Connector Index
Identification numbers have been assigned to in-line connectors, junction connectors, and terminals. The number is preceded by the letter "C" for connectors, "G" for ground terminals, or "T" for non-ground terminals.
| Harness | Location |
|---|
| Engine Compartment | Dashboard | Others (Floor, Door, Trunk, Tailgate, and Roof) | Notes |
| A/C wire harness | | C351, C409 | | Connector to Harness (see A/C WIRE HARNESS ) |
| Audio wire harness (with navigation) | | C401, C402, C403, C404, C405, C406, C407, C408, C409, C410, C411, C412, C413 G401 | | Connector to Harness (see AUDIO WIRE HARNESS (WITH NAVIGATION) ) |
| Audio wire harness (without navigation) | | C401, C402, C403, C404, C405, C406, C407, C408, C409, C410, C412, C413 G401 | | Connector to Harness (see AUDIO WIRE HARNESS (WITHOUT NAVIGATION) ) |
| Battery ground cable | (-), G1 | | | Connector to Harness (see CONNECTOR TO HARNESS INDEX ) |
| Cable reel subharness | | | | Connector to Harness (see CABLE REEL SUBHARNESS ) |
| CKP sensor subharness | C104 | | | Connector to Harness (see CKP SENSOR SUBHARNESS ) |
| Dashboard wire harness (view of driver's side) | | C301, C302, C303, C304, C501, C502, C601, C602, C751 G501, G502 | | Connector to Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) |
| Dashboard wire harness (view of middle to passenger's side) | | C204, C205, C206, C401, C402, C651, C761 G503, G505 | G504 | Connector to Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
| Dashboard wire harness (view of steering column side) | | | | Connector to Harness (see DASHBOARD WIRE HARNESS (VIEW OF STEERING COLUMN SIDE) ) |
| Driver's door courtesy light subharness | | | C752 | Connector to Harness (see DRIVER'S DOOR COURTESY LIGHT SUBHARNESS ) |
| Driver's door switch subharness | | | C753 | Connector to Harness (see DRIVER'S DOOR SWITCH SUBHARNESS ) |
| Driver's door wire harness | | | C751, C752, C753, C754 | Connector to Harness (see DRIVER'S DOOR WIRE HARNESS ) |
| Driver's seat wire harness (with DPMS) | | | C701 | Connector to Harness (see DRIVER'S SEAT WIRE HARNESS (WITH DPMS) ) |
| Driver's seat wire harness (without DPMS) | | | C701 | Connector to Harness (see DRIVER'S SEAT WIRE HARNESS (WITHOUT DPMS) ) |
| Engine ground cable | T1, G2 | | | Connector to Harness (see ENGINE GROUND CABLE ) |
| Engine wire harness (A/T) | C101, C102, C103, C104, C106, C107 G101, G102 | | | Connector to Harness (see ENGINE WIRE HARNESS (A/T) ) |
| Engine wire harness (M/T) | C101, C102, C103, C104, C105 G101, G102 | | | Connector to Harness (see ENGINE WIRE HARNESS (M/T) ) |
| EPS ground subharness | C251 T9 | | | Connector to Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) |
| EPS subharness | C354 T6, T7, T8 | | | Connector to Harness (see EPS SUBHARNESS ) |
| Front passenger's door courtesy light subharness | | | C762 | Connector to Harness (see FRONT PASSENGER'S DOOR COURTESY LIGHT SUBHARNESS ) |
| Front passenger's door wire harness | | | C761, C762 | Connector to Harness (see FRONT PASSENGER'S DOOR WIRE HARNESS ) |
| Front passenger's seat wire harness | | | C702 | Connector to Harness (see FRONT PASSENGER'S SEAT WIRE HARNESS ) |
| Left engine compartment subharness | | C202, C203, C352, C353 | | Connector to Harness (see LEFT ENGINE COMPARTMENT SUBHARNESS ) |
| Left engine compartment wire harness (dashboard branch) | | C301, C302, C303, C304, C305, C306, C351, C352, C353 G302 | | Connector to Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) |
| Left engine compartment wire harness (engine compartment branch) | C101, C151, C201, C251, C354 G301 | | | Connector to Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) |
| Left rear door wire harness | | | C771 | Connector to Harness (see LEFT REAR DOOR WIRE HARNESS ) |
| Left side wire harness (Sedan) | | C305, C601, C602 | C603, C604, C654, C771 G601, G602, G603 | Connector to Harness (see LEFT SIDE WIRE HARNESS (SEDAN) ) |
| Left side wire harness (Sport Wagon) | | C305, C306, C601, C602 | C603, C604, C605, C654, C771 G601, G603 | Connector to Harness (see LEFT SIDE WIRE HARNESS (SPORT WAGON) ) |
| Moonroof subharness (Sedan) | | | C551 | Connector to Harness (see MOONROOF SUBHARNESS (SEDAN) ) |
| Moonroof subharness (Sport Wagon) | | | C551 | Connector to Harness (see MOONROOF SUBHARNESS (SPORT WAGON) ) |
| ODS unit harness | | | C703 | Connector to Harness (see ODS UNIT HARNESS ) |
| Rear window defogger ground wire (Sedan) | | | C801 | Connector to Harness (see REAR WINDOW DEFOGGER GROUND WIRE (SEDAN) ) |
| Rear wire harness (Sedan) | | | C604, C655 G901 | Connector to Harness (see REAR WIRE HARNESS (SEDAN) ) |
| Rear wire harness (Sport Wagon) | | | C604, C605, C655, C661, C662, C663 G901 | Connector to Harness (see REAR WIRE HARNESS (SPORT WAGON) ) |
| Right engine compartment wire harness (dashboard branch) | | C202, C203, C204, C205, C206, C207 G201, G203 | | Connector to Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) |
| Right engine compartment wire harness (engine compartment branch) | C201 G202 | | | Connector to Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) |
| Right rear door wire harness | | | C781 | Connector to Harness (see RIGHT REAR DOOR WIRE HARNESS ) |
| Right side wire harness (Sedan) | | C410, C411, C412, C651 | C652, C653, C654, C655, C781 G651 | Connector to Harness (see RIGHT SIDE WIRE HARNESS (SEDAN) ) |
| Right side wire harness (Sport Wagon) | | C410, C411, C412, C651 | C652, C653, C654, C655, C781 G651 | Connector to Harness (see RIGHT SIDE WIRE HARNESS (SPORT WAGON) ) |
| Roof wire harness (Sedan) | | C501, C502 | C551, C552 | Connector to Harness (see ROOF WIRE HARNESS (SEDAN) ) |
| Roof wire harness (Sport Wagon) | | C501, C502 | C551, C552 | Connector to Harness (see ROOF WIRE HARNESS (SPORT WAGON) ) |
| Shift solenoid wire harness (A/T) | C106 | | | Connector to Harness (see SHIFT SOLENOID WIRE HARNESS (A/T) ) |
| SRS floor subharness (Sport Wagon) | | | C704 G751 | Connector to Harness (see SRS FLOOR WIRE HARNESS (SPORT WAGON) ) |
| SRS floor wire harness (Sedan) | | C403 | C603, C653, C701, C702, C703 G701, G702 | Connector to Harness (see SRS FLOOR WIRE HARNESS (SEDAN) ) |
| SRS floor wire harness (Sport Wagon) | | C403 | C603, C653, C701, C702, C703, C704 G701, G702 | Connector to Harness (see SRS FLOOR WIRE HARNESS (SPORT WAGON) ) |
| Starter subharness | (+), C102, C151, T4, T5, T101, T102 | | | Connector to Harness (see STARTER SUBHARNESS ) |
| Tailgate wire harness (Sport Wagon) | | | C661, C662, C663, C664 | Connector to Harness (see TAILGATE WIRE HARNESS (SPORT WAGON) ) |
| Transmission ground cable | T2, G3 | | | Connector to Harness (see TRANSMISSION GROUND CABLE ) |
| Transmission range switch subharness (A/T) | C107 | | | Connector to Harness (see CKP SENSOR SUBHARNESS ) |
Battery Ground Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| (-) | 2 | | Left side of engine compartment | Battery negative terminal | |
| G1 | 3 | | Left side of engine compartment | Body ground, via battery ground cable | |
BATTERY GROUND CABLE - CONNECTOR TO HARNESS INDEX
Engine Ground Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T1 | 6 | | Right side of engine compartment | Engine | |
| G2 | 1 | | Right side of engine compartment | Body ground, via engine ground cable | |
ENGINE GROUND CABLE - CONNECTOR TO HARNESS INDEX
Transmission Ground Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T2 | 5 | | Left side of engine compartment | Transmission housing | |
| G3 | 4 | | Left side of engine compartment | Body ground, via transmission ground cable | |
TRANSMISSION GROUND CABLE - CONNECTOR TO HARNESS INDEX
Scheme 1054
Starter Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C compressor | 9 | 3 | Right front of engine compartment | | |
| Alternator | 10 | 4 | Right front of engine compartment | | |
| Knock sensor | 8 | 1 | Front of engine | | |
| Starter solenoid | 2 | 1 | Front of engine | | |
| C102 | 7 | 10 | Front of engine | Engine wire harness M/T A/T | |
| C151 | 5 | 1 | Left side of engine compartment | Left engine compartment wire harness (engine compartment branch) | |
| T4 | 11 | | Right front of engine compartment | Alternator +B terminal | |
