Connector Index
Identification numbers have been assigned to in-line connectors, junction connectors, and terminals. The number is preceded by the letter "C" for connectors, "G" for ground terminals, or "T" for non-ground terminals.
| Harness | Location |
|---|
| Engine Compartment | Dashboard | Others (Floor, Door, Trunk, and Roof) | Notes |
| A/C wire harness | | C351, C409 | | Connector to Harness (see A/C WIRE HARNESS ) |
| Audio wire harness (with navigation) | | C401, C402, C403, C404, C405, C406, C407, C408, C409, C410, C411, C412 G401 | | Connector to Harness (see AUDIO WIRE HARNESS (WITH NAVIGATION) ) |
| Audio wire harness (without navigation) | | C401, C402, C403, C404, C405, C406, C407, C408, C409, C410, C411, C412 G401 | | Connector to Harness (see AUDIO WIRE HARNESS (WITHOUT NAVIGATION) ) |
| Battery ground cable | (-), G1 | | | Connector to Harness (see BATTERY GROUND CABLE ) |
| Cable reel subharness | | | | Connector to Harness (see CABLE REEL SUBHARNESS ) |
| Dashboard wire harness (view of driver's side) | | C301, C302, C303, C304, C501, C502, C601, C602, C751 G501, G502 | | Connector to Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) |
| Dashboard wire harness (view of middle to passenger's side) | | C204, C205, C206, C401, C402, C651, C761 G503, G505 | G504 | Connector to Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
| Dashboard wire harness (view of steering column side) | | | | Connector to Harness (see DASHBOARD WIRE HARNESS (VIEW OF STEERING COLUMN SIDE) ) |
| Driver's door courtesy light subharness | | | C752 | Connector to Harness (see DRIVER'S DOOR COURTESY LIGHT SUBHARNESS ) |
| Driver's door switch subharness | | | C753 | Connector to Harness (see DRIVER'S DOOR SWITCH SUBHARNESS ) |
| Driver's door wire harness | | | C751, C752, C753, C754 | Connector to Harness (see DRIVER'S DOOR WIRE HARNESS ) |
| Driver's seat wire harness | | | C701 | Connector to Harness (see DRIVER'S SEAT WIRE HARNESS ) |
| Engine ground cable | T1, G2 | | | Connector to Harness (see ENGINE GROUND CABLE ) |
| Engine wire harness (engine section) | C101, C102, C103, C104, C105, C106 C107 T4, T102 G101 | | | Connector to Harness (see ENGINE WIRE HARNESS (ENGINE SECTION) ) |
| Engine wire harness (transmission section) | C108 | | | Connector to Harness (see ENGINE WIRE HARNESS (TRANSMISSION SECTION) ) |
| EPS ground subharness | C251 T9 | | | Connector to Harness (see EPS GROUND SUBHARNESS ) |
| EPS subharness | C354 T6, T7, T8 | | | Connector to Harness (see EPS SUBHARNESS ) |
| Front passenger's door courtesy light subharness | | | C762 | Connector to Harness (see FRONT PASSENGER'S DOOR COURTESY LIGHT SUBHARNESS ) |
| Front passenger's door wire harness | | | C761, C762 | Connector to Harness (see FRONT PASSENGER'S DOOR WIRE HARNESS ) |
| Front passenger's seat wire harness | | | C702 | Connector to Harness (see FRONT PASSENGER'S SEAT WIRE HARNESS ) |
| Knock sensor subharness | C104 | | | Connector to Harness (see KNOCK SENSOR SUBHARNESS ) |
| Left engine compartment subharness | | C202, C203, C352, C353 | | Connector to Harness (see LEFT ENGINE COMPARTMENT SUBHARNESS ) |
| Left engine compartment wire harness (dashboard branch) | | C301, C302, C303, C304, C305, C351, C352, C353 G302 | | Connector to Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS DASHBOARD BRANCH) ) |
| Left engine compartment wire harness (engine compartment branch) | C101, C102, C201, C251, C354 G301 | | | Connector to Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) |
| Left rear door wire harness | | | C771 | Connector to Harness (see LEFT REAR DOOR WIRE HARNESS ) |
| Left side wire harness | | C305, C601, C602 | C603, C604, C654, C771 G601, G602, G603 | Connector to Harness (see LEFT SIDE WIRE HARNESS ) |
| Moonroof subharness | | | C551 | Connector to Harness (see MOONROOF SUBHARNESS ) |
| ODS unit harness | | | C703 | Connector to Harness (see ODS UNIT HARNESS ) |
| Rear window defogger ground wire | | | G801 | Connector to Harness (see REAR WINDOW DEFOGGER GROUND WIRE ) |
| Rear wire harness | | | C604, C605 G901 | Connector to Harness (see REAR WIRE HARNESS ) |
| Right engine compartment wire harness (dashboard branch) | | C202, C203, C204, C205, C206, C207 G201, G203 | | Connector to Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) |
| Right engine compartment wire harness (engine compartment branch) | C201 G202 | | | Connector to Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) |
| Right rear door wire harness | | | C781 | Connector to Harness (see RIGHT REAR DOOR WIRE HARNESS ) |
| Right side wire harness | | C410, C411, C412, C651 | C652, C653, C654, C655, C781 G651 | Connector to Harness (see RIGHT SIDE WIRE HARNESS ) |
| Roof wire harness | | C501, C502 | C551, C552 | Connector to Harness (see ROOF WIRE HARNESS ) |
| Shift solenoid wire harness | C108 | | | Connector to Harness (see SHIFT SOLENOID WIRE HARNESS ) |
| SRS floor wire harness | | C403 | C603, C653, C701, C702, C703 G701, G702 | Connector to Harness (see SRS FLOOR WIRE HARNESS ) |
| Starter cable | (+), T5, T101 | | | Connector to Harness (see STARTER CABLE ) |
| Transmission ground cable | T2, G3 | | | Connector to Harness (see TRANSMISSION GROUND CABLE ) |
CONNECTOR REFERENCE CHART
Battery Ground Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| (-) | 1 | | Left side of engine compartment | Battery negative terminal | |
| G1 | 2 | | Left side of engine compartment | Body ground, via battery ground cable | |
BATTERY GROUND CABLE HARNESS REFERENCE CHART
Engine Ground Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T1 | 5 | | Right side of engine compartment | Engine | |
| G2 | 6 | | Right side of engine compartment | Body ground, via engine ground cable | |
ENGINE GROUND CABLE HARNESS REFERENCE CHART
Transmission Ground Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T2 | 4 | | Left side of engine compartment | Transmission housing | |
| G3 | 3 | | Left side of engine compartment | Body ground, via transmission ground cable | |
TRANSMISSION GROUND CABLE HARNESS REFERENCE CHART
Identifying Engine, Battery And Transmission Ground Cable. Scheme 16
Scheme 16: Identifying Engine, Battery And Transmission Ground Cable
Starter Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T5 | 3 | | Front of engine | Starter motor | |
| T101 (battery) | 1 | Left side of engine compartment | Under-hood fuse/relay box (see CONNECTOR TO FUSE/RELAY BOX INDEX ) |
