Scheme 374
Scheme 374: M50D Seat Front Vertical Motor - Driver
| Connector Part Information Harness Type: Driver Seat OEM Connector: 10848198 Service Connector: Service by Harness - See Part Catalog Description: 5-Way F MQS/MCP Mixed Series (BK) |
|---|
| Terminal Part Information Pins: 1, 5 Terminal/Tray: Service by Connector Assembly - 10848198 Core/Insulation Crimp: Not Available Release Tool/Test Probe: Pending Pins: 2, 4 Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 D-GN | 286 | Driver Seat Front Vertical Motor Up Control |
| 2 | 0.35 BN/WH | 557 | Front Vertical Seat Motor Position Sensor Signal |
| 3 | | | Not Used |
| 4 | 0.35 OG/WH | 3298 | Reference Voltage |
| 5 | 2 D-BU | 287 | Driver Seat Front Vertical Motor Down Control |
M50D Seat Front Vertical Motor - Driver
M50P Seat Front Vertical Motor - Passenger (AG2)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 10848198 Service Connector: Service by Harness - See Part Catalog Description: 5-Way F MQS/MCP Mixed Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Connector Assembly - 10848198 Core/Insulation Crimp: Not Available Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 D-GN | 297 | Passenger Seat Front Vertical Motor Up Control |
| 2-4 | | | Not Used |
| 5 | 2 D-BU | 298 | Passenger Seat Front Vertical Motor Down Control |
M50P Seat Front Vertical Motor - Passenger (AG2)
M51D Seat Horizontal Motor - Driver
| Connector Part Information Harness Type: Driver Seat OEM Connector: 10848198 Service Connector: Service by Harness - See Part Catalog Description: 5-Way F MQS/MCP Mixed Series (BK) |
|---|
| Terminal Part Information Pins: 1, 5 Terminal/Tray: Service by Connector Assembly - 10848198 Core/Insulation Crimp: Not Available Release Tool/Test Probe: Pending Pins: 2, 4 Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 TN | 285 | Driver Seat Horizontal Motor Forward Control |
| 2 | 0.35 D-GN | 569 | Horizontal Seat Motor Position Sensor Signal |
| 3 | | | Not Used |
| 4 | 0.35 OG/WH | 3298 | Reference Voltage |
| 5 | 2 L-GN | 284 | Driver Seat Horizontal Motor Rearward Control |
M51D Seat Horizontal Motor - Driver
M51P Seat Horizontal Motor - Passenger (AG2)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 10848198 Service Connector: Service by Harness - See Part Catalog Description: 5-Way F MQS/MCP Mixed Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Connector Assembly - 10848198 Core/Insulation Crimp: Not Available Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 L-GN | 290 | Passenger Seat Horizontal Motor Rearward Control |
| 2-4 | | | Not Used |
| 5 | 2 TN | 296 | Passenger Seat Horizontal Motor Forward Control |
M51P Seat Horizontal Motor - Passenger (AG2)
Scheme 375
Scheme 375: M53D Seat Lumbar Support Motor - Driver (AL2)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 12020556 Service Connector: 12101820 Description: 2-Way F Metri-Pack 480 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12124304/2 Core/Insulation Crimp: A/B Release Tool/Test Probe: 12094430/J-35616-40 (BU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 TN | 768 | Driver Seat Lumbar Motor Up Control |
| B | 2 PU | 767 | Driver Seat Lumbar Motor Down Control |
M53D Seat Lumbar Support Motor - Driver (AL2)
M53P Seat Lumbar Support Motor - Passenger (AL2)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 12020556 Service Connector: 12101820 Description: 2-Way F Metri-Pack 480 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12124304/2 Core/Insulation Crimp: A/B Release Tool/Test Probe: 12094430/J-35616-40 (BU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 TN | 768 | Driver Seat Lumbar Motor Up Control |
