Engine Control Module (ECM) Diagnostic Trouble Codes - 2 of 3: Other Volvo V40 I рестайлинг

Checking the fuel injection system, ignition system and components

Check that the engine oil level is correct.

Check the ignition system for moisture in the spark plug wells. Check the ignition cables for open-circuits.

Check the spark plugs. Search for damage in the insulation and other damage. If there is any doubt about their function, replace the spark plugs.

Check the ignition coil connectors and the ground cable. Check for contact resistance and oxidation according to Contact resistance and oxidation .

Check the engine compression according to Checking the engine .

Check the injectors according to Checking the injectors .

Check the fuel pressure and residual pressure according to Measuring fuel pressure EMS 2000 .

Check the intake system for air leakage according to intake system/leak test .

1. Continue Refer to «Information»(ref-441346-S16877470642011121500000)

Fault-tracing information

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

Check that the engine oil level is correct.

Check the ignition system for moisture in the spark plug wells. Check the ignition cables for open-circuits.

Check the spark plugs. Search for damage in the insulation and other damage. If there is any doubt about their function, replace the spark plugs.

Check the ignition coil connectors and the ground cable. Check for contact resistance and oxidation according to Contact resistance and oxidation .

Check the engine compression according to Checking the engine .

Check the injectors according to Checking the injectors .

Check the fuel pressure and residual pressure according to Measuring fuel pressure EMS 2000 .

Check the intake system for air leakage according to intake system/leak test .

1. Continue Refer to «Verification»(ref-441346-S30447685492011121500000)

Verification

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 130

If the engine is running unevenly or is jerky, this may indicate misfiring.

1. Reinstall the components, reconnect the connectors etc.
2. Start the engine. Check immediately that there is no misfiring
3. Let the engine idle. Check that there is no misfiring
4. Rev the engine. Check that there is no misfiring as engine speed increases, at constant engine speeds and when returning to idle speed. HINT: It may be difficult to detect misfiring in the workshop. Further checks can be made when carrying out the final checks after the diagnostic trouble codes (DTCs) have been erased.

Is the engine misfiring?

1. YES Refer to «Information»(ref-441346-S03331241362011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Sporadic signal. Intermittent fault

See Sporadic signal. Intermittent fault

See Sporadic signal. Intermittent fault

Start the engine.

Allow the engine to idle for approximately 2 minutes.

Read off the status of the diagnostic trouble code (DTC).

Is the status intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S07297769702011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Sporadic signal. Permanent fault

See Sporadic signal. Permanent fault

See Sporadic signal. Permanent fault

Checking for air leakage in the intake system

Check for air leakage in the intake system according to intake system/leak test .

Remedy as necessary.

Was there any air leakage?

1. YES Refer to «Information»(ref-441346-S28210496272011121500000)
2. NO Refer to «Checking for air leakage in the exhaust system»(ref-441346-S09130977742011121500000)

Checking for air leakage in the exhaust system

Check for air leakage in the exhaust system according to Checking the exhaust system for leakage .

Remedy as necessary.

Was there any leakage?

1. YES Refer to «Information»(ref-441346-S28210496272011121500000)
2. NO Refer to «Checking fuel and residual pressures»(ref-441346-S01978205192011121500000)

Checking fuel and residual pressures

Check the fuel pressure and residual pressure according to Measuring fuel pressure EMS 2000 .

Remedy as necessary.

Was the pressure OK?

1. YES Refer to «Checking the engine»(ref-441346-S20080505572011121500000)
2. NO Refer to «Information»(ref-441346-S28210496272011121500000)

Replacing the component

1. Try a new three-way catalytic converter (TWC). Replace according to «Three-way catalytic converter (TWC), replacing»(ref-441339-S31371542972011121500000) .

1. Continue Refer to «Information»(ref-441346-S28210496272011121500000)

Scheme 131

Scheme 132

1. Ignition off
2. Disconnect system relay 2/14
3. Remove spark plugs. Check the compression at wide open throttle (WOT). In particular, check for uneven compression between the cylinders. NOTE: Compression testing should always be carried out at wide open throttle (WOT) and with the engine at operating temperature. Diagnostic trouble codes (DTCs) ECM-24 and ECM-A3 will be stored because the system relay is disconnected.

Is the compression OK?

1. YES Refer to «Replacing the component»(ref-441346-S32742834552011121500000)
2. NO Refer to «Engine repairs»(ref-441346-S38593327572011121500000)

Engine repairs

Carry out the repair required to the engine.

1. Continue Refer to «Verification»(ref-441346-S07913071142011121500000)

HINT: Check after repair that the fault has been rectified.

Scheme 133

Scheme 134

1. Reinstall system relay 2/14. Start the engine and check that idle speed runs evenly.

Is idle speed even?

1. YES Refer to «Information»(ref-441346-S28210496272011121500000)
2. NO Refer to «Information»(ref-441346-S07449189312011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

Check for air leakage in the intake system according to intake system/leak test .

Remedy as necessary.

Was there any air leakage?

1. YES Refer to «Information»(ref-441346-S25041514092011121500000)
2. NO Refer to «Checking for air leakage in the exhaust system»(ref-441346-S20412373422011121500000)

Check for air leakage in the exhaust system according to Checking the exhaust system for leakage .

Remedy as necessary.

Was there any leakage?

1. YES Refer to «Information»(ref-441346-S25041514092011121500000)
2. NO Refer to «Checking fuel and residual pressures»(ref-441346-S35489229492011121500000)

Check the fuel pressure and residual pressure according to Measuring fuel pressure EMS 2000 .

Remedy as necessary.

Was the pressure OK?

1. YES Refer to «Checking the engine»(ref-441346-S39116326782011121500000)
2. NO Refer to «Information»(ref-441346-S25041514092011121500000)

1. Try a new three-way catalytic converter (TWC). Replace according to «Three-way catalytic converter (TWC), replacing»(ref-441339-S31371542972011121500000) .

1. Continue Refer to «Information»(ref-441346-S25041514092011121500000)

Checking the engine

1. Ignition off
2. Disconnect system relay 2/14
3. Remove spark plugs. Check the compression at wide open throttle (WOT). In particular, check for uneven compression between the cylinders. NOTE: Compression testing should always be carried out at wide open throttle (WOT) and with the engine at operating temperature. Diagnostic trouble codes (DTCs) ECM-24 and ECM-A3 will be stored because the system relay is disconnected.

Is the compression OK?

1. YES Refer to «Replacing the component»(ref-441346-S20204391502011121500000)
2. NO Refer to «Engine repairs»(ref-441346-S31347165612011121500000)

Carry out the repair required to the engine.

1. Continue Refer to «Verification»(ref-441346-S31908613932011121500000)

HINT: Check after repair that the fault has been rectified.

1. Reinstall system relay 2/14. Start the engine and check that idle speed runs evenly.

Is idle speed even?

1. YES Refer to «Information»(ref-441346-S25041514092011121500000)
2. NO Refer to «Information»(ref-441346-S19116560982011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See Faulty signal. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal missing. Intermittent fault

See Signal missing. Intermittent fault

Checking the power supply

1. Ignition off. Connect a voltmeter between the canister purge (CP) valve connector terminal #1 (control module side) and ground.

The voltmeter must display battery voltage for 2 seconds immediately after the ignition is switched on.

1. OK Refer to «Checking the signal cable»(ref-441346-S39731921972011121500000)
2. NOT OK Refer to «Checking the power cable»(ref-441346-S33242362342011121500000)

Checking the signal cable

Check the cable between canister purge (CP) valve terminal #1 and engine control module (ECM) connector terminal #4. Check for an open-circuit according to Open-circuit, permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S22778250382011121500000)

Defective canister purge (CP) valve

Try a new canister purge (CP) valve according to Replacing the canister purge (CP) valve .

1. Continue Refer to «Verification»(ref-441346-S22778250382011121500000)

Checking the power cable

Check the cable between canister purge (CP) valve terminal #2 and system relay base 2/14 terminal #5. Check for an open-circuit according to Open-circuit, permanent faults .

Remedy as necessary.

Scheme 135

1. Continue Refer to «Verification»(ref-441346-S22778250382011121500000)

1. Reconnect the connectors, reinstall components etc. Activate the canister purge (CP) valve according to «Description of activations»(ref-441338-S37270559222011121500000) .

Does the canister purge (CP) valve click?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S35261825582011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal too high. Intermittent fault

See Signal too high. Intermittent fault

Check canister purge (CP) valve

1. Ignition off
2. Disconnect the front canister purge (CP) valve connector. Connect an ohmmeter between canister purge (CP) valve terminals #1 and #2 (valve side).

