Controls, Housing (Automatic Transmission 0b6 Awd (avant)) Audi A4 B8

Automatic Trans 103 illustrations ~12090 words

SHIFT MECHANISM EMERGENCY RELEASE

Note. It is not possible to move the selector lever out of P if the battery is disconnected or if it is discharged. The vehicle cannot be moved or towed. The shift lock solenoid -N110- will cancel out the lock when the emergency release is activated.

Procedure

Remove the front ashtray insert.

Pry out the cap inside the ashtray housing with a screwdriver -arrow-.

Scheme 362

Scheme 362: SHIFT MECHANISM EMERGENCY RELEASE
Scheme 362: SHIFT MECHANISM EMERGENCY RELEASE

Note. The shape of the cover caps may differ from those in the illustration.

Press the cylinder -arrow- on the shift lock solenoid through the opening in the center of the ashtray housing and, at the same time, press the locking button in the selector lever handle and move the selector out of P.

Scheme 363

Scheme 363
Scheme 363

Note. This unlocks the locking lever -1- when the selector lever is in P. If the cylinder -arrow- on the shift lock solenoid is covered by insulation or a wire, then move the insulation or the wire to the side.

AUTOMATIC TRANSMISSION FLUID LINES, CLEANING

Special tools and workshop equipment required

  1. Used Oil Collecting and Extracting Device V.A.G 1782
  2. Hose diameter approximately 18 mm
  3. Compressed air gun, commercially available
  4. Protective eyewear

Procedure

Note. Automatic transmission clean working conditions, refer to CLEAN WORKING CONDITIONS .

Before installing a replacement transmission, always clean out the ATF cooler and ATF pipes using compressed air (maximum 10 bar).

Note. If extremely dirty ATF flows out when cleaning using compressed air, flush the ATF cooler and lines using clean ATF.

ATF, CHECKING LEVEL AND CORRECTING

Special tools and workshop equipment required

  1. Vehicle Diagnosis, Testing and Information System VAS 5051B
  2. Used Oil Collecting and Extracting Device V.A.G 1782
  3. ATF Filler Tool V.A.G 1924
  4. Protective eyewear

Test Conditions

  1. The transmission must not be in the emergency operating mode.
  2. Move the vehicle onto a 4-column workshop hoist or over a work pit so it is completely level.
  3. The selector level is in P.
  4. The parking brake button should be activated to close the electromechanical parking brake.
  5. Exhaust hose/-hoses of an exhaust extraction system connected.
  6. The A/C and the heater are off.
  7. The VAS 5051B is connected.
  8. The ATF temperature must not be higher than 30 °C (86 °F) at the beginning of the test. The transmission must cool down first if the temperature is higher.

Note. ATF temperature appears in the display of VAS 5051B. The ATF level will vary according to the temperature of the ATF. It is possible to overfill the ATF if the level is checked when the temperature is too low. It is possible to overfill the ATF if the level is checked when the temperature is too high. Overfilling or under filling will influence the function of the transmission.

Procedure

Select the following menu items on the VAS 5051B in the Function/component Selection in guided fault finding

  1. Drive
  2. 0B6-Transmission
  3. 01-On Board Diagnostic (OBD) Capable Systems
  4. 02-Transmission Electronics
  5. 02-Transmission Electronics, Functions
  6. 02-Read Measured Value Block

Select the measured value from the list Transmission Fluid Temperature on the VAS 5051B.

Check the ATF temperature.

ATF, Checking Level and Correcting

Note. The ATF level is checked at the ATF inspection plug. The ATF level is correct if a small amount of fluid drips out of the inspection opening (this is normal as the fluid expands as it heats up) at an ATF temperature between 35°C (95°F) and 45°C (113°F) (for hot countries 50°C (122°F)).

CAUTIONThere is a risk of damaging the transmission. Only use the ATF available as a replacement part for the automatic transmission 0B6. Other oils can cause malfunctions or transmission failure. For the correct allocation. The ATF filler tool must be clean and the ATF must not be mixed with any other ATF.

Fill the reservoir on the V.A.G 1924 with the ATF for the automatic transmission 0B6; for the correct ATF specification.

Scheme 364

Scheme 364
Scheme 364

Secure reservoir of V.A.G 1924 as high as possible on vehicle.

CAUTIONThere is a risk of damaging the transmission. Engine must not be started if only a small amount or no ATF is in the transmission after repair work or after significant ATF loss. In this case, pre-filling is necessary ATF, DRAINING OR FILLING AFTER REPAIR .

Remove the rear noise insulation. Refer to Removal and Installation .

Scheme 365

Scheme 365
Scheme 365

Start the engine with the selector lever in P.

While pressing the brake pedal and with the vehicle idling, shift through all the selector lever positions (P, R, N, D, S) leaving each position engaged for at least 10 seconds.

Move the selector lever into N.

Increase the RPM to 2000 and hold it there for at least 60 seconds.

Move the selector lever into P.

Run the engine at idle.

Place the V.A.G 1782 under the transmission.

WARNINGDanger of eye injury. Wear protective eyewear.

When ATF temperature of 35 °C (95 °F) is reached, remove the ATF inspection plug -arrow B- and drain off any excess ATF.

Scheme 366

Scheme 366
Scheme 366

Note. The ATF inspection plug is accessible through the opening on the tunnel crossmember.

Scheme 367

Scheme 367
Scheme 367
  1. If ATF drips from the ATF inspection opening before the ATF has reached 40° C (104 °F), the ATF level -arrow- is OK.

Note. The ATF inspection plug must be installed again before the ATF reaches a temperature of 45 °C (113 °F) (50 °C (122 °F) with hot climates).

Fasten ATF inspection plug with new gasket -arrow- to 9 Nm. The ATF level test is now completed.

Scheme 368

Scheme 368
Scheme 368

Install the noise insulation. Refer to Removal and Installation .

  1. If no ATF drips out of the ATF inspection opening when the temperature has reached 40 °C (104 °F)

Filling the ATF

Note. The ATF inspection plug must be installed again before the ATF reaches 45 °C (113 °F) (50 °C (122 °F) for countries with hot climates). Let the transmission cool down and check again.

Guide filler hook of V.A.G 1924 from underneath into an opening in the cap -arrow-.

Scheme 369

Scheme 369
Scheme 369

Add ATF using V.A.G 1924 until ATF drips from the check hole.

Note. Too little or too much ATF will impair the transmission.

Fasten ATF inspection plug with new gasket -arrow- to 9 Nm. The ATF level test is now completed.

Remove the ATF residue on the tunnel crossmember and clean the crossmember thoroughly.

Scheme 370

Scheme 370
Scheme 370

Note. There are several recesses on the top side of the tunnel crossmember where leaking ATF can collect. They must be cleaned thoroughly. Ignore -arrows-.

Install the rear noise insulation. Refer to Removal and Installation .

ATF, DRAINING OR FILLING AFTER REPAIR

Special tools and workshop equipment required

  1. Vehicle Diagnosis, Testing and Information System VAS 5051B
  2. Used Oil Collecting and Extracting Device V.A.G 1782
  3. ATF Filler Tool V.A.G 1924
  4. Protective eyewear

Procedure

  1. The engine is off.
  2. Move the vehicle onto a 4-column workshop hoist or over a work pit so it is completely level.
  3. The selector level is in P.
  4. The parking brake button should be activated to close the electromechanical parking brake.

Remove the rear noise insulation. Refer to Removal and Installation .

Place the V.A.G 1782 under the transmission.

WARNINGDanger of eye injury. Wear protective eyewear.

Remove the ATF drain plug -arrow A- and drain the ATF.

CAUTIONThere is a risk of damaging the transmission. Do not start the engine when there is no ATF in the transmission.

Note. Follow the disposal requirements. Replace the ATF drain plug and seal.

Tighten the new drain plug -arrow A- to 12 Nm.

Fill the Transmission with ATF.

CAUTIONThere is a risk of damaging the transmission. Only use the ATF available as a replacement part for the automatic transmission 0B6. Other oils can cause malfunctions or transmission failure. For the correct allocation. The ATF filler tool must be clean and the ATF must not be mixed with any other ATF.

Fill the reservoir on the V.A.G 1924 with the ATF for the automatic transmission 0B6; for the correct ATF specification.

Secure reservoir of V.A.G 1924 as high as possible on vehicle.

Remove ATF inspection plug -arrow B-.

Guide filler hook of V.A.G 1924 from underneath into an opening in the cap -arrow-.

Add ATF using V.A.G 1924 until ATF drips from the check hole.

Move the selector lever into P.

Start the engine, wait 20 seconds and then turn it off.

Add ATF using V.A.G 1924 until ATF drips from the check hole.

Start the engine.

Continue to add ATF using the V.A.G 1924 until ATF starts to come out again from the check hole.

Tighten the ATF inspection plug.

While pressing the brake pedal and with the vehicle idling, shift through all the selector lever positions (P, R, N, D, S) leaving each position engaged for at least 10 seconds.

Move the selector lever into N.

Increase the RPM to 2000 and hold it there for at least 60 seconds.

Move the selector lever into P.

Check the ATF level and correct if necessary. Refer to ATF, CHECKING LEVEL AND CORRECTING .

Note. Follow the instructions and test requirements for checking the ATF level.

Install the rear noise insulation. Refer to Removal and Installation .

Scheme 371

Scheme 371: ELECTRICAL AND ELECTRONIC COMPONENTS AND COMPONENT LOCATIONS
Scheme 371: ELECTRICAL AND ELECTRONIC COMPONENTS AND COMPONENT LOCATIONS
  1. Installed location: The Data Link Connector (DLC) for the vehicle diagnosis, testing and information system VAS 5051B is located in the driver side footwell.

Mechatronic, Transmission Control Module -J217-, Multifunction Transmission Range Switch -F125-, Transmission Input Speed Sensor -G182- and Transmission Output Speed Sensor -G195

Scheme 372

Scheme 372
Scheme 372
  1. Installed location: The mechatronic unit is bolted to the bottom of the transmission housing and is covered by the transmission fluid pan.

The Mechatronic unit incorporates the hydraulic control, the transmission control module, the multifunction transmission range switch and the sensors and actuators as a complete synchronized unit. The following are part of

  1. Transmission control module -J217
  2. Multifunction transmission range switch -F125
  3. Transmission input speed sensor -G182
  4. Transmission output speed sensor -G195

Only the complete Mechatronic unit can be replaced.

Note. OBD checks all the components named.

Wiring Harness in Transmission

Scheme 373

Scheme 373
Scheme 373
  1. Installed location: The connector -C- attached the wiring harness -A- on the Mechatronic -B-.

Transmission Range Display -Y6

Scheme 374

Scheme 374
Scheme 374
  1. Installed location: The transmission range display is integrated in the instrument cluster.

Note. The instrument cluster must be replaced if the transmission range display is faulty. Refer to Removal and Installation .

Scheme 375

Scheme 375
Scheme 375
  1. Installed location: The selector lever sensor system control module and the tiptronic switch are a single unit -2-, which is clipped to the selector mechanism function unit -arrows-.

Note. Ignore -arrow A-.

Scheme 376

Scheme 376
Scheme 376
  1. Installed location: The shift lock solenoid -1- is clipped to the selector mechanism.

