Automatic Transmission - 6t70/6t75 - Component Locator Cadillac SRX II

Automatic Trans 19 illustrations

Scheme 88

Scheme 88: Disassembled Views
Scheme 88: Disassembled Views
CalloutComponent Name
1Control Valve Body Cover Assembly
2Transmission Fluid Level Indicator Assembly
3Fluid Level Indicator Tube - Model Dependent
4Fluid Level Indicator Tube Seal - Model Dependent
5Control Valve Body Cover Assembly Gasket
6Control Valve Body Cover Stud
7Control Valve Body Cover Bolt
8Control Valve Body Bolt
9Control Valve Body Bolt
10Control Valve Body Cover Wiring Connector Hole Seal
11Control Solenoid Valve Spring
12Control Valve Body Bolt
13Control Valve Body Bolt
14Control Valve Body Bolt
15Control Solenoid (w/Body and TCM) Valve Assembly
16Control Solenoid (w/Body and TCM) Filter Plate Assembly
17Manual Shaft Detent Assembly
18Control Valve Body Assembly
19A/Trans Output Speed Sensor Assembly
20A/Trans Output Speed Sensor Bolt
21A/Trans Case Assembly
22Torque Converter Housing Outer Seal
23Front Differential Drive Pinion (w/Transfer Gear) Gear Assembly
24Front Differential Drive Pinion Gear Lube Tube
25Torque Converter and Support and A/Trans Fluid Pump Housing Assembly
26Torque Converter and Differential Housing Bolt
27Torque Converter Assembly
28Dust Cover Push Pin - Model Dependent
29Dust Cover Bolt - Model Dependent
30Dust Cover - Model Dependent
31Front Differential Carrier Assembly
32Input Shaft Thrust Bearing Assembly
33A/Trans Case Cover Gasket
34A/Trans Case Cover Assembly
35A/Trans Case Cover Assembly Bolt

Scheme 89

Scheme 89
Scheme 89
CalloutComponent Name
51A/Trans Case Assembly
52Transmission Fluid Cooler Pipe Stud
53Transmission Case Cover Locator Pin
54A/Trans Fluid Trough O-Ring Seal
55A/Trans Fluid Trough Assembly
56A/Trans Fluid Trough Bolt
57A/Trans Pump Fluid Outlet Seal Assembly
58Front Differential Drive Pinion Gear Lube Dam
59Front Differential Drive Pinion Gear Bearing Cup
60Front Differential Carrier Bearing Cup
61Front Wheel Drive Shaft Oil Seal Assembly
62A/Trans Fluid Press Test Hole Plug
63A/Trans Fluid Level Hole Plug
64Control Valve Body Locator Pin
651-2-3-4 Clutch Fluid Passage Seal

Scheme 90

Scheme 90
Scheme 90
CalloutComponent Name
201A/Trans Fluid Filter Assembly
202Filter Neck Seal
203A/Trans Fluid Pump Assembly
204A/Trans Fluid Pump Bolt
205Front Differential Transfer Drive Gear Support Seal Assembly
206Front Differential Transfer Drive Gear Support Torque Converter Fluid Seal Assembly
207Front Differential Transfer Drive Gear Support Bolt
208Front Differential Transfer Drive Gear Support Assembly
209Front Differential Transfer Drive Gear Fluid Passage Tube Assembly
210Front Differential Transfer Drive Gear Fluid Passage Tube Bolt
211Front Differential Transfer Drive Gear Fluid Passage Tube Bolt
212Front Differential Transfer Drive Gear Support Fluid Passage Tube Gasket
213Front Differential Transfer Drive Gear Support Seal
214Drive Sprocket Thrust Washer
215Oil Pump Drive Link Driven Sprocket
216Oil Pump Drive Link Drive Sprocket
217Drive Link
218Drive Link Assembly
219Drive Sprocket Thrust Washer
220Drive Sprocket Thrust Washer
221Torque Converter and Differential Housing Assembly
222Front Differential Drive Pinion Gear Bearing Cup
223Front Differential Drive Pinion Gear Bearing Thrust Washer
224Front Differential Drive Pinion Gear Lube Dam
225Torque Converter Fluid Seal Assembly
226Front Wheel Drive Shaft Oil Seal Assembly
227Front Differential Bearing Thrust Washer
228Front Differential Carrier Bearing Cup
229Front Differential Carrier Baffle
230Front Differential Carrier Baffle Bolt

