Body Electrical (special Tools & General Troubleshooting) (4-cyl) Acura TSX II

SPECIAL TOOLS REFERENCE CHART

Scheme 1092

Tips and Precautions

Special Tools Required

Back Probe Adapter, 17 mm 07TAZ-001020A

Before Troubleshooting

1. Check applicable fuses in the appropriate fuse/relay box.
2. Check the battery for damage, state of charge, and clean and tight connections.

Note. Do not quick-charge a battery unless the battery ground cable has been disconnected, otherwise you will damage the alternator diodes. Do not attempt to crank the engine with the battery ground cable loosely connected or you will severely damage the wiring.

Handling Connectors

Scheme 1093

Scheme 1094

Scheme 1095

Scheme 1096

Scheme 1097

Scheme 1098

Scheme 1099

1. Make sure the connectors are clean and have no loose wire terminals.
2. Make sure multiple cavity connectors are packed with dielectric grease (except waterproof connectors).
3. All connectors have push-down release type locks (A).
4. Some connectors have a clip on their side used to attach them to a mount bracket on the body or on another component. This clip has a pull type lock.
5. Some mounted connectors cannot be disconnected unless you first release the lock and remove the connector from its mount bracket (A).
6. Never try to disconnect connectors by pulling on their wires; pull on the connector halves instead.
7. Always reinstall plastic covers.
8. Before connecting connectors, make sure the terminals (A) are in place and not bent.
9. Check for loose retainers (A) and rubber seals (B).
10. The backs of some connectors are packed with dielectric grease. Add grease if necessary. If the grease is contaminated, replace it.
11. Insert the connector all the way and make sure it is securely locked.
12. Position wires so that the open end of the cover faces down.

Handling Wires and Harnesses

Scheme 1100

1. Secure wires and wire harnesses to the frame with their respective wire ties at the designated locations.
2. Remove clips carefully; do not damage their locks (A).
3. After installing harness clips, make sure the harness does not interfere with any moving parts.
4. Keep wire harnesses away from exhaust components and other hot parts, from sharp edges of brackets and holes, and from exposed screws and bolts.
5. Seat grommets in their grooves properly (A). Do not leave grommets distorted (B).

Scheme 1101

Testing and Repairs

Scheme 1102

Scheme 1103

1. Do not use wires or harnesses with broken insulation. Replace them or repair them by wrapping the break with electrical tape.
2. Never attempt to modify, splice, or repair SRS wiring. If there is an open or damage on SRS wiring or terminals, replace the harness.
3. After installing parts, make sure that no wires are pinched under them.
4. When using electrical test equipment, follow the manufacturer's instructions and those described in this service information.
5. If possible, insert the probe of the tester from the wire side (except waterproof connectors).
6. Use back probe adapter 07TAZ-001020A.
7. Refer to the instructions in the Honda Terminal Kit for identification and replacement of connector terminals.

Five-Step Troubleshooting

1. Verify The Complaint: Turn on all the components in the problem circuit to verify the client complaint. Note the symptoms. Do not begin disassembly or testing until you have narrowed down the problem area.
2. Analyze The Schematic: Look up the schematic for the problem circuit. Determine how the circuit is supposed to work by tracing the current paths from the power feed through the circuit components to ground. If several circuits fail at the same time, the fuse or a ground is a likely cause. Based on the symptoms and your understanding of the circuit operation, identify one or more possible causes of the problem.
3. Isolate The Problem By Testing The Circuit: Make circuit tests to check the diagnosis you made in step 2 . Keep in mind that a logical, simple procedure is the key to efficient troubleshooting. Test for the most likely cause of failure first. Try to make tests at points that are easily accessible.
4. Fix The Problem: Once the specific problem is identified, make the repair. Be sure to use proper tools and safe procedures.
5. Make Sure The Circuit Works: Turn on all components in the repaired circuit in all modes to make sure you've fixed the entire problem. If the problem was a blown fuse, be sure to test all of the circuits on the fuse. Make sure no new problems turn up and the original problem does not recur.

Wire Color Codes

The following abbreviations are used to identify wire colors in the circuit schematics

WHT........................................ White

YEL.......................................... Yellow

BLK.......................................... Black

BLU......................................... Blue

GRN........................................ Green

RED......................................... Red

ORN........................................ Orange

PNK......................................... Pink

BRN......................................... Brown

GRY......................................... Gray

PUR......................................... Purple

TAN......................................... Tan

LT BLU.................................... Light Blue

LT GRN................................... Light Green

The wire insulation has one color or one color with another color stripe. The second color is the stripe.

Scheme 1104

How to Check for DTCs with the Honda Diagnostic System (HDS)

Note. For specific operations, refer to the user's manual that came with the Honda Diagnostic System (HDS). Make sure the HDS is loaded with the latest software.

Scheme 1105

1. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
2. Turn the ignition switch to ON (II).
3. Make sure the HDS communicates with the vehicle; if it does not, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-4-cyl__dlc-circuit-troubleshooting) ).
4. Enter the BODY ELECTRICAL then select the desired MODE MENU.
5. Check for DTCs with the HDS. NOTE: if the DTCs do not pertain to the selected menu, select the All DTC Check icon to view all Body Electrical DTCs.
6. If any DTCs are indicated, note them, and go to the indicated DTC troubleshooting.