| T5 | 1 | | Front of engine | Starter motor | |
| T101 (battery) | 3 | | Left side of engine compartment | Under-hood fuse/relay box | |
| T102 (alternator) | 4 | | Left side of engine compartment | Under-hood fuse/relay box | |
| (+) | 6 | | Left side of engine compartment | Battery positive terminal | |
STARTER SUBHARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1055
Engine Wire Harness (M/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Air fuel ratio (A/F) sensor | 10 | 4 | Middle of engine compartment | | |
| Back-up light switch | 21 | 2 | On the transmission housing | | |
| Camshaft position (CMP) sensor A | 23 | 3 | Middle of engine compartment | | |
| Camshaft position (CMP) sensor B | 9 | 3 | Middle of engine compartment | | |
| ECM connector B | 20 | 49 | Left side of engine compartment | | |
| ECM connector C | 19 | 49 | Left side of engine compartment | | |
| Engine coolant temperature (ECT) sensor 1 | 15 | 2 | Middle of engine compartment | | |
| Engine mount control solenoid | 31 | 2 | Middle of engine compartment | | |
| EVAP canister purge valve | 14 | 2 | Middle of engine compartment | | |
| Ignition coil No. 1 | 5 | 3 | Middle of engine compartment | | |
| Ignition coil No. 2 | 6 | 3 | Middle of engine compartment | | |
| Ignition coil No. 3 | 7 | 3 | Middle of engine compartment | | |
| Ignition coil No. 4 | 8 | 3 | Middle of engine compartment | | |
| Injector No. 1 | 30 | 2 | Middle of engine compartment | | |
| Injector No. 2 | 29 | 2 | Middle of engine compartment | | |
| Injector No. 3 | 28 | 2 | Middle of engine compartment | | |
| Injector No. 4 | 27 | 2 | Middle of engine compartment | | |
| Manifold absolute pressure (MAP) sensor | 26 | 3 | Middle of engine compartment | | |
| Mass air flow (MAF) sensor/Intake air temperature (IAT) sensor | 17 | 5 | Air cleaner housing cover | | |
| Oil pressure switch | 2 | 1 | Middle of engine compartment | | |
| Output shaft (countershaft) speed sensor | 22 | 3 | Front of transmission housing | | |
| Reverse lockout solenoid | 18 | 2 | On the transmission housing | | |
| Rocker arm oil control solenoid | 3 | 2 | Middle of engine compartment | | |
| Rocker arm oil pressure switch | 4 | 2 | Middle of engine compartment | | |
| Secondary HO2S | 32 | 4 | Middle of engine compartment | | |
| Throttle position sensor/Throttle actuator | 24 | 6 | Middle of engine compartment | | |
| VTC oil control solenoid valve | 1 | 2 | Middle of engine compartment | | |
| C101 | 16 | 23 | Left side of engine compartment | Left engine compartment wire harness (engine compartment branch) | |
| C102 | 25 | 10 | Left side of engine compartment | Starter subharness | |
| C103 (junction connector) | 12 | 24 | Middle of engine compartment | | |
| C104 | 13 | 3 | Middle of engine compartment | CKP sensor subharness | |
| C105 (junction connector) | 11 | 12 | Middle of engine compartment | | |
| G101 | 33 | | Middle of engine compartment | Body ground, via engine wire harness | |
| G102 | 34 | | Middle of engine compartment | Body ground, via engine wire harness | |
ENGINE WIRE HARNESS (M/T) - CONNECTOR TO HARNESS INDEX
Scheme 1056
Engine Wire Harness (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/T clutch pressure control solenoid valve A | 25 | 2 | Transmission housing | | |
| A/T clutch pressure control solenoid valve B | 23 | 2 | Transmission housing | | |
| A/T clutch pressure control solenoid valve C | 22 | 2 | Transmission housing | | |
| Air fuel ratio (A/F) sensor | 9 | 4 | Exhaust manifold | | |
| Camshaft position (CMP) sensor A | 29 | 3 | Middle of engine compartment | | |
| Camshaft position (CMP) sensor B | 8 | 3 | Middle of engine compartment | | |
| Engine coolant temperature (ECT) sensor 1 | 13 | 2 | Middle of engine compartment | | |
| Engine mount control solenoid | 35 | 2 | Middle of engine compartment | | |
| EVAP canister purge valve | 10 | 2 | Middle of engine compartment | | |
| Ignition coil No. 1 | 4 | 3 | Middle of engine compartment | | |
| Ignition coil No. 2 | 5 | 3 | Middle of engine compartment | | |
| Ignition coil No. 3 | 6 | 3 | Middle of engine compartment | | |
| Ignition coil No. 4 | 7 | 3 | Middle of engine compartment | | |
| Injector No. 1 | 34 | 2 | Middle of engine compartment | | |
| Injector No. 2 | 33 | 2 | Middle of engine compartment | | |
| Injector No. 3 | 32 | 2 | Middle of engine compartment | | |
| Injector No. 4 | 31 | 2 | Middle of engine compartment | | |
| Input shaft (mainshaft) speed sensor | 16 | 3 | Transmission housing | | |
| Manifold absolute pressure (MAP) sensor | 30 | 3 | Middle of engine compartment | | |
| Mass air flow (MAF) sensor/Intake air temperature (IAT) sensor | 17 | 5 | Middle of engine compartment | | |
| Oil pressure switch | 1 | 1 | Middle of engine compartment | | |
| Output shaft (countershaft) speed sensor | 14 | 3 | Transmission housing | | |
| PCM connector B | 20 | 49 | Left side of engine compartment | | |
| PCM connector C | 19 | 49 | Left side of engine compartment | | |
| Rocker arm oil control solenoid | 2 | 2 | Middle of engine compartment | | |
| Rocker arm oil pressure switch | 3 | 2 | Middle of engine compartment | | |
| Secondary HO2S | 36 | 4 | Exhaust manifold | | |
| Throttle position sensor/Throttle actuator | 27 | 6 | Middle of engine compartment | | |
| Transmission fluid pressure switch A (2nd clutch) | 26 | 1 | Transmission housing | | |
| Transmission fluid pressure switch B (3rd clutch) | 21 | 1 | Transmission housing | | |
| VTC oil control solenoid valve | 37 | 2 | Middle of engine compartment | | |
| C101 | 18 | 23 | Left side of engine compartment | Left engine compartment wire harness (Engine compartment branch) | |
| C102 | 28 | 10 | Left side of engine compartment | Starter subharness | |
| C103 (junction connector) | 11 | 24 | Middle of engine compartment | | |
| C104 | 12 | 3 | Middle of engine compartment | CKP sensor subharness | |
| C106 | 24 | 8 | Transmission housing | Shift solenoid wire harness | |
| C107 | 15 | 10 | Transmission housing | Transmission range switch subharness | |
| G101 | 38 | | Middle of engine compartment | Body ground, via engine wire harness | |
| G102 | 39 | | Middle of engine compartment | Body ground, via engine wire harness | |
ENGINE WIRE HARNESS (A/T) - CONNECTOR TO HARNESS INDEX
Scheme 1057
CKP Sensor Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| CKP sensor | 1 | 3 | Under the engine | | |
| C104 | 2 | 3 | Middle of engine compartment | Engine wire harness M/T A/T | |
CKP SENSOR SUBHARNESS - CONNECTOR TO HARNESS INDEX
Shift Solenoid Wire Harness (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| ATF temperature sensor | 9 | 2 | In the transmission | | |
| Shift solenoid valve A | 8 | 1 | In the transmission | | |
| Shift solenoid valve B | 6 | 1 | In the transmission | | |
| Shift solenoid valve C | 5 | 1 | In the transmission | | |
| Shift solenoid valve E | 7 | 1 | In the transmission | | |
| C106 | 10 | 8 | Transmission housing | Engine wire harness | |
SHIFT SOLENOID WIRE HARNESS (A/T) - CONNECTOR TO HARNESS INDEX
Transmission Range Switch Subharness (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Transmission range switch | 4 | 10 | Left side of transmission | | |
| C107 | 3 | 10 | Transmission housing | Engine wire harness | |
TRANSMISSION RANGE SWITCH SUBHARNESS (A/T) - CONNECTOR TO HARNESS INDEX
Scheme 1058
EPS Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Torque sensor | 5 | 3 | Left of engine compartment | | |
| C354 | 4 | 6 | Left of engine compartment | Left engine compartment wire harness (engine compartment branch) | |
| T6 | 3 | | Middle of engine compartment | Steering gearbox | |
| T7 | 2 | | Middle of engine compartment | Steering gearbox | |
| T8 | 1 | | Middle of engine compartment | Steering gearbox | |
EPS SUBHARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1059
Left Engine Compartment Wire Harness (Engine Compartment Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C condenser fan motor | 25 | 2 | Front of engine compartment | | |
| Brake fluid level switch | 5 | 2 | Left side of engine compartment | | |
