Steering Wheel Lock & Module - Replacing: Other Volvo S60 I

Steering Column 9 illustrations ~659 words

Steering Wheel Lock, Replacing

Note. As the graphics in this service information are used for different model years and/or models, some variation may occur. However, the essential information in the graphics is always correct.

Preparation

Pull down the steering wheel adjustment lever and pull up the steering wheel to the uppermost position.

Scheme 17

Scheme 17: Removing the Steering Column Covers

Remove the ignition key (1).

Remove the three screws (2).

Press in the snap fasteners and remove the lower steering column cover (3).

Pull up the upper steering column cover (4).

Scheme 18

Scheme 18: Removing the Steering Wheel Lock Unit

Disconnect the connectors.

Press in the snap fastener and remove the steering wheel lock unit.

Scheme 19

Scheme 19: Removing the Mechanical Cable For the Ignition Switch Interlock (Only Applies To Cars With Automatic

Remove the ignition switch interlock cable.

Move the ignition key to position I.

Press up the lock facing and pull out the cable.

Scheme 20

Scheme 20: Removing the Connectors On the Steering Wheel Module (SWM)

Disconnect the connectors on the gear selector assembly.

Scheme 21

Scheme 21: Removing the Steering Wheel Lock

Drill out the security screws holding the steering wheel lock.

HINT: Use an angle drill.

Remove the steering wheel lock.

Scheme 22

Scheme 22: Installing the Steering Wheel Lock

Insert the ignition key in the new steering wheel lock.

Check that the key is in position I and that the locking lug on the steering wheel lock is down.

Install the new steering wheel lock against the cap on the steering column.

Install the new security screws.

Tighten the security screws until the screw heads break off.

Installing the Connectors On the Steering Wheel Module (SWM)

Install the connectors on the gear selector assembly.

Installing the Mechanical Cable For the Ignition Switch Interlock (Only Applies To Cars With Automatic Transmissions)

Set the gear selector lever to P position.

Move the ignition key to position I.

Press the cable into the ignition switch and feel to see that it sits correctly.

Remove the ignition key and check that the gear selector lever is blocked in P position.

Scheme 23

Scheme 23: Installing the Steering Wheel Lock Unit

Remove the ignition key.

Install

  1. the connectors
  2. the steering lock module.

Scheme 24

Scheme 24: Installing the Steering Column Covers

Install the lower steering column cover.

Note. Ensure that the no cables are trapped.

Install the screws for the lower steering column cover.

Fold down the upper steering column cover and press the snap fasteners into place in the lower steering column cover.

Note. Ensure that the gaiters around the control levers are correctly positioned against the column covers.

Finishing

Adjust the steering wheel setting and lock the steering wheel adjustment lever.

Use VIDA vehicle communication to check that no diagnostic trouble codes have been stored during the work.

Ordering Software/Keys

Note. To enable adding a key, a key and software must be ordered. Only software must be ordered to enable erasing a key.

Order a key and/or software. See 8691258 .

Note. When key and/or software is available, then programming/erasing can be performed.

The function must be checked if a new key has been added.

Steering Wheel Module (SWM), Replacing

  1. See «Steering Wheel Module (SWM), Replacing»(ref-415265-S02806378412011081500000) .

Preparations

  1. Lower the lever for adjustment of steering wheel position and pull up the steering wheel to its highest position.

Follow-on work

  1. Adjust the position of the steering wheel and close the locking device for adjustment of the steering wheel position.

Ordering software/key

Note. To install the key, the key and the software must be ordered. To erase the key, only the software needs to be ordered.

Order the key and/or software as described in 9438428 .

Programming the key in the control unit

Note. If the key and/or software are accessible, programming/erasing can be done.

If a new key has been installed, check the function.

Use VIDA vehicle communication to check that no diagnostic trouble codes have been stored during the work.

Doing a function check

  1. Test-start the engine.

Stop Lamp High Mounted, Replacing

  1. See «Stop lamp, rear windshield, replacing»(ref-415246-S38490612942011081500000) .

Scheme 25

Scheme 25: Stop Lamp Rear Windshield

The stop lamp can only be replaced as a complete unit.

  1. Remove the panel for the tailgate. See «Lower Tailgate Panel»(ref-445797-S33444366472012010600000)
  2. Remove the clip
  3. Disconnect the connector
  4. Slide the lamp to the left and remove it.
