FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|---|---|
| Belt Tensioner to Cylinder Head Bolt | 23 | |
| Bracket to Cover Bolt | 8 | |
| Camshaft Adjuster to Camshaft Bolt (1) | 60 + 90° | |
| Camshaft Adjustment Valve to Control Housing Bolt | 3.8 | |
| Cover to Cylinder Head Bolt | M6 | 8 |
| Chain Tensioner to Cover | 40 | |
| Chain Tensioner with Tensioning Rail to Cylinder Block Bolt | 8 | |
| Control Housing to Cylinder Head Bolt (2) | 8 | |
| Cylinder Head Cover to Cylinder Head Bolt/Nut | 10 | |
| Fuel Line Bracket to Cylinder Head Cover Bolt | ||
| Guide Rail Pin (Without Collar) to Cylinder Block | 10 | |
| Heat Shield to Exhaust Manifold Bolt | 23 | |
| Intake Manifold to Cylinder Head Bolt | 15 | |
| Intake Manifold Support to Intake Manifold Bolt | 20 | |
| Lifting Eye to Cylinder Head Bolt | 23 | |
| Oil Dipstick Guide Tube to Intake Manifold Bolt | 5 | |
| Sealing Flange to Cover Bolt | M8 | 23 |
| Sprocket to Intermediate Shaft Bolt (1) | 60 + 90° | |
| Wiring Route to Cover Bolt/Stud Bolt | 8 | |
| Wiring Harness Bracket to Cover Bolt | 8 | |
| Wiring Harness Bracket/Coolant Thermostat Housing to Cover Bolt | 8 | |
| (1) Always replace (2) Use liquid locking fluid D 000 600 A2 to install | ||
| (1) | Always replace |
| (2) | Use liquid locking fluid D 000 600 A2 to install |
Cylinder Head Bolt Tightening Sequence and Specification
Scheme 319
Note. The longer cylinder head bolts must be inserted in the middle holes of the cylinder head.
Tighten the cylinder head bolts in the sequence specified -1 through 20-, starting from the inside and working toward the outside, as follows
Tighten all the bolts to 30 Nm.
Then, tighten all the bolts to 50 Nm.
Tighten all bolts an additional 90° (1/4) using a ratchet.
Afterwards, tighten all the bolts again an additional 90° (1/4) turn, using the ratchet.
Camshaft Bearing Cap Nut Tightening Sequence and Specification
Scheme 320
A - Intake Camshaft
Install and tighten the nuts for bearing caps 5 and 9 alternately and in a diagonal sequence to 5 Nm + an additional 45° (1/8) turn.
Install and tighten the nuts for bearing caps 1 and 13 to 5 Nm + an additional 45° (1/8) turn.
Install and tighten the nuts for bearing cap 7 to 5 Nm + an additional 45° (1/8) turn.
Install and tighten the nuts for bearing caps 3 and 11 to 5 Nm + an additional 45° (1/8) turn.
B - Exhaust Camshaft
Install and tighten the nuts for bearing caps 6 and 10 alternately and in a diagonal sequence to 5 Nm + an additional 45° (1/8) turn.
Install and tighten the nuts for bearing caps 2 and 14 to 5 Nm + an additional 45° (1/8) turn.
Install and tighten the nuts for bearing cap 8 to 5 Nm + an additional 45° (1/8) turn.
Install and tighten the nuts for bearing caps 4 and 12 to 5 Nm + an additional 45° (1/8) turn.