Scheme 377

Scheme 377
Scheme 377
  1. Installed location: The transmission park selector switch, which consists of two reed contacts -1- and - 2-, is installed on the circuit board -B- on the shift lock solenoid -A-.

Note. The transmission park selector switch can only be replaced together with the shift lock solenoid.

Scheme 378

Scheme 378
Scheme 378

Note. A specific value from the accelerator pedal position sensor -G79- and the accelerator pedal position sensor -G185- is stored in the engine control module.

  1. Installation location: Accelerator pedal position sensors are integrated inside the accelerator pedal module -arrow-.

Note. If the accelerator pedal sensor is faulty, then replace the accelerator pedal module. Refer to Removal and Installation .

Scheme 379

Scheme 379
Scheme 379
  1. Installed location: The selector lever transmission range position display unit -1- is inside the center console.

SELECTOR MECHANISM OVERVIEW

WARNINGThere is a risk of injury and accident from accidentally engaging a gear when the engine is running. Before work is done with the engine running, move the selector lever into P and press the parking brake button to engage the electromechanical parking brake.

Before disassembling the selector mechanism, perform check. Refer to SELECTOR MECHANISM, CHECKING .

Scheme 380

Scheme 380
Scheme 380
  1. Selector Lever Handle Refer to «SELECTOR LEVER HANDLE AND SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant)
  2. Decorative Ring Removing and installing, refer to «SELECTOR LEVER HANDLE AND SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant)
  3. Selector Lever Boot Removing and installing, refer to «SELECTOR LEVER HANDLE AND SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant)
  4. Clamp For securing the selector lever handle to the selector lever Removing and installing, refer to «SELECTOR LEVER HANDLE AND SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant)
  5. Selector Lever Transmission Range Position Display -Y26- Refer to «SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-lever-transmission-range-position-display)
  6. Nut 10 Nm Quantity: 4 For securing the shift mechanism to the body
  7. Rubber Seal
  8. Selector Lever Sensor System Control Module -J587- with Tiptronic Switch -F189- Refer to «SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE WITH TIPTRONIC SWITCH»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-lever-sensor-system-control-module)
  9. Selector Mechanism Function Unit Can only be replaced as a unit Refer to «SHIFT MECHANISM FUNCTION UNIT»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__shift-mechanism-function-unit)
  10. Shift Lock Solenoid -N110- Refer to «Shift Lock Solenoid -N110»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__shift-lock-solenoid-n110)
  11. Transmission Park Selector Switch -F305- Consists of two microswitches on the circuit board on the shift lock solenoid Can only be replaced together with the shift lock solenoid, refer to «Shift Lock Solenoid -N110»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__shift-lock-solenoid-n110)
  12. Noise Insulation Not on all vehicles; for the correct allocation.
  13. Lock Washers Quantity: 4 Removing and installing For securing the noise insulation to the shift mechanism function unit
  14. Retaining Clip Secures selector lever cable on selector mechanism function unit
  15. O-ring Removing and installing
  16. Selector Lever Cable Do not bend There are different versions depending on the vehicle. For the correct allocation. Refer to «SELECTOR LEVER CABLE ASSEMBLY OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant) Lightly lubricate ball socket with polycarbamide grease G 052 142 A2 before installing.
  17. Cover Over the shift lock solenoid

Scheme 381

Scheme 381: SELECTOR LEVER CABLE ASSEMBLY OVERVIEW
Scheme 381: SELECTOR LEVER CABLE ASSEMBLY OVERVIEW
  1. Clip For selector lever cable Removing and installing
  2. Bolt 8 Nm Quantity: 2
  3. Selector Lever Cable Do not bend Refer to «SELECTOR LEVER CABLE»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-lever-cable) The selector lever cable must be replaced if the rubber grommet is damaged. Lightly lubricate ball socket with polycarbamide grease G 052 142 A2 before installing. Make sure the rubber grommet on the transmission side is not twisted when installing. Refer to «SELECTOR LEVER CABLE, ADJUSTING»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-lever-cable-adjusting)
  4. Cable Mounting Bracket
  5. Bolt 13 Nm For selector lever cable adjustment Secured on the shift mechanism function unit
  6. O-ring Removing and installing
  7. Selector Shaft Lever

SELECTOR LEVER CABLE, ADJUSTING

Special tools and workshop equipment required

  1. Trim Removal Wedge 3409
  2. Socket and Key T40031

Procedure

  1. Tightening specification, refer to «SELECTOR LEVER CABLE ASSEMBLY OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant) .

Pry the selector lever boot frame -1- out of the center console -arrows- using the 3409.

Scheme 382

Scheme 382
Scheme 382

Move the selector lever into D.

Through opening -arrow- in shift mechanism, loosen bolt on selector lever cable approximately one turn using the T40031.

Scheme 383

Scheme 383
Scheme 383

Note. Loosen the clamping screw approximately one turn but do not remove it. The clamping screw is only accessible when the selector lever is in D. The selector lever must remain in D when the clamping screw is loose.

Carefully move the selector forward and back gently without shifting into another selector lever position. This releases the tension in the selector lever cable.

Move the selector lever into the tiptronic gate.

Note. Do not touch the selector lever during the adjusting.

Tighten the clamping screw in this position with the T40031 without touching the selector lever.

Selector mechanism, checking, refer to SELECTOR MECHANISM, CHECKING .

If shift mechanism does not function properly after adjusting selector lever cable

Bring the selector lever cable into the basic setting. Refer to SELECTOR LEVER CABLE, BRINGING INTO BASIC SETTING .

SELECTOR LEVER CABLE, BRINGING INTO BASIC SETTING

Special tools and workshop equipment required

  1. Pry Lever - Rmv Outside Mirror 80 - 200
  2. Trim Removal Wedge 3409
  3. Vehicle Diagnosis, Testing and Information System VAS 5051B
  4. Socket and Key T40031

Procedure

  1. Guided fault finding with the VAS 5051B is completed and all faults have been corrected.

Select the following menu entries on the VAS 5051B in Function/Component Selection Guided Fault Finding

  1. Drive
  2. 0B6-Transmission
  3. 01-On Board Diagnostic (OBD) Capable Systems
  4. 02-Transmission Electronics
  5. 02-Transmission Electronics Functions
  6. 02-Read Measure Value Block

Select the measured value gear on the VAS 5051B.

Compare the following displays

  1. Measured value gear on the VAS 5051B
  2. Selector lever position
  3. Selector lever transmission range position display unit -Y26- on the shift mechanism
  4. Transmission range display -Y6- in the instrument cluster

Conditions

  1. The displays must match

If the displays do not match

Adjust selector lever cable. Refer to SELECTOR LEVER CABLE, ADJUSTING

If the individual displays cannot be reached by adjusting the selector lever cable

Selector Lever Cable, Bringing into Basic Setting

  1. Tightening specification, refer to «SELECTOR LEVER CABLE ASSEMBLY OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant) .

Pry the selector lever boot frame -A- out of the center console -arrows- using the 3409.

Move the selector lever into D.

Loosen the screw on the selector lever cable through the opening -arrow- in the selector mechanism one turn using the T40031.

Note. Only loosen the clamping screw - do not remove it. The clamping screw is only accessible when the selector lever is in D. The selector lever must remain in D when the clamping screw is loose.

Remove the ball socket -1- on the selector lever cable from the selector shaft lever using the 80 - 200.

Scheme 384

Scheme 384
Scheme 384

Note. Do not bend or kink the selector lever cable. Lubricate the cable eye and the ball socket on the selector lever cable with polycarbamide greaseG 052 142 A2 before installing. Ignore -2-.

Push the selector shaft lever -1- on the transmission all the way back -arrow-, until the parking lock engages.

Scheme 385

Scheme 385
Scheme 385

Note. When parking lock is engaged, it must not be possible to turn both front wheels in one direction at the same time.

Press the selector shaft lever forward three detents so the transmission is in D.

Make sure the selector lever inside the vehicle is also in D.

Select the 02 - Transmission Electronics and then Read Measure Value Block on the VAS 5051B in Guided Fault Finding

Select measured value gear on the VAS 5051B.

Compare the following displays

  1. Measured value gear on the VAS 5051B
  2. Selector lever position
  3. Selector lever transmission range position display unit -Y26- on the shift mechanism
  4. Transmission range display -Y6- in the instrument cluster

Conditions

  1. The displays must match

Carefully press the selector lever cable ball socket -1- in this position onto the selector shaft lever.

Note. Do not bend selector shaft lever when pressing on, otherwise shift mechanism can no longer be adjusted exactly. Ignore -2-.

Adjust the selector lever cable. Refer to SELECTOR LEVER CABLE, ADJUSTING .

Selector mechanism, checking, refer to SELECTOR MECHANISM, CHECKING .

Scheme 386

Scheme 386: SELECTOR LEVER HANDLE AND SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT OVERVIEW
Scheme 386: SELECTOR LEVER HANDLE AND SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT OVERVIEW
  1. Clamp For securing handle to selector lever Removing and installing, refer to «SELECTOR LEVER HANDLE»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-lever-handle) Removing and installing
  2. Decorative Ring Removing and installing, refer to «SELECTOR LEVER BOOT, SEPARATING FROM HANDLE»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-lever-boot-separating-from-handle)
  3. Selector Lever Handle «SELECTOR LEVER HANDLE»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-lever-handle)
  4. Selector Lever Boot Refer to «SELECTOR LEVER BOOT, SEPARATING FROM HANDLE»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-lever-boot-separating-from-handle)
  5. Selector Lever Transmission Range Position Display -Y26- Refer to «SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-lever-transmission-range-position-display)

Scheme 387

Scheme 387: TUNNEL CROSSMEMBER, TRANSMISSION MOUNT AND TRANSMISSION SUPPORT OVERVIEW
Scheme 387: TUNNEL CROSSMEMBER, TRANSMISSION MOUNT AND TRANSMISSION SUPPORT OVERVIEW
  1. Nut 20 Nm Only remove if the transmission mount must be separated from the transmission support
  2. Bolt 70 Nm
  3. Bolt 40 Nm
  4. Nut 20 Nm
  5. Transmission Support Refer to «TRANSMISSION SUPPORT WITH TRANSMISSION MOUNT»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__transmission-support-with-transmission-mount)
  6. Transmission Mount Refer to «TRANSMISSION MOUNT»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__transmission-mount)
  7. Lower Stop For the transmission mount
  8. Bolt 20 Nm plus an addition 90° turn Only remove if the transmission mount must be separated from the transmission support
  9. Tunnel Crossmember Refer to «TUNNEL CROSSMEMBER»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__tunnel-crossmember)

AUTOMATIC TRANSMISSION FLUID COOLER AND LINES OVERVIEW

Note. Clean working conditions for the automatic transmission. Refer to CLEAN WORKING CONDITIONS . General Repair Instructions, refer to REPAIR INFORMATION . Seal any open lines and connections with a clean plug from the engine plug set VAS 6122. Check ATF level after replacing ATF pipes. Refer to ATF, CHECKING LEVEL AND CORRECTING

CAUTIONThere is a risk of damaging the transmission. Remove all the plugs on the ATF pipes and on the transmission that were installed during removal. The ATF cooling function will not work and the transmission will be damaged if the plugs are forgotten.

