Wiring Systems and Power Management - Component Connector End Views - T10G Through x88 Cadillac SRX II

Body Electrical 9 illustrations ~134 words

Scheme 431

Scheme 431: T10G Keyless Entry Antenna - Rear Fascia
Scheme 431: T10G Keyless Entry Antenna - Rear Fascia
Connector Part Information Harness Type: Body OEM Connector: 15365708 Service Connector: 13576533 Description: 2-Way F MQS Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 962885-5/15 Core/Insulation Crimp: 6/6 Release Tool/Test Probe: 12094429/J-35616-64B (L-BU)
PinWireCircuitFunction
10.5 D-GN3568Antenna +
20.5 D-GN/WH3569Antenna

T10G Keyless Entry Antenna - Rear Fascia

T10J Keyless Entry Antenna - Center Console Front

Connector Part Information Harness Type: Body OEM Connector: 15365708 Service Connector: 13576533 Description: 2-Way F MQS Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 962885-5/15 Core/Insulation Crimp: 6/6 Release Tool/Test Probe: 12094429/J-35616-64B (L-BU)
PinWireCircuitFunction
10.5 BN/BK3552Antenna +
20.5 WH3553Antenna

T10J Keyless Entry Antenna - Center Console Front

Scheme 432

Scheme 432: T11 Multimedia Player Interface Module (UTE or UYK or UYI)
Scheme 432: T11 Multimedia Player Interface Module (UTE or UYK or UYI)
Connector Part Information Harness Type: Instrument Panel OEM Connector: 15489824 Service Connector: 15126711 Description: 20-Way F 64 Series (BK)
Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.5 RD/WH340Battery Positive Voltage
20.35 PK2060Auxiliary Detection Signal
30.35 GY/WH3374Auxiliary Audio Jack Common
40.35 D-GN/WH3376Auxiliary Audio Common Signal
50.35 NONE3375Drain Wire
6-7Not Used
80.35 D-GN5060Low Speed GMLAN Serial Data
90.35 BN5170Mid Speed GMLAN Serial Data Bus
90.35 BN5170Mid Speed GMLAN Serial Data Bus
100.35 BN5170Mid Speed GMLAN Serial Data Bus - (Except EXP)
110.5 BK/WH1551Ground
120.35 L-GN5839Left Auxiliary Audio Signal (2)
130.35 D-GN/WH5841Right Auxiliary Audio Signal (2)
140.35 YE3377Auxiliary Audio Jack Left (+)
150.35 TN/WH3378Auxiliary Audio Jack Right (+)
16-17Not Used
180.35 NONE5842Drain Wire
190.35 BN/WH5169Mid Speed GMLAN Serial Data Bus+
190.35 BN/WH5169Mid Speed GMLAN Serial Data Bus+
200.35 BN/WH5169Mid Speed GMLAN Serial Data Bus+ (except EXP)

T11 Multimedia Player Interface Module (UTE or UYK or UYI)

Scheme 433

Scheme 433: X80C Accessory Power Receptacle - Cargo
Scheme 433: X80C Accessory Power Receptacle - Cargo
Connector Part Information Harness Type: Body OEM Connector: 12176446 Service Connector: 15305923 Description: 3-Way F Metri-Pack 280 Series, Flexlock (BK)
Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)
PinWireCircuitFunction
A1 RD/WH4940Battery Positive Voltage
BNot Used
C1 BK1350Ground

X80C Accessory Power Receptacle - Cargo

Scheme 434

Scheme 434: X80D Accessory Power Receptacle - Center Console Compartment
Scheme 434: X80D Accessory Power Receptacle - Center Console Compartment
Connector Part Information Harness Type: Instrument Panel OEM Connector: 12176836 Service Connector: 15305923 Description: 3-Way F Metri-Pack 280 Series (GY)
Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)
PinWireCircuitFunction
A1 D-GN801RAP 2 Fuse Supply Voltage
BNot Used
C1 BK1650Ground

X80D Accessory Power Receptacle - Center Console Compartment

X80G Accessory Power Receptacle - Instrument Panel

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12176836 Service Connector: 15305923 Description: 3-Way F Metri-Pack 280 Series (GY)
Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)
PinWireCircuitFunction
A1 D-GN801RAP 2 Fuse Supply Voltage
BNot Used
C1 BK1650Ground

X80G Accessory Power Receptacle - Instrument Panel

X80H Accessory Power Receptacle - Center Console

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12176836 Service Connector: 15305923 Description: 3-Way F Metri-Pack 280 Series (GY)
Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)
PinWireCircuitFunction
A1 D-GN801RAP 2 Fuse Supply Voltage
BNot Used
C1 BK1650Ground

