Lubrication System, Component Overview Audi TT 8N рестайлинг

Note. The following list refers to items in see scheme 349.

1. Nm Secured to intake manifole
2. Oil dipstick
3. Guide tube for oil dipstick
4. Cylinder block
5. Oil return valve Removing and Installing, see «REMOVING AND INSTALLING OIL RETURN VALVE»(ref-200989-S18441744252005102400000) Note installed position
6. 8 Nm
7. Cover for oil pump drive
8. O-ring Replace Lubricate before installing
9. Oil pump drive
10. Intermediate shaft
11. Thrust washer
12. 10 Nm Install using locking fluid See Parts catalog.
13. Oil spray jet (for cooling of pistons) For crankshaft bearings 2...7 Opening pressure: 2.0 bar Removing and Installing, see «REMOVING AND INSTALLING OIL SPRAY JET»(ref-200989-S38599897972005102400000)
14. Input shaft for oil pump drive
15. Oil pump Disassembling and Assembling, see «OIL PUMP, COMPONENT OVERVIEW»(ref-200989-S00453070442005102400000) Coat oil pressure pipe at cylinder block and at oil pump housing with sealing paste See Parts catalog.
16. 23 Nm
17. Oil drain plug, 30 Nm
18. Sump Removing and Installing, see «SUMP, REMOVING AND INSTALLING»(ref-200989-S19221148462005102400000)
19. Oil level/Oil level thermal sensor -G266- Removing and Installing, see «REMOVING AND INSTALLING OIL LEVEL THERMAL SENSOR -G266»(ref-200989-S42135807302005102400000)
20. 12 Nm
21. Oil filter bracket Overview of components, see «OIL FILTER BRACKET, COMPONENT OVERVIEW»(ref-200989-S39669194392005102400000) . Removing and Installing, see «OIL FILTER BRACKET, REMOVING AND INSTALLING»(ref-200989-S27608109512005102400000)

Scheme 342

Scheme 343

1. To remove, screw in M8 x 1.5 bolt approx. 4 turns into valve (arrow) and pull out.
2. To install, lubricate O-ring and press valve into oil channel by hand.