| (+) | 2 | | Left side of engine compartment | Battery positive terminal | |
STARTER CABLE HARNESS REFERENCE CHART
Identifying Starter Cable. Scheme 17
Scheme 17: Identifying Starter Cable
Engine Wire Harness (Engine Section)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C compressor clutch | 33 | 1 | Right side of engine compartment | | |
| A/T clutch pressure control solenoid valve C | 26 | 2 | Transmission housing | | |
| Alternator | 34 | 4 | Middle of engine compartment | | |
| Camshaft position (CMP) sensor | 40 | 3 | Right side of engine | | |
| Crankshaft position (CKP) sensor | 23 | 3 | Left side of engine | | |
| Engine coolant temperature (ECT) sensor 1 | 28 | 2 | Left side of engine | | |
| Engine mount control solenoid | 11 | 2 | Left side of engine compartment | | |
| Engine oil pressure switch | 44 | 1 | Right side of engine compartment | | |
| EVAP canister purge valve | 10 | 2 | Left side of engine compartment | | |
| Exhaust gas recirculation (EGR) valve and position sensor | 27 | 5 | Left side of engine compartment | | |
| Front A/F sensor (Bank 2, Sensor 1) | 30 | 6 | Front of engine compartment | | |
| Front secondary heated oxygen sensor (secondary HO2S) (Bank 2, Sensor 2) | 29 | 4 | Front of engine compartment | | |
| Ignition coil No. 1 | 2 | 3 | Middle of engine | | |
| Ignition coil No. 2 | 6 | 3 | Middle of engine | | |
| Ignition coil No. 3 | 9 | 3 | Middle of engine | | |
| Ignition coil No. 4 | 36 | 3 | Middle of engine | | |
| Ignition coil No. 5 | 32 | 3 | Middle of engine | | |
| Ignition coil No. 6 | 31 | 3 | Middle of engine | | |
| Injector No. 1 | 3 | 2 | Middle of engine | | |
| Injector No. 2 | 4 | 2 | Middle of engine | | |
| Injector No. 3 | 8 | 2 | Middle of engine | | |
| Injector No. 4 | 39 | 2 | Middle of engine | | |
| Injector No. 5 | 38 | 2 | Middle of engine | | |
| Injector No. 6 | 37 | 2 | Middle of engine | | |
| Intake manifold tuning (IMT) actuator | 46 | 5 | Middle of engine | | |
| Manifold absolute pressure (MAP) sensor | 14 | 3 | Left side of engine compartment | | |
| Mass air flow (MAF) sensor/Intake air temperature (IAT) sensor | 18 | 5 | Left side of engine compartment | | |
| PCM connector B | 24 | 49 | Left side of engine compartment | | |
| PCM connector C | 25 | 49 | Left side of engine compartment | | |
| Rear A/F sensor (Bank 1, Sensor 1) | 12 | 6 | Rear of engine compartment | | |
| Rear secondary heated oxygen sensor (secondary HO2S) (Bank 1, Sensor 2) | 13 | 4 | Rear of engine compartment | | |
| Rocker arm oil control solenoid | 43 | 1 | Right side of engine | | |
| Rocker arm oil pressure switch | 45 | 2 | Right side of engine | | |
| Throttle position sensor/Throttle actuator | 17 | 6 | Left side of engine compartment | | |
| Transmission fluid pressure switch A (2nd clutch) | 16 | 1 | Transmission housing | | |
ENGINE WIRE HARNESS (ENGINE SECTION) REFERENCE CHART
Identifying Engine Wire Harness (Engine Section). Scheme 18
Scheme 18: Identifying Engine Wire Harness (Engine Section)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C101 | 20 | 13 | Left side of engine compartment | Left engine compartment wire harness (engine compartment branch) | |
| C102 | 19 | 4 | Left side of engine compartment | Left engine compartment wire harness (engine compartment branch) | |
| C103 (junction connector) | 5 | 24 | Middle of engine compartment | | |
| C104 | 42 | 1 | Middle of engine | Knock sensor subharness | |
| C105 (junction connector) | 21 | 24 | Left side of engine compartment | | |
| C106 (junction connector) | 7 | 24 | Middle of engine compartment | | |
| C107 (junction connector) | 22 | 24 | Left side of engine compartment | | |
| T4 | 35 | | Right side of engine compartment | Alternator +B terminal | |
| T102 | 15 | | Left side of engine compartment | Under-hood fuse/relay box (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| G101 | 1 | | Middle of engine compartment | Body ground, via engine wire harness | |
ENGINE WIRE HARNESS (ENGINE SECTION) REFERENCE CHART
Knock Sensor Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Knock sensor | 41 | 1 | Middle of engine | | |
| C104 | 42 | 1 | Middle of engine | Engine wire harness (engine section) | |
KNOCK SENSOR SUBHARNESS REFERENCE CHART
Identifying Engine Wire Harness And Knock Sensor Harness (Engine Section). Scheme 19
Scheme 19: Identifying Engine Wire Harness And Knock Sensor Harness (Engine Section)
Engine Wire Harness (Transmission Section)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/T clutch pressure control solenoid valve A | 7 | 2 | Transmission housing | | |
| A/T clutch pressure control solenoid valve B | 8 | 2 | Transmission housing | | |
| ATF temperature sensor | 9 | 2 | Transmission housing | | |
| Input shaft (mainshaft) speed sensor | 13 | 3 | Transmission housing | | |
| Output shaft (countershaft) speed sensor | 11 | 3 | Transmission housing | | |
| Starter solenoid | 1 | 1 | Left side of engine compartment | | |
| Transmission range switch | 10 | 10 | Transmission housing | | |
| Transmission fluid pressure switch B (3rd clutch) | 12 | 1 | Transmission housing | | |
| 4th clutch transmission fluid pressure switch | 6 | 1 | Transmission housing | | |
| C108 | 14 | 5 | Transmission housing | Shift solenoid wire harness | |
ENGINE WIRE HARNESS (TRANSMISSION SECTION) REFERENCE CHART
Shift Solenoid Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Shift solenoid valve A | 2 | 1 | In the transmission | | |
| Shift solenoid valve B | 5 | 1 | In the transmission | | |
| Shift solenoid valve C | 3 | 1 | In the transmission | | |
| Shift solenoid valve D | 4 | 1 | In the transmission | | |
| C108 | 14 | 5 | Transmission housing | Engine wire harness (transmission section) | |
SHIFT SOLENOID WIRE HARNESS REFERENCE CHART
Identifying Shift Solenoid And Engine Wire Harness. Scheme 20
Scheme 20: Identifying Shift Solenoid And Engine Wire Harness
EPS Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Torque sensor | 5 | 3 | Left of engine compartment | | |
| C354 | 4 | 6 | Left of engine compartment | Left engine compartment wire harness (engine compartment branch) | |
| T6 | 3 | | Middle of engine compartment | Steering gearbox | |
| T7 | 2 | | Middle of engine compartment | Steering gearbox | |
| T8 | 1 | | Middle of engine compartment | Steering gearbox | |
EPS SUBHARNESS REFERENCE CHART
Identifying EPS Subharness. Scheme 21
Scheme 21: Identifying EPS Subharness
