Connector Index
Identification numbers have been assigned to in-line connectors, Junction connectors, and terminals. The number is preceded by the letter "C" for connectors, "G" for ground terminals or "T" for non-ground terminals.
| Harness | Location |
|---|
| Engine Compartment | Dashboard | Others (Floor, Door, Trunk, and Roof) | Notes |
| A/C wire harness | | C851 | | (see A/C WIRE HARNESS ) |
| Battery ground cable | (-) G1 | | | (see BATTERY GROUND CABLE ) |
| Cable reel subharness ('04-05 models) | | | | (see CABLE REEL SUBHARNESS ('04-05 MODELS) ) |
| Dashboard wire harness (left branch) | | C401 through C407, C411, C501, C502, C601, C851 G501 and G502, G504 | | (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| Dashboard wire harness (right branch) | | C201, C551 through C559, C651, C731 and C732 G503, G505 and G506 | | (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) |
| Dashboard wire harness (SRS branch) | | C403 and C501 G505 | | (see DASHBOARD WIRE HARNESS (SRS BRANCH) ) |
| Driver's door subharness | | | C503, C631 and C632 | (see DRIVER'S DOOR SUBHARNESS ) |
| Driver's door wire harness | | | C631 and C632 | (see DRIVER'S DOOR WIRE HARNESS ) |
| Driver's seat wire harness ('04-05 models) | | | C901 | (see DRIVER'S SEAT WIRE HARNESS ('04-05 MODELS) ) |
| Driver's seat wire harness ('06-08 models) | | | C901, C903 and C904 | (see DRIVER'S SEAT WIRE HARNESS ('06-08 MODELS) ) |
| Engine compartment wire harness (left branch) | C151 and C301 G302 | C401 through C404 | | (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| Engine compartment wire harness (right branch) | G202 and G203 | | | (see ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH); ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH) ) |
| Engine ground cable A | T1 G2 | | | (see ENGINE GROUND CABLE A ) |
| Engine ground cable B | T2 G3 | | | (see ENGINE GROUND CABLE B ) |
| Engine wire harness | C101 and C102, C108 C152 G101 T10 through T13 | C201 and C251 | | (see ENGINE WIRE HARNESS ) |
| Floor wire harness (left branch) | | C501 through C503 | C701, C751, C901 through C904 G601 and G603 | (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| Floor wire harness (right branch) | | C551, C552, C557 | C781, C801 and C902 G602 | (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) |
| Floor wire harness (SRS branch) | | | C501, C801 and C904 | (see FLOOR WIRE HARNESS (SRS BRANCH) ) |
| Front engine compartment wire harness (left branch) | C301 G301 | | | (see FRONT ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| Front engine compartment wire harness (right branch) | G201 | | | (see FRONT ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH); FRONT ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH) ) |
| Front passenger's door wire harness | | | C731 and C732 | (see FRONT PASSENGER'S DOOR WIRE HARNESS ) |
| Front passenger's seat subharness ('06-08 models) | | | C905 | (see FRONT PASSENGER'S SEAT SUBHARNESS (4-WAY ADJUSTABLE) ('06-08 MODELS) ) |
| Front passenger's seat wire harness ('05-08 models) | | | C902 and C905 | (see FRONT PASSENGER'S SEAT WIRE HARNESS (4-WAY ADJUSTABLE) ('05-08 MODELS) ) |
| Left rear door wire harness | | | C751 | (see LEFT REAR DOOR WIRE HARNESS ) |
| ODS unit harness ('06-08 models) | | | C801 | (see ODS UNIT HARNESS ('06-08 MODELS) ) |
| OPDS unit harness ('04-05 models) | | | C801 | (see OPDS UNIT HARNESS ('04-05 MODELS) ) |
| Rear window defogger ground wire | | | G604 | (see REAR WINDOW DEFOGGER GROUND WIRE ) |
| Rear wire harness | | | C702 and C703 G701 | (see REAR WIRE HARNESS ) |
| Right rear door wire harness | | | C781 | (see RIGHT REAR DOOR WIRE HARNESS ) |
| Roof wire harness | | C601 and C651 | | (see ROOF WIRE HARNESS ) |
| Shift solenoid wire harness (A/T) | C108 | | | (see ENGINE WIRE HARNESS ) |
| Side curtain airbag harness | | | | (see SIDE CURTAIN AIRBAG HARNESS ) |
| Starter subharness | C101 and C151 T101 through T104 (+) | | | (see STARTER SUBHARNESS ) |
| Throttle actuator control module subharness | | C251 | | (see THROTTLE ACTUATOR CONTROL MODULE SUBHARNESS ) |
| TPMS subharness ('07-08 models) | | C559 | | (see TPMS SUBHARNESS ('07-08 MODELS) ) |
| Transmission range switch subharness (A/T) | C152 | | | (see ENGINE WIRE HARNESS ) |
CONNECTOR HARNESS SPECIFICATION
Battery Ground Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| G1 | 6 | | Left side of engine compartment | Body ground, via battery ground cable |
| (-) | 5 | | Left side of engine compartment | Battery negative terminal |
BATTERY GROUND CABLE REFERENCE
Engine Ground Cable A
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| T1 | 2 | | Right side of engine compartment | Body ground, via battery ground cable |
| G2 | 1 | | Right side of engine compartment | Body ground, via engine ground cable A |
ENGINE GROUND CABLE REFERENCE
Engine Ground Cable B
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| T2 | 3 | | Left side of engine compartment | Transmission housing |
| G3 | 4 | | Left side of engine compartment | Body ground, via engine ground cable B |
ENGINE GROUND CABLE REFERENCE
Scheme 19
Starter Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Alternator | 1 | 4 | Right side of engine compartment | |
| Knock sensor | 3 | 1 | Middle of engine | |
| Starter solenoid | 5 | 1 | Middle of engine | |
| C101 | 10 | 6 | Middle of engine | Engine wire harness (see ENGINE WIRE HARNESS ) |