| ECM/PCM connector A | 12 | 49 | Left side of engine compartment | | |
| Engine coolant temperature (ECT) sensor 2 | 21 | 2 | Front of engine compartment | | |
| Horn (high) | 24 | 1 | Front of engine compartment | | |
| Horn (low) | 27 | 1 | Front of engine compartment | | |
| Keyless buzzer | 16 | 2 | Behind left side of front bumper | | |
| Left fog light | 15 | 2 | Behind left side of front bumper | | |
| Left front impact sensor | 17 | 2 | Behind left side of front bumper | | |
| Left front TPMS initiator | 9 | 3 | Left front of fender well | | |
| Left front parking/side marker/turn signal light | 11 | 3 | Behind left headlight | | |
| Left front wheel speed sensor | 8 | 2 | Left side of engine compartment | | |
| Left headlight (high) | 19 | 2 | Behind left headlight | | |
| Left headlight (low) | 13 | 3 | Behind left headlight | | (2) |
| Left HID unit | 13 | 2 | Behind left headlight | | (1) |
| Optional connector (for parking and back-up sensor system) | 18 | 3 | Left front of engine compartment | | |
| Outside air temperature sensor | 28 | 2 | Front of engine compartment | | |
| Radiator fan motor | 20 | 2 | Front of engine compartment | | |
| Security hood switch | 26 | 2 | Front of engine compartment | | |
| Under-hood fuse/relay box connector A (electrical load detector) (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 4 | 3 | Left side of engine compartment | | |
| Under-hood fuse/relay box connector B (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 2 | 14 | Left side of engine compartment | | |
| Under-hood fuse/relay box connector D (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 3 | 10 | Left side of engine compartment | | |
| Windshield wiper motor | 6 | 4 | Left side of engine compartment | | |
| C101 | 10 | 23 | Left side of engine compartment | Engine wire harness M/T A/T | |
| C151 | 1 | 1 | Left side of engine compartment | Starter subharness | |
| C201 | 29 | 2 | Right front of engine compartment | Right engine compartment wire harness (engine compartment branch) | |
| C251 | 23 | 1 | Left front of engine compartment | EPS ground subharness | |
| C354 | 7 | 6 | Left side of engine compartment | EPS subharness | |
| G301 | 14 | | Behind left side of front bumper | Body ground, via left engine compartment wire harness | |
| (1) With HID (2) Without HID |
LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) - CONNECTOR TO HARNESS INDEX
EPS Ground Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C251 | 23 | 1 | Left front of engine compartment | Left engine compartment wire harness (engine compartment branch) | |
| T9 | 22 | | Left front of engine compartment | Front suspension subframe | |
EPS GROUND SUBHARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1060
Left Engine Compartment Wire Harness (Dashboard Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Accelerator pedal position sensor | 7 | 6 | Under left side of dash | | |
| Brake pedal position switch | 8 | 4 | Under left side of dash | | |
| Clutch interlock switch (for starter cut) | 2 | 2 | Under left side of dash | | M/T |
| Clutch pedal position switch (for cruise) | 9 | 3 | Under left side of dash | | M/T |
| Driver's under-dash fuse/relay box connector F (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 17 | 33 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector G (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 16 | 13 | Under left side of dash | | |
| Optional connector (for parking and back-up sensor system) | 3 | 4 | Under left side of dash | | |
| C301 | 11 | 24 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C302 | 12 | 2 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C303 | 10 | 4 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C304 | 13 | 13 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C305 | 14 | 8 | Under left side of dash | Left side wire harness Sedan Sport Wagon | |
| C306 | 15 | 2 | Under left side of dash | Left side wire harness (Sport Wagon) | (1) |
| C351 | 6 | 2 | Under middle of dash | A/C wire harness | |
| C352 | 5 | 23 | Under middle of dash | Left engine compartment subharness | |
| C353 | 4 | 2 | Under middle of dash | Left engine compartment subharness | |
| G302 | 1 | | Under left side of dash | Body ground, via left engine compartment wire harness | |
| (1) With power tailgate |
LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) - CONNECTOR TO HARNESS INDEX
Scheme 1061
Left Engine Compartment Subharness
LEFT ENGINE COMPARTMENT SUBHARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1062
Right Engine Compartment Wire Harness (Engine Compartment Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C pressure sensor | 13 | 3 | Right front of engine compartment | | |
| EPS motor | 2 | 3 | Right rear of engine compartment | | |
| Motor angle sensor | 3 | 6 | Right rear of engine compartment | | |
| Right fog light | 6 | 2 | Behind right side of front bumper | | |
| Right front impact sensor | 7 | 2 | Behind right side of front bumper | | |
| Right front parking/side marker/turn signal light | 12 | 3 | Behind right headlight | | |
| Right front TPMS initiator | 15 | 3 | Right front of fender well | | |
| Right front wheel speed sensor | 1 | 2 | Right side of engine compartment | | |
| Right headlight (high) | 5 | 2 | Behind right headlight | | |
| Right headlight (low) | 10 | 3 | Behind right headlight | | (2) |
| Right HID unit | 10 | 2 | Behind right headlight | | (1) |
| VSA modulator-control unit | 14 | 32 | Right side of engine compartment | | |
| Washer fluid level switch | 9 | 2 | Behind right side of front bumper | | (3) |
| Windshield washer motor | 8 | 2 | Right front of engine compartment | | (4) |
| Windshield/Rear window washer motor | 8 | 2 | Behind right side of front bumper | | (5) |
| C201 | 4 | 2 | Right front of engine compartment | Left engine compartment wire harness (engine compartment branch) | |
| G202 | 16 | | Behind right side of front bumper | Body ground, via right engine compartment wire harness | |
| (1) With HID (2) Without HID (3) Canada models (4) Sedan (5) Sport Wagon |
RIGHT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) - CONNECTOR TO HARNESS INDEX
Scheme 1063
Right Engine Compartment Wire Harness (Dashboard Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| EPS control unit connector A | 9 | 2 | Under right side of dash | | |
| EPS control unit connector B | 2 | 2 | Under right side of dash | | |
| EPS control unit connector C | 1 | 2 | Under right side of dash | | |
| EPS control unit connector D | 3 | 28 | Under right side of dash | | |
| Passenger's under-dash fuse/relay box connector E (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 13 | 18 | Under right side of dash | | |
| C202 | 5 | 18 | Under right side of dash | Left engine compartment subharness | |
| C203 | 8 | 2 | Under right side of dash | Left engine compartment subharness | |
| C204 | 10 | 3 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C205 | 12 | 16 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C206 | 11 | 4 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C207 (junction connector) | 4 | 12 | Under right side of dash | | |
| G201 | 6 | | Under right side of dash | Body ground, via right engine compartment wire harness | |
| G203 | 7 | | Under right side of dash | Body ground, via right engine compartment wire harness | |
RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) - CONNECTOR TO HARNESS INDEX
Scheme 1064
Dashboard Wire Harness (View of Driver's Side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Data link connector (DLC) | 27 | 16 | Under left side of dash | | |
| Driver's footwell light | 17 | 2 | Under left side of dash | | |
| Driver's junction box 1 connector A | 8 | 6 | Under left side of dash | | |
| Driver's junction box 1 connector B | 9 | 6 | Under left side of dash | | |
| Driver's junction box 1 connector C | 10 | 8 | Under left side of dash | | |
| Driver's junction box 1 connector D | 7 | 4 | Under left side of dash | | |
| Driver's junction box 1 connector E | 3 | 10 | Under left side of dash | | |
| Driver's junction box 1 connector F | 4 | 8 | Under left side of dash | | |
