Power Relay Test
Use this chart to identify the type of relay, then do the test listed for it.
Note. For the turn signal/hazard relay input test (see TURN SIGNAL/HAZARD RELAY INPUT TEST ).
| Relay | Test |
|---|---|
| A/C compressor clutch relay | Normally-open type |
| A/C condenser fan relay | |
| Accessory power socket relay | |
| Blower motor relay | |
| Fog lights relay ('06-08 models) | |
| Ignition coil relay | |
| A/F ratio sensor relay | |
| PGM-FI main relay 1, 2 | |
| Power window relay | |
| Radiator fan relay | |
| Rear window defogger relay | |
| Starter cut relay | |
| Seat heater relay | |
| Throttle actuator control module relay | |
| Daytime running lights relay (Canada models) | Five-terminal type |
| Moonroof close relay | |
| Moonroof open relay |
RELAY REFERENCE CHART
Normally-open type
Check for continuity between the terminals.
Scheme 2
- There should be continuity between the No. 1 and No. 2 terminals when battery positive terminal is connected to the No. 4 terminal, and battery negative terminal is connected to the No. 3 terminal.
- There should be no continuity between the No. 1 and No. 2 terminals when power is disconnected. (Scheme 2): Checking Continuity Between Terminals - Normally-Open Type
Five-terminal type
Check for continuity between the terminals.
Scheme 3
- There should be continuity between the No. 1 and No. 2 terminals when battery positive terminal is connected to the No. 5 terminal, and battery negative terminal is connected to the No. 3 terminal.
- There should be continuity between the No. 1 and No. 4 terminals when power is disconnected. (Scheme 3): Checking Continuity Between Terminals - Five-Terminal Type
