Aligning the front frame member
Left-hand side
Scheme 129
Volvo have developed two traction mountings to facilitate aligning in the event of damage to the front frame member on the 850, S/V/C70, S80, V70 2000-, and S60.
Left-hand side: 999 5798
Right-hand side: 999 5797
The tools are designed so that they can be forced into the end of a very badly deformed member which ensures a good mounting without the risk of deformation.
Right-hand side
Scheme 130
Scheme 131
Volvo have developed a special tool to facilitate aligning in the event of damage to the frame member when mounting the engine frame on the front of the 850, S/V/C70, S80, V70 2000-, and S60. 999 5799
The tool is designed to be screwed into the engine frame mounting. After that the frame can be pulled in any direction.
Scheme 132
Volvo have developed a traction mounting to facilitate aligning in the event of damage to the rear frame member damage on the 850 and S/V/C70. 999 7000
The traction mounting screws through the existing member which ensures a good mounting without the risk of deformation.
On five door models the side member extension must be removed in order to install the tool.
Aligning the rear frame member
Left and right hand side
Scheme 133
Volvo have developed a traction mounting to facilitate aligning in the event of damage to the rear frame member on the S60, V70 2000-, and S80.
999 7001
The traction mounting screws through the existing member which ensures a good mounting without the risk of deformation.