| Driver's junction box 1 connector G | 6 | 10 | Under left side of dash | | |
| Driver's junction box 1 connector H | 5 | 10 | Under left side of dash | | |
| Driver's junction box 2 connector A | 40 | 4 | Under left side of dash | | |
| Driver's junction box 2 connector B | 31 | 4 | Under left side of dash | | |
| Driver's junction box 2 connector C | 32 | 4 | Under left side of dash | | |
| Driver's junction box 2 connector D | 33 | 6 | Under left side of dash | | |
| Driver's junction box 2 connector E | 39 | 6 | Under left side of dash | | |
| Driver's junction box 2 connector F | 34 | 6 | Under left side of dash | | |
| Driver's junction box 2 connector G | 35 | 6 | Under left side of dash | | |
| Driver's junction box 2 connector H | 38 | 4 | Under left side of dash | | |
| Driver's junction box 2 connector J | 37 | 8 | Under left side of dash | | |
| Driver's junction box 2 connector K | 36 | 10 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector B (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 29 | 2 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector C (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 18 | 5 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector M (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 11 | 4 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector N (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 12 | 16 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector P (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 13 | 20 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector Q (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 15 | 20 | Under left side of dash | Driver's MICU | |
| Driver's under-dash fuse/relay box connector R (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 14 | 24 | Under left side of dash | Driver's MICU | |
| Gauge control module | 2 | 32 | Behind gauge | | |
| VSA OFF switch | 16 | 5 | Left side of dashboard | | |
DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) - CONNECTOR TO HARNESS INDEX
Scheme 1065
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C301 | 21 | 24 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C302 | 23 | 2 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C303 | 20 | 4 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C304 | 22 | 13 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C501 | 24 | 20 | Under left side of dash | Roof wire harness Sedan Sport Wagon | |
| C502 | 28 | 8 | Under left side of dash | Roof wire harness Sedan Sport Wagon | |
| C601 | 26 | 23 | Under left side of dash | Left side wire harness Sedan Sport Wagon | |
| C602 | 25 | 16 | Under left side of dash | Left side wire harness Sedan Sport Wagon | |
| C751 | 30 | 28 | Under left side of dash | Driver's door wire harness | |
| G501 | 1 | | Under left side of dash | Body ground, via dashboard wire harness | |
| G502 | 19 | | Under left side of dash | Body ground, via dashboard wire harness | |
DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) - CONNECTOR TO HARNESS INDEX
Scheme 1066
Dashboard Wire Harness (View of Steering Column Side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Cable reel connector A | 3 | 20 | In steering column | Cable reel subharness via cable reel | |
| Cable reel connector B | 4 | 4 | In steering column | Driver's airbag inflator via cable reel | |
| Cargo area accessory power socket relay | 6 | 4 | Under left side of dash | | (1) |
| Combination light switch | 2 | 12 | In steering column | | |
| Center junction box connector A | 13 | 4 | Under middle of dash | | |
| Center junction box connector B | 14 | 4 | Under middle of dash | | |
| Center junction box connector C | 15 | 4 | Under middle of dash | | |
| Center junction box connector D | 16 | 6 | Under middle of dash | | |
| Center junction box connector E | 12 | 6 | Under middle of dash | | |
| Center junction box connector F | 11 | 6 | Under middle of dash | | |
| Center junction box connector G | 7 | 6 | Under middle of dash | | |
| Center junction box connector H | 10 | 4 | Under middle of dash | | |
| Center junction box connector J | 9 | 8 | Under middle of dash | | |
| Center junction box connector K | 8 | 10 | Under middle of dash | | |
| Console accessory power socket relay | 21 | 4 | Under left side of dash | | |
| Ignition key switch | 19 | 6 | In steering column | | |
| Ignition switch | 20 | 5 | In steering column | | |
| Immobilizer-keyless control unit | 18 | 7 | In steering column | | |
| Steering angle sensor | 1 | 5 | In steering column | | |
| TPMS control unit | 5 | 20 | Behind gauge | | |
| Wiper/washer switch | 17 | 8 | In steering column | | |
| (1) Sport Wagon |
DASHBOARD WIRE HARNESS (VIEW OF STEERING COLUMN SIDE) - CONNECTOR TO HARNESS INDEX
Scheme 1067
Dashboard Wire Harness (View of Middle to Passenger's Side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/T gear position indicator panel light/park-pin switch | 20 | 6 | Under center console | A/T | |
| Driver's seat heater switch | 19 | 6 | Under center console | | |
| Front accessory power socket | 17 | 2 | Under center console | | |
| Front passenger's airbag inflator | 13 | 4 | Under right side of dash | | |
| Front passenger's footwell light | 12 | 2 | Under right side of dash | | |
| Front passenger's seat heater switch | 18 | 7 | Under center console | | |
| In-car temperature sensor | 1 | 2 | Middle of dash | | |
| Parking brake switch | 22 | 1 | Center console | | |
| Passenger's under-dash fuse/relay box connector A (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 7 | 38 | Under right side of dash | | |
| Passenger's under-dash fuse/relay box connector B (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 8 | 1 | Under right side of dash | | |
| Passenger's under-dash fuse/relay box connector C (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 9 | 12 | Under right side of dash | | |
| SRS unit connector A | 16 | 39 | Under middle of dash | | |
| Yaw rate-lateral acceleration sensor | 21 | 4 | Under center console | | |
| C204 | 5 | 3 | Under left side of dash | Right engine compartment wire harness (dashboard branch) | |
| C205 | 10 | 16 | Under left side of dash | Right engine compartment wire harness (dashboard branch) | |
| C206 | 4 | 4 | Under left side of dash | Right engine compartment wire harness (dashboard branch) | |
| C401 | 15 | 28 | Under middle of dash | Audio wire harness With navigation Without navigation | |
| C402 | 14 | 16 | Under middle of dash | Audio wire harness With navigation Without navigation | |
| C651 | 11 | 23 | Under right side of dash | Right side wire harness Sedan Sport Wagon | |
| C761 | 6 | 23 | Under right side of dash | Front passenger's door wire harness | |
| G503 | 2 | | Under middle of dash | Body ground, via dashboard wire harness | |
| G504 | 23 | | Under center console | Body ground, via dashboard wire harness | |
| G505 | 3 | | Under right side of dash | Body ground, via dashboard wire harness | |
DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) - CONNECTOR TO HARNESS INDEX
Scheme 1068
Audio Wire Harness (With Navigation)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Audio-navigation switch panel | 5 | 24 | Middle of dash | | |
| Audio-navigation unit connector A | 30 | 24 | Under middle of dash | | |
| Audio-navigation unit connector B | 31 | 24 | Under middle of dash | | |
| Audio-navigation unit connector C | 33 | 14 | Under middle of dash | | |
| Audio-navigation unit connector D | 36 | 20 | Under middle of dash | | |
| Audio-navigation unit connector F | 32 | 12 | Under middle of dash | | |
| Audio-navigation unit connector G | 37 | 8 | Under middle of dash | | |
| Audio-navigation unit connector H | 29 | 28 | Under middle of dash | | |
| Automatic lighting/sunlight sensor | 8 | 5 | Middle of dash | | |
| Auxiliary jack | 34 | 5 | Under center console | | |
| Center speaker | 7 | 2 | Middle of dash | | |
| Climate control unit connector A | 2 | 28 | Middle of dash | | |
| Climate control unit connector B | 1 | 12 | Middle of dash | | |
| Console accessory power socket | 35 | 2 | Under center console | | |
| Glove box light | 13 | 2 | Glove box | | |