Left Engine Compartment Wire Harness (Engine Compartment Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C condenser fan motor | 25 | 2 | Front of engine compartment | | |
| Brake fluid level switch | 5 | 2 | Left side of engine compartment | | |
| Engine coolant temperature (ECT) sensor 2 | 22 | 2 | Front of engine compartment | | |
| Horn (high) | 24 | 1 | Front of engine compartment | | |
| Horn (low) | 28 | 1 | Front of engine compartment | | |
| Keyless buzzer | 17 | 2 | Behind left side of front bumper | | |
| Left fog light | 15 | 2 | Behind left side of front bumper | | |
| Left front impact sensor | 16 | 2 | Behind left side of front bumper | | |
| Left front TPMS initiator | 8 | 3 | Left front of fenderwell | | |
| Left front parking/side marker/turn signal light | 11 | 3 | Behind left headlight | | |
| Left front wheel speed sensor | 7 | 2 | Left side of engine compartment | | |
| Left headlight (high) | 19 | 2 | Behind left headlight | | |
| Left HID unit | 13 | 2 | Behind left headlight | | |
| Optional connector (for parking and back-up sensor system) | 18 | 3 | Left front of engine compartment | | |
| Outside air temperature sensor | 27 | 2 | Front of engine compartment | | |
| PCM connector A | 12 | 49 | Left side of engine compartment | | |
| Radiator fan motor | 21 | 2 | Front of engine compartment | | |
| Security hood switch | 26 | 2 | Front of engine compartment | | |
| Under-hood fuse/relay box connector A (electrical load detector) (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 3 | 3 | Left side of engine compartment | | |
| Under-hood fuse/relay box connector B (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 1 | 14 | Left side of engine compartment | | |
| Under-hood fuse/relay box connector C (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 2 | 5 | Left side of engine compartment | | |
| Windshield wiper motor | 6 | 4 | Left side of engine compartment | | |
| C101 | 10 | 13 | Left side of engine compartment | Engine wire harness (engine section) | |
| C102 | 9 | 4 | Left side of engine compartment | Engine wire harness (engine section) | |
| C201 | 29 | 2 | Right front of engine compartment | Right engine compartment wire harness (engine compartment branch) | |
| C251 | 23 | 1 | Left front of engine compartment | EPS ground subharness | |
| C354 | 4 | 6 | Left side of engine compartment | EPS subharness | |
| G301 | 14 | | Behind left side of front bumper | Body ground, via left engine compartment wire harness | |
LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) REFERENCE CHART
EPS Ground Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C251 | 23 | 1 | Left front of engine compartment | Left engine compartment wire harness (engine compartment branch) | |
| T9 | 20 | | Left front of engine compartment | Front suspension subframe | |
EPS GROUND SUBHARNESS REFERENCE CHART
Identifying EPS Ground Subharness And Left Engine Compartment Wire Harness (Engine Compartment Branch). Scheme 22
Scheme 22: Identifying EPS Ground Subharness And Left Engine Compartment Wire Harness (Engine Compartment Branch)
Left Engine Compartment Wire Harness Dashboard Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Accelerator pedal position sensor | 6 | 6 | Under left side of dash | | |
| Brake pedal position switch | 7 | 4 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector F (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 14 | 33 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector G (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 13 | 13 | Under left side of dash | | |
| Optional connector (for parking and back-up sensor system) | 2 | 4 | Under left side of dash | | |
| C301 | 9 | 24 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C302 | 10 | 2 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C303 | 8 | 4 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C304 | 11 | 13 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C305 | 12 | 8 | Under left side of dash | Left side wire harness | |
| C351 | 5 | 2 | Under middle of dash | A/C wire harness | |
| C352 | 4 | 23 | Under middle of dash | Left engine compartment subharness | |
| C353 | 3 | 2 | Under middle of dash | Left engine compartment subharness | |
| G302 | 1 | | Under left side of dash | Body ground, via left engine compartment wire harness | |
LEFT ENGINE COMPARTMENT WIRE HARNESS DASHBOARD BRANCH) REFERENCE CHART
Identifying Left Engine Compartment Wire Harness (Dashboard Branch). Scheme 23
Scheme 23: Identifying Left Engine Compartment Wire Harness (Dashboard Branch)
Left Engine Compartment Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C202 | 3 | 18 | Under right side of dash | Right engine compartment wire harness (dashboard branch) | |
| C203 | 2 | 2 | Under right side of dash | Right engine compartment wire harness (dashboard branch) | |
| C352 | 4 | 23 | Under middle of dash | Left engine compartment wire harness (dashboard branch) | |
| C353 | 1 | 2 | Under middle of dash | Left engine compartment wire harness (dashboard branch) | |
LEFT ENGINE COMPARTMENT SUBHARNESS REFERENCE CHART
Identifying Left Engine Compartment Subharness. Scheme 24
Scheme 24: Identifying Left Engine Compartment Subharness
Right Engine Compartment Wire Harness (Engine Compartment Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C pressure sensor | 12 | 3 | Right front of engine compartment | | |
| EPS motor | 2 | 3 | Right rear of engine compartment | | |
| Motor angle sensor | 3 | 6 | Right rear of engine compartment | | |
| Right fog light | 6 | 2 | Behind right side of front bumper | | |
| Right front impact sensor | 7 | 2 | Behind right side of front bumper | | |
| Right front parking/side marker/turn signal light | 11 | 3 | Behind right headlight | | |
| Right front TPMS initiator | 14 | 3 | Right front of fenderwell | | |
| Right front wheel speed sensor | 1 | 2 | Right side of engine compartment | | |
| Right headlight (high) | 5 | 2 | Behind right headlight | | |
| Right HID unit | 10 | 2 | Behind right headlight | | |
| VSA modulator-control unit | 13 | 32 | Right side of engine compartment | | |
| Washer fluid level switch | 9 | 2 | Behind right side of front bumper | | (1) |
| Windshield washer motor | 8 | 2 | Behind right side of front bumper | | |
| C201 | 4 | 2 | Right front of engine compartment | Left engine compartment wire harness (engine compartment branch) | |
| G202 | 15 | | Behind right side of front bumper | Body ground, via right engine compartment wire harness | |
