Automatic A/c-Heater System: Overview Volvo V70 II

Automatic HVAC System 1 illustration ~108 words

DESCRIPTION

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in AIR BAG SYSTEM SAFETY article in GENERAL SERVICING.
CAUTIONWhen battery or radio is disconnected, radio will go into anti-theft protection mode. Obtain radio code anti-theft protection code from owner prior to servicing vehicle.

The Electronic Climate Control (ECC) module (A/C-heater control panel) contains a function selector dial or buttons, driver's and passenger's temperature dials, a recirculated air switch, AC ON and OFF switch, and a fan speed (blower motor) control lever. (Scheme 1) The heater (blower motor) fan is controlled by ECC output (power) stage. Air conditioning system will only operate above 32°F (0°C). Blower switch must not be in zero position to allow compressor to engage.

Additional system components include solar sensor, outside temperature sensor, passenger compartment temperature sensor, low-pressure switch, 4 damper motors, pressure sensor, engine coolant temperature sensor and A/C relay.