| B | 2 PU | 767 | Driver Seat Lumbar Motor Down Control |
M53P Seat Lumbar Support Motor - Passenger (AL2)
M55D Seat Rear Vertical Motor - Driver
| Connector Part Information Harness Type: Driver Seat OEM Connector: 10848198 Service Connector: Service by Harness - See Part Catalog Description: 5-Way F MQS/MCP Mixed Series (BK) |
|---|
| Terminal Part Information Pins: 1, 5 Terminal/Tray: Service by Connector Assembly - 10848198 Core/Insulation Crimp: Not Available Release Tool/Test Probe: Pending Pins: 2, 4 Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 L-BU | 283 | Driver Seat Rear Vertical Motor Down Control |
| 2 | 0.35 TN | 568 | Rear Vertical Seat Motor Position Sensor Signal |
| 3 | | | Not Used |
| 4 | 0.35 OG/WH | 3298 | Reference Voltage |
| 5 | 2 YE | 282 | Driver Seat Rear Vertical Motor Up Control |
M55D Seat Rear Vertical Motor - Driver
M55P Seat Rear Vertical Motor - Passenger (AG2)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 10848198 Service Connector: Service by Harness - See Part Catalog Description: 5-Way F MQS/MCP Mixed Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Connector Assembly - 10848198 Core/Insulation Crimp: Not Available Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 L-BU | 289 | Passenger Seat Rear Vertical Motor Down Control |
| 2-4 | | | Not Used |
| 5 | 2 YE | 288 | Passenger Seat Rear Vertical Motor Up Control |
M55P Seat Rear Vertical Motor - Passenger (AG2)
M56D Seat Recline Motor - Driver
| Connector Part Information Harness Type: Driver Seat OEM Connector: 10848198 Service Connector: Service by Harness - See Part Catalog Description: 5-Way F MQS/MCP Mixed Series (BK) |
|---|
| Terminal Part Information Pins: 1, 5 Terminal/Tray: Service by Connector Assembly - 10848198 Core/Insulation Crimp: Not Available Release Tool/Test Probe: Pending Pins: 2, 4 Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 L-BU | 277 | Driver Seat Recline Motor Rearward Control |
| 2 | 0.35 WH/BK | 570 | Driver Seat Recline Motor Position Sensor Signal |
| 3 | | | Not Used |
| 4 | 0.35 OG/WH | 3298 | Reference Voltage |
| 5 | 2 L-GN | 276 | Driver Seat Recline Motor Forward Control |
M56D Seat Recline Motor - Driver
M56P Seat Recline Motor - Passenger (AG2)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 10848198 Service Connector: Service by Harness - See Part Catalog Description: 5-Way F MQS/MCP Mixed Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Connector Assembly - 10848198 Core/Insulation Crimp: Not Available Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 D-BU | 77 | Passenger Seat Recline Motor Rearward |
| 2-4 | | | Not Used |
| 5 | 2 D-GN | 76 | Passenger Seat Recline Motor Forward |
M56P Seat Recline Motor - Passenger (AG2)
Scheme 376
Scheme 376: M64 Starter Motor X1 (LF1)
| Connector Part Information Harness Type: Engine OEM Connector: 12089916 Service Connector: 12101763 Description: 1-Way F Metri-Pack 280 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12077413/4 Core/Insulation Crimp: F/5 Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 PU | 6 | Starter Solenoid Crank Voltage |
M64 Starter Motor X1 (LF1)
Scheme 377
Scheme 377: M72 Variable Power Steering Solenoid Valve
| Connector Part Information Harness Type: Power Steering Jumper OEM Connector: 13530224 Service Connector: Pending Description: 2-Way F Junior Power Timer Series Sealed (BU) |