| (1) Canada models |
RIGHT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) REFERENCE CHART
Identifying Right Engine Compartment Wire Harness (Engine Compartment Branch). Scheme 25
Scheme 25: Identifying Right Engine Compartment Wire Harness (Engine Compartment Branch)
Right Engine Compartment Wire Harness (Dashboard Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| EPS control unit connector A | 9 | 2 | Under right side of dash | | |
| EPS control unit connector B | 2 | 2 | Under right side of dash | | |
| EPS control unit connector C | 1 | 2 | Under right side of dash | | |
| EPS control unit connector D | 3 | 28 | Under right side of dash | | |
| Passenger's under-dash fuse/relay box connector E (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 13 | 18 | Under right side of dash | | |
| C202 | 5 | 18 | Under right side of dash | Left engine compartment subharness | |
| C203 | 8 | 2 | Under right side of dash | Left engine compartment subharness | |
| C204 | 10 | 3 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C205 | 12 | 16 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C206 | 11 | 4 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C207 (junction connector) | 4 | 12 | Under right side of dash | | |
| G201 | 6 | | Under right side of dash | Body ground, via right engine compartment wire harness | |
| G203 | 7 | | Under right side of dash | Body ground, via right engine compartment wire harness | |
RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) REFERENCE CHART
Identifying Right Engine Compartment Wire Harness (Dashboard Branch). Scheme 26
Scheme 26: Identifying Right Engine Compartment Wire Harness (Dashboard Branch)
Dashboard Wire Harness (View of Driver's Side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Data link connector (DLC) | 27 | 16 | Under left side of dash | | |
| Driver's footwell light | 17 | 2 | Under left side of dash | | |
| Driver's junction box 1 connector A | 8 | 6 | Under left side of dash | | |
| Driver's junction box 1 connector B | 9 | 6 | Under left side of dash | | |
| Driver's junction box 1 connector C | 10 | 8 | Under left side of dash | | |
| Driver's junction box 1 connector D | 7 | 4 | Under left side of dash | | |
| Driver's junction box 1 connector E | 3 | 10 | Under left side of dash | | |
| Driver's junction box 1 connector F | 4 | 8 | Under left side of dash | | |
| Driver's junction box 1 connector G | 6 | 10 | Under left side of dash | | |
| Driver's junction box 1 connector H | 5 | 10 | Under left side of dash | | |
| Driver's junction box 2 connector A | 40 | 4 | Under left side of dash | | |
| Driver's junction box 2 connector B | 31 | 4 | Under left side of dash | | |
| Driver's junction box 2 connector C | 32 | 4 | Under left side of dash | | |
| Driver's junction box 2 connector D | 33 | 6 | Under left side of dash | | |
| Driver's junction box 2 connector E | 39 | 6 | Under left side of dash | | |
| Driver's junction box 2 connector F | 34 | 6 | Under left side of dash | | |
| Driver's junction box 2 connector G | 35 | 6 | Under left side of dash | | |
| Driver's junction box 2 connector H | 38 | 4 | Under left side of dash | | |
| Driver's junction box 2 connector J | 37 | 8 | Under left side of dash | | |
| Driver's junction box 2 connector K | 36 | 10 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector B (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 29 | 2 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector C (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 18 | 5 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector M (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 11 | 4 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector N (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 12 | 16 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector P (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 13 | 20 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector Q (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 15 | 20 | Under left side of dash | Driver's MICU | |
| Driver's under-dash fuse/relay box connector R (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 14 | 24 | Under left side of dash | Driver's MICU | |
| Gauge control module | 2 | 32 | Behind gauge | | |
| VSA OFF switch | 16 | 5 | Left side of dashboard | | |
DASHBOARD WIRE HARNESS (VIEW OF DRIVER's SIDE) REFERENCE CHART
Identifying Dashboard Wire Harness (Driver's Side). Scheme 27
Scheme 27: Identifying Dashboard Wire Harness (Driver's Side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C301 | 21 | 24 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C302 | 23 | 2 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C303 | 20 | 4 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C304 | 22 | 13 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C501 | 24 | 20 | Under left side of dash | Roof wire harness | |
| C502 | 28 | 12 | Under left side of dash | Roof wire harness | |
| C601 | 26 | 23 | Under left side of dash | Left side wire harness | |
| C602 | 25 | 16 | Under left side of dash | Left side wire harness | |
| C751 | 30 | 28 | Under left side of dash | Driver's door wire harness | |
| G501 | 1 | | Under left side of dash | Body ground, via dashboard wire harness | |
| G502 | 19 | | Under left side of dash | Body ground, via dashboard wire harness | |
DASHBOARD WIRE HARNESS (VIEW OF DRIVER's SIDE) REFERENCE CHART
Identifying Dashboard Wire Harness (Driver's Side). Scheme 28
Scheme 28: Identifying Dashboard Wire Harness (Driver's Side)
Dashboard Wire Harness (View of Steering Column Side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| ACC cut relay | 7 | 5 | Behind gauge | | |
| Cable reel connector A | 3 | 20 | In steering column | Cable reel subharness via cable reel | |
| Cable reel connector B | 4 | 4 | In steering column | Driver's airbag inflator via cable reel | |
| Center junction box connector A | 15 | 4 | Under middle of dash | | |
| Center junction box connector B | 16 | 4 | Under middle of dash | | |
| Center junction box connector C | 17 | 4 | Under middle of dash | | |
| Center junction box connector D | 18 | 6 | Under middle of dash | | |
| Center junction box connector E | 14 | 6 | Under middle of dash | | |
| Center junction box connector F | 13 | 6 | Under middle of dash | | |
| Center junction box connector G | 9 | 6 | Under middle of dash | | |
| Center junction box connector H | 12 | 4 | Under middle of dash | | |
