Dynamic Stability Assist (Dsa) & Engine Control Module (ECM) Diagnostic Trouble Codes: Other

EEPROM memory fault. Permanent fault

Try a new DSA control module according to DSA control module, replacement .

EEPROM memory fault. Intermittent fault

The DSA control module is OK.

Erase the diagnostic trouble codes (DTC).

Continue Refer to «Information»(ref-441334-S12062160912011121500000)

Fault-tracing information

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

EEPROM memory fault

See EEPROM memory fault

Checking the signal cable

Control module connected.
Start the engine.
Read off the status of the switch.
Carefully remove the switch from the instrument panel.
Disconnect the switch. Check whether the ON or OFF status is displayed.

Is the OFF status displayed?

YES Refer to «Replacing the component»(ref-441334-S19533549132011121500000)
NO Refer to «Checking for a short-circuit»(ref-441334-S31134116512011121500000)

Replacing the component

Try a new DSA switch according to Replacing the DSA switch .

Continue Refer to «Verification»(ref-441334-S34229320122011121500000)

Checking for a short-circuit

Check the cable between switch connector terminal 4 and control module terminal 6 for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Scheme 50

Scheme 50: Checking for a short-circuit

Scheme 51

Continue Refer to «Verification»(ref-441334-S34229320122011121500000)

Verification

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
Control module connected.
Start the engine.
Read off the status of the switch. Check the function of the switch: OFF should be displayed when the switch is unaffected. On should be displayed when the switch is activated (pressed in).

Is the function of the switch OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S37257393802011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Checking the DSA switch

Control module connected.
Start the engine
Read off the status of the switch. Check the function of the switch: OFF should be displayed when the switch is unaffected. ON should be displayed when the switch is activated (pressed in).

Is the function of the switch OK?

YES Refer to «Signal too low. Intermittent fault»(ref-441334-S29518101032011121500000)
NO Refer to «Checking the signal cable»(ref-441334-S01530481922011121500000)

Control module connected.
Start the engine
Read off the status of the switch
Carefully remove the climate control module according to «Comfort module»(ref-441328-S27180039832011121500000)
Disconnect the climate control module connectors. Check whether the ON or OFF status is displayed.

Is the OFF status displayed?

YES Refer to «Replacing the component»(ref-441334-S10518860522011121500000)
NO Refer to «Checking for a short-circuit»(ref-441334-S41282516672011121500000)

Try a new climate control module according to Comfort module .

Continue Refer to «Verification»(ref-441334-S32538577562011121500000)

Check the cable between climate control module terminal #A11 DSA control module terminal #6. Check for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Continue Refer to «Verification»(ref-441334-S32538577562011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
Control module connected.
Start the engine.
Read off the status of the switch. Check the function of the switch: OFF should be displayed when the switch is unaffected. On should be displayed when the switch is activated (pressed in).

Is the function of the switch OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S38006030772011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal too low

See Signal too low

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Faulty signal. Intermittent fault

Checking the DSA warning lamp with the ignition off

Note. A diagnostic trouble code (DTC) may be stored if a DSA control module for model year 2003- is installed in a -2002 model year car. Check that the correct version of the control module is installed.

Scheme 52

Scheme 52: Checking the DSA warning lamp with the ignition off

Ignition off. Check whether the ABS warning lamp lights.

Does the warning lamp light?

YES Refer to «Checking for a short-circuit»(ref-441334-S29506362092011121500000)
NO Refer to «Checking the other warning lamps in the combined instrument panel»(ref-441334-S29089656542011121500000)

Check the cable between combined instrument panel connector B terminal #22 and control module terminal #16. Check for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

Scheme 53

Continue Refer to «Verification»(ref-441334-S16875025252011121500000)

Checking the other warning lamps in the combined instrument panel

Check that the other warning lamps in the combined instrument panel are functioning.

Are the other warning lamps functioning?

YES Refer to «Checking the DSA warning lamp»(ref-441334-S12093669422011121500000)
NO Refer to «Checking the combined instrument panel»(ref-441334-S36351598392011121500000)

Checking the combined instrument panel

Check that the combined instrument panel is functioning.

Checking the DSA warning lamp

Start the engine
Activate the DSA warning lamp so that it flashes. Check the function of the warning lamp.

Is the warning lamp lit continuously?

YES Refer to «Checking for a short-circuit»(ref-441334-S14601591652011121500000)
NO Refer to «Checking the signal from the combined instrument panel»(ref-441334-S12016490542011121500000)

Check the cable between the combined instrument panel connector B terminal #22 and control module terminal #16. Check for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Continue Refer to «Verification»(ref-441334-S16875025252011121500000)

Scheme 54

Scheme 54: Checking the signal from the combined instrument panel

Scheme 55

Scheme 56

Ignition off
Expose the DSA control module
Disconnect the control module
Ignition on. Connect a voltmeter between control module connector terminal #16 and ground.

The voltmeter should read approximately battery voltage.

OK Refer to «Checking the signal cable for a short-circuit to supply voltage»(ref-441334-S42903180832011121500000)
NOT OK Refer to «Checking the resistance of the signal cable»(ref-441334-S05775725972011121500000)

Scheme 57

Scheme 58

Ignition off
Expose the combined instrument panel
Disconnect the combined instrument panel
Control module disconnected Connect an ohmmeter between combined instrument panel connector B terminal #22 and control module connector terminal #16.

The ohmmeter should read approximately 0 ohms.

OK Refer to «Checking the bulb»(ref-441334-S11679043292011121500000)
NOT OK Refer to «Checking for an open-circuit»(ref-441334-S03862627982011121500000)

Checking the bulb

Check that the bulb in the combined instrument panel is intact.

Is the bulb intact?

YES Refer to «Replacing the component»(ref-441334-S12256810092011121500000)
NO Refer to «Replacing the component»(ref-441334-S32050287282011121500000)

Try a new combined instrument panel.

Continue Refer to «Verification»(ref-441334-S16875025252011121500000)

Replace the bulb.

Continue Refer to «Verification»(ref-441334-S16875025252011121500000)

Checking for an open-circuit

Check the cable between combined instrument panel connector B terminal #22 and control module terminal #16. Check for an open-circuit according to Open-circuit, permanent faults .

Scheme 59

Continue Refer to «Verification»(ref-441334-S16875025252011121500000)

Checking the signal cable for a short-circuit to supply voltage

Ignition off
Expose the combined instrument panel
Disconnect the combined instrument panel
Control module disconnected
Ignition on. Connect a voltmeter between control module connector terminal #16 and ground.

The voltmeter should read approximately 0 V.

OK Refer to «Fault cause and checking for contact resistance and oxidation»(ref-441334-S18720153872011121500000)
NOT OK Refer to «Checking for a short-circuit»(ref-441334-S10012787962011121500000)

Fault cause and checking for contact resistance and oxidation

The cause of the diagnostic trouble code (DTC) was loose connections in the DSA control module connector and/or connector B for the combined instrument panel.

Check the connectors for contact resistance and oxidation according to Contact resistance and oxidation . Remedy if necessary.

Continue Refer to «Verification»(ref-441334-S16875025252011121500000)

Continue Refer to «Verification»(ref-441334-S16875025252011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
Start the engine.
Activate the DSA warning lamp so that it flashes. Check the function of the warning lamp.

Is the function of the warning lamp OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S31558293482011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Ignition off. Check whether the ABS warning lamp lights.

Does the warning lamp light?

YES Refer to «Checking for a short-circuit»(ref-441334-S23689277502011121500000)
NO Refer to «Checking the other warning lamps in the combined instrument panel»(ref-441334-S24031871342011121500000)

Continue Refer to «Verification»(ref-441334-S10331643722011121500000)

Check that the other warning lamps in the combined instrument panel are functioning.

Are the other warning lamps functioning?

YES Refer to «Checking the DSA warning lamp»(ref-441334-S26496151182011121500000)
NO Refer to «Checking the combined instrument panel»(ref-441334-S42825283682011121500000)

Check that the combined instrument panel is functioning.

Start the engine
Activate the DSA warning lamp so that it flashes. Check the function of the warning lamp.

Is the warning lamp lit continuously?

YES Refer to «Checking for a short-circuit»(ref-441334-S23856543132011121500000)
NO Refer to «Checking the signal from the combined instrument panel»(ref-441334-S19664331162011121500000)

Continue Refer to «Verification»(ref-441334-S10331643722011121500000)

Checking the signal from the combined instrument panel

Ignition off
Expose the DSA control module
Disconnect the control module
Ignition on. Connect a voltmeter between control module connector terminal #16 and ground.

The voltmeter should read approximately battery voltage.

OK Refer to «Checking the signal cable for a short-circuit to supply voltage»(ref-441334-S23562457432011121500000)
NOT OK Refer to «Checking the resistance of the signal cable»(ref-441334-S11376279062011121500000)

Checking the resistance of the signal cable

Ignition off
Expose the combined instrument panel
Disconnect the combined instrument panel
Control module disconnected Connect an ohmmeter between combined instrument panel connector B terminal #22 and control module connector terminal #16.

The ohmmeter should read approximately 0 ohms.

OK Refer to «Checking the bulb»(ref-441334-S04828908222011121500000)
NOT OK Refer to «Checking for an open-circuit»(ref-441334-S38248213822011121500000)

Check that the bulb in the combined instrument panel is intact.

Is the bulb intact?

YES Refer to «Replacing the component»(ref-441334-S21184291052011121500000)
NO Refer to «Replacing the component»(ref-441334-S28653149072011121500000)

Try a new combined instrument panel.

Continue Refer to «Verification»(ref-441334-S10331643722011121500000)

Replace the bulb.

Continue Refer to «Verification»(ref-441334-S10331643722011121500000)

Check the cable between combined instrument panel connector B terminal #22 and control module terminal #16. Check for an open-circuit according to Open-circuit, permanent faults .

Continue Refer to «Verification»(ref-441334-S10331643722011121500000)

Ignition off
Expose the combined instrument panel
Disconnect the combined instrument panel
Control module disconnected
Ignition on. Connect a voltmeter between control module connector terminal #16 and ground.

