Battery Ground Cable
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | (-) | | Left Front of Engine Compartment | Battery Negative Terminal | |
| 2 | G1 | | Left Front of Engine Compartment | Body Ground via Battery Ground Cable | |
Transmission Ground Cable
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 3 | G3 | | Under Left Front of Engine Compartment | Body Ground via Transmission Ground Cable | |
| 4 | T2 | | Transmission Housing | Transmission | |
Engine Ground Cable
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 5 | T1 | | Right Side of Engine Compartment | Engine | |
| 6 | G2 | | Right Side of Engine Compartment | Body Ground via Engine Ground Cable | |
Scheme 352
Starter Cable
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | T101 (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | | Left Rear of Engine Compartment | Under-hood Fuse/Relay Box | |
| 2 | (+) | | Left Front of Engine Compartment | Battery Positive Terminal | |
| 3 | T5 | | Left Side of Engine | Starter | |
Scheme 353
Engine Wire Harness (Engine Section)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | G101 | | Right Side of Engine | Body Ground via Engine Wire Harness | |
| 2 | Ignition Coil No. 1 | 3-BLK | Rear of Engine | | |
| 3 | Injector No. 1 | 2-GRY | Middle of Engine | | |
| 4 | Injector No. 2 | 2-GRY | Middle of Engine | | |
| 5 | C103 (Junction Connector) | 24-BLK | Rear of Engine | | |
| 6 | Ignition Coil No. 2 | 3-BLK | Rear of Engine | | |
| 7 | C106 (Junction Connector) | 24-BLK | Rear of Engine | | |
| 8 | Injector No. 3 | 2-GRY | Middle of Engine | | |
| 9 | Ignition Coil No. 3 | 3-BLK | Rear of Engine | | |
| 10 | EVAP Canister Purge Valve | 2-BLK | Left Side of Engine | | |
| 11 | Engine Mount Control Solenoid Valve | 2-GRY | Left Side of Engine | | |
| 12 | Rear A/F Sensor (B1, S1) | 6-BLK | Rear of Engine | | |
| 13 | Rear Secondary HO2S (B1, S2) | 4-BLK | Rear of Engine | | |
| 14 | MAP Sensor | 3-BLK | Left Side of Engine | | |
| 15 | T102 (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | | Left Rear of Engine Compartment | Under-hood Fuse/Relay Box | |
| 16 | Transmission Fluid Pressure Switch A (2nd Clutch) | 1-GRN | Under Rear of Transmission Housing | | |
| 17 | TP Sensor/Throttle Actuator | 6-BLK | Left Side of Engine | | |
| 18 | MAF/IAT Sensor | 5-BLK | Left Side of Engine Compartment | | |
| 19 | C102 (Female) | 4-BLK | Left Side of Engine Compartment | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) | |
| 20 | C101 (Female) | 13-BLK/ GRY | Left Side of Engine Compartment | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) | |
| 21 | C105 (Junction Connector) | 24-BLK | Transmission Housing | | |
| 22 | C107 (Junction Connector) | 24-BLK | Transmission Housing | | |
| 23 | CKP Sensor | 3-BLK | Under Rear of Engine | | |
| 24 | PCM Connector B | 49-BLK/ GRY | Left Side of Engine Compartment | | |
| 25 | PCM Connector C | 49-BLK/ GRN | Left Side of Engine Compartment | | |
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 26 | A/T Clutch Pressure Control Solenoid Valve C | 2-BLK | Transmission Housing | | |
| 27 | EGR Valve and EGR Valve Position Sensor | 5-BLK | Left Side of Engine | | |
| 28 | ECT Sensor 1 | 2-BLK | Left Side of Engine | | |
| 29 | Front Secondary HO2S (B2, S2) | 4-BLK | Front of Engine | | |
| 30 | Front A/F Sensor (B2, S1) | 6-BLK | Front of Engine | | |
| 31 | Ignition Coil No. 6 | 3-BLK | Front of Engine | | |
| 32 | Ignition Coil No. 5 | 3-BLK | Front of Engine | | |
| 33 | A/C Compressor Clutch | 1-GRN/BLK | Front of Engine | | |
| 34 | Alternator | 4-BLU | Front of Engine | | |
| 35 | T4 | | Front of Engine | Alternator | |
| 36 | Ignition Coil No. 4 | 3-BLK | Front of Engine | | |
| 37 | Injector No. 6 | 2-GRY | Middle of Engine | | |
| 38 | Injector No. 5 | 2-GRY | Middle of Engine | | |
| 39 | Injector No. 4 | 2-GRY | Middle of Engine | | |
| 40 | CMP Sensor | 3-BLK | Right Side of Engine | | |
| 42 | C104 (Female) | 1-GRN/BLK | Right Side of Engine | KNOCK SENSOR SUB-HARNESS | |
| 43 | Rocker Arm Oil Control Solenoid | 1-GRN/BLK | Under Right Side of Engine | | |
| 44 | Oil Pressure Switch | 1-GRN | Under Right Side of Engine | | |
| 45 | Rocker Arm Oil Pressure Switch | 2-GRY | Under Right Side of Engine | | |
| 46 | IMT Actuator | 5-BLK | Right Side of Engine | | |
Scheme 354
Knock Sensor Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 41 | Knock Sensor | 1-BLU | Middle of Engine | | |
| 42 | C104 (Male) | 1-GRN/BLK | Right Side of Engine | ENGINE WIRE HARNESS | |
Scheme 355
Engine Wire Harness (Transmission Section)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Starter Solenoid | 1-BLK | Left Side of Engine | | |
| 6 | 4th Clutch Transmission Fluid Pressure Switch | 1-GRN | Transmission Housing | | |
| 7 | A/T Clutch Pressure Control Solenoid Valve A | 2-BLK | Transmission Housing | | |
| 8 | A/T Clutch Pressure Control Solenoid Valve B | 2-BRN | Transmission Housing | | |
| 9 | ATF Temperature Sensor | 2-GRY | Under Transmission Housing | | |