|---|
| Terminal Part Information Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-36/J-35616-35 (VT) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 YE | 6641 | Variable Effort Steering Solenoid Low Control |
| 2 | 0.8 BN | 1295 | Variable Effort Steering Solenoid High Control |
M72 Variable Power Steering Solenoid Valve
Scheme 378
Scheme 378: M74D Window Motor - Driver
| Connector Part Information Harness Type: Driver Door OEM Connector: 13595813 Service Connector: Service by Harness - See Part Catalog Description: 7-Way F Kaizen 0.64 2.8 Timer Series, Sealed (BK) |
|---|
| Terminal Part Information Pins: 1, 2 Terminal/Tray: 4-964273-1/15 Core/Insulation Crimp: C/5 Release Tool/Test Probe: J-38125-36/J-35616-35 (VT) Pins: 3, 4, 5, 6, 7 Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 3 BK | 750 | Ground |
| 2 | 3 RD/BK | 1842 | Battery Positive Voltage |
| 3 | 0.35 TN/BK | 3379 | Driver Window Switch Up Signal |
| 4 | 0.35 D-GN | 6134 | Local Interconnect Network 3 |
| 5 | 0.35 L-GN | 3381 | Driver Window Express Signal |
| 6 | 0.35 GY/BK | 745 | Left Front Door Ajar Switch Signal |
| 7 | 0.35 GY | 3380 | Driver Window Switch Down Signal |
M74D Window Motor - Driver
Scheme 379
Scheme 379: M74LR Window Motor - Left Rear
| Connector Part Information Harness Type: Left Rear Door OEM Connector: 12129487 Service Connector: 88988609 Description: 2-Way F Metri-Pack 280 Series, Flexlock, Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12110845/4 Core/Insulation Crimp: F/5 Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 D-BU | 668 | Power Window Motor Left Rear Up Control |
| B | 3 BN | 669 | Power Window Motor Left Rear Down Control |
M74LR Window Motor - Left Rear
M74P Window Motor - Passenger
| Connector Part Information Harness Type: Passenger Door OEM Connector: 13595813 Service Connector: Service by Harness - See Part Catalog Description: 7-Way F Kaizen 0.64 2.8 Timer Series, Sealed (BK) |
|---|
| Terminal Part Information Pins: 1, 2 Terminal/Tray: 4-964273-1/15 Core/Insulation Crimp: C/5 Release Tool/Test Probe: J-38125-36/J-35616-35 (VT) Pins: 3, 4, 5, 6, 7 Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 3 BK | 650 | Ground |
| 2 | 3 RD/BK | 4042 | Battery Positive Voltage |
| 3 | 0.35 L-BU | 3384 | Passenger Window Switch Up Signal |
| 4 | 0.35 D-GN | 6134 | Local Interconnect Network 3 |
| 5 | 0.35 PU | 3386 | Passenger Window Express Signal |
| 6 | 0.35 TN/WH | 746 | Right Front Door Ajar Switch Signal |
| 7 | 0.35 TN | 3385 | Passenger Window Switch Down Signal |
M74P Window Motor - Passenger
M74RR Window Motor - Right Rear
| Connector Part Information Harness Type: Right Rear Door OEM Connector: 12129487 Service Connector: 88988609 Description: 2-Way F Metri-Pack 280 Series, Flexlock, Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12110845/4 Core/Insulation Crimp: F/5 Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 D-BU | 670 | Power Window Motor Right Rear Up Control |
| B | 3 BN | 671 | Power Window Motor Right Rear Down Control |
M74RR Window Motor - Right Rear
Scheme 380
Scheme 380: M75 Windshield Wiper Motor
| Connector Part Information Harness Type: Body OEM Connector: 12084891 Service Connector: 15305874 Description: 5-Way F Metri-Pack 280 Series, Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12077411/2 Core/Insulation Crimp: 2/5 Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | | | Not Used |
| B | 0.5 YE | 196 | Windshield Wiper Motor Park Switch Signal |
