FASTENER TIGHTENING SPECIFICATIONS
| Component | Bolt Size | Nm |
|---|---|---|
| Bracket to Body 1, 2 | 20 + 90° | |
| Bracket to Engine Mount 1, 2 | 20 + 90° | |
| Bolts and Nuts | ||
| M6 | 10 | |
| M8 | 20 | |
| M10 | 45 | |
| M12 | 65 | |
| Engine Mount to Body 1, 2 | 40 + 90° | |
| Engine Mount to Engine Support 1, 2 | 60 + 90° | |
| Engine Support to Engine | 45 | |
| Exceptions | ||
| Clamp B+ to Starter | 16 | |
| Ground (GND) Cable to Transmission | 23 | |
| Pendulum Supports to Transmission 1, 2 | 40 + 90° | |
| Pendulum Supports to Subframe 1, 2 | 100 + 90° | |
| 1 Replace bolt 2 90° corresponds to a quarter turn. | ||
Engine/Transmission Fastening
Scheme 325
| Item | Bolt | Nm |
|---|---|---|
| 1, 2 | M12 X 65 | 80 |
| 3 1) , 4 1) | M12 X 135 | 80 |
| 5 through 7 | M10 X 60 | 40 |
| 8 | M12 X 90 | 65 |
| 1) Bolt with threaded pin M8 | ||
