Installing the charge air pipe (only applies to 6 cylinder turbocharged engines)

Connect all the charge air pipes to each other.

Tighten the hose clamps.

Install the screws for the charge air pipe in the intake manifold. Tighten to 10 Nm .

Particle filter, replacing

Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

Scheme 543

Remove

1. the rear temperature sensor
2. the particle filter hoses.

Scheme 544

Remove 2 M8 nuts from the rear edge of the particle filter.

Scheme 545

HINT: Move the rear of the particle filter down to access the upper nut at the front joint.

Remove the 3 M8 nuts from the rear edge of the particle filter.

Unhook the particle filter from the rubber mountings.

Remove the particle filter and scrap the gaskets.

Installing the particle filter

Install a new gasket.

Reposition the filter in the rubber mountings.

Install

1. the 3 new M8 nuts. Tighten.
2. the particle filter hoses using new clips
3. the temperature sensor. Tighten according to appropriate service information.

Install

1. a new gasket at the joint between the particle filter and the exhaust system
2. the 2 new M8 nuts. Tighten.
