Scheme 399
Scheme 399: Q8 Control Solenoid Valve Assembly X4 (MH2 or MH4)
| Connector Part Information Harness: Automatic Transmission OEM: 15467085 Service: Non-Serviceable Description: 2-Way F Metri-Pack 150.2 Series (L-GY) |
|---|
| Terminal Part Information Terminated Lead: Non-Serviceable Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Non-Serviceable Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 WH | | OSS High Signal |
| B | 0.5 BK | | OSS Low Signal |
Q8 Control Solenoid Valve Assembly X4 (MH2 or MH4)
Scheme 400
Scheme 400: Q12 Evaporative Emission Purge Solenoid Valve
| Connector Part Information Harness Type: Engine OEM Connector: 10740370 Service Connector: 88988586 Description: 2-Way F 2.8 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-561/J-35616-35 (VT) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 PK/BK | 5293 | Ignition Voltage |
| 2 | 0.5 D-GN/WH | 428 | EVAP Canister Purge Solenoid Control |
Q12 Evaporative Emission Purge Solenoid Valve
Scheme 401
Scheme 401: Q13 Evaporative Emission Vent Solenoid Valve
| Connector Part Information Harness Type: Fuel Tank Jumper OEM Connector: 12052643 Service Connector: 12101858 Description: 2-Way F Metri-Pack 150 Series, Sealed (RD) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 WH | 1310 | EVAP Canister Vent Solenoid Control |
| B | 0.5 RD/WH | 2440 | Battery Positive Voltage |
Q13 Evaporative Emission Vent Solenoid Valve
Scheme 402
Scheme 402: Q37LF Shock Absorber Actuator - Left Front
| Connector Part Information Harness Type: Left Front Wheel Speed Sensor Jumper OEM Connector: 13510085 Service Connector: 19179278 Description: 2-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 L-BU/WH | 1107 | Left Front Damper Control |
| B | 0.8 GY | 1113 | Left Front Damper Low Reference |
Q37LF Shock Absorber Actuator - Left Front
Scheme 403
Scheme 403: Q37LR Shock Absorber Actuator - Left Rear
| Connector Part Information Harness Type: Chassis OEM Connector: 15326806 Service Connector: 19151499 Description: 2-Way M GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4 Release Tool/Test Probe: 15315247/J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 D-BU/WH | 1114 | Left Rear Damper Control |
| B | 0.5 D-GN | 1115 | Left Rear Damper Low Reference |
Q37LR Shock Absorber Actuator - Left Rear
Q37RF Shock Absorber Actuator - Right Front
| Connector Part Information Harness Type: Right Front Wheel Speed Sensor Jumper OEM Connector: 13510085 Service Connector: 19179278 Description: 2-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 L-BU/WH | 1116 | Right Front Damper Control |
| B | 0.8 GY | 1117 | Right Front Damper Low Reference |
Q37RF Shock Absorber Actuator - Right Front
Q37RR Shock Absorber Actuator - Right Rear
| Connector Part Information Harness Type: Chassis OEM Connector: 15326806 Service Connector: 19151499 Description: 2-Way M GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4 Release Tool/Test Probe: 15315247/J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 D-BU/WH | 1118 | Right Rear Damper Control |
| B | 0.5 D-GN | 1119 | Right Rear Damper Low Reference |
Q37RR Shock Absorber Actuator - Right Rear
Scheme 404
Scheme 404: Q38 Throttle Body
| Connector Part Information Harness Type: Engine OEM Connector: 15355297 Service Connector: 13504128 Description: 6-Way F GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15326427/5 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 BN | 582 | TAC Motor Control - 2 (LF1) |
| 0.5 GY | 561 | Throttle Motor - (LAU) |
| B | 0.5 YE | 581 | TAC Motor Control - 1 (LF1) |
| 0.5 WH | 560 | Throttle Motor + (LAU) |
| C | 0.5 TN | 2752 | Low Reference |
| D | 0.5 D-GN | 485 | TP Sensor 1 Signal |
| E | 0.5 GY | 2701 | 5-Volt Reference (LF1) |
| 0.5 GY | 416 | 5-Volt Reference (LAU) |
| F | 0.5 PU | 486 | TP Sensor 2 Signal |