| C | 1 BK | 1050 | Ground |
| D | 1 PU | 92 | Windshield Wiper Motor High Speed |
| E | 1 D-GN | 95 | Windshield Wiper Motor Low Speed |
M75 Windshield Wiper Motor
Scheme 381
Scheme 381: P4 Security Siren (UA2 or UTC)
| Connector Part Information Harness Type: Body OEM Connector: 10756595 Service Connector: 88953370 Description: 4-Way F Quadlok Micro Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 962885-5/15 Core/Insulation Crimp: 6/6 Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used |
| 2 | 0.35 RD/WH | 4540 | Ignition 1 Voltage |
| 3 | 0.35 D-BU | 6133 | Local Interconnect Network 2 |
| 4 | 0.5 BK | 1050 | Ground |
P4 Security Siren (UA2 or UTC)
Scheme 382
Scheme 382: P9 Driver Information Center Display (UD5)
| Connector Part Information Harness Type: Headliner OEM Connector: 12045813 Service Connector: 12101889 Description: 4-Way F Metri-Pack 150 Series (CR) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 WH | 2370 | Telltale Assembly Supply Voltage |
| B | 0.35 OG | 2371 | Left Amber Indicator Control |
| C | 0.35 D-BU | 2372 | Center Amber Indicator Control |
| D | 0.35 GY | 2373 | Red Indicator Control |
P9 Driver Information Center Display (UD5)
Scheme 383
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 15419715 Service Connector: 88988313 Description: 2-Way F GT 150 Series, Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BK | 150 | Ground |
| B | 0.8 D-GN | 29 | Horn Control |
Scheme 384
Scheme 384: P14 Passenger Air Bag Disable Indicator
| Connector Part Information Harness Type: Overhead Console OEM Connector: 13608102 Service Connector: 19153174 Description: 6-Way F 1.2 HCM Series (NA) |
|---|
| Terminal Part Information Terminal/Tray: SHCM-A03T-P025/20 Core/Insulation Crimp: J/J Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 D-BU | 2307 | Passenger Air Bag On Indicator Control |
| 2 | 0.35 BK | 1350 | Ground |
| 3 | 0.35 D-GN | 2308 | Passenger Air Bag Off Indicator Control |
| 4 | 0.35 PK | 1139 | Ignition Voltage |
| 5 | 0.35 PU | 5234 | Front Passenger Seat Belt Indicator Control |
| 6 | | | Not Used |
P14 Passenger Air Bag Disable Indicator
Scheme 385
Scheme 385: P16 Instrument Cluster
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 15489824 Service Connector: 15126711 Description: 20-Way F 64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 D-GN | 5060 | Low Speed GMLAN Serial Data |
| 2-3 | | | Not Used |
| 4 | 0.35 D-GN/WH | 1358 | DIC Switch Signal |
| 5 | 0.35 BN | 897 | DIC Switch Low Reference |
| 6 | 0.35 YE | 61 | Low Reference |
| 7 | 0.35 D-GN/WH | 636 | Ambient Air Temperature Sensor Signal |
| 8 | | | Not Used |
| 9 | 0.35 YE/BK | 68 | Low Coolant Level Indicator Control (EXP) |
| 10 | 0.5 BK | 1750 | Ground |
| 11-13 | | | Not Used |
| 14 | 0.35 OG | 7594 | Windshield Washer Solvent Heater Switch Indicator Control |
| 15 | 0.35 TN | 185 | Low Washer Fluid Indicator Control |
| 16 | 0.35 PK | 893 | DIC Select Menu Switch Signal |
| 17 | 0.35 BN/WH | 419 | MIL Control |
| 18 | | | Not Used |
| 19 | 0.35 PK | 139 | Ignition 1 Voltage |
| 20 | 0.5 RD/WH | 2840 | Battery Positive Voltage |
Scheme 386
Scheme 386: P17 Info Display Module (UYE, UYI, UYK, or UYZ)
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13518475 Service Connector: 13316159 Description: 8-Way F YESC Kaizen Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 RD/WH | 3240 | Battery Positive Voltage |
| 2 | 0.35 BK/WH | 1751 | Ground |
| 3 | 0.35 L-BU | 7532 | Local Interconnect Network 10 |