The ohmmeter should read approximately 21 ohms at +20 °C.

1. OK Refer to «Checking the signal cable»(ref-441346-S38492800632011121500000)
2. NOT OK Refer to «Defective canister purge (CP) valve»(ref-441346-S25970605802011121500000)

1. Ignition on. Check the cable between canister purge (CP) valve connector terminal #1 (control module side) and engine control module (ECM) connector terminal #4. Check for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) . Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S39337411592011121500000)

Try a new valve according to Replacing the canister purge (CP) valve .

1. Continue Refer to «Verification»(ref-441346-S39337411592011121500000)

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Connect VCT2000
4. Ignition on. Activate the canister purge (CP) valve according to «Description of activations»(ref-441338-S37270559222011121500000) .

Does the canister purge (CP) valve click?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S05453405772011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal too high. Permanent fault

See Signal too high. Permanent fault

Signal too low. Intermittent fault

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

Signal too low. Permanent fault

See Signal too low. Permanent fault

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

1. After carrying out the repair check that the fault has been remedied.
2. Restore components and connectors.
3. Start the engine. Allow the engine to idle. Activate reading out of the engine temperature by clicking on the symbol for VCT2000. Check that the engine temperature is above 50 °C.

Continue when the temperature is above 50 °C.

1. Continue Refer to «Verifying, continued»(ref-441346-S31706053642011121500000)

Verifying, continued

1. Rev the engine to 4,000 RPM a couple of times.
2. Check if the trouble code's status has changed to intermittent. If the trouble code's status has changed to intermittent, the problem is solved.

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S39634392772011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

1. After carrying out the repair check that the fault has been remedied.
2. Restore components and connectors.
3. Start the engine. Allow the engine to idle. Activate reading out of the engine temperature by clicking on the symbol for VCT2000. Check that the engine temperature is above 50 °C.

Continue when the temperature is above 50 °C.

1. Continue Refer to «Verifying, continued»(ref-441346-S09133744392011121500000)

1. Rev the engine to 4,000 RPM a couple of times.
2. Check if the trouble code's status has changed to intermittent. If the trouble code's status has changed to intermittent, the problem is solved.

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S18138480712011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. After carrying out the repair check that the fault has been remedied.
2. Restore components and connectors.
3. Start the engine. Allow the engine to idle. Activate reading out of the engine temperature by clicking on the symbol for VCT2000. Check that the engine temperature is above 50 °C.

Continue when the temperature is above 50 °C.

1. Continue Refer to «Verifying, continued»(ref-441346-S16160112012011121500000)

1. Rev the engine to 4,000 RPM a couple of times.
2. Check if the trouble code's status has changed to intermittent. If the trouble code's status has changed to intermittent, the problem is solved.

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S05545986132011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

1. After carrying out the repair check that the fault has been remedied.
2. Restore components and connectors.
3. Start the engine. Allow the engine to idle. Activate reading out of the engine temperature by clicking on the symbol for VCT2000. Check that the engine temperature is above 50 °C.

Continue when the temperature is above 50 °C.

1. Continue Refer to «Verifying, continued»(ref-441346-S18328381292011121500000)

1. Rev the engine to 4,000 RPM a couple of times.
2. Check if the trouble code's status has changed to intermittent. If the trouble code's status has changed to intermittent, the problem is solved.

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S31383233782011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. After carrying out the repair check that the fault has been remedied.
2. Restore components and connectors.
3. Start the engine. Allow the engine to idle. Activate reading out of the engine temperature by clicking on the symbol for VCT2000. Check that the engine temperature is above 50 °C.

Continue when the temperature is above 50 °C.

1. Continue Refer to «Verifying, continued»(ref-441346-S21918228022011121500000)

1. Rev the engine to 4,000 RPM a couple of times.
2. Check if the trouble code's status has changed to intermittent. If the trouble code's status has changed to intermittent, the problem is solved.

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S03577715912011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

Check

1. Ignition off. Check the connectors on the camshaft reset valve, control module and camshaft position (CMP) sensor. Check for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S00267239222011121500000) . Check the engine oil quality, check for contaminants in particular. Replace the engine oil if necessary. Check engine oil pressure for unstable oil pressure. Remove the camshaft reset valve. Check the oil ducts for the camshaft reset valve and camshaft pulley in the cylinder head for blockages. Remedy as necessary. Other information: To check the oil pressure, see «Oil pressure: Inspecting and replacing the oil pressure sensor»(ref-441348-S30938733402011121500000) To access the control module, see «Engine control module (ECM), replacing»(ref-441335-S25586099582011121500000) To access or replace the camshaft reset valve, see «Replacing the variable valve timing (VVT) control valve»(ref-441341-S33641210962011121500000) .

1. Continue Refer to «Information»(ref-441346-S01064436332011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

Checking the oil pressure

1. Check the engine oil quality. Check for contaminants particularly
2. Replace the engine oil if necessary
3. Check whether the engine oil pressure is unstable. See «Oil pressure: Inspecting and replacing the oil pressure sensor»(ref-441348-S30938733402011121500000)
4. Remedy as necessary.

Was the engine oil pressure incorrect?

1. YES Refer to «Verification»(ref-441346-S17123546852011121500000)
2. NO Refer to «Checking oil ducts»(ref-441346-S08562366352011121500000)

Checking oil ducts

1. Remove the camshaft reset valve
2. Check the oil ducts for the camshaft reset valve and camshaft pulley in the cylinder head for blockages. NOTE: If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced.
3. Remedy as necessary
4. Try a new camshaft reset valve, if no fault is found in the oil ducts.

Other information

1. To remove or replace the camshaft reset valve, see «Replacing the camshaft seals»(ref-441341-S17309697062011121500000) .

1. Continue Refer to «Verification»(ref-441346-S17123546852011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Check the engine oil quality. Check for contaminants particularly
2. Replace the engine oil if necessary
3. Check whether the engine oil pressure is unstable. See «Oil pressure: Inspecting and replacing the oil pressure sensor»(ref-441348-S30938733402011121500000)
4. Remedy as necessary.

Was the engine oil pressure incorrect?

1. YES Refer to «Verification»(ref-441346-S20793910502011121500000)
2. NO Refer to «Checking oil ducts»(ref-441346-S07247413002011121500000)

1. Remove the camshaft reset valve
2. Check the oil ducts for the camshaft reset valve and camshaft pulley in the cylinder head for blockages. NOTE: If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced.
3. Remedy as necessary
4. Try a new camshaft reset valve, if no fault is found in the oil ducts.

Other information

1. To remove or replace the camshaft reset valve, see «Replacing the variable valve timing (VVT) control valve»(ref-441341-S33641210962011121500000) .

1. Continue Refer to «Verification»(ref-441346-S20793910502011121500000)

1. Let the control module carry out a diagnostic of the CVVT system to verify the diagnostic trouble code (DTC). The control module will only carry out a diagnostic for the diagnostic trouble code (DTC) if the engine coolant temperature (ECT) was between +10 °C and +50 °C the last time the ignition was switched on. The diagnostic continues until the engine coolant temperature (ECT) is +84 °C
2. Switch off the ignition. Start the engine. Run the engine at idle speed
3. Read off the current engine coolant temperature (ECT), the engine coolant temperature (ECT) the last time the ignition was switched on. Check that the engine coolant temperature (ECT) was between +10 °C and +50 °C the last time the ignition was switched on. NOTE: The diagnostic trouble code (DTC) cannot be verified if the engine coolant temperature (ECT) was not between +10 °C and +50 °C the last time the ignition was switched on.
4. Let the engine run at idle speed until the engine coolant temperature (ECT) is +84 °C.

Continue when the engine coolant temperature (ECT) is +84 °C

1. Continue Refer to «Verification, continued»(ref-441346-S11958617002011121500000)

Verification, continued

1. Let the engine idle. Read off diagnostic trouble codes (DTCs). Check that the status of the diagnostic trouble code (DTC) has changed to intermittent. The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S40098747552011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Permanent fault

1. Ignition off. Check the connectors on the camshaft reset valve, control module and camshaft position (CMP) sensor. Check for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S00267239222011121500000) . Check the engine oil quality, check for contaminants in particular. Replace the engine oil if necessary. Check the engine oil pressure for low oil pressure. Remove the camshaft reset valve. Check the oil ducts for the camshaft reset valve and camshaft pulley in the cylinder head for blockages. Remedy as necessary. Other information: To check the oil pressure, see «Oil pressure: Inspecting and replacing the oil pressure sensor»(ref-441348-S30938733402011121500000) To access the control module, see «Engine control module (ECM), replacing»(ref-441335-S25586099582011121500000) To access or replace the camshaft reset valve, see «Replacing the variable valve timing (VVT) control valve»(ref-441341-S33641210962011121500000) .

