Induction Pipe - Removal & Installation: Overview Volvo S60 I

Operation Number(s): 25102-2

Perform draining Fuel system pressure release

Perform draining COOLING SYSTEM - DRAINING/FILLING

Disconnect power steering pump Power steering pump

Scheme 531

Scheme 532

Scheme 533

Scheme 534

Scheme 535

Scheme 536

Scheme 537

Scheme 538

Install pump power steering Power steering pump

Perform filling COOLING SYSTEM - DRAINING/FILLING

Scheme 539

1. Install lifting beam «9995716»(ref-403953-S41765249862011061000000). Install lifting hooks «9995460»(ref-403953-S32932431362011061000000)
2. Lift the engine to relieve the load on the engine pads.

Scheme 540

Slacken off the 5 hose clamps for all the charge air pipes.

Remove the 2 screws from the charge air pipe on the intake manifold.

Separate all the charge air pipe. Leave the pipes lying on the spark plug cover.

Scheme 541

Remove

1. the screws for the spark plug cover
2. the cover
3. the ground strip screw.

Applies only to turbocharged engines

Remove the screws.

Lift up the delivery lines. Remove the spark plug cover.

Scheme 542

Remove the 2 screws at the engine mounting.

Install lifting lug 9995717.

See also:
• Fuel system pressure release
• COOLING SYSTEM - DRAINING/FILLING
