GN)
PinWireCircuitFunction
10.35 PK7557Ambient Lighting
20.35 BK750Ground

E1D Accent Lamp - Driver Door (TSQ)

Scheme 280

Scheme 280: E1G Accent Lamp - Left Instrument Panel (TSQ)
Scheme 280: E1G Accent Lamp - Left Instrument Panel (TSQ)
Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.35 BK1650Ground
B0.35 PK7557Accent Lamps Control

E1G Accent Lamp - Left Instrument Panel (TSQ)

E1H Accent Lamp - Right Instrument Panel (TSQ)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.35 BK1650Ground
B0.35 PK7558Accent Lamps Control

E1H Accent Lamp - Right Instrument Panel (TSQ)

E1J Accent Lamp - Left Lower Instrument Panel (TSQ)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.35 BK1650Ground
B0.35 PK7558Accent Lamps Control

E1J Accent Lamp - Left Lower Instrument Panel (TSQ)

E1K Accent Lamp - Right Lower Instrument Panel (EAL)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.35 BK1650Ground
B0.35 PU7558Accent Lamps Control

E1K Accent Lamp - Right Lower Instrument Panel (EAL)

Scheme 281

Scheme 281: E1K Accent Lamp - Right Lower Instrument Panel (TSQ)
Scheme 281: E1K Accent Lamp - Right Lower Instrument Panel (TSQ)
Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047662 Service Connector: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN)
PinWireCircuitFunction
A0.35 BK1650Ground
B0.35 PK7557Ambient Lighting

E1K Accent Lamp - Right Lower Instrument Panel (TSQ)

Scheme 282

Scheme 282: E1L Accent Lamp - Overhead Console (TSQ)
Scheme 282: E1L Accent Lamp - Overhead Console (TSQ)
Connector Part Information Harness Type: Overhead Console OEM Connector: 13595207 Service Connector: 19179373 Description: 2-Way F 0.64 Series (BK)
Terminal Part Information Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
10.35 PK7557Ambient Lighting
20.35 BK1350Ground

E1L Accent Lamp - Overhead Console (TSQ)

E1LR Accent Lamp - Left Rear Door (TSQ)

Connector Part Information Harness Type: Right Rear Door Trim OEM Connector: 13670097 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F 1.6 Timer Series (BK)
Terminal Part Information Terminal/Tray: 964274-2/16 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: J-38125-560/J-35616-14 (GN)
PinWireCircuitFunction
10.35 PK7557Ambient Lighting
20.35 BK2150Ground

E1LR Accent Lamp - Left Rear Door (TSQ)

E1P Accent Lamp - Passenger Door (TSQ)

Connector Part Information Harness Type: Passenger Door Trim OEM Connector: 13670097 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F 1.6 Timer Series (BK)
Terminal Part Information Terminal/Tray: 964274-2/16 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: J-38125-560/J-35616-14 (GN)
PinWireCircuitFunction
10.35 PK7557Ambient Lighting
20.35 BK650Ground

E1P Accent Lamp - Passenger Door (TSQ)

E1RR Accent Lamp - Right Rear Door (TSQ)

Connector Part Information Harness Type: Right Rear Door Trim OEM Connector: 13670097 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F 1.6 Timer Series (BK)
Terminal Part Information Terminal/Tray: 964274-2/16 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: J-38125-560/J-35616-14 (GN)
PinWireCircuitFunction
10.35 PK7557Ambient Lighting
20.35 BK2050Ground

E1RR Accent Lamp - Right Rear Door (TSQ)

Scheme 283

Scheme 283: E4LR Turn Signal Lamp - Left Rear (T89)
Scheme 283: E4LR Turn Signal Lamp - Left Rear (T89)
Connector Part Information Harness Type: Body OEM Connector: 15431040 Service Connector: 88988109 Description: 2-Way F 1.5 Series Sealed (GY)
Terminal Part Information Terminal/Tray: 7116-4102-08/9 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094430/J-35616-2A (GY)
PinWireCircuitFunction
10.5 BK1350Ground
2Not Available
30.35 YE/BK1334Left Rear Turn Signal Lamp Supply Voltage

E4LR Turn Signal Lamp - Left Rear (T89)

E4LR Turn Signal Lamp - Left Rear (Without T89)

