2.0L - Engine Assembly - Engine Code(s): Bpy: Adjustments Audi A3 8P facelift

Mechanical 1 illustration ~125 words

SUBFRAME MOUNT, CHECKING ADJUSTMENT

Remove the engine cover and air filter. Refer to Removal and Installation .

Pull the EVAP canister with connected lines upward in direction of the -arrow- out of the retainer and lay it aside.

The following dimensions must be attained

Scheme 326

Scheme 326
Scheme 326
  1. The clearance between the engine support -2- and the right longitudinal member must be -a- = 16 mm.
  2. The casting edge of the engine support -2- must be parallel to the support arm -1- (dimension x = dimension x).

Note. The dimension a = 16 mm, can for example also be checked with a suitable cylindrical rod.

If a clearance dimension is too small or too large, proceed as follows
