Connector to Fuse/Relay Box Index

Under-Hood Fuse/Relay Box

Socket	Ref	Terminal	Connects to
A (electrical load detector (ELD))	11	3	Left engine compartment wire harness (engine compartment branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) )
A/C compressor clutch relay	16	4
B (relay circuit board)	14	14	Left engine compartment wire harness (engine compartment branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) )
Blower motor relay	1	4
D (relay circuit board)	13	10	Left engine compartment wire harness (engine compartment branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) )
ELD	12	3	Connector A (3P)
Electronic throttle control system (ETCS) control relay	6	4
Horn relay	2	4
Ignition coil relay	5	4
PGM-FI main relay 1	3	4
PGM-FI subrelay	4	4
Radiator fan relay	7	4
Rear window defogger relay	8	4
Relay circuit board	15		Connector B (14P) and connector D (10P)
T101	9		Starter subharness (see STARTER SUBHARNESS )
T102	10		Starter subharness (see STARTER SUBHARNESS )

UNDER-HOOD FUSE/RELAY CONNECTOR TERMINAL REFERENCE

Driver's Under-Dash Fuse/Relay Box

Socket	Ref	Terminal	Connects to
A	1		Not used
B	2	2	Dashboard wire harness (view of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
C	3	5	Dashboard wire harness (view of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
D	11	16	Left side wire harness sedan (see LEFT SIDE WIRE HARNESS (SEDAN) ) Sport Wagon (see LEFT SIDE WIRE HARNESS (SPORT WAGON) )
E	10	20	Left side wire harness
F	9	33	Left engine compartment wire harness (dashboard branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) )
Front accessory power socket relay	4	4
G	8	13	Left engine compartment wire harness (dashboard branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) )
H (optional connector)	7	10
K (MICU service check connector)	6	2
M	13	2	Dashboard wire harness (view of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
N	14	16	Dashboard wire harness (view of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
P	15	20	Dashboard wire harness (view of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
PGM-FI main relay 2	12	4
Q	17	20	Dashboard wire harness (view of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
R	16	24	Dashboard wire harness (view of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
Starter cut relay	5	4

DRIVER'S UNDER-DASH FUSE/RELAY BOX CONNECTOR TERMINAL REFERENCE

Passenger's Under-Dash Fuse/Relay Box

Socket	Ref	Terminal	Connects to
A	1	38	Dashboard wire harness (view of middle to passenger's side) (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) )
B	8	1	Dashboard wire harness (view of middle to passenger's side) (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) )
C	7	12	Dashboard wire harness (view of middle to passenger's side) (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) )
D	2	28	Audio wire harness With navigation (see AUDIO WIRE HARNESS (WITH NAVIGATION) ) Without navigation (see AUDIO WIRE HARNESS (WITHOUT NAVIGATION) )
E	6	18	Right engine compartment wire harness (dashboard branch) (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) )
F	5	2	Not used
G	3	16	Not used
H	4	38	Right side wire harness Sedan (see RIGHT SIDE WIRE HARNESS (SEDAN) ) Sport Wagon (see RIGHT SIDE WIRE HARNESS (SPORT WAGON) )

PASSENGER'S UNDER-DASH FUSE/RELAY BOX CONNECTOR TERMINAL REFERENCE