The voltmeter should read approximately 0 V.

OK Refer to «Fault cause and checking for contact resistance and oxidation»(ref-441334-S20929107392011121500000)
NOT OK Refer to «Checking for a short-circuit»(ref-441334-S24118476832011121500000)

The cause of the diagnostic trouble code (DTC) was loose connections in the DSA control module connector and/or connector B for the combined instrument panel.

Check the connectors for contact resistance and oxidation according to Contact resistance and oxidation . Remedy if necessary.

Continue Refer to «Verification»(ref-441334-S10331643722011121500000)

Continue Refer to «Verification»(ref-441334-S10331643722011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
Start the engine.
Activate the DSA warning lamp so that it flashes. Check the function of the warning lamp.

Is the function of the warning lamp OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S06632975832011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Faulty signal. Permanent fault

See Faulty signal. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Faulty signal. Intermittent fault

Checking the resistance of the signal cable (continued)

DSA control module disconnected.
Engine control module (ECM) disconnected.
Breakout box connected to the engine control module (ECM). For FENIX 5.1 Connect an ohmmeter between DSA control module connector terminal 15 and engine control module (ECM) breakout box terminal 42. For EMS 2000 Connect an ohmmeter between DSA control module connector terminal 15 and engine control module (ECM) breakout box terminal 20. Other information To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) . To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) . To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

The ohmmeter should read approximately 0 ohms.

OK Refer to «Checking the signal cable resistance to ground»(ref-441334-S00381731072011121500000)
NOT OK Refer to «Checking for an open-circuit»(ref-441334-S06170755872011121500000)

For FENIX 5.1

Check the cable between engine control module (ECM) terminal 42 and DSA control module terminal 15 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

For EMS 2000

Check the cable between engine control module (ECM) terminal 20 and DSA control module terminal 15 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Continue Refer to «Verification»(ref-441334-S38773826892011121500000)

Scheme 60

Ignition off.
DSA control module disconnected.
Engine control module (ECM) disconnected.
Breakout box connected to the engine control module (ECM). For FENIX 5.1 Connect an ohmmeter between breakout box terminal 42 and ground. For EMS 2000 Connect an ohmmeter between breakout box terminal 20 and ground. Other information To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) . To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

The ohmmeter should read infinite resistance.

OK Refer to «Checking the signal cable for a short-circuit to supply voltage»(ref-441334-S23471667232011121500000)
NOT OK Refer to «Checking for a short-circuit»(ref-441334-S08961316392011121500000)

For FENIX 5.1

Check the cable between engine control module (ECM) terminal 42 and DSA control module terminal 15 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

For EMS 2000

Check the cable between engine control module (ECM) terminal 20 and DSA control module terminal 15 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

Continue Refer to «Verification»(ref-441334-S38773826892011121500000)

Scheme 61

Scheme 62

Ignition off.
Connect the DSA control module.
Connect the engine control module (ECM).
Breakout box connected to the engine control module (ECM).
Start the engine. For FENIX 5.1 Connect an electrician's screwdriver (with a bulb of at least 3 W) between breakout box terminal 42 and ground. For EMS 2000 Connect an electrician's screwdriver (with a bulb of at least 3 W) between breakout box terminal 20 and ground. Other information To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) . To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) . To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

The electricians screwdriver should not light. Is the electrician's screwdriver unlit?

YES Refer to «Fault cause and checking for contact resistance and oxidation»(ref-441334-S22521585942011121500000)
NO Refer to «Checking for a short-circuit»(ref-441334-S34337706322011121500000)

The diagnostic trouble code (DTC) was poor contact in the engine control module (ECM) and or the DSA control module connectors.

Check the connectors for contact resistance and oxidation and remedy according to Contact resistance and oxidation .

Continue Refer to «Verification»(ref-441334-S38773826892011121500000)

For FENIX 5.1

Check the cable between engine control module (ECM) terminal 42 and DSA control module terminal 15 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

For EMS 2000

Check the cable between engine control module (ECM) terminal 20 and DSA control module terminal 15 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

Continue Refer to «Verification»(ref-441334-S38773826892011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
Start the engine.
Activate torque limiting by clicking on the VCT 2000 symbol. Check that the engine is uneven when idling.

Does the engine idle unevenly when the function is activated?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S02591186272011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Permanent fault

Checking the stop lamp switch

Start the engine. Read off the status of the stop lamp switch.

When the brake pedal is unaffected, the value should be OFF. When the brake pedal is depressed the value should be ON.

OK Refer to «Signal too high. Intermittent fault»(ref-441334-S31645182512011121500000)
NOT OK Refer to «Checking the status of the stop lamp»(ref-441334-S30326853492011121500000)

Checking the status of the stop lamp

Ignition on. Check whether any of the stop lamps light even though the brake pedal is not depressed.

Are any of the stop lamps lit?

YES Refer to «Checking and adjusting the stop lamp switch»(ref-441334-S02791049002011121500000)
NO Refer to «Checking the signal cable»(ref-441334-S42663723342011121500000)

Checking and adjusting the stop lamp switch

Start the engine. Check that the stop lamp switch is correctly adjusted. It must not be activated when the brake pedal is released.

Is the stop lamp switch activated when the brake pedal is released?

YES Refer to «Fault causes and adjusting the stop lamp switch»(ref-441334-S08199329912011121500000)
NO Refer to «Checking the stop lamp switch»(ref-441334-S11778030642011121500000)

Fault causes and adjusting the stop lamp switch

The cause of the diagnostic trouble code (DTC) was incorrect adjustment of the stop lamp switch.

Adjust the stop lamp switch according to Stop lamp switch, adjustment .

Continue Refer to «Verification»(ref-441334-S04881158122011121500000)

Disconnect the stop lamp switch. Check whether the stop lamps go out.

Do the stop lamps go out?

YES Refer to «Replacing the component»(ref-441334-S11866058782011121500000)
NO Refer to «Checking for a short-circuit»(ref-441334-S13949530842011121500000)

Try a new stop lamp switch according to Replacing the stop lamp switch .

Continue Refer to «Verification»(ref-441334-S04881158122011121500000)

Check the wiring between stop lamp switch terminal #3, the stop lamps and DSA control module terminal #7. Check for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

Check the cable between DSA control module terminal #7 and stop lamp switch terminal #2. Check for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

The connection is via the central electrical module. The input signal is via terminal #B1:3. The output signal is via terminal #B1:4 to the DSA control module.

Scheme 63

Continue Refer to «Verification»(ref-441334-S04881158122011121500000)

Ignition on
DSA control module connected.
Brake pedal unaffected. Connect a voltmeter between ground and DSA control module connector terminal #7. Other information To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) .

The voltmeter should read approximately 0 V.

OK Refer to «Fault cause and diagnostic testing for contact resistance and oxidation»(ref-441334-S21180228612011121500000)
NOT OK Refer to «Checking for an open-circuit»(ref-441334-S08910264202011121500000)

Check the cable between DSA control module terminal #7 and one of the stop lamps. Check for an open-circuit according to Open-circuit, permanent faults .

If the cable is OK: Check the stop lamp bulbs. Check the ground terminal. Check for an open-circuit according to Open-circuit, permanent faults .

Continue Refer to «Verification»(ref-441334-S04881158122011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 64

Ignition off.
Reconnect the connectors, reinstall components etc.
DSA control module connected.
Start the engine. Read off the status of the stop (brake) lamp switch.

When the brake pedal is unaffected, the value should be OFF. When the brake pedal is depressed the value should be ON.

OK VERIFIED: Troubleshooting has been completed.
NOT OK Refer to «Information»(ref-441334-S42831339392011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal too high

See Signal too high

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Faulty signal. Intermittent fault

Ignition off
Expose the DSA control module
Ignition on
DSA control module connected.
The brake pedal is released. Connect a voltmeter between ground and DSA control module connector terminal 7.

The voltmeter should read approximately 0 V.

OK Refer to «Checking a voltage drop in the signal cable»(ref-441334-S34619962042011121500000)
NOT OK Refer to «Checking for an open-circuit»(ref-441334-S32344261422011121500000)

Check the cable between DSA control module terminal 7 and one of the stop (brake) lamps for an open-circuit according to Open-circuit, permanent faults .

Check the central electrical module (CEM) connector for contact resistance and oxidation according to Contact resistance and oxidation .

If the cable is OK, check the stop (brake) lamp bulbs and the stop (brake) lamp ground terminal for an open-circuit according to Open-circuit, permanent faults .

Continue Refer to «Verification»(ref-441334-S21437500412011121500000)

Checking a voltage drop in the signal cable

HINT: All stop (brake) lamps must be intact during this check. This is so that the voltage in the circuit is as high as possible.

Ignition on
DSA control module connected.
Depress the brake pedal. Hold it depressed. Connect a voltmeter between ground and DSA control module connector terminal 7.

The voltmeter should read 0- 1.5 V below battery voltage.

OK Refer to «Fault cause and checking for contact resistance and oxidation»(ref-441334-S10625928032011121500000)
NOT OK Refer to «Checking a voltage drop in the stop (brake) lamp switch»(ref-441334-S16588006942011121500000)

The cause of the diagnostic trouble code (DTC) was loose connections in the DSA control module connector.

Check the control module connector for contact resistance and oxidation and remedy according to Contact resistance and oxidation .

Continue Refer to «Verification»(ref-441334-S21437500412011121500000)

Checking a voltage drop in the stop (brake) lamp switch

Ignition on
DSA control module connected.
Depress the brake pedal. Hold it depressed. Connect a voltmeter between stop (brake) lamp switch connector terminals 2 and 1.

The voltmeter should read 0- 1.5 V.

OK Refer to «Checking for contact resistance and oxidation»(ref-441334-S40750191172011121500000)
NOT OK Refer to «Replacing the component»(ref-441334-S25766761982011121500000)

Checking for contact resistance and oxidation

Check the circuit for stop (brake) lamp switch connector terminal 1 for contact resistance and oxidation according to Contact resistance and oxidation .