1. Continue Refer to «Information»(ref-441346-S10618729382011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

1. Check the engine oil quality. Check for contaminants particularly
2. Replace the engine oil if necessary
3. Check that the engine oil pressure is not low. See «Oil pressure: Inspecting and replacing the oil pressure sensor»(ref-441348-S30938733402011121500000)
4. Remedy as necessary.

Was the engine oil pressure incorrect?

1. YES Refer to «Verification»(ref-441346-S35200366732011121500000)
2. NO Refer to «Checking oil ducts»(ref-441346-S08685190962011121500000)

1. Remove the camshaft reset valve
2. Check the oil ducts for the camshaft reset valve and camshaft pulley in the cylinder head for blockages. NOTE: If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced.
3. Remedy as necessary
4. Try a new camshaft reset valve, if no fault is found in the oil ducts.

Other information

1. To remove or replace the camshaft reset valve, see «Replacing the camshaft seals»(ref-441341-S17309697062011121500000) .

1. Continue Refer to «Verification»(ref-441346-S35200366732011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Check the engine oil quality. Check for contaminants particularly
2. Replace the engine oil if necessary
3. Check that the engine oil pressure is not low. See «Oil pressure: Inspecting and replacing the oil pressure sensor»(ref-441348-S30938733402011121500000)
4. Remedy as necessary.

Was the engine oil pressure incorrect?

1. YES Refer to «Verification»(ref-441346-S16119795312011121500000)
2. NO Refer to «Checking oil ducts»(ref-441346-S05347821332011121500000)

1. Remove the camshaft reset valve
2. Check the oil ducts for the camshaft reset valve and camshaft pulley in the cylinder head for blockages. NOTE: If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced.
3. Remedy as necessary
4. Try a new camshaft reset valve, if no fault is found in the oil ducts.

Other information

1. To remove or replace the camshaft reset valve, see «Replacing the variable valve timing (VVT) control valve»(ref-441341-S33641210962011121500000) .

1. Continue Refer to «Verification»(ref-441346-S16119795312011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Permanent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

Checking camshaft setting

1. Ignition off
2. Check the camshaft position (CMP) sensor and the control module connectors. Check for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000)
3. Check the setting of the camshafts. See «Camshaft seals, replacing»(ref-441341-S14468238192011121500000)
4. Remedy as necessary. Other information: To access the control module, see «Engine control module (ECM), replacing»(ref-441335-S25586099582011121500000) To access the camshaft position (CMP) sensor connector, see «Replacing camshaft position (CMP) sensor»(ref-441335-S38740013462011121500000) .

1. Continue Refer to «Verification»(ref-441346-S23502616882011121500000)

1. Let the control module carry out a diagnostic of the CVVT system to verify the diagnostic trouble code (DTC). The control module will only carry out a diagnostic for the diagnostic trouble code (DTC) if the engine coolant temperature (ECT) was +50 °C or higher the last time the ignition was switched on
2. Start the engine and let it run at idle speed
3. Read off the engine coolant temperature (ECT). Let the engine idle until the engine coolant temperature (ECT) is at least +50 °C.

Continue when the engine coolant temperature (ECT) is at least +50 °C

1. Continue Refer to «Verification, continued»(ref-441346-S00536545182011121500000)

1. Ignition off
2. Start the engine. Let it idle for approximately 1 minute in order to update the control module reference value for the camshaft position. Read off diagnostic trouble codes (DTCs). Check that the status of the diagnostic trouble code (DTC) has changed to intermittent. The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S33114027082011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Checking the connectors

1. Ignition off
2. Check the leak diagnostic pump, system relay and control module connectors. Check for contact resistance and oxidation. See «Contact resistance and oxidation»(ref-441291-S41448420802011121500000)
3. Check if the hose between the lower terminal on the leak diagnostic pump and the filter in the wheel arch are blocked
4. Remedy as necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) To replace the filter for the leak diagnostic pump, see «Replacing the leak diagnostic filter»(ref-441337-S40704451852011121500000) .

1. Continue Refer to «Activating the leak diagnostic»(ref-441346-S37833291262011121500000)

1. Ignition off
2. Replace the leak diagnostic pump. See «Replacing the leak diagnostic pump»(ref-441337-S19530588282011121500000) .

1. Continue Refer to «Verification»(ref-441346-S32969721322011121500000)

1. The control module has detected a fault other than the one that affects the relevant diagnostic trouble code (DTC). This may be because a fault occurred during the fault-tracing. Check that the hoses, connectors and components etc. have been correctly reinstalled. Check that they are not damaged.

HINT: After carrying out the repair, check that the fault has been remedied.

Note. This test cannot be performed if there are diagnostic trouble codes (DTCs) stored in EMS2000.

1. Reinstall the components, reconnect the connectors etc.
2. Ignition on
3. Check that no other diagnostic trouble codes (DTCs) are stored. If other diagnostic trouble codes (DTCs) are stored, these must be remedied and erased first.

Are any other diagnostic trouble codes (DTCs) stored?

1. YES Refer to «Fault-tracing information»(ref-441346-S35815603342011121500000)
2. NO Refer to «Activating the leak diagnostic»(ref-441346-S18004478832011121500000)

1. The control module has detected a fault other than the one that affects the relevant diagnostic trouble code (DTC). This may be because a fault occurred during the fault-tracing. Check that the hoses, connectors and components etc. have been correctly reinstalled. Check that they are not damaged.

1. This diagnostic trouble code (DTC) cannot be verified before other DTCs have been remedied and erased
2. Fault-trace, remedy and erase other diagnostic trouble codes (DTCs) first. Then select this diagnostic trouble code (DTC) to perform verification.

1. Continue Refer to «Information»(ref-441346-S36651068152011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Scheme 136

1. Ignition off. Check the leak diagnostic pump, system relay and control module connectors. Check for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Check that the air flow through the hoses from the upper terminal on the leak diagnostic pump to the intake manifold terminal (1) is unimpeded. Check that there is no leakage between the terminals. NOTE: Air can only flow from the leak diagnostic pump to the intake manifold. Check the function of the non-return valve (2). See the arrow on the non-return valve. Remedy as necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) To replace the leak diagnostic pump, see «Replacing the leak diagnostic pump»(ref-441337-S19530588282011121500000) .

1. Continue Refer to «Information»(ref-441346-S28819770432011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Checking the connectors and components

1. Ignition off. Check the leak diagnostic pump, system relay and control module connectors. Check for contact resistance and oxidation. See «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

1. Continue Refer to «Activating the leak diagnostic»(ref-441346-S30316053982011121500000)

Checking components

1. Ignition off
2. Check that the air flow through the hoses from the upper rear connection on the leak diagnostic pump to the intake manifold connection (1) is unimpeded. Check that there is no leakage between the connections NOTE: Air can only flow from the leak diagnostic pump to the intake manifold.
3. Check the function of the non-return valve (4). See the arrow on the non-return valve
4. Remedy as necessary.

Was a fault detected?

1. YES Refer to «Verification»(ref-441346-S03929521572011121500000)
2. NO Refer to «Replacing the component»(ref-441346-S39172404492011121500000)

1. Replace the leak diagnostic pump. See «Replacing the leak diagnostic pump»(ref-441337-S19530588282011121500000) .

1. Continue Refer to «Verification»(ref-441346-S03929521572011121500000)

1. The control module has detected a fault other than the one that affects the relevant diagnostic trouble code (DTC). This may be because a fault occurred during the fault-tracing. Check that the hoses, connectors and components etc. have been correctly reinstalled. Check that they are not damaged.

HINT: After carrying out the repair, check that the fault has been remedied.

Note. This test cannot be performed if there are diagnostic trouble codes (DTCs) stored in EMS2000.

1. Reinstall the components, reconnect the connectors etc.
2. Ignition on
3. Check that no other diagnostic trouble codes (DTCs) are stored. If other diagnostic trouble codes (DTCs) are stored, these must be remedied and erased first.

Are any other diagnostic trouble codes (DTCs) stored?

1. YES Refer to «Fault-tracing information»(ref-441346-S06369467432011121500000)
2. NO Refer to «Activating the leak diagnostic»(ref-441346-S29946993792011121500000)

1. The control module has detected a fault other than the one that affects the relevant diagnostic trouble code (DTC). This may be because a fault occurred during the fault-tracing. Check that the hoses, connectors and components etc. have been correctly reinstalled. Check that they are not damaged.

