Tightening Torque, Paint - Specifications: Specifications Volvo V70 II

Frames, Subframes & Crossmembers 2 illustrations ~178 words

General Tightening Torque

Note. Screws coated with a locking fluid or self locking nuts must be replaced with new when reinstalled.

See the table below to find the tightening torques for components not included in the summary.

Nuts and screws which are not self locking can be reused provided that they are in good condition.

ThreadTightening torque (Nm)
M55
M610
M717
M824
M1050
M1280
M14130

Summary Of Tightening Torques For Specific Components

Note. Screws coated with locking fluid or sealant must be replaced with new ones when reinstalled.

Always use new screws and nuts when angle tightening. Any exceptions to this rule will be indicated in the method.

Angle-tightening in tight spaces. See Screwed joint, torque/angle tightening .

Seat belts
Seatbelt front: seatbelt reel Seatbelt front: bracket Seatbelt rear center: seatbelt reel Seatbelt rear center: upper seatbelt mounting Seatbelt (third row): seatbelt reel40 Nm 48 Nm 24 Nm 48 Nm
Collision sensor
Collision sensor Collision sensor front6 Nm 6 Nm
Buckle seatbelt
Buckle seatbelt front Buckle seatbelt rear (second row) Buckle seatbelt rear (third row)48 Nm 48 Nm 48 Nm
End plate
End plate front Endplate rear (second row) End plate center seat (second row) End plate rear (third row)48 Nm 48 Nm 48 Nm 48 Nm
Whiplash unit
Deformation element Whiplash element: self tapping Torx-screw, fixed seat Whiplash element: lock nut17 Nm 9 Nm 18 Nm
Rails
Rails front mounting Rails center mounting Rails rear mounting8 Nm 8 Nm 8 Nm
Engine coolant heater
Control module Water pump holder / clamp Cover (over engine coolant temperature sensor and overheat protection thermostat) Overheat protection thermostat Engine cooling fan (FC) mounting Engine cooling fan (FC) shaft Glow plug2 Nm 3 Nm 2 Nm 2 Nm 2 Nm 3 Nm 15 Nm
AC compressor
Magnetic clutch compressor - magnetic coil Magnetic clutch compressor - drive plate (5 and 6 cylinder engines) Magnetic clutch compressor - drive plate (8 cylinder engine)5 Nm 13 Nm 24 Nm
Air conditioning (A/C) condenser with integrated drier
Pressure sensor Drier, lower mounting13 Nm 13 Nm
Drier, upper mountingStep 1: 6 Nm. Step 2: Loosen 90°.
Rear air conditioning (A/C)
Upper mounting points (climate control unit assembly) Lower mounting point (climate control unit assembly) Fan motor Pipe connection to expansion valve Covers around evaporator6 Nm 6 Nm 1.7 0.3 Nm 4.5 0.5 Nm 1.5 0.3 Nm
Seats
Upper screw seat frame50 Nm
Lower screw seat frame24 Nm
Floor hatch
Sems screw M6 x 206 Nm
Center arm rest rear seat
Screw for the bracket1 Nm
Screw for the shaft and cover4 Nm

Scheme 1

Scheme 1: Exterior Color, Color Codes

Scheme 2

Scheme 2

Exterior color, code / supplier / paint type. Written in two groups divided by a -.

The first group (3 digits) is the exterior color, the last group (2 digits) is the supplier and paint type.

If the car has 2 colors, both codes are written, divided by a "/". Then the main color is to the left of "/".