Check the cable between DSA control module terminal 7 and stop (brake) lamp switch terminal 2 for contact resistance and oxidation according to Contact resistance and oxidation .

The connection is via the central electrical module. The input signal is via terminal B1:3. The output signal is via terminal B1:4 to the DSA control module.

Check the central electrical module (CEM) connector for contact resistance and oxidation according to Contact resistance and oxidation .

Continue Refer to «Verification»(ref-441334-S21437500412011121500000)

Check that the correct bulbs are installed in the stop (brake) lamps. Check that no extra power consuming components are connected to the circuit.

Then replace the stop (brake) lamp switch according to Replacing the stop lamp switch .

Continue Refer to «Verification»(ref-441334-S21437500412011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
Start the engine.
Depress the brake pedal. Hold it down for approximately 10 seconds. Read off the status of the diagnostic trouble code (DTC).

Has the status changed to intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S23242444032011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal missing. Intermittent fault

See Signal missing. Intermittent fault

Checking the resistance in the signal cable

DSA control module disconnected.
Engine control module (ECM) disconnected.
Breakout box connected to the engine control module (ECM). FENIX 5.1 Connect an ohmmeter between DSA control module connector terminal 13 and engine control module (ECM) breakout box terminal 37. EMS 2000 Connect an ohmmeter between DSA control module connector terminal 13 and engine control module (ECM) breakout box terminal 71. Other information To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) . To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) . To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

The ohmmeter should read approximately 0 ohms.

OK Refer to «Checking the signal cable resistance to ground»(ref-441334-S13343680042011121500000)
NOT OK Refer to «Checking for an open-circuit»(ref-441334-S16774075502011121500000)

FENIX 5.1

Check the cable between DSA control module connector terminal 13 and engine control module (ECM) terminal 37 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

EMS 2000

Check the cable between DSA control module connector terminal 13 and engine control module (ECM) terminal 71 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Continue Refer to «Verification»(ref-441334-S01304389022011121500000)

Checking the signal cable resistance to ground

Ignition off.
DSA control module disconnected.
Engine control module (ECM) disconnected.
Breakout box connected to the engine control module (ECM). FENIX 5.1 On vehicles with automatic transmission: Disconnect the automatic transmission control module (TCM). Connect an ohmmeter between breakout box terminal 37 and ground. EMS 2000 Connect an ohmmeter between breakout box terminal 71 and ground. Other information To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) . To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

The ohmmeter should read infinite resistance.

OK Refer to «Checking the signal cable for a short-circuit to supply voltage»(ref-441334-S30248613492011121500000)
NOT OK Refer to «Checking for a short-circuit»(ref-441334-S18780501742011121500000)

FENIX 5.1

Check the cable between engine control module (ECM) terminal 37 and DSA control module terminal 13 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .
On vehicles with automatic transmission: Also check the cable between engine control module (ECM) terminal 37 and automatic transmission control module (TCM) terminal 23 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

EMS 2000

Check the cable between engine control module (ECM) terminal 71 and DSA control module terminal 13 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

Continue Refer to «Verification»(ref-441334-S01304389022011121500000)

Ignition off.
Connect the DSA control module.
Connect the engine control module (ECM).
Breakout box connected to the engine control module (ECM).
Start the engine. FENIX 5.1 On vehicles with automatic transmission: Connect the automatic transmission control module (TCM). Connect an electrician's screwdriver (with a bulb of at least 3 W) between breakout box terminal 37 and ground. EMS 2000 Connect an electrician's screwdriver (with a bulb of at least 3 W) between breakout box terminal 71 and ground. Other information To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) . To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) . To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

The electricians screwdriver should not light. Is the electrician's screwdriver unlit?

YES Refer to «Fault cause and checking for contact resistance and oxidation»(ref-441334-S36635351582011121500000)
NO Refer to «Checking for a short-circuit»(ref-441334-S04411676502011121500000)

The diagnostic trouble code (DTC) was caused by poor contact in the DSA control module and / or engine control module (ECM) connectors.

Check the connectors for contact resistance and oxidation and remedy according to Contact resistance and oxidation .

Continue Refer to «Verification»(ref-441334-S01304389022011121500000)

FENIX 5.1

Check the cable between engine control module (ECM) terminal 37 and DSA control module terminal 13 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .
On vehicles with automatic transmission: Also check the cable between engine control module (ECM) terminal 37 and automatic transmission control module (TCM) terminal 23 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

EMS 2000

Check the cable between engine control module (ECM) terminal 71 and DSA control module terminal 13 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

Continue Refer to «Verification»(ref-441334-S01304389022011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
DSA control module connected.
Start the engine. Read off the load signal. Check that the value is OK. HINT: Normal range idling with the engine at operating temperature, neutral selected and the air conditioning (A/C) off: approximately 36 μs. This value increases with load.

Is the value of the load signal OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S13303169532011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Faulty signal

See Faulty signal

Checking the DSA control module

Ignition off.
Expose the DSA control module.
Disconnect the DSA control module.
Connect a new DSA control module alongside.
Start and stop the engine a few times.
Let the engine idle. Read off diagnostic trouble codes (DTCs).

Is diagnostic trouble code (DTC) DSA-223 still stored?

YES Refer to «Replacing the component»(ref-441334-S22867555742011121500000)
NO Refer to «Replacing the component»(ref-441334-S16508170292011121500000)

The old DSA control module is OK: Reinstall it.

Note. It is vital that any diagnostic trouble codes (DTCs) in the engine control module (ECM) and the DSA control module are remedied before the engine control module (ECM) is replaced.

FENIX 5.1

Try a new engine control module (ECM) according to «Replacing engine control module (ECM)»(ref-441334-S08363673442011121500000) .

EMS 2000

Try a new engine control module (ECM) according to «Replacing the engine control module (ECM)»(ref-441334-S06136385422011121500000) .

Continue Refer to «Verification»(ref-441334-S32254267252011121500000)

The old DSA control module is defective.

Install the new DSA control module according to DSA control module, replacement .

Continue Refer to «Verification»(ref-441334-S32254267252011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
DSA control module connected.
Start and stop the engine a few times.
Let the engine idle. Read off diagnostic trouble codes (DTCs).

Is diagnostic trouble code (DTC) DSA-223 still stored?

YES Refer to «Information»(ref-441334-S03934070652011121500000)
NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Information concerning B4184S and B4204S

From and including May 1997 there is only one replacement part engine control module (ECM) for each type of engine. These engine control modules (ECM) applies to both cars without, and for earlier cars, cars with pulsed secondary air injection system (PAIR) pump.

The engine control module (ECM) no longer controls the secondary air injection system (PAIR) pump when it is fitted to cars with manual transmission and pulsed secondary air injection system (PAIR) pump.

These cars however still meet the statutory requirement for emission levels.

Scheme 65

Scheme 65: Replacing engine control module (ECM)

Remove the side panels from center console.
Drill out the security screws to the right of the bracket with screwdriver (P/N 998 5477). NOTE: Ensure that no swarf falls onto the carpet.
Pull out the right-hand side of the bracket.
Remove the engine control module (ECM) from its clamp and disconnect the connector.

Before replacing the engine control module with a new one, the Verlog code of the old module has to be erased. The code is erased through VIDA which is used for communication with the immobilizer system through VCT 2000. If the code is not erased, the control module cannot be checked if it is returned due to a warranty claim, or if it is to be moved to another car. This is caused by the module having learnt the Verlog code generated by the immobilizer system of the car in which the module has been placed. When that has been done, the engine control module can only work together with that specific immobilizer system, as long as the Verlog code in the module is not erased.

Note. The Verlog-code can only be erased using the particular immobilizer- control module whose Verlog-code the engine control module (ECM) has learned.

Erase the Verlog code in the engine control module through VIDA vehicle communication (requires Volvo scan tool) . The PIN code is supplied by Volvo's central vehicle register. PIN codes are ordered in the same way as mechanical key codes.

Note. Keep the ignition switched off after erasure until the engine control module (ECM)) has been removed from the car. Otherwise the engine control module (ECM) will relearn the Verlog code.

Reinstall

Reinstall bracket and press together.
Install a new security screw.
Tighten the security screw until the screw head breaks off.

Replacing the engine control module (ECM)

Before replacing the engine control module (ECM)

Before the engine control module is replaced, the VIN code in the old engine control module must be deleted.

The code is deleted using VIDA vehicle communication system Immobilizer Group 3(36) S40/V40. If the code is not deleted, the old engine control module cannot be tested if it has been returned as part of a warranty claim. In addition, it cannot be used in another car.

This is because the engine control module has learned a unique VIN code from the immobilizer system in the car in which it was originally installed.

Once the VIN code from the immobilizer system is programmed, the engine control module can only be used with that specific immobilizer module until the VIN code in the engine control module is deleted.

Note. VIN code deletion is only possible together with the immobilizer module whose VIN code is programmed in the engine control module.

Delete the VIN code in the engine control module . The PIN code required for this measure can only be obtained from the Volvo central vehicle register. Use the same routine as when ordering a mechanical key code.

Note. Always check that deletion was successful. This is done by reading out the parameter VIN PROGRAMMED . If deletion was successful, the parameter indicates NO. Do as follows Engine management system EMS 2000 Turn off the ignition for 30 seconds and then turn it back on (if the electric cooling fan is running, wait until it has stopped and then wait an additional 30 seconds). Then read out the parameter VIN PROGRAMMED. When the parameter indicates NO, turn off the ignition and disconnect the engine control module. Do not start the engine as this will cause the engine control module to relearn the VIN code.

HINT: The spare part control module is unprogrammed (virgin mode). If the right PIN codes are not programmed, the MIL lamp will illuminate.

Scheme 66

Scheme 66: Replacing the engine control module (ECM)

Always check that the control module and control module box connector pins and sleeves are not bent or damaged. This may have caused the fault.

Removing the control module

As part of the anti-theft protection on cars with electronic immobilizer, the control module box is locked with a lock strap. A shear screw is used to install the lock strap.

Mark the center of the shear screw and drill a hole of a suitable diameter for a screw puller.
Fit the screw puller and remove the screw.

