VIBRATION DAMPER SHAFT SEAL

Special tools and workshop equipment required

1. Thrust Piece -T10354
2. Pulling Hook -T20143/2

Removing

Remove the vibration damper. Refer to VIBRATION DAMPER .

Install the thrust piece -T10368-.

Remove the shaft seal using the pulling hook -T20143/2-.

Installing

1. Tightening specifications, refer to «RIBBED BELT OVERVIEW»(ref-475539-S16564343712012052300000) .

Clean the running and sealing surface.

Remove the thrust piece -T10368-.

Pull the seal -arrow- in all the way using the thrust piece -T10354- and the vibration damper bolt.

Scheme 230

Note. Replace the vibration damper bolt Replace the O-ring

The rest of the installation is basically a reverse of the removal sequence.
