Controls, Housing (Continuously Variable Transmission Internal Components 0aw (sedan)) Audi A4 B8

Automatic Trans 28 illustrations ~1650 words

ATF FLUSH

Special tools and workshop equipment required

  1. Vehicle Tester

Procedure

With normal ATF change, only about 55 to 60% of total ATF in transmission is replaced.

The "ATF flush" is necessary when old ATF in the transmission must be removed completely.

The ATF must always be flushed for the following work

  1. Replacing the input shaft
  2. Maintenance work on the input shaft

As described in the following, the test run must be executed twice and then the respective ATF must be changed.

This is the only way the ATF in the transmission can be changed completely.

The following describes flushing the ATF in 7 steps.

CAUTIONThere is a risk of damaging the transmission. Perform all the work exactly as described.

After installing the transmission: Fill the ATF, refer to ATF, FILLING FOR ATF FLUSH .

Flush ATF

ATF level, checking and correcting, refer to Diagnosis and Testing .

Note. Observe all notes and test requirements for "Checking ATF level and filling".

The ATF flush is completed after the ATF level is checked.

ATF, DRAINING FOR ATF FLUSH

Special tools and workshop equipment required

  1. Hook 3438
  2. Oil Collecting and Extracting Device V.A.G 1782
  3. Protective goggles

Procedure

CAUTIONThere is a risk of damaging the transmission. Do not start the engine if there is only a little or no ATF in the transmission.

Scheme 190

Scheme 190
  1. The engine is off.
  2. Move the vehicle onto a 4-column shop hoist or over a work pit so it is completely level.
  3. The selector level is in "P".
  4. The electro-mechanical parking brake is set.
  5. Depending on the version, ATF inspection plugs of different lengths -A- are installed. The ATF check plug must be replaced after the ATF level test. To prevent damaging the transmission, compare the old and new ATF inspection plug.

Remove the rear noise insulation. Refer to Description and Operation .

Scheme 191

Scheme 191

Place the V.A.G 1782 under the transmission.

WARNINGDanger of eye injury. Wear protective goggles.

Remove the ATF check plug -A-.

Drain the ATF.

Note. Follow all disposal regulations! Depending on the version, different ATF inspection plugs and different oil level tubes are installed.

Transmission with a Long, Bent Oil Level Tube

Pull the oil level tube -A- out of the ATF check hole using the 3438 and let the remaining ATF drain out.

Scheme 192

Scheme 192

Push the ATF level tube -A- into the ATF check hole -B- by hand.

Scheme 193

Scheme 193
  1. Installed position: the large tab -1- on the ATF level tube must face the recess -2- on the ATF check hole.

Note. The ATF level tube -A- must be replaced after the second attempt.

Transmission with a Short, Straight ATF Level Tube

Pull the oil level tube -A- out of the ATF check hole using the 3438 and let the remaining ATF drain out.

Scheme 194

Scheme 194

Scheme 195

Scheme 195
  1. The O-ring -1- must fit correctly inside the groove in the oil level tube.

Push the ATF level tube -A- carefully and straight into the ATF check hole -B- by hand.

Note. The O-ring on the oil level tube -A- seals the oil level height tube -C-. Only this way can the ATF level be correctly adjusted. The ATF level tube -A- must be replaced after the second attempt. Ignore 3438

Continue ATF flushing Flush ATF

ATF, FILLING FOR ATF FLUSH

Special tools and workshop equipment required

  1. Oil Collecting and Extracting Device V.A.G 1782
  2. ATF Filler System F/CVT Transmission VAS 5162

Preparing

  1. Drain the ATF
CAUTIONThere is a risk of damaging the transmission. Use replacement ATF for the "0AW Transmission" only. Other types of non-approved ATFs and oils can cause malfunctions in the transmission or the transmission could stop working all together. The ATF filler tool must be clean and the ATF must not be mixed with any other ATF.

Note. The illustration on the reservoir for VAS 5162 in the upper left graphic, refers to the use of special ATF for CVT transmissions. In addition, the necessary work steps for filling are illustrated, which are described as follows

Procedure

Fill the VAS 5162 with the ATF for the "CVT 0AW Transmission".

Secure the filled container to the vehicle as high as possible.