| 10 | Transmission Range Switch | 10-BLK/ GRY | Transmission Housing | | |
| 11 | Output Shaft (Countershaft) Speed Sensor | 3-BLK | Under Transmission Housing | | |
| 12 | Transmission Fluid Pressure Switch B (3rd Clutch) | 1-GRN | Under Transmission Housing | | |
| 13 | Input Shaft (Mainshaft) Speed Sensor | 3-BLU | Under Transmission Housing | | |
| 14 | C108 (Female) | 5-BLK | Transmission Housing | SHIFT SOLENOID WIRE HARNESS | |
Shift Solenoid Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 2 | Shift Control Solenoid Valve A | 1-N/A | In Transmission | | |
| 3 | Shift Control Solenoid Valve C | 1-N/A | In Transmission | | |
| 4 | Shift Control Solenoid Valve D | 1-N/A | In Transmission | | |
| 5 | Shift Control Solenoid Valve B | 1-N/A | In Transmission | | |
| 14 | C108 (Male) | 5-BLK | Transmission Housing | ENGINE WIRE HARNESS | |
Scheme 356
Left Engine Compartment Wire Harness (Engine Compartment Branch)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Under-hood Fuse/Relay Box Connector B (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 14-WHT | Left Rear of Engine Compartment | | |
| 2 | Under-hood Fuse/Relay Box Connector C (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 5-WHT | Left Rear of Engine Compartment | | |
| 3 | Under-hood Fuse/Relay Box Connector A (ELD Unit) (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 3-WHT | Left Rear of Engine Compartment | | |
| 4 | C354 (Female) | 6-WHT | Left Rear of Engine Compartment EPS Unit Sub-harness (see EPS UNIT SUB-HARNESS ) | | |
| 5 | Brake Fluid Level Switch | 2-GRY | Left Rear of Engine Compartment | | |
| 6 | Windshield Wiper Motor | 4-BLK | Under Left Side of Cowl Cover | | |
| 7 | Left Front Wheel Speed Sensor | 2-BLK | Left Front Wheelwell | | |
| 8 | Left Front TPMS Initiator | 3-BLK | Left Front Wheelwell | | |
| 9 | C102 (Male) | 4-BLK | Left Side of Engine Compartment Engine Wire Harness (see ENGINE WIRE HARNESS (ENGINE SECTION) ) | | |
| 10 | C101 (Male) | 13-BLK/ GRY | Left Side of Engine Compartment Engine Wire Harness (see ENGINE WIRE HARNESS (ENGINE SECTION) ) | | |
| 11 | Left Front Turn Signal/Parking Light | 3-WHT | Left Front Wheelwell | | |
| 12 | PCM Connector A | 49-BLK/ WHT | Left Side of Engine Compartment | | |
| 13 | Left HID Unit | 2-BLK | Left Front of Engine Compartment | | |
| 14 | G301 | Behind Left Side of Front Bumper | Body Ground via Left Engine Compartment Wire Harness | | |
| 15 | Left Fog Light | 2-BLK | Behind Left Side of Front Bumper | | |
| 16 | Left Front Impact Sensor | 2-YEL | Behind Left Side of Front Bumper | | |
| 17 | Keyless Buzzer | 2-GRY | Behind Left Side of Front Bumper | | |
| 18 | Back-up Sensor System Connector B (Option Connector) | 3-BRN | Left Front of Engine Compartment | | |
| 19 | Left Headlight (High Beam) | 2-BLU | Left Front of Engine Compartment | | |
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 21 | Radiator Fan Motor | 2-BLK | Under Left Front of Engine Compartment | | |
| 22 | ECT Sensor 2 | 2-BLK | Under Left Front of Engine Compartment | | |
| 23 | C251 (Female) | 1-BLK | Under Left Front of Engine Compartment | EPS GROUND SUB-HARNESS | |
| 24 | High Horn | 1-BLK | Behind Middle of Front Bumper | | |
| 25 | A/C Condenser Fan Motor | 2-BLK | Under Middle Front of Engine Compartment | | |
| 26 | Security Hood Switch | 2-BLK | Behind Middle of Front Bumper | | |
| 27 | Outside Air Temperature Sensor | 2-GRY | Behind Right Side of Front Bumper | | |
| 28 | Low Horn | 1-BLK | Behind Middle of Front Bumper | | |
| 29 | C201 (Female) | 2-BLK | Behind Right Side of Front Bumper | Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) | |
Scheme 357
EPS Ground Sub-harness
Scheme 358
Left Engine Compartment Wire Harness (Dashboard Branch)
Scheme 359
EPS Unit Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | T8 | | Right Rear of Engine Compartment | Steering Gearbox | |
| 2 | T7 | | Right Rear of Engine Compartment | Steering Gearbox | |
| 3 | T6 | | Left Rear of Engine Compartment | Steering Gearbox | |
| 4 | C354 (Male) | 6-WHT | Left Rear of Engine Compartment | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) | |
| 5 | EPS Torque Sensor | 3-BLK/ WHT | Left Rear of Engine Compartment | | |
Scheme 360
Left Engine Compartment Sub-harness
Scheme 361
Right Engine Compartment Wire Harness (Engine Compartment Branch)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Right Front Wheel Speed Sensor | 2-BLK | Right Front Wheelwell | | |
| 2 | EPS Motor Angle Sensor | 6-WHT | Right Rear of Engine Compartment | | |
| 3 | EPS Motor | 3-BLK | Right Rear of Engine Compartment | | |
| 4 | C201 (Male) | 2-BLK | Behind Right Side of Front Bumper | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
| 5 | Right Headlight (High Beam) | 2-BLU | Right Front of Engine Compartment | | |
| 6 | Right Fog Light | 2-BLK | Behind Right Side of Front Bumper | | |
| 7 | Right Front Impact Sensor | 2-YEL | Behind Right Side of Front Bumper | | |
| 8 | Windshield Washer Motor | 2-BLK | Behind Right Side of Front Bumper | | |