| HandsFreeLink control unit | 14 | 28 | Under right of dash | | |
| Hazard warning switch | 3 | 5 | Middle of dash | | |
| Interface dial | 4 | 5 | Middle of dash | | |
| Navigation display unit | 6 | 28 | Middle of dash | | |
| Navigation service check connector | 19 | 2 | Under right side of dash | | |
| Passenger's airbag cutoff indicator | 9 | 4 | Middle of dash | | |
| Passenger's under-dash fuse/relay box connector D | 20 | 28 | Under right side of dash | | |
| Trunk lid opener main switch | 12 | 2 | Under right of dash | | (1) |
| C401 | 10 | 28 | Middle of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C402 | 11 | 16 | Middle of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C403 | 25 | 16 | Middle of dash | SRS floor wire harness Sedan Sport Wagon | |
| C404 (junction connector) | 28 | 12 | Under middle of dash | | |
| C405 (junction connector) | 27 | 12 | Under middle of dash | | |
| C406 (junction connector) | 23 | 12 | Under middle of dash | | |
| C407 (junction connector) | 21 | 12 | Under right side of dash | | |
| C408 (junction connector) | 17 | 12 | Under right side of dash | | |
| C409 | 26 | 20 | Under middle of dash | A/C wire harness | |
| C410 | 16 | 28 | Under right side of dash | Right side wire harness Sedan Sport Wagon | |
| C411 | 15 | 34 | Under right side of dash | Right side wire harness Sedan Sport Wagon | |
| C412 | 18 | 12 | Under right side of dash | Right side wire harness Sedan Sport Wagon | |
| C413 (junction connector) | 24 | 12 | Under middle of dash | | |
| G401 | 22 | | Under middle of dash | Body ground, via audio wire harness | |
| (1) Sedan |
AUDIO WIRE HARNESS (WITH NAVIGATION) - CONNECTOR TO HARNESS INDEX
Scheme 1069
Audio Wire Harness (Without Navigation)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Audio unit connector A | 1 | 24 | Under middle of dash | | |
| Audio unit connector B | 2 | 20 | Under middle of dash | | |
| Audio unit connector D | 3 | 8 | Under middle of dash | | |
| Audio unit connector E | 4 | 14 | Under middle of dash | | |
| Audio-HVAC display unit | 5 | 12 | Middle of dash | | |
| Automatic lighting/sunlight sensor | 6 | 5 | Middle of dash | | |
| Auxiliary jack | 28 | 5 | Under center console | | |
| Center pocket light | 25 | 2 | Middle of dash | | |
| Climate control unit connector A | 27 | 28 | Middle of dash | | |
| Climate control unit connector B | 26 | 12 | Middle of dash | | |
| Console accessory power socket | 30 | 2 | Under center console | | |
| Glove box light | 11 | 2 | Glove box | | |
| HandsFreeLink control unit | 12 | 28 | Under right of dash | | |
| Hazard warning switch | 31 | 5 | Middle of dash | | |
| Passenger's airbag cutoff indicator | 7 | 4 | Middle of dash | | |
| Passenger's under-dash fuse/relay box connector D (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 16 | 28 | Under right side of dash | | |
| Trunk lid opener main switch | 10 | 2 | Under right of dash | | (1) |
| USB adaptor unit | 29 | 14 | Under center console | | |
| C401 | 8 | 28 | Middle of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C402 | 9 | 16 | Middle of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C403 | 21 | 16 | Middle of dash | SRS floor wire harness Sedan Sport Wagon | |
| C404 (junction connector) | 24 | 12 | Under middle of dash | | |
| C405 (junction connector) | 23 | 12 | Under middle of dash | | |
| C406 (junction connector) | 19 | 12 | Under middle of dash | | |
| C407 (junction connector) | 17 | 12 | Under right side of dash | | |
| C408 (junction connector) | 14 | 12 | Under right side of dash | | |
| C409 | 22 | 20 | Under middle of dash | | |
| C410 | 13 | 28 | Under right side of dash | Right side wire harness Sedan Sport Wagon | |
| C412 | 15 | 12 | Under right side of dash | Right side wire harness Sedan Sport Wagon | |
| C413 (junction connector) | 20 | 12 | Under middle of dash | | |
| G401 | 18 | | Under middle of dash | Body ground, via audio wire harness | |
| (1) Sedan |
AUDIO WIRE HARNESS (WITHOUT NAVIGATION) - CONNECTOR TO HARNESS INDEX
Scheme 1070
Left Side Wire Harness (Sedan)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Condenser A (for rear window defogger) | 18 | 2 | Left B-pillar | | |
| Condenser B (for rear window defogger) | 21 | 2 | Left B-pillar | | |
| Driver's door switch | 23 | 1 | Left B-pillar | | |
| Driver's under-dash fuse/relay box connector D (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 3 | 16 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector E (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 2 | 20 | Under left side of dash | | |
| EVAP canister vent shut valve | 15 | 2 | Under floor (Fuel tank) | | |
| Fuel fill door lock actuator | 13 | 2 | Left front of trunk | | |
| Fuel tank pressure (FTP) sensor | 16 | 3 | Under floor (Fuel tank) | | |
| Fuel tank unit | 5 | 4 | Under rear seat cushion | | |
| High mount brake light | 10 | 2 | Middle of rear shelf | | |
| Left rear door switch | 20 | 1 | Left C-pillar | | |
| Left rear speaker | 12 | 2 | Left side of rear shelf | | |
| Left rear TPMS initiator | 19 | 3 | Under floor | | |
| Left rear wheel speed sensor | 17 | 2 | Under floor | | |
| Rear window defogger connector A (+) | 7 | 1 | Middle of rear shelf | | |
| Subwoofer | 8 | 2 | Middle of rear shelf | | |
| Trunk light | 11 | 2 | Middle of rear shelf | | |
| C305 | 1 | 8 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C601 | 26 | 23 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C602 | 25 | 16 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C603 | 24 | 2 | Left side of floor | SRS floor wire harness (Sedan) | |
| C604 | 14 | 20 | Left rear of trunk | Rear wire harness (Sedan) | |
| C654 | 9 | 18 | Under rear shelf | Right side wire harness (Sedan) | |
| C771 | 22 | 18 | Left B-pillar | Left rear door wire harness | |
| G601 | 27 | | Left side of floor | Body ground, via left side wire harness | |
| G602 | 6 | | Under rear seat cushion | Body ground, via left side wire harness | |
| G603 | 4 | | Left of rear shelf | Body ground, via left side wire harness | |
LEFT SIDE WIRE HARNESS (SEDAN) - CONNECTOR TO HARNESS INDEX
Scheme 1071
Left Side Wire Harness (Sport Wagon)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Cargo area accessory power socket | 14 | 2 | Left side of cargo area | | |
| Left cargo area light | 8 | 2 | Left side of cargo area | | |
| Driver's door switch | 21 | 1 | Left B-pillar | | |
| Driver's under-dash fuse/relay box connector D (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 4 | 16 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector E (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 3 | 20 | Under left side of dash | | |
| EVAP canister vent shut valve | 15 | 2 | Under floor (fuel tank) | | |
| Fuel fill door lock actuator | 10 | 2 | Left side of cargo area | | |
| Fuel tank pressure (FTP) sensor | 11 | 3 | Under floor (fuel tank) | | |
| Fuel tank unit | 17 | 4 | Under rear seat cushion | | |
| Left rear door switch | 19 | 1 | Left C-pillar | | |
| Left rear TPMS initiator | 18 | 3 | Under floor | | |
| Left rear wheel speed sensor | 16 | 2 | Under floor | | |
| C305 | 2 | 8 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C306 | 5 | 2 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C601 | 1 | 23 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C602 | 6 | 16 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C603 | 22 | 2 | Under driver's seat | SRS floor wire harness (Sport Wagon) | |
| C604 | 13 | 20 | Left side of tailgate | Rear wire harness (Sport Wagon) | |
| C605 | 12 | 8 | Left side of tailgate | Rear wire harness (Sport Wagon) | |
| C654 | 9 | 2 | Left side of cargo area | Right side wire harness (Sport Wagon) | |
| C771 | 20 | 18 | Left B-pillar | Left rear door wire harness | |
| G601 | 23 | | Left side of floor | Body ground, via left side wire harness | |
| G603 | 7 | | Under left rear seat cushion | Body ground, via left side wire harness | |
LEFT SIDE WIRE HARNESS (SPORT WAGON) - CONNECTOR TO HARNESS INDEX
Scheme 1072
SRS Floor Wire Harness (Sedan)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's seat belt tensioner | 17 | 4 | Left B-pillar | | |
