Under-hood Fuse/Relay Box
| Socket | Ref | Terminal | Connects to |
|---|---|---|---|
| A/C compressor clutch relay | 2 | 4 | |
| A/C condenser fan relay | 15 | 4 | |
| A (ELD unit) | 5 | 3 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| B | 7 | Not used | |
| Blower motor relay | 1 | 4 | |
| C | 8 | 2 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| D | 4 | 9 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| E | 9 | 16 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| F | 10 | 20 | Front engine compartment wire harness (see FRONT ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| G | 6 | 2 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| H | 11 | 14 | Front engine compartment wire harness (see FRONT ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| J | 12 | 5 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| K | 13 | 10 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| Radiator fan relay | 14 | 4 | |
| Rear window defogger relay | 3 | 4 | |
| T101 | 17 | Starter subharness (see STARTER SUBHARNESS ) | |
| T102 | 16 | Starter subharness (see STARTER SUBHARNESS ) |
UNDER-HOOD FUSE/RELAY BOX REFERENCE CHART
Scheme 44
Under-hood Multi-relay Box
| Socket | Ref | Terminal | Connects to |
|---|---|---|---|
| Fog light relay ('06-08 models) | 1 | 5 | Front engine compartment wire harness (see FRONT ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| Daytime running lights relay (Canada models) | 2 | 5 | Front engine compartment wire harness (see FRONT ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
UNDER-HOOD MULTI-RELAY BOX REFERENCE CHART
Scheme 45
Under-dash Fuse/Relay Box
| Socket | Ref | Terminal | Connects to |
|---|---|---|---|
| A | 6 | 6 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| Accessory power socket relay | 19 | 4 | |
| A/F sensor relay (LAF) | 20 | 4 | |
| B | 12 | 6 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| C | 11 | 12 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| D | 13 | 17 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| E | 8 | 16 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| F | 9 | 14 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| G ('06-08 models) | 14 | 6 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| H | 15 | 14 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| Ignition coil relay (IG COIL) | 23 | 4 | |
| J | 27 | 21 | Driver's door subharness (see DRIVER'S DOOR WIRE HARNESS ) |
| K | 26 | 12 | Driver's door subharness (see DRIVER'S DOOR WIRE HARNESS ) |
| M | 25 | 3 | MCIC (MPCS) service check connector |
| N | 2 | 45 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| P | 17 | 30 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| PGM-FI main relay 1 (Fl MAIN) | 21 | 4 | |
| PGM-FI main relay 2 (FUEL PUMP) | 24 | 4 | |
| Power window relay | 22 | 4 | |
| Q | 16 | 14 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| R | 3 | 2 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| S | 5 | 2 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| Starter cut relay (ST CUT) | 18 | 4 | |
| T | 7 | 6 | Optional connector |
| Turn signal/hazard relay | 4 | 6 | |
| X | 1 | 39 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| W | 10 | 5 | Roof wire harness (see ROOF WIRE HARNESS ) |
UNDER-DASH FUSE/RELAY BOX REFERENCE CHART