Scheme 405
Scheme 405: Q40 Turbocharger Bypass Solenoid Valve
| Connector Part Information Harness Type: Engine OEM Connector: 12186308 Service Connector: 89046837 Description: 2-Way F Junior Power Timer Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-36/J-35616-35 (VT) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 PK/BK | 5293 | Ignition Voltage |
| 2 | 0.5 WH | 5268 | Air Pressure Sensor Signal |
Q40 Turbocharger Bypass Solenoid Valve
Scheme 406
Scheme 406: Q42 Turbocharger Wastegate Solenoid Valve
| Connector Part Information Harness Type: Engine OEM Connector: 15404492 Service Connector: 13574942 Description: 2-Way F 2.8 Junior Power Timer Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-36/J-35616-35 (VT) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 PK/BK | 5293 | Ignition Voltage |
| 2 | 0.5 YE | 258 | Wastegate Solenoid Control |
Q42 Turbocharger Wastegate Solenoid Valve
R6 Data Link Resistor
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 15326801 Service Connector: 19179278 Description: 2-Way F Ducon 6.3 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 BN/WH | 5169 | Mid Speed GMLAN Serial Data Bus+ |
| B | 0.35 BN | 5170 | Mid Speed GMLAN Serial Data Bus |
Scheme 407
Scheme 407: R10L Cooling Fan Resistor - Left (LF1)
| Connector Part Information Harness Type: Engine OEM Connector: 13662304 Service Connector: 19179378 Description: 2-Way F 375 58Y Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-3250/10 Core/Insulation Crimp: G/3 Release Tool/Test Probe: 12094430/J-35616-22 (RD) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 5 YE | 5358 | Auxiliary Cooling Fan Motor Supply Voltage |
| 2 | 5 L-BU | 409 | Cooling Fan Motor Supply Voltage |
R10L Cooling Fan Resistor - Left (LF1)
R10R Cooling Fan Resistor - Right (LF1)
| Connector Part Information Harness Type: Engine OEM Connector: 13662304 Service Connector: 19179378 Description: 2-Way F 375 58Y Series Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-3250/10 Core/Insulation Crimp: G/3 Release Tool/Test Probe: 12094430/J-35616-22 (RD) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 5 GY | 532 | Cooling Fan Motor Supply Voltage |
| 2 | 5 L-BU | 409 | Cooling Fan Motor Supply Voltage |
R10R Cooling Fan Resistor - Right (LF1)
Scheme 408
Scheme 408: S1 Adjustable Pedal Control Switch
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13595476 Service Connector: 19167753 Description: 6-Way F Kaizen 64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 BK | 1750 | Ground |
| 2 | | | Not Used |
| 3 | 0.35 PU | 5286 | Adjustable Pedals Forward Switch Signal |
| 4 | | | Not Used |
| 5 | 0.35 OG/BK | 5285 | Adjustable Pedals Rearward Switch Signal |
| 6 | | | Not Used |
S1 Adjustable Pedal Control Switch
S3 Transmission Shift Lever
| Connector Part Information Harness Type: Floor Console OEM Connector: 13595476 Service Connector: Pending Description: 6-Way F AIT II Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 D-BU | 5985 | Accessory Wakeup Serial Data |
| 2 | 0.35 BK | 1650 | Ground |
| 3 | 0.35 PU | 5526 | Tap Up/Tap Down Switch Signal |
| 4 | 0.35 TN | 7553 | Park Lock Solenoid Control |
| 5 | 0.35 YE | 7554 | Park Lock Solenoid Soft Control |
| 6 | 0.35 PU/WH | 5905 | Park Switch Signal |
S3 Transmission Shift Lever
Scheme 409
Scheme 409: S12 Dome Lamp Switch
| Connector Part Information Harness Type: Overhead Console OEM Connector: 13541539 Service Connector: 19179273 Description: 4-Way F AIT II Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 BK | 1350 | Ground |
| 2 | 0.35 PU | 328 | Interior Lamp Defeat Switch Signal |
| 3 | 0.35 WH | 156 | Courtesy Lamp Switch Signal |
| 4 | 0.35 YE | 6817 | LED Backlight Dimming Control |
Scheme 410
Scheme 410: S25 Garage Door Opener