| 9 | Washer Fluid Level Switch | 2-N/A | Behind Right Side of Front Bumper | | Canada |
| 10 | G202 | | Behind Right Side of Front Bumper | Body Ground via Right Engine Compartment Wire Harness | |
| 11 | Right HID Unit | 2-BLK | Right Front of Engine Compartment | | |
| 12 | Right Front Turn Signal/Parking Light | 3-WHT | Right Front Wheelwell | | |
| 13 | A/C Pressure Sensor | 3-BLK | Right Side of Engine Compartment | | |
| 14 | VSA Modulator-Control Unit | 47-BLK/ WHT 3-BLK | Right Side of Engine Compartment | | |
| 15 | Right Front TPMS Initiator | 3-BLK | Right Front Wheelwell | | |
Scheme 362
Right Engine Compartment Wire Harness (Dashboard Branch)
Scheme 363
Dashboard Wire Harness (View of Driver's Side)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | G501 | | Under Left Side of Dash | Body Ground via Dashboard Wire Harness | |
| 2 | Gauge Control Module | 32-GRY | Left Side of Dash | | |
| 3 | Driver's Junction Box 1 Connector E | 10-WHT | Under Left Side of Dash | | |
| 4 | Driver's Junction Box 1 Connector F | 8-WHT | Under Left Side of Dash | | |
| 5 | Driver's Junction Box 1 Connector H | 10-BLU | Under Left Side of Dash | | |
| 6 | Driver's Junction Box 1 Connector G | 10-LT GRN | Under Left Side of Dash | | |
| 7 | Driver's Junction Box 1 Connector D | 4-WHT | Under Left Side of Dash | | |
| 8 | Driver's Junction Box 1 Connector A | 6-BLU | Under Left Side of Dash | | |
| 9 | Driver's Junction Box 1 Connector B | 6-BRN | Under Left Side of Dash | | |
| 10 | Driver's Junction Box 1 Connector C | 8-BRN | Under Left Side of Dash | | |
| 11 | Driver's Under-dash Fuse/Relay Box Connector M (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 4-YEL | Behind Left Kick Panel | | |
| 12 | Driver's Under-dash Fuse/Relay Box Connector N (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 16-LT GRN | Behind Left Kick Panel | | |
| 13 | Driver's Under-dash Fuse/Relay Box Connector P (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 20-LT GRN | Behind Left Kick Panel | | |
| 14 | Driver's Under-dash Fuse/Relay Box Connector R (Driver's MICU) (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 24-LT GRN | Behind Left Kick Panel | | |
| 15 | Driver's Under-dash Fuse/Relay Box Connector Q (Driver's MICU) (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 20-LT GRN | Behind Left Kick Panel | | |
| 16 | VSA OFF Switch | 5-BLU | Left Side of Dash | | |
| 17 | Driver's Footwell Light | 2-GRY | Under Left Side of Dash | | |
| 18 | Driver's Under-dash Fuse/Relay Box Connector C (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 5-LT GRN | Behind Left Kick Panel | | |
| 19 | G502 | | Under Left Side of Dash | Body Ground via Dashboard Wire Harness | |
| 20 | C303 (Male) | 4-YEL | Behind Left Kick Panel | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
Scheme 364
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 21 | C301 (Male) | 24-WHT | Behind Left Kick Panel | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
| 22 | C304 (Male) | 13-WHT | Behind Left Kick Panel | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
| 23 | C302 (Male) | 2-WHT | Behind Left Kick Panel | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
| 24 | C501 (Male) | 20-WHT | Behind Left Kick Panel | Roof Wire Harness (see ROOF WIRE HARNESS ) | |
| 25 | C602 (Female) | 16-WHT | Behind Left Kick Panel | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS ) | |
| 26 | C601 (Female) | 23-WHT | Behind Left Kick Panel | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS ) | |
| 27 | DLC | 16-GRY | Under Left Side of Dash | | |
| 28 | C502 (Male) | 12-WHT | Behind Left Kick Panel | Roof Wire Harness (see ROOF WIRE HARNESS ) | |
| 29 | Driver's Under-dash Fuse/Relay Box Connector B (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 2-LT GRN | Behind Left Kick Panel | | |
| 30 | C751 (Female) | 28-WHT | Left A-pillar | Driver's Door Wire Harness (see DRIVER'S DOOR WIRE HARNESS ) | |
| 31 | Driver's Junction Box 2 Connector B | 4-BLU | Under Left Side of Dash | | |
| 32 | Driver's Junction Box 2 Connector C | 4-BRN | Under Left Side of Dash | | |
| 33 | Driver's Junction Box 2 Connector D | 6-WHT | Under Left Side of Dash | | |
| 34 | Driver's Junction Box 2 Connector F | 6-BLU | Under Left Side of Dash | | |
| 35 | Driver's Junction Box 2 Connector G | 6-BRN | Under Left Side of Dash | | |
| 36 | Driver's Junction Box 2 Connector K | 10-WHT | Under Left Side of Dash | | |
| 37 | Driver's Junction Box 2 Connector J | 8-WHT | Under Left Side of Dash | | |
| 38 | Driver's Junction Box 2 Connector H | 4-WHT | Under Left Side of Dash | | |
| 39 | Driver's Junction Box 2 Connector E | 6-GRY | Under Left Side of Dash | | |
| 40 | Driver's Junction Box 2 Connector A | 4-GRY | Under Left Side of Dash | | |
Scheme 365
Dashboard Wire Harness (View of Steering Column Side)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Steering Angle Sensor | 5-GRN | In Steering Column Cover | | |
| 2 | Combination Light Switch | 12-BLK/ WHT | In Steering Column Cover | | |
