Side Member, Rear, Replace

When replacing the side member, the alignment bench and its units of measurement must be used.

Use a puller tool. See Aligning the rear frame member .

Pull out the bodywork to the correct dimension.

Cut or saw away the damaged sections.

Use an angle grinder or plasma torch to cut the bumper rail.

Scheme 110

Scheme 110: Side Member, Rear, Replace

Remove 50 mm more of the cover for the side member than the side member (Dimension A).

Carry out procedure Wheel housing, rear, replacing (Bifuel) or Wheel housing, rear, replacing (other engines).

Scheme 111

Scheme 111

Spot-weld the reinforcement in the replacement part.

Scheme 112

Scheme 112

Secure the rear side member

Use the measurement system on the alignment bench.

Weld into place.

Grind the welds.

Carry out operation Spare wheel well, replacing .

Scheme 113

Scheme 113

Cut the cover for the rear frame member.

Outer edge M2 dimension = 40 mm.

Scheme 114

Scheme 114

Spot-weld the cover for the rear side member.

See Side member, rear, replace

See Side member, rear, replace

See Side member, rear, replace

See Side member, rear, replace

See Side member, rear, replace

See Side member, rear, replace