| Driver's side airbag inflator | 2 | 2 | Under driver's seat | | |
| Front passenger's seat belt tensioner | 11 | 4 | Right B-pillar | | |
| Front passenger's side airbag inflator | 7 | 2 | Under front passenger's seat | | |
| Left side curtain airbag inflator | 14 | 2 | Left C-pillar | | |
| Left side impact sensor (first) | 18 | 4 | Left B-pillar | | |
| Left side impact sensor (second) | 16 | 2 | Left C-pillar | | |
| Rear safing sensor | 15 | 4 | Under rear seat cushion | | |
| Right side curtain airbag inflator | 12 | 2 | Right C-pillar | | |
| Right side impact sensor (first) | 10 | 4 | Right B-pillar | | |
| Right side impact sensor (second) | 13 | 2 | Right C-pillar | | |
| SRS unit connector B | 3 | 39 | Under middle of dash | | |
| C403 | 4 | 16 | Under middle of dash | Audio wire harness With navigation Without navigation | |
| C603 | 19 | 2 | Under driver's seat | Left side wire harness (Sedan) | |
| C653 | 9 | 4 | Under front passenger's seat | Right side wire harness (Sedan) | |
| C701 | 1 | 23 | Under driver's seat | Driver's seat wire harness With DPMS Without DPMS | |
| C702 | 6 | 18 | Under front passenger's seat | Front passenger's seat wire harness | |
| C703 | 5 | 4 | Under front passenger's seat | ODS unit harness | |
| G701 | 20 | | Under driver's seat | Body ground, via SRS floor wire harness | |
| G702 | 8 | | Under front passenger's seat | Body ground, via SRS floor wire harness | |
SRS FLOOR WIRE HARNESS (SEDAN) - CONNECTOR TO HARNESS INDEX
Scheme 1073
SRS Floor Wire Harness (Sport Wagon)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's seat belt tensioner | 19 | 4 | Left B-pillar | | |
| Driver's side airbag inflator | 2 | 2 | Under driver's seat | | |
| Front passenger's seat belt tensioner | 12 | 4 | Right B-pillar | | |
| Front passenger's side airbag inflator | 8 | 2 | Under front passenger's seat | | |
| Left side curtain airbag inflator | 11 | 2 | Left C-pillar | | |
| Left side impact sensor (first) | 20 | 4 | Left B-pillar | | |
| Left side impact sensor (second) | 18 | 2 | Left C-pillar | | |
| Rear safing sensor | 17 | 4 | Under rear seat cushion | | |
| Right side impact sensor (first) | 10 | 4 | Right B-pillar | | |
| Right side impact sensor (second) | 13 | 2 | Right C-pillar | | |
| SRS unit connector B | 3 | 39 | Under middle of dash | | |
| C403 | 4 | 16 | Under middle of dash | Audio wire harness With navigation Without navigation | |
| C603 | 21 | 2 | Under driver's seat | Left side wire harness (Sport Wagon) | |
| C653 | 9 | 4 | Under front passenger's seat | Right side wire harness (Sport Wagon) | |
| C701 | 1 | 23 | Under driver's seat | Driver's seat wire harness (with DPMS) | |
| C702 | 7 | 18 | Under front passenger's seat | Front passenger's seat wire harness | |
| C703 | 6 | 4 | Under front passenger's seat | ODS unit harness | |
| C704 | 16 | 2 | Right C-pillar | SRS floor subharness (Sport Wagon) | |
| G701 | 22 | | Under driver's seat | Body ground, via SRS floor wire harness | |
| G702 | 5 | | Under front passenger's seat | Body ground, via SRS floor wire harness | |
SRS FLOOR WIRE HARNESS (SPORT WAGON) - CONNECTOR TO HARNESS INDEX
SRS Floor Subharness (Sport Wagon)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right side curtain airbag inflator | 15 | 2 | Right C-pillar | | |
| C704 | 16 | 2 | Right C-pillar | SRS floor wire harness (Sport Wagon) | |
| G751 | 14 | | Right C-pillar | Body ground, via SRS floor subharness | |
SRS FLOOR SUBHARNESS (SPORT WAGON) - CONNECTOR TO HARNESS INDEX
Scheme 1074
Right Side Wire Harness (Sedan)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| AcuraLink connector (Female connector) | 7 | 5 | Under right side of rear seat | | (1) |
| AcuraLink connector (Male connector) | 7 | 5 | Under right side of rear seat | | (1) |
| AcuraLink control unit (XM receiver) connector A | 6 | 32 | Under right side of rear seat | | (1) |
| Electrical compass unit | 22 | 6 | Under rear shelf | | (4) |
| Front passenger's door switch | 8 | 1 | Right B-pillar | | |
| Passenger's under-dash fuse/relay box connector H (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 13 | 38 | Under right side of dash | | |
| Right rear door switch | 16 | 1 | Right C-pillar | | |
| Right rear speaker | 3 | 2 | Right side of rear shelf | | |
| Right rear TPMS initiator | 17 | 3 | Under right side of floor | | |
| Right rear wheel speed sensor | 18 | 2 | Under right side of floor | | |
| Stereo amplifier A | 20 | 18 | Right side of trunk | | |
| Stereo amplifier B | 19 | 28 | Right side of trunk | | (3) |
| Stereo amplifier B | 19 | 24 | Right side of trunk | | (4) |
| XM receiver connector A | 6 | 14 | Under right side of rear seat | Audio wire harness (with navigation) | (2) |
| C410 | 10 | 28 | Under right side of dash | Audio wire harness With navigation Without navigation | |
| C411 | 11 | 34 | Under right side of dash | Audio wire harness (with navigation) | |
| C412 | 12 | 12 | Under right side of dash | Audio wire harness With navigation Without navigation | (5) |
| C651 | 9 | 23 | Right kick panel | Dashboard wire harness (view of middle to passenger's side) | |
| C652 (junction connector) | 2 | 12 | Under rear shelf | | |
| C653 | 14 | 4 | Under front passenger's seat | SRS floor wire harness (Sedan) | |
| C654 | 1 | 18 | Under rear shelf | Left side wire harness (Sedan) | |
| C655 | 21 | 6 | Right side of trunk | Rear wire harness (Sedan) | (3) |
| C781 | 15 | 18 | Right B-pillar | Right rear door wire harness | |
| G651 | 28 | | Under front passenger's seat | Body ground, via right side wire harness | |
| (1) With AcuraLink (2) Without AcuraLink (3) With navigation (4) Without navigation (5) With XM radio |
RIGHT SIDE WIRE HARNESS (SEDAN) - CONNECTOR TO HARNESS INDEX
Rear Window Defogger Ground Wire (Sedan)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Rear window defogger connector B (-) | 4 | 1 | Right C-pillar | | |
| G801 | 5 | | Right C-pillar | Body ground, via rear window defogger ground | |
REAR WINDOW DEFOGGER GROUND WIRE (SEDAN) - CONNECTOR TO HARNESS INDEX
Scheme 1075
Right Side Wire Harness (Sport Wagon)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| AcuraLink connector (female connector) | 2 | 5 | Under right side of rear seat | | (1) |
| AcuraLink connector (male connector) | 3 | 5 | Under right side of rear seat | | (1) |
| AcuraLink control unit (XM receiver) connector A | 1 | 32 | Left side of cargo area | | (1) |
| Front passenger's door switch | 16 | 1 | Right B-pillar | | |
| Passenger's under-dash fuse/relay box connector H (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 14 | 38 | Under right side of dash | | |
| Right cargo area light | 6 | 2 | Right side of cargo area | | |
| Right rear door switch | 8 | 1 | Right C-pillar | | |
| Right rear TPMS initiator | 7 | 3 | Under right side of floor | | |
| Right rear wheel speed sensor | 18 | 2 | Under right side of floor | | |
| Stereo amplifier A | 19 | 18 | Right side of cargo area | | |
| Stereo amplifier B | 20 | 28 | Right side of cargo area | | (3) |
| Stereo amplifier B | 20 | 24 | Right side of cargo area | | (4) |
| Subwoofer | 21 | 8 | Right side of cargo area | | |
| XM receiver connector A | 1 | 14 | Left side of cargo area | | (2) |
| C410 | 11 | 28 | Under right side of dash | Audio wire harness With navigation Without navigation | |
| C411 | 12 | 34 | Under right side of dash | Audio wire harness (with navigation) | |
| C412 | 13 | 12 | Under right side of dash | Audio wire harness With navigation Without navigation | (5) |
| C651 | 15 | 23 | Right kick panel | Dashboard wire harness (view of middle to passenger's side) | |
| C652 (junction connector) | 4 | 12 | Center of cargo area | | |
| C653 | 9 | 4 | Under front passenger's seat | SRS floor wire harness (Sport Wagon) | |
| C654 | 5 | 2 | Center of cargo area | Left side wire harness (Sport Wagon) | |
| C655 | 22 | 20 | Right side of cargo area | Rear wire harness (Sport Wagon) | |
| C781 | 17 | 18 | Right B-pillar | Right rear door wire harness | |
| G651 | 10 | | Under front passenger's seat | Body ground, via right side wire | |