| 3 | Cable Reel Connector A | 20-WHT | In Steering Column Cover | Cable Reel Connector C | |
| 4 | Cable Reel Connector B | 4-YEL | In Steering Column Cover | Driver's Airbag First and Second Inflators | |
| 5 | TPMS Control Unit | 20-GRY | Under Left Side of Dash | | |
| 6 | Console Accessory Power Socket Relay | 4-BLK | Under Left Side of Dash | | |
| 7 | ACC Cut Relay | 5-GRY | Under Left Side of Dash | | |
| 8 | IG2 Cut Relay | 5-GRY | Under Left Side of Dash | | |
| 9 | Center Junction Box Connector G | 6-BRN | Under Left Side of Dash | | |
| 10 | Center Junction Box Connector K | 10-WHT | Under Left Side of Dash | | |
| 11 | Center Junction Box Connector J | 8-WHT | Under Left Side of Dash | | |
| 12 | Center Junction Box Connector H | 4-WHT | Under Left Side of Dash | | |
| 13 | Center Junction Box Connector F | 6-BLU | Under Left Side of Dash | | |
| 14 | Center Junction Box Connector E | 6-GRY | Under Left Side of Dash | | |
| 15 | Center Junction Box Connector A | 4-GRY | Under Left Side of Dash | | |
| 16 | Center Junction Box Connector B | 4-BLU | Under Left Side of Dash | | |
| 17 | Center Junction Box Connector C | 4-BRN | Under Left Side of Dash | | |
| 18 | Center Junction Box Connector D | 6-WHT | Under Left Side of Dash | | |
| 19 | Wiper/Washer Switch | 8-BLK/ WHT | In Steering Column Cover | | |
| 20 | Immobilizer-Keyless Control Unit | 7-WHT | In Steering Column Cover | | |
| 21 | Ignition Key Switch/Key Light | 6-GRN | In Steering Column Cover | | |
| 22 | Ignition Switch | 5-WHT | In Steering Column Cover | | |
Scheme 366
Dashboard Wire Harness (View of Middle to Passenger's Side)
Scheme 367
Audio Wire Harness (Navigation)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Climate Control Unit Connector B | 12-GRY | Behind Climate Control Unit | | |
| 2 | Climate Control Unit Connector A | 28-GRY | Behind Climate Control Unit | | |
| 3 | Hazard Warning Switch | 5-WHT | Middle of Dash | | |
| 4 | Interface Dial | 5-GRN | Middle of Dash | | |
| 5 | Audio/Navigation Switch Panel | 24-GRY | Middle of Dash | | |
| 6 | ANC/Active Sound Control Unit | 16-GRY | Behind Middle of Dash | | |
| 7 | Front Center Speaker | 2-GRY | Middle of Dash | | Navigation |
| 8 | Navigation Display Unit | 28-GRY | Middle of Dash | | |
| 9 | Automatic Lighting Sensor/Sunlight Sensor | 5-GRN | Middle of Dash | | |
| 10 | Front Passenger's Airbag Cut-off Indicator | 4-WHT | Middle of Dash | | USA, Canada |
| 11 | C401 (Male) | 28-WHT | Behind Glove Box | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) | |
| 12 | C402 (Male) | 16-WHT | Behind Glove Box | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) | |
| 13 | Trunk Lid Opener Main Switch | 2-WHT | Glove Box | | |
| 14 | Glove Box Light | 2-GRY | Glove Box | | |
| 15 | HandsFreeLink Control Unit | 28-GRY | Under Right Side of Dash | | |
| 16 | C411 (Male) | 34-WHT | Behind Right Kick Panel | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS ) | |
| 17 | C410 (Male) | 28-WHT | Behind Right Kick Panel | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS ) | |
| 18 | C408 (Junction Connector) | 12-WHT | Under Right Side of Dash | | XM Radio, AcuraLink |
| 19 | Navigation Service Check Connector | 2-WHT | Under Right Side of Dash | | |
| 20 | C412 (Male) | 12-WHT | Under Right Side of Dash | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS ) | XM Radio, AcuraLink |
| 21 | Passenger's Under-dash Fuse/Relay Box Connector D (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 28-LT GRN | Behind Right Kick Panel | | |
| 22 | C407 (Junction Connector) | 12-WHT | Under Right Side of Dash | | XM Radio, AcuraLink |
Scheme 368
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 23 | G401 | | Behind Middle of Dash | Body Ground via Audio Wire Harness | |
| 24 | C406 (Junction Connector) | 12-WHT | Behind Middle of Dash | | |
| 25 | C413 Junction Connector | 12-BLU | Behind Middle of Dash | | |
| 26 | C403 (Male) | 16-WHT | Under Middle of Dash | SRS Floor Wire Harness (see SRS FLOOR WIRE HARNESS ) | |
| 27 | C409 (Male) | 20-WHT | Under Middle of Dash | A/C Wire Harness (see A/C WIRE HARNESS ) | |
| 28 | C405 (Junction Connector) | 12-BLU | Behind Middle of Dash | | |
| 29 | C404 (Junction Connector) | 12-BRN | Behind Middle of Dash | | |
| 30 | Audio-Navigation Unit H | 28-GRY | Behind Audio-Navigation Unit | | |
| 31 | Audio-Navigation Unit A | 24-GRY | Behind Audio-Navigation Unit | | |
| 32 | Audio-Navigation Unit B | 24-GRY | Behind Audio-Navigation Unit | | |
| 33 | Audio-Navigation Unit F | 12-GRY | Behind Audio-Navigation Unit | | |
| 34 | Audio-Navigation Unit C | 14-WHT | Behind Audio-Navigation Unit | | |
| 35 | Auxiliary Jack Assembly | 5-GRN | Center Console | | |
| 36 | Console Accessory Power Socket | 2-BLK | Center Console | | |
| 37 | Audio-Navigation Unit D | 20-GRY | Behind Audio-Navigation Unit | | |
| 38 | Audio-Navigation Unit G | 8-GRY | Behind Audio-Navigation Unit | | |
Scheme 369