| Connector Part Information Harness Type: Overhead Console OEM Connector: 12162335 Service Connector: 13505907 Description: 3-Way F P/C Series (NA) |
|---|
| Terminal Part Information Terminated Lead: Service by Connector Assembly - 12162335 Release Tool: Not Available Diagnostic Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 RD/WH | 3940 | Fuse Output Battery Type 3 Fuse |
| 2 | 0.35 YE | 6817 | LED Backlight Dimming Control |
| 3 | 0.35 BK | 1350 | Ground |
Scheme 411
Scheme 411: S30 Headlamp Switch
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 10890121 Service Connector: 13316200 Description: 12-Way F 0.64 Micro Quadlok Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 YE | 7556 | Headlamp Switch Reference Voltage |
| 2 | | | Not Used |
| 3 | 0.35 L-BU | 13 | Headlamp Switch Park Lamps Signal |
| 4 | 0.35 WH | 103 | Headlamp Switch Headlamps On Signal |
| 5 | 0.35 D-GN | 306 | Headlamp Switch Headlamps Off Signal/Automatic Headlamp Low Control |
| 6 | 0.35 BK | 1750 | Ground |
| 7 | 0.35 YE | 6817 | LED Backlight Dimming Control |
| 8 | | | Not Used |
| 9 | 0.35 PK | 3039 | Ignition Voltage (T84) |
| 10 | 0.35 D-GN | 189 | Headlamp Leveling Motor Supply Voltage (T84) |
| 11 | | | Not Used |
| 12 | 0.35 D-GN | 7555 | Headlamp Switch Signal |
Scheme 412
Scheme 412: S38 Ignition Mode Switch
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 10890122 Service Connector: 13316160 Description: 8-Way F 0.64 Series (BN) |
|---|
| Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used |
| 2 | 0.35 L-GN | 5720 | ACC Indicator Control |
| 3 | 0.35 L-GN/BK | 3558 | Ignition Switch Run Signal |
| 4 | 0.35 BK/WH | 1751 | Ground |
| 5 | 0.35 D-BU | 5719 | Start Indicator Control |
| 6 | 0.35 L-GN/WH | 5723 | BCM Ignition Mode Data Signal |
| 7 | 0.35 GY/BK | 3559 | Low Reference |
| 8 | 0.35 YE | 6817 | LED Backlight Dimming Control |
Scheme 413
Scheme 413: S40 Passenger Air Bag Disable Switch (C99)
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 10768790 Service Connector: 13316145 Description: 4-Way F 0.64 Micro Quadlok Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 TN/BK | 371 | I/P Module Disable Switch - Signal |
| 2 | | | Not Used |
| 3 | 0.35 BN/L-BU | 7328 | Low Reference |
| 4 | | | Not Used |
S40 Passenger Air Bag Disable Switch (C99)
Scheme 414
Scheme 414: S43 Ultrasonic Intrusion Sensor Disable Switch
| Connector Part Information Harness Type: Overhead Console OEM Connector: 10866875 Service Connector: Service by Harness - See Part Catalog Description: 4-Way F 0.64 Micro Quadlok Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 PK | 5068 | Intrusion Sensor Switch Disable Signal |
| 2 | 0.35 BK | 1350 | Ground |
| 3 | 0.35 YE | 6817 | LED Backlight Dimming Control |
| 4 | 0.35 L-BU | 3278 | Theft Deterrent Status |
S43 Ultrasonic Intrusion Sensor Disable Switch
S45B Liftgate Control Switch - Interior
| Connector Part Information Harness Type: Liftgate OEM Connector: 10768790 Service Connector: 13576535 Description: 4-Way F 0.64 Micro Quadlok Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 BK | 750 | Ground |
| 2 | 0.35 YE | 6817 | LED Backlight Dimming Control |
| 0.35 YE | 6817 | LED Backlight Dimming Control |
| 3 | 0.35 D-GN | 6112 | Liftgate On/Off Switch Signal |
| 4 | 0.35 GY/BK | 6113 | Rear Liftgate Open/Close Switch Signal |
S45B Liftgate Control Switch - Interior
Scheme 415
Scheme 415: S45B Liftgate Control Switch - Interior (TB5)
| Connector Part Information Harness Type: Liftgate OEM Connector: 10756595 Service Connector: 88953370 Description: 4-Way F Quadlok Micro Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 962885-5/15 Core/Insulation Crimp: 6/6 Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 BK | 1350 | Ground |
| 2 | 0.35 GY/WH | 3034 | Backlight Lamp Control |
| 3 | 0.35 D-GN | 3033 | Liftgate Close Signal |
| 4 | 0.35 PU/WH | 5801 | Low Reference |