| C151 | 8 | 1 | Left side of engine compartment | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| T101 | 7 | | Left side of engine compartment | Under-hood fuse/relay box (see CONNECTOR TO FUSE/RELAY BOX INDEX ). |
| T102 | 6 | | Left side of engine compartment | Under-hood fuse/relay box (see CONNECTOR TO FUSE/RELAY BOX INDEX ). |
| T103 | 2 | | Right side of engine compartment | Alternator |
| T104 | 4 | | Middle of engine | Starter motor |
| (+) | 9 | | Left side of engine compartment | Battery positive terminal |
STARTER SUBHARNESS REFERENCE
Scheme 20
Engine Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/F sensor | 20 | 4 | Left side of engine | | A/T |
| A/F sensor | 24 | 4 | Left side of engine | | M/T |
| A/T clutch pressure control solenoid valve A | 28 | 2 | Transmission housing | | |
| A/T clutch pressure control solenoid valve B | 39 | 2 | Transmission housing | | |
| A/T clutch pressure control solenoid valve C | 37 | 2 | Transmission housing | | |
| APP sensor | 2 | 6 | Right side of engine compartment | | |
| Back-up light switch | 29 | 2 | Transmission housing | | M/T |
| CMP sensor A | 13 | 3 | Left side of engine | | |
| CMP sensor B | 12 | 3 | Left side of engine | | |
| CKP sensor | 51 | 3 | Under right side of engine compartment | | |
| EVAP canister purge valve | 11 | 2 | Left side of engine | | |
| Engine coolant temperature (ECT) sensor 1 | 14 | 2 | Left side of engine | | |
| Engine mount control solenoid valve | 50 | 2 | Middle of engine | | |
| Oil pressure switch | 53 | 1 | Under right side of engine compartment | | |
| ECM/PCM connector A | 6 | 31 | Under middle of dash | | |
| ECM/PCM connector B | 7 | 24 | Under middle of dash | | |
| Ignition coil No. 1 | 1 | 3 | Middle of engine | | |
| Ignition coil No. 2 | 4 | 3 | Middle of engine | | |
| Ignition coil No. 3 | 9 | 3 | Middle of engine | | |
| Ignition coil No. 4 | 10 | 3 | Middle of engine | | |
| Injector No. 1 | 49 | 2 | Middle of engine | | |
| Injector No. 2 | 48 | 2 | Middle of engine | | |
| Injector No. 3 | 47 | 2 | Middle of engine | | |
| Injector No. 4 | 45 | 2 | Middle of engine | | |
| Input shaft (mainshaft) speed sensor | 19 | 3 | Transmission housing | | A/T |
| Intake air temperature (IAT) sensor | 41 | 2 | Left side of engine | | |
| MAP sensor | 44 | 3 | Left side of engine | | |
| Output shaft (countershaft) speed sensor | 21 | 3 | Transmission housing | | A/T |
| Output shaft (countershaft) speed sensor | 25 | 3 | Transmission housing | | M/T |
| PCM connector C | 8 | 22 | Under middle of dash | | A/T |
| Reverse lockout solenoid | 22 | 2 | Transmission housing | | M/T |
| Throttle body (TP sensor/throttle actuator) | 42 | 6 | Left side of engine | | |
| VTC oil control solenoid valve | 52 | 2 | Right side of engine | | |
| Rocker arm oil pressure switch (VTEC oil pressure switch) | 54 | 2 | Rear side of engine | | |
| Rocker arm oil control solenoid (VTEC solenoid valve) | 55 | 2 | Rear side of engine | | |
| 2nd clutch transmission fluid pressure switch | 40 | 1 | Transmission housing | | A/T |
| 3rd clutch transmission fluid pressure switch | 30 | 1 | Transmission housing | | A/T |
ENGINE WIRE HARNESS REFERENCE
Scheme 21
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C101 | 43 | 6 | Left side of engine | Starter subharness (see STARTER SUBHARNESS ) | |
| C102 (Junction connector) | 27 | 24 | Left side of engine compartment | | |
| C108 | 38 | 8 | Transmission housing | Shift solenoid wire harness | A/T |
| C152 | 18 | 10 | Transmission housing | Transmission range switch subharness | A/T |
| C201 | 5 | 13 | Under middle of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | |
| C251 | 3 | 13 | Under right side of dash | Throttle actuator control module subharness (see THROTTLE ACTUATOR CONTROL MODULE SUBHARNESS ) | |
| S1 (Terminal joint) | 18 | | Left side of engine compartment | | |
| S2 (Terminal joint) | 17 | | Left side of engine compartment | | |
| S3 (Terminal joint) | 16 | | Left side of engine compartment | | |
| S4 (Terminal joint) | 15 | | Left side of engine compartment | | |
| G101 | 46 | | Middle of engine | Engine ground via engine wire harness | |
Transmission Range Switch Subharness (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Transmission range switch | 26 | 10 | Transmission housing | |
| C152 | 23 | 10 | Transmission housing | Engine wire harness |
TRANSMISSION RANGE SWITCH SUBHARNESS (A/T)
Shift Solenoid Wire Harness (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| ATF temperature sensor | 35 | 2 | Inside transmission housing | |
| Shift solenoid valve A | 33 | 1 | Inside transmission housing | |
| Shift solenoid valve B | 32 | 1 | Inside transmission housing | |
| Shift solenoid valve C | 31 | 1 | Inside transmission housing | |
| Shift solenoid valve D | 34 | 1 | Inside transmission housing | |
| Shift solenoid valve E | 36 | 1 | Inside transmission housing | |
| C108 | 38 | 8 | Transmission housing | Engine wire harness |
SHIFT SOLENOID WIRE HARNESS (A/T) REFERENCE
Scheme 22
Front Engine Compartment Wire Harness (Right branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C compressor | 10 | 3 | Right side of engine compartment | | |
| A/C condenser fan motor | 11 | 2 | Right side of engine compartment | | |
| A/C pressure switch | 6 | 2 | Right side of engine compartment | | |
| High horn | 12 | 1 | Behind middle of front bumper | | |