Scheme 388

Scheme 388
Scheme 388
  1. ATF Cooler Integrated in the coolant cooler Removing and installing, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/cooling-fan/#20l-cooling-system-engine-codes-caeb-avant)
  2. O-ring Removing and installing Coat with ATF before inserting
  3. ATF Pipe, Return From the ATF cooler to the transmission Before removal, mark the ATF pipes in relation to each other so they are not switched.
  4. O-ring Removing and installing Coat with ATF before inserting
  5. ATF Pipe, Supply From the transmission to the ATF cooler Before removal, mark the ATF pipes in relation to each other so they are not switched.
  6. Bolt 5 Nm First insert the ATF pipes with new O-rings by hand as far as the stop
  7. ATF Pipe, Supply From the transmission to the ATF cooler Before removal, mark the ATF pipes in relation to each other so they are not switched. Nuts on lines, 29 Nm The ATF pipes are secured to each other
  8. Bolt 8 Nm
  9. Bracket
  10. ATF Pipe, Return From the ATF cooler to the transmission Before removal, mark the ATF pipes in relation to each other so they are not switched. Nuts on lines, 29 Nm The ATF pipes are secured to each other
  11. Bolt 20 Nm First insert the ATF pipes with new O-rings by hand as far as the stop The retaining tab on the lower ATF pipe must lie on the transmission threads The retaining tab on the upper ATF pipe must lie on the lower one.
  12. O-ring Removing and installing Coat with ATF before inserting

AUTOMATIC TRANSMISSION COOLER AND LINES OVERVIEW

Note. Clean working conditions for the automatic transmission. Refer to CLEAN WORKING CONDITIONS . General repair instructions, refer to REPAIR INFORMATION . Seal any open lines and connections with a clean plug from the engine plug set VAS 6122. Check ATF level after replacing ATF pipes. Refer to ATF, CHECKING LEVEL AND CORRECTING

CAUTIONThere is a risk of damaging the transmission. Remove all the plugs on the ATF pipes and on the transmission that were installed during removal. The ATF cooling function will not work and the transmission will be damaged if the plugs are forgotten.

Scheme 389

Scheme 389
Scheme 389
  1. O-ring Removing and installing Coat with ATF before inserting
  2. ATF Pipe, Supply Connection piece on ATF cooler With connector coupling -14
  3. Bolt 5 Nm First insert the ATF pipes with new O-rings by hand as far as the stop
  4. Bolt 9 Nm Secures the ATF pipe on the engine
  5. ATF Pipe, Return From the ATF cooler to the transmission With connector coupling -14
  6. ATF Pipe, Supply From the transmission to the ATF cooler
  7. Screw 23 Nm Secures the ATF pipe with the driveshaft heat shield
  8. Nut 8 Nm Secures the ATF pipe on the engine
  9. O-ring Removing and installing Coat with ATF before inserting
  10. Transmission
  11. Bolt 20 Nm First insert the ATF pipes with new O-rings by hand as far as the stop The retaining tab on the lower ATF pipe must fit inside the threaded hole in the transmission. The retaining tab on the upper ATF pipe must touch the bottom one.
  12. O-ring Removing and installing Is installed in the connector coupling -14-. Coat with ATF before inserting
  13. Clip To separate the connector coupling -14-, remove the securing clip. To install the ATF pipe on the connector coupling, first let the clip engage 3 times in the connector coupling.
  14. Connector Coupling To disconnect the ATF pipe, remove the clip -13-. To install the ATF pipes, connect the clip -13- and replace the O-ring -12-. Slide the ATF pipes together and let them engage.
  15. Connector Piece For the connector coupling
  16. ATF Pipe, Return Connection piece on ATF cooler From the ATF cooler to the transmission Connected with the connector coupling -14
  17. ATF Cooler Integrated in the coolant cooler Removing and installing, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/cooling-fan/#20l-cooling-system-engine-codes-caeb-avant) .

FASTENER TIGHTENING SPECIFICATIONS

ComponentBolt SizeNm
Bolts and Nuts
M69
M715
M820
M1040
M1265
ATF Inspection Plug9
Cable Mounting Bracket8
Transmission Support
Nut20
Bolt40
Lower Stop20 + 90°
Selector Lever Cable13
Shift mechanism to the body10
Tunnel Crossmember
Nut20
Bolt70
4 and 6 Cylinder
ATF Line, Return
8 2
20 2
ATF Pipe, Supply Nuts on Lines29
ATF Pipe, Supply5
8-Cylinder
ATF Line, Return
9 1
23 1
ATF Line, Supply
Bolt9
Nut8
ATF Pipe, Supply to ATF Cooler5
Transmission20
1 For bolt tightening clarification, refer to AUTOMATIC TRANSMISSION COOLER AND LINES OVERVIEW and see items -4 and 7- 2 For bolt tightening clarification, refer to AUTOMATIC TRANSMISSION FLUID COOLER AND LINES OVERVIEW and see items -8 and 11

Driveshaft Heat Shield - Tightening Specification

Tighten the heat shield bolts -arrows- to 23 Nm.

Scheme 390

Scheme 390
Scheme 390

Securing Engine to Transmission (4-Cylinder)

Scheme 391

Scheme 391
Scheme 391
ItemBoltNm
1 1)M10 x 50 2)65
2 1) , 7M12 x 100 3)4)30 + 90°
3, 6M12 x 75 3)4)30 + 90°
4, 5M12 x 120 3)4)30 + 90°
8, 10M10 x 75 3)4)15 + 90°
9M10 x 60 3)4)15 + 90°
11 5)M12 x 50 3)4)30 + 90°
AAlignment sleeves for centering
1) Also secures the starter. 2) Bolt strength rating 10.9. There is no limit to the number of times the steel bolt can be used again. 3) Audi A4 through VIN 8K-9A-066499, Audi A5 through VIN 8T-9A-007999: replace the aluminum bolts. 4) Audi A4 from VIN 8K-9A-066500, Audi A5 from VIN 8T-9A-008000: the aluminum bolts may be used two times. see scheme 181 5) Attaches the engine to the transmission.

Securing Engine to Transmission (6-Cylinder)

Scheme 392

Scheme 392
Scheme 392
ItemBoltNm
1M10 x 50 1)65
2 to 6M12 x 100 2)3)30 + 90°
7M12 x 125 2)3)30 + 90°
8, 11M10 x 60 2)3)15 + 90°
9, 10M10 x 95 2)3)15 + 90°
AAlignment sleeves for centering
1) bolt strength rating 10.9. There is no limit to the number of times the steel bolt can be used again. 2) Audi A4 through VIN 8K-9A-066499, Audi A5 through VIN. 8T-9A-007999: replace the aluminum bolts. 3) Audi A4 from VIN 8K-9A-066500, Audi A5 from VIN 8T-9A-008000: the aluminum bolts may be used two times. see scheme 181

Securing Engine to Transmission (8-Cylinder)

ItemBoltNm
1M10 x 50 1)65
2 to 6M12 x 100 3)4)30 + 90°
7M12 x 175 2)3)30 + 90°
8, 11M10 x 60 2)3)15 + 90°
9M10 x 75 2)3)15 + 90°
10M10 x 95 2)3)15 + 90°
AAlignment sleeves for centering
1) Bolt strength rating 10.9. There is no limit to the number of times the steel bolt can be used again. 2) Audi A4 through VIN 8K-9A-066499, Audi A5 through VIN. 8T-9A-007999: replace the aluminum bolts. 3) Audi A4 from VIN 8K-9A-066500, Audi A5 from VIN 8T-9A-008000: the aluminum bolts may be used two times. see scheme 181

SELECTOR MECHANISM, CHECKING

Overview

  1. 1. Selector mechanism function test «1. SELECTOR MECHANISM FUNCTION TEST»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__1-selector-mechanism-function-test)
  2. 2. Checking the ignition key lock, refer to «2. CHECK IGNITION KEY WITHDRAWAL LOCK»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__2-check-ignition-key-withdrawal-lock)
  3. 3. Selector lever handle locking button, checking «3. CHECK LOCKING BUTTON IN THE SELECTOR LEVER HANDLE»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__3-check-locking-button-in-the)

1. SELECTOR MECHANISM FUNCTION TEST

  1. The starter does not work when the selector lever is in S, D, R or in the tiptronic gate
  2. If selector lever position N is selected at speeds greater than 5 km/h, the shift lock solenoid must not engage and block the selector lever. The selector lever can be moved into a another gear.
  3. For speeds below 2 km/h (almost standstill) and shifting into selector lever position N, the shift lock solenoid must only engage after approximately 1 second. The selector lever can be move out of N only when the brake pedal is pressed.

Selector lever in P

Press the button on the parking brake to activate it.

Press the key briefly in the ignition lock to reach the ignition on position.

Do not press the brake pedal.

  1. The selector lever is locked and cannot be moved out of P while locking button on selector lever handle is pressed. The shift lock solenoid -N110- locks the selector lever.

Press the brake pedal and hold it down.

  1. The shift lock solenoid unlocks the selector lever. It is not possible to shift into a gear. Press the locking button in the selector lever handle and slowly move the selector lever out of P through R, N, D, S. While doing this, make sure the transmission range display -Y6- inside the instrument cluster matches the actual position of the selector lever.

The selector lever is in N and the ignition is turned on

Do not press the brake pedal.

  1. After a brief moment: The selector lever is locked and cannot be moved out of N even though the locking button in the selector lever handle is pressed. The shift lock solenoid locks the selector lever.

Press the brake pedal.

  1. The shift lock solenoid unlocks the selector lever. It is possible to shift into D.

The selector lever is in D and the ignition is turned on

Move the selector lever into the tiptronic gate.

  1. The D in the selector lever transmission range position display unit -Y26- must turn off and the plus and minus must turn on.
  2. The transmission range display inside the instrument cluster must change from D to M1 when the selector lever is moved into the tiptronic gate.

Perform a guided fault finding if the specified values are not reached.

Adjust the selector lever cable. Refer to SELECTOR LEVER CABLE, ADJUSTING .

Selector lever handle locking button, checking 3. CHECK LOCKING BUTTON IN THE SELECTOR LEVER HANDLE

Check ignition key removal lock.

2. CHECK IGNITION KEY WITHDRAWAL LOCK

Press the button on the parking brake to activate it.

Do not press the brake pedal.

Press the key briefly in the ignition lock to reach the ignition on position.

Press the brake pedal and hold it down.

  1. It must be possible to move the selector lever out of P without getting stuck when the locking button in the selector lever handle is pressed.

Turn off the ignition.

  1. It should not be possible to remove the ignition key when the selector lever is in any other position than P.

Move the selector lever into P.

Remove the key.

  1. It should be possible to remove the key only when the selector lever is in P.
  2. It is not possible to move the selector lever out of P when both the locking button and the brake pedal are pressed.

If the ignition key lock does not work as described, perform guided fault finding.

3. CHECK LOCKING BUTTON IN THE SELECTOR LEVER HANDLE

Make sure locking button moves easily.

  1. It must be possible to press the locking button without using great force.
  2. After releasing, the locking button must come all the way back out by itself.

Check the selector lever handle for correct installation if the specified values are not reached. Refer to SELECTOR LEVER HANDLE .

Check if the selector rod or selector lever is bent.

Function test

  1. The ignition is switched on.

The locking button on the selector lever handle must be pressed for the following shifts. If it is not pressed, the selector lever cannot be shifted into the specified position.