Scheme 91

Scheme 91
Scheme 91
CalloutComponent Name
301Control Valve Channel Upper Plate Assembly
302Control Valve Body Bolt
303Control Valve Body Bolt
304Control Valve Channel Plate
305Control Valve Body Bolt
306Actuator Feed Accumulator Piston
307Actuator Feed Accumulator Spring
308Control Valve Body Locator Pin
309Control Valve Upper Body Spacer Plate Assembly
310Control Valve Body Spacer Plate Retainer
311Control Valve Body Ball Check Valve
312Control Valve Upper Body Assembly
313Control Valve Lower Body Spacer Plate Assembly
314Control Valve Lower Body

Scheme 92

Scheme 92
Scheme 92
CalloutComponent Name
325Low and Reverse and 4-5-6 Clutch Regulator Valve Spring
326Low and Reverse and 4-5-6 Clutch Regulator Valve
327Pressure Regulator Valve Bore Plug
328Torque Converter Clutch Valve Spring Retainer
329Torque Converter Clutch Regulator Apply Valve Spring
330Torque Converter Clutch Regulator Apply Valve
331Torque Converter Clutch Regulator Apply Shuttle Valve
3322-6 Clutch Regulator Valve Spring
3332-6 Clutch Regulator Valve
3342-6 Clutch Regulator Valve Gain Valve
3353-5-Reverse Clutch Regulator Valve Spring
3363-5-Reverse Clutch Regulator Valve
337Pressure Regulator Valve
338Pressure Regulator Valve Spring
339Pressure Regulator Valve Bore Plug Retainer
340Isolator Valve
341Isolator Valve Spring
342Torque Converter Clutch Control Valve
343Torque Converter Clutch Control Valve Spring
344Clutch Select Solenoid Valve #3 Spring
345Clutch Select Solenoid #3 Valve
346Clutch Select Solenoid Valve #2 Spring
347Clutch Select Solenoid #2 Valve
348Manual Valve
349Control Valve Upper Body

Scheme 93

Scheme 93
Scheme 93
CalloutComponent Name
3271-2-3-4 Clutch Regulator Valve Bore Plug
339Actuator Feed Limit Valve Spring Retainer
3604-5-6 Clutch Boost Valve
3614-5-6 Clutch Boost Valve Spring
362Actuator Feed Limit Valve
363Actuator Feed Limit Valve Spring
3643-5-Reverse Clutch Boost Valve
3653-5-Reverse Clutch Boost Valve Spring
3664-5-6 Clutch Accumulator Piston
3674-5-6 Clutch Accumulator Piston Spring
3684-5-6 Clutch Accumulator Piston Retainer
3691-2-3-4 Clutch Boost Valve
3701-2-3-4 Clutch Boost Valve Spring
3711-2-3-4 Clutch Regulator Valve Spring
3721-2-3-4 Clutch Regulator Valve
373Default Override 1-2-3-4 Clutch Valve
374Control Valve Lower Body

Scheme 94

Scheme 94
Scheme 94
CalloutComponent Name
400A/Trans Input Speed Sensor Assembly
401A/Trans Input Speed Sensor Bolt
402ISS O-Ring Seal
403A/Trans Case Cover Assembly
4043-5-Reverse and 4-5-6 Clutch Fluid Seal Ring
4052-6 Clutch Piston
4062-6 Clutch Spring Assembly
4072-6 Clutch Spring Retainer Ring
408Low and Reverse Clutch Piston Assembly
409Low and Reverse Clutch Spring
410Low and Reverse Clutch Spring Retainer Ring

Scheme 95

Scheme 95
Scheme 95
CalloutComponent Name
415A/Trans Input Shaft Speed Sensor Reluctor Ring Retainer Ring
416A/Trans Input Shaft Speed Sensor Reluctor Wheel
4173-5-Reverse Clutch Piston
4183-5-Reverse Clutch Spring
4193-5-Reverse Clutch Piston Inner Seal
4203-5-Reverse Clutch Piston Inner Seal
4213-5-Reverse Clutch Piston Dam Seal
4223-5-Reverse and 4-5-6 Clutch Housing Assembly
4233-5-Reverse Clutch (Waved) Plate
4243-5-Reverse Clutch Plate
4253-5-Reverse Clutch (w/Friction Material) Plate Assembly
4263-5-Reverse Clutch Backing Plate
4273-5-Reverse Clutch Backing Plate Retainer Ring