X80H Accessory Power Receptacle - Center Console

Scheme 435

Scheme 435: X83 Auxiliary Audio Input
Scheme 435: X83 Auxiliary Audio Input
Connector Part Information Harness Type: Floor Console OEM Connector: 13595476 Service Connector: 19167753 Description: 6-Way F AIT II Series (BK)
Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 L-GN5839Left Auxiliary Audio Signal (2)
20.35 D-GN/WH5841Not Used
30.35 GY/WH3374Ground
4Not Used
50.35 PK2060Auxiliary Detection Signal
6Not Used

X83 Auxiliary Audio Input

Scheme 436

Scheme 436: X84 Data Link Connector
Scheme 436: X84 Data Link Connector
Connector Part Information Harness Type: Instrument Panel OEM Connector: 13580435 Service Connector: 19178163 Description: 16-Way F (BK)
Terminal Part Information Terminal/Tray: 50420-8000/15 Core/Insulation Crimp: Pins 1, 3, 5, 6, 11-14 - H/H Core/Insulation Crimp: Pins 4, 16 - Pending Release Tool/Test Probe: 12094429/J-35616-2A (GY)
PinWireCircuitFunction
10.35 D-GN5060Low Speed GMLAN Serial Data
2Not Used
30.35 BN/WH5169Mid Speed GMLAN Serial Data Bus+ (UYG, UYI, UYK, UPH, or UPJ)
40.8 BK1750Ground
50.35 BK/WH1751Ground
60.35 TN/BK2500High Speed GMLAN Serial Data Bus+
7-10Not Used
110.35 BN5170Mid Speed GMLAN Serial Data Bus - (UYG, UYI, UYK, UPH, or UPJ)
120.35 D-BU6105High Speed GMLAN Serial Data (+)
130.35 L-BU6106High Speed GMLAN Serial Data (-)
140.35 TN2501High Speed GMLAN Serial Data Bus
15Not Used
160.8 RD/WH40Battery Positive Voltage

X84 Data Link Connector

Scheme 437

Scheme 437: X85 Steering Wheel Air Bag Coil X1
Scheme 437: X85 Steering Wheel Air Bag Coil X1
Connector Part Information Harness Type: Steering Column OEM Connector: 15393421 Service Connector: 88987853 Description: 4-Way F Micro-Pack 064 Series (YE)
Terminal Part Information Terminal/Tray: Service with Pigtail Core/Insulation Crimp: Service with Pigtail Release Tool/Test Probe: N/A
PinWireCircuitFunction
10.5 TN3021Steering Wheel Module - Stage 1 - High Control
20.5 BN3020Steering Wheel Module - Stage 1 - Low Control
30.5 WH3023Steering Wheel Module - Stage 2 - High Control
40.5 PK3022Steering Wheel Module - Stage 2 - Low Control

X85 Steering Wheel Air Bag Coil X1

Scheme 438

Scheme 438: X85 Steering Wheel Air Bag Coil X2
Scheme 438: X85 Steering Wheel Air Bag Coil X2
Connector Part Information Harness Type: Steering Column OEM Connector: 13574592 Service Connector: Service by Harness - See Part Catalog Description: 10-Way F Kaizen 64 Series (BK)
Terminal Part Information Terminal/Tray: Service with Terminated Lead Core/Insulation Crimp: Service with Terminated Lead Release Tool/Test Probe: N/A
PinWireCircuitFunction
10.35 L-GN/WH3287Horn Switch Signal
20.35 YE7556Headlamp Switch Reference Voltage
30.35 BN6136LED Backlight Dimming Control
40.5 BK1750Ground
50.35 GY1884Cruise Control Switch Signal
6Not Used
70.35 L-GN6818Steering Wheel Control Switch Signal
8-10Not Used

X85 Steering Wheel Air Bag Coil X2

Scheme 439

Scheme 439: X88 Trailer Connector (Without UG4)
Scheme 439: X88 Trailer Connector (Without UG4)
Connector Part Information Harness Type: Body OEM Connector: 12160825 Service Connector: 15305801 Description: 4-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12045773/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-3 (GY)
PinWireCircuitFunction
A0.8 BN2109Trailer Park Lamps Supply Voltage
B0.8 YE318Left Rear Trailer Stop/Turn Lamp Supply Voltage
C0.8 D-GN319Right Rear Trailer Stop/Turn Lamp Supply Voltage
D0.8 BK1350Ground

X88 Trailer Connector (Without UG4)