Installing the control module

Scheme 67

Check that no pins or sockets are damaged on the connector.
Install the new control module.

Control module programming (model year 1999 only)

After control module the control module is installed, PIN codes must be programmed. The car's PIN codes are stored in the Volvo central vehicle register. Contact your sales company to obtain the codes.

Note. A new control module that has been installed in a car and programmed is only suitable for the car it is in. The engine control module may not be transferred to another car.

VIDA vehicle communication is used for control module programming.

Control module programming (model year 2000 only)

Ordering software

Order the software. See 9139873 .

Installing the engine control module, continued

As part of the anti-theft protection on cars with electronic immobilizer, the control module box is locked with a lock strap. A shear screw is used to install the lock strap.

Note. Do not reinstall the lock strap until the car has been repaired and all faults have been remedied.

Fit the lock strap using a new shear screw (part no. 980471-7) and tighten the screw so that the head is sheared off.

Reading and erasing diagnostic trouble codes (DTCs)

It is important that diagnostic trouble codes are read out and deleted upon control module replacement.

Read out any diagnostic trouble codes.
Erase Diagnostic Trouble Codes (DTCs).

See Faulty signal

Selecting the engine management system

Enter the engine management system

FENIX 5.1 Refer to «Checking diagnostic trouble codes (DTCs) in the engine control module (ECM)»(ref-441334-S13852773762011121500000)
EMS 2000. Refer to «Checking diagnostic trouble codes (DTCs) in the engine control module (ECM)»(ref-441334-S24577437632011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

DSA control module disconnected.
Engine control module (ECM) disconnected.
Breakout box connected to the engine control module (ECM). FENIX 5.1 Connect an ohmmeter between DSA control module connector terminal 5 and engine control module (ECM) breakout box terminal 41. EMS 2000 Connect an ohmmeter between DSA control module connector terminal 5 and engine control module (ECM) breakout box terminal 36. Other information To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) . To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) . To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

The ohmmeter should read approximately 0 ohms.

OK Refer to «Checking the signal cable resistance to ground»(ref-441334-S20927133052011121500000)
NOT OK Refer to «Checking for an open-circuit»(ref-441334-S41650660982011121500000)

FENIX 5.1

Check the cable between DSA control module terminal 5 and engine control module (ECM) terminal 41 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

EMS 2000

Check the cable between DSA control module terminal 5 and engine control module (ECM) terminal 36 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Other information

To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) .
To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) .
To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

Continue Refer to «Verification»(ref-441334-S09812540682011121500000)

Ignition off.
DSA control module disconnected.
Engine control module (ECM) disconnected.
Breakout box connected to the engine control module (ECM). FENIX 5.1 Connect an ohmmeter between breakout box terminal 41 and ground. On vehicles with automatic transmission: Disconnect the automatic transmission control module (TCM). EMS 2000 Connect an ohmmeter between breakout box terminal 36 and ground. Other information To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) . To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

The ohmmeter should read infinite resistance.

OK Refer to «Checking the signal cable for a short-circuit to supply voltage»(ref-441334-S38166276892011121500000)
NOT OK Refer to «Checking for a short-circuit»(ref-441334-S06447471662011121500000)

FENIX 5.1

Check the cable between engine control module (ECM) terminal 41 and DSA control module terminal 5 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .
On vehicles with automatic transmission: Also check the cable between engine control module (ECM) terminal 41 and automatic transmission control module (TCM) terminal 38 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

EMS 2000

Check the cable between engine control module (ECM) terminal 36 and DSA control module terminal 5 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

Other information

To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) .
To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) .
To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

Continue Refer to «Verification»(ref-441334-S09812540682011121500000)

Ignition off.
Connect the DSA control module.
Connect the engine control module (ECM).
On vehicles with automatic transmission: Connect the automatic transmission control module (TCM).
Breakout box connected to the engine control module (ECM).
Start the engine. FENIX 5.1 Connect an electrician's screwdriver (with a bulb of at least 3 W) between breakout box terminal 41 and ground. EMS 2000 Connect an electrician's screwdriver (with a bulb of at least 3 W) between breakout box terminal 36 and ground. Other information To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) . To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) . To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

The electricians screwdriver should not light. Is the electrician's screwdriver unlit?

YES Refer to «Fault cause and checking for contact resistance and oxidation»(ref-441334-S16283317932011121500000)
NO Refer to «Checking for a short-circuit»(ref-441334-S21447577152011121500000)

The diagnostic trouble code (DTC) was caused by poor contact in the DSA control module and / or engine control module (ECM) connectors.

Check the connectors for contact resistance and oxidation and remedy according to Contact resistance and oxidation .

Continue Refer to «Verification»(ref-441334-S09812540682011121500000)

FENIX 5.1

Check the cable between engine control module (ECM) terminal 41 and DSA control module terminal 5 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .
On vehicles with automatic transmission: Also check the cable between engine control module (ECM) terminal 41 and automatic transmission control module (TCM) terminal 38 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

EMS 2000

Check the cable between engine control module (ECM) terminal 36 and DSA control module terminal 5 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

Other information

To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) .
To connect the breakout box for FENIX 5.1, see «Connecting the breakout box. FENIX 5.1»(ref-461610-S04346069642012040200000) .
To connect the breakout box for EMS 2000, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .

Continue Refer to «Verification»(ref-441334-S09812540682011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
DSA control module connected.
Start the engine.
Depress the accelerator pedal quickly a few times. Release the pedal so that the engine idles each time.
Switch off the engine.
Ignition on.
Read off the position of the throttle position (TP) sensor. Fully depress the accelerator pedal several times. Check that the throttle position (TP) sensor position increases and decreases.

Is the position of the throttle position (TP) sensor OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S05915884332011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Faulty signal

Ignition off.
DSA control module disconnected.
ABS control module disconnected.
Breakout box connected to the ABS control module. Connect an ohmmeter between DSA control module connector: terminal 2 and breakout box terminal 25 (diagnostic trouble code (DTC) DSA-311) terminal 3 and breakout box terminal 26 (diagnostic trouble code (DTC) DSA-312) terminal 4 and breakout box terminal 23 (diagnostic trouble code (DTC) DSA-313) terminal 12 and breakout box terminal 24 (diagnostic trouble code (DTC) DSA-314). Other information To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) . To connect the breakout box for ABS, see «Connecting the breakout box. ABS»(ref-441334-S27833644282011121500000) .

The ohmmeter should read approximately 0 ohms.

OK Refer to «Checking the signal cable resistance to ground»(ref-441334-S19822275792011121500000)
NOT OK Refer to «Checking for an open-circuit»(ref-441334-S21735567072011121500000)

Check the cable between the DSA control module

terminal 2 and breakout box terminal 25 (diagnostic trouble code (DTC) DSA-311)
terminal 3 and breakout box terminal 26 (diagnostic trouble code (DTC) DSA-312)
terminal 4 and breakout box terminal 23 (diagnostic trouble code (DTC) DSA-313)
terminal 12 and breakout box terminal 24 (diagnostic trouble code (DTC) DSA-314)

for an open-circuit according to Open-circuit, permanent faults .

Other information

To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) .
To connect the breakout box for ABS, see «Connecting the breakout box. ABS»(ref-441334-S27833644282011121500000) .

Continue Refer to «Verification»(ref-441334-S34371342812011121500000)

Ignition off.
DSA control module disconnected.
ABS control module disconnected. Connect an ohmmeter between ground and DSA control module connector: terminal 2 (diagnostic trouble code (DTC) DSA-311) terminal 3 (diagnostic trouble code (DTC) DSA-312) terminal 4 (diagnostic trouble code (DTC) DSA-313) terminal 12 (diagnostic trouble code (DTC) DSA-314). Other information To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) .

The ohmmeter should read infinite resistance.

OK Refer to «Checking the signal cable for a short-circuit to supply voltage»(ref-441334-S21572478552011121500000)
NOT OK Refer to «Checking for a short-circuit»(ref-441334-S42552858712011121500000)

Check the cable between the DSA control module

terminal 2 and breakout box terminal 25 (diagnostic trouble code (DTC) DSA-311)
terminal 3 and breakout box terminal 26 (diagnostic trouble code (DTC) DSA-312)
terminal 4 and breakout box terminal 23 (diagnostic trouble code (DTC) DSA-313)
terminal 12 and breakout box terminal 24 (diagnostic trouble code (DTC) DSA-314).

for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Other information

To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) .
To connect the breakout box for ABS, see «Connecting the breakout box. ABS»(ref-441334-S27833644282011121500000) .

Continue Refer to «Verification»(ref-441334-S34371342812011121500000)

Ignition off.
Connect the DSA control module.
Connect the ABS control module.
Breakout box connected to the ABS control module.
Ignition on. Connect an electrician's screwdriver (with a bulb of at least 3 W) between ground and breakout box: terminal 25 (diagnostic trouble code (DTC) DSA-311) terminal 26 (diagnostic trouble code (DTC) DSA-312) terminal 23 (diagnostic trouble code (DTC) DSA-313) terminal 24 (diagnostic trouble code (DTC) DSA-314). Other information To connect the breakout box for ABS, see «Connecting the breakout box. ABS»(ref-441334-S27833644282011121500000) .

The electricians screwdriver should not light. Is the electrician's screwdriver unlit?

YES Refer to «Fault cause and checking for contact resistance and oxidation»(ref-441334-S12003353392011121500000)
NO Refer to «Checking for a short-circuit»(ref-441334-S36401057222011121500000)

The diagnostic trouble code (DTC) was caused by poor contact in the DSA control module and / or ABS control module connectors.

Check the connectors for contact resistance and oxidation and remedy according to Contact resistance and oxidation .