1. This diagnostic trouble code (DTC) cannot be verified before other DTCs have been remedied and erased
2. Fault-trace, remedy and erase other diagnostic trouble codes (DTCs) first. Then select this diagnostic trouble code (DTC) to perform verification.

1. Continue Refer to «Information»(ref-441346-S03103447722011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition off. Check the leak diagnostic pump, system relay and control module connectors. Check for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S00267239222011121500000) . Check the cable between leak diagnostic pump terminal #2 and control module terminal #35. Check for an open-circuit according to «Open-circuit, intermittent faults»(ref-441291-S39448265522011121500000) . Remedy as necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) To replace the leak diagnostic pump, see «Replacing the leak diagnostic pump»(ref-441337-S19530588282011121500000) .

1. Continue Refer to «Information»(ref-441346-S07022081372011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition off. Check the connectors for the leak diagnostic pump, the system relay and control module. Check for contact resistance and oxidation. See «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Check the cable between leak diagnostic pump terminal #2 and control module terminal #35. Check for an open-circuit. See «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Check for a short-circuit to ground. See «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) . Remedy as necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

1. Continue Refer to «Activating the leak diagnostic»(ref-441346-S11544958882011121500000)

1. Ignition off
2. Replace the leak diagnostic pump. See «Replacing the leak diagnostic pump»(ref-441337-S19530588282011121500000) .

1. Continue Refer to «Verification»(ref-441346-S23680276622011121500000)

1. The control module has detected a fault other than the one that affects the relevant diagnostic trouble code (DTC). This may be because a fault occurred during the fault-tracing. Check that the hoses, connectors and components etc. have been correctly reinstalled. Check that they are not damaged.

HINT: After carrying out the repair, check that the fault has been remedied.

Note. This test cannot be performed if there are diagnostic trouble codes (DTCs) stored in EMS2000.

1. Reinstall the components, reconnect the connectors etc.
2. Ignition on
3. Check that no other diagnostic trouble codes (DTCs) are stored. If other diagnostic trouble codes (DTCs) are stored, these must be remedied and erased first.

Are any other diagnostic trouble codes (DTCs) stored?

1. YES Refer to «Fault-tracing information»(ref-441346-S24639025292011121500000)
2. NO Refer to «Activating the leak diagnostic»(ref-441346-S19064677852011121500000)

1. The control module has detected a fault other than the one that affects the relevant diagnostic trouble code (DTC). This may be because a fault occurred during the fault-tracing. Check that the hoses, connectors and components etc. have been correctly reinstalled. Check that they are not damaged.

1. This diagnostic trouble code (DTC) cannot be verified before other DTCs have been remedied and erased
2. Fault-trace, remedy and erase other diagnostic trouble codes (DTCs) first. Then select this diagnostic trouble code (DTC) to perform verification.

1. Continue Refer to «Information»(ref-441346-S12840159902011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Intermittent fault

See Faulty signal. Permanent fault

See Signal too high. Intermittent fault

See Signal too high. Permanent fault

See Signal too low. Intermittent fault

See Signal too low. Permanent fault

See Faulty signal. Intermittent fault

See Faulty signal. Permanent fault

See Signal too high. Intermittent fault

See Signal too high. Permanent fault

See Signal too low. Intermittent fault

See Signal too low. Permanent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

See Signal too high. Permanent fault

See Signal too high. Permanent fault

See Signal too high. Permanent fault

See Signal too low. Permanent fault

See Signal too low. Permanent fault

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

1. Ignition off
2. Check the filter (1) between the leak diagnostic pump and the EVAP canister for blockage
3. Check if the hoses between the leak diagnostic pump and the EVAP canister and between the EVAP canister and the fuel tank are blocked
4. Remedy as necessary. Other information: To expose the EVAP canister, see «Replacing the charcoal filter»(ref-441346-S00430834162011121500000) .

Was a fault detected?

1. NO Refer to «Replacing the component»(ref-441346-S23715672312011121500000)
2. YES Refer to «Verification»(ref-441346-S24562612642011121500000)

1. Replace the leak diagnostic pump according to «Replacing the leak diagnostic pump»(ref-441337-S19530588282011121500000) .

1. Continue Refer to «Verification»(ref-441346-S24562612642011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Note. This test cannot be performed if there are diagnostic trouble codes (DTCs) stored in EMS2000.

1. Reinstall the components, reconnect the connectors etc.
2. Ignition on
3. Check that no other diagnostic trouble codes (DTCs) are stored. If other diagnostic trouble codes (DTCs) are stored, these must be remedied and erased first.

Are any other diagnostic trouble codes (DTCs) stored?

1. YES Refer to «Fault-tracing information»(ref-441346-S32453608652011121500000)
2. NO Refer to «Activating the leak diagnostic»(ref-441346-S41370210622011121500000)

1. The control module has detected a fault other than the one that affects the relevant diagnostic trouble code (DTC). This may be because a fault occurred during the fault-tracing. Check that the hoses, connectors and components etc. have been correctly reinstalled. Check that they are not damaged.

1. This diagnostic trouble code (DTC) cannot be verified before other DTCs have been remedied and erased
2. Fault-trace, remedy and erase other diagnostic trouble codes (DTCs) first. Then select this diagnostic trouble code (DTC) to perform verification.

1. Continue Refer to «Information»(ref-441346-S01707613912011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Replacing the charcoal filter

Special tools

9512619

Preparations

1. Remove the engine splash guard
2. Remove the right fog lamp (if applicable) according to «Replacing fog lamps»(ref-441350-S09402482492011121500000) .

Removing the charcoal filter

Scheme 137

1. Remove the screw from the side member.
2. Remove the two screws from the washer fluid reservoir.
3. Pull the charcoal filter down.
4. Remove the hoses from the charcoal filter.

Installing the charcoal filter

1. Install the two hoses on the coal filter. Use new clamps. Use tool «9512619»(ref-403953-S02470437792011061000000) . NOTE: The hose connector furthest to the right must be connected to the canister purge (CP) valve. The hose must be correctly routed when it is secured.
2. Install the charcoal filter
3. First install the bolt. Then install the screws on the reservoir
4. Install the fog lamp (if applicable) according to «Replacing fog lamps»(ref-441350-S09402482492011121500000) .
5. Install the engine splash guard.

1. Ignition off
2. Check the filter (1) between the leak diagnostic pump and the EVAP canister for blockage
3. Remedy as necessary.

Was a fault detected?

1. YES Refer to «Verification»(ref-441346-S19265582242011121500000)
2. NO Refer to «Replacing the component»(ref-441346-S34657456232011121500000)

1. Ignition off. Try a new leak diagnostic pump according to «Replacing the leak diagnostic pump»(ref-441337-S19530588282011121500000) to check whether the fault is in the leak diagnostic pump.

1. Continue Refer to «Activating the leak diagnostic»(ref-441346-S30940919422011121500000)

Checking hoses

1. The fault may be due to blocked hoses between the leak diagnostic pump and the EVAP canister and the hoses between the EVAP canister and the tank
2. Reinstall the old leak diagnostic pump
3. Check if the hoses between the leak diagnostic pump and the EVAP canister and between the EVAP canister and the fuel tank are blocked. Dismantle the fuel tank if necessary. Other information To remove the fuel tank, see «Fuel tank, replacing»(ref-441337-S06337078412011121500000)

1. Continue Refer to «Verification»(ref-441346-S19265582242011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Note. This test cannot be performed if there are diagnostic trouble codes (DTCs) stored in EMS2000.

1. Reinstall the components, reconnect the connectors etc.
2. Ignition on
3. Check that no other diagnostic trouble codes (DTCs) are stored. If other diagnostic trouble codes (DTCs) are stored, these must be remedied and erased first.

Are any other diagnostic trouble codes (DTCs) stored?

1. YES Refer to «Fault-tracing information»(ref-441346-S07337652432011121500000)
2. NO Refer to «Activating the leak diagnostic»(ref-441346-S38705252072011121500000)

1. The control module has detected a fault other than the one that affects the relevant diagnostic trouble code (DTC). This may be because a fault occurred during the fault-tracing. Check that the hoses, connectors and components etc. have been correctly reinstalled. Check that they are not damaged.

1. This diagnostic trouble code (DTC) cannot be verified before other DTCs have been remedied and erased
2. Fault-trace, remedy and erase other diagnostic trouble codes (DTCs) first. Then select this diagnostic trouble code (DTC) to perform verification.