S45B Liftgate Control Switch - Interior (TB5)
Scheme 416
Scheme 416: S47D Seat Memory Switch - Driver (AAB or AUN)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 10768368 Service Connector: 88988105 Description: 6-Way F Micro Quadlok Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: J/J Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 D-BU/WH | 5978 | Low Reference |
| 2-4 | | | Not Used |
| 5 | 0.5 OG | 614 | Memory Set Switch Signal |
| 6 | 0.5 WH | 615 | Memory 1 Switch Signal |
S47D Seat Memory Switch - Driver (AAB or AUN)
Scheme 417
Scheme 417: S48E Multi-Function Switch - Center Console
| Connector Part Information Harness Type: Floor Console OEM Connector: 15491259 Service Connector: 15127042 Description: 10-Way F 0.64 YESC Kaizen Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 YE | 6817 | LED Backlight Dimming Control |
| 2 | 0.35 BK | 1650 | Ground |
| 3 | 0.35 PU/WH | 6816 | LED Dimming Signal (UD5) |
| 4 | | | Not Used |
| 5 | 0.35 GY | 2555 | Rear Park Assist Disable Signal (UD5) |
| 6 | 0.35 BN | 5852 | Rear Park Assist LED Disable Signal (UD5) |
| 7 | 0.35 L-BU | 1788 | Traction Control Switch Signal |
| 8 | | | Not Used |
| 9 | 0.5 GY | 2093 | 5-Volt Reference 1 |
| 10 | 0.5 PK/WH | 2092 | Fuel Economy Mode Switch Signal |
S48E Multi-Function Switch - Center Console
Scheme 418
Scheme 418: S52 Outside Rearview Mirror Switch
| Connector Part Information Harness Type: Driver Door Trim OEM Connector: 13587624 Service Connector: 19151154 Description: 12-Way F 64 Series, Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1-4 | | | Not Used |
| 5 | 0.35 L-GN/WH | 3404 | Outside Rearview Mirror Left/Right Switch Signal |
| 6 | 0.35 PU/WH | 1382 | LED Dimming Signal/LED Dimming Supply |
| 7-10 | | | Not Used |
| 11 | 0.5 BN | 5478 | Mirror Switch Low Reference |
| 12 | 0.35 PK/WH | 3405 | Outside Rearview Mirror Up/Down Switch Signal |
S52 Outside Rearview Mirror Switch
Scheme 419
Scheme 419: S64D Seat Adjuster Switch - Driver
| Connector Part Information Harness Type: Driver Seat OEM Connector: 15326931 Service Connector: 15306309 Description: 10-Way F GT 280 Series (BK) |
|---|
| Terminal Part Information Without AUN or AAB Terminal/Tray: 15304713/19 Core/Insulation Crimp: 4/4 Release Tool/Test Probe: 15315247/J-35616-4A (PU) With AUN or AAB Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 D-GN | 286 | Driver Seat Front Vertical Motor Up Control (without AUN or AAB) |
| 0.5 D-GN | 1518 | Power Seat Front Vertical Up Switch Signal (with AUN or AAB) |
| B | 2 BK | 750 | Ground (without AUN or AAB) |
| C | 2 L-GN | 284 | Driver Seat Horizontal Motor Rearward Control (without AUN or AAB) |
| 0.5 L-GN | 1523 | Power Seat Horizontal Rearward Switch Signal (with AUN or AAB) |
| D | 2 TN | 285 | Driver Seat Horizontal Motor Forward Control (without AUN or AAB) |
| 0.5 TN | 1522 | Power Seat Horizontal Forward Switch Signal (with AUN or AAB) |
| E | 2 RD/WH | 5040 | Battery Positive Voltage (without AUN or AAB) |
| 0.35 BK | 750 | Ground (with AUN or AAB) |
| F | 2 YE | 282 | Driver Seat Rear Vertical Motor Up Control (without AUN or AAB) |
| 0.5 YE | 1519 | Power Seat Rear Vertical Up Switch Signal (with AUN or AAB) |
| G | 2 L-BU | 277 | Driver Seat Recline Motor Rearward Control (without AUN or AAB) |
| 0.5 D-GN/WH | 1270 | Power Seat Recline Rearward Switch Signal (with AUN or AAB) |
| H | 2 L-GN | 276 | Driver Seat Recline Motor Forward Control (without AUN or AAB) |
| 0.5 GY/BK | 1269 | Power Seat Recline Forward Switch Signal (with AUN or AAB) |
| J | 2 L-BU | 283 | Driver Seat Rear Vertical Motor Down Control (without AUN or AAB) |
| 0.5 L-BU | 1521 | Power Seat Rear Vertical Down Switch Signal (with AUN or AAB) |
| K | 2 D-BU | 287 | Driver Seat Front Vertical Motor Down Control (without AUN or AAB) |
| 0.5 D-BU | 1520 | Power Seat Front Vertical Down Switch Signal (with AUN or AAB) |
