Note. The following list refers to items in see scheme 229.
- Cylinder block Cylinder bore, checking See «CHECKING PISTON»(ref-200989-S15934312962005102400000) . See «PISTON AND CYLINDER DIMENSIONS»(ref-200989-S38055955792005102400000) .
- Oil spray nozzle for piston cooling For crankshaft bearings 2...7 Opening pressure: 2.0 bar See «REMOVING AND INSTALLING OIL SPRAY JET»(ref-200989-S38599897972005102400000) .
- Bearing shell For cylinder block with oil intake bore Do not interchange used bearings (mark) Replacement parts are only color coded "yellow"
- Crankshaft After removal, lay aside so that sensor wheel item -10- is not supporting weight or it will be damaged Axial play, New: 0.07...0.23 mm; Wear limit: 0.30 mm Measure radial play with Plastigage Do not turn crankshaft when measuring radial play Radial play, New: 0.02...0.06 mm; Wear limit: 0.10 mm See «CRANKSHAFT DIMENSIONS»(ref-200989-S26254584422005102400000) .
- Thrust washer For bearing 5 Observe locating point Lubricating groove faces crankshaft
- Bearing cap Bearing cap 1: belt pulley side Bearing cap 5 with notches for thrust washers Retaining tabs of bearing shells and cylinder block/bearing caps must lie above one another
- 30 Nm + 180° (1/2 turn) further REPLACE
- Bearing shell For bearing cap without bore Do not interchange used bearings (mark) Replacement parts are only color coded "yellow"
- Thrust washer For bearing 5 Observe locating point Lubricating groove faces crankshaft
- Sensor wheel For Engine speed sensor -G28- Sensor wheel must be replaced every time bolts are loosened. See «REMOVING AND INSTALLING SENSOR WHEEL»(ref-200989-S27841127912005102400000) . Installing. See «REMOVING AND INSTALLING SENSOR WHEEL»(ref-200989-S27841127912005102400000)
- 10 Nm + 90° (1/4 turn) further REPLACE Sensor wheel must be replaced every time bolts are loosened. See «REMOVING AND INSTALLING SENSOR WHEEL»(ref-200989-S27841127912005102400000) .