1. Continue Refer to «Information»(ref-441346-S11960135242011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

By activating the leak diagnostic the status (permanent/intermittent) of the fault can be determined. The fault is intermittent if this diagnostic trouble code (DTC) is detected without any fault being found when the leak diagnostic is run.

If the size of the leak is unknown (qualifier unknown) when reading off diagnostic trouble codes (DTCs) the size of the leak can be determined in the tank system quick test if the fault is permanent.

Scheme 138

1. Continue Refer to «Other diagnostic trouble codes (DTCs)»(ref-441346-S29098818192011121500000)

1. Ignition off. Check that the fuel tank filler cap is properly tightened and that its seal is intact Check the hoses and terminals on the leak diagnostic pump and fuel filler pipe for leakage and damage Remedy as necessary.

1. Continue Refer to «Activating the leak diagnostic»(ref-441346-S00061876522011121500000)

Checking the component

1. Ignition off
2. Expose the canister purge (CP) valve. Remove the hose between the canister purge (CP) valve and the intake manifold Connect a vacuum pump to the canister purge (CP) valve instead Pump up a vacuum. Check that the vacuum does not drop If the vacuum drops, there is a leak through the canister purge (CP) valve Remedy as necessary.

Was a fault detected?

1. YES Refer to «Verification»(ref-441346-S20426141082011121500000)
2. NO Refer to «Checking the fuel tank system»(ref-441346-S13865186282011121500000)

Checking the fuel tank system

1. The fault may be due to leakage in the fuel tank, fuel filler pipe, fuel tank filler cap, EVAP canister, leak diagnostic pump or in the hoses between these components
2. Check the fuel tank system and the evaporative emission (EVAP) system for leaks. See «Pressurizing the fuel tank system, check»(ref-441351-S34058861352011121500000) .

1. Continue Refer to «Activating the leak diagnostic»(ref-441346-S00061545412011121500000)

1. Ignition off. Try a new leak diagnostic pump. See «Replacing the leak diagnostic pump»(ref-441337-S19530588282011121500000) .

1. Continue Refer to «Verification»(ref-441346-S20426141082011121500000)

1. The control module has detected a fault other than the one that affects the relevant diagnostic trouble code (DTC). This may be because a fault occurred during the fault-tracing. Check that the hoses, connectors and components etc. have been correctly reinstalled. Check that they are not damaged.

Intermittent fault

The control module has previously detected a leak in the tank system but the fault is no longer active. The fault may be due to leakage in the fuel tank, fuel filler pipe, fuel tank filler cap, EVAP canister, Canister purge (CP) valve, leak diagnostic pump or in the hoses between these components.

HINT: This DTC can be stored if the car is driven without the fuel tank filler cap or if the fuel tank filler cap is incorrectly tightened.

Other information

1. To check the fuel tank system and the evaporative emission (EVAP) system for leaks, see «Pressurizing the fuel tank system, check»(ref-441351-S34058861352011121500000)
2. To replace the canister purge (CP) valve, see «Replacing the canister purge (CP) valve»(ref-441337-S30590136202011121500000)
3. To replace the leak diagnostic pump, see «Replacing the leak diagnostic pump»(ref-441337-S19530588282011121500000) .

HINT: After carrying out the repair, check that the fault has been remedied.

Note. This test cannot be performed if there are diagnostic trouble codes (DTCs) stored in EMS2000.

1. Reinstall the components, reconnect the connectors etc.
2. Ignition on
3. Check that no other diagnostic trouble codes (DTCs) are stored. If other diagnostic trouble codes (DTCs) are stored, these must be remedied and erased first.

Are any other diagnostic trouble codes (DTCs) stored?

1. YES Refer to «Fault-tracing information»(ref-441346-S09169764232011121500000)
2. NO Refer to «Activating the leak diagnostic»(ref-441346-S27337786522011121500000)

1. The control module has detected a fault other than the one that affects the relevant diagnostic trouble code (DTC). This may be because a fault occurred during the fault-tracing. Check that the hoses, connectors and components etc. have been correctly reinstalled. Check that they are not damaged.

1. This diagnostic trouble code (DTC) cannot be verified before other DTCs have been remedied and erased
2. Fault-trace, remedy and erase other diagnostic trouble codes (DTCs) first. Then select this diagnostic trouble code (DTC) to perform verification.

1. Continue Refer to «Information»(ref-441346-S21004803812011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

See Leakage

Information

There is no fault-tracing for this diagnostic fault code (DTC).

For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

Checking air flow

1. Expose the canister purge (CP) valve
2. Remove the hose from the canister purge (CP) valve to the EVAP canister
3. Ignition on. Activate the canister purge (CP) valve by clicking on the VCT-2000 symbol. Check that the connection with the intake manifold opens and closes when the canister purge (CP) valve opens and closes: Blow into the exposed terminal in the canister purge (CP) valve. NOTE: A certain resistance will be felt because of the non-return valve. If necessary, remedy the hoses / hoses connections for the intake manifold. Replace the non-return valves or canister purge (CP) valve if necessary. To access the canister purge (CP) valve, see «Replacing the canister purge (CP) valve»(ref-441337-S30590136202011121500000) To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) For information about signals, see «Signal specification»(ref-441338-S16642011902011121500000) .

Was a fault detected?

1. YES Refer to «Verification»(ref-441346-S01588236322011121500000)
2. NO Refer to «Checking hoses»(ref-441346-S38454486212011121500000)

1. Ignition off
2. The fault may be due to blocked hoses or components between the canister purge (CP) valve and the fuel tank
3. Expose the EVAP canister and the roll-over valve to check the evaporative emission (EVAP) system. Check the evaporative emission (EVAP) system hoses, terminals and components for blockage according to «Pressurizing the fuel tank system, check»(ref-441351-S34058861352011121500000) . Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S01588236322011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Note. This test cannot be performed if there are diagnostic trouble codes (DTCs) stored in EMS2000.

1. Reinstall the components, reconnect the connectors etc.
2. Ignition on
3. Check that no other diagnostic trouble codes (DTCs) are stored. If other diagnostic trouble codes (DTCs) are stored, these must be remedied and erased first.

Are any other diagnostic trouble codes (DTCs) stored?

1. YES Refer to «Fault-tracing information»(ref-441346-S31258575602011121500000)
2. NO Refer to «Activating the leak diagnostic»(ref-441346-S19065338942011121500000)

1. The control module has detected a fault other than the one that affects the relevant diagnostic trouble code (DTC). This may be because a fault occurred during the fault-tracing. Check that the hoses, connectors and components etc. have been correctly reinstalled. Check that they are not damaged.

1. This diagnostic trouble code (DTC) cannot be verified before other DTCs have been remedied and erased
2. Fault-trace, remedy and erase other diagnostic trouble codes (DTCs) first. Then select this diagnostic trouble code (DTC) to perform verification.

1. Continue Refer to «Information»(ref-441346-S42580536842011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

Checking the terminal

1. Ignition off
2. Disconnect the connector for the air conditioning (A/C) pressure sensor. Check the connector for the air conditioning (A/C) pressure sensor. Check for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy as necessary.

Were any faults found?

1. YES Refer to «Verification»(ref-441346-S13178345502011121500000)
2. NO Refer to «Checking the signal cable»(ref-441346-S06407412102011121500000)

1. Air conditioning (A/C) pressure sensor connector disconnected
2. Ignition on. Connect a voltmeter between connector terminal 2 for the air conditioning (A/C) pressure sensor (control module side) and ground.

The voltmeter should read 0 V.

1. OK Refer to «Checking the ground lead»(ref-441346-S35026787702011121500000)
2. NOT OK Refer to «Checking the signal cable»(ref-441346-S04218175632011121500000)

Checking the ground lead

Connect an ohmmeter between connector terminal 1 for the air conditioning (A/C) pressure sensor and the ground terminal.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Defective air conditioning (A/C) pressure sensor»(ref-441346-S07837074542011121500000)
2. NOT OK Refer to «Checking the ground lead»(ref-441346-S02471856322011121500000)

Defective air conditioning (A/C) pressure sensor

Try a new air conditioning (A/C) pressure sensor according to Replacing the air conditioning (A/C) system pressure sensor .

1. Continue Refer to «Verification»(ref-441346-S13178345502011121500000)

Check the cable between connector terminal 1 for the air conditioning (A/C) pressure sensor (control module side) and engine control module (ECM) terminal #77. Check for an open-circuit according to Open-circuit, permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S13178345502011121500000)

Check the cable between connector terminal 2 for the air conditioning (A/C) pressure sensor (control module side) and engine control module (ECM) terminal #14. Check for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S13178345502011121500000)

1. Reconnect the connectors, reinstall components etc.
2. Ignition on. Read off the parameter for the pressure in the air conditioning (A/C) system.