| (1) With AcuraLink (2) Without AcuraLink (3) With navigation (4) Without navigation (5) With XM radio |
RIGHT SIDE WIRE HARNESS (SPORT WAGON) - CONNECTOR TO HARNESS INDEX
Scheme 1076
Rear Wire Harness (Sedan)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left back-up light | 11 | 3 | Left side of trunk | | |
| Left rear license light | 2 | 2 | Middle of trunk | | |
| Left rear side marker light | 15 | 2 | Left side of trunk | | |
| Left rear taillight/brake light | 13 | 4 | Left side of trunk | | |
| Left rear turn signal light | 14 | 3 | Left side of trunk | | |
| Rearview camera | 1 | 6 | Middle of trunk | | (1) |
| Right back-up light | 5 | 3 | Right side of trunk | | |
| Right rear license light | 4 | 2 | Middle of trunk | | |
| Right rear side marker light | 6 | 2 | Right side of trunk | | |
| Right rear taillight/brake light | 8 | 4 | Right side of trunk | | |
| Right rear turn signal light | 7 | 3 | Right side of trunk | | |
| Trunk lid outer handle switch | 3 | 3 | Middle of trunk | | |
| Trunk lid release actuator/Trunk lid latch switch | 10 | 3 | Middle of trunk | | |
| C604 | 16 | 20 | Left side of rear | Left side wire harness (Sedan) | |
| C655 | 9 | 6 | Right side of rear | Right side wire harness (Sedan) | (1) |
| G901 | 12 | | Left side of rear | Body ground, via rear wire harness | |
| (1) With navigation |
REAR WIRE HARNESS (SEDAN) - CONNECTOR TO HARNESS INDEX
Scheme 1077
Rear Wire Harness (Sport Wagon)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Brake light diode 1 | 18 | 2 | Left side of cargo area | | |
| Brake light diode 2 | 12 | 2 | Right side of cargo area | | |
| Electrical compass unit | 4 | 6 | Left rear side of roof | | (2) |
| Left rear taillight/brake light | 8 | 3 | Left side of cargo area | | |
| Left rear turn signal light | 9 | 2 | Left side of cargo area | | |
| Left satellite speaker | 1 | 2 | Left D-pillar | | |
| Power tailgate buzzer | 16 | 2 | Behind left side of rear bumper | | (1) |
| Power tailgate control unit connector A | 21 | 5 | Left side of cargo area | | (1) |
| Power tailgate control unit connector B | 20 | 20 | Left side of cargo area | | (1) |
| Power tailgate control unit connector C | 19 | 14 | Left side of cargo area | | (1) |
| Power tailgate drive unit connector A | 2 | 2 | Left rear side of roof | | (1) |
| Power tailgate drive unit connector B | 3 | 8 | Left rear side of roof | | (1) |
| Right rear taillight/brake light | 11 | 3 | Right side of cargo area | | |
| Right rear turn signal light | 13 | 2 | Right side of cargo area | | |
| C604 | 15 | 20 | Left side of tailgate | Left side wire harness (Sport Wagon) | |
| C605 | 17 | 8 | Left side of tailgate | Left side wire harness (Sport Wagon) | |
| C655 | 14 | 20 | Right side of cargo area | Right side wire harness (Sport Wagon) | |
| C661 | 5 | 2 | Left rear side of roof | Tailgate wire harness (Sport Wagon) | |
| C662 | 6 | 20 | Left rear side of roof | Tailgate wire harness (Sport Wagon) | |
| C663 | 10 | 20 | Right side of cargo area | Tailgate wire harness (Sport Wagon) | (1) |
| G901 | 7 | | Left side of cargo area | Body ground, via rear wire harness | |
| (1) With power tailgate (2) Without navigation |
REAR WIRE HARNESS (SPORT WAGON) - CONNECTOR TO HARNESS INDEX
Scheme 1078
Tailgate Wire Harness (Sport Wagon)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| High mount brake light | 4 | 2 | Center of tailgate | | |
| Left back-up light | 23 | 2 | Left side of tailgate | | |
| Left inner taillight | 24 | 2 | Left side of tailgate | | |
| Left license plate light | 5 | 2 | Center of tailgate | | |
| Right satellite speaker | 6 | 2 | Right D-pillar | | (3) |
| Power tailgate closer motor | 17 | 2 | Center of tailgate | | (1) |
| Power tailgate closer unit/latch and ratchet switch | 21 | 6 | Center of tailgate | | (1) |
| Power tailgate left pinch sensor | 22 | 2 | Left side of tailgate | | (1) |
| Power tailgate inside switch | 16 | 5 | Left side of tailgate | | (1) |
| Power tailgate right pinch sensor | 15 | 2 | Right side of tailgate | | (1) |
| Rear window defogger connector A (+) | 1 | 1 | Left side of tailgate | | |
| Rear window defogger connector B (-) | 8 | 1 | Right side of tailgate | | (1) |
| Rear window wiper motor | 7 | 4 | Center of tailgate | | |
| Rearview camera | 14 | 6 | Center of tailgate | | (3) |
| Right back-up light | 13 | 2 | Right side of tailgate | | |
| Right inner taillight | 12 | 2 | Right side of tailgate | | |
| Right license plate light | 11 | 2 | Center of tailgate | | |
| Tailgate latch switch | 19 | 2 | Center of tailgate | | (2) |
| Tailgate outer handle switch | 10 | 3 | Center of tailgate | | |
| Tailgate release actuator | 18 | 2 | Center of tailgate | | (2) |
| C661 | 2 | 2 | Left rear side of roof | Rear wire harness (Sport Wagon) | |
| C662 | 3 | 20 | Left rear side of roof | Rear wire harness (Sport Wagon) | |
| C663 | 9 | 20 | Right side of cargo area | Rear wire harness (Sport Wagon) | (1) |
| C664 (junction connector) | 20 | 12 | Right side of tailgate | | |
| (1) With power tailgate (2) Without power tailgate (3) With navigation |
| (2) | Without power tailgate |
TAILGATE WIRE HARNESS (SPORT WAGON) - CONNECTOR TO HARNESS INDEX
Scheme 1079
Roof Wire Harness (Sedan)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Automatic dimming inside mirror | 2 | 7 | Front of roof | | |
| Front individual map light | 11 | 3 | Front of roof | | |
| Left vanity mirror light | 8 | 2 | Left front of roof | | |
| HFL microphone | 5 | 3 | Front of roof | | (2) |
| HFL-navigation microphone | 5 | 7 | Front of roof | | (1) |
| HomeLink unit | 4 | 5 | Front of roof | | |
| Moonroof switch | 3 | 12 | Front of roof | | |
| Right vanity mirror light | 1 | 2 | Right front of roof | | |
| C501 | 13 | 20 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C502 | 12 | 8 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C551 | 6 | 13 | Middle of roof | Moonroof subharness (Sedan) | |
| C552 (junction connector) | 7 | 12 | Left front of roof | | |
| (1) With navigation (2) Without navigation |
ROOF WIRE HARNESS (SEDAN) - CONNECTOR TO HARNESS INDEX
Moonroof Subharness (Sedan)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Ceiling light | 9 | 3 | Rear of roof | | |
| Moonroof control unit/motor | 10 | 14 | Rear of roof | | |
| C551 | 6 | 13 | Middle of roof | Roof wire harness (Sedan) | |
MOONROOF SUBHARNESS (SEDAN) - CONNECTOR TO HARNESS INDEX
Scheme 1080
Roof Wire Harness (Sport Wagon)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Automatic dimming inside mirror | 2 | 7 | Front of roof | | |
| Front individual map light | 13 | 3 | Front of roof | | |
| Driver's vanity mirror light | 8 | 2 | Left front side of roof | | |
| HFL microphone | 5 | 3 | Front of roof | | (2) |
| HFL-navigation microphone | 5 | 7 | Front of roof | | (1) |
| HomeLink unit | 4 | 5 | Front of roof | | |
| Moonroof switch | 3 | 12 | Front of roof | | |
| Passenger's vanity mirror light | 1 | 2 | Right front side of roof | | |
| C501 | 12 | 20 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C502 | 11 | 8 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C551 | 6 | 13 | Middle of roof | Moonroof subharness (Sport Wagon) | |
| C552 (junction connector) | 7 | 12 | Left front of roof | | |
| (1) With navigation (2) Without navigation |
ROOF WIRE HARNESS (SPORT WAGON) - CONNECTOR TO HARNESS INDEX
Moonroof Subharness (Sport Wagon)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Ceiling light | 10 | 3 | Rear of roof | | |
| Moonroof control unit/motor | 9 | 14 | Rear of roof | | |
| C551 | 6 | 13 | Middle of roof | Roof wire harness (Sport Wagon) | |
MOONROOF SUBHARNESS (SPORT WAGON) - CONNECTOR TO HARNESS INDEX
Scheme 1081
Driver's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door lock actuator/knob switch/key cylinder switch | 14 | 10 | Driver's door | | |
| Driver's power window motor | 11 | 6 | Driver's door | | |
| Left front speaker | 9 | 2 | Driver's door | | |
| Left front tweeter | 4 | 2 | Driver's door | | |
| Left power mirror | 5 | 13 | Driver's door | | |
| Driver's door power tailgate switch | 10 | 5 | Driver's door | | (2) |
| Power window master switch (door multiplex control unit) | 1 | 37 | Driver's door | | |