| 4 | 0.35 L-GN | 3291 | Center Stack Wake - Up Signal |
| 5 | 0.35 PK | 3290 | Center Stack Reset Signal |
| 6 | 0.35 NONE | 7460 | Drain Wire |
| 7 | 0.35 TN | 7458 | CGI (+) |
| 8 | 0.35 YE | 7459 | CGI (-) |
P17 Info Display Module (UYE, UYI, UYK, or UYZ)
P17 Info Display Module X1
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13518475 Service Connector: 13576542 Description: 8-Way F YESC Kaizen Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 RD/WH | 3240 | Battery Positive Voltage |
| 2 | 0.35 BK/WH | 1751 | Ground |
| 3 | 0.35 L-GN | 3364 | Reset |
| 4 | 0.35 WH | 7066 | Remote Enable |
| 5 | | | Not Used |
| 6 | 0.35 BARE | 3368 | Drain Wire |
| 7 | 0.35 PK | 3369 | Navigation Display Touch + |
| 8 | 0.35 PU | 3370 | Navigation Display Touch |
P17 Info Display Module X1
Scheme 387
Scheme 387: P17 Info Display Module X2
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13551679 Service Connector: 19115653 Description: 8-Way F Kaizen 64 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 RD/WH | 3240 | Battery Positive Voltage |
| 2 | 0.35 BK | 1750 | Ground |
| 3 | 0.35 WH | 7066 | Remote Enable |
| 4 | 0.35 PU/WH | 3361 | Display Pop-Up Control Signal |
| 5 | 0.35 WH | 3362 | Display Position Signal |
| 6-8 | | | Not Used |
P17 Info Display Module X2
Scheme 388
Scheme 388: P19AC Speaker - Subwoofer
| Connector Part Information Harness Type: Body OEM Connector: 12129136 Service Connector: 12129136 Description: 4-Way F Metri-Pack 280 Series, Flexlock (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12110842/4 Core/Insulation Crimp: A/B Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 D-BU/WH | 346 | Left Subwoofer Speaker Output (+) |
| B | 2 L-GN/BK | 1794 | Left Subwoofer Speaker Output (-) |
| C-D | | | Not Used |
P19AC Speaker - Subwoofer
Scheme 389
Scheme 389: P19B Speaker - Center Instrument Panel
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13608099 Service Connector: 13314097 Description: 2-Way F 1.5 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 8240-0128/22 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 L-BU | 1960 | Front Center Speaker Output (-) |
| 2 | 0.8 YE | 1860 | Front Center Speaker Output (+) |
P19B Speaker - Center Instrument Panel
Scheme 390
Scheme 390: P19F Speaker - Left Rear Cargo Door
| Connector Part Information Harness Type: Liftgate Extension OEM Connector: 12064869 Service Connector: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 WH | 1959 | Left Rear Midrange Speaker Output (-) |
| B | 0.8 TN | 1859 | Left Rear Midrange Speaker Output (+) |
P19F Speaker - Left Rear Cargo Door
Scheme 391
Scheme 391: P19G Speaker - Left Front (UQ3)
| Connector Part Information Harness Type: Driver Door OEM Connector: 13665500 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 GY | 118 | Left Front Speaker Output (-) |
| 2 | 0.8 TN | 201 | Left Front Speaker Output (+) |
P19G Speaker - Left Front (UQ3)
Scheme 392
Scheme 392: P19G Speaker - Left Front (UQA or UQS)
| Connector Part Information Harness Type: Driver Door OEM Connector: 13649632 Service Connector: 13504282 Description: 2-Way F GT 150 Series (L-GY) |
|---|
| Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 GY | 118 | Left Front Speaker Output (-) |
| 2 | 0.8 TN | 201 | Left Front Speaker Output (+) |
P19G Speaker - Left Front (UQA or UQS)
Scheme 393
Scheme 393: P19H Speaker - Left Front Tweeter