S64D Seat Adjuster Switch - Driver
Scheme 420
Scheme 420: S65D Seat Lumbar Support Switch - Driver (AL2)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 12041429 Service Connector: 12167129 Description: 5-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12015858/4 Core/Insulation Crimp: F/G Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 BK | 750 | Ground |
| B | 2 PU | 767 | Driver Seat Lumbar Motor Down Control |
| C | 2 BK | 750 | Ground |
| D | 2 RD/WH | 5040 | Battery Positive Voltage |
| E | 2 TN | 768 | Driver Seat Lumbar Motor Up Control |
S65D Seat Lumbar Support Switch - Driver (AL2)
S65P Seat Lumbar Support Switch - Passenger (AL2)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 12041429 Service Connector: 12167129 Description: 5-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12015858/4 Core/Insulation Crimp: F/G Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 BK | 650 | Ground |
| B | 2 PU | 767 | Driver Seat Lumbar Motor Down Control |
| C | 2 BK | 650 | Ground |
| D | 2 RD/WH | 1440 | Battery Positive Voltage |
| E | 2 TN | 768 | Driver Seat Lumbar Motor Up Control |
S65P Seat Lumbar Support Switch - Passenger (AL2)
S72 Sunroof Switch
| Connector Part Information Harness Type: Overhead Console OEM Connector: 10768790 Service Connector: 13576535 Description: 4-Way F 0.64 Micro Quadlok Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 D-BU | 128 | Sunroof Switch Low Reference |
| 2 | 0.35 YE | 6817 | LED Backlight Dimming Control |
| 3 | 0.35 BK | 1350 | Ground |
| 4 | 0.35 L-BU | 5027 | Sunroof Switch Data 1 |
Scheme 421
Scheme 421: S78 Turn Signal/Multi-Function Switch
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13604008 Service Connector: 13576635 Description: 12-Way F 0.64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SNAC3-A021T-M0.64/20 Core/Insulation Crimp: J/J Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 D-GN | 663 | Hazard Switch Left Turn Signal |
| 2 | 0.35 PU | 524 | Headlamp Dimmer Switch High Beam Signal |
| 3 | 0.35 BK | 1750 | Ground |
| 4 | 0.35 YE | 307 | Headlamp Switch Flash to Pass Signal |
| 5 | 0.35 PK | 893 | DIC Select Menu Switch Signal |
| 6 | 0.35 BN | 897 | DIC Switch Low Reference |
| 7 | 0.35 TN | 664 | Hazard Switch Turn Right Signal |
| 8-11 | | | Not Used |
| 12 | 0.35 D-GN/WH | 1358 | DIC Switch Signal |
S78 Turn Signal/Multi-Function Switch
Scheme 422
Scheme 422: S79D Window Switch - Driver
| Connector Part Information Harness Type: Driver Door Trim OEM Connector: 13551679 Service Connector: 19115653 Description: 8-Way F Kaizen 64 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: Pins 1 - Pending Core/Insulation Crimp: Pins 2-8 - P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 BK | 750 | Ground |
| 2 | 0.35 D-GN | 3381 | Driver Window Express Signal |
| 3 | 0.35 GY | 3380 | Driver Window Switch Down Signal |
| 4 | 0.5 RD/WH | 1940 | Battery Positive Voltage |
| 5 | 0.35 D-GN | 6134 | Local Interconnect Network 3 |
| 6 | 0.35 TN/BK | 3379 | Driver Window Switch Up Signal |
| 7 | 0.35 D-GN | 3270 | Driver Door Lock Status Signal |
| 8 | 0.35 PU | 1124 | Door Lock Key Switch Unlock Signal |
S79D Window Switch - Driver
Scheme 423
Scheme 423: S79LR Window Switch - Left Rear
| Connector Part Information Harness Type: Left Rear Door OEM Connector: 15491286 Service Connector: 88988652 Description: 8-Way F 2.8 Series (BK) |
|---|
| Terminal Part Information Pins: 1-3 Terminal/Tray: 8100-4443/22 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-35 (VT) Pins: 5-8 Terminal/Tray: 8100-4445/22 Core/Insulation Crimp: F/D Release Tool/Test Probe: 15315247/J-35616-35 (VT) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 GY | 6135 | Local Interconnect Network 4 |
| 2 | 0.35 L-BU/BK | 747 | Left Rear Door Ajar Switch Signal |