| Trunk lid opener switch | 10 | 5 | Driver's door | | (1) |
| C751 | 7 | 28 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C752 | 13 | 2 | Driver's door | Driver's door courtesy light subharness | |
| C753 | 8 | 20 | Driver's door | Driver's door switch subharness | |
| C754 (junction connector) | 6 | 12 | Driver's door | | |
| (1) Sedan (2) Sport Wagon |
DRIVER'S DOOR WIRE HARNESS - CONNECTOR TO HARNESS INDEX
Driver's Door Courtesy Light Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door courtesy light | 12 | 2 | Driver's door | | |
| C752 | 13 | 2 | Driver's door | Driver's door wire harness | |
DRIVER'S DOOR COURTESY LIGHT SUBHARNESS - CONNECTOR TO HARNESS INDEX
Driver's Door Switch Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driving position memory switch | 2 | 7 | Driver's door | | |
| Power mirror switch | 3 | 13 | Driver's door | | |
| C753 | 8 | 20 | Driver's door | Driver's door wire harness | |
DRIVER'S DOOR SWITCH SUBHARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1082
Front Passenger's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's door lock actuator/knob switch | 4 | 10 | Front passenger's door | | |
| Front passenger's power window motor | 7 | 6 | Front passenger's door | | |
| Front passenger's power window switch | 3 | 37 | Front passenger's door | | |
| Right front speaker | 8 | 2 | Front passenger's door | | |
| Right front tweeter | 2 | 2 | Front passenger's door | | |
| Right power mirror | 1 | 13 | Front passenger's door | | |
| C761 | 9 | 23 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C762 | 5 | 2 | Front passenger's door | Front passenger's door courtesy light subharness | |
FRONT PASSENGER'S DOOR WIRE HARNESS - CONNECTOR TO HARNESS INDEX
Front Passenger's Door Courtesy Light Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's door courtesy light | 6 | 2 | Front passenger's door | | |
| C762 | 5 | 2 | Front passenger's door | Front passenger's door wire harness | |
FRONT PASSENGER'S DOOR COURTESY LIGHT SUBHARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1083
Left Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left rear door courtesy light | 5 | 2 | Left rear door | | |
| Left rear door lock actuator/knob switch | 1 | 10 | Left rear door | | |
| Left rear power window motor | 6 | 2 | Left rear door | | |
| Left rear power window switch | 2 | 14 | Left rear door | | |
| Left rear speaker | 4 | 2 | Left rear door | | (1) |
| C771 | 3 | 18 | Left B-pillar | Left side wire harness Sedan Sport Wagon | |
| (1) Sedan with navigation and Sport Wagon |
| (1) | Sedan with navigation and Sport Wagon |
LEFT REAR DOOR WIRE HARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1084
Right Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right rear door courtesy light | 4 | 2 | Right rear door | | |
| Right rear door lock actuator/knob switch | 2 | 10 | Right rear door | | |
| Right rear power window motor | 3 | 2 | Right rear door | | |
| Right rear power window switch | 1 | 14 | Right rear door | | |
| Right rear speaker | 5 | 2 | Right rear door | | (1) |
| C781 | 6 | 18 | Right B-pillar | Right side wire harness Sedan Sport Wagon | |
| (1) Sedan with navigation and Sport Wagon |
| (1) | Sedan with navigation and Sport Wagon |
RIGHT REAR DOOR WIRE HARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1085
Driver's Seat Wire Harness (With DPMS)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's power seat adjustment switch | 3 | 12 | Left side of driver's seat | | |
| Driver's seat back heater | 9 | 2 | Driver's seat | | |
| Driver's seat belt buckle switch | 10 | 2 | Driver's seat | | |
| Driver's seat cushion heater | 7 | 4 | Driver's seat | | |
| Driver's seat front up-down motor/position sensor | 14 | 5 | Driver's seat | | |
| Driver's seat heater relay (high) | 12 | 4 | Driver's seat | | |
| Driver's seat heater relay (low) | 11 | 5 | Driver's seat | | |
| Driver's seat position sensor | 1 | 2 | Driver's seat | | |
| Driver's seat rear up-down motor/position sensor | 2 | 5 | Driver's seat | | |
| Driver's seat recline motor/position sensor | 5 | 5 | Bottom of seat back | | |
| Driver's seat slide motor/position sensor | 13 | 5 | Driver's seat | | |
| Power seat control unit connector A | 8 | 40 | Under driver's seat | | |
| Power seat control unit connector B | 6 | 18 | Under driver's seat | | |
| C701 | 4 | 23 | Under driver's seat | SRS floor wire harness Sedan Sport Wagon | |
DRIVER'S SEAT WIRE HARNESS (WITH DPMS) - CONNECTOR TO HARNESS INDEX
Scheme 1086
Driver's Seat Wire Harness (Without DPMS)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's power seat adjustment switch | 7 | 12 | Left side of driver's seat | | |
| Driver's seat back heater | 10 | 2 | Driver's seat | | |
| Driver's seat belt buckle switch | 1 | 2 | Right side of driver's seat | | |
| Driver's seat cushion heater | 2 | 4 | Driver's seat | | |
| Driver's seat front up-down motor | 3 | 2 | Driver's seat | | |
| Driver's seat heater relay (high) | 11 | 4 | Driver's seat | | |
| Driver's seat heater relay (low) | 12 | 5 | Driver's seat | | |
| Driver's seat position sensor | 5 | 2 | Driver's seat | | |
| Driver's seat rear up-down motor | 6 | 2 | Driver's seat | | |
| Driver's seat slide motor | 4 | 5 | Driver's seat | | |
| Driver's seat recline motor | 8 | 2 | Bottom of seat back | | |
| C701 | 9 | 23 | Under driver's seat | SRS floor wire harness (Sedan) | |
DRIVER'S SEAT WIRE HARNESS (WITHOUT DPMS) - CONNECTOR TO HARNESS INDEX
Scheme 1087
Front Passenger's Seat Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's seat adjustment switch | 6 | 12 | Front passenger's seat | | |
| Front passenger's seat belt buckle switch | 2 | 2 | Front passenger's seat | | |
| Front passenger's seat cushion heater | 1 | 4 | Front passenger's seat | | |
| Front passenger's seat heater relay (high) | 4 | 4 | Front passenger's seat | | |
| Front passenger's seat heater relay (low) | 3 | 5 | Front passenger's seat | | |
| Front passenger's seat recline motor | 7 | 2 | Front passenger's seat | | |
| Front passenger's seat slide motor | 8 | 5 | Front passenger's seat | | |
| C702 | 5 | 18 | Under front passenger's seat | SRS floor wire harness Sedan Sport Wagon | |
FRONT PASSENGER'S SEAT WIRE HARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1088
ODS Unit Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's seat weight sensor (inner side) | 2 | 2 | Front passenger's seat | | |
| Front passenger's seat weight sensor (outer side) | 4 | 3 | Front passenger's seat | | |
| ODS unit | 1 | 18 | Front passenger's seat | | |
| C703 | 3 | 4 | Under front passenger's seat | SRS floor wire harness Sedan Sport Wagon | |
ODS UNIT HARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1089
Cable Reel Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Audio remote switch | 1 | 12 | Steering wheel | | |
| Cable reel connector C | 6 | 20 | Steering wheel | | |
| Cruise control combination switch | 4 | 12 | Steering wheel | | |
| HFL/Voice control switch | 8 | 7 | Steering wheel | | |
| Horn switch | 7 | 2 | Steering wheel | | |
| Select/reset/information switch | 5 | 7 | Steering wheel | | |
| Paddle shifter + (Upshift switch) | 3 | 4 | Steering wheel | | ATT |
| Paddle shifter- (Downshift switch) | 2 | 4 | Steering wheel | | A/T |
CABLE REEL SUBHARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1090
A/C Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Blower motor | 6 | 2 | Under right side of dash | | |
| Driver's air mix control motor | 1 | 7 | Under middle of dash | | |
| Evaporator temperature sensor | 4 | 2 | Under middle of dash | | |
| Mode control motor | 3 | 7 | Under middle of dash | | |
| Passenger's air mix control motor | 9 | 7 | Under middle of dash | | |
| Power transistor | 7 | 4 | Under middle of dash | | |
| Recirculation control motor | 5 | 7 | Under middle of dash | | |
| C351 | 2 | 2 | Under middle of dash | Left engine compartment wire harness (dashboard branch) | |
| C409 | 8 | 20 | Under middle of dash | Audio wire harness With navigation Without navigation | |
A/C WIRE HARNESS - CONNECTOR TO HARNESS INDEX
Scheme 1091