  1. Move the selector lever from P into R and press the brake pedal at the same time.
  2. D into S
  3. N into R; stationary, press the brake pedal after waiting longer
  4. R into P

Check the selector lever handle for correct installation if the specified values are not reached. Refer to SELECTOR LEVER HANDLE .

Perform guided fault finding and check the shift lock solenoid.

Adjust the selector lever cable. Refer to SELECTOR LEVER CABLE, ADJUSTING .

SHIFT LOCK SOLENOID -N110

Removing

Move the selector lever into P.

Remove the multimedia system control head -E380-. Refer to Removal and Installation .

Remove the front ashtray. Refer to Removal and Installation .

Scheme 393

Scheme 393: SHIFT LOCK SOLENOID -N110
Scheme 393: SHIFT LOCK SOLENOID -N110

Loosen the nuts -1, 3, 5 and 6- a few turns but do not remove them completely.

Scheme 394

Scheme 394
Scheme 394

Note. This lowers the shift mechanism function unit slightly for better accessibility.

CAUTIONThe shift mechanism can be destroyed by broken clips, tabs or other objects. Make sure no components or other objects fall into the shift mechanism. The shift mechanism must be replaced if that happens.

Open the retaining tabs -2- and -3- in the direction of the -arrow-, slightly raise the front of the sealing cap -A- and hold it in that position.

Scheme 395

Scheme 395
Scheme 395

Note. This prevents the retaining tabs from engaging again.

Using a screwdriver, open the upper retaining tab -1- on the cover in the direction of the -arrow- over the bracket -B- and remove the cover -A- upward.

Disconnect the electrical connector on the shift lock solenoid.

Press the hooks -A- into the selector mechanism -arrow- and hold them in this position.

Scheme 396

Scheme 396
Scheme 396

Note. Replace the selector mechanism function unit if any of the hooks -A- are broken off.

Tilt the shift lock solenoid in direction of the -arrow- so that the ball head -1- comes out of the lever on the selector mechanism.

Remove the shift lock solenoid.

Installing

Install in reverse order, paying attention to the following

  1. Tightening specification, refer to «SELECTOR MECHANISM OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-mechanism-overview) .

Turn the ball head -1- into the correct installed position.

Install the shift lock solenoid at an angle into the selector mechanism and then tilt it opposite the direction of the -arrow-.

  1. The ball head -1- must engage completely in the operating lever on shift mechanism. Press it down using a small screwdriver if necessary.

Attach the shift lock solenoid to the hook -A-.

Position the cover -A- over the shift lock solenoid and carefully lock it in -1 through 3-.

Connect the electrical connectors.

Check the shift mechanism function before completing assembly. Refer to SELECTOR MECHANISM, CHECKING .

Install the front ashtray. Refer to Removal and Installation .

Install the multimedia system control head. Refer to Removal and Installation .

SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE WITH TIPTRONIC SWITCH

Note. The selector lever sensor system control module -J587- and the tiptronic switch -F189- are a single component.

Removing

Remove the selector lever handle. Refer to SELECTOR LEVER HANDLE .

Remove the multimedia system control head -E380-. Refer to Removal and Installation .

Remove the front ashtray. Refer to Removal and Installation .

Disconnect the connector -1-.

Open the four tabs -arrows- and remove the selector lever sensor system control module and tiptronic switch upward.

Note. Ignore -arrow A-.

Installing

Install in reverse order, paying attention to the following

Install the selector lever sensor system control module with the tiptronic switch into the four tabs -arrows-.

Attach the wire to the selector lever transmission range position display unit -Y26- -arrows-.

Install the front ashtray. Refer to Removal and Installation .

Install the multimedia system control head. Refer to Removal and Installation .

Install the selector lever handle. Refer to SELECTOR LEVER HANDLE .

SELECTOR LEVER CABLE

Special tools and workshop equipment required

  1. Pry Lever - Rmv Outside Mirror80 - 200
  2. Trim Removal Wedge3409
  3. Socket and KeyT40031

Removing

Press the button on the parking brake to activate it.

Move the selector lever into D.

Pry the selector lever boot frame -A- out of the center console -arrows- using the 3409.

Insert the T40031 through the opening -arrow- in the selector mechanism and loosen the bolt on the selector lever cable one turn.

Note. Only loosen the clamping screw - do not remove it. The clamping screw is only accessible when the selector lever is in D. The selector lever must remain in D when the clamping screw is loose.

Remove the left front muffler. Refer to Description and Operation .

Remove the bolts -arrows- and remove the driveshaft heat shield -1-.

Scheme 397

Scheme 397
Scheme 397

Remove the ball socket -1- on the selector lever cable from the selector shaft lever using the 80 - 200.

Remove the clip -2- and remove the selector lever cable from the transmission.

Note. Do not bend or kink the selector lever cable.

Remove the four lock washers -1-.

Scheme 398

Scheme 398
Scheme 398

Note. Replace the lock washers.

Remove the noise insulation -2- and slide it forward.

Remove the circlip -1- from the selector lever cable.

Scheme 399

Scheme 399
Scheme 399

Remove the selector lever cable -2- from the selector mechanism.

Installing

Install in reverse order, paying attention to the following

  1. Tightening specifications, refer to «SELECTOR LEVER CABLE ASSEMBLY OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant) .

Note. Replace the O-ring on the selector lever cable. Lubricate the cable eye and the ball socket on the selector lever cable with polycarbamide greaseG 052 142 A2 before installing.

Slide the noise insulation -2- over the opening on the selector lever cable -3-.

Install the O-ring -1- on the selector lever cable.

Scheme 400

Scheme 400
Scheme 400

Install the selector lever cable -2- into the gearshift mechanism function unit -arrow-.

Secure the selector lever cable -2- with the circlip -3-.

  1. Installed position: The angled end of the circlip -1- faces the selector mechanism.

Install the noise insulation -2- with four new lock washers -1-.

Push the selector shaft lever -1- on the transmission all the way back -arrow-, until the parking lock engages.

Note. When parking lock is engaged, it must not be possible to turn both front wheels in one direction at the same time.

Press the selector shaft lever forward three detents so the transmission is in D.

Make sure the selector lever inside the vehicle is also in D.

Carefully press the selector lever cable ball socket -1- in this position onto the selector shaft lever.

Note. Do not bend selector shaft lever when pressing on, otherwise shift mechanism can no longer be adjusted exactly.

Attach the selector lever cable with clips -2-.

Note. Do not bend or kink the selector lever cable.

Check the selector lever cable and adjust if necessary. Refer to SELECTOR LEVER CABLE, ADJUSTING .

Selector mechanism, checking. Refer to SELECTOR MECHANISM, CHECKING .

TRANSMISSION PARK SELECTOR SWITCH -F305

  1. Installed location: The transmission park selector switch, which consists of two reed contacts -1- and - 2-, is installed on the circuit board -B- on the shift lock solenoid -N110- -A-.

The transmission park selector switch can only be replaced together with the shift lock solenoid. Refer to Shift Lock Solenoid -N110 .

SHIFT MECHANISM FUNCTION UNIT

Special tools and workshop equipment required

  1. Pry Lever - Rmv Outside Mirror 80 - 200
  2. Counterhold Tool T10172 with Adapter T10172/5

Removing

Remove the front muffler or front exhaust pipe. Refer to Removal and Installation .

Remove the bolts -arrows- and remove the driveshaft heat shield -1-.

Remove the bolts that connect the drivehaft to the transmission by counterholding them with the T10172 and T10172/5.

Scheme 401

Scheme 401
Scheme 401

Press the driveshaft together with rear final drive; the universal joint is able to slide axially.

Allow the driveshaft to hang down.

Loosen the fasteners -arrows- and remove the heat shield -1-.

Scheme 402

Scheme 402
Scheme 402

Remove the ball socket -1- on the selector lever cable from the selector shaft lever using the 80 - 200.

Remove the clip -2- and remove the selector lever cable from the transmission.

Note. Do not bend or kink the selector lever cable.

Remove the multimedia system control head -E380-. Refer to Removal and Installation .

Remove the front ashtray. Refer to Removal and Installation .

Disconnect the connectors -2- and -4-.

Remove the insulation mat over the shift mechanism.

Note. The illustration does not show the insulation mat. A second technician is required when detaching shift mechanism below vehicle.

Remove the bolts -1, 3, 5 and 6-.

Note. Depending on the version, the clips -arrows- may not be installed so the shift mechanism may fall down after removing the bolts.

Remove the selector mechanism downward.

Installing

Install in reverse order, paying attention to the following

  1. Tightening specifications, refer to «SELECTOR MECHANISM OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-mechanism-overview) .

Note. Lubricate the ball socket on the selector lever cable with polycarbamide greaseG 052 142 A2 before installing. Do not bend or kink the selector lever cable.

Adjust the selector lever cable. Refer to SELECTOR LEVER CABLE, ADJUSTING .

Selector mechanism, checking. Refer to SELECTOR MECHANISM, CHECKING .

Install the driveshaft. Refer to REMOVAL AND INSTALLATION or Removal and Installation .

Install the front muffler or front exhaust pipe. Refer to Removal and Installation .

Install the front ashtray. Refer to Removal and Installation .

Install the multimedia system control head. Refer to Removal and Installation .

SELECTOR LEVER HANDLE

Special tools and workshop equipment required

  1. Trim Removal Wedge 3409
  2. Hose Clamp Pliers V.A.G 1275

Removing

Move the selector lever into N.

Note. Both the selector lever handle and the selector lever boot are removed.

Pry the selector lever boot frame -1- out of the center console -arrows- using the 3409.

Secure the locking button in its extended position with a cable tie -arrow- as illustrated.

Scheme 403

Scheme 403
Scheme 403

Fold the selector lever boot -1- upward and over the selector lever handle -2-.

Scheme 404

Scheme 404
Scheme 404

Open the clamp -arrow- and remove the selector lever handle with the selector lever boot without touching the locking button.

Installing

Note. In order to install the selector lever handle, the locking button must be pulled out all the way and secured either with a cable tie -arrow- or with the assembly tool supplied with a new handle. If the lock button was not secured, do not pull it out from the handle using mechanical aids. Mount the compressed air gun to the bottom of the handle and then push the locking button out with compressed air.

Install the new clamp -arrow- on the selector lever handle.

Install the selector lever handle all the way onto the selector lever - make sure the locking button faces the driver.

  1. When doing this, handle must engage into ring groove of the selector lever.

Remove the cable ties or assembly aids. The locking button mechanism will engage in the vertical groove on the selector lever. Press the locking button into the selector lever handle if necessary.

Move the selector lever into R and S to check the function of the buttons.

  1. If the selector lever positions cannot be reached, remove the handle again. Refer to «SELECTOR LEVER HANDLE»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__selector-lever-handle) .

Secure the selector lever handle -C- to the selector lever with the clamp -A-. Use V.A.G 1275.

Install the selector lever boot frame -B- in the center console.

SELECTOR LEVER BOOT, SEPARATING FROM HANDLE

Removing

Remove the selector lever handle. Refer to SELECTOR LEVER HANDLE .

Bind together the spring tabs -A- on the selector lever handle using a cable tie -B- as illustrated.

Scheme 405

Scheme 405: SELECTOR LEVER BOOT, SEPARATING FROM HANDLE
Scheme 405: SELECTOR LEVER BOOT, SEPARATING FROM HANDLE

Slide the sleeve -C- for the selector lever boot over the tabs -arrow-.