| Right fog light | 8 | 2 | Behind middle of front bumper | | (1) |
| Right front parking light | 3 | 2 | Behind right headlight assembly | | |
| Right front turn signal light | 7 | 2 | Behind right headlight assembly | | |
| Right headlight (high) | 9 | 3 | Behind right headlight assembly | | |
| Right headlight (low) | 4 | 2 | Behind right headlight assembly | | |
| G201 | 5 | | Right side of front bumper | Body ground, via front engine compartment wire harness | |
| (1) '06-08 models |
FRONT ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH)
TPMS Subharness ('07-08 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Right front initiator | 2 | 3 | Right fender well | |
| C559 | 1 | 4 | Behind right kick panel | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) |
TPMS SUBHARNESS REFERENCE
Scheme 23
Front Engine Compartment Wire Harness (Left branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Daytime running lights relay | 2 | 5 | Left side of engine compartment | | Canada models |
| Engine coolant temperature (ECT) sensor 2 | 13 | 2 | Left side of engine compartment | | '06-08 models |
| Fog light relay | 1 | 5 | Left side of engine compartment | | '06-08 models |
| Security hood switch | 17 | 2 | Behind middle of front bumper | | |
| Low horn | 14 | 1 | Behind middle of front bumper | | |
| Keyless buzzer | 5 | 2 | Behind left front fender | | |
| Left fog light | 11 | 2 | Behind middle of front bumper | | '06-08 models |
| Left front parking light | 6 | 2 | Behind left headlight assembly | | |
| Left front turn signal light | 10 | 2 | Behind left headlight assembly | | |
| Left headlight (high) | 12 | 3 | Behind left headlight assembly | | |
| Left headlight (low) | 8 | 2 | Behind left headlight assembly | | |
| Outside air temperature sensor | 16 | 2 | Middle of front bumper | | |
| Radiator fan motor | 15 | 2 | Left side of engine compartment | | |
| Radiator fan switch | 13 | 2 | Under left side of engine compartment | | '04-05 models |
| Under-hood fuse/relay box connector F (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 3 | 20 | Left side of engine compartment | | |
| Under-hood fuse/relay box connector H (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 4 | 14 | Left side of engine compartment | | |
| C301 | 7 | 6 | Left side of engine compartment | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) | Canada models |
| G301 | 9 | | Behind left side of front bumper | Body ground, via front engine compartment wire harness | |
FRONT ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) REFERENCE
Scheme 24
Engine Compartment Wire Harness (Right branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Power steering pressure (PSP) switch | 2 | 2 | Right side of engine compartment | | |
| Right front impact sensor | 8 | 2 | Behind right side of engine compartment | | (1) |
| Right front impact sensor | 7 | 2 | Behind middle of front bumper | | (2) |
| Right front wheel sensor | 1 | 2 | Right side of engine compartment | | |
| VSA modulator-control unit | 9 | 47 | Right side of engine compartment | | |
| Washer fluid level switch | 5 | 2 | Behind right side of front bumper | | Canada models |
| Windshield washer motor | 4 | 2 | Behind right side of front bumper | | |
| G202 | 6 | | Right side of front bumper | Body ground, via engine compartment wire harness | |
| G203 | 3 | | Right side of engine compartment | Body ground, via engine compartment wire harness | |
| (1) '04-05 models (2) '06-08 models |
ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH) REFERENCE
Scheme 25
Engine Compartment Wire Harness (Left branch)
ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) REFERENCE
Scheme 26
Dashboard Wire Harness (Left branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Antenna lead | 19 | 1 | Under middle of dash | | |
| Audio-HVAC display panel unit connector A | 15 | 22 | Behind audio/HVAC display unit | | |
| Audio-HVAC display panel unit connector B | 16 | 16 | Behind audio/HVAC display unit | | |
| Audio-HVAC display panel unit connector C | 14 | 10 | Behind audio/HVAC display unit | | |
| Audio unit connector A | 21 | 20 | Behind audio unit | | |
| Audio unit connector B | 24 | 14 | Behind audio unit | | |
| Audio unit connector C | 19 | 5 | Behind audio unit | | |
| Audio unit connector D | 22 | 6 | Behind audio unit | | (4) |
| Brake pedal position switch | 36 | 4 | Under left side of dash | | |
| Cable reel connector A | 33 | 4 | In steering column cover | | |
| Cable reel connector B | 18 | 13 | In steering column cover | | (2) |
| Cable reel connector B | 18 | 20 | In steering column cover | | (3) |
| Clutch interlock switch | 39 | 2 | Under left side of dash | | M/T |
| Clutch pedal position switch | 40 | 3 | Under left side of dash | | M/T |
| Data link connector (DLC) | 42 | 16 | Under left side of dash | | |
| Gauge control module connector A | 12 | 22 | Behind gauges control module | | |
| Gauge control module connector B | 9 | 18 | Behind gauges control module | | |
| Hazard warning switch | 13 | 5 | Middle of dash | | (1) |
| Hazard warning switch | 13 | 7 | Middle of dash | | (4) |
| Ignition switch | 28 | 7 | In steering column cover | | |
| Immobilizer control unit-receiver | 32 | 7 | In steering column cover | | |
| Ignition key switch/key light | 29 | 6 | In steering column cover | | |