Connector Part Information Harness Type: Body OEM Connector: 15461166 Service Connector: 88988110 Description: 2-Way F 1.5 Series Sealed (GN)
Terminal Part Information Terminal/Tray: 7116-4102-08/9 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094430/J-35616-2A (GY)
PinWireCircuitFunction
10.5 BK1350Ground
2Not Available
30.35 YE/BK1334Left Rear Turn Signal Lamp Supply Voltage

E4LR Turn Signal Lamp - Left Rear (Without T89)

E4P Park/Turn Signal Lamp - Right

Connector Part Information Harness Type: Body OEM Connector: 15326808 Service Connector: 15306388 Description: 3-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.5 D-GN7541Stop Lamp Control Signal
B0.5 BN/WH309Right Park Lamp Supply Voltage
C0.5 BK1250Ground

E4P Park/Turn Signal Lamp - Right

E4RR Turn Signal Lamp - Right Rear (T89)

Connector Part Information Harness Type: Body OEM Connector: 15431040 Service Connector: 88988109 Description: 2-Way F 1.5 Series Sealed (GY)
Terminal Part Information Terminal/Tray: 7116-4102-08/9 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094430/J-35616-2A (GY)
PinWireCircuitFunction
10.35 BK1250Ground
2Not Available
30.35 D-GN/WH1335Right Rear Turn Signal Lamp Supply Voltage

E4RR Turn Signal Lamp - Right Rear (T89)

E4RR Turn Signal Lamp - Right Rear (Without T89)

Connector Part Information Harness Type: Body OEM Connector: 15461166 Service Connector: 88988110 Description: 2-Way F 1.5 Series Sealed (GN)
Terminal Part Information Terminal/Tray: 7116-4102-08/9 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094430/J-35616-2A (GY)
PinWireCircuitFunction
10.35 BK1250Ground
2Not Available
30.35 D-GN/WH1335Right Rear Turn Signal Lamp Supply Voltage

E4RR Turn Signal Lamp - Right Rear (Without T89)

Scheme 284

Scheme 284: E4Y Turn Signal Repeater Lamp - Left
Scheme 284: E4Y Turn Signal Repeater Lamp - Left
Connector Part Information Harness Type: Body OEM Connector: 15419380 Service Connector: 88988059 Description: 2-Way F 1.5 Series Sealed (GY)
Terminal Part Information Terminal/Tray: 7116-4102-08/9 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094430/J-35616-2A (GY)
PinWireCircuitFunction
10.35 L-BU/WH1314Left Front Turn Signal Lamp Supply Voltage
20.35 BK750Ground

E4Y Turn Signal Repeater Lamp - Left

E4Z Turn Signal Repeater Lamp - Right

Connector Part Information Harness Type: Body OEM Connector: 15419380 Service Connector: 88988059 Description: 2-Way F 1.5 Series Sealed (GY)
Terminal Part Information Terminal/Tray: 7116-4102-08/9 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094430/J-35616-2A (GY)
PinWireCircuitFunction
10.35 D-BU/WH1315Right Front Turn Signal Lamp Supply Voltage
20.35 BK650Ground

E4Z Turn Signal Repeater Lamp - Right

Scheme 285

Scheme 285: E5A Backup Lamp - Left
Scheme 285: E5A Backup Lamp - Left
Connector Part Information Harness Type: Body OEM Connector: 13531640 Service Connector: 19149296 Description: 2-Way F Clean Body Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 962885-5/15 Core/Insulation Crimp: 6/6 Release Tool/Test Probe: 12094429/J-35616-64B (L-BU)
PinWireCircuitFunction
10.5 L-GN24Backup Lamp Supply Voltage
20.5 BK1350Ground

E5A Backup Lamp - Left

E5AA Tail/Stop Lamp - Left

Connector Part Information Harness Type: Body OEM Connector: 15326808 Service Connector: 15306388 Description: 3-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.5 YE7542Stop Lamp Control Signal
B0.5 PU709Left Park Lamp Supply Voltage
C0.5 BK1350Ground

E5AA Tail/Stop Lamp - Left

Scheme 286

Scheme 286: E5AA Tail/Stop Lamp - Left (T89)
Scheme 286: E5AA Tail/Stop Lamp - Left (T89)
Connector Part Information Harness Type: Body OEM Connector: 15326815 Service Connector: 19180287 Description: 4-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.5 YE7542Stop Lamp Control Signal
B0.5 PU709Left Park Lamp Supply Voltage
C0.5 BK1350Ground
D0.35 OG122Rear Fog Lamp Supply Voltage

E5AA Tail/Stop Lamp - Left (T89)