Remove the cable tie and the sleeve with the selector lever boot from the selector lever.

Installing

Install in reverse order, paying attention to the following

Selector lever boot installed position

  1. The longer side of the frame for the selector lever boot faces the driver.

Install the selector lever handle. Refer to SELECTOR LEVER HANDLE .

SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT

Removing

Move the selector lever into N.

Unclip the frame -A- from the center console and remove it -arrows-.

Fold selector lever boot up.

Release the spring -2- and remove the selector lever transmission range position display unit -Y26- -1- -arrow-.

Disconnect the electrical connector.

Installing

Installation is in reverse order of removal.

TUNNEL CROSSMEMBER

Special tools and workshop equipment required

  1. Engine/Transmission Jack V.A.G 1383 A
  2. Transmission Support T10337

Removing

Remove the rear noise insulation. Refer to Removal and Installation .

Install the T10337 on the V.A.G 1383 A.

Scheme 406

Scheme 406
Scheme 406

Position the T10337 on the bottom of the transmission.

Lift the transmission slightly using the V.A.G 1383 A.

WARNINGThere is the risk of an accident. The V.A.G 1383 A may only be used during assembly and must not sit unsupervised under the vehicle.

Remove the bolts from the tunnel crossmember -arrows-.

Remove the nuts -arrow- and the tunnel crossmember.

Scheme 407

Scheme 407
Scheme 407

Installing

Install in reverse order, paying attention to the following

  1. Tightening specifications, refer to «TUNNEL CROSSMEMBER, TRANSMISSION MOUNT AND TRANSMISSION SUPPORT OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant) .

Install the rear noise insulation. Refer to Removal and Installation .

TRANSMISSION SUPPORT WITH TRANSMISSION MOUNT

Removing

Remove the tunnel crossmember. Refer to TUNNEL CROSSMEMBER .

Remove the bolts -arrows- and the transmission support with the transmission mount from the transmission.

Scheme 408

Scheme 408: TRANSMISSION SUPPORT WITH TRANSMISSION MOUNT
Scheme 408: TRANSMISSION SUPPORT WITH TRANSMISSION MOUNT

Installing

Install in reverse order, paying attention to the following

  1. Tightening specifications, refer to «TUNNEL CROSSMEMBER, TRANSMISSION MOUNT AND TRANSMISSION SUPPORT OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant) .

Install tunnel crossmember. Refer to TUNNEL CROSSMEMBER .

TRANSMISSION MOUNT

Removing

Remove the transmission support with the transmission mount. Refer to TRANSMISSION SUPPORT WITH TRANSMISSION MOUNT .

Remove the bolts -1- and remove the lower stop -2- for the transmission mount.

Scheme 409

Scheme 409: TRANSMISSION MOUNT
Scheme 409: TRANSMISSION MOUNT

Remove the nut -4- and remove the transmission mount -5- from the transmission support.

Installing

  1. Tightening specifications, refer to «TUNNEL CROSSMEMBER, TRANSMISSION MOUNT AND TRANSMISSION SUPPORT OVERVIEW»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant) .

Mount the transmission support -3- on the transmission mount -5-.

Tighten the nut -4- hand-tight.

Tighten the lower stop -2- with the bolts -1-.

Tighten the nut -4-.

Install the transmission support and transmission mount. Refer to TRANSMISSION SUPPORT WITH TRANSMISSION MOUNT .

TRANSMISSION, REMOVING

Special tools and workshop equipment required

  1. Pry Lever - Rmv Outside Mirror 80 - 200
  2. Engine/Transmission Jack V.A.G 1383 A
  3. Step Ladder VAS 5085
  4. Engine Bung Set VAS 6122
  5. Counterhold Tool T10172 with Adapter T10172/5
  6. Transmission Support T40173
  7. Engine Support Bridge 10 - 222 A
  8. Counter Hold Tool T10355

Removing

Position the front wheels so they are straight.

Turn off the ignition and remove the key.

CAUTIONRisk of destroying electronic components when disconnecting the battery. Follow the instructions for disconnecting the battery. Refer to. Removal and Installation .

Disconnect the battery. Refer to Removal and Installation .

Carefully remove the engine cover from the pins in the direction of the -arrow-. Do not pull sharply on the engine cover or pull it to one side.

Scheme 410

Scheme 410
Scheme 410

Remove the left and right drive axle cover -1- inside the wheel housing.

Scheme 411

Scheme 411
Scheme 411

Remove the noise insulation. Refer to Removal and Installation .

Remove the front muffler or front exhaust pipe. Refer to Removal and Installation .

Remove the bolt -arrow- from the ATF pipes.

Scheme 412

Scheme 412
Scheme 412

Note. Lay a cloth under the separating point to prevent ATF from leaking out.

Remove the bolts -1- and -2- and remove the ATF pipes from the transmission, then secure them at the top.

Scheme 413

Scheme 413
Scheme 413

Seal any open lines and connections with a clean plug from the VAS 6122.

Remove the bolts -2 through 5- connecting the engine to transmission. They are accessible from above.

Note. The bolt -2- attaches the starter to the transmission and also has a spacer -arrow-. The spacer sleeve must be inserted between the starter and the transmission.

Position the 10 - 222 A with the adapter 10 - 222 A /3 on the left and right suspension strut towers as illustrated.

Scheme 414

Scheme 414
Scheme 414

Engage the spindle 10 - 222 A /11 on the engine lifting eyes.

Remove the bolts -arrows- and remove the heat shield from the right drive axle.

Remove left and right drive axles from transmission flange shafts.

CAUTIONThere is a risk of destroying the transmission control module (Mechatronic) with static discharge. Do not touch contacts in transmission connector with hands.

To discharge static electricity, touch the transmission housing (without wearing gloves).

Disconnect the connector on transmission by rotating screw connections counter-clockwise -arrow-.

Scheme 415

Scheme 415
Scheme 415

Free up the electrical wiring harness on the transmission.

Disconnect the connector -2- from the engine speed sensor -G28- and free up the wire.

Scheme 416

Scheme 416
Scheme 416

Note. Ignore -1-.

Remove the ball socket -1- on the selector lever cable from the selector shaft lever using the 80 - 200.

Remove the clip -2- and remove the selector lever cable from the transmission.

Note. Do not bend or kink the selector lever cable.

CAUTIONThe suspension components could be damaged. Do not rest the vehicle on its wheels if the subframe mount, the steering gear or the subframe crossbrace are not installed correctly.

All A4; A5 Coupe

Remove the nut -1- from the power steering hydraulic line.

Scheme 417

Scheme 417
Scheme 417

Remove the bolts -arrows- and remove the subframe crossbrace.

A5 Cabriolet

Remove the left and right bolt -2-.

Scheme 418

Scheme 418
Scheme 418

Note. Ignore -1-.

Remove the bolt -2- for the power steering hydraulic line.

Scheme 419

Scheme 419
Scheme 419

Remove the bolts -1- and -arrows- and the subframe crossbrace.

All Vehicles

CAUTIONThe airbag spiral spring could be damaged. Remove the steering column from the steering gear only when the front wheels are in the straight-ahead position. Do not change the steering wheel and steering gear position. Secure the steering wheel, for example using adhesive tape.

Lower the steering wheel as far as possible.

Turn the steering wheel into its center position (wheels in the straight-ahead position) and secure it.

Remove the bolt -arrow- from the steering column. Refer to Removal and Installation .

Scheme 420

Scheme 420
Scheme 420

Remove the steering column -1- from the steering gear -2- and slide it all the way up.

Scheme 421

Scheme 421
Scheme 421

Remove the bolt -1-, push the front exhaust pipe strap off the transmission and swivel it toward the rear -arrow-.

Scheme 422

Scheme 422
Scheme 422

Remove the bolts -arrows- and remove the driveshaft heat shield.

Remove the bolts that connect the driveshaft to the transmission by counterholding them with the T10172 and T10172/5.

Press the driveshaft together with rear final drive; the universal joint is able to slide axially.

Secure the driveshaft to the side.

Remove the lower cover -1- from the transmission -arrow-.

Scheme 423

Scheme 423
Scheme 423

Remove the 3 bolts -arrow- from the torque converter.

Scheme 424

Scheme 424
Scheme 424

To do this, turn the crankshaft on the vibration damper 120° and then counterhold it using the T10355.

Scheme 425

Scheme 425
Scheme 425

Note. Ignore -arrow-.

Remove the starter. Refer to Removal and Installation .

Note. The starter must be installed in order to install the locking piece -1- correctly in the starter opening when installing the transmission.

Remove the remaining bolts -6 through 11- that attach the engine to the transmission.

Position the V.A.G 1383 A and the T40173 under the transmission and secure it with the tensioning strap -1- as illustrated.

Scheme 426

Scheme 426
Scheme 426

Note. The T40173 is not illustrated.

Remove the bolts from the tunnel crossmember -arrows-.

Lower the transmission using the V.A.G 1383 A first to dimension -a-.

Scheme 427

Scheme 427
Scheme 427
  1. Dimension -a- = maximum 100 mm.

Slightly pre-tension both 10 - 222 A /11.

Press the transmission off the engine and lower it carefully using the V.A.G 1383 A.

TRANSMISSION, INSTALLING

Special tools and workshop equipment required

  1. Ring Spanner Insert AF16 V.A.G 1332/14
  2. Transportation Lock T40170

Procedure

Note. Replace bolts that are tightened to the specification. Replace self-locking nuts and bolts and seals, gaskets and O-rings. Secure all hose connections with hose clamps of the same type as those equipped by the factory. When installing, bring all cable ties back to same positions.

Transmission Installation Tightening Specifications: TRANSMISSION INSTALLATION TIGHTENING SPECIFICATIONS

Before installing a replacement transmission, always clean out the ATF cooler and ATF pipes using compressed air (maximum 10 bar). Refer to AUTOMATIC TRANSMISSION FLUID LINES, CLEANING .

Clean residue from the threaded holes in the cylinder block using a thread tap before installing.

When installing a replacement transmission, install the transmission support, the transmission mounting and the tunnel crossmember on the new transmission. Refer to TUNNEL CROSSMEMBER, TRANSMISSION MOUNT AND TRANSMISSION SUPPORT OVERVIEW .

Mount the transmission onto the T40173 and secure it using the tension strap -1- as illustrated.

The following preparations must be made before connecting the engine and transmission

Scheme 428

Scheme 428
Scheme 428

Turn the torque converter so that the hole next to the notch -arrow- is visible in the lower cut-out in the transmission housing as illustrated.

Note. There is only 1 notch on the circumference; rotate the torque converter as needed.

Insert the T40170 in the transmission housing from below and secure it on the flange shaft -1-.

Scheme 429

Scheme 429
Scheme 429

Check if the alignment sleeves -A- for centering the engine/transmission are in the cylinder block and insert them if they are not.

Inspect the aluminum bolts used to connect the engine to the transmission to see if they can be used again and mark them, if necessary TIGHTENING SPECIFICATIONS .

Place the transmission on the engine and tighten the bolts -6 through 11- that connect the engine to the transmission.

Remove the T40170.

Clip the locking piece -1- into the starter opening.

Scheme 430

Scheme 430
Scheme 430
  1. The locking piece -1- must be installed so that it fits correctly -arrows-.