| In-car temperature sensor | 25 | 2 | Under middle of dash | | |
| Left tweeter | 5 | 2 | Left side of dash | | |
| Moonroof switch | 41 | 6 | Left side of dash | | |
| Navigation display unit | 17 | 20 | Behind audio/HVAC display unit | | |
| Sunlight sensor | 11 | 2 | Middle of dash | | |
| Stereo amplifier connector A | 26 | 14 | Under middle of dash | | |
| Stereo amplifier connector B | 27 | 20 | Under middle of dash | | |
| Steering angle sensor | 34 | 5 | In steering column cover | | |
| TPMS control unit | 35 | 20 | Under left side of dash | | (5) |
| Under-dash fuse/relay box connector A (see UNDER-DASH FUSE/RELAY BOX ) | 48 | 6 | Left kick panel | | |
| Under-dash fuse/relay box connector N (see UNDER-DASH FUSE/RELAY BOX ) | 49 | 45 | Behind left kick panel | | |
| Under-dash fuse/relay box connector P (MICU) (see UNDER-DASH FUSE/RELAY BOX ) | 46 | 30 | Behind left kick panel | | |
| Under-dash fuse/relay box connector Q (MICU) (see UNDER-DASH FUSE/RELAY BOX ) | 47 | 14 | Behind left kick panel | | |
| Under-dash fuse/relay box connector R (see UNDER-DASH FUSE/RELAY BOX ) | 50 | 2 | Behind left kick panel | | |
| Under-dash fuse/relay box connector S (see UNDER-DASH FUSE/RELAY BOX ) | 51 | 2 | Behind left kick panel | | |
| Under-dash fuse/relay box connector X (see UNDER-DASH FUSE/RELAY BOX ) | 45 | 39 | Behind left kick panel | | |
| VSA OFF switch | 38 | 5 | Left side of dash | | |
| Wiper/washer switch connector A | 23 | 8 | In steering column cover | | |
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
| C401 | 8 | 20 | Under left side of dash | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) | (6) |
| C401 | 8 | 24 | Under left side of dash | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) | (7) |
| C402 | 37 | 1 | Under left side of dash | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) | (6) |
| C402 | 37 | 2 | Under left side of dash | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) | (7) |
| C403 | 10 | 4 | Under left side of dash | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) | |
| C404 | 7 | 13 | Under left side of dash | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) | (6) |
| C405 (Junction connector A) | 6 | 28 | Under left side of dash | | |
| C406 (Junction connector B) | 4 | 28 | Under left side of dash | | |
| C407 (Junction connector C) | 3 | 28 | Under left side of dash | | |
| C411 | 20 | 1 | Behind audio unit | | |
| C501 | 43 | 24 | Under left side of dash | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
| C502 | 44 | 4 | Under left side of dash | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
| C601 | 52 | 10 | Under left side of dash | Roof wire harness (see ROOF WIRE HARNESS ) | |
| C851 | 31 | 21 | Under middle of dash | A/C wire harness (see A/C WIRE HARNESS ) | |
| G501 | 2 | | Under left side of dash | Body ground, via dashboard wire harness | |
| G502 | 1 | | Under left side of dash | Body ground, via dashboard wire harness | |
| G504 | 30 | | Under middle of dash | Body ground, via dashboard wire harness | |
| (1) '04-05 models (2) Except '06-08 models with navigation (3) '06-08 models with navigation (4) '06-08 models (5) '07-08 models (6) '04-06 models (7) '07-08 models |
| (2) | Except '06-08 models with navigation |
| (3) | '06-08 models with navigation |
DASHBOARD WIRE HARNESS (LEFT BRANCH) REFERENCE
Scheme 27
Dashboard Wire Harness (Right branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Audio-HVAC subdisplay unit | 5 | 10 | Middle of dash | | With navigation |
| Auxiliary jack assembly | 39 | 5 | Rear of center console | | '06-08 models |
| Blower motor | 26 | 2 | Under right side of dash | | |
| Clock | 5 | 10 | Middle of dash | | Without navigation |
| Console accessory power socket | 40 | 2 | Under center console | | |
| Console box light | 4 | 2 | Middle of dash | | |
| Driver's seat heater switch | 37 | 6 | Under center console | | |
| ECM/PCM connector D | 32 | 17 | Under middle of dash | | |
| ECM/PCM connector E | 31 | 31 | Under middle of dash | | |
| Front accessory power socket | 2 | 2 | Under console panel | | |
| Front passenger's airbag first and second inflators | 6 | 4 | Behind glove box | | |
| Front passenger's seat heater switch | 35 | 6 | Under center console | | |
| Glove box light | 28 | 2 | Behind glove box | | |
| HandsFreeLink control unit | 25 | 22 | Under right side of dash | | '06-08 models |
| Imoes unit | 15 | 5 | Behind glove box | | '07-08 models |
| Park pin switch/transmission gear selection switch/A/T gear position console light | 36 | 8 | Under console panel | | A/T |
| Parking brake switch | 38 | 1 | Under center console | | |
| Power transistor | 27 | 4 | Under right side of dash | | |
| Right tweeter | 16 | 2 | Under middle of dash | | |
| Seat heater relay | 14 | 5 | Under console panel | | |
| Shift lock solenoid | 34 | 2 | Under right side of dash | | A/T |
| SRS unit connector A | 3 | 28 | Under center console | | |
| Throttle actuator control module relay | 13 | 5 | Behind glove box | | |
| Trunk lid opener main switch | 29 | 2 | Behind glove box | | '04 model |
| Trunk lid opener main switch | 12 | 2 | Behind glove box | | '05-08 models |
| C201 | 30 | 13 | Under middle of dash | Engine wire harness (see ENGINE WIRE HARNESS ) | |
| C551 | 21 | 14 | Behind right kick panel | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | '04 model |