| Center junction box connector J | 11 | 8 | Under middle of dash | | |
| Center junction box connector K | 10 | 10 | Under middle of dash | | |
| Combination light switch | 2 | 12 | In steering column | | |
| Console accessory power socket relay | 6 | 4 | Under left side of dash | | |
| IG2 cut relay | 8 | 5 | Behind gauge | | |
| Ignition key switch | 21 | 6 | In steering column | | |
| Ignition switch | 22 | 5 | In steering column | | |
| Immobilizer-keyless control unit | 20 | 7 | In steering column | | |
| Steering angle sensor | 1 | 5 | In steering column | | |
| TPMS control unit | 5 | 20 | Behind gauge | | |
| Wiper/washer switch | 19 | 8 | In steering column | | |
DASHBOARD WIRE HARNESS (VIEW OF STEERING COLUMN SIDE) REFERENCE CHART
Identifying Dashboard Wire Harness (Steering Column Side). Scheme 29
Scheme 29: Identifying Dashboard Wire Harness (Steering Column Side)
Dashboard Wire Harness (View of Middle to Passenger's Side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/T gear position indicator panel light/park-pin switch | 20 | 6 | Under center console | | |
| Driver's seat heater switch | 19 | 6 | Under center console | | |
| Front accessory power socket | 17 | 2 | Under center console | | |
| Front passenger's airbag inflator | 13 | 4 | Under right side of dash | | |
| Front passenger's footwell light | 12 | 2 | Under right side of dash | | |
| Front passenger's seat heater switch | 18 | 7 | Under center console | | |
| In-car temperature sensor | 1 | 2 | Middle of dash | | |
| Parking brake switch | 22 | 1 | Center console | | |
| Passenger's under-dash fuse/relay box connector A (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 7 | 38 | Under right side of dash | | |
| Passenger's under-dash fuse/relay box connector B (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 8 | 1 | Under right side of dash | | |
| Passenger's under-dash fuse/relay box connector C (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 9 | 12 | Under right side of dash | | |
| SRS unit connector A | 16 | 39 | Under middle of dash | | |
| Yaw rate-lateral acceleration sensor | 21 | 4 | Under center console | | |
| C204 | 5 | 3 | Under left side of dash | Right engine compartment wire harness (dashboard branch) | |
| C205 | 10 | 16 | Under left side of dash | Right engine compartment wire harness (dashboard branch) | |
| C206 | 4 | 4 | Under left side of dash | Right engine compartment wire harness (dashboard branch) | |
| C401 | 15 | 28 | Under middle of dash | Audio wire harness With navigation Without navigation | |
| C402 | 14 | 16 | Under middle of dash | Audio wire harness With navigation Without navigation | |
| C651 | 11 | 23 | Under right side of dash | Right side wire harness | |
| C761 | 6 | 23 | Under right side of dash | Front passenger's door wire harness | |
| G503 | 2 | | Under middle of dash | Body ground, via dashboard wire harness | |
| G504 | 23 | | Under center console | Body ground, via dashboard wire harness | |
| G505 | 3 | | Under right side of dash | Body ground, via dashboard wire harness | |
DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER's SIDE) REFERENCE CHART
Identifying Dashboard Wire Harness (Passenger Side). Scheme 30
Scheme 30: Identifying Dashboard Wire Harness (Passenger Side)
Audio Wire Harness (With Navigation)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| ANC/Active sound control unit | 6 | 16 | Middle of dash | | |
| Audio-navigation switch panel | 31 | 24 | Middle of dash | | |
| Audio-navigation unit connector A | 31 | 24 | Under middle of dash | | |
| Audio-navigation unit connector B | 32 | 24 | Under middle of dash | | |
| Audio-navigation unit connector C | 34 | 15 | Under middle of dash | | |
| Audio-navigation unit connector D | 37 | 20 | Under middle of dash | | |
| Audio-navigation unit connector F | 33 | 12 | Under middle of dash | | |
| Audio-navigation unit connector G | 38 | 8 | Under middle of dash | | |
| Audio-navigation unit connector H | 30 | 28 | Under middle of dash | | |
| Automatic lighting/sunlight sensor | 9 | 5 | Middle of dash | | |
| Auxiliary jack | 35 | 5 | Under center console | | |
| Center speaker | 7 | 2 | Middle of dash | | |
| Climate control unit connector A | 2 | 28 | Middle of dash | | |
| Climate control unit connector B | 1 | 12 | Middle of dash | | |
| Console accessory power socket | 36 | 2 | Under center console | | |
| Glove box light | 14 | 2 | Glove box | | |
| HandsFreeLink control unit | 15 | 28 | Under right of dash | | |
| Hazard warning switch | 3 | 5 | Middle of dash | | |
| Interface dial | 4 | 5 | Middle of dash | | |
| Navigation display unit | 8 | 28 | Middle of dash | | |
| Navigation service check connector | 19 | 2 | Under right side of dash | | |
| Passenger's airbag cutoff indicator | 10 | 4 | Middle of dash | | |
| Passenger's under-dash fuse/relay box connector D | 21 | 28 | Under right side of dash | | |
| Trunk lid opener main switch | 13 | 2 | Under right of dash | | |
| C401 | 11 | 28 | Middle of dash | Dash board wire harness (view of middle to passenger's side) | |
| C402 | 12 | 16 | Middle of dash | Dash board wire harness (view of middle to passenger's side) | |
| C403 | 26 | 16 | Middle of dash | SRS floor wire harness | |
| C404 (junction connector) | 29 | 12 | Under middle of dash | | |
| C405 (junction connector) | 28 | 12 | Under middle of dash | | |
| C406 (junction connector) | 24 | 12 | Under middle of dash | | |
| C407 (junction connector) | 22 | 12 | Under right side of dash | | |
| C408 (junction connector) | 18 | 12 | Under right side of dash | | |
| C409 | 27 | 20 | Under middle of dash | A/C wire harness | |
| C410 | 17 | 28 | Under right side of dash | Right side wire harness | |
| C411 | 16 | 34 | Under right side of dash | Right side wire harness | |
| C412 | 20 | 12 | Under right side of dash | Right side wire harness | |
| C413 (junction connector) | 25 | 12 | Under middle of dash | | |
| G401 | 23 | | Under middle of dash | Body ground, via audio wire harness | |
AUDIO WIRE HARNESS (WITH NAVIGATION) REFERENCE CHART
Identifying Audio Wire Harness (With Navigation). Scheme 31
Scheme 31: Identifying Audio Wire Harness (With Navigation)
Audio Wire Harness (Without Navigation)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| ANC/Active sound control unit | 27 | 16 | Middle of dash | | |
| Audio unit connector A | 1 | 24 | Under middle of dash | | |