Audio Wire Harness (without Navigation)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Audio Unit Connector A | 24-GRY | Behind Audio Unit | | |
| 2 | Audio Unit Connector B | 20-GRY | Behind Audio Unit | | |
| 3 | Audio Unit Connector D | 8-GRY | Behind Audio Unit | | |
| 4 | Audio Unit Connector E | 14-WHT | Behind Audio Unit | | |
| 5 | Audio-HVAC Display Unit | 12-GRY | Middle of Dash | | |
| 6 | Automatic Lighting Sensor/Sunlight Sensor | 5-GRN | Middle of Dash | | |
| 7 | Front Passenger's Airbag Cut-off Indicator | 4-WHT | Middle of Dash | | USA, Canada |
| 8 | C401 (Male) | 28-WHT | Behind Glove Box | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) | |
| 9 | C402 (Male) | 16-WHT | Behind Glove Box | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) | |
| 10 | Trunk Lid Opener Main Switch | 2-WHT | Glove Box | | |
| 11 | Glove Box Light | 2-GRY | Glove Box | | |
| 12 | HandsFreeLink Control Unit | 28-GRY | Under Right Side of Dash | | |
| 13 | C411 (Male) | 34-WHT | Behind Right Kick Panel | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS ) | |
| 14 | C410 (Male) | 28-WHT | Behind Right Kick Panel | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS ) | |
| 15 | C408 (Junction Connector) | 12-WHT | Under Right Side of Dash | | XM Radio |
| 16 | C412 (Male) | 12-WHT | Under Right Side of Dash | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS ) | XM Radio |
| 17 | Passenger's Under-dash Fuse/Relay Box Connector D (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 28-LT GRN | Behind Right Kick Panel | | |
| 18 | C407 (Junction Connector) | 12-WHT | Under Right Side of Dash | | XM Radio |
| 19 | G401 | | Behind Middle of Dash | Body Ground via Audio Wire Harness | |
| 20 | C406 (Junction Connector) | 12-WHT | Behind Middle of Dash | | |
| 21 | C413 (Junction Connector) | 12-BLU | Behind Middle of Dash | | |
| 22 | C403 (Male) | 16-WHT | Under Middle of Dash | SRS Floor Wire Harness (see SRS FLOOR WIRE HARNESS ) | |
| 23 | C409 (Male) | 20-WHT | Under Middle of Dash | A/C Wire Harness (see A/C WIRE HARNESS ) | |
Scheme 370
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 24 | C405 (Junction Connector) | 12-BLU | Behind Middle of Dash | | |
| 25 | C404 (Junction Connector) | 12-BRN | Behind Middle of Dash | | |
| 26 | Center Pocket Light | 2-GRY | Middle of Dash | | |
| 27 | ANC/Active Sound Control Unit | 16-GRY | Behind Middle of Dash | | |
| 28 | Climate Control Unit Connector B | 12-GRY | Behind Climate Control Unit | | |
| 29 | Climate Control Unit Connector A | 28-GRY | Behind Climate Control Unit | | |
| 30 | Auxiliary Jack Assembly | 5-GRN | Center Console | | |
| 31 | USB Adapter Control Unit Connector A | 14-WHT | Under Center Console | | |
| 32 | Console Accessory Power Socket | 2-BLK | Center Console | | |
| 33 | Hazard Warning Switch | 5-WHT | Middle of Dash | | |
Scheme 371
Left Side Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | C305 (Male) | 8-WHT | Behind Left Kick Panel | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
| 2 | Driver's Under-dash Fuse/Relay Box Connector E (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 20-LT GRN | Behind Left Kick Panel | | |
| 3 | Driver's Under-dash Fuse/Relay Box Connector D (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 16-LT GRN | Behind Left Kick Panel | | |
| 4 | G603 | | Left Rear of Floor | Body Ground via Left Side Wire Harness | |
| 5 | Fuel Tank Unit | 4-GRY | Rear of Floor | | |
| 6 | G602 | | Left C-pillar | Body Ground via Left Side Wire Harness | |
| 7 | Rear Window Defogger Connector A | 1-BLK | Left C-pillar | | |
| 8 | Subwoofer | 2-GRY | Middle of Rear Shelf | | |
| 9 | C654 (Female) | 18-BRN | Right Side of Rear Shelf | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS ) | |
| 10 | High Mount Brake Light | 2-GRY | Middle of Rear Shelf | | |
| 11 | Trunk Light | 2-WHT | Middle of Rear Shelf | | |
| 12 | Left Rear Speaker | 2-GRY | Left Side of Rear Shelf | | |
| 13 | Fuel Fill Door Lock Actuator | 2-GRY | Left Side of Trunk | | |
| 14 | C604 (Female) | 20-WHT | Left Side of Trunk | Rear Wire Harness (see REAR WIRE HARNESS ) | |
| 15 | EVAP Canister Vent Shut Valve | 2-LT GRN | Under Middle Rear of Vehicle | | USA, Canada |
| 16 | FTP Sensor | 3-BLK | Under Middle Rear of Vehicle | | USA, Canada |
| 17 | Left Rear Wheel Speed Sensor | 2-BLK | Under Left Rear of Vehicle | | |
| 18 | Rear Window Defogger Noise Condenser A | 2-WHT | Left C-pillar | | |
| 19 | Left Rear TPMS Initiator | 3-BLK | Left Rear Wheelwell | | |
| 20 | Left Rear Door Switch | 1-WHT | Left C-pillar | | |
| 21 | Rear Window Defogger Noise Condenser B | 2-WHT | Left C-pillar | | |
| 22 | C771 (Female) | 18-WHT | Left B-pillar | Left Rear Door Wire Harness (see LEFT REAR DOOR WIRE HARNESS ) | |
| 23 | Driver's Door Switch | 1-WHT | Left B-pillar | | |
| 24 | C603 (Male) | 2-GRY | Left Side of Floor | SRS Floor Wire Harness (see SRS FLOOR WIRE HARNESS ) | |
| 25 | C602 (Male) | 16-WHT | Behind Left Kick Panel | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF STEERING COLUMN SIDE) ) | |