Continue Refer to «Verification»(ref-441334-S34371342812011121500000)

Check the cable between the DSA control module

terminal 2 and ABS control module terminal 25 (diagnostic trouble code (DTC) DSA-311)
terminal 3 and ABS control module terminal 26 (diagnostic trouble code (DTC) DSA-312)
terminal 4 and ABS control module terminal 23 (diagnostic trouble code (DTC) DSA-313)
terminal 12 and ABS control module terminal 24 (diagnostic trouble code (DTC) DSA-314)

for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

Other information

To connect the breakout box for DSA, see «Connecting the breakout box. DSA»(ref-441291-S01847758132011121500000) .
To connect the breakout box for ABS, see «Connecting the breakout box. ABS»(ref-441334-S27833644282011121500000) .

Continue Refer to «Verification»(ref-441334-S34371342812011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
DSA control module connected.
Ignition on.
Read off the wheel speeds.
Raise the car so that the relevant wheel is clear of the ground. Spin the relevant wheel. Check the wheel speed.

Is the wheel speed OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S00812235412011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Connecting the breakout box. ABS

Special tools

9511426

9813190

Connecting the breakout box

Scheme 68

Scheme 68: Connecting the breakout box. ABS

Ignition off
Disconnect the ABS control module
Check the control module and the control module connector to ensure that: The male and female terminals are undamaged and properly attached (cannot be pressed in). The wiring for the female terminals is securely connected. Check in particular those terminals that are relevant to the stored diagnostic trouble code (DTC) / symptoms
Connect adapter «9511426»(ref-403953-S33123744892011061500000) to the control module connector (wiring side). Connect breakout box «9813190»(ref-403953-S32930552542011061000000) to the adapter.

See Faulty signal

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

Checking the power cable

Ignition off
Disconnect the injector connector
Ignition on. Connect a voltmeter between injector connector terminal 1 (control module side) and ground.

The voltmeter should read battery voltage for 2 seconds immediately after the ignition is switched on.

OK Refer to «Checking injectors»(ref-441334-S20629571232011121500000)
NOT OK Refer to «Checking wiring and terminals»(ref-441334-S31173602262011121500000)

Checking injectors

Connect an ohmmeter between injector connector terminals 1 and 2 (injector side).

Scheme 69

Scheme 69: Checking injectors

The ohmmeter should read approximately 14-15 ohms at +20 °C.

OK Refer to «Checking wiring and terminals»(ref-441334-S40766688562011121500000)
NOT OK Refer to «Defective injector»(ref-441334-S37463091572011121500000)

Defective injector

Try a new injector according to Replacing the injector(s) .

Continue Refer to «Selecting diagnostic trouble code (DTC)»(ref-441334-S06004952762011121500000)

Reconnect the connectors, reinstall components etc.
Ignition on. Activate the injector by clicking on the VCT 2000 symbol.

Does the injector click?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S23902454012011121500000)

Reconnect the connectors, reinstall components etc.
Ignition on. Activate the injector by clicking on the VCT 2000 symbol.

Does the injector click?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S23902454012011121500000)

Reconnect the connectors, reinstall components etc.
Ignition on. Activate the injector by clicking on the VCT 2000 symbol.

Does the injector click?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S23902454012011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Reconnect the connectors, reinstall components etc.
Ignition on. Activate the injector using the VCT2000 symbol.

Does the injector click?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S22048199672011121500000)

Reconnect the connectors, reinstall components etc.
Ignition on. Click the VCT2000 symbol to activate the injector.

Does the injector click?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S22048199672011121500000)

Reconnect the connectors, reinstall components etc.
Ignition on. Click the VCT2000 symbol to activate the injector.

Does the injector click?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S22048199672011121500000)

Reconnect the connectors, reinstall components etc.
Ignition on. Click the VCT2000 symbol to activate the injector.

Does the injector click?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S22048199672011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Intermittent fault

See Signal missing. Permanent fault

See Signal missing. Intermittent fault

See Signal missing. Permanent fault

See Signal missing. Intermittent fault

Checking cables

Check the engine control module (ECM) and canister purge (CP) valve connectors for contact resistance and oxidation according to Contact resistance and oxidation .

Check that the resistance in the canister purge (CP) valve between terminals 1 and 2 is approximately 30 ohms at +20 °C.

Check and rectify the signal line between Engine control module (ECM) #4 and the EVAP-valve's connection #1 for intermittent open circuits.

Check the voltage cable between the EVAP-valve's connection #2 and the system relay (2/14) connection #3 for intermittent open circuits.

Other information

To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) .
See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

Scheme 70

Continue Refer to «Information»(ref-441334-S13350364522011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Checking the terminal

Ignition off
Disconnect the canister purge (CP) valve connector. Check the canister purge (CP) valve connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy as necessary.

Did you find a problem?

YES Refer to «Verification»(ref-441334-S22022925582011121500000)
NO Refer to «Checking the canister purge (CP) valve»(ref-441334-S00916422902011121500000)

Scheme 71

Canister purge (CP) valve connector disconnected
Ignition on. Connect an ohmmeter between canister purge (CP) valve connector terminals 1 and 2.

The ohmmeter should show about 30 ohms at +20 °C.

OK Refer to «Checking the power supply»(ref-441334-S04471539322011121500000)
NOT OK Refer to «Defective canister purge (CP) valve»(ref-441334-S06725473332011121500000)

Checking the power supply

Ignition off. Connect a voltmeter between the canister purge (CP) valve connector terminal 2 (control module side) and ground.

The voltmeter should read battery voltage for 2 seconds immediately after the ignition is switched on.

OK Refer to «Checking the signal cable»(ref-441334-S37931307622011121500000)
NOT OK Refer to «Checking the power cable»(ref-441334-S18515488172011121500000)

Check the cable between the EVAP-valve's connection #1 and Engine control module (ECM) connector #4 for open circuit. Checking wiring and terminals. Permanent fault

Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S22022925582011121500000)

Defective canister purge (CP) valve

Try a new canister purge (CP) valve according to Replacing the canister purge (CP) valve .

Continue Refer to «Verification»(ref-441334-S22022925582011121500000)

Check the cable between canister purge (CP) valve terminal 2 and system relay base 2/14 terminal 3 for an open-circuit according to Open-circuit, permanent faults .

Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S22022925582011121500000)

Reconnect the connectors, reinstall components etc. Activate the canister purge (CP) valve according to «Description of activations»(ref-441338-S37270559222011121500000) .

Do you hear a click from the EVAP valve?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S29343249032011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Check canister purge (CP) valve

Ignition off
Disconnect the front canister purge (CP) valve connector. Connect an ohmmeter between the canister purge (CP) valve terminals 1 and 2 (valve side).

The ohmmeter should show about 30 ohms at +20 °C.

OK Refer to «Checking the signal cable»(ref-441334-S08137431862011121500000)
NOT OK Refer to «Defective canister purge (CP) valve»(ref-441334-S13114209352011121500000)

Ignition on. Check the cable between the EVAP-valve's connector #1 (to control module) and Engine control module (ECM) connector #4 for short-circuiting to voltage. «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000) Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S27995935512011121500000)

Try a new valve according to Replacing the canister purge (CP) valve .

Continue Refer to «Verification»(ref-441334-S27995935512011121500000)

Ignition off
Reconnect the connectors, reinstall components etc.
Connect VCT 2000
Ignition on. Activate the canister purge (CP) valve according to «Description of activations»(ref-441338-S37270559222011121500000) .

Do you hear a click from the EVAP valve?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S15939501752011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Ignition off
Disconnect the front canister purge (CP) valve connector. Check the cable between the canister purge (CP) valve connector terminal 1 (control module side) and engine control module (ECM) connector terminal 4 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) . Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S20012499912011121500000)

Reconnect the connectors, reinstall components etc.
Connect VCT 2000. Activate the canister purge (CP) valve according to «Description of activations»(ref-441338-S37270559222011121500000) .

Does the canister purge (CP) valve click?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S20131531222011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Ignition off
Disconnect the connector for the atmospheric pressure sensor. Check the atmospheric pressure sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy as necessary.

Was a fault detected?

YES Refer to «Verification»(ref-441334-S24739686112011121500000)
NO Refer to «Checking the signal cable»(ref-441334-S06955396932011121500000)

Ignition off
Disconnect the connector for the atmospheric pressure sensor
Ignition on. Connect a voltmeter between the atmospheric pressure sensor connector terminal 3 (control module side) and ground.

The voltmeter should read 0 V.

OK Refer to «Checking the ground lead»(ref-441334-S16351951492011121500000)
NOT OK Refer to «Checking the signal cable»(ref-441334-S02647361472011121500000)

Checking the ground lead

Connect an ohmmeter between atmospheric pressure sensor connector terminal 2 and ground.

The ohmmeter should read approximately 0 ohms.

OK Refer to «Defective atmospheric pressure sensor»(ref-441334-S15761249962011121500000)
NOT OK Refer to «Checking the ground lead»(ref-441334-S23144885022011121500000)

Defective atmospheric pressure sensor

Try a new atmospheric pressure sensor according to Replacing the atmospheric pressure sensor .

Continue Refer to «Verification»(ref-441334-S24739686112011121500000)

Check the cable between atmospheric pressure sensor connector terminal 2 (control module side) and engine control module (ECM) terminal 77 for an open-circuit according to Open-circuit, permanent faults .

Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S24739686112011121500000)

Check the cable between atmospheric pressure sensor connector terminal 3 (control module side) and engine control module (ECM) terminal 18 for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S24739686112011121500000)

Reconnect the connectors, reinstall components etc.
Connect VCT 2000
Ignition on. Read off the BARO parameter. The value indicates atmospheric pressure.

Is the value OK?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S27469207612011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Ignition off
Disconnect the connector for the atmospheric pressure sensor. Check the atmospheric pressure sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy as necessary.

Was a fault detected?

YES Refer to «Verification»(ref-441334-S03817183392011121500000)
NO Refer to «Checking the power cable»(ref-441334-S15035119892011121500000)

Ignition on
Atmospheric pressure sensor connector disconnected. Connect a voltmeter between atmospheric pressure sensor connector terminal 1 (control module side) and the ground terminal.

The voltmeter should read approximately 5 V.

OK Refer to «Checking the signal cable»(ref-441334-S32757032942011121500000)
NOT OK Refer to «Checking the power cable»(ref-441334-S22672608122011121500000)

Ignition off
Atmospheric pressure sensor connector disconnected. Connect an ohmmeter between atmospheric pressure sensor connector terminal 3 (control module side) and the ground terminal.