| Audio unit connector B | 2 | 20 | Under middle of dash | | |
| Audio unit connector D | 3 | 8 | Under middle of dash | | |
| Audio unit connector E | 4 | 14 | Under middle of dash | | |
| Audio-HVAC display unit | 5 | 12 | Middle of dash | | |
| Automatic lighting/sunlight sensor | 6 | 5 | Middle of dash | | |
| Auxiliary jack | 30 | 5 | Under center console | | |
| Center pocket light | 26 | 2 | Middle of dash | | |
| Climate control unit connector A | 29 | 28 | Middle of dash | | |
| Climate control unit connector B | 28 | 12 | Middle of dash | | |
| Console accessory power socket | 32 | 2 | Under center console | | |
| Glove box light | 11 | 2 | Glove box | | |
| HandsFreeLink control unit | 12 | 28 | Under right of dash | | |
| Hazard warning switch | 33 | 5 | Middle of dash | | |
| Passenger's airbag cutoff indicator | 7 | 4 | Middle of dash | | |
| Passenger's under-dash fuse/relay box connector D | 17 | 28 | Under right side of dash | | |
| Trunk lid opener main switch | 10 | 2 | Under right of dash | | |
| USB adaptor unit | 31 | 14 | Under center console | | |
| C401 | 8 | 28 | Middle of dash | Dash board wire harness (view of middle to passenger's side) | |
| C402 | 9 | 16 | Middle of dash | Dash board wire harness (view of middle to passenger's side) | |
| C403 | 22 | 16 | Middle of dash | SRS floor wire harness | |
| C404 (junction connector) | 25 | 12 | Under middle of dash | | |
| C405 (junction connector) | 24 | 12 | Under middle of dash | | |
| C406 (junction connector) | 20 | 12 | Under middle of dash | | |
| C407 (junction connector) | 18 | 12 | Under right side of dash | | |
| C408 (junction connector) | 15 | 12 | Under right side of dash | | |
| C409 | 23 | 20 | Under middle of dash | | |
| C410 | 14 | 28 | Under right side of dash | Right side wire harness | |
| C411 | 13 | 34 | Under right side of dash | Right side wire harness | |
| C412 | 16 | 12 | Under right side of dash | Right side wire harness | |
| C413 (junction connector) | 21 | 12 | Under middle of dash | | |
| G401 | 19 | | Under middle of dash | Body ground, via audio wire harness | |
AUDIO WIRE HARNESS (WITHOUT NAVIGATION) REFERENCE CHART
Identifying Audio Wire Harness (Without Navigation). Scheme 32
Scheme 32: Identifying Audio Wire Harness (Without Navigation)
Left Side Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Condenser A (for rear window defogger) | 18 | 2 | Left B-pillar | | |
| Condenser B (for rear window defogger) | 21 | 2 | Left B-pillar | | |
| Driver's door switch | 23 | 1 | Left B-pillar | | |
| Driver's under-dash fuse/relay box connector D (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 3 | 16 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector E (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 2 | 20 | Under left side of dash | | |
| EVAP canister vent shut valve | 15 | 2 | Under floor (Fuel tank) | | |
| Fuel fill door lock actuator | 13 | 2 | Left front of trunk | | |
| Fuel tank pressure (FTP) sensor | 16 | 3 | Under floor (Fuel tank) | | |
| Fuel tank unit | 5 | 4 | Under rear seat cushion | | |
| High mount brake light | 10 | 2 | Middle of rear shelf | | |
| Left rear door switch | 20 | 1 | Left C-pillar | | |
| Left rear speaker | 12 | 2 | Left side of rear shelf | | |
| Left rear TPMS initiator | 19 | 3 | Under floor | | |
| Left rear wheel speed sensor | 17 | 2 | Under floor | | |
| Rear window defogger connector A (+) | 7 | 1 | Middle of rear shelf | | |
| Subwoofer | 8 | 2 | Middle of rear shelf | | |
| Trunk light | 11 | 2 | Middle of rear shelf | | |
| C305 | 1 | 8 | Under left side of dash | Left engine compartment wire harness (dashboard branch) | |
| C601 | 26 | 23 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C602 | 25 | 16 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C603 | 24 | 2 | Left side of floor | SRS floor wire harness | |
| C604 | 14 | 20 | Left rear of trunk | Rear wire harness | |
| C654 | 9 | 18 | Under rear shelf | Right side wire harness | |
| C771 | 22 | 18 | Left B-pillar | Left rear door wire harness | |
| G601 | 27 | | Left side of floor | Body ground, via left side wire harness | |
| G602 | 6 | | Under rear seat cushion | Body ground, via left side wire harness | |
| G603 | 4 | | Left of rear shelf | Body ground, via left side wire harness | |
LEFT SIDE WIRE HARNESS REFERENCE CHART
Identifying Left Side Wire Harness. Scheme 33
Scheme 33: Identifying Left Side Wire Harness
SRS Floor Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's seat belt tensioner | 17 | 4 | Left B-pillar | | |
| Driver's side airbag inflator | 2 | 2 | Under driver's seat | | |
| Front passenger's seat belt tensioner | 11 | 4 | Right B-pillar | | |
| Front passenger's side airbag inflator | 7 | 2 | Under front passenger's seat | | |
| Left side curtain airbag inflator | 12 | 2 | Left C-pillar | | |
| Left side impact sensor (first) | 18 | 4 | Left B-pillar | | |
| Left side impact sensor (second) | 16 | 2 | Left C-pillar | | |
| Rear safing sensor | 15 | 4 | Under rear seat cushion | | |
| Right side curtain airbag inflator | 14 | 2 | Right C-pillar | | |
| Right side impact sensor (first) | 10 | 4 | Right B-pillar | | |
| Right side impact sensor (second) | 13 | 2 | Right C-pillar | | |
| SRS unit connector B | 3 | 39 | Under middle of dash | | |
| C403 | 4 | 16 | Under middle of dash | Audio wire harness With navigation Without navigation | |
| C603 | 19 | 2 | Under driver's seat | Left side wire harness | |
| C653 | 9 | 4 | Under front passenger's seat | Right side wire harness | |
| C701 | 1 | 23 | Under driver's seat | Driver's seat wire harness | |
| C702 | 6 | 18 | Under front passenger's seat | Front passenger's seat wire harness | |
| C703 | 5 | 4 | Under front passenger's seat | ODS unit harness | |
| G701 | 20 | | Under driver's seat | Body ground, via SRS floor wire harness | |
| G702 | 8 | | Under front passenger's seat | Body ground, via SRS floor wire harness | |
SRS FLOOR WIRE HARNESS REFERENCE CHART
Identifying Srs Floor Wire Harness. Scheme 34
Scheme 34: Identifying Srs Floor Wire Harness
Right Side Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| AcuraLink connector (Female connector) | 7 | 5 | Under right side of rear seat | | (1) |
| AcuraLink connector (Male connector) | 7 | 5 | Under right side of rear seat | | (1) |
| AcuraLink control unit (XM receiver) connector A | 6 | 32 | Under right side of rear seat | | (1) |
| Electrical compass unit | 24 | 6 | Under rear shelf | | (4) |
