Climate Units - Specifications, Electrical/electronic: Other Volvo V70 II

Automatic HVAC System 1 illustration ~118 words

Resistance values, evaporator temperature sensor

The component specification gives the value of the component without the connector connected.

Scheme 74

Scheme 74: Resistance values, evaporator temperature sensor
Measurement values, resistanceOther
40 °C = approximately 91.8 kohms -35 °C = approximately 66.3 kohms -30 °C = approximately 48.4 kohms -25 °C = approximately 35.7 kohms -20 °C = approximately 26.6 kohms -15 °C = approximately 20.0 kohms -10 °C = approximately 15.2 kohms -5 °C = approximately 11.6 kohms 0 °C = approximately 9.0 kohms 5 °C = approximately 7.0 kohms 10 °C = approximately 5.5 kohms 15 °C = approximately 4.3 kohms 20 °C = approximately 3.5 kohms 25 °C = approximately 2.7 kohms 30 °C = approximately 2.2 kohms 35 °C = approximately 1.8 kohms 40 °C = approximately 1.5 kohms 45 °C = approximately 1.2 kohms 50 °C = approximately 1.0 kohms 55 °C = approx. 826 ohms 60 °C = approx. 688 ohms 65 °C = approx. 576 ohms 70 °C = approx. 485 ohms 75 °C = approx. 409 ohms 80 °C = approx. 347 ohms 85 °C = approx. 296 ohms 90 °C = approx. 253 ohms 95 °C = approx. 217 ohms 100 °C = approx. 187 ohmsMeasure the resistance between terminals #1 and #2.

Temperature and resistance table, evaporator temperature sensor

Component resistance values

The resistance values assume a temperature of +20°C unless otherwise stated.

Note. For the damper motors, a diode must be connected in series with each winding. This can have a great effect on the measurement value when resistance testing if measured using a tool other than VIDA. The resistance given will be significantly higher than the value given in the table below.

ComponentOther
Evaporator temperature sensorResistance: -40 °C = approximately 91.8 kohms -30 °C = approximately 48.4 kohms -20 °C = approximately 26.6 kohms -10 °C = approximately 15.2 kohms 0 °C = approximately 9.0 kohms 10 °C = approximately 5.5 kohms 20 °C = approximately 3.4 kohms 30 °C = approximately 2.2 kohms 40 °C = approximately 1.5 kohms 50 °C = approximately 1.0 kohms 60 °C = approximately 0.7 kohms 70 °C = approximately 0.5 kohms 80 °C = approximately 0.3 kohms 90 °C = approximately 0.2 kohms
Blower fan motor power unitResistance: #A4-#A1 = 510 ohms #A3-#B1 = 4.7 kohms
Damper motor normal (temp l/r, def)Resistance in the windings between terminals: #1-#3 = 46 ohms #1-#4 = 46 ohms #1-#5 = 46 ohms #1-#6 = 46 ohms
Damper motor fast (floor / vent, rec, mode)Resistance in the windings between terminals: #1-#3 = 15 ohms #1-#4 = 15 ohms #1-#5 = 15 ohms #1-#6 = 15 ohms
Fan motor passenger compartment temperature sensorResistance in the windings between terminals: #3-#4 = 68 ohms #1-#5 = 450-900 ohms

Component Temperature And Resistance Table, System Components

Components resistance values

Resistance values are given at +20°C (+68°F) unless otherwise stated.

ComponentOther
Water temperature sensorResistance: 10°C (50°F): approximately 20 kohms 20°C (68°F): approximately 11 kohms 30°C (86°F): approximately 8 kohms 75°C (167°F): approximately 1.5 kohms 90°C (194°F): approximately 900 ohms
Heater fanWire resistance between connections: 1-10 ohms
Water pumpWire resistance between connections: 1-10 ohms
Fuel pumpWire resistance between connections: approximately 8 ohms
Glow plugResistance: approximately 1 ohms
Overheat thermostatResistance: Not activated < 3 ohms Activated > 10 kohms