| C551 | 21 | 20 | Behind right kick panel | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | '05 model |
| C551 | 21 | 12 | Behind right kick panel | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | '06 model |
| C551 | 20 | 23 | Behind right kick panel | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | '07-08 models |
| C552 | 23 | 21 | Behind right kick panel | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | Navigation (1) |
| C552 | 23 | 24 | Behind right kick panel | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | Navigation (2) |
| C553 (Junction connector A) | 8 | 28 | Behind glove box | | |
| C554 (Junction connector B) | 9 | 28 | Behind glove box | | |
| C555 (Junction connector C) | 10 | 28 | Behind glove box | | |
| C556 (Junction connector D) | 11 | 28 | Behind glove box | | |
| C557 | 22 | 10 | Behind right kick panel | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | '05 model |
| C557 | 22 | 12 | Behind right kick panel | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | '06-08 models |
| C558 (Junction connector) | 7 | 12 | Behind glove box | | |
| C559 | 24 | 4 | Behind right kick panel | TPMS subharness (see TPMS SUBHARNESS ('07-08 MODELS) ) | '07-08 models |
| C651 | 17 | 6 | Behind glove box | Roof wire harness (see ROOF WIRE HARNESS ) | Navigation |
| C731 | 20 | 13 | Behind glove box | Front passenger's door wire harness (see FRONT PASSENGER'S DOOR WIRE HARNESS ) | |
| C732 | 19 | 12 | Behind glove box | Front passenger's door wire harness (see FRONT PASSENGER'S DOOR WIRE HARNESS ) | |
| G503 | 18 | | Behind glove box | Body ground, via dashboard wire harness | |
| G505 | 1 | | Under center console | Body ground, via dashboard wire harness | |
| G506 | 33 | | Under middle of dash | Body ground, via dashboard wire harness | |
| (1) '05 model (2) '06-08 models |
DASHBOARD WIRE HARNESS (RIGHT BRANCH) REFERENCE
Scheme 28
Floor Wire Harness (Left branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| AM/FM antenna amplifier-rear window defogger coil connector A | 11 | 1 | Left C-pillar | | |
| Driver's door switch | 24 | 1 | Left B-pillar | | |
| Driver's seat belt tensioner | 23 | 4 | Left B-pillar | | |
| Driver's side airbag inflator | 22 | 2 | Under driver's seat | | |
| Driver's side impact sensor | 25 | 2 | Left side of floor | | |
| EVAP canister vent shut valve | 16 | 2 | Under left side of vehicle | | |
| Fuel tank unit | 10 | 5 | Middle front of trunk | | |
| Fuel tank pressure (FTP) sensor | 15 | 3 | Under left side of vehicle | | |
| Left rear door switch | 8 | 1 | Left C-pillar | | |
| Left rear initiator | 14 | 3 | Under left side of vehicle | | '07-08 models |
| Left rear wheel sensor | 15 | 2 | Under left side of vehicle | | |
| Noise condenser | 12 | 2 | Left C-pillar | | |
| Under-dash fuse/relay box connector E (see UNDER-DASH FUSE/RELAY BOX ) | 4 | 16 | Behind left kick panel | | |
| Under-dash fuse/relay box connector F (see UNDER-DASH FUSE/RELAY BOX ) | 3 | 14 | Behind left kick panel | | |
| Under-dash fuse/relay box connector G (see UNDER-DASH FUSE/RELAY BOX ) | 2 | 6 | Under left side of dash | | '06-08 models |
| Under-dash fuse/relay box connector H (see UNDER-DASH FUSE/RELAY BOX ) | 5 | 14 | Behind left kick panel | | |
| Yaw rate-lateral acceleration sensor | 20 | 5 | Left side of floor | | |
| C501 | 26 | 24 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| C502 | 27 | 4 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| C503 | 1 | 8 | Under left side of dash | Driver's door subharness (see DRIVER'S DOOR SUBHARNESS ) | '06-08 models |
| C701 (Junction connector) | 13 | 18 | Left front of trunk | Rear wire harness connectors C702 and C703 via junction connector (see REAR WIRE HARNESS ) | |
| C751 | 21 | 17 | Left B-pillar | Left rear door wire harness (see LEFT REAR DOOR WIRE HARNESS ) | |
| C901 | 7 | 10 | Under driver's seat | Driver's seat wire harness '04-05 models (see DRIVER'S SEAT WIRE HARNESS ('04-05 MODELS) ) '06-08 models (see DRIVER'S SEAT WIRE HARNESS ('06-08 MODELS) ) | |
| C903 | 18 | 13 | Under driver's seat | Driver's seat wire harness (see DRIVER'S SEAT WIRE HARNESS ('06-08 MODELS) ) | '06-08 models |
| C904 | 17 | 2 | Under driver's seat | Driver's seat wire harness (see DRIVER'S SEAT WIRE HARNESS ('06-08 MODELS) ) | '06-08 models |
| G601 | 6 | | Left side of floor | Body ground, via floor wire harness | |
| G603 | 9 | | Middle front of trunk | Body ground, via floor wire harness | |
FLOOR WIRE HARNESS (LEFT BRANCH) REFERENCE
Scheme 29
Floor Wire Harness (Right branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's door switch | 12 | 1 | Right B-pillar | | |
| Front passenger's seat belt switch | 9 | 3 | Under front passenger's seat | | '04 model |
| Front passenger's seat belt tensioner | 13 | 4 | Right B-pillar | | |
| Front passenger's seat heater | 8 | 4 | Under front passenger's seat | | '04 model |
| Front passenger's side airbag inflator | 3 | 2 | Under front passenger's seat | | |
| Front passenger's side impact sensor | 10 | 2 | Right side of floor | | |
| High mount brake light | 27 | 2 | Middle of rear shelf | | |
| Left rear speaker | 21 | 2 | Left side of rear shelf | | |
| Navigation inspection connector | 29 | 2 | Right side of rear shelf | | |
| Navigation unit connector A | 23 | 20 | Right side of rear shelf | | |
| Navigation unit connector B | 24 | 14 | Right side of rear shelf | | |
