Under-Hood Fuse/relay Box Acura TSX I

Body Electrical 1 illustration ~592 words

Scheme 18

Scheme 18: Removal
Scheme 18: Removal
  1. Make sure you have the anti-theft codes for the audio system and the navigation system (if equipped), then write down the audio presets.
  2. Disconnect the negative battery cable, then disconnect the positive cable, and wait at least 3 minutes.
  3. Remove the under-hood multi-relay box from the under-hood fuse/relay box.
  4. Remove the screws (A) from the alternator and battery cable terminals.
  5. Remove the two mounting bolts (B) from the under-hood fuse/relay box.
  6. Remove the under cover from the under-hood fuse/ relay box.
  7. Disconnect the connectors from the under-hood fuse/relay box.
  8. If replacing the fuse/relay box, carefully remove the relays by prying under the base of the relay. NOTE: Do not use pliers, they will damage the relays.

Installation

  1. Install the relays and connect the connectors to the under-hood fuse/relay box, then install the under-hood fuse/relay box in the reverse order of removal.
  2. Install the removed parts in the reverse order of removal.
  3. Connect the positive cable to the battery, then connect negative cable to the battery.
  4. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
  5. Do the power window control unit reset procedure (see «RESETTING THE POWER WINDOW»(/acura/tsx/i-2003-2008/remont/windows/#power-window-system__resetting-the-power-window) ).
  6. Enter the anti-theft codes for the audio system and navigation system (if equipped), then enter the audio presets. Set the clock (on vehicles without navigation).
  7. Confirm that all systems work properly.

B1055: Relay Control Module lost communication with MICU; B1056: Relay Control Module lost communication with MICU; B1057: Relay Control Module lost communication with MICU (door switch message); B1058: Relay Control Module lost communication with Door Multiplex Control Unit (door lock switch message); B1059: Relay Control Module lost communication with Door Multiplex Control Unit (panic message); B1060: Relay Control Module lost communication with Gauge Control Module (VSP/NE message); B1061: Relay Control Module lost communication with Gauge Control Module (A/T message); B1062: Relay Control Module lost communication with Combination Switch Control Unit (headlight switch message); B1063: Relay Control Module lost communication with Combination Switch Control Unit (wiper switch message)

  1. Clear the DTCs using the Honda Diagnostic System (HDS).
  2. Cycle the ignition switch OFF then ON.
  3. Check for DTCs by selecting the DTCs MENU (DTCs) from the HDS. Is DTC B1055, B1056, B1057, B1058, B1059, B1060, B1061, B1062 and/or B1063 indicated? YES -Go to step 4. NO -Intermittent failure, the B-CAN communication line is OK at this time.
  4. Check for DTCs other than those listed. Are any other DTCs present? YES -Go to step 5. NO -Perform Relay Control Module Input Test (see «RELAY CONTROL MODULE INPUT TEST»(/acura/tsx/i-2003-2008/remont/communication-devices/#multiplex-integrated-control-system) ).
  5. Find the chart that contains at least one retrieved DTC in column A and one retrieved DTC in column B. Perform the input test for the ECU listed in that chart. If no DTC from column B is found then continue to Relay Control Module input test. Chart 1 DTC TROUBLESHOOTING CHART 1 A B ECU B1055 B1005 B1159 MICU (see «MICU INPUT TEST»(/acura/tsx/i-2003-2008/remont/communication-devices/#multiplex-integrated-control-system) ) B1056 B1006 B1255 B1057 B1157 B1806 B1807 Chart 2 DTC TROUBLESHOOTING CHART 2 A B ECU B1058 B1006 Door Multiplex Control Unit (see «DOOR MULTIPLEX CONTROL UNIT INPUT TEST»(/acura/tsx/i-2003-2008/remont/communication-devices/#multiplex-integrated-control-system) ) B1059 B1010 B1160 Chart 3 DTC TROUBLESHOOTING CHART 3 A B ECU B1060 B1008 B1206 Gauge Control Module (see «GAUGE CONTROL MODULE INPUT TEST»(/acura/tsx/i-2003-2008/remont/communication-devices/#multiplex-integrated-control-system) ) B1061 B1205 B1207 B1805 B1808 Chart 4 DTC TROUBLESHOOTING CHART 4 A B ECU B1062 B1007 B1156 Combination Switch Control Unit (see «COMBINATION SWITCH CONTROL UNIT INPUT TEST»(/acura/tsx/i-2003-2008/remont/communication-devices/#multiplex-integrated-control-system) ) B1063 B1155
