FILLING THE POWER STEERING FLUID RESERVOIR
Fit the battery cable.
| WARNING | Avoid skin contact with the oil. |
Install
- the hose with the clamp to the oil reservoir
- the oil reservoir.
Fill the power steering fluid reservoir.
Note. For the correct oil grade use Volvo power steering fluid, part number: 116 1529-1.
Turn the steering wheel between both end positions several times.
Check and fill with oil as necessary. Apply the parking brake. Start the engine.
A: Turn the steering wheel slowly to the right, keep it at the end position for 2 seconds.
B: Turn the steering wheel slowly to the left, keep it at the end position for 2 seconds. Repeat steps A and B 10 times.
INSTALLING FLUID RESERVOIR
- Install the reservoir in reverse order
- Top up with oil. Use Volvo power steering fluid, P/N 1161529-1 to ensure the correct oil quality.
DRAINING OIL
| WARNING | Avoid skin contact with the oil. |
Note. Place paper over the generator (GEN) as protection against oil.
Install lock grip pliers on the hose from the fluid reservoir as close to the power steering pump as possible.
Extract the oil.
RESERVOIR FLUID POWER STEERING
Special tools T9512859 EVACUATION EQUIPMENT FOR FLUID Tool number: T9512859 Tool description: EVACUATION EQUIPMENT FOR FLUID Tool boards
| Materials | |
|---|---|
| Designation | Part number |
| Power steering oil | 1161529 |
Note. Removal steps in this procedure may contain installation details.
Draw up the fluid from the reservoir.
see 9512859
Scheme 24
To install, reverse the removal procedure.
Fill the reservoir. Use: Power steering oil, 1161529 .
| CAUTION | Avoid skin contact with the oil. |
Note. For the correct oil grade use Volvo power steering fluid, part number: 116 1529-1.
Fit the battery cable. Fill the power steering fluid reservoir.
Turn the steering wheel between both end positions several times.
Check and fill with oil as necessary.
Apply the parking brake.
Start the engine.
A: Turn the steering wheel slowly to the right, keep it at the end position for 2 seconds.
B: Turn the steering wheel slowly to the left, keep it at the end position for 2 seconds. Repeat steps A and B 10 times.
DRAINING THE POWER STEERING FLUID RESERVOIR
| CAUTION | Avoid skin contact with the oil. |
Lift up the oil reservoir. Place paper under the oil reservoir for any oil spillage.
Position a container under the oil reservoir. Remove the hose with the clamp from the oil reservoir. Drain the oil.
Fit the battery cable.
| CAUTION | Avoid skin contact with the oil. |
Install
- the hose with the clamp to the oil reservoir
- the oil reservoir.
Fill the power steering fluid reservoir.
Note. For the correct oil grade use Volvo power steering fluid, part number: 116 1529-1.
Turn the steering wheel between both end positions several times.
Check and fill with oil as necessary.
Apply the parking brake. Start the engine.
A: Turn the steering wheel slowly to the right, keep it at the end position for 2 seconds.
B: Turn the steering wheel slowly to the left, keep it at the end position for 2 seconds.
Repeat steps A and B 10 times.
| CAUTION | Avoid skin contact with the oil. |
Note. For the correct oil grade use Volvo power steering fluid, part number: 116 1529-1.
Fit the battery cable. Fill the power steering fluid reservoir.
Turn the steering wheel between both end positions several times.
Check and fill with oil as necessary.
Apply the parking brake.
Start the engine.
A: Turn the steering wheel slowly to the right, keep it at the end position for 2 seconds.
B: Turn the steering wheel slowly to the left, keep it at the end position for 2 seconds. Repeat steps A and B 10 times.