Scheme 196

Scheme 196
  1. The shut-off valve on the VAS 5162 must be closed.
CAUTIONThere is a risk of damaging the transmission. Do not start the engine if there is only a little or no ATF in the transmission. In this case, a preliminary filling with 5.5 to 6 liters ATF must be performed.

Remove the O-ring -1- on the connection -2- on the VAS 5162.

Scheme 197

Scheme 197
CAUTIONDanger of misfilling the transmission. The connection -2- must be mounted by hand all the way into the inspection plug hole on the transmission without the O-ring. The oil level tube can be pushed into the ATF inspection plug hole in the upper position only when the O-ring is not on the connection -2-. This is the only way to correctly check and/or adjust the ATF level to the maximum.

Install the VAS 5162 connection, without the O-ring, all the way into the ATF check hole hand-tight.

Note. By doing so, the oil level tube is pushed into the correct installation position.

Turn the valve to the filler hose -lower arrow-. The ATF flows into the transmission.

Scheme 198

Scheme 198

Fill at least 5.5 to 6 liters ATF into transmission.

Move the selector lever into "P".

CAUTIONImmediately after starting the engine, let it run at 2, 500 RPM. Running the engine at high speeds is necessary so that the ATF pump is bled after a transmission repair. If this is not done, the pump could get damaged because it was briefly operated without any ATF.

Start the engine.

Using the accelerator pedal, let the engine run briefly at 2, 500 RPM.

Press the brake pedal and hold it down.

Shift through all selector lever positions "P, R, N, D, S" and let each position remain shifted at idle for approximately 2 seconds.

Selector lever in "P" and let engine continue to run at idle.

Thread connection on shut-off valve of the VAS 5162 from ATF inspection plug opening.

Let any excess ATF drain out.

Tighten the old ATF check plug.

  1. Tightening specifications: 30 Nm.

Continue ATF flushing Flush ATF .

Check the ATF level after the second flushing and fill if necessary. Refer to Diagnosis and Testing .

Note. Observe all notes and test requirements for "Checking ATF level and filling".

TRANSMISSION, TRANSPORTING

Special tools and workshop equipment required

  1. Shackle 10 - 222 A /12
  2. Shop Crane VAS 6100

Procedure

Attach the 10 - 222 A /12 to the upper rib on the transmission housing.

Scheme 199

Scheme 199

Attach the VAS 6100 hook, as illustrated.

Lift the transmission with VAS 6100 and 10 - 222 A /12.

ATF FLUSH, PERFORMING A TEST RUN

  1. ATF filled, refer to «ATF, FILLING FOR ATF FLUSH»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-continuously-variable-transmission-internal-components-0aw-sedan__atf-filling-for-atf-flush) .
CAUTIONDo not let the engine run or tow the vehicle without ATF.

Drive the vehicle from the hoist.

Note. For vehicles with air suspension, the vehicle lifting mode must be disabled. .

Comply precisely with the following conditions and execute all safety instructions.

WARNINGObey all traffic laws during the following road test. If necessary, vehicle must be driven on a test site.

Start the engine.

Move the selector lever into "D".

Move selector lever into "tiptronic gate".

Press the accelerator pedal slightly to accelerate the vehicle.

Pay attention to the display of the gear in the instrument cluster

Switch from the 1st gear to the highest gear by pressing the selector lever to "+".

Switch back to the 1st gear by pressing the selector lever to "-".

Note. If applicable, press the brake pedal

Press the brake pedal and brake the wheels to 0 km/h.

Place selector lever in position "R".

Press the accelerator pedal and speed up to 20 km/h.

Press the brake pedal and brake the wheels to 0 km/h.

Switch the selector lever back to the position "D" and repeat the entire process five times.

Note. Repeat the entire cycle five time so that all the old ATF will get mixed with the new ATF.

Switch the selector lever to the position "P" and turn off the engine.

Continue ATF flushing Flush ATF

CAUTIONThere is a risk of damaging the transmission. Filling the ATF during the ATF flushing procedure does not replace the ATF level test. Check the ATF level and after flushing and adjust it if necessary. Refer to Diagnosis and Testing .

TRANSMISSION, SECURING IN ENGINE/TRANSMISSION HOLDER

Special tools and workshop equipment required

  1. Hooks 10 - 222 A /2
  2. Engine and Transmission Holder VAS 6095
  3. Bracket T10358
  4. Transmission Support T40206 with T40206/1
  5. M8 x 30 bolt, nut, two washers

Procedure

  1. ATF drained. Refer to «General Information»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-continuously-variable-transmission-0aw-sedan) and gear oil drained «General Information»(/audi/a4/b8-2007-2012/remont/axle-shafts/#final-drive-differential-continuously-variable-transmission-0aw-sedan) .