Scheme 96

Scheme 96
Scheme 96
CalloutComponent Name
4223-5-Reverse and 4-5-6 Clutch Housing Assembly
4304-5-6 Clutch Piston Inner Seal
4314-5-6 Clutch Piston Outer Seal
4324-5-6 Clutch Piston Outer Seal
4334-5-6 Clutch Piston
4344-5-6 Clutch Spring
4354-5-6 Clutch Piston Fluid Dam
4364-5-6 Clutch Dam Retainer Ring
4374-5-6 Clutch Hub Thrust Bearing Assembly
438Reaction Carrier Hub Assembly
4394-5-6 Clutch Plate
4404-5-6 Clutch (w/Friction Material) Plate Assembly
4414-5-6 Clutch Backing Plate
4424-5-6 Clutch Backing Plate Retainer Ring

Scheme 97

Scheme 97
Scheme 97
CalloutComponent Name
4452-6 Clutch Cushion Spring
4462-6 Clutch Plate
4472-6 Clutch (w/Friction Material) Plate Assembly
4482-6 Clutch Backing Plate
449Low and Reverse Clutch Apply Plate
450Low and Reverse Clutch Cushion (Waved) Spring
451Low and Reverse Clutch (w/Friction Material) Plate Assembly
452Low and Reverse Clutch Plate
453Low and Reverse Clutch Backing Plate
454Low and Reverse Clutch Retainer Ring
455Low and Reverse Clutch Assembly (OWC)
4561-2-3-4 Clutch (w/Friction Material) Plate Assembly
4571-2-3-4 Clutch Plate
4581-2-3-4 Clutch (Waved) Plate
4591-2-3-4 Clutch Spring Retainer Ring
4601-2-3-4 Clutch Spring
4611-2-3-4 Clutch Piston
449Low and Reverse Clutch Apply Plate

Scheme 98

Scheme 98
Scheme 98
CalloutComponent Name
4652-6 Clutch Hub Thrust Bearing
466Reaction Sun Gear Assembly
467Reaction Carrier Assembly
468Input Carrier Thrust Bearing Assembly
469Input Sun Gear Thrust Bearing Assembly
470Input Carrier Assembly
471Input Sun Gear
472Output Carrier Thrust Bearing Assembly
473Output Carrier Thrust Bearing Assembly
474Output Carrier Assembly
475Output Sun Gear Assembly
476Front Differential Transfer Drive Gear Input Hub Bearing Assembly
477Output Carrier Transfer Drive Gear Hub Assembly
478Input Internal Gear
479Input Internal Gear Retaining Ring
482Reaction Internal Gear Retaining Ring
483Reaction Carrier Internal Gear

Scheme 99

Scheme 99
Scheme 99
CalloutComponent Name
480Front Differential Drive Pinion Gear Bearing Assembly
481Front Differential Drive Pinion (w/Transfer Gear) Gear Assembly

Scheme 100

Scheme 100
Scheme 100
CalloutComponent Name
485Front Differential Carrier Bearing Assembly
486Front Differential Carrier Assembly
487Front Differential Carrier Bearing Assembly
488Front Differential Carrier Thrust Washer
489Front Differential Pinion Gear
490Front Differential Pinion Gear Shaft Retainer
491Front Differential Pinion Gear Shaft
492Front Differential Side Gear Thrust Washer
493Front Differential Side Gear

Scheme 101

Scheme 101
Scheme 101
CalloutComponent Name
500Park Pawl Actuator Bracket Bolt
501Park Pawl Actuator Bracket
502Park Pawl Shaft
503Park Pawl
504Park Pawl Spring
505Park Pawl Actuator Guide Pin
506Park Pawl Actuator Guide
507A/Trans Case Assembly
508Manual Shift Shaft Seal
509Park Pawl Actuator Assembly
510Manual Shift Shaft Pin
511Manual Shift Detent (w/Shaft Position Switch) Lever Assembly