| 26 | C601 (Male) | 23-WHT | Behind Left Kick Panel | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF STEERING COLUMN SIDE) ) | |
| 27 | G601 | | Left Side of Floor | Body Ground via Left Side Wire Harness | |
Scheme 372
SRS Floor Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | C701 (Female) | 23-WHT | Under Driver's Seat | Driver's Seat Wire Harness (see DRIVER'S SEAT WIRE HARNESS ) | |
| 2 | Driver's Side Airbag Inflator | 2-YEL | Under Driver's Seat | | |
| 3 | SRS Unit Connector B | 39-YEL | Behind Middle of Dash | | |
| 4 | C403 (Female) | 16-WHT | Under Middle of Dash | Audio Wire Harness (see AUDIO WIRE HARNESS (WITHOUT NAVIGATION) or AUDIO WIRE HARNESS (WITHOUT NAVIGATION) ) | |
| 5 | C703 (Female) | 4-WHT | Under Front Passenger's Seat | ODS Unit Wire Harness (see ODS UNIT WIRE HARNESS ) | |
| 6 | C702 (Female) | 18-BLU/ WHT | Under Front Passenger's Seat | Front Passenger's Seat Wire Harness (see FRONT PASSENGER'S SEAT WIRE HARNESS ) | |
| 7 | Front Passenger's Side Airbag Inflator | 2-YEL | Under Front Passenger's Seat | | |
| 8 | G702 | | Right Side of Floor | Body Ground via SRS Floor Wire Harness | |
| 9 | C653 (Female) | 4-GRY | Right Side of Floor | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS ) | |
| 10 | Right Side Impact Sensor (1st) | 4-YEL | Right B-pillar | | |
| 11 | Front Passenger's Seat Belt Tensioner | 4-YEL | Right B-pillar | | |
| 12 | Right Side Curtain Airbag Inflator | 2-YEL | Right C-pillar | | |
| 13 | Right Side Impact Sensor (2nd) | 2-YEL | Right C-pillar | | |
| 14 | Left Side Curtain Airbag Inflator | 2-YEL | Left C-pillar | | |
| 15 | Rear Safing Sensor | 4-YEL | Rear of Floor | | |
| 16 | Left Side Impact Sensor (2nd) | 2-YEL | Left C-pillar | | |
| 17 | Driver's Seat Belt Tensioner | 4-YEL | Left B-pillar | | |
| 18 | Left Side Impact Sensor (1st) | 4-YEL | Left B-pillar | | |
| 19 | C603 (Female) | 2-GRY | Left Side of Floor | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS ) | |
| 20 | G701 | | Left Side of Floor | Body Ground via SRS Floor Wire Harness | |
Scheme 373
Right Side Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | C654 (Male) | 18-BRN | Right Side of Rear Shelf | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS ) | |
| 2 | C652 (Junction Connector) | 12-BRN | Right Side of Rear Shelf | | AcuraLink |
| 3 | Right Rear Speaker | 2-GRY | Right Side of Rear Shelf | | |
| 6 | AcuraLink Control Unit (XM Receiver) Connector A | 32-GRY | Right C-pillar | | AcuraLink |
| 6 | XM Receiver Connector A | 14-WHT | Right C-pillar | | XM Radio |
| 7 | AcuraLink Reprogramming Connector | 5-WHT | Right C-pillar | | AcuraLink |
| 8 | Front Passenger's Door Switch | 1-WHT | Right B-pillar | | |
| 9 | C651 (Female) | 23-WHT | Behind Right Kick Panel | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) | |
| 10 | C410 (Female) | 28-WHT | Behind Right Kick Panel | Audio Wire Harness (see AUDIO WIRE HARNESS (NAVIGATION) or AUDIO WIRE HARNESS (WITHOUT NAVIGATION) ) | |
| 11 | C411 (Female) | 34-WHT | Behind Right Kick Panel | Audio Wire Harness (see AUDIO WIRE HARNESS (NAVIGATION) or AUDIO WIRE HARNESS (WITHOUT NAVIGATION) ) | |
| 12 | C412 (Female) | 12-WHT | Under Right Side of Dash | Audio Wire Harness (see AUDIO WIRE HARNESS (NAVIGATION) or AUDIO WIRE HARNESS (WITHOUT NAVIGATION) ) | XM Radio, AcuraLink |
| 13 | Passenger's Under-dash Fuse/Relay Box Connector H (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 38-LT GRN | Behind Right Kick Panel | | |
| 14 | G651 | | Right Side of Floor | Body Ground via Right Side Wire Harness | |
| 15 | C653 (Male) | 4-GRY | Right Side of Floor | SRS Floor Wire Harness (see SRS FLOOR WIRE HARNESS ) | |
| 16 | C781 (Female) | 18-WHT | Right B-pillar | Right Rear Door Wire Harness (see RIGHT REAR DOOR WIRE HARNESS ) | |
| 17 | Right Rear Door Switch | 1-WHT | Right C-pillar | | |
| 18 | Right Rear TPMS Initiator | 3-BLK | Right Rear Wheelwell | | |
| 19 | Right Rear Wheel Speed Sensor | 2-BLK | Under Right Rear of Vehicle | | |
| 20 | Stereo Amplifier Connector C | 5-GRY | Right Side of Trunk | | Navigation |
| 21 | Stereo Amplifier Connector B | 28-GRY | Right Side of Trunk | | Navigation |
| 21 | Stereo Amplifier Connector B | 24-GRY | Right Side of Trunk | | Without Navigation |
| 22 | Stereo Amplifier Connector A | 18-GRY | Right Side of Trunk | | |
| 23 | C655 (Female) | 6-WHT | Right Side of Trunk | Rear Wire Harness (see REAR WIRE HARNESS ) | Navigation |
| 24 | Electrical Compass Unit | 6-BLU | Right Side of Rear Shelf | | Electrical Compass |
Rear Window Defogger Ground Wire
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 4 | Rear Window Defogger Connector B | 1-BLK | Right C-pillar | | |
| 5 | G801 | | Right C-pillar | Body Ground via Rear Window Defogger Ground Wire | |
Scheme 374
Rear Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Rearview Camera | 6-WHT | Left Side of Trunk Lid | | Navigation |
| 2 | Left License Plate Light | 2-WHT | Middle of Trunk Lid | | |
| 3 | Trunk Lid Outer Handle Switch | 3-GRY | Middle of Trunk Lid | | |