Is the pressure within its permitted range?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S31618086472011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

1. Ignition off
2. Disconnect the connector for the air conditioning (A/C) pressure sensor. Check the connector for the air conditioning (A/C) pressure sensor for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy as necessary.

Were any faults found?

1. YES Refer to «Verification»(ref-441346-S38503301122011121500000)
2. NO Refer to «Checking the signal cable»(ref-441346-S35911007032011121500000)

1. Air conditioning (A/C) pressure sensor connector disconnected. Connect an ohmmeter between connector terminal 2 for the air conditioning (A/C) pressure sensor (control module side) and the ground terminal.

The ohmmeter should read 300-400 kohms.

1. OK Refer to «Checking the ground lead»(ref-441346-S02704788112011121500000)
2. NOT OK Refer to «Checking the signal cable»(ref-441346-S38919474162011121500000)

Connect an ohmmeter between connector terminal 1 for the air conditioning (A/C) pressure sensor and the ground terminal.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Defective air conditioning (A/C) pressure sensor»(ref-441346-S28852846582011121500000)
2. NOT OK Refer to «Checking the power cable»(ref-441346-S00453103602011121500000)

Try a new air conditioning (A/C) pressure sensor according to Replacing the air conditioning (A/C) system pressure sensor .

1. Continue Refer to «Verification»(ref-441346-S38503301122011121500000)

Check the cable between connector terminal 3 for the air conditioning (A/C) pressure sensor (control module side) and engine control module (ECM) terminal 74 for an open-circuit according to Open-circuit, permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S38503301122011121500000)

Check the cable between connector terminal 2 for the air conditioning (A/C) pressure sensor (control module side) and engine control module (ECM) terminal 14 for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S38503301122011121500000)

1. Reconnect the connectors, reinstall components etc.
2. Connect VCT 2000
3. Ignition on. Read off the A/C PRESS parameter.

Is the pressure within its permitted range?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S24154658332011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition off
2. Disconnect the connector for the air conditioning (A/C) pressure sensor. Check the connector for the air conditioning (A/C) pressure sensor. Check for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy as necessary.

Were any faults found?

1. YES Refer to «Verification»(ref-441346-S04411292122011121500000)
2. NO Refer to «Checking the signal cable»(ref-441346-S02086016142011121500000)

1. Air conditioning (A/C) pressure sensor connector disconnected. Check the cable between connector terminal #2 on the air conditioning (A/C) pressure sensor and control unit terminal #14. Check for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Check for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

Was a fault detected?

1. YES Refer to «Verification»(ref-441346-S04411292122011121500000)
2. NO Refer to «Checking the ground lead»(ref-441346-S04232161342011121500000)

Connect an ohmmeter between connector terminal #1 for the air conditioning (A/C) pressure sensor and the ground terminal.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Defective air conditioning (A/C) pressure sensor»(ref-441346-S10353357252011121500000)
2. NOT OK Refer to «Checking the power cable»(ref-441346-S09101459742011121500000)

Try a new air conditioning (A/C) pressure sensor according to Replacing the air conditioning (A/C) system pressure sensor .

1. Continue Refer to «Verification»(ref-441346-S04411292122011121500000)

Check the cable between connector terminal #3 for the air conditioning (A/C) pressure sensor (control module side) and engine control module (ECM) terminal #74. Check for an open-circuit according to Open-circuit, permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S04411292122011121500000)

Check the cable between connector terminal #2 for the air conditioning (A/C) pressure sensor (control module side) and engine control module (ECM) terminal #14. Check for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S04411292122011121500000)

1. Reconnect the connectors, reinstall components etc.
2. Connect VCT2000
3. Ignition on. Read off the A/C PRESS parameter.

Is the pressure within its permitted range?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S06800441092011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

Checking cables

Check the signal cable between the engine control module (ECM) #52 and ABS control module terminal 25 for an intermittent open-circuit and remedy according to Open-circuit, intermittent faults and for an intermittent short-circuit to ground according to Short-circuit to ground, intermittent faults .

Other information

1. To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

Checking vehicle speed signal

1. Ignition on. Raise the front wheels and check the vehicle speed signal at the engine control module (ECM) terminal #52. Other information To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

The value should oscillate between approximately 0 volts and just on battery voltage when the left front wheel is spun.

1. OK Refer to «Checking terminals»(ref-441346-S42225260742011121500000)
2. NOT OK Refer to «Checking wiring and terminals»(ref-441346-S12290556042011121500000)

Checking terminals

Check the ABS control module and engine control module (ECM) connectors for contact resistance and oxidation according to. Contact resistance and oxidation .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S04286259932011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Raise the car so that the drive wheels are clear of the ground. Ensure that the car is secure.
2. Start the engine and let it idle.
3. Activate reading off the vehicle speed: Click on the VCT 2000 symbol.
4. Shift gear selector to position D so that the drive wheels begin to rotate Depress the accelerator pedal (AP) and check that the speed is updated. NOTE: Ensure that the wheels are not rotating when the gear selector is moved. NOTE: Diagnostic trouble codes (DTCs) may be stored in the ABS system when the rear wheels are stationary and the front wheels rotate.

Was the signal updated?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S27100163512011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the components, reconnect the connectors etc.
2. Start the engine
3. Rev the engine above 4500 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S39107033852011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the components, reconnect the connectors etc.
2. Start the engine
3. Rev the engine above 4500 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S21754902172011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the components, reconnect the connectors etc.
2. Start the engine
3. Rev the engine above 4500 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S00677706132011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

1. Ignition off
2. Check the throttle position (TP) sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Check for damage carefully.

Was a fault detected?

1. YES Refer to «Verification»(ref-441346-S26428362462011121500000)
2. NO Refer to «Checking the cable and components»(ref-441346-S03541121222011121500000)

Checking the cable and components

1. Ignition off. Check the signal cable between throttle position sensor terminal C and control module terminal 43. Check the power supply cable between throttle position sensor terminal B and control module terminal 78. Check these cables for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) . Check the ground lead between throttle position (TP) sensor terminal A and terminal 77 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Check the signal from the throttle position (TP) sensor terminal C to the control module terminal 43. Replace the throttle position (TP) sensor according to «Replacing throttle position (TP) sensor»(ref-441335-S28276217162011121500000) if necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) For information about signals, see «Signal specification»(ref-441338-S16642011902011121500000) .

Select Continue when the fault has been remedied.

1. Continue Refer to «Verification»(ref-441346-S26428362462011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the components, reconnect the connectors etc.
2. Start the engine
3. Rev the engine above 4500 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S39607019802011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition off
2. Check the throttle position (TP) sensor connector. Check for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Check for damage carefully.

Was a fault detected?

1. YES Refer to «Verification»(ref-441346-S41805390202011121500000)
2. NO Refer to «Checking the cable and component»(ref-441346-S06383240402011121500000)

Checking the cable and component

1. Ignition off. Check the signal cable between throttle position sensor #C and control module terminal #43. Check the power supply cable between throttle position sensor terminal #B and control module terminal #78. Check for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) . Check the ground lead between throttle position sensor terminal #A and control module terminal #77. Check for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Replace the throttle position (TP) sensor if no fault is found in the above fault-tracing. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) To replace the throttle position (TP) sensor, see «Replacing throttle position (TP) sensor»(ref-441335-S28276217162011121500000) For information about signals, see «Signal specification»(ref-441338-S16642011902011121500000) .

1. Continue Refer to «Verification»(ref-441346-S41805390202011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the components, reconnect the connectors etc.
2. Start the engine
3. Rev the engine above 4500 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S28427093632011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

1. Ignition off
2. Check the throttle position (TP) sensor connector. Check for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S00267239222011121500000) . Check for loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) . In particular, check for any damage
3. Check the signal cable between throttle position sensor terminal #C and control module terminal #43. Check the power supply cable between throttle position sensor terminal #B and control module terminal #78. Check these cables for an intermittent open-circuit according to «Open-circuit, intermittent faults»(ref-441291-S39448265522011121500000) . Check for an intermittent short-circuit to ground according to «Short-circuit to ground, intermittent faults»(ref-441291-S16169375282011121500000) . HINT: The throttle position (TP) sensor receives 5 V from control module terminal #78. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) To check and replace the throttle position (TP) sensor, see «Replacing throttle position (TP) sensor»(ref-441335-S28276217162011121500000) .