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13595633 Service Connector: See Catalog Description: 2-Way F Kaizen 64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 GY | 118 | Left Front Speaker Output (-) |
| 2 | 0.5 TN | 201 | Left Front Speaker Output (+) |
P19H Speaker - Left Front Tweeter
P19K Speaker - Left Rear
| Connector Part Information Harness Type: Left Rear Door OEM Connector: 12064869 Service Connector: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 WH | 1959 | Left Rear Midrange Speaker Output (-) |
| B | 0.8 TN | 1859 | Left Rear Midrange Speaker Output (+) |
P19K Speaker - Left Rear (UQ3)
| Connector Part Information Harness Type: Left Rear Door OEM Connector: 13665500 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 YE | 116 | Left Rear Speaker Output (-) |
| 2 | 0.8 BN | 199 | Left Rear Speaker Output (+) |
P19K Speaker - Left Rear (UQ3)
P19K Speaker - Left Rear (UQS)
| Connector Part Information Harness Type: Left Rear Door OEM Connector: 13649632 Service Connector: 13504282 Description: 2-Way F GT 150 Series (L-GY) |
|---|
| Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 YE | 116 | Left Rear Speaker Output (-) |
| 2 | 0.8 BN | 199 | Left Rear Speaker Output (+) |
P19K Speaker - Left Rear (UQS)
P19T Speaker - Right Rear Cargo Door
| Connector Part Information Harness Type: Liftgate Extension OEM Connector: 12064869 Service Connector: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 OG | 1955 | Right Rear Midrange Speaker Output (-) |
| B | 0.8 TN | 1855 | Right Rear Midrange Speaker Output (+) |
P19T Speaker - Right Rear Cargo Door
P19U Speaker - Right Front (UQ3)
| Connector Part Information Harness Type: Passenger Door OEM Connector: 13665500 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 D-GN | 117 | Right Front Speaker Output (-) |
| 2 | 0.8 L-GN | 200 | Right Front Speaker Output (+) |
P19U Speaker - Right Front (UQ3)
P19U Speaker - Right Front (UQA or UQS)
| Connector Part Information Harness Type: Passenger Door OEM Connector: 13649632 Service Connector: 13504282 Description: 2-Way F GT 150 Series (L-GY) |
|---|
| Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 D-GN | 117 | Right Front Speaker Output (-) |
| 2 | 0.8 L-GN | 200 | Right Front Speaker Output (+) |
P19U Speaker - Right Front (UQA or UQS)
P19V Speaker - Right Front Tweeter
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13595633 Service Connector: See Catalog Description: 2-Way F Kaizen 64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 D-GN | 117 | Right Front Speaker Output (-) |
| 2 | 0.5 L-GN | 200 | Right Front Speaker Output (+) |
P19V Speaker - Right Front Tweeter
P19X Speaker - Right Rear
| Connector Part Information Harness Type: Right Rear Door OEM Connector: 12064869 Service Connector: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 OG | 1955 | Right Rear Midrange Speaker Output (-) |
| B | 0.8 TN | 1855 | Right Rear Midrange Speaker Output (+) |
P19X Speaker - Right Rear
P19X Speaker - Right Rear (UQ3)
| Connector Part Information Harness Type: Right Rear Door OEM Connector: 13665500 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 L-BU | 115 | Right Rear Speaker Output (-) |
| 2 | 0.8 D-BU | 46 | Right Rear Speaker Output (+) |
P19X Speaker - Right Rear (UQ3)
P19X Speaker - Right Rear (UQS)
| Connector Part Information Harness Type: Right Rear Door OEM Connector: 13649632 Service Connector: 13504282 Description: 2-Way F GT 150 Series (L-GY) |
|---|
| Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 L-BU | 115 | Right Rear Speaker Output (-) |
| 2 | 0.8 D-BU | 46 | Right Rear Speaker Output (+) |