E5AB Tail/Stop Lamp - Right

Connector Part Information Harness Type: Body OEM Connector: 15326808 Service Connector: 15306388 Description: 3-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.5 D-GN7541Stop Lamp Control Signal
B0.5 BN/WH309Right Park Lamp Supply Voltage
C0.5 BK1250Ground

E5AB Tail/Stop Lamp - Right

E5AB Tail/Stop Lamp - Right (T89)

Connector Part Information Harness Type: Body OEM Connector: 15326815 Service Connector: 19180287 Description: 4-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.5 D-GN7541Stop Lamp Control Signal
B0.5 BN/WH309Right Park Lamp Supply Voltage
C0.5 BK1250Ground
D0.5 L-GN24Backup Lamp Supply Voltage

E5AB Tail/Stop Lamp - Right (T89)

E5B Backup Lamp - Right

Connector Part Information Harness Type: Body OEM Connector: 13531640 Service Connector: 19149296 Description: 2-Way F Clean Body Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 962885-5/15 Core/Insulation Crimp: 6/6 Release Tool/Test Probe: 12094429/J-35616-64B (L-BU)
PinWireCircuitFunction
10.5 L-GN24Backup Lamp Supply Voltage
20.5 BK1250Ground

E5B Backup Lamp - Right

E6 Center High Mounted Stop Lamp

Connector Part Information Harness Type: Liftgate OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.35 WH5065Center High Mounted Stop Lamp (CHMSL) Control
B0.35 BK1350Ground

E6 Center High Mounted Stop Lamp

Scheme 287

Scheme 287: E8A Door Sill Plate Lamp - Driver
Scheme 287: E8A Door Sill Plate Lamp - Driver
Connector Part Information Harness Type: Body OEM Connector: 15326801 Service Connector: 19179278 Description: 2-Way F Ducon 6.3 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.35 PK7557Ambient Lighting
B0.35 BK2150Ground

E8A Door Sill Plate Lamp - Driver

E8B Door Sill Plate Lamp - Passenger

Connector Part Information Harness Type: Body OEM Connector: 15326801 Service Connector: 19179278 Description: 2-Way F Ducon 6.3 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A0.35 PK7557Ambient Lighting
B0.35 BK2050Ground

E8B Door Sill Plate Lamp - Passenger

E8D Door Courtesy Lamp - Driver

Connector Part Information Harness Type: Driver Door Trim OEM Connector: 13595207 Service Connector: 19179373 Description: 2-Way F 0.64 Series (BK)
Terminal Part Information Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
10.35 GY157Courtesy Lamp Control
20.35 BK750Ground

E8D Door Courtesy Lamp - Driver

E8J Instrument Panel Courtesy Lamp - Left

Connector Part Information Harness Type: Instrument Panel OEM Connector: 13595207 Service Connector: 19179373 Description: 2-Way F 0.64 Series (BK)
Terminal Part Information Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
10.35 GY157Courtesy Lamp Control
20.35 BK1750Ground

E8J Instrument Panel Courtesy Lamp - Left

E8K Instrument Panel Courtesy Lamp - Right

Connector Part Information Harness Type: Instrument Panel OEM Connector: 13595207 Service Connector: 19179373 Description: 2-Way F 0.64 Series (BK)
Terminal Part Information Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
10.35 GY157Courtesy Lamp Control
20.35 BK1650Ground

E8K Instrument Panel Courtesy Lamp - Right

E8L Liftgate Courtesy Lamp

Connector Part Information Harness Type: Liftgate OEM Connector: 13595207 Service Connector: 19179373 Description: 2-Way F 0.64 Series (BK)
Terminal Part Information Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
10.35 OG/BK737Rear Compartment Lamp Control
20.5 BK1350Ground

E8L Liftgate Courtesy Lamp

E8LR Door Courtesy Lamp - Left Rear

Connector Part Information Harness Type: Left Rear Door Trim OEM Connector: 13595207 Service Connector: 19179373 Description: 2-Way F 0.64 Series (BK)
Terminal Part Information Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
10.35 GY157Courtesy Lamp Control
20.35 BK2150Ground

E8LR Door Courtesy Lamp - Left Rear

E8P Door Courtesy Lamp - Passenger

Connector Part Information Harness Type: Passenger Door Trim OEM Connector: 13595207 Service Connector: 19179373 Description: 2-Way F 0.64 Series (BK)
Terminal Part Information Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
10.35 GY157Courtesy Lamp Control
20.35 BK650Ground