1. Continue Refer to «Information»(ref-441346-S09059969012011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

1. Ignition off
2. Check the throttle position (TP) sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) .

Was a fault detected?

1. YES Refer to «Verification»(ref-441346-S11573561342011121500000)
2. NO Refer to «Checking the cable and components»(ref-441346-S35750478212011121500000)

1. Ignition off. Check the signal cable between throttle position sensor terminal C and control module terminal 43. Check the power supply cable between throttle position sensor terminal B and control module terminal 77. Check these cables for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Check signal cable terminal C on the throttle position (TP) sensor for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) . HINT: The throttle position (TP) sensor receives 5 V from engine control module terminal 78. Check the signal from the throttle position (TP) sensor terminal C to control module terminal 43. Replace the throttle position (TP) sensor according to «Replacing throttle position (TP) sensor»(ref-441335-S28276217162011121500000) if necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) For information about signals, see «Signal specification»(ref-441338-S16642011902011121500000) .

1. Continue Refer to «Verification»(ref-441346-S11573561342011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the components, reconnect the connectors etc.
2. Start the engine
3. Rev the engine above 4500 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S17025460072011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition off
2. Check the throttle position (TP) sensor connector. Check for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) .

Was a fault detected?

1. YES Refer to «Verification»(ref-441346-S12836843372011121500000)
2. NO Refer to «Checking the cable and component»(ref-441346-S11369444652011121500000)

1. Ignition off. Check the signal cable between throttle position sensor #C and control module terminal #43. Check the power supply cable between throttle position sensor terminal #B and control module terminal #77. Check for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Check the throttle position (TP) sensor signal cable #C. Check for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) . HINT: The throttle position (TP) sensor receives 5 V from control module terminal #78. Replace the throttle position (TP) sensor if no fault is found in the above fault-tracing. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) To replace the throttle position (TP) sensor, see «Replacing throttle position (TP) sensor»(ref-441335-S28276217162011121500000) For information about signals, see «Signal specification»(ref-441338-S16642011902011121500000) .

1. Continue Refer to «Verification»(ref-441346-S12836843372011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the components, reconnect the connectors etc.
2. Start the engine
3. Rev the engine above 4500 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S13159247612011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

Checking signal

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the components, reconnect the connectors etc.
2. Start the engine. Rev the engine above 4500 RPM twice Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Replacing the component»(ref-441346-S23683496442011121500000)

1. Try a new throttle position (TP) sensor according to «Replacing throttle position (TP) sensor»(ref-441335-S28276217162011121500000) .

1. Continue Refer to «Verification»(ref-441346-S39893784492011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the components, reconnect the connectors etc.
2. Start the engine
3. Rev the engine above 4500 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S10769524292011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

No fault-tracing has been developed for this diagnostic trouble code (DTC). A diagnostic trouble code (DTC) for this fault is stored in the transmission control module (TCM) first and then in the engine control module (ECM). This diagnostic trouble code (DTC) can not be erased before the diagnostic trouble code (DTC) in the transmission control module (TCM) has been erased and remedied.

First read off the diagnostic trouble codes (DTCs) in the transmission control module (TCM). Fault-trace and remedy as required. This diagnostic trouble code (DTC) can then be erased. For further information about this diagnostic trouble code (DTC), select Information, then DTC information.

See Fault-tracing information

See Fault-tracing information

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

Check the engine speed (RPM) sensor and engine control module (ECM) connectors for contact resistance and oxidation according to Contact resistance and oxidation . Remedy if necessary.

Check in particular for damage or loose terminal pins.

Reconnect the connectors.

Start the engine. Allow the engine to run at idle speed for 30 seconds.

Ignition off for 30 seconds.

Note. If the engine cooling fan (FC) is running, the ignition must be off for 30 seconds after the engine cooling fan (FC) has stopped.

Start the engine. Allow the engine to run at idle speed for 30 seconds.

Read off the status of the diagnostic trouble code (DTC).

Is the status intermittent?

1. YES Refer to «Verification»(ref-441346-S28232689812011121500000)
2. NO Refer to «Checking the wiring and components»(ref-441346-S29046781952011121500000)

Defective engine speed (RPM) sensor

Try a new engine speed (RPM) sensor according to Replacing engine speed (RPM) sensor .

1. Continue Refer to «Verification»(ref-441346-S28232689812011121500000)

Start the engine. Allow the engine to run at idle speed for 30 seconds.

Ignition off for 30 seconds.

Note. If the engine cooling fan (FC) is running, the ignition must be off for 30 seconds after the engine cooling fan (FC) has stopped.

Start the engine. Allow the engine to run at idle speed for 30 seconds.

Read off the status of the diagnostic trouble code (DTC).

Is the status intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S32573519832011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the engine speed (RPM) sensor and engine control module (ECM) connectors for contact resistance and oxidation according to Contact resistance and oxidation . Remedy if necessary.

Check in particular for damage or loose terminal pins.

Reconnect the connectors.

Start the engine. Allow the engine to run at idle speed for 30 seconds.

Ignition off for 30 seconds.

Note. If the engine cooling fan (FC) is running, the ignition must be off for 30 seconds after the engine cooling fan (FC) has stopped.

Start the engine. Allow the engine to run at idle speed for 30 seconds.

Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Is the status intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking the wiring and components»(ref-441346-S40636520882011121500000)

1. Start the engine. Allow the engine to run at idle speed for 30 seconds Ignition off for 30 seconds NOTE: If the engine cooling fan (FC) is running, the ignition must be off for 30 seconds after the engine cooling fan (FC) has stopped. Start the engine. Allow the engine to run at idle speed for 30 seconds. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Is the status intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S06186407752011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

Check the engine speed (RPM) sensor and engine control module (ECM) connectors for contact resistance and oxidation according to Contact resistance and oxidation . Remedy if necessary.

Check in particular for damage or loose terminal pins.

Reconnect the connectors.

Start the engine. Allow the engine to run at idle speed for 30 seconds.

Ignition off for 30 seconds.

Note. If the engine cooling fan (FC) is running, the ignition must be off for 30 seconds after the engine cooling fan (FC) has stopped.

Start the engine. Allow the engine to run at idle speed for 30 seconds.

Read off the status of the diagnostic trouble code (DTC).

Is the status intermittent?

1. YES Refer to «Verification»(ref-441346-S18246935282011121500000)
2. NO Refer to «Checking the wiring and components»(ref-441346-S23013169642011121500000)

Try a new engine speed (RPM) sensor according to Replacing engine speed (RPM) sensor .

1. Continue Refer to «Verification»(ref-441346-S18246935282011121500000)

1. Start the engine. Allow the engine to run at idle speed for 30 seconds Ignition off for 30 seconds. NOTE: If the engine cooling fan (FC) is running, the ignition must be off for 30 seconds after the engine cooling fan (FC) has stopped. Start the engine. Allow the engine to run at idle speed for 30 seconds. Read off the status of the diagnostic trouble code (DTC).

Is the status intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S38377001482011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

1. Ignition on. Check the cable between the engine cooling fan (FC) relay base terminal 2 and the engine control module (ECM) connector terminal 68 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) . Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S06907896332011121500000)

Defective air conditioning (A/C) relay

Try a new air conditioning (A/C) relay.

1. Continue Refer to «Verification»(ref-441346-S06907896332011121500000)

1. Reconnect the connectors, reinstall components etc.
2. Connect VCT 2000
3. Ignition on. Activate the air conditioning (A/C) relay by clicking the VCT 2000 symbol.

Does the air conditioning (A/C) relay click?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S05507034972011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the air conditioning (A/C) relay

1. Ignition off
2. Remove air conditioning (A/C) relay 2/10. Connect an ohmmeter between the air conditioning (A/C) relay terminals #1 and #2 (relay side).

The ohmmeter must read approximately 105 ohms at +20 °C

1. OK Refer to «Checking the signal cable»(ref-441346-S33759421712011121500000)
2. NOT OK Refer to «Defective air conditioning (A/C) relay»(ref-441346-S07250662752011121500000)

1. Ignition on. Check the cable between engine cooling fan (FC) relay base terminal #2 and engine control module (ECM) connector terminal #68. Check for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) . Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S40811180742011121500000)

Try a new air conditioning (A/C) relay.

1. Continue Refer to «Verification»(ref-441346-S40811180742011121500000)

1. Reconnect the connectors, reinstall components etc.
2. Connect VCT2000
3. Ignition on. Click the VCT2000 symbol to activate the A/C relay.