| 3 | 0.35 BK | 2150 | Ground |
| 4 | | | Not Used |
| 5 | 3 BK | 2150 | Ground |
| 6 | 3 D-BU | 668 | Power Window Motor Left Rear Up Control |
| 7 | 3 BN | 669 | Power Window Motor Left Rear Down Control |
| 8 | 3 RD/BK | 1842 | Battery Positive Voltage |
S79LR Window Switch - Left Rear
S79P Window Switch - Passenger X1
| Connector Part Information Harness Type: Passenger Door Trim OEM Connector: 15491286 Service Connector: 88988652 Description: 8-Way F 2.8 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 8100-4443/22 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-35 (VT) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 BK | 650 | Ground |
| 2 | 0.35 YE | 6817 | LED Backlight Dimming Control |
| 3 | | | Not Used |
| 4 | 0.35 RD/WH | 5240 | Battery Positive Voltage |
| 5 | | | Not Used |
| 6 | 0.35 PU | 3386 | Passenger Window Express Signal |
| 7 | 0.35 TN | 3385 | Passenger Window Switch Down Signal |
| 8 | 0.35 L-BU | 3384 | Passenger Window Switch Up Signal |
S79P Window Switch - Passenger X1
Scheme 424
Scheme 424: S79P Window Switch - Passenger X2
| Connector Part Information Harness Type: Passenger Door Trim OEM Connector: 13551678 Service Connector: 89047364 Description: 12-Way F 64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 YE/BK | 3413 | Passenger Side Outside Rearview Mirror Extend Control |
| 2 | 0.35 OG/BK | 3397 | Passenger Side Mirror Up/Down Motor Control |
| 3 | 0.35 WH | 3398 | Passenger Side Mirror Motor Common |
| 4 | 0.35 YE | 3399 | Reference Voltage |
| 5 | 0.35 L-BU/BK | 3401 | Passenger Side Mirror Vertical Position Signal |
| 6 | 0.35 L-GN | 3400 | Low Reference |
| 7 | 0.5 L-BU/BK | 3414 | Passenger Side Outside Rearview Mirror Retract Control |
| 8 | 0.35 GY/BK | 3396 | Passenger Side Mirror Right/Left Motor Control |
| 9 | 0.35 WH | 7530 | Local Interconnect Network 8 |
| 10 | | | Not Used |
| 11 | 0.35 BN | 3403 | Passenger Side Mirror Horizontal Position Signal |
| 12 | | | Not Used |
S79P Window Switch - Passenger X2
S79RR Window Switch - Right Rear
| Connector Part Information Harness Type: Right Rear Door OEM Connector: 15491286 Service Connector: 88988652 Description: 8-Way F 2.8 Series (BK) |
|---|
| Terminal Part Information Pins: 1, 2 Terminal/Tray: 8100-4443/22 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-35 (VT) Pins: 5-8 Terminal/Tray: 8100-4445/22 Core/Insulation Crimp: F/D Release Tool/Test Probe: 15315247/J-35616-35 (VT) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 GY | 6135 | Local Interconnect Network 4 |
| 2 | 0.35 L-GN/BK | 748 | Right Rear Door Ajar Switch Signal |
| 3-4 | | | Not Used |
| 5 | 3 BK | 2050 | Ground |
| 6 | 3 D-BU | 670 | Power Window Motor Right Rear Up Control |
| 7 | 3 BN | 671 | Power Window Motor Right Rear Down Control |
| 8 | 3 RD/BK | 4042 | Battery Positive Voltage |
S79RR Window Switch - Right Rear
Scheme 425
Scheme 425: S82 Windshield Wiper/Washer Switch
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13609516 Service Connector: 13316157 Description: 8-Way F 1.2 HCM Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SHCM-A03T-P025/20 Core/Insulation Crimp: J/J Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 L-GN | 1715 | Windshield Wiper Switch High Signal |
| 2 | 0.35 TN/BK | 6009 | Low Reference |
| 3 | 0.35 L-BU | 1714 | Windshield Wiper Switch Low Signal |
| 4 | 0.35 GY | 391 | Rear Window Wiper Switch Signal |
| 5 | 0.35 PK | 94 | Windshield Washer Switch Signal |
| 6-7 | | | Not Used |
| 8 | 0.35 L-GN | 6096 | Washer Fluid Heated Control Switch Signal |
S82 Windshield Wiper/Washer Switch
S90 Sunroof Sunshade Switch
| Connector Part Information Harness Type: OEM Connector: 13597457 Service Connector: 13576536 Description: 4-Way F 0.64 Micro Quadlok Series (WH) |
|---|
| Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 GY | 5307 | Front Sunshade Switch Low Reference |