Scheme 102

Scheme 102: Component Location
Scheme 102: Component Location
CalloutComponent Name
1Manual Shift Detent Lever Assembly (w/Shaft Position Switch)
2Trans Fluid Level Indicator
3Reaction Carrier Assembly
4Output Speed Sensor
5Input Carrier Assembly
6Output Carrier Assembly
7Front Differential Transfer Drive Gear
8Front Differential Transfer Drive Gear Support Assembly
9Torque Converter Assembly
10Park Pawl Actuator Assembly
11Fluid Pump Drive Link Assembly
12Park Pawl
13Front Differential Transfer Driven Gear
14Front Differential Drive Pinion Gear
15Park Gear
16Torque Converter and Support and Fluid Pump Housing Assembly
17Front Differential Carrier Assembly
18Front Differential Carrier Baffle
19Front Differential Ring Gear
20Front Differential Drive Pinion Gear Lube Tube
211-2-3-4 Clutch Assembly
22Low and Reverse Clutch Assembly (OWC)
23Low and Reverse Clutch
242-6 Clutch Assembly
253-5-Reverse Clutch Assembly
264-5-6 Clutch Assembly
27Input Speed Sensor
28Case Cover Assembly
29Control Valve Body Cover
30Input Shaft Speed Sensor Reluctor Wheel
31Control Valve Lower Body Assembly
32Control Valve Upper Body Assembly
33Control Valve Channel Plate Assembly
34Control Solenoid Valve Assembly (w/Body and TCM)
35Manual Valve

Scheme 103

Scheme 103: Bushing, Bearing, and Washer Locations
Scheme 103: Bushing, Bearing, and Washer Locations
CalloutComponent Name
32Input Shaft Thrust Bearing Assembly
214Drive Sprocket Thrust Washer
219Drive Sprocket Thrust Washer
220Drive Sprocket Thrust Washer
223Front Differential Drive Pinion Gear Bearing Thrust Washer
227Front Differential Bearing Thrust Washer
4374-5-6 Clutch Hub Thrust Bearing Assembly
4652-6 Clutch Hub Thrust Bearing
468Input Carrier Thrust Bearing Assembly
469Input Sun Gear Thrust Bearing Assembly
472Output Carrier Thrust Bearing Assembly
473Output Carrier Thrust Bearing Assembly
476Front Differential Transfer Drive Gear Input Hub Bearing Assembly
480Front Differential Drive Pinion Gear Bearing Assembly
485Front Differential Carrier Bearing Assembly
487Front Differential Carrier Bearing Assembly
488Front Differential Carrier Thrust Washer
492Front Differential Side Gear Thrust Washer

Scheme 104

Scheme 104: Seal Locations
Scheme 104: Seal Locations
CalloutComponent Name
5Control Valve Body Cover Assembly Gasket
16Control Solenoid (w/Body and TCM) Filter Plate Assembly
22Torque Converter Housing Outer Seal
33A/Trans Case Cover Gasket
58Front Differential Drive Pinion Gear Lube Dam
61Front Wheel Drive Shaft Oil Seal Assembly
205Front Differential Transfer Drive Gear Support Seal Assembly
213Front Differential Transfer Drive Gear Support Seal
224Front Differential Drive Pinion Gear Lube Dam
225Torque Converter Fluid Seal Assembly
226Front Wheel Drive Shaft Oil Seal Assembly
4043-5-Reverse and 4-5-6 Clutch Fluid Seal Ring
4052-6 Clutch Piston
408Low and Reverse Clutch Piston Assembly
4173-5-Reverse Clutch Piston
4193-5-Reverse Clutch Piston Inner Seal
4203-5-Reverse Clutch Piston Inner Seal
4213-5-Reverse Clutch Piston Dam Seal
4304-5-6 Clutch Piston Inner Seal
4314-5-6 Clutch Piston Outer Seal
4324-5-6 Clutch Piston Outer Seal
4611-2-3-4 Clutch Piston

Scheme 105

Scheme 105
Scheme 105
CalloutComponent Name
4Fluid Level Indicator Tube Seal - Model Dependent
10Control Valve Body Cover Wiring Connector Hole Seal
54A/Trans Fluid Trough O-Ring Seal
57A/Trans Pump Fluid Outlet Seal Assembly
651-2-3-4 Clutch Fluid Passage Seal
202Filter Neck Seal
206Front Differential Transfer Drive Gear Support Torque Converter Fluid Seal Assembly
212Front Differential Transfer Drive Gear Support Fluid Passage Tube Gasket
402ISS O-Ring Seal
508Manual Shift Shaft Seal

Scheme 106

Scheme 106: Ball Check Valve Locations
Scheme 106: Ball Check Valve Locations
I.D.Input OilInput OilOutput Oil
1Drive 1-6DRV B26/1234 CL Feed
2Solenoid 1ReverseCSV2 Enable
3Solenoid 2456CSV3 Enable
4PS4456CSV2 Latch
5Drive 1-635 Rev FD35 Rev Supply
62-6/12341234 Clutch Feed
735R Supply35R Clutch Feed
8Low/Rev SupplyLow/Rev Clutch Feed
9456 Clutch Supply456 Clutch Feed

More articles — Transmission