| Navigation unit connector C | 22 | 8 | Right side of rear shelf | | |
| Navigation unit connector G | 25 | 5 | Right side of rear shelf | | '06-08 models |
| Right rear door switch | 17 | 1 | Right C-pillar | | |
| Right rear initiator | 18 | 3 | Under right side of vehicle | | '07-08 models |
| Right rear speaker | 28 | 2 | Right side of rear shelf | | |
| Right rear wheel sensor | 16 | 2 | Under right side of vehicle | | |
| Secondary heated oxygen sensor | 11 | 4 | Right side of floor | | |
| SRS unit connector B | 1 | 28 | Under middle of dash | | |
| Trunk light | 26 | 2 | Middle of rear shelf | | |
| XM receiver connector A | 19 | 14 | Right side of trunk | | '05-08 models |
| C551 | 6 | 14 | Under right kick panel | Dashboard wire harness | '04 model (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) |
| C551 | 6 | 20 | Under right kick panel | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | '05 model |
| C551 | 6 | 12 | Under right kick panel | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | '06 model |
| C551 | 6 | 23 | Under right kick panel | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | '07-08 models |
| C552 | 7 | 21 | Under right kick panel | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | Navigation (1) |
| C552 | 7 | 24 | Under right kick panel | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | Navigation (2) |
| C557 | 5 | 10 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | '05 model |
| C557 | 5 | 12 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | '06-08 models |
| C781 | 14 | 17 | Right B-pillar | Right rear door wire harness (see RIGHT REAR DOOR WIRE HARNESS ) | |
| C801 | 4 | 4 | Under front passenger's seat | OPDS unit harness (see OPDS UNIT HARNESS ('04-05 MODELS) ) | |
| C902 | 2 | 10 | Under front passenger's seat | Front passenger's seat wire harness (see FRONT PASSENGER'S SEAT WIRE HARNESS (4-WAY ADJUSTABLE) ('05-08 MODELS) ) | '05-08 models |
| G602 | 15 | | Right side of floor | Body ground, via floor wire harness | |
| (1) '05 model (2) '06-08 models |
FLOOR WIRE HARNESS (RIGHT BRANCH) REFERENCE
Rear Window Defogger Ground Wire
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Rear window defogger connector B | 20 | 1 | Right C-pillar | |
| G604 | 30 | | Right C-pillar | Body ground, via rear window defogger ground wire |
REAR WINDOW DEFOGGER GROUND WIRE SPECIFICATION
Scheme 30
Rear Wire Harness
| Connector or Terminal | Ref | Cavities | Location | L Connects to |
|---|
| Left back-up light | 11 | 3 | Left side of trunk lid | |
| Left inner taillight | 12 | 2 | Left side of trunk lid | |
| Left rear turn signal light | 15 | 3 | Left side of trunk | |
| Left rear side marker light | 14 | 2 | Left side of trunk | |
| Left brake light/taillight | 13 | 4 | Left side of trunk | |
| Left license plate light | 9 | 2 | Middle of trunk lid | |
| Right back-up light | 5 | 3 | Right side of trunk lid | |
| Right inner taillight | 4 | 2 | Right side of trunk lid | |
| Right license plate light | 6 | 2 | Middle of trunk lid | |
| Right rear turn signal light | 1 | 3 | Right side of trunk | |
| Right rear side marker light | 2 | 2 | Right side of trunk | |
| Right brake light/taillight | 3 | 4 | Right side of trunk | |
| Trailer lighting connector | 16 | 2 | Left side of trunk | |
| Trunk lid latch switch/opener solenoid | 7 | 3 | Middle of trunk lid | |
| Trunk lid opener switch | 8 | 2 | Middle of trunk lid | |
| C702 (Junction connector) | 18 | 14 | Left side of trunk | Floor wire harness connector C701 via junction connector (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| C703 (Junction connector) | 17 | 10 | Left side of trunk | Floor wire harness connector C701 via junction connector (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| G701 | 10 | | Left side of trunk | Body ground, via rear wire harness |
REAR WIRE HARNESS SPECIFICATION
Scheme 31
Roof Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Automatic dimming inside mirror | 4 | 7 | Behind rearview mirror | | |
| Ceiling light | 11 | 3 | Rear of roof | | |
| Driver's vanity mirror light | 6 | 2 | Driver's sunvisor mount | | |
| Ambient light | 3 | 10 | Front of roof | | |
| Front passenger's vanity mirror light | 2 | 2 | Front passenger's sunvisor mount | | |
| Individual map lights | 5 | 3 | Front of roof | | |
| Moonroof close relay | 8 | 5 | Rear of roof | | |
| Moonroof motor | 7 | 2 | Rear of roof | | |
| Moonroof open relay | 9 | 5 | Rear of roof | | |
| Moonroof limit switch | 10 | 4 | Rear of roof | | |
| Under-dash fuse/relay box connector W (see UNDER-DASH FUSE/RELAY BOX ) | 12 | 5 | Behind left kick panel | | |
| C601 | 13 | 10 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| C651 | 1 | 6 | Behind glove box | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | Navigation |
ROOF WIRE HARNESS SPECIFICATION
Scheme 32
Cable Reel Subharness ('04-05 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Audio remote switch | 1 | 4 | Steering wheel | | |
| Cable reel connector C | 3 | 13 | Steering wheel | | (1) |
| Cable reel connector C | 3 | 20 | Steering wheel | | (2) |
| Cruise control combination switch | 5 | 5 | Steering wheel | | |
| Horn switch | 4 | 1 | Steering wheel | | |
| Voice control switch | 2 | 4 | Steering wheel | | |
| (1) Without navigation (2) With navigation |
CABLE REEL SUBHARNESS SPECIFICATION