| Front passenger's door switch | 8 | 1 | Right B-pillar | | |
| Passenger's under-dash fuse/relay box connector H (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 13 | 38 | Under right side of dash | | |
| Right rear door switch | 17 | 1 | Right C-pillar | | |
| Right rear speaker | 3 | 2 | Right side of rear shelf | | |
| Right rear TPMS initiator | 18 | 3 | Under right side of floor | | |
| Right rear wheel speed sensor | 19 | 2 | Under right side of floor | | |
| Stereo amplifier A | 22 | 18 | Right side of trunk | | |
| Stereo amplifier B | 21 | 28 | Right side of trunk | | (3) |
| Stereo amplifier B | 21 | 24 | Right side of trunk | | (4) |
| Stereo amplifier C | 20 | 5 | Right side of trunk | | |
| XM receiver connector A | 6 | 14 | Under right side of rear seat | Audio wire harness | (2) |
| C410 | 10 | 28 | Under right side of dash | Audio wire harness With navigation Without navigation | |
| C411 | 11 | 34 | Under right side of dash | Audio wire harness With navigation Without navigation | |
| C412 | 12 | 12 | Under right side of dash | Audio wire harness With navigation Without navigation | |
| C651 | 9 | 23 | Right kick panel | Dashboard wire harness (view of middle to passenger's side) | |
| C652 (junction connector) | 2 | 12 | Under rear shelf | | |
| C653 | 15 | 4 | Under front passenger's seat | SRS floor wire harness | |
| C654 | 1 | 18 | Under rear shelf | Left side wire harness | |
| C655 | 23 | 6 | Right side of trunk | Rear wire harness | (3) |
| C781 | 16 | 18 | Right B-pillar | Right rear door wire harness | |
| G651 | 14 | | Under front passenger's seat | Body ground, via right side wire harness | |
| (1) With AcuraLink (2) Without AcuraLink (3) With navigation (4) Without navigation |
RIGHT SIDE WIRE HARNESS REFERENCE CHART
Rear Window Defogger Ground Wire
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Rear window defogger connector B (-) | 4 | 1 | Right C-pillar | | |
| G801 | 5 | | Right C-pillar | Body ground, via rear window defogger ground | |
REAR WINDOW DEFOGGER GROUND WIRE REFERENCE CHART
Identifying Right Side Wire Harness And Rear Window Defogger Ground Wire. Scheme 35
Scheme 35: Identifying Right Side Wire Harness And Rear Window Defogger Ground Wire
Rear Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left back-up light | 11 | 3 | Left side of trunk | | |
| Left rear license light | 2 | 2 | Middle of trunk | | |
| Left rear side marker light | 14 | 2 | Left side of trunk | | |
| Left rear taillight/brake light | 13 | 4 | Left side of trunk | | |
| Left rear turn signal light | 15 | 3 | Left side of trunk | | |
| Rearview camera | 1 | 6 | Middle of trunk | | (1) |
| Right back-up light | 5 | 3 | Right side of trunk | | |
| Right rear license light | 4 | 2 | Middle of trunk | | |
| Right rear side marker light | 6 | 2 | Right side of trunk | | |
| Right rear taillight/brake light | 8 | 4 | Right side of trunk | | |
| Right rear turn signal light | 7 | 3 | Right side of trunk | | |
| Trunk lid outer handle switch | 3 | 3 | Middle of trunk | | |
| Trunk lid release actuator/Trunk lid latch switch | 10 | 3 | Middle of trunk | | |
| C604 | 16 | 20 | Left side of rear | Left side wire harness | |
| C655 | 9 | 6 | Right side of rear | Right side wire harness | (1) |
| G901 | 12 | | Left side of rear | Body ground, via rear wire harness | |
| (1) With navigation |
REAR WIRE HARNESS REFERENCE CHART
Identifying Rear Wire Harness. Scheme 36
Scheme 36: Identifying Rear Wire Harness
Roof Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Automatic dimming inside mirror | 2 | 7 | Front of roof | | |
| Front ANC/Active sound control microphone | 5 | 3 | Front of roof | | (2) |
| Front | 5 | 7 | Front of roof | | (1) |
| HFL-Navigation-ANC/Active sound control microphone | | | | | |
| Front individual map light | 12 | 3 | Front of roof | | |
| Driver's vanity mirror light | 11 | 2 | Left front side of roof | | |
| HFL microphone | 5 | 3 | Front of roof | | (2) |
| HomeLink unit | 4 | 5 | Front of roof | | |
| Moonroof switch | 3 | 12 | Front of roof | | |
| Rear ANC/Active sound control microphone | 10 | 2 | Rear of roof | | |
| Passenger's vanity mirror light | 1 | 2 | Right front side of roof | | |
| C501 | 14 | 20 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C502 | 13 | 12 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C551 | 6 | 13 | Middle of roof | Moonroof subharness | |
| C552 (junction connector) | 7 | 12 | Left front of roof | | |
| (1) With navigation (2) Without navigation |
ROOF WIRE HARNESS REFERENCE CHART
Moonroof Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Ceiling light | 8 | 3 | Rear of roof | | |
| Moonroof control unit/motor | 9 | 14 | Rear of roof | | |
| C551 | 6 | 13 | Middle of roof | Roof wire harness | |
MOONROOF SUBHARNESS REFERENCE CHART
Identifying Roof Wire Harness And Moonroof Subharness. Scheme 37
Scheme 37: Identifying Roof Wire Harness And Moonroof Subharness
Driver's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door lock actuator/knob switch/key cylinder switch | 14 | 10 | Driver's door | | |
| Driver's power window motor | 11 | 6 | Driver's door | | |
| Left front speaker | 9 | 2 | Driver's door | | |
| Left front tweeter | 4 | 2 | Driver's door | | |
| Left power mirror | 5 | 13 | Driver's door | | |
| Power window master switch (door multiplex control unit) | 1 | 37 | Driver's door | | |
| Trunk lid opener switch | 10 | 5 | Driver's door | | |
| C751 | 7 | 28 | Under left side of dash | Dashboard wire harness (view of driver's side) | |
| C752 | 13 | 2 | Driver's door | Driver's door courtesy light subharness | |
| C753 | 8 | 20 | Driver's door | Driver's door switch subharness | |
| C754 (junction connector) | 6 | 12 | Driver's door | | |
DRIVER's DOOR WIRE HARNESS REFERENCE CHART
Driver's Door Courtesy Light Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door courtesy light | 12 | 2 | Driver's door | | |
| C752 | 13 | 2 | Driver's door | Driver's door wire harness | |
DRIVER's DOOR COURTESY LIGHT SUBHARNESS REFERENCE CHART
Driver's Door Switch Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driving position memory switch | 2 | 7 | Driver's door | | |
| Power mirror switch | 3 | 13 | Driver's door | | |
| C753 | 8 | 20 | Driver's door | Driver's door wire harness | |
DRIVER's DOOR SWITCH SUBHARNESS REFERENCE CHART
Identifying Driver's Door Wire Harness, Courtesy Light Subharness And Switch Subharness. Scheme 38
Scheme 38: Identifying Driver's Door Wire Harness, Courtesy Light Subharness And Switch Subharness