E8P Door Courtesy Lamp - Passenger

Scheme 288

Scheme 288: E14A Seat Heating Element - Driver Back (KA1)
Scheme 288: E14A Seat Heating Element - Driver Back (KA1)
Connector Part Information Harness Type: Driver Seat OEM Connector: 12059254 Service Connector: 12126020 Description: 2-Way M Metri-Pack 150 Series (GN)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.8 L-GN2078Heated Seat Cushion Element Control
B0.8 PU2424Driver Heated Seat Back Element Control

E14A Seat Heating Element - Driver Back (KA1)

Scheme 289

Scheme 289: E14B Seat Heating Element - Driver Cushion (KA1)
Scheme 289: E14B Seat Heating Element - Driver Cushion (KA1)
Connector Part Information Harness Type: Driver Seat OEM Connector: 12047786 Service Connector: 12085536 Description: 4-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: Pins A, B - E/A Core/Insulation Crimp: Pins C, D - E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.8 PK2077Heated Seat Cushion Element Supply Voltage
B0.8 L-GN2078Heated Seat Cushion Element Control
C0.35 YE/BK2079Heated Seat Cushion Temperature Sensor Signal
D0.35 YE2080Driver Heated Seat Cushion Temperature Sensor Low Reference

E14B Seat Heating Element - Driver Cushion (KA1)

E14C Seat Heating Element - Passenger Back (KA1)

Connector Part Information Harness Type: Passenger Seat OEM Connector: 12059254 Service Connector: 12126020 Description: 2-Way M Metri-Pack 150 Series (GN)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.8 PK2480Passenger Heated Seat Cushion Element Control
B0.8 L-BU2433Passenger Heated Seat Back Element Control

E14C Seat Heating Element - Passenger Back (KA1)

E14D Seat Heating Element - Passenger Cushion (KA1)

Connector Part Information Harness Type: Passenger Seat OEM Connector: 12047786 Service Connector: 12085536 Description: 4-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: Pins A, B - E/A Core/Insulation Crimp: Pins C, D - E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.8 D-BU2479Passenger Heated Seat Element Supply Voltage
B0.8 PK2480Passenger Heated Seat Cushion Element Control
C0.35 GY2434Passenger Heated Seat Cushion Temperature Sensor Signal
D0.35 PK2435Passenger Heated Seat Cushion Temperature Sensor Low Reference

E14D Seat Heating Element - Passenger Cushion (KA1)

Scheme 290

Scheme 290: E18 Rear Defogger Grid X1
Scheme 290: E18 Rear Defogger Grid X1
Connector Part Information Harness Type: Liftgate OEM Connector: 12059885 Service Connector: 12101893 Description: 1-Way M Metri-Pack 480 Series (BK)
Terminal Part Information Terminal/Tray: 12020120/2 Core/Insulation Crimp: A/D Release Tool/Test Probe: 12094430/J-35616-41 (BU)
PinWireCircuitFunction
A2 PU293Rear Defog Element Supply Voltage

E18 Rear Defogger Grid X1

E18 Rear Defogger Grid X2

Connector Part Information Harness Type: Liftgate OEM Connector: 12059885 Service Connector: 12101893 Description: 1-Way M Metri-Pack 480 Series (BK)
Terminal Part Information Terminal/Tray: 12020120/2 Core/Insulation Crimp: A/D Release Tool/Test Probe: 12094430/J-35616-41 (BU)
PinWireCircuitFunction
A2 BK1350Ground

E18 Rear Defogger Grid X2

E27 Instrument Panel Compartment Lamp

Connector Part Information Harness Type: Instrument Panel OEM Connector: 13595207 Service Connector: 19179373 Description: 2-Way F 0.64 Series (BK)
Terminal Part Information Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
10.5 OG6815Inadvertent Power Supply Voltage
20.35 BK1650Ground

E27 Instrument Panel Compartment Lamp

Scheme 291

Scheme 291: E29LF Fog Lamp - Left Front (T96)
Scheme 291: E29LF Fog Lamp - Left Front (T96)
Connector Part Information Harness Type: Front Bumper OEM Connector: 12059183 Service Connector: 12101898 Description: 2-Way F Metri-Pack 280 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12077411/2 Core/Insulation Crimp: 2/5 Release Tool/Test Probe: 12094430/J-35616-4A (PU)
PinWireCircuitFunction
A0.8 PU2234Front Fog Lamp Supply Voltage
B0.8 BK150Ground

E29LF Fog Lamp - Left Front (T96)

More articles — Electrical