Throttle Actuator Control Module Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Throttle actuator control module | 7 | 16 | Under right side of dash | |
| C251 | 16 | 13 | Under right side of dash | Engine wire harness (see ENGINE WIRE HARNESS ) |
THROTTLE ACTUATOR CONTROL MODULE SUBHARNESS SPECIFICATION
Scheme 33
Driver's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door courtesy light | 13 | 2 | Driver's door | | |
| Driver's door key cylinder switch | 1 | 3 | Driver's door | | |
| Driver's door lock actuator | 14 | 2 | Driver's door | | |
| Driver's door lock knob switch | 15 | 3 | Driver's door | | |
| Driver's door speaker | 11 | 2 | Driver's door | | |
| Driver's power window motor | 12 | 6 | Driver's door | | |
| Driver's seat memory switch | 4 | 12 | Driver's door | | (1) |
| Left power mirror/left side turn signal light | 5 | 13 | Driver's door | | |
| Power mirror switch | 3 | 13 | Driver's door | | |
| Power window master switch (door multiplex control unit) | 2 | 23 | Driver's door | | |
| C631 | 7 | 20 | Driver's door | Driver's door subharness | |
| C632 | 10 | 17 | Driver's door | Driver's door subharness | |
| (1) '06-08 models |
DRIVER'S DOOR WIRE HARNESS SPECIFICATION
Driver's Door Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Under-dash fuse/relay box connector J (see UNDER-DASH FUSE/RELAY BOX ) | 8 | 21 | Behind left kick panel | | |
| Under-dash fuse/relay box connector K (see UNDER-DASH FUSE/RELAY BOX ) | 9 | 12 | Behind left kick panel | | |
| C503 | 7 | 8 | Under left side of dash Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | | (1) |
| C631 | 6 | 20 | Driver's door | Driver's door wire harness | |
| C632 | 10 | 17 | Driver's door | Driver's door wire harness | |
| (1) '06-08 models |
DRIVER'S DOOR SUBHARNESS SPECIFICATION
Scheme 34
Front Passenger's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Front passenger's door courtesy light | 5 | 2 | Front passenger's door | |
| Front passenger's door lock actuator | 4 | 2 | Front passenger's door | |
| Front passenger's door lock switch | 2 | 3 | Front passenger's door | |
| Front passenger's door lock knob switch | 3 | 3 | Front passenger's door | |
| Front passenger's door speaker | 8 | 2 | Front passenger's door | |
| Front passenger's power window motor | 7 | 6 | Front passenger's door | |
| Front passenger's power window switch | 6 | 6 | Front passenger's door | |
| Right power mirror/right side turn signal light | 1 | 13 | Front passenger's door | |
| C731 | 9 | 13 | Behind glove box | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) |
| C732 | 10 | 12 | Behind glove box | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) |
FRONT PASSENGER'S DOOR WIRE HARNESS SPECIFICATION
Scheme 35
Left Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Left rear door speaker | 3 | 2 | Left rear door | |
| Left rear door lock actuator | 5 | 2 | Left rear door | |
| Left rear door lock knob switch | 6 | 3 | Left rear door | |
| Left rear power window motor | 1 | 6 | Left rear door | |
| Left rear power window switch | 4 | 6 | Left rear door | |
| C751 | 2 | 17 | Left B-pillar | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
LEFT REAR DOOR WIRE HARNESS SPECIFICATION
Scheme 36
Right Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Right rear door speaker | 4 | 2 | Right rear door | |
| Right rear door lock actuator | 2 | 2 | Right rear door | |
| Right rear door lock knob switch | 1 | 3 | Right rear door | |
| Right rear power window motor | 6 | 6 | Right rear door | |
| Right rear power window switch | 3 | 6 | Right rear door | |
| C781 | 5 | 17 | Right B-pillar | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) |
RIGHT REAR DOOR WIRE HARNESS SPECIFICATION
Scheme 37
Dashboard Wire Harness (SRS branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Cable reel connector A | 19 | 4 | Under left side of dash | |
| Front passenger's airbag first and second inflators | 5 | 4 | Under right side of dash | |
| SRS unit connector A | 2 | 28 | Under middle of dash | |
| Under-dash fuse/relay box connector R (see UNDER-DASH FUSE/RELAY BOX ) | 21 | 2 | Behind left kick panel | |
| Under-dash fuse/relay box connector S (see UNDER-DASH FUSE/RELAY BOX ) | 22 | 2 | Behind left kick panel | |
| C403 | 1 | 4 | Under left side of dash | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| C501 | 20 | 24 | Under left side of dash | Floor wire harness |
| G505 | 16 | | | Body ground, via dashboard wire harness |
DASHBOARD WIRE HARNESS (SRS BRANCH) SPECIFICATION
Floor Wire Harness (SRS branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's seat belt tensioner | 14 | 4 | Left B-pillar | | |
| Driver's side airbag inflator | 18 | 2 | Under driver's seat | | |
| Front passenger's seat belt tensioner | 9 | 4 | Right B-pillar | | |
| Front passenger's side airbag inflator | 7 | 2 | Under front passenger's seat | | |
| Left side impact sensor (first) | 17 | 2 | Left side of floor | | |
| Right side impact sensor (first) | 10 | 2 | Under front passenger's seat | | |
| SRS unit connector B | 3 | 28 | Under middle of dash | | |
| C501 | 20 | 24 | Under left side dash | Dashboard wire harness | |
| C801 | 6 | 4 | Under front passenger's seat | OPDS unit harness | '04-05 models |
| C801 | 6 | 4 | Under front passenger's seat | ODS unit harness | '06-08 models |
| C904 | 15 | 2 | Under driver's seat | Driver's seat wire harness | '06-08 models |