The ohmmeter should read approximately 59 kohms.

OK Refer to «Checking the ground lead»(ref-441334-S05560734842011121500000)
NOT OK Refer to «Checking the signal cable»(ref-441334-S41246689632011121500000)

Connect an ohmmeter between atmospheric pressure sensor connector terminal 2 (engine control module (ECM) side) and ground.

The ohmmeter should read approximately 0 ohms.

OK Refer to «Defective atmospheric pressure sensor»(ref-441334-S42108109312011121500000)
NOT OK Refer to «Checking the ground lead»(ref-441334-S29167930592011121500000)

Try a new atmospheric pressure sensor according to Replacing the atmospheric pressure sensor .

Continue Refer to «Verification»(ref-441334-S03817183392011121500000)

Check the cable between atmospheric pressure sensor connector terminal 1 (control module side) and engine control module (ECM) terminal 78 for an open-circuit according to Open-circuit, permanent faults .

Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S03817183392011121500000)

Check the cable between atmospheric pressure sensor connector terminal 3 (control module side) and engine control module (ECM) terminal 18 for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S03817183392011121500000)

Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S03817183392011121500000)

Ignition off
Reconnect the connectors, reinstall components etc.
Connect VCT 2000
Ignition on. Read off the BARO parameter.

Is the value OK?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S38589455342011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the connectors

Ignition off
Check the atmospheric pressure sensor and engine control module (ECM) connectors for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S00267239222011121500000) and loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) . Check for damage carefully. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) For information about signals, see «Signal specification»(ref-441338-S16642011902011121500000) To replace the atmospheric pressure sensor, see «Replacing the atmospheric pressure sensor»(ref-441335-S15233333552011121500000) .

Continue Refer to «Information»(ref-441334-S06852490832011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

HINT: After carrying out the repair, check that the fault has been remedied.

Reinstall the components, reconnect the connectors etc.
Ignition on. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S35876951912011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal too high. Intermittent fault

See Signal too high. Intermittent fault

Ignition off
Check the boost pressure sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Check for damage carefully.

Was a fault detected?

YES Refer to «Verification»(ref-441334-S07108455672011121500000)
NO Refer to «Checking the cable and components»(ref-441334-S07618122442011121500000)

Checking the cable and components

Ignition off. Check the cable between the boost pressure sensor terminal 3 and control module terminal 13 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) . and the cable between boost pressure sensor terminal 2 and ground for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . If no fault is found during the above fault-tracing, try a new boost pressure sensor according to «Replacing the atmospheric pressure sensor»(ref-441335-S15233333552011121500000) if necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) For information about signals, see «Signal specification»(ref-441338-S16642011902011121500000) .

Continue Refer to «Verification»(ref-441334-S07108455672011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reinstall the components, reconnect the connectors etc.
Start the engine
Rev the engine above 4000 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S03660769562011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Ignition off
Check the connector of boost pressure sensor 2 (MAP) for contact resistance and oxidation as described in «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Check especially for damage.

Was a fault detected?

YES Refer to «Verification»(ref-441334-S38202380532011121500000)
NO Refer to «Checking cable and component»(ref-441334-S02629880112011121500000)

Checking cable and component

Ignition off Check the cable between boost pressure sensor 2 (MAP) terminal #3 and control module terminal #13 for short circuit to supply voltage as described in «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) . and the cable between boost pressure sensor 2 (MAP) terminal #2 and ground for open circuit as described in «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . If no fault is detected during the above fault tracing, try a new boost pressure sensor 2 (MAP) as described in «Boost pressure sensor 2, replacing»(ref-441339-S34452999362011121500000) as necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) . For information on signals, see «Signal specification»(ref-441338-S16642011902011121500000) .

Continue Refer to «Verification»(ref-441334-S38202380532011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reinstall the components, reconnect the connectors etc.
Start the engine
Rev the engine above 4000 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S06442616312011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal too high. Permanent fault

See Signal too high. Permanent fault

Ignition off. Check the boost pressure sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S00267239222011121500000) and loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) . Check for damage carefully. Check the signal cable between boost pressure sensor terminal 3 and control module terminal 13. Check the power supply cable between boost pressure sensor terminal 1 and control module terminal 74. Check these cables for an intermittent open-circuit according to «Open-circuit, intermittent faults»(ref-441291-S39448265522011121500000) . HINT: The boost pressure sensor receives 5 V from control module terminal 74. Check the signal cable between boost pressure sensor terminal 3 and control module terminal 13 for an intermittent short-circuit to ground according to «Short-circuit to ground, intermittent faults»(ref-441291-S16169375282011121500000) . Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) For information about signals, see «Signal specification»(ref-441338-S16642011902011121500000) To replace the boost pressure sensor, see «Replacing the atmospheric pressure sensor»(ref-441335-S15233333552011121500000) .

Continue Refer to «Information»(ref-441334-S38788286592011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Ignition off Check the connector of boost pressure sensor 2 (MAP) for contact resistance and oxidation as described in «Contact resistance and oxidation»(ref-441291-S00267239222011121500000) and loose connections as described in «Loose connections (terminals)»(ref-441291-S22081329982011121500000) . Check especially for damage. Check the signal cable between boost pressure sensor 2 (MAP) terminal #3 and control module terminal #13 and the power supply cable between boost pressure sensor 2 (MAP) terminal #1 and control module terminal #74 for intermittent open circuit as described in «Open-circuit, intermittent faults»(ref-441291-S39448265522011121500000) . HINT: Boost pressure sensor 2 (MAP) is supplied 5 V from control module terminal #74. Check the signal cable between boost pressure sensor 2 (MAP) terminal #3 and control module terminal #13 for intermittent short circuit to ground as described in «Short-circuit to ground, intermittent faults»(ref-441291-S16169375282011121500000) . Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) . For information on signals, see «Signal specification»(ref-441338-S16642011902011121500000) . For boost pressure sensor 2 (MAP) replacement, see «Boost pressure sensor 2, replacing»(ref-441339-S34452999362011121500000) .

Continue Refer to «Information»(ref-441334-S12784574232011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal too low. Intermittent fault

See Signal too low. Intermittent fault

Ignition off. Check the boost pressure sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) .

Was a fault detected?

YES Refer to «Verification»(ref-441334-S01824372992011121500000)
NO Refer to «Checking the cable and components»(ref-441334-S12945414632011121500000)

Ignition off. Check the signal cable between boost pressure sensor terminal 3 and control module terminal 13. Check the power supply cable between boost pressure sensor terminal 1 and control module terminal 74. Check these cables for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Check boost pressure sensor terminal 3 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) . HINT: The boost pressure sensor receives 5 V from control module terminal 74. If no fault is found during the above fault-tracing, try a new boost pressure sensor according to «Replacing the atmospheric pressure sensor»(ref-441335-S15233333552011121500000) if necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) For information about signals, see «Signal specification»(ref-441338-S16642011902011121500000) .

Continue Refer to «Verification»(ref-441334-S01824372992011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reinstall the components, reconnect the connectors etc.
Start the engine
Rev the engine above 4000 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S28660417092011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Ignition off Check the connector of boost pressure sensor 2 (MAP) for contact resistance and oxidation as described in «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) .

Was a fault detected?

YES Refer to «Verification»(ref-441334-S34232379572011121500000)
NO Refer to «Checking cable and component»(ref-441334-S12447336462011121500000)

Ignition off Check the signal cable between boost pressure sensor 2 (MAP) terminal #3 and control module terminal #13 and the power supply cable between boost pressure sensor 2 (MAP) terminal #1 and control module terminal #74 for open circuit as described in «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Check boost pressure sensor 2 (MAP) terminal #3 for short circuit to ground as described in «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) . HINT: Boost pressure sensor 2 (MAP) is supplied 5 V from control module terminal #74. If no fault is detected during the above fault tracing, try a new boost pressure sensor 2 (MAP) as described in «Boost pressure sensor 2, replacing»(ref-441339-S34452999362011121500000) as necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) . For information on signals, see «Signal specification»(ref-441338-S16642011902011121500000) .

Continue Refer to «Verification»(ref-441334-S34232379572011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reinstall the components, reconnect the connectors etc.
Start the engine
Rev the engine above 4000 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S41865633992011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal too low. Permanent fault

See Signal too low. Permanent fault

Ignition off. Release the boost pressure control (BPC) valve according to «Checking and adjusting the boost pressure control (BPC) valve on the turbocharger (TC)»(ref-441340-S19636300142011121500000) . Check that the boost pressure control (BPC) valve does not stick in the closed position. Check the turbocharger (TC) according to «Checking the turbocharger (TC)»(ref-461612-S33570863422012040200000) . Check in particular the hoses and the function of the pressure regulator. Remedy as necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) For information about signals, see «Signal specification»(ref-441338-S16642011902011121500000) To replace the boost pressure sensor, see «Replacing the atmospheric pressure sensor»(ref-441335-S15233333552011121500000) .

Continue Refer to «Information»(ref-441334-S28925217372011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Check

Ignition off Release the wastegate as described in «Checking and adjusting the boost pressure control (BPC) valve on the turbocharger (TC)»(ref-441340-S19636300142011121500000) . Check that the wastegate does not seize or get stuck in the closed position. Check the turbocharger as described in «Checking boost pressure with manometer while test driving the car»(ref-441340-S06905798592011121500000) . Especially check the function and hoses of the pressure regulator. Remedy as necessary. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) . For information on signals, see «Signal specification»(ref-441338-S16642011902011121500000) . For boost pressure sensor 2 (MAP) replacement, see «Boost pressure sensor 2, replacing»(ref-441339-S34452999362011121500000) .

