SPECIFICATIONS
| WARNING | Vehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See appropriate AIR BAG RESTRAINT SYSTEMS article in RESTRAINTS. |
| Application | Specification |
|---|
| Compressor Type | Zexel DKS-17CH 6-Cyl. |
| Compressor Belt Tension | (1) |
| Compressor Oil Capacity | (2) 6.0 ozs. |
| Refrigerant (R-134a) Capacity | 35.2 ozs. |
| System Operating Pressures (3) |
| High Side | 406-464 psi (28.0-32.0 kg/cm 2 ) |
| Low Side | 25.4-32.6 psi (1.75-2.25 kg/cm 2 ) |
| (1) Belt tension is maintained by automatic belt tensioner. (2) Use PAG Oil (Part No. 11 61 407-0). (3) Pressure switch cut-out points. |
| (1) | Belt tension is maintained by automatic belt tensioner. |
| (2) | Use PAG Oil (Part No. 11 61 407-0). |
| (3) | Pressure switch cut-out points. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Clutch Plate Bolt | 10 (13) |
| Center Console Screws | 18 (25) |
| Compressor Pipe Fittings | 18 (25) |
| Compressor-To-"A" Pillar Bolts | 37 (50) |
| Condenser Bracket Bolts | 18 (25) |
| INCH Lbs. (N.m) |
| A/C Pressure Sensor | 84 (10) |
| Condenser Fittings | 84 (10) |
| Expansion Valve | 84 (10) |
| Receiver-Drier Fittings | 84 (10) |
Automatic A/C-Heater System Wiring Diagram (2000 S80 - 1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (2000 S80 - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000 S80 - 2 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (2000 S80 - 2 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 S60, S80 & V70 - 1 Of 2). Scheme 3
Scheme 3: Automatic A/C-Heater System Wiring Diagram (2001 S60, S80 & V70 - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 S60, S80 & V70 - 2 Of 2). Scheme 4
Scheme 4: Automatic A/C-Heater System Wiring Diagram (2001 S60, S80 & V70 - 2 Of 2)