| 4 | Right License Plate Light | 2-WHT | Middle of Trunk Lid | | |
| 5 | Right Back-up Light | 3-GRY | Right Side of Trunk Lid | | |
| 6 | Right Rear Side Marker Light | 2-WHT | Right Side of Trunk | | |
| 7 | Right Rear Turn Signal Light | 3-GRY | Right Side of Trunk | | |
| 8 | Right Brake Light/Taillight | 4-GRY | Right Side of Trunk | | |
| 9 | C655 (Male) | 6-WHT | Right Side of Trunk | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS ) | Navigation |
| 10 | Trunk Lid Opener Solenoid/Latch Switch | 3-GRY | Middle of Trunk Lid | | |
| 11 | Left Back-up Light | 3-GRY | Left Side of Trunk Lid | | |
| 12 | G901 | | Left Side of Trunk | Body Ground via Rear Wire Harness | |
| 13 | Left Brake Light/Taillight | 4-GRY | Left Side of Trunk | | |
| 14 | Left Rear Turn Signal Light | 3-GRY | Left Side of Trunk | | |
| 15 | Left Rear Side Marker Light | 2-WHT | Left Side of Trunk | | |
| 16 | C604 (Male) | 20-WHT | Left Side of Trunk | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS ) | |
Scheme 375
Driver's Door Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Power Window Master Switch | 37-GRY | Driver's Door | | |
| 4 | Driver's Door Tweeter | 2-BLK | Driver's Door | | |
| 5 | Left Power Mirror | 13-WHT | Driver's Door | | |
| 6 | C754 (Junction Connector) | 12-GRY | Driver's Door | | |
| 7 | C751 (Male) | 28-WHT | Left A-pillar | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF STEERING COLUMN SIDE) ) | |
| 8 | C753 (Male) | 20-WHT | Driver's Door | DRIVER'S DOOR SWITCH SUB-HARNESS | |
| 9 | Driver's Door Speaker | 2-GRY | Driver's Door | | |
| 10 | Trunk Lid Opener Switch | 5-WHT | Driver's Door | | |
| 11 | Driver's Power Window Motor | 6-BLK | Driver's Door | | |
| 13 | C752 (Female) | 2-WHT | Driver's Door | DRIVER'S DOOR COURTESY LIGHT SUB-HARNESS | |
| 14 | Driver's Door Lock Actuator/Knob Switch/Key Cylinder Switch | 10-WHT | Driver's Door | | |
Driver's Door Courtesy Light Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 12 | Driver's Door Courtesy Light | 2-GRY | Driver's Door | | |
| 13 | C752 (Male) | 2-WHT | Driver's Door | DRIVER'S DOOR WIRE HARNESS | |
Driver's Door Switch Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 2 | Driving Position Memory Switch (DPMS) | 7-WHT | Driver's Door | | |
| 3 | Power Mirror Switch | 13-WHT | Driver's Door | | |
| 8 | C753 (Female) | 20-WHT | Driver's Door | DRIVER'S DOOR WIRE HARNESS | |
Scheme 376
Front Passenger's Door Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Right Power Mirror | 13-WHT | Front Passenger's Door | | |
| 2 | Front Passenger's Door Tweeter | 2-BLK | Front Passenger's Door | | |
| 3 | Front Passenger's Power Window Switch | 37-GRY | Front Passenger's Door | | |
| 4 | Front Passenger's Door Lock Actuator/Knob Switch | 10-WHT | Front Passenger's Door | | |
| 5 | C762 (Female) | 2-WHT | Front Passenger's Door | FRONT PASSENGER'S DOOR COURTESY LIGHT SUB-HARNESS | |
| 7 | Front Passenger's Power Window Motor | 6-BLK | Front Passenger's Door | | |
| 8 | Front Passenger's Door Speaker | 2-GRY | Front Passenger's Door | | |
| 9 | C761 (Male) | 23-BLU/ WHT | Right A-pillar | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) | |
Front Passenger's Door Courtesy Light Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 5 | C762 (Male) | 2-WHT | Front Passenger's Door | Front Passenger's Door Wire | |
| 6 | Front Passenger's Door Courtesy Light | 2-GRY | Front Passenger's Door | | |
Scheme 377
Left Rear Door Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Left Rear Door Lock Actuator/Knob Switch | 10-WHT | Left Rear Door | | |
| 2 | Left Rear Power Window Switch | 14-GRY | Left Rear Door | | |
| 3 | C771 (Male) | 18-WHT | Left B-pillar | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS ) | |
| 4 | Left Rear Door Speaker | 2-GRY | Left Rear Door | | Navigation |
| 5 | Left Rear Door Courtesy Light | 2-GRY | Left Rear Door | | |
| 6 | Left Rear Power Window Motor | 2-GRY | Left Rear Door | | |
Scheme 378
Right Rear Door Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Right Rear Power Window Switch | 14-GRY | Right Rear Door | | |
| 2 | Right Rear Door Lock Actuator/Knob Switch | 10-WHT | Right Rear Door | | |
| 3 | Right Rear Power Window Motor | 2-GRY | Right Rear Door | | |
| 4 | Right Rear Door Courtesy Light | 2-GRY | Right Rear Door | | |
| 5 | Right Rear Door Speaker | 2-GRY | Right Rear Door | | Navigation |
| 6 | C781 (Male) | 18-WHT | Right B-pillar | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS ) | |
Scheme 379
Roof Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Front Passenger's Vanity Mirror Light | 2-WHT | Front Passenger's Sunvisor Mount | | |
| 2 | Automatic Dimming Inside Mirror | 7-BLK | Behind Rearview Mirror | | |
| 3 | Interior Light/Moonroof Switch | 12-GRY | Front of Roof | | |
| 4 | HomeLink® Unit | 5-GRY | Front of Roof | | |
| 5 | Front HFL-Navigation-ANC/Active Sound Control Microphone | 7-GRY | Front of Roof | | Navigation |
| 5 | Front ANC/Active Sound Control Microphone | 3-GRY | Front of Roof | | Without Navigation |
