Scheme 6
D1 = 978 mm
Scheme 7
D2 = 1381 mm
D3 = 809 mm
Scheme 8
D4 = 813 mm
Scheme 9
D5 = 1202 mm
D6 = 1136 mm
Scheme 10
E1 = 1492 mm
E2 = 1484 mm
E8 = 1421 mm
Scheme 11
Scheme 12
A11 = 210 mm
A12 = 27 mm
A13 = 20 mm
Scheme 13
E3 = 1478 mm
E4 = 1428 mm
Scheme 14
E5 = 1648 mm
Scheme 15
E6 = 1488 mm
Scheme 16
E7 = 581 mm
Scheme 17
A1 = 1490 mm
A2 = 708 mm.
A3 = 868 mm
Scheme 18
A4 = 946 mm
A5 = 1282 mm
A6 = 1350 mm
Scheme 19
A7 = 926 mm
A8 = 812 mm
Scheme 20
A9 = 97 mm
Left side.
Scheme 21
A10 = 159 mm
Right-hand side.
A17 = 21 mm
A11 = 216 mm
A12 = 31 mm
A13 = 23 mm
Scheme 22
A14 = 98 mm
A15 = 40 mm
A16 = 38 mm
Scheme 23
B1 = 1066 mm
B2 = 785 mm
B3 = 1239 mm
Scheme 24
Scheme 25
Scheme 26
1. There must not be any sealant on the surface.
2. Seal with class A finish.
See Class A .
3. Seal with class B finish.
See Class B .
4. Seal with class D finish.
See Class D .
Scheme 27
Visible seal with high requirements for the finish.
The material must have been applied liberally but evenly. There must be no areas where excess sealant has gathered.
Use a rubber putty knife to smooth the surface.
See panel section A for the appearance of the bead.
Scheme 28
Visible seal with lower requirements for the finish.
The material should be liberally but evenly applied.
Lines and minor pitting is acceptable.
The sealant must not have been applied too thickly.
The dimension of the bead must be as in panel section B.
B1 = minimum 0.5 mm, maximum 2.0 mm.
B2 = minimum 4.0 mm, maximum 10.0 mm.
B3 = minimum 2.0 mm.
B4 = minimum 2.0 mm, maximum 4.0 mm.
Scheme 29
Seal with no requirements for the finish.
The sealant must be liberally applied.
Minimum material thickness = 0.5 mm.
Lines, lumps and pools of up to 5 mm are acceptable.
The dimension of the bead must be as in panel section D.
D1 = minimum 0.5 mm, maximum 5.0 mm.
D2 = minimum 7.0 mm, maximum 50 mm.
Scheme 30
1 = free of sealant 35 mm diameter.
Scheme 31
M1 = minimum 20 mm.
1. Free of sealant 45 mm diameter.
Scheme 32
Scheme 33
1. There must not be any sealant on the surface.
Scheme 34
1. Free of sealant.
2. Holes sealed.
3. Free of sealant 35x45 mm.
Scheme 35
1. Free of sealant.
Scheme 36
2. Only as protection against wear.
M5 = minimum 40 mm.
M6 = minimum 110 mm.
M7 = minimum 50 mm.
Scheme 37
M8 = maximum 5 mm.
2. Only as protection against wear.
Scheme 38
1. Free of sealant.
2. Only as protection against wear.
M2 = minimum 21 mm.
Scheme 39
1. Free of sealant 45 mm diameter.
M3 = minimum 40 mm.
M4 = maximum 25 mm.
Scheme 40
M10 = 100 mm.
M11 = 45 mm.
M12 = 75 mm.
M13 = minimum 5 mm.
M14 = maximum 15 mm.
M15 = maximum 10 mm.
Scheme 41
1. Free of sealant 45 mm diameter.
2. Only as protection against wear.
M16 = 130 mm.
Scheme 42
1. Free of sealant 45 mm diameter.
M3 = minimum 40 mm.
M4 = maximum 25 mm.
M11 = 45 mm.
M12 = 75 mm.
M13 = minimum 5 mm.
M14 = maximum 20 mm.
M15 = maximum 10 mm.
Scheme 43
1 Free of sealant 30 mm diameter.
Scheme 44
1. Free of sealant.
M17 = minimum 11 mm.
M18 = minimum 10 mm.
Scheme 45
1. Free of sealant.
Scheme 46
1. Free of sealant 35 mm diameter.
M19 = maximum 10 mm.
M20 = maximum 15 mm.
Scheme 47
1. Free of sealant 35 mm diameter.
M21 = 15 mm +/- 10 mm.
Scheme 48
1. Drainage plug free of sealant.
M22 = maximum 15 mm.
M23 = maximum 2.5 mm.
Scheme 49
1. Drainage plug free of sealant.
2. Free of sealant 35 mm diameter.
Scheme 50
1. There must not be any sealant in the seal hole (1).
The thickness of the seal must not exceed 2.0 mm. (The seal deviates from the factory seal along the D-post).
Scheme 51
Scheme 52
The class of finish deviates from the seal from the factory along the side of the roof.
(original seal).
Scheme 53
Scheme 54
1. Applied up to the weld.
Scheme 55
1. Thickness of the seal on the lower edge of the door = maximum 1 mm.
Scheme 56
1. Thickness of the seal on the lower edge of the door = maximum 1 mm.