Secure the T40206 with T40206/1 to the transmission as illustrated.

Scheme 200

Scheme 200

Attach the T10358 with the M8 x 30 bolt -1-, the nut and the two washers to the lifting eye on the right side of the transmission.

Attach the VAS 6100 and T10358 to the 10 - 222 A /2.

Lift the transmission and place it into the VAS 6095.

Scheme 201

Scheme 201

Scheme 202

Scheme 202: DUAL-MASS FLYWHEEL OVERVIEW
  1. Dual Mass Flywheel Removing and installing, refer to «DUAL MASS FLYWHEEL»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-continuously-variable-transmission-internal-components-0aw-sedan__dual-mass-flywheel)
  2. Transmission Housing
  3. Input Shaft Seal Removing and installing, refer to «INPUT SHAFT SEAL»(/audi/a4/b8-2007-2012/remont/automatic-trans/#gears-hydraulic-controls-continuously-variable-transmission-internal-components-0aw-sedan__input-shaft-seal)
  4. Bolt Replace Quantity: three for 4-cylinder engines Quantity: 6 for 6-cylinder engines Tightening specification and sequence, refer to «Specifications»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-continuously-variable-transmission-0aw-sedan) , "Transmission, Installing"

DUAL MASS FLYWHEEL

Special tools and workshop equipment required

  1. Extractor T40176
  2. Grease for clutch disc shaft splines G 000 100
  3. Sealing grease G 052 128 A1

Removing

  1. Transmission, securing to engine and transmission holder, refer to «TRANSMISSION, SECURING IN ENGINE/TRANSMISSION HOLDER»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-continuously-variable-transmission-internal-components-0aw-sedan__transmission-securing-in-enginetransmission-holder) .

Remove the left flange shaft. Refer to Removal and Installation .

Attach the T40176 to the dual mass flywheel -A- using the nut -B- -arrow-.

Scheme 203

Scheme 203

Rotate the T40176 upward.

Scheme 204

Scheme 204

Note. To prevent the dual-mass flywheel from tilting, counter hold it underneath as illustrated.

Remove the dual-mass flywheel from the input shaft -arrows-.

CAUTIONDanger of causing damage to the transfer plate on the dual mass flywheel. Do not lay the dual mass flywheel on one side on the transfer plate -arrow-. This could bend the transfer plate -arrow-, which will then lead to functionality problems.

Scheme 205

Scheme 205

Set the dual mass flywheel down carefully, for example on the workbench.

Installing

Installation is performed in the reverse order of removal while observing the following

Always clean the clutch housing in the area where the differential is accessed -arrow A- and the shaft seal -arrow B-.

Scheme 206

Scheme 206

Note. Replace the shaft seal between the differential and transmission housing -arrow B- if it is damaged. Refer to LEFT FLANGE SHAFT SEAL .

Fill the space between the sealing and dust lip half way with sealing grease G 052 128 A1.

Clean the input shaft -arrow-.

Scheme 207

Scheme 207

Lightly grease the input shaft splines with clutch disc spline grease G 000 100.

Carefully mount the dual mass flywheel onto the input shaft -arrow- without tilting it.

Install the left flange shaft. Refer to LEFT FLANGE SHAFT .

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 208

Scheme 208: SPECIAL TOOLS

Scheme 209

Scheme 209

Scheme 210

Scheme 210

Scheme 211

Scheme 211

Scheme 212

Scheme 212

Scheme 213

Scheme 213

Scheme 214

Scheme 214

Scheme 215

Scheme 215

Scheme 216

Scheme 216

Scheme 217

Scheme 217
  1. Shackle 10 - 222 A /12
  2. Hooks 10 - 222 A /2
  3. Hook 3438
  4. Bracket T10358
  5. Extractor T40176
  6. Transmission Support T40206 with T40206/1
  7. Oil Collecting and Extracting Device V.A.G 1782
  8. ATF Filler System F/CVT Transmission VAS 5162
  9. Engine and Transmission Holder VAS 6095
  10. Shop Crane VAS 6100