Note. There are different versions of the locking piece depending on the engine. For information on allocation. Apply some grease to the locking piece if it is difficult to install the starter.

Install the starter. Refer to Removal and Installation .

Loosen the spindles 10 - 222 A /11.

Raise the transmission and tighten the tunnel crossmember bolts -arrows-. Refer to TUNNEL CROSSMEMBER, TRANSMISSION MOUNT AND TRANSMISSION SUPPORT OVERVIEW .

Loosen the tension strap and remove the V.A.G 1383 A with the T40173 from under the transmission.

Note. The following step is necessary to make sure the torque converter rests on the drive plate evenly and is not tilted.

Press the torque converter -2- against the drive plate -3- slightly in the direction of the -arrow- using an assembly lever -1-.

Scheme 431

Scheme 431
Scheme 431

Attach the torque converter to the drive plate as follows

Note. Tighten the bolts with the V.A.G 1332/14.

Install the first bolt -arrow- and tighten by hand (2 Nm).

Continue turning the crankshaft on the vibration damper 240° in direction of engine rotation using the T10355.

With the crankshaft in this position, tighten the bolt -arrow- to 60 Nm.

Continue turning the crankshaft 120° and tighten the remaining 2 bolts to the tightening specification.

Install in reverse order of removal paying attention to the following

Tighten the remaining bolts -2 through 5-.

Note. The bolt -2- attaches the starter to the transmission and also has a spacer -arrow-. The spacer sleeve must be inserted between the starter and the transmission.

Install the ATF pipes. Refer to AUTOMATIC TRANSMISSION FLUID COOLER AND LINES OVERVIEW .

Install selector lever cable. Refer to SELECTOR LEVER CABLE .

Attach the steering column to the steering gear. Refer to Removal and Installation .

Install the subframe crossbrace. Refer to Removal and Installation .

Attach the left and right drive axles to the transmission flange shafts. Refer to Removal and Installation .

Install the driveshaft heat shield DRIVESHAFT HEAT SHIELD - TIGHTENING SPECIFICATION .

Install exhaust system and adjust free of tension. Refer to Description and Operation .

Install the noise insulation. Refer to Removal and Installation .

Connect the battery. Refer to Removal and Installation .

CAUTIONThere is a risk of destroying control modules with excess voltage. Do not use a charger as a starting aid.

Check the selector lever cable and adjust if necessary. Refer to SELECTOR LEVER CABLE, ADJUSTING .

Check the ATF level and correct if necessary. Refer to ATF, CHECKING LEVEL AND CORRECTING .

TRANSMISSION INSTALLATION TIGHTENING SPECIFICATIONS

Note. The tightening specifications apply only to lightly greased, oiled, phosphated or blackened nuts and bolts. Additional lubricant such as engine or transmission oil may be used, but do not use graphite lubricant. Do not use any ungreased parts. Tightening specification tolerance: ± 15%.

Other tightening specifications

ComponentNm
Bolts and NutsM69
M715
M820
M1040
M1265

DRIVESHAFT HEAT SHIELD - TIGHTENING SPECIFICATION

Tighten the heat shield bolts -arrows- to 23 Nm.

Securing Engine to Transmission

ItemBoltNm
1 1)M10 x 50 2)65
2 1) , 7M12 x 100 3)4)30 + 90°
3, 6M12 x 75 3)4)30 + 90°
4, 5M12 x 120 3)4)30 + 90°
8, 10M10 x 75 3)4)15 + 90°
9M10 x 60 3)4)15 + 90°
11 5)M12 x 50 3)4)30 + 90°
AAlignment sleeves for centering
1) Also secures the starter. 2) Bolt strength rating 10.9. There is no limit to the number of times the steel bolt can be used again. 3) Audi A4 through VIN 8K-9A-066499, Audi A5 through VIN 8T-9A-007999: replace the aluminum bolts. 4) Audi A4 from VIN 8K-9A-066500, Audi A5 from VIN 8T-9A-008000: the aluminum bolts may be used two times. see scheme 181 5) Attaches the engine to the transmission.
(1) To prevent damaging the bolts when marking them, do not clamp them in a vise. Insert the bolt using a 14 mm socket with a 1 / 2 drive, which is inserted in to the vise, as illustrated.
(1)To prevent damaging the bolts when marking them, do not clamp them in a vise. Insert the bolt using a 14 mm socket with a 1 / 2 drive, which is inserted in to the vise, as illustrated.

Scheme 432

Scheme 432
Scheme 432
  1. Audi A4 from VIN 8K-9A-066500, Audi A5 from VIN 8T-9A-008000: the aluminum bolts -2 through 11- may be used two times. Therefore, the bolts must be marked with two notches X made by a chisel after they have be used the first time -arrow-.
  2. Bolts marked with an X cannot be used any further.

Special tools and workshop equipment required

  1. Engine Support Bridge 10 - 222 A
  2. Pry Lever - Rmv Outside Mirror 80 - 200
  3. Engine/Transmission Jack V.A.G 1383 A
  4. Step Ladder VAS 5085
  5. Engine Support Basic Set T40091
  6. Engine Support Supplement Set T40093
  7. Oil Collecting and Extracting Device V.A.G 1782
  8. Engine Bung Set VAS 6122
  9. Counterhold ToolT10172 with Adapter T10172/5
  10. Socket T40058
  11. Transmission Support T40173

Removing

Position the front wheels so they are straight.

Turn off the ignition and remove the key.

CAUTIONRisk of destroying electronic components when disconnecting the battery. Observe measures for disconnecting battery.

Disconnect the battery. Refer to Removal and Installation .

Remove the rear engine cover -arrows-.

Scheme 433

Scheme 433
Scheme 433

Remove the left and right front wheels.

Remove the left and right drive axle cover -1- inside the wheel housing.

Remove the noise insulation. Refer to Removal and Installation .

Remove the left front muffler. Refer to DESCRIPTION AND OPERATION .

Remove the right catalytic converter .

Remove the bolt -arrow- from the ATF pipes.

Note. Lay a cloth under the separating point to prevent ATF from leaking out.

Remove the bolts -1- and -2- and remove the ATF pipes from the transmission, then secure them at the top.

Seal any open lines and connections with a clean plug from the VAS 6122.

Remove the bolts -2 through 5- connecting the engine to transmission. They are accessible from above.

Position the 10 - 222 A with connector T40091/3 on the left and right suspension strut towers as shown in the illustration.

Scheme 434

Scheme 434
Scheme 434

Engage the spindle 10 - 222 A /11 in the right engine lifting eye.

Install the additional 10 - 222 A parts as illustrated. Place the support T40093/3 on the notches in the longitudinal member.

Scheme 435

Scheme 435
Scheme 435

Engage the 10 - 222 A /11 in the left front engine lifting eye.

Remove the bolts -arrows- and remove the heat shield from the right drive axle.

Remove the bolts -arrows- and the left drive axle heat shield.

Scheme 436

Scheme 436
Scheme 436

Remove left and right drive axles from transmission flange shafts.

CAUTIONThere is a risk of destroying the transmission control module (Mechatronic) with static discharge. Do not touch contacts in transmission connector with hands.

To discharge static electricity, touch the transmission housing (without wearing gloves).

Disconnect the connector on transmission by rotating screw connections counter-clockwise -arrow-.

Free up the electrical wiring harness on the transmission.

Disconnect the connector -2- from the engine speed sensor -G28- and free up the wire.

Note. Ignore -1-.

Remove the ball socket -1- on the selector lever cable from the selector shaft lever using the 80 - 200.

Remove the clip -2- and remove the selector lever cable from the transmission.

Note. Do not bend or kink the selector lever cable.

CAUTIONThe suspension components could be damaged. Do not rest the vehicle on its wheels if the subframe mount, the steering gear or the subframe crossbrace are not installed correctly.

All A4; A5 Coupe

Remove the nut -1- from the power steering hydraulic line.

Remove the bolts -arrows- and remove the subframe crossbrace.

A5 Cabriolet

Remove the left and right bolt -2-.

Note. Ignore -1-.

Remove the bolt -2- for the power steering hydraulic line.

Remove the bolts -1- and -arrows- and the subframe crossbrace.

All Vehicles

CAUTIONThe airbag spiral spring could be damaged. Remove the steering column from the steering gear only when the front wheels are in the straight-ahead position. Do not change the steering wheel and steering gear position. Secure the steering wheel, for example using adhesive tape.

Lower the steering wheel as far as possible.

Turn the steering wheel into its center position (wheels in the straight-ahead position) and secure it.

Remove the bolt -arrow- from the steering column. Refer to Removal and Installation .

Remove the steering column -1- from the steering gear -2- and slide it all the way up.

Remove the bolt -1- press the retaining tab off the transmission and tilt it back -arrow-.

Remove the bolts -arrows- and remove the driveshaft heat shield.

Remove the bolt that connects the driveshaft to the transmission by counterholding them with the T10172 and T10172/5.

Press the driveshaft together with rear final drive; the universal joint is able to slide axially.

Secure the driveshaft to the side.

Remove the lower cover -1- from the transmission -arrow-.

Insert the T40058 guide pins as follows

Scheme 437

Scheme 437
Scheme 437
  1. The large diameter -arrow 1- faces the engine.
  2. The small diameter -arrow 2- faces the adapter.

Counterhold the crankshaft using the T40058 to loosen the torque converter bolts.

Scheme 438

Scheme 438
Scheme 438

Note. When mounting, turn the crankshaft only in the direction of engine rotation -arrow-.

Remove the six torque converter bolts -arrow- while turning the crankshaft 60° further in the direction of engine rotation.

Remove the starter. Refer to Removal and Installation .

Note. The starter must be installed in order to install the locking piece -1- correctly in the starter opening when installing the transmission.

Remove the remaining bolts -6 through 11- that attach the engine to the transmission.

Position the V.A.G 1383 A and the T40173 under the transmission and secure it with the tensioning strap -1- as illustrated.

Note. The T40173 is not illustrated.

Remove the bolts from the tunnel crossmember -arrows-.

Lower the transmission using the V.A.G 1383 A first to dimension -a-.

  1. Dimension -a- = maximum 100 mm.

Slightly pre-tension both 10 - 222 A /11.

Press the transmission off the engine and lower it carefully using the V.A.G 1383 A.

Special tools and workshop equipment required

  1. Ring Spanner Insert AF16 V.A.G 1332/14
  2. Transportation Lock T40170

Procedure

Note. Replace bolts that are tightened to the specification. Replace self-locking nuts and bolts and seals, gaskets and O-rings. Secure all hose connections with hose clamps of the same type as those equipped by the factory. When installing, bring all cable ties back to same positions.

Transmission Installation Tightening Specifications: TIGHTENING SPECIFICATIONS TIGHTENING SPECIFICATIONS

Before installing a replacement transmission, always clean out the ATF cooler and ATF pipes using compressed air (maximum 10 bar). Refer to AUTOMATIC TRANSMISSION FLUID LINES, CLEANING .

Clean residue from the threaded holes in the cylinder block using a thread tap before installing.

When installing a replacement transmission, install the transmission support, the transmission mounting and the tunnel crossmember on the new transmission. Refer to TUNNEL CROSSMEMBER, TRANSMISSION MOUNT AND TRANSMISSION SUPPORT OVERVIEW .

Mount the transmission onto the T40173 and secure it using the tension strap -1- as illustrated.