Continue Refer to «Information»(ref-441334-S32147909122011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

Checking the boost pressure sensor signal

Ignition on
Read off the boost pressure sensor and atmospheric pressure sensor values
Check that the boost pressure sensor value is within 200 mbar of the atmospheric pressure sensor value. The atmospheric pressure sensor value is used as a reference value for this test. Select one of the following alternatives to continue: The boost pressure sensor value is more than 200 mbar higher than the atmospheric pressure sensor value Refer to «Checking the wiring»(ref-441334-S03488064402011121500000) The boost pressure sensor value is approximately the same as the atmospheric pressure sensor value. Refer to «Checking the connectors and the boost pressure system»(ref-441334-S41798277882011121500000)

Checking the connectors and the boost pressure system

Ignition off. Check the boost pressure sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Release the boost pressure control (BPC) valve according to «Checking and adjusting the boost pressure control (BPC) valve on the turbocharger (TC)»(ref-441340-S19636300142011121500000) . Check that the boost pressure control (BPC) valve does not stick in the closed position. Check the turbocharger (TC) according to «Checking the turbocharger (TC)»(ref-461612-S33570863422012040200000) . Check in particular the hoses and the function of the pressure regulator. Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S42037158142011121500000)

Reinstall the connector
Ignition on. Read off the boost pressure sensor and atmospheric pressure sensor values. Check that the boost pressure sensor value does not deviate from the atmospheric pressure sensor value by more than 200 mbar. The atmospheric pressure sensor value is used as a reference value for this test. Try a new boost pressure sensor if the boost pressure sensor value does not correspond to the atmospheric pressure sensor value to an accuracy of 200 mbar.

Continue Refer to «Verification»(ref-441334-S42037158142011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Test drive the car with changing throttle opening and at constant throttle opening. This will ensure that the boost pressure system operates throughout the entire range
Connect the VIDA station
Ignition on
Check if the diagnostic trouble code (DTC) status has changed to intermittent. If it has, the fault has been remedied.

Has the status of the diagnostic trouble code (DTC) status changed?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S16706237122011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Ignition on
Activate the readout of boost pressure sensor values.
Check that the value from boost pressure sensor 2 (MAP) does not deviate from that of boost pressure sensor 1 (BOP) by more than 200 mbar. Boost pressure sensor 1 (BOP) is used as the reference value in this test. Select one of the following alternatives to continue: The value of boost pressure sensor 2 (MAP) deviates more than 200 mbar from the value of boost pressure sensor 1 (BOP). Refer to «Replacing the component»(ref-441334-S06010621822011121500000) The values of the boost pressure sensors are about the same. Refer to «Checking connectors and the boost pressure system»(ref-441334-S41874882022011121500000)

Checking connectors and the boost pressure system

Ignition off Check the connector of boost pressure sensor 1 (MAP) for contact resistance and oxidation as described in «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Release the wastegate as described in «Checking and adjusting the boost pressure control (BPC) valve on the turbocharger (TC)»(ref-441340-S19636300142011121500000) . Check that the wastegate does not seize or get stuck in the closed position. Check the turbocharger as described in «Checking boost pressure with manometer while test driving the car»(ref-441340-S06905798592011121500000) . Especially check the function and hoses of the pressure regulator. If no fault is detected during the above fault tracing, try a new boost pressure sensor 2 (MAP). Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S20876809512011121500000)

Ignition off
Check the connector of boost pressure sensor 2 (MAP) and the control module for contact resistance and oxidation as described in «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . If no faults are found on the connectors, try a new boost pressure sensor 2 (MAP). Other information For boost pressure sensor 2 (MAP) replacement, see «Boost pressure sensor 2, replacing»(ref-441339-S34452999362011121500000) .

Continue Refer to «Verification»(ref-441334-S23631470592011121500000)

Restore the connectors.
Ignition on Activate the readout of boost pressure sensor and atmospheric pressure values. Check that the value from boost pressure sensor does not deviate from that of the atmospheric pressure sensor by more than 200 mbar. The atmospheric pressure sensor is used as the reference value in this test. If the value of the boost pressure sensor is not within 200 mbar of the atmospheric pressure sensor, try a new boost pressure sensor. Other information For boost pressure sensor replacement, see «Boost pressure sensor 2, replacing»(ref-441339-S34452999362011121500000) .

Continue Refer to «Verification»(ref-441334-S23631470592011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Test drive the car with changing throttle opening and at constant throttle opening. This will ensure that the boost pressure system operates throughout the entire range
Connect the VIDA station
Ignition on
Check if the diagnostic trouble code (DTC) status has changed to intermittent. If it has, the fault has been remedied.

Has the status of the diagnostic trouble code (DTC) status changed?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S20190376972011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reinstall the components, reconnect the connectors etc.
Ignition on. Read off boost pressure sensor 2 (MAP sensor) and boost pressure sensor 1 Check that the boost pressure valve values are the same. Check that the boost pressure sensor values are within 200 mbar of each other

Are the values for the boost pressure sensors approximately the same?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S20190376972011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

Ignition off Check the connectors of the boost pressure sensor and the engine control module (ECM) for contact resistance and oxidation as described in «Contact resistance and oxidation»(ref-441291-S00267239222011121500000) and loose connections as described in «Loose connections (terminals)»(ref-441291-S22081329982011121500000) . Check especially for damage. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) . For information on signals, see «Signal specification»(ref-441338-S16642011902011121500000) . For boost pressure sensor replacement, see «Boost pressure sensor 2, replacing»(ref-441339-S34452999362011121500000) .

Continue Refer to «Information»(ref-441334-S24049812822011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Ignition off Check the connectors of boost pressure sensor 2 (MAP) and the engine control module for contact resistance and oxidation as described in «Contact resistance and oxidation»(ref-441291-S00267239222011121500000) and for loose connections as described in «Loose connections (terminals)»(ref-441291-S22081329982011121500000) . Check especially for damage. Other information: To connect the breakout box, see «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) . For information on signals, see «Signal specification»(ref-441338-S16642011902011121500000) . For boost pressure sensor replacement, see «Boost pressure sensor 2, replacing»(ref-441339-S34452999362011121500000) .

Continue Refer to «Information»(ref-441334-S10153693702011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

Reinstall the connector
Ignition on. Read off the boost pressure and atmospheric pressure. Check that the boost pressure sensor value does not deviate from the atmospheric pressure sensor value by more than 200 mbar. The atmospheric pressure sensor value is used as a reference value for this test.

Is the boost pressure sensor value within 200 mbar of the atmospheric pressure sensor value?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Checking the wiring»(ref-441334-S00848239802011121500000)

Reinstall the connector
Ignition on. Read off the boost pressure and atmospheric pressure. Check that the boost pressure sensor value does not deviate from the atmospheric pressure sensor value by more than 200 mbar. The atmospheric pressure sensor value is used as a reference value for this test. Try a new boost pressure sensor if the boost pressure sensor value does not correspond to the atmospheric pressure sensor value.

Continue Refer to «Verification»(ref-441334-S25800445932011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reinstall the components, reconnect the connectors etc.
Ignition on. Read off the boost pressure sensor and atmospheric pressure sensor values by clicking on the VCT-2000 symbol Compare the boost pressure sensor and atmospheric pressure sensor values. The atmospheric pressure sensor value is used as a reference value for this test

Is the boost pressure sensor value correct?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S17380627902011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking boost pressure sensor signals

Restore the connectors.
Ignition on Activate the readout of boost pressure sensor values. Check that the value from boost pressure sensor 2 (MAP) does not deviate from that of boost pressure sensor 1 (BOP) by more than 200 mbar. Boost pressure sensor 1 (BOP) is used as the reference value in this test.

Are the values of the boost pressure sensors within 200 mbar of one another?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Checking the boost pressure sensor signal»(ref-441334-S17089457942011121500000)

If the values of the boost pressure sensors do not agree, try a new boost pressure sensor 2 (MAP)

Other information

For boost pressure sensor 2 (MAP) replacement, see «Boost pressure sensor 2, replacing»(ref-441339-S34452999362011121500000) .

Continue Refer to «Verification»(ref-441334-S30245469192011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reinstall the components, reconnect the connectors etc.
Ignition on. Read off boost pressure sensor 2 (MAP sensor) and boost pressure sensor 1 Check that the boost pressure valve values are the same. Check that the boost pressure sensor values are within 200 mbar of each other

Are the values for the boost pressure sensors approximately the same?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S36818940842011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

Checking the connector

Ignition off
Intake air temperature (IAT) sensor connector disconnected. Check the connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy as necessary.

Were any faults found?

YES Refer to «Verification»(ref-441334-S05660983492011121500000)
NO Refer to «Checking the ground lead»(ref-441334-S06097521262011121500000)

Connect an ohmmeter between the intake air temperature (IAT) sensor connector terminal #2 (control module side) and ground.

The ohmmeter should read approximately 0 ohms.

OK Refer to «Checking the signal cable»(ref-441334-S21042247712011121500000)
NOT OK Refer to «Checking wiring and terminals»(ref-441334-S17214351862011121500000)

Scheme 72

Ignition on
Disconnect the intake air temperature sensor connector. Connect a voltmeter between the intake air temperature (IAT) sensor connector terminal #1 (control module side) and ground. The voltmeter should read approximately 5 V. more than 5 V Refer to «Checking wiring and terminals»(ref-441334-S41897181662011121500000) approximately 5 V Refer to «Defective intake air temperature (IAT) sensor»(ref-441334-S29987334882011121500000) 0 V Refer to «Checking wiring and terminals»(ref-441334-S17214351862011121500000)

Defective intake air temperature (IAT) sensor

Try a new intake air temperature (IAT) sensor according to Replacing the intake air temperature sensor .

Continue Refer to «Verification»(ref-441334-S05660983492011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reconnect the connectors, reinstall components etc.
Start the engine. Let the engine idle. Read off diagnostic trouble codes (DTCs). Check that the status of the diagnostic trouble code (DTC) has changed to intermittent. The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S12202420042011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

Ignition off
Intake air temperature (IAT) sensor connector disconnected. Connect an ohmmeter between intake air temperature (IAT) sensor connector terminal #1 (control module side) and ground.

The ohmmeter should read 3,000-4,500 ohms.