| 6 | HFL Microphone | 3-GRN | Front of Roof | | Without Navigation |
| 7 | C551 (Female) | 13-WHT | Front of Roof | MOONROOF SUB-HARNESS | |
| 8 | C552 (Junction Connector) | 12-BRN | Left Front of Roof | | |
| 11 | Rear ANC/Active Sound Control Microphone | 2-GRN | Rear of Roof | | |
| 12 | Driver's Vanity Mirror Light | 2-WHT | Driver's Sunvisor Mount | | |
| 13 | Front Individual Map Lights | 3-GRY | Front of Roof | | |
| 14 | C502 (Female) | 12-WHT | Behind Left Kick Panel | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF STEERING COLUMN SIDE) ) | |
| 15 | C501 (Female) | 20-WHT | Behind Left Kick Panel | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF STEERING COLUMN SIDE) ) | |
Moonroof Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 7 | C551 (Male) | 13-WHT | Front of Roof | ROOF WIRE HARNESS | |
| 9 | Ceiling Light | 3-NAT | Rear of Roof | | |
| 10 | Moonroof Control Unit/Motor | 14-GRY | Middle of Roof | | |
Scheme 380
Driver's Seat Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Driver's Seat Position Sensor | 2-BLK | Under Driver's Seat | | USA, Canada |
| 2 | Driver's Power Seat Rear Up-down Motor/Position Sensor | 5-WHT | Under Driver's Seat | | |
| 3 | Driver's Power Seat Adjustment Switch | 12-GRY | Left Side of Driver's Seat | | |
| 4 | C701 (Male) | 23-WHT | Under Driver's Seat | SRS Floor Wire Harness (see SRS FLOOR WIRE HARNESS ) | |
| 5 | Driver's Power Seat Recline Motor/Position Sensor | 5-BLU | Under Driver's Seat | | |
| 6 | Power Seat Control Unit Connector A | 40-GRY | Under Driver's Seat | | |
| 7 | Driver's Seat Heater Connector A | 4-GRY | Under Driver's Seat | | |
| 8 | Power Seat Control Unit Connector B | 18-GRY | Under Driver's Seat | | |
| 9 | Driver's Seat Heater Connector B | 2-GRY | Under Driver's Seat | | |
| 10 | Driver's Seat Belt Buckle Switch | 2-WHT | Under Driver's Seat | | |
| 11 | Driver's Seat Heater Relay (Low) | 5-BLU | Under Driver's Seat | | |
| 12 | Driver's Seat Heater Relay (High) | 4-BLU | Under Driver's Seat | | |
| 13 | Driver's Power Seat Slide Motor/Position Sensor | 5-GRY | Under Driver's Seat | | |
| 14 | Driver's Power Seat Front Up-down Motor/Position Sensor | 5-WHT | Under Driver's Seat | | |
Scheme 381
Front Passenger's Seat Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Front Passenger's Seat Heater | 4-BRN/ GRY | Under Front Passenger's Seat | | |
| 2 | Front Passenger's Seat Belt Buckle Switch | 2-WHT | Under Front Passenger's Seat | | |
| 3 | Front Passenger's Seat Heater Relay (Low) | 5-BLU | Under Front Passenger's Seat | | |
| 4 | Front Passenger's Seat Heater Relay (High) | 4-BLU | Under Front Passenger's Seat | | |
| 5 | C702 (Male) | 18-BLU/ WHT | Under Front Passenger's Seat | SRS Floor Wire Harness (see SRS FLOOR WIRE HARNESS ) | |
| 6 | Front Passenger's Power Seat Adjustment Switch | 12-GRY | Right Side of Front Passenger's Seat | | |
| 7 | Front Passenger's Power Seat Recline Motor | 2-GRN | Under Front Passenger's Seat | | |
| 8 | Front Passenger's Power Seat Slide Motor | 5-GRY | Under Front Passenger's Seat | | |
Scheme 382
ODS Unit Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | ODS Unit Connector D | 18-BLK | Left Side of Front Passenger's Seat Back | | |
| 2 | Inner Side Front Passenger's Weight Sensor | 2-WHT | Under Front Passenger's Seat | | USA, Canada |
| 3 | C703 (Male) | 4-WHT | Under Front Passenger's Seat | SRS Floor Wire Harness (see SRS FLOOR WIRE HARNESS ) | |
| 4 | Outer Side Front Passenger's Weight Sensor | 3-WHT | Under Front Passenger's Seat | | USA, Canada |
Scheme 383
Cable Reel Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Audio Remote Switch | 12-WHT | Steering Wheel | | |
| 2 | Paddle Shifter - (Downshift Switch) | 4-WHT | Steering Wheel | | |
| 3 | Paddle Shifter + (Upshift Switch) | 4-WHT | Steering Wheel | | |
| 4 | Cruise Control Combination Switch | 12-WHT | Steering Wheel | | |
| 5 | Select/Reset/Information Switch | 7-GRN | Steering Wheel | | |
| 6 | Cable Reel Connector C | 20-WHT | Steering Wheel | Cable Reel Connector B | |
| 7 | Horn Switch | 2-WHT | Steering Wheel | | |
| 8 | HFL-Voice Control Switch | 7-GRN | Steering Wheel | | |
Scheme 384
A/C Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Driver's Air Mix Control Motor | 7-GRN | Under Left Side of Dash | | |
| 2 | C351 (Male) | 2-WHT | Under Left Side of Dash | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
| 3 | Mode Control Motor | 7-GRN | Under Right Side of Dash | | |
| 4 | Evaporator Temperature Sensor | 2-WHT | Behind Glove Box | | |
| 5 | Recirculation Control Motor | 7-GRN | Behind Glove Box | | |
| 6 | Blower Motor | 2-WHT | Under Right Side of Dash | | |
| 7 | Blower Power Transistor | 4-NAT | Under Right Side of Dash | | |
| 8 | C409 (Female) | 20-WHT | Under Middle of Dash | Audio Wire Harness (see AUDIO WIRE HARNESS (WITHOUT NAVIGATION) or AUDIO WIRE HARNESS (WITHOUT NAVIGATION) ) | |
| 9 | Front Passenger's Air Mix Control Motor | 7-GRN | Under Right Side of Dash | | |
Scheme 385