P19X Speaker - Right Rear (UQS)
Scheme 394
Scheme 394: P22D Video Display - Driver Seat Headrest (UWG)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 15491285 Service Connector: 15136073 Description: 16-Way F Kaizen 64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 RD/WH | 4840 | Battery Positive Voltage |
| 2 | 0.35 WH | 7066 | Remote Enable |
| 3 | 0.35 OG/BK | 5329 | Left Rear Low Level Audio Signal (+) |
| 4 | 0.35 PU/WH | 5330 | Right Infrared Audio Signal |
| 5 | 0.35 PU | 6979 | DVD Audio Common |
| 6 | 0.35 L-BU | 5826 | Left DVD Audio Signal (+) |
| 7 | 0.35 WH | 5828 | Right DVD Audio Signal (+) |
| 8 | 0.5 BK/WH | 1551 | Ground |
| 9 | 0.35 D-GN | 6975 | DVD Video Signal (+) |
| 10 | 0.35 WH/BK | 5335 | DVD Video Signal (-) |
| 11 | 0.35 D-BU/WH | 3360 | Rear Seat Audio |
| 12 | 0.35 OG/BK | 5831 | Remote Infrared Signal (+) |
| 13 | 0.35 TN/WH | 5830 | Right Infrared Audio Signal |
| 14 | 0.35 BK/WH | 1551 | Ground |
| 15 | 0.35 L-GN/BK | 5845 | Video Module Signal |
| 16 | 0.35 PK/BK | 5844 | Video Bright Signal |
P22D Video Display - Driver Seat Headrest (UWG)
P22P Video Display - Passenger Seat Headrest (UWG)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 15491285 Service Connector: 15136073 Description: 16-Way F Kaizen 64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 RD/WH | 4840 | Battery Positive Voltage |
| 2 | 0.35 WH | 7066 | Remote Enable |
| 3-7 | | | Not Used |
| 8 | 0.5 BK/WH | 1551 | Ground |
| 9 | 0.35 L-GN | 7396 | DVD Video Signal 2 (+) (DNU) |
| 10 | 0.35 WH | 7394 | DVD Video Signal 2 (-) |
| 11 | | | Not Used |
| 12 | 0.35 OG/BK | 5831 | Remote Infrared Signal (+) |
| 13 | 0.35 TN/WH | 5830 | Right Infrared Audio Signal |
| 14 | 0.35 BK/WH | 1551 | Ground |
| 15 | 0.35 D-GN/WH | 7395 | Video Mode 2 Signal |
| 16 | 0.35 PK/BK | 5844 | Video Bright Signal |
P22P Video Display - Passenger Seat Headrest (UWG)
Scheme 395
Scheme 395: Q6A Camshaft Position Actuator Solenoid Valve - Bank 1 Exhaust
| Connector Part Information Harness Type: Engine OEM Connector: 15411401 Service Connector: 88988588 Description: 2-Way F Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4025/11 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15313892/J-35616-18 (BK) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 L-GN | 5282 | CMP Actuator Solenoid Control - Exhaust Bank 1 (LF1) |
| 0.5 PK/BK | 5293 | Ignition Voltage (LAU) |
| 2 | 0.5 BN/WH | 6754 | Low Reference (LF1) |
| 0.5 L-GN | 5282 | CMP Actuator Solenoid Control - Exhaust Bank 1 (LAU) |
Q6A Camshaft Position Actuator Solenoid Valve - Bank 1 Exhaust
Q6B Camshaft Position Actuator Solenoid Valve - Bank 1 Intake
| Connector Part Information Harness Type: Engine OEM Connector: 15411401 Service Connector: 88988588 Description: 2-Way F Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4025/11 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15313892/J-35616-18 (BK) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 PU | 5284 | CMP Actuator Solenoid Control - Intake Bank 1 (LF1) |
| 0.5 PK/BK | 5293 | Ignition Voltage (LAU) |
| 2 | 0.5 BN | 6753 | Low Reference (LF1) |
| 0.5 PU | 5284 | CMP Actuator Solenoid Control - Intake Bank 1 (LAU) |
Q6B Camshaft Position Actuator Solenoid Valve - Bank 1 Intake
Q6C Camshaft Position Actuator Solenoid Valve - Bank 2 Exhaust