The following preparations must be made before connecting the engine and transmission

Turn the torque converter so that hole next to the notch -arrow- is visible in the lower cut-out in the transmission housing as illustrated.

Note. There is only 1 notch on the circumference; rotate the torque converter as needed.

Insert the T40170 in the transmission housing from below and secure it on the flange shaft -1-.

Check if the alignment sleeves -A- for centering the engine/transmission are in the cylinder block and insert them if they are not.

Inspect the aluminum bolts used to connect the engine to the transmission to see if they can be used again and mark them, if necessary TIGHTENING SPECIFICATIONS .

Attach the transmission to the engine and the tighten the bolts -1 and 6 through 11-.

Remove the T40170.

Clip the locking piece -1- into the starter opening.

  1. The locking piece -1- must be installed so that it fits correctly -arrows-.

Note. There are different versions of the locking piece depending on the engine. For information on allocation. Apply some grease to the locking piece if it is difficult to install the starter.

Install the starter. Refer to Removal and Installation .

Loosen the 10 - 222 A /11.

Raise the transmission and tighten the tunnel crossmember bolts -arrows-. Refer to TUNNEL CROSSMEMBER, TRANSMISSION MOUNT AND TRANSMISSION SUPPORT OVERVIEW .

Loosen the tension strap and remove the V.A.G 1383 A with the T40173 from under the transmission.

Note. The following step is necessary to make sure the torque converter rests on the drive plate evenly and is not tilted.

Press the torque converter -2- against the drive plate -3- slightly in the direction of the -arrow- using an assembly lever -1-.

Attach the torque converter to the drive plate as follows

Note. Use the V.A.G 1332/14 to tighten.

Install the first bolt -arrow- and tighten by hand (2 Nm).

Insert the T40058 guide pins as follows

  1. The large diameter -arrow 1- faces the engine.
  2. The small diameter -arrow 2- faces the adapter.

Continue turning the crankshaft 180° in the direction of the engine rotation using the T40058 -arrow-.

With the crankshaft in this position, tighten the bolt -arrow- to 60 Nm.

Continue turning the crankshaft 60° and tighten the remaining 5 bolts to the tightening specification.

Tighten the remaining bolts -2 through 5-.

Install in reverse order of removal paying attention to the following

Attach the steering column to the steering gear. Refer to Removal and Installation .

Install the subframe crossbrace. Refer to Removal and Installation .

Install selector lever cable. Refer to SELECTOR LEVER CABLE .

Install the ATF pipes. Refer to AUTOMATIC TRANSMISSION FLUID COOLER AND LINES OVERVIEW .

Attach the left and right drive axles to the transmission flange shafts. Refer to Removal and Installation .

Install the driveshaft heat shield DRIVESHAFT HEAT SHIELD - TIGHTENING SPECIFICATION .

Install the driveshaft. Refer to Removal and Installation or Removal and Installation .

Reconnect exhaust system making sure it is not under stress .

Install the noise insulation. Refer to Removal and Installation .

Connect the battery. Refer to Removal and Installation .

CAUTIONThere is a risk of destroying control modules with excess voltage. Do not use a charger as a starting aid.

Check the selector lever cable and adjust if necessary. Refer to SELECTOR LEVER CABLE, ADJUSTING .

Check the ATF level and correct if necessary. Refer to ATF, CHECKING LEVEL AND CORRECTING .

TIGHTENING SPECIFICATIONS

Note. The tightening specifications apply only to lightly greased, oiled, phosphated or blackened nuts and bolts. Additional lubricant such as engine or transmission oil may be used, but do not use graphite lubricant. Do not use any ungreased parts. Tightening specification tolerance: ± 15%.

Other tightening specifications

ComponentNm
Bolts and nutsM69
M715
M820
M1040
M1265

Driveshaft Heat Shield - Tightening Specification

Tighten the heat shield bolts -arrows- to 23 Nm.

Mounting transmission to engine

ItemScrewNm
1M10 x 50 1)65
2 ••• 6M12 x 100 2)3)30 + 90°
7M12 x 125 2)3)30 + 90°
8, 11M10 x 60 2)3)15 + 90°
9, 10M10 x 95 2)3)15 + 90°
AAlignment sleeves for centering
1) bolt strength rating 10.9. There is no limit to the number of times the steel bolt can be used again. 2) Audi A4 through VIN 8K-9A-066499, Audi A5 through VIN. 8T-9A-007999: replace the aluminum bolts. 3) Audi A4 from VIN 8K-9A-066500, Audi A5 from VIN 8T-9A-008000: the aluminum bolts may be used two times. see scheme 181
(1) To prevent damaging the bolts when marking them, do not clamp them in a vise. Insert the bolt using a 14 mm socket with a 1 / 2 drive, which is inserted in to the vise, as illustrated.
(1)To prevent damaging the bolts when marking them, do not clamp them in a vise. Insert the bolt using a 14 mm socket with a 1 / 2 drive, which is inserted in to the vise, as illustrated.
  1. Audi A4 from VIN 8K-9A-066500, Audi A5 from VIN 8T-9A-008000: the aluminum bolts -2 through 11- may be used two times. Therefore, the bolts must be marked with two notches X made by a chisel after they have be used the first time -arrow-.
  2. Bolts marked with an X cannot be used any further.

Special tools and workshop equipment required

  1. Pry Lever - Rmv Outside Mirror80 - 200
  2. Engine/Transmission JackV.A.G 1383 A
  3. Step LadderVAS 5085
  4. Engine Bung SetVAS 6122
  5. Counterhold ToolT10172 with AdapterT10172/5
  6. Transmission SupportT40173

Removing

Position the front wheels so they are straight.

Turn off the ignition and remove the key.

CAUTIONRisk of destroying electronic components when disconnecting the battery. Observe measures for disconnecting battery.

Disconnect the battery. Refer to Removal and Installation .

Remove the engine cover -arrows-.

Scheme 439

Scheme 439
Scheme 439

Remove the bulkhead plenum chamber. Refer to Removal and Installation .

Remove the bolts -arrows-.

Scheme 440

Scheme 440
Scheme 440

Disconnect the connector on the engine coolant level warning switch -F66- and move the coolant reservoir to the side with the coolant hoses -1, 2 and 3- still connected.

Note. Catch any leaking ATF with a cloth.

Remove the bolt -2- and the nut -3-.

Scheme 441

Scheme 441
Scheme 441

Note. Ignore -1, 4, 5 and 6-.

Remove the bolts -2 through 5- connecting the engine to transmission. They are accessible from above.

Remove the left and right front wheels.

Remove the left and right drive axle cover -1- inside the wheel housing.

Remove the noise insulation. Refer to Removal and Installation .

Remove the bolts -arrows- and remove the heat shield from the right drive axle.

Remove the bolts -arrows- and the left drive axle heat shield.

Remove left and right drive axles from transmission flange shafts.

CAUTIONThere is a risk of destroying the transmission control module (Mechatronic) with static discharge. Do not touch contacts in transmission connector with hands.

To discharge static electricity, touch the transmission housing (without wearing gloves).

Disconnect the connector on transmission by rotating screw connections counter-clockwise -arrow-.

Free up the electrical wiring harness on the transmission.

CAUTIONThe suspension components could be damaged. Do not rest the vehicle on its wheels if the subframe mount, the steering gear or the subframe crossbrace are not installed correctly.

All A4; A5 Coupe

Remove the nut -1- from the power steering hydraulic line.

Scheme 442

Scheme 442
Scheme 442

Remove the bolts -arrows- and remove the subframe crossbrace.

A5 Cabriolet

Remove the left and right bolt -2-.

Note. Ignore -1-.

Remove the bolt -2- for the power steering hydraulic line.

Remove the bolts -1- and -arrows- and the subframe crossbrace.

All Vehicles

CAUTIONThe airbag spiral spring could be damaged. Remove the steering column from the steering gear only when the front wheels are in the straight-ahead position. Do not change the steering wheel and steering gear position. Secure the steering wheel, for example using adhesive tape.

Lower the steering wheel as far as possible.

Turn the steering wheel into its center position (wheels in the straight-ahead position) and secure it.

Remove the bolt -arrow- from the steering column. Refer to Removal and Installation .

Scheme 443

Scheme 443
Scheme 443

Remove the steering column from the steering gear and push it all the way up.

Disconnect the connectors -1- to the steering gear and -2- from the engine speed sensor -G28-.

Remove the ball socket -1- on the selector lever cable from the selector shaft lever using the 80 - 200.

Remove the clip -2- and remove the selector lever cable from the transmission.

Note. Do not bend or kink the selector lever cable.

Remove the bolt -2-.

Scheme 444

Scheme 444
Scheme 444

Press the tab in direction of -arrow B- and move it to the rear -arrow A-.

Remove the bolts -1- and -2- and remove the tab with the spring.

Scheme 445

Scheme 445
Scheme 445

Remove the bolts -arrows- and the bracket.

CAUTIONThe decoupling elements in the front muffler could get damaged. Do not bend the decoupling elements in the front muffler more than 10°.

Loosen the clamping sleeves -1- and -2-, slide them back and tie up the left and right front mufflers to the left and right noise insulation with cable ties.

Scheme 446

Scheme 446
Scheme 446

Remove the bolts -arrows- and remove the driveshaft heat shield.

Remove the bolt that connects the driveshaft to the transmission by counterholding them with the T10172 and T10172/5.

Press the driveshaft together with rear final drive; the universal joint is able to slide axially.

Secure the driveshaft to the side.

Note. Catch any leaking ATF with a cloth.

Remove the bolts -1, 4, 5 and 6-.

Move the ATF pipe to the side.

Seal any open lines and connections with a clean plug from the VAS 6122.

Note. Ignore -2- and -3-.

Remove the lower cover -1- from the transmission -arrow-.

Counterhold the crankshaft with the T10172 with adapterT10172/7 to loosen the torque converter bolts.

Scheme 447

Scheme 447
Scheme 447

Note. When mounting, turn the crankshaft only in the direction of engine rotation -arrow-.

Remove the six torque converter bolts -arrow- while turning the crankshaft 60° further in the direction of engine rotation.

Remove the starter. Refer to Removal and Installation .

Note. The starter must be installed in order to install the locking piece -1- correctly in the starter opening when installing the transmission.

Remove the remaining bolts -6 through 11- that attach the engine to the transmission.

Position the V.A.G 1383 A and the T40173 under the transmission and secure it with the tensioning strap -1- as illustrated.

Note. The transmission supportT40173 is not illustrated.

Remove the bolts from the tunnel crossmember -arrows-.

Press the transmission off the engine and lower it carefully using the V.A.G 1383 A.

Special tools and workshop equipment required

  1. Ring Spanner Insert AF16V.A.G 1332/14
  2. Transportation LockT40170

Procedure

Note. Replace bolts that are tightened to the specification. Replace self-locking nuts and bolts and seals, gaskets and O-rings. Secure all hose connections with hose clamps of the same type as those equipped by the factory. When installing, bring all cable ties back to same positions.

Transmission Installation Tightening Specifications: TIGHTENING SPECIFICATIONS .

Before installing a replacement transmission, always clean out the ATF cooler and ATF pipes using compressed air (maximum 10 bar). Refer to AUTOMATIC TRANSMISSION FLUID LINES, CLEANING .

Clean residue from the threaded holes in the cylinder block using a thread tap before installing.