FLOOR WIRE HARNESS (SRS BRANCH) REFERENCE
OPDS Unit Harness ('04-05 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| OPDS unit connector D | 11 | 8 | In front passenger's seat | |
| C801 | 6 | 4 | Under front passenger's seat | Floor wire harness |
OPDS UNIT HARNESS REFERENCE
ODS Unit Harness ('06-08 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Front passenger's seat weight sensor (IN) | 12 | 3 | Under front passenger's seat | |
| Front passenger's seat weight sensor (OUT) | 8 | 2 | Under front passenger's seat | |
| ODS unit | 11 | 18 | Under front passenger's seat | |
| C801 | 6 | 4 | Under front passenger's seat | Floor wire harness |
ODS UNIT HARNESS REFERENCE
Driver's Seat Wire Harness ('06-08 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Driver's seat position sensor | 13 | 2 | Under driver's seat | |
| C904 | 15 | 2 | Under driver's seat | Floor wire harness |
DRIVER'S SEAT WIRE HARNESS REFERENCE
Side Curtain Airbag Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| SRS unit connector C | 4 | 16 | Under middle of dash | |
SIDE CURTAIN AIRBAG HARNESS REFERENCE
Scheme 38
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| SRS unit connector A | 1 | 28 | Under middle of dash | |
DASHBOARD WIRE HARNESS (SRS BRANCH) REFERENCE
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| SRS unit connector B | 2 | 28 | Under middle of dash | |
FLOOR WIRE HARNESS (SRS BRANCH) REFERENCE
| Connector or Terminal | Ref | Cavities | Location |
|---|
| Left side impact sensor (second) | 6 | 2 | Left C-pillar |
| Driver's side curtain airbag | 7 | 2 | Left C-pillar |
| Front passenger's side curtain airbag | 4 | 2 | Right C-pillar |
| Right side impact sensor (second) | 5 | 2 | Right C-pillar |
| SRS unit connector C | 3 | 16 | Under middle of dash |
SIDE CURTAIN AIRBAG HARNESS SPECIFICATION
Scheme 39
Driver's Seat Wire Harness ('04-05 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Driver's power seat adjustment switch | 8 | 12 | Left side of driver's seat | |
| Driver's seat belt buckle switch | 3 | 3 | Under driver's seat | |
| Driver's seat heater | 4 | 4 | Under driver's seat | |
| Driver's power seat front up/down motor | 6 | 2 | Under driver's seat | |
| Driver's power seat rear up/down motor | 7 | 2 | Under driver's seat | |
| Driver's power seat recline motor | 5 | 5 | Under driver's seat | |
| Driver's power slide motor | 1 | 2 | Under driver's seat | |
| C901 | 2 | 10 | Under driver's seat | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
DRIVER'S SEAT WIRE HARNESS SPECIFICATION
Scheme 40
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Driver's power seat adjustment switch | 10 | 12 | Left side of driver's seat | |
| Driver's seat belt buckle switch | 13 | 3 | Under driver's seat | |
| Driver's seat heater | 3 | 4 | Under driver's seat | |
| Driver's seat position sensor | 5 | 2 | Under driver's seat | |
| Front up-down motor/position sensor | 4 | 5 | Under driver's seat | |
| Power seat control unit A | 1 | 40 | Under driver's seat | |
| Power seat control unit B | 12 | 18 | Under driver's seat | |
| Rear up-down motor/position sensor | 8 | 5 | Under driver's seat | |
| Recline motor | 9 | 5 | Under driver's seat | |
| Driver's power seat slide motor | 11 | 2 | Under driver's seat | |
| Driver's power seat slide position sensor | 2 | 3 | Under driver's seat | |
| C901 | 6 | 10 | Under driver's seat | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| C903 | 7 | 13 | Under driver's seat | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| C904 | 14 | 2 | Under driver's seat | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
DRIVER'S SEAT WIRE HARNESS SPECIFICATION
Scheme 41
Front Passenger's Seat Wire Harness (4-Way Adjustable) ('05-08 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's power seat adjustment switch | 3 | 12 | Right side of front passenger's seat | | |
| Front passenger's seat belt buckle switch | 6 | 3 | Under front passenger's seat | | |
| Front passenger's seat heater | 8 | 4 | Under front passenger's seat | | |
| Front passenger's seat recline motor | 7 | 5 | Under front passenger's seat | | (1) |
| Front passenger's seat slide motor | 5 | 2 | Under front passenger's seat | | |
| C902 | 4 | 10 | Under front passenger's seat | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | |
| C905 | 2 | 2 | Right side of front passenger's seat | Front passenger's seat subharness | (2) |
| (1) '05 model (2) '06-08 models |
FRONT PASSENGER'S SEAT WIRE HARNESS SPECIFICATION
Front Passenger's Seat Subharness (4-Way Adjustable) ('06-08 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Front passenger's seat recline motor | 1 | 2 | Right side of front passenger's seat | |
| C905 | 2 | 2 | Right side of front passenger's seat | Front passenger's seat wire harness |
FRONT PASSENGER'S SEAT SUBHARNESS SPECIFICATION
Scheme 42
A/C Wire harness
| Connector or Terminal | Ref | Cavities | Location | Connects to |
|---|
| Driver's air mix control motor | 5 | 7 | Under middle of dash | |
| Evaporator temperature sensor | 6 | 2 | Under middle of dash | |
| Front passenger's air mix control motor | 3 | 7 | Under middle of dash | |
| Mode control motor | 2 | 7 | Under middle of dash | |
| Recirculation control motor | 1 | 7 | Under middle of dash | |
| C851 | 4 | 21 | Under middle of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
A/C WIRE HARNESS SPECIFICATION
Scheme 43