Front Passenger's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's door lock actuator/knob switch | 4 | 10 | Front passenger's door | | |
| Front passenger's power window motor | 7 | 6 | Front passenger's door | | |
| Front passenger's power window switch | 3 | 37 | Front passenger's door | | |
| Right front speaker | 8 | 2 | Front passenger's door | | |
| Right front tweeter | 2 | 2 | Front passenger's door | | |
| Right power mirror | 1 | 13 | Front passenger's door | | |
| C761 | 9 | 23 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) | |
| C762 | 5 | 2 | Front passenger's door | Front passenger's door courtesy light subharness | |
FRONT PASSENGER's DOOR WIRE HARNESS REFERENCE CHART
Front Passenger's Door Courtesy Light Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's door courtesy light | 6 | 2 | Front passenger's door | | |
| C762 | 5 | 2 | Front passenger's door | Front passenger's door wire harness | |
FRONT PASSENGER's DOOR COURTESY LIGHT SUBHARNESS REFERENCE CHART
Identifying Front Passenger's Door Wire Harness And Courtesy Light. Scheme 39
Scheme 39: Identifying Front Passenger's Door Wire Harness And Courtesy Light
Left Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left rear door courtesy light | 5 | 2 | Left rear door | | |
| Left rear door lock actuator/knob switch | 1 | 10 | Left rear door | | |
| Left rear power window motor | 6 | 2 | Left rear door | | |
| Left rear power window switch | 2 | 14 | Left rear door | | |
| Left rear speaker | 4 | 2 | Left rear door | | |
| C771 | 3 | 18 | Left B-pillar | Left side wire harness | |
LEFT REAR DOOR WIRE HARNESS REFERENCE CHART
Identifying Left Rear Door Wire Harness. Scheme 40
Scheme 40: Identifying Left Rear Door Wire Harness
Right Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right rear door courtesy light | 4 | 2 | Right rear door | | |
| Right rear door lock actuator/knob switch | 2 | 10 | Right rear door | | |
| Right rear power window motor | 3 | 2 | Right rear door | | |
| Right rear power window switch | 1 | 14 | Right rear door | | |
| Right rear speaker | 5 | 2 | Right rear door | | |
| C781 | 6 | 18 | Right B-pillar | Right side wire harness | |
RIGHT REAR DOOR WIRE HARNESS REFERENCE CHART
Identifying Right Rear Door Wire Harness. Scheme 41
Scheme 41: Identifying Right Rear Door Wire Harness
Driver's Seat Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's power seat adjustment switch | 3 | 12 | Left side of driver's seat | | |
| Driver's seat back heater | 9 | 2 | Driver's seat | | |
| Driver's seat belt buckle switch | 10 | 2 | Driver's seat | | |
| Driver's seat cushion heater | 7 | 4 | Driver's seat | | |
| Driver's seat front up-down motor/position sensor | 14 | 5 | Driver's seat | | |
| Driver's seat heater relay (high) | 12 | 4 | Driver's seat | | |
| Driver's seat heater relay (low) | 11 | 5 | Driver's seat | | |
| Driver's seat position sensor | 1 | 2 | Driver's seat | | |
| Driver's seat rear up-down motor/position sensor | 2 | 5 | Driver's seat | | |
| Driver's seat recline motor/position sensor | 5 | 5 | Bottom of seat back | | |
| Driver's seat slide motor/position sensor | 13 | 5 | Driver's seat | | |
| Power seat control unit connector A | 8 | 40 | Under driver's seat | | |
| Power seat control unit connector B | 6 | 18 | Under driver's seat | | |
| C701 | 4 | 23 | Under driver's seat | SRS floor wire harness | |
DRIVER's SEAT WIRE HARNESS REFERENCE CHART
Identifying Driver's Seat Wire Harness. Scheme 42
Scheme 42: Identifying Driver's Seat Wire Harness
Front Passenger's Seat Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's seat adjustment switch | 6 | 12 | Front passenger's seat | | |
| Front passenger's seat belt buckle switch | 2 | 2 | Front passenger's seat | | |
| Front passenger's seat cushion heater | 1 | 4 | Front passenger's seat | | |
| Front passenger's seat heater relay (high) | 4 | 4 | Front passenger's seat | | |
| Front passenger's seat heater relay (low) | 3 | 5 | Front passenger's seat | | |
| Front passenger's seat recline motor | 7 | 2 | Front passenger's seat | | |
| Front passenger's seat slide motor | 8 | 5 | Front passenger's seat | | |
| C702 | 5 | 18 | Under front passenger's seat | SRS floor wire harness | |
FRONT PASSENGER's SEAT WIRE HARNESS REFERENCE CHART
Identifying Driver Seat And Wire Harness. Scheme 43
Scheme 43: Identifying Driver Seat And Wire Harness
ODS Unit Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's seat weight sensor (inner side) | 2 | 2 | Front passenger's seat | | |
| Front passenger's seat weight sensor (outer side) | 4 | 3 | Front passenger's seat | | |
| ODS unit | 1 | 18 | Front passenger's seat | | |
| C703 | 3 | 4 | Under front passenger's seat | SRS floor wire harness | |
ODS UNIT HARNESS REFERENCE CHART
Identifying Front Passenger Seat And Wire Harness. Scheme 44
Scheme 44: Identifying Front Passenger Seat And Wire Harness
Cable Reel Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Audio remote switch | 1 | 12 | Steering wheel | | |
| Cable reel connector C | 6 | 20 | Steering wheel | | |
| Cruise control combination switch | 4 | 12 | Steering wheel | | |
| HFL/Voice control switch | 8 | 7 | Steering wheel | | |
| Horn switch | 7 | 2 | Steering wheel | | |
| Select/reset/information switch | 5 | 7 | Steering wheel | | |
| Paddle shifter+ (Upshift switch) | 3 | 4 | Steering wheel | | |
| Paddle shifter- (Downshift switch) | 2 | 4 | Steering wheel | | |
CABLE REEL SUBHARNESS REFERENCE CHART
Identifying Front Passenger Seat And ODS Unit Harness. Scheme 45
Scheme 45: Identifying Front Passenger Seat And ODS Unit Harness
A/C Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Blower motor | 6 | 2 | Under right side of dash | | |
| Driver's air mix control motor | 1 | 7 | Under middle of dash | | |
| Evaporator temperature sensor | 4 | 2 | Under middle of dash | | |
| Mode control motor | 3 | 7 | Under middle of dash | | |
| Passenger's air mix control motor | 9 | 7 | Under middle of dash | | |
| Power transistor | 7 | 4 | Under middle of dash | | |
| Recirculation control motor | 5 | 7 | Under middle of dash | | |
| C351 | 2 | 2 | Under middle of dash | Left engine compartment wire harness (dashboard branch) | |
| C409 | 8 | 20 | Under middle of dash | Audio wire harness With navigation Without navigation | |
A/C WIRE HARNESS REFERENCE CHART
Identifying Cable Reel Subharness. Scheme 46
Scheme 46: Identifying Cable Reel Subharness