| 2 | 0.35 YE | 6817 | LED Backlight Dimming Control |
| 3 | 0.35 BK | 1350 | Ground |
| 4 | 0.35 D-BU/WH | 3032 | Sunshade Open/Close Switch Signal |
S90 Sunroof Sunshade Switch
T3 Audio Amplifier X1
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 15491286 Service Connector: 88988652 Description: 8-Way F 2.8 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 8100-4445/22 Core/Insulation Crimp: Pins 2, 6 - 4/4 Core/Insulation Crimp: Pins 4, 8, 8 - F/D Release Tool/Test Probe: 15315247/J-35616-35 (VT) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used |
| 2 | 2 L-GN/BK | 1794 | Left Subwoofer Speaker Output (-) |
| 3 | | | Not Used |
| 4 | 3 RD/WH | 3740 | Battery Positive Voltage |
| 5 | | | Not Used |
| 6 | 2 D-BU/WH | 346 | Left Subwoofer Speaker Output (+) |
| 7 | | | Not Used |
| 8 | 3 BK/WH | 1551 | Ground |
Scheme 426
Scheme 426: T3 Audio Amplifier X2
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 15489823 Service Connector: 15134091 Description: 16-Way F 1.5 Series (BK) |
|---|
| Terminal Part Information Pins: 1-10, 13-16 Terminal/Tray: 8240-0128/22 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) Pins: 12 Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.8 L-BU | 115 | Right Rear Speaker Output (-) |
| 2 | 0.8 D-BU | 46 | Right Rear Speaker Output (+) |
| 3 | 0.8 WH | 1959 | Left Rear Midrange Speaker Output (-) |
| 4 | 0.8 TN | 1859 | Left Rear Midrange Speaker Output (+) |
| 5 | 0.8 OG | 1955 | Right Rear Midrange Speaker Output (-) |
| 6 | 0.8 TN | 1855 | Right Rear Midrange Speaker Output (+) |
| 7 | 0.8 D-GN | 117 | Right Front Speaker Output (-) |
| 8 | 0.8 L-GN | 200 | Right Front Speaker Output (+) |
| 9 | 0.8 GY | 118 | Left Front Speaker Output (-) |
| 10 | 0.8 TN | 201 | Left Front Speaker Output (+) |
| 11 | | | Not Used |
| 12 | 0.35 BK | 1350 | Ground |
| 13 | 0.8 L-BU | 1960 | Front Center Speaker Output (-) |
| 14 | 0.8 YE | 1860 | Front Center Speaker Output (+) |
| 15 | 0.8 BN | 199 | Left Rear Speaker Output (+) |
| 16 | 0.8 YE | 116 | Left Rear Speaker Output (-) |
Scheme 427
Scheme 427: T3 Audio Amplifier X3
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 15491285 Service Connector: 15136073 Description: 16-Way F Kaizen 64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 WH | 6763 | Subwoofer Speaker High |
| 2 | 0.35 OG | 6761 | Left Rear Low Level Audio Signal (-) |
| 3 | 0.35 D-BU | 6760 | Left Rear Low Level Audio Signal (+) |
| 4 | 0.35 TN | 1946 | Right Rear Low Level Audio Signal (-) |
| 5 | 0.35 BN | 1999 | Left Rear Low Level Audio Signal (-) |
| 6 | 0.35 OG/BK | 1546 | Front Low Level Audio Signal (-) |
| 7 | 0.35 D-GN | 1947 | Left Front Low Level Audio Signal (-) |
| 8 | 0.35 WH | 7066 | Remote Enable |
| 9 | 0.35 PK | 6762 | Subwoofer Speaker Low |
| 10 | | | Not Used |
| 11 | 0.35 OG | 6978 | Amplifier Control |
| 12 | 0.35 D-BU | 546 | Right Rear Low Level Audio Signal (+) |
| 13 | 0.35 BN/WH | 599 | Left Rear Low Level Audio Signal (+) |
| 14 | 0.35 L-GN/WH | 512 | Right Front Low Level Audio Signal (+) |
| 15 | 0.35 TN | 511 | Left Front Low Level Audio Signal (+) |
| 16 | | | Not Used |
Scheme 428
Scheme 428: T8A Ignition Coil 1
| Connector Part Information Harness Type: Engine OEM Connector: 15466325 Service Connector: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D - 2/1 Core/Insulation Crimp: Pins B, C - E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BK | 550 | Ground |
| B | 0.5 BN | 2129 | Low Reference (LF1) |
| 0.5 OG/BK | 453 | Low Reference (LAU) |
| C | 0.5 PU | 2121 | IC 1 Control |
| D | 0.8 PK/BK | 5291 | Ignition Voltage |
T8B Ignition Coil 2
| Connector Part Information Harness Type: Engine OEM Connector: 15466325 Service Connector: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D - 2/1 Core/Insulation Crimp: Pins B, C - E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BK | 450 | Ground |
