CAMSHAFT ADJUSTMENT VALVE 1
Special tools and workshop equipment required
- Torque Wrench 5-60 Nm V.A.G 1783
- Torx® Bit Set V.A.G 1766
- Ratchet Insert 1/4" VAS 6234
- Spring Type Clip Pliers VAS 5024 A
Removing
Note. Always replace gaskets and seals.
Remove the engine cover and air filter. Refer to Removal and Installation .
Separate electrical connector -1-.
Scheme 125
Disengage wiring harness -2- from bracket.
Remove the bolt -3-.
Note. Do not pull out the camshaft adjustment valve 1 -N205- at connector.
Remove bolts -arrows- and remove camshaft adjustment valve 1 from housing.
Scheme 126
Installing
- Tightening specifications, refer to «CYLINDER HEAD OVERVIEW»(ref-496096-S14233578952012082100000) .
Note. Camshaft adjustment valve 1 as well as housing must be free of dirt and contamination. Remove the new camshaft adjustment valve 1 from packaging only prior to installation.
| CAUTION | The camshaft adjustment valve 1 must not experience any hits or impacts. |
Coat sealing ring with engine oil.
Carefully insert camshaft adjustment valve 1 into housing and press it in perpendicular to valve axle by hand as far as stop.
Install bolts and tighten to 4 Nm with the V.A.G 1783, VAS 6234, Torx® bit T20 and bit holder from V.A.G 1766.
Assemble in reverse order of disassembly.