| Connector Part Information Harness Type: Engine OEM Connector: 15411401 Service Connector: 88988588 Description: 2-Way F Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4025/11 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15313892/J-35616-18 (BK) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 WH/BK | 5283 | CMP Actuator Solenoid Control - Exhaust Bank 2 (LF1) |
| 0.5 PK/BK | 5293 | Ignition Voltage (LAU) |
| 2 | 0.5 D-BU/WH | 6756 | Low Reference (LF1) |
| 0.5 WH/BK | 5283 | CMP Actuator Solenoid Control - Exhaust Bank 2 (LAU) |
Q6C Camshaft Position Actuator Solenoid Valve - Bank 2 Exhaust
Q6D Camshaft Position Actuator Solenoid Valve - Bank 2 Intake
| Connector Part Information Harness Type: Engine OEM Connector: 15411401 Service Connector: 88988588 Description: 2-Way F Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4025/11 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15313892/J-35616-18 (BK) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 OG/BK | 5272 | CMP Actuator Solenoid Control - Intake Bank 2 (LF1) |
| 0.5 PK/BK | 5293 | Ignition Voltage (LAU) |
| 2 | 0.5 D-BU | 6755 | Low Reference (LF1) |
| 0.5 OG/BK | 5272 | CMP Actuator Solenoid Control - Intake Bank 2 (LAU) |
Q6D Camshaft Position Actuator Solenoid Valve - Bank 2 Intake
Scheme 396
Scheme 396: Q8 Control Solenoid Valve Assembly X1 (MH2 or MH4)
| Connector Part Information Harness Type: Engine OEM Connector: 13570698 Service Connector: 19151494 Description: 20-Way F GT 150 Series, Sealed (D-BU w/BK Case) |
|---|
| Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: Pins 1, 10, 13, 18 - E/1 Core/Insulation Crimp: Pins 2, 5, 12, 14, 15, 20 - E/4 Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 BK/WH | 451 | Ground |
| 2 | 0.5 TN/BK | 2500 | High Speed GMLAN Serial Data Bus+ |
| 3-4 | | | Not Used |
| 5 | 0.5 TN/BK | 2500 | High Speed GMLAN Serial Data Bus+ |
| 6-9 | | | Not Used |
| 10 | 0.8 RD/WH | 1840 | Battery Positive Voltage |
| 11 | | | Not Used |
| 12 | 0.5 TN | 2501 | High Speed GMLAN Serial Data Bus |
| 13 | 0.8 PK | 2139 | Ignition Voltage |
| 14 | 0.5 TN | 2501 | High Speed GMLAN Serial Data Bus |
| 15 | 0.5 D-BU | 5985 | Serial Data Wake - Up Signal |
| 16-17 | | | Not Used |
| 18 | 0.8 BK/WH | 451 | Ground |
| 19 | | | Not Used |
| 20 | 0.5 OG/BK | 1786 | Park/Neutral Signal |
Q8 Control Solenoid Valve Assembly (MH2 or MH4)
Scheme 397
Scheme 397: Q8 Control Solenoid Valve Assembly X2 (MH2 or MH4)
| Connector Part Information Harness: Automatic Transmission OEM: 15336500 Service: Non-Serviceable Description: 6-Way F Metri-Pack 150.2 Series (GN) |
|---|
| Terminal Part Information Terminated Lead: Non-Serviceable Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Non-Serviceable Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 GY | | Low Reference |
| B | 0.5 BK | | Transmission Range Switch Signal P |
| C | 0.5 YE | | Transmission Range Switch Signal C |
| D | 0.5 RD | | Transmission Range Switch Signal B |
| E | 0.5 D-GN | | Transmission Range Switch Signal A |
| F | 0.5 WH | | Park/Neutral Switch Signal |
Q8 Control Solenoid Valve Assembly X2 (MH2 or MH4)
Scheme 398
Scheme 398: Q8 Control Solenoid Valve Assembly X3 (MH2 or MH4)
| Connector Part Information Harness: Automatic Transmission OEM: 15467085 Service: Non-Serviceable Description: 2-Way F Metri-Pack 150.2 Series (L-GY) |
|---|
| Terminal Part Information Terminated Lead: Non-Serviceable Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Non-Serviceable Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 WH | | ISS High Signal |
| B | 0.5 BK | | ISS Low Signal |
Q8 Control Solenoid Valve Assembly X3 (MH2 or MH4)