When installing a replacement transmission, install the transmission support, the transmission mounting and the tunnel crossmember on the new transmission. Refer to TUNNEL CROSSMEMBER, TRANSMISSION MOUNT AND TRANSMISSION SUPPORT OVERVIEW .

Mount the transmission onto the T40173 and secure it using the tension strap -1- as illustrated.

The following preparations must be made before connecting the engine and transmission

Turn the torque converter so that hole next to the notch -arrow- is visible in the lower cut-out in the transmission housing as illustrated.

Note. There is only 1 notch on the circumference; rotate the torque converter as needed.

Insert the T40170 in the transmission housing from below and secure it on the flange shaft -1-.

Check if the alignment sleeves -A- for centering the engine/transmission are in the cylinder block and insert them if they are not.

Inspect the aluminum bolts used to connect the engine to the transmission to see if they can be used again and mark them, if necessary TIGHTENING SPECIFICATIONS .

Attach the transmission to the engine and the tighten the bolts -1 and 6 through 11-.

Remove the T40170.

Clip the locking piece -1- into the starter opening.

  1. The locking piece -1- must be installed so that it fits correctly -arrows-.

Note. There are different versions of the locking piece depending on the engine. For information on allocation. Apply some grease to the locking piece if it is difficult to install the starter.

Install the starter. Refer to Removal and Installation .

Raise the transmission and tighten the tunnel crossmember bolts -arrows-. Refer to TUNNEL CROSSMEMBER, TRANSMISSION MOUNT AND TRANSMISSION SUPPORT OVERVIEW .

Loosen the tension strap and remove the V.A.G 1383 A with the T40173 from under the transmission.

Note. The following step is necessary to make sure the torque converter rests on the drive plate evenly and is not tilted.

Press the torque converter -2- against the drive plate -3- slightly in the direction of the -arrow- using an assembly lever -1-.

Attach the torque converter to the drive plate as follows

Note. Use the ring spanner insert AF16 V.A.G 1332/14 to tighten.

Install the first bolt -arrow- and tighten by hand (2 Nm).

Turn the crankshaft 180° in direction of engine rotation -arrow- using the T10172 with T10172/7

With the crankshaft in this position, tighten the bolt -arrow- to 60 Nm.

Continue turning the crankshaft 60° and tighten the remaining 5 bolts to the tightening specification.

Tighten the remaining bolts -2 through 5-.

Install in reverse order of removal paying attention to the following

Attach the steering column to the steering gear. Refer to Removal and Installation .

Install the subframe crossbrace. Refer to Removal and Installation .

Install selector lever cable. Refer to SELECTOR LEVER CABLE .

Install the ATF pipes. Refer to AUTOMATIC TRANSMISSION COOLER AND LINES OVERVIEW .

Attach the left and right drive axles to the transmission flange shafts. Refer to Removal and Installation .

Install the driveshaft heat shield TIGHTENING SPECIFICATIONS .

Reconnect exhaust system making sure it is not under stress .

Install the noise insulation. Refer to Removal and Installation .

Install the bulkhead plenum chamber. Refer to Removal and Installation .

Connect the battery. Refer to Removal and Installation .

CAUTIONThere is a risk of destroying control modules with excess voltage. Do not use a charger as a starting aid.

Check the selector lever cable and adjust if necessary. Refer to SELECTOR LEVER CABLE, ADJUSTING .

Check the ATF level and correct if necessary. Refer to ATF, CHECKING LEVEL AND CORRECTING .

Note. The tightening specifications apply only to lightly greased, oiled, phosphated or blackened nuts and bolts. Additional lubricant such as engine or transmission oil may be used, but do not use graphite lubricant. Do not use any ungreased parts. Tightening specification tolerance: ± 15%.

Other tightening specifications

ComponentNm
Bolts and nutsM69
M715
M820
M1040
M1265

Driveshaft Heat Shield - Tightening Specification

Tighten the heat shield bolts -arrows- to 23 Nm.

Mounting Transmission to Engine

ItemBoltNm
1M10 x 50 1)65
2 to 6M12 x 100 3)4)30 + 90°
7M12 x 175 2)3)30 + 90°
8, 11M10 x 60 2)3)15 + 90°
9M10 x 75 2)3)15 + 90°
10M10 x 95 2)3)15 + 90°
AAlignment sleeves for centering
1) Bolt strength rating 10.9. There is no limit to the number of times the steel bolt can be used again. 2) Audi A4 through VIN 8K-9A-066499, Audi A5 through VIN. 8T-9A-007999: replace the aluminum bolts. 3) Audi A4 from VIN 8K-9A-066500, Audi A5 from VIN 8T-9A-008000: the aluminum bolts may be used two times. Refer to TIGHTENING SPECIFICATIONS .
(1) To prevent damaging the bolts when marking them, do not clamp them in a vise. Insert the bolt using a 14 mm socket with a 1 / 2 drive, which is inserted in to the vise, as illustrated.
(1)To prevent damaging the bolts when marking them, do not clamp them in a vise. Insert the bolt using a 14 mm socket with a 1 / 2 drive, which is inserted in to the vise, as illustrated.
  1. Audi A4 from VIN 8K-9A-066500, Audi A5 from VIN 8T-9A-008000: the aluminum bolts -2 through 11- may be used two times. Therefore, the bolts must be marked with two notches X made by a chisel after they have be used the first time -arrow
  2. Bolts marked with an X cannot be used any further.

TRANSMISSION, TRANSPORTING

Special tools and workshop equipment required

  1. Hook and Support Tool 3311 with Bolt 3311/1
  2. Shop Crane VAS 6100

Procedure

  1. Transmission removed.
CAUTIONTransmission components could be damaged if they are not set down correctly. Do not set the transmission on the ATF pan.
WARNINGAn accident could result if the transmission is not secured correctly. Exchange the bolt on the 3311 for a new, longer 3311/1. Only this way can the transmission be secured.

Scheme 448

Scheme 448
Scheme 448

Secure transmission on 3311 (use new, longer 3311/1).

The transmission can be lifted and transported using a VAS 6100.

Note. Ignore VW 309

TRANSMISSION, SECURING IN ENGINE/TRANSMISSION HOLDER

Special tools and workshop equipment required

  1. Holding Plate VW 309
  2. Engine and Transmission Holder VAS 6095

Procedure

  1. Transmission secured with the shop crane VAS 6100. Refer to «TRANSMISSION, TRANSPORTING»(/audi/a4/b8-2007-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd-avant__transmission-transporting) .

Install the VW 309 on the hook and support tool 3311.

Place the transmission into the VAS 6095 using the VAS 6100.

Note. The vents for the transmission housing and final drive must be closed before turning a filled transmission with oil pan upward on the engine and transmission holder.

Scheme 449

Scheme 449: SPECIAL TOOLS
Scheme 449: SPECIAL TOOLS

Special tools and workshop equipment required

  1. Vehicle Diagnosis, Testing and Information System VAS 5051B
  2. Used Oil Collecting and Extracting Device V.A.G 1782
  3. ATF Filler Tool V.A.G 1924

Scheme 450

Scheme 450
Scheme 450

Special tools and workshop equipment required

  1. Pry Lever - Rmv Outside Mirror 80 - 200
  2. Engine/Transmission Jack V.A.G 1383 A
  3. Step Ladder VAS 5085
  4. Engine Bung Set VAS 6122
  5. Counterhold Tool T10172 with Adapter T10172/5
  6. Transmission Support T40173

Scheme 451

Scheme 451
Scheme 451

Special tools and workshop equipment required

  1. Oil Collecting and Extracting Device V.A.G 1782
  2. Engine Bung Set VAS 6122
  3. Counterhold Tool T10172 with Adapter T10172/5
  4. Socket T40058
  5. Transmission Support T40173

Scheme 452

Scheme 452
Scheme 452

Special tools and workshop equipment required

  1. Engine Support Bridge 10 - 222 A
  2. Pry Lever - Rmv Outside Mirror 80 - 200
  3. Engine/Transmission Jack V.A.G 1383 A
  4. Step Ladder VAS 5085
  5. Engine Support Basic Set T40091
  6. Engine Support Supplement Set T40093

Special tools and workshop equipment required

Scheme 453

Scheme 453
Scheme 453

Scheme 454

Scheme 454
Scheme 454

Scheme 455

Scheme 455
Scheme 455

Scheme 456

Scheme 456
Scheme 456

Scheme 457

Scheme 457
Scheme 457

Scheme 458

Scheme 458
Scheme 458

Scheme 459

Scheme 459
Scheme 459

Scheme 460

Scheme 460
Scheme 460

Scheme 461

Scheme 461
Scheme 461

Scheme 462

Scheme 462
Scheme 462

Scheme 463

Scheme 463
Scheme 463

Scheme 464

Scheme 464
Scheme 464
  1. Trim Removal Wedge 3409
  2. Socket and Key T40031
  3. Hose Clamp Pliers V.A.G 1275
  4. Transmission Support T10337
  5. Engine Support Bridge 10 - 222 A
  6. Counter Hold Tool T10355
  7. Ring Spanner Insert AF16 V.A.G 1332/14
  8. Transportation Lock T40170
  9. Hook and Support Tool 3311 with Bolt 3311/1
  10. Shop Crane VAS 6100
  11. Holding Plate VW 309
  12. Engine and Transmission Holder VAS 6095

See also:
• CLEAN WORKING CONDITIONS
• Removal and Installation
• MECHATRONIC UNIT
• WIRING HARNESS IN TRANSMISSION
• Removal and Installation
• Removal and Installation
• REPAIR INFORMATION
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Description and Operation
• REMOVAL AND INSTALLATION
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Removal and Installation
• ATF, DRAINING OR FILLING AFTER REPAIR
• ATF, CHECKING LEVEL AND CORRECTING
• SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE WITH TIPTRONIC SWITCH
• Shift Lock Solenoid -N110
• SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT
• SELECTOR MECHANISM, CHECKING
• SELECTOR LEVER HANDLE AND SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT OVERVIEW
• SHIFT MECHANISM FUNCTION UNIT
• SELECTOR LEVER CABLE
• SELECTOR LEVER CABLE, ADJUSTING
• SELECTOR LEVER CABLE, BRINGING INTO BASIC SETTING
• SELECTOR LEVER HANDLE
• SELECTOR LEVER BOOT, SEPARATING FROM HANDLE
• TRANSMISSION SUPPORT WITH TRANSMISSION MOUNT
• TRANSMISSION MOUNT
• TUNNEL CROSSMEMBER
• AUTOMATIC TRANSMISSION COOLER AND LINES OVERVIEW
• AUTOMATIC TRANSMISSION FLUID COOLER AND LINES OVERVIEW
• 1. SELECTOR MECHANISM FUNCTION TEST
• 2. CHECK IGNITION KEY WITHDRAWAL LOCK
• 3. CHECK LOCKING BUTTON IN THE SELECTOR LEVER HANDLE
• SELECTOR MECHANISM OVERVIEW
• TRANSMISSION INSTALLATION TIGHTENING SPECIFICATIONS
• AUTOMATIC TRANSMISSION FLUID LINES, CLEANING
• TIGHTENING SPECIFICATIONS
• DRIVESHAFT HEAT SHIELD - TIGHTENING SPECIFICATION
• TRANSMISSION, TRANSPORTING

More articles — Transmission
