Oil Filter Bracket, Component Overview Audi TT 8N рестайлинг

Note. The following list refers to items in see scheme 359.

1. Sealing cap Tighten to 25 Nm
2. O-ring Replace
3. Oil filter element Observe change intervals
4. Oil filter bracket With oil retention valve
5. 23 Nm
6. Screw plug, 15 Nm
7. Oil seal If seal is leaking, cut open and replace
8. Oil seal If seal is leaking, cut open and replace
9. Oil pressure switch -F1-, 1.4 bar Black insulation Checking, see «OIL PRESSURE AND OIL PRESSURE SWITCH, CHECKING»(ref-200989-S12756768902005102400000) Tighten to 25 Nm
10. Oil seals Replace
11. Sealing cap Tighten to 25 Nm
12. Oil seal Replace Lubricate before installing
13. Oil cooler Ensure clearance from adjacent components Diagram of coolant hose connections, see «COOLING SYSTEM, COMPONENT OVERVIEW»(ref-200990-S09609717422005102400000) Read note if making repairs on engine. See «LUBRICATION SYSTEM COMPONENTS, REMOVING AND INSTALLING»(ref-200989-S00681434402005102400000) .
14. Oil seal Installed position, see «INSTALLED POSITION OF OIL SEAL AND PLASTIC ELEMENT IN OIL COOLER»(ref-200989-S41934749602005102400000) Lubricate before installing Press onto oil cooler with plastic element item -15
15. Plastic element Insert into oil cooler together with oil seal item -14- Installed position, see «INSTALLED POSITION OF OIL SEAL AND PLASTIC ELEMENT IN OIL COOLER»(ref-200989-S41934749602005102400000)

Scheme 352
