Accessory Power Sockets Acura TSX I

Body Electrical 8 illustrations ~408 words

Scheme 50

Scheme 50: Component Location Index
Scheme 50: Component Location Index

Scheme 51

Scheme 51: Circuit Diagram
Scheme 51: Circuit Diagram

Scheme 52

Scheme 52: Front Accessory Power Socket Test/Replacement
Scheme 52: Front Accessory Power Socket Test/Replacement

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54
  1. Remove the center console holder (see step 4 on «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
  2. Disconnect the 2P connector from the front accessory power socket.
  3. Inspect the connector terminals to be sure they are all making good contact. If the terminals are bent, loose, or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 4.
  4. Turn the ignition switch to ACC (I), and measure the voltage between the No. 1 terminal and body ground. There should be battery voltage. If there is battery voltage, go to step 5. If there is no battery voltage, check for: Blown No. 9 (15 A) or No. 32 (7.5 A) fuse in the under-dash fuse/relay box. Faulty accessory power socket relay. Poor ground (G 501). An open in the wire.
  5. Check for continuity between the No. 2 terminal and body ground. There should be continuity. If there is continuity, go to step 6. If there is no continuity, check for: Poor ground (G 506). An open in the wire.
  6. Remove the housing (A) and socket (B).
  7. Remove the ring (A).
  8. Install in the reverse order of removal.

Scheme 55

Scheme 55: Console Accessory Power Socket Test/Replacement
Scheme 55: Console Accessory Power Socket Test/Replacement

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57
  1. Open the center console.
  2. Remove the screw and accessory power socket panel (A).
  3. Disconnect the 2P connector (B) from the console accessory power socket (C).
  4. Inspect the connector terminals to be sure they are all making good contact. If the terminals are bent, loose, or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5.
  5. Turn the ignition switch to ACC (I), and measure the voltage between the No. 1 terminal and body ground. There should be battery voltage. If there is battery voltage, go to step 6. If there is no battery voltage, check for: Blown No. 9 (15 A) or No. 32 (7.5 A) fuse in the under-dash fuse/relay box. Faulty accessory power socket relay. Poor ground (G501). An open in the wire.
  6. Check for continuity between the No. 2 terminal and body ground. There should be continuity. If there is continuity, go to step 7. If there is no continuity, check for: Poor ground (G 506). An open in the wire.
  7. Remove the housing (A) and socket (B).
  8. Remove the housing (A) from the panel (B).
  9. Install in the reverse order of removal.