Does the air conditioning (A/C) relay click?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S37278117382011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

1. Ignition off
2. Disconnect air conditioning (A/C) relay 2/10
3. Ignition on. Connect a voltmeter between air conditioning (A/C) relay base terminal #1 and ground.

The voltmeter should read battery voltage.

1. OK Refer to «Checking the signal cable»(ref-441346-S14355866742011121500000)
2. NOT OK Refer to «Checking the signal cable»(ref-441346-S36337855322011121500000)

1. Ignition off. Connect an ohmmeter between air conditioning (A/C) relay base terminal #2 and ground.

The ohmmeter should read infinite resistance.

1. OK Refer to «Checking air conditioning (A/C) relay»(ref-441346-S33983001432011121500000)
2. NOT OK Refer to «Checking the signal cable»(ref-441346-S12582837592011121500000)

Checking air conditioning (A/C) relay

Connect an ohmmeter between the air conditioning (A/C) relay terminals #1 and #2 (relay side).

The ohmmeter should read approximately 105 ohms at +20 °C.

1. OK Refer to «Checking the signal cable»(ref-441346-S22402405082011121500000)
2. NOT OK Refer to «Defective air conditioning (A/C) relay»(ref-441346-S09269202152011121500000)

1. Ignition off. Check the cable between air conditioning (A/C) system relay base terminal #2 and the engine control module (ECM) connector terminal #68 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S36667662472011121500000)

Try a new air conditioning (A/C) relay.

Scheme 139

1. Continue Refer to «Verification»(ref-441346-S36667662472011121500000)

Check the cable between air conditioning (A/C) system relay base terminal #2 and the engine control module (ECM) connector terminal #68 for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S36667662472011121500000)

Check the cable between air conditioning (A/C) system relay base terminal #2 and the engine control module (ECM) connector terminal #68 for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S36667662472011121500000)

1. Reconnect the connectors, reinstall components etc.
2. Connect VCT 2000
3. Ignition on. Activate the air conditioning (A/C) using the VCT 2000 according to «Description of activations»(ref-441338-S37270559222011121500000) .

Does the air conditioning (A/C) relay click?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S04865873092011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the fuse

1. Ignition off. Check the fuse for the circuit in the integrated relay / fusebox in the engine compartment. Replace if necessary. Other information To access or replace the relay or fuse, see the inside of the cover on the engine compartment relay/fusebox .

Was a fault detected?

1. YES Refer to «Verification»(ref-441346-S21237937332011121500000)
2. NO Refer to «Checking the power supply»(ref-441346-S16110945632011121500000)

1. Ignition off
2. Disconnect air conditioning (A/C) relay 2/10
3. Ignition on. Connect a voltmeter between air conditioning (A/C) relay base terminal #1 and ground.

The voltmeter should read battery voltage.

1. OK Refer to «Checking the signal cable»(ref-441346-S38516028502011121500000)
2. NOT OK Refer to «Checking the signal cable»(ref-441346-S21245940902011121500000)

1. Ignition off. Connect an ohmmeter between air conditioning (A/C) relay base terminal #2 and ground.

The ohmmeter should read infinite resistance.

1. OK Refer to «Checking the air conditioning (A/C) relay»(ref-441346-S21301605682011121500000)
2. NOT OK Refer to «Checking the signal cable»(ref-441346-S40795972422011121500000)

Connect an ohmmeter between the air conditioning (A/C) relay terminals #1 and #2 (relay side).

The ohmmeter should read approximately 105 ohms at +20 °C.

1. OK Refer to «Checking the signal cable»(ref-441346-S40180693672011121500000)
2. NOT OK Refer to «Defective air conditioning (A/C) relay»(ref-441346-S03641926162011121500000)

1. Ignition off. Check the cable between air conditioning (A/C) system relay base terminal #2 and engine control module (ECM) connector terminal #68. Check for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S21237937332011121500000)

Try a new air conditioning (A/C) relay.

1. Continue Refer to «Verification»(ref-441346-S21237937332011121500000)

Check the cable between air conditioning (A/C) system relay base terminal #2 and engine control module (ECM) connector terminal #68. Check for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S21237937332011121500000)

Check the cable between air conditioning (A/C) system relay base terminal #2 and engine control module (ECM) connector terminal #68. Check for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S21237937332011121500000)

1. Reconnect the connectors, reinstall components etc.
2. Connect VCT2000
3. Ignition on. Activate the air conditioning (A/C) relay using VCT2000 according to «Description of activations»(ref-441338-S37270559222011121500000) .

Does the air conditioning (A/C) relay click?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S03327694632011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Intermittent fault, signal missing

See Intermittent fault, signal missing

See Intermittent fault, signal missing

1. Ignition off
2. Disconnect the combined instrument panel connector
3. Ignition on. Connect a voltmeter between the combined instrument panel connector terminal B23 (engine control module (ECM) side) and ground.

The voltmeter should read 5 V.

1. OK Refer to «Checking the malfunction indicator lamp (MIL)»(ref-441346-S21582947382011121500000)
2. NOT OK Refer to «Checking wiring and terminals»(ref-441346-S04477803602011121500000)

Scheme 140

1. Ignition on. Connect a voltmeter between the combined instrument panel terminal B23 and ground.

The voltmeter should read battery voltage.

1. OK Refer to «Loose connections»(ref-441346-S35680706912011121500000)
2. NOT OK Refer to «Defective malfunction indicator lamp (MIL)»(ref-441346-S38200613472011121500000)

Loose connections

The cause of the diagnostic trouble code (DTC) has been loose connections in the combined instrument panel and/or control module connectors.

1. Continue Refer to «Verification»(ref-441346-S10472382952011121500000)

Defective malfunction indicator lamp (MIL)

Replace the malfunction indicator lamp (MIL) according to Replacing bulbs in the combined instrument panel .

1. Continue Refer to «Verification»(ref-441346-S10472382952011121500000)

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Connect VCT 2000
4. Ignition on. Activate the malfunction indicator lamp (MIL) according to «Description of activations»(ref-441338-S37270559222011121500000) .

Does the malfunction indicator lamp (MIL) go out on activation?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S05746791722011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Permanent fault, signal missing

See Permanent fault, signal missing

See Permanent fault, signal missing

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Intermittent fault, signal too high

See Intermittent fault, signal too high

See Intermittent fault, signal too high

1. Ignition off
2. Disconnect the combined instrument panel connector
3. Ignition on. Connect a voltmeter between the combined instrument panel connector terminal #B23 (control module side) and ground.

The voltmeter should read 5 V.

1. OK Refer to «Checking the malfunction indicator lamp (MIL)»(ref-441346-S27870677022011121500000)
2. NOT OK Refer to «Checking the signal cable»(ref-441346-S36902081162011121500000)

Checking the malfunction indicator lamp (MIL)

1. Disconnect the malfunction indicator lamp (MIL) from the combined instrument panel according to «Replacing bulbs in the combined instrument panel»(ref-441350-S06877150482011121500000) . Take an Ohm reading from the malfunction indicator lamp (MIL).

The ohmmeter should read 10-15 ohms.

1. OK Refer to «Defective combined instrument panel»(ref-441346-S19927276372011121500000)
2. NOT OK Refer to «Defective malfunction indicator lamp (MIL)»(ref-441346-S17489646312011121500000)

Defective combined instrument panel

Try a new combined instrument panel according to Driver information module (DIM), installation/removal, component replacement .

1. Continue Refer to «Verification»(ref-441346-S06658467332011121500000)

Replace the malfunction indicator lamp (MIL) according to Replacing bulbs in the combined instrument panel .

1. Continue Refer to «Verification»(ref-441346-S06658467332011121500000)

Check the cable between engine control module (ECM) terminal #34 and the combined instrument panel connector terminal #B23. Check for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S06658467332011121500000)

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Connect VCT2000
4. Ignition on. Activate the malfunction indicator lamp (MIL).

Does the malfunction indicator lamp (MIL) function correctly?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S00939347632011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Permanent fault, signal too high

See Permanent fault, signal too high

See Permanent fault, signal too high

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Intermittent fault, signal too low

See Intermittent fault, signal too low

See Intermittent fault, signal too low

1. Ignition off. Check the cable between combined instrument panel connector terminal B23 (control module side) and engine control module (ECM) terminal 34 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

Remedy as necessary.

1. Continue Refer to «Verification»(ref-441346-S28197751182011121500000)

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Connect VCT 2000
4. Ignition on. Activate the malfunction indicator lamp (MIL) using VCT 2000 according to «Description of activations»(ref-441338-S37270559222011121500000) .

Does the lamp go out on activation?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441346-S11905987662011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