OK Refer to «Defective intake air temperature (IAT) sensor»(ref-441334-S19708322572011121500000)
NOT OK Refer to «Checking the cable»(ref-441334-S42087636532011121500000)

Try a new intake air temperature (IAT) sensor according to Replacing the intake air temperature sensor .

Continue Refer to «Verification»(ref-441334-S27242869962011121500000)

Checking the cable

Check the cable between intake air temperature (IAT) sensor connector terminal #1 and engine control module (ECM) terminal #48. Check for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S27242869962011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reconnect the connectors, reinstall components etc.
Start the engine. Let the engine idle. Read off diagnostic trouble codes (DTCs). Check that the status of the diagnostic trouble code (DTC) has changed to intermittent. The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S13072186172011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Faulty signal. Intermittent fault

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See Faulty signal. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

Checking the voltage

Ignition off
Disconnect the mass air flow (MAF) sensor connector
Ignition on. Connect a voltmeter between mass air flow (MAF) sensor connector terminal #2 (control module side) and ground.

The voltmeter should read 0 V.

OK Refer to «Checking the ground lead»(ref-441334-S00108139392011121500000)
NOT OK Refer to «Checking wiring and terminals»(ref-441334-S24290382372011121500000)

Connect a voltmeter between mass air flow (MAF) sensor connector terminal #1 (engine control module (ECM) side) and ground.

The ohmmeter should read approximately 0 ohms.

OK Refer to «Defective mass air flow (MAF) sensor»(ref-441334-S39798432102011121500000)
NOT OK Refer to «Checking wiring and terminals»(ref-441334-S08491188342011121500000)

Defective mass air flow (MAF) sensor

Try a new mass air flow (MAF) sensor according to Replacing the mass air flow (MAF) sensor .

Continue Refer to «Verification»(ref-441334-S20993812952011121500000)

Ignition off
Reconnect the connectors, reinstall components etc.
Connect VCT2000
Start the engine. Let the engine run until it reaches operating temperature. Read off the MAF parameter. The value should be 8-13 kg/h when idling. It should increase with throttle opening.

Is the value OK?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S29968355442011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

Ignition off
Disconnect the mass air flow (MAF) sensor connector. Check the connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy as necessary.

Was a fault detected?

YES Refer to «Verification»(ref-441334-S05120824552011121500000)
NO Refer to «Checking the power cable»(ref-441334-S41721364132011121500000)

Ignition off
Mass air flow (MAF) sensor connector disconnected
Ignition on. Connect a voltmeter between mass air flow (MAF) sensor connector terminal #3 (control module side) and ground.

The voltmeter must display battery voltage for 2 seconds immediately after the ignition is switched on.

OK Refer to «Checking the signal cable»(ref-441334-S29853641562011121500000)
NOT OK Refer to «Checking wiring and terminals»(ref-441334-S03874073642011121500000)

Ignition off. Check the cable between mass air flow (MAF) sensor connector terminal #2 (engine control module (ECM) side) and engine control module (ECM) terminal #16. Check for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Check for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

Was a fault detected?

YES Refer to «Verification»(ref-441334-S05120824552011121500000)
NO Refer to «Checking intake system»(ref-441334-S42380774592011121500000)

Try a new mass air flow (MAF) sensor according to Replacing the mass air flow (MAF) sensor .

Continue Refer to «Verification»(ref-441334-S05120824552011121500000)

Ignition off
Reconnect the connectors, reinstall components etc.
Connect VCT2000
Start the engine. Let the engine run until it reaches operating temperature. Read off the MAFH parameter. The value should be 8-13 kg/h when idling. It should increase with throttle opening.

Is the value OK?

YES OKAY: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S14582913772011121500000)

Checking intake system

Check the intake system for air leakage according to intake system/leak test .

Was a fault detected?

YES Refer to «Verification»(ref-441334-S05120824552011121500000)
NO Refer to «Defective mass air flow (MAF) sensor»(ref-441334-S26705308342011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Faulty signal. Intermittent fault

Checking connectors and components

HINT: If there is a diagnostic trouble code (DTC) for the boost pressure sensor, fault tracing the diagnostic trouble code (DTC) for the boost pressure sensor should be handled first.

Ignition off Check the connector of the mass air flow sensor, boost pressure sensor, system relay and engine control module (ECM) for contact resistance and oxidation. Check the induction system for air leaks. HINT: The diagnostic trouble code (DTC) can be caused by a damaged boost pressure sensor 2 (MAP) or mass air flow sensor. Remedy as necessary. Other information See «Engine control module (ECM), replacing»(ref-441335-S25586099582011121500000) . See «Connecting the breakout box. EMS 2000»(ref-441291-S13587040122011121500000) . See «Signal specification»(ref-441338-S16642011902011121500000) . See «Boost pressure sensor 1, replacing»(ref-441339-S06643094402011121500000) . See «Replacing the mass air flow (MAF) sensor»(ref-441341-S07422979692011121500000) . See «Contents»(ref-441289-S02135994792011121500000)

Continue Refer to «Verification»(ref-441334-S34487587432011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reinstall the components, reconnect the connectors etc.
Start the engine
Rev the engine above 4000 RPM twice. Check whether the diagnostic trouble code (DTC) status changes to intermittent. If the fault has been remedied, the diagnostic trouble code (DTC) status should have changed to intermittent

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S16581963022011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

Ignition off
Engine coolant temperature (ECT) sensor connector disconnected. Check the connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy as necessary.

Were any faults found?

YES Refer to «Verification»(ref-441334-S28960103502011121500000)
NO Refer to «Checking the ground lead»(ref-441334-S39133346172011121500000)

Connect an ohmmeter between engine coolant temperature (ECT) sensor connector terminal #2 (control module side) and ground.

The ohmmeter should read approximately 0 ohms.

OK Refer to «Checking the signal cable»(ref-441334-S04817076652011121500000)
NOT OK Refer to «Checking wiring and terminals»(ref-441334-S35656026392011121500000)

Ignition on
Disconnect the intake air temperature sensor connector. Connect a voltmeter between engine coolant temperature (ECT) sensor connector terminal #1 (control module side) and ground. The voltmeter should read approximately 5 V. more than 5 V Refer to «Checking wiring and terminals»(ref-441334-S36962466862011121500000) approximately 5 V Refer to «Defective engine coolant temperature (ECT) sensor»(ref-441334-S35245142872011121500000) 0 V Refer to «Checking wiring and terminals»(ref-441334-S35656026392011121500000)

Defective engine coolant temperature (ECT) sensor

Try a new engine coolant temperature (ECT) sensor according to Replacing the engine coolant temperature (ECT) sensor .

Continue Refer to «Verification»(ref-441334-S28960103502011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reconnect the connectors, reinstall components etc.
Start the engine. Let the engine idle. Read off diagnostic trouble codes (DTCs). Check that the status of the diagnostic trouble code (DTC) has changed to intermittent. The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S31001026042011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

Ignition off
Engine coolant temperature (ECT) sensor connector disconnected. Connect an ohmmeter between engine coolant temperature (ECT) sensor connector terminal #1 (control module side) and ground.

The ohmmeter must read more than 1000 ohms.

OK Refer to «Defective engine coolant temperature (ECT) sensor»(ref-441334-S36962336422011121500000)
NOT OK Refer to «Checking the cable»(ref-441334-S33344164932011121500000)

Try a new engine coolant temperature (ECT) sensor according to Replacing the engine coolant temperature (ECT) sensor .

Continue Refer to «Verification»(ref-441334-S22174065552011121500000)

Check the cable between engine coolant temperature sensor connector terminal #1 and engine control module (ECM) terminal #47. Check for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary.

Continue Refer to «Verification»(ref-441334-S22174065552011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Reconnect the connectors, reinstall components etc.
Start the engine. Let the engine idle. Read off diagnostic trouble codes (DTCs). Check that the status of the diagnostic trouble code (DTC) has changed to intermittent. The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «Information»(ref-441334-S13434526612011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

Dynamic Stability Assist (Dsa) & Engine Control Module (ECM) Diagnostic Trouble Codes: Other Volvo V40 I рестайлинг

EEPROM memory fault. Permanent fault

EEPROM memory fault. Intermittent fault

Fault-tracing information

EEPROM memory fault

Checking the signal cable

Replacing the component

Checking for a short-circuit

Scheme 50

Scheme 51

Verification

Checking the DSA switch

Signal too low

Faulty signal. Intermittent fault

Checking the DSA warning lamp with the ignition off

Scheme 52

Scheme 53

Checking the other warning lamps in the combined instrument panel

Checking the combined instrument panel

Checking the DSA warning lamp

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Checking the bulb

Checking for an open-circuit

Scheme 59

Checking the signal cable for a short-circuit to supply voltage

Fault cause and checking for contact resistance and oxidation

Checking the signal from the combined instrument panel

Checking the resistance of the signal cable

Faulty signal. Permanent fault

Checking the resistance of the signal cable (continued)

Scheme 60

Scheme 61

Scheme 62

Checking the stop lamp switch

Checking the status of the stop lamp

Checking and adjusting the stop lamp switch

Fault causes and adjusting the stop lamp switch

Scheme 63

Scheme 64

Signal too high

Checking a voltage drop in the signal cable

Checking a voltage drop in the stop (brake) lamp switch

Checking for contact resistance and oxidation

Signal missing. Intermittent fault

Checking the resistance in the signal cable

Checking the signal cable resistance to ground

Signal missing. Permanent fault

Faulty signal

Checking the DSA control module

Information concerning B4184S and B4204S

Scheme 65

Reinstall

Replacing the engine control module (ECM)

Scheme 66

Scheme 67

Selecting the engine management system

Connecting the breakout box. ABS

Scheme 68

Checking the power cable

Checking injectors

Scheme 69

Defective injector

Checking cables

Scheme 70

Checking the terminal

Scheme 71

Checking the power supply

Defective canister purge (CP) valve

Check canister purge (CP) valve

Checking the ground lead

Defective atmospheric pressure sensor

Checking the connectors

Signal too high. Intermittent fault

Checking the cable and components

Checking cable and component

Signal too high. Permanent fault