| B | 0.5 BN/WH | 2130 | Low Reference (LF1) |
| 0.5 OG/BK | 453 | Low Reference (LAU) |
| C | 0.5 OG/WH | 2122 | IC 2 Control |
| D | 0.8 PK/BK | 5292 | Ignition Voltage |
T8C Ignition Coil 3
| Connector Part Information Harness Type: Engine OEM Connector: 15466325 Service Connector: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D - 2/1 Core/Insulation Crimp: Pins B, C - E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BK | 550 | Ground |
| B | 0.5 BN | 2129 | Low Reference (LF1) |
| 0.5 OG/BK | 453 | Low Reference (LAU) |
| C | 0.5 L-BU | 2123 | IC 3 Control |
| D | 0.8 PK/BK | 5291 | Ignition Voltage |
T8D Ignition Coil 4
| Connector Part Information Harness Type: Engine OEM Connector: 15466325 Service Connector: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D - 2/1 Core/Insulation Crimp: Pins B, C - E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BK | 450 | Ground |
| B | 0.5 BN/WH | 2130 | Low Reference (LF1) |
| 0.5 OG/BK | 453 | Low Reference (LAU) |
| C | 0.5 D-GN/WH | 2124 | IC 4 Control |
| D | 0.8 PK/BK | 5292 | Ignition Voltage |
T8E Ignition Coil 5
| Connector Part Information Harness Type: Engine OEM Connector: 15466325 Service Connector: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D - 2/1 Core/Insulation Crimp: Pins B, C - E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BK | 550 | Ground |
| B | 0.5 BN | 2129 | Low Reference (LF1) |
| 0.5 OG/BK | 453 | Low Reference (LAU) |
| C | 0.5 D-GN | 2125 | IC 5 Control |
| D | 0.8 PK/BK | 5291 | Ignition Voltage |
T8F Ignition Coil 6
| Connector Part Information Harness Type: Engine OEM Connector: 15466325 Service Connector: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D - 2/1 Core/Insulation Crimp: Pins B, C - E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BK | 450 | Ground |
| B | 0.5 BN/WH | 2130 | Low Reference (LF1) |
| 0.5 OG/BK | 453 | Low Reference (LAU) |
| C | 0.5 L-BU/WH | 2126 | IC 6 Control |
| D | 0.8 PK/BK | 5292 | Ignition Voltage |
Scheme 429
Scheme 429: T10C Keyless Entry Antenna - Left Front Door Handle
| Connector Part Information Harness Type: Body OEM Connector: 13617298 Service Connector: Pending Description: 4-Way M 0.64 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAITW-A03T-064/20 Core/Insulation Crimp: J/J Release Tool/Test Probe: J-38125-215A/J-35616-65B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 PU | 3560 | Antenna + |
| 2 | 0.35 PU/WH | 3561 | Antenna |
| 3 | 0.35 L-GN/WH | 6655 | Remote Control Door Lock/Unlock Signal |
| 4 | 0.35 BK/WH | 751 | Ground |
T10C Keyless Entry Antenna - Left Front Door Handle
T10D Keyless Entry Antenna - Right Front Door Handle
| Connector Part Information Harness Type: Passenger Door OEM Connector: 13617298 Service Connector: Service by Harness - See Part Catalog Description: 4-Way M 0.64 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAITW-A03T-064/20 Core/Insulation Crimp: J/J Release Tool/Test Probe: J-38125-215A/J-35616-65B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 L-GN | 3562 | Antenna + |
| 2 | 0.35 L-GN/BK | 3563 | Antenna |
| 3 | 0.35 L-BU | 3576 | Remote Control Door Lock/Unlock Signal |
| 4 | 0.35 BK/WH | 651 | Ground |
T10D Keyless Entry Antenna - Right Front Door Handle
Scheme 430
Scheme 430: T10E Keyless Entry Antenna - Rear Compartment
| Connector Part Information Harness Type: Body OEM Connector: 10864908 Service Connector: 24414929 Description: 4-Way F 64 MQS Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 928999-5/15 Core/Insulation Crimp: H/H Release Tool/Test Probe: 12094429/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 L-GN | 3556 | Antenna + |
| 2 | 0.35 D-GN | 3557 | Antenna |
| 3-4 | | | Not Used |
T10E Keyless Entry Antenna - Rear Compartment
